Philips 20DV6942-37 User Manual

User Manual

20DV6942/37

TV/DVD

Thank you for choosing Philips.

Need help fast?

Read your User Manual first for quick tips

that make using your Philips product more enjoyable. If you have read your instructions and still need assistance you may access our

online help at www.p4c.philips.com or

call 1-800-531-0039 while with your product.

8670 000 20966

Model No.: Serial No.:

PANEL INDEX

Panel

Subject Panel No.

Basic Antenna/Cable TV Connections . . .1 Connecting Other Equipment to the

TV/DVD . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting the TV/DVD

to Other Systems . . . . . . . . . . . . . . . . . .3

Remote Control . . . . . . . . . . . . . . . . . .4-5

Basic Features . . . . . . . . . . . . . . . . . . . . .6

Programming TV Channels . . . . . . . . . . . .7

Skipping Channels, Favorite Channels . . .8

Language, Clock . . . . . . . . . . . . . . . . . . . .9

On Time, Off Time . . . . . . . . . . . . . . . . .10

Picture, SmartTimer . . . . . . . . . . . . . . . .11

Sound, MTS . . . . . . . . . . . . . . . . . . . . . .12

Closed Captions, SleepTimer . . . . . . . . .13

Picture, Sound Effects . . . . . . . . . . . . . .14

AutoLock

Secret Code . . . . . . . . . . . .15

Subject Panel No.

CH Lock . . . . . . . . . . . . . . . . . . . . . . . .16

Master Enable, MPAA Ratings . . . . . . . .17

TV Parental Guidelines . . . . . . . . . . . . .18

Canadian English or French Ratings . . . .19

General Disc Information . . . . . . . . . . .20

DVD Features . . . . . . . . . . . . . . . . . .21-23

MP3/JPEG Playback . . . . . . . . . . . . . . . .24

Search Mode . . . . . . . . . . . . . . . . . . . . .25

DVD General Setup . . . . . . . . . . . . . . . .26

DVD Analog Audio Setup,

DVD Video Setup . . . . . . . . . . . . . . . . .27

Digital Setup . . . . . . . . . . . . . . . . . . . . .28

DVD Preferences . . . . . . . . . . . . . . . . . .29

DVD Parental Control . . . . . . . . . . . . . .30

Troubleshooting . . . . . . . . . . . . . . . . . . .31

Philips Limited Warranty . . . . . . . . . . . .32

Side 1

Side 2

PANEL LAYOUT

Sequence

and

Panel Index

COVER

MODEL REGISTRATION INFORMATION

SAFETY

INFO

PANEL

Return your Product Registration Card today

to get the very most from your purchase.

Congratulations on your purchase, and welcome to the “family!”

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS.You’ve selected one of the best-built, bestbacked products available today.We’ll do everything in our power to keep you happy with your purchase for many years to come. As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network. Most importantly, you can count on our uncompromising commitment to your total satisfaction.All of this is our way of saying welcome - and thanks for investing in a PHILIPS product.

P.S. To get the most from your PHILIPS purchase, be sure to complete and return your Product Registration Card at once.

Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once to ensure:

Know these

safetysymbols

This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: To reduce the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture, and objects fillled with liquids, such as vases, should not be placed on this apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

*Proof of Purchase

Returning the enclosed card guarantees that your date of purchase will be on file, so no additional paperwork will be required from you to obtain warranty service.

*Product Safety Notification

By registering your product, you'll receive notification directly from the manufacturer - in the rare case of a product recall or safety defect.

*Additional Benefits of Product Ownership

Registering your product guarantees that you'll receive all of the privileges to which you're entitled, including special money-saving offers.

t s

Visit our World Wide Web Site at http://www.philips.com

IMPORTANT SAFETY INSTRUCTIONS

Read before operating equipment

Note to the CATV system installer: This

reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building,as close to the point of cable entry as practical.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings. Install

in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves,or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.A polarized plug has two blades with one wider than the other.A grounding type plug has two blades and a third grounding prong.The wide blade or third prong are provided for your safety.When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table

specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into apparatus, the apparatus has been exposed to rain or moisture, does not operate normally,or has been dropped.

15. This product may contain lead and mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org

16. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power supply cord or the plug has been dam-

aged; or

B. Objects have fallen, or liquid has been spilled into

the appliance; or

C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally

or exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure

damaged.

17. Tilt/Stability - All televisions must comply with recommended international global safety standards for tilt and stability properties of its cabinet design.

• Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet which could ultimately overturn the product.

• Also, do not endanger yourself, or children,by placing electronic equipment/toys on the top of the cabinet. Such items could unsuspectingly fall from the top of the set and cause product damage and/or personal injury.

18. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

19. Power Lines - An outdoor antenna should be located away from power lines.

20. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure below.

21. Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

22. Battery Usage CAUTION - To prevent battery leakage that may result in bodily injury, property damage, or damage to the unit:

• Install all batteries correctly, with + and - aligned as marked on the unit.

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries when the unit is not used for a long time.

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

(NEC ART 250, PART H)

BASIC A

NTENNA/CABLE TV CONNECTIONS

Your Cable Box/Satellite Receiver may have Audio/Video Out jacks instead of a single Antenna Out jack (RF coaxial or 75 ohm) as shown here. Use audio/video cables to connect those jacks to the TV/DVD’s AV INPUTS. Press TV/AV/DVD on the remote to select VIDEO mode. Select TV channels at the Cable Box/Satellite Receiver as usual, leaving the TV/DVD on VIDEO.

HELPFUL HINT

75 OHM

ANTENNA

INPUT

CABLE TV

OR SATELLITE

SIGNAL

75 OHM ANTENNA INPUT

VIDEO

AUDIO-R

AV INPUT

(MONO)

AV OUTPUT

COAXIAL

DVD DIGITAL

OUTPUT

o receive television programming, con-

nect your TV/DVD using one of the connections shown.The TV channels will be available after you use Auto Search to select channels.

Using Cable TV service or an Indoor or Outdoor Antenna

Connect a Cable TV signal or an antenna to the 75 OHM ANTENNA INPUT on the rear of the TV/DVD.

Using a Cable Box or Satellite Receiver

1. Connect the Cable TV or Satellite signal to the IN Jack on the Cable Box/Satellite Receiver.

2. Connect an RF coaxial cable (not supplied) to the OUT Jack on the Cable Box/ Satellite Receiver and to the 75 OHM ANTENNA INPUT on the TV/DVD.

3. To view any channel, set the TV/DVD to the output channel (3 or 4) of the Cable Box/Satellite Receiver. Then, select channels at the Cable Box/Satellite Receiver.

When all other connections are complete, plug in the TV/DVD’s power cord.

OUT

75 OHM

ANTENNA

INPUT

CABLE TV

OR SATELLITE SIGNAL

RF COAXIAL

CABLE

75 OHM ANTENNA INPUT

VIDEO

AUDIO-R

AV INPUT

(MONO)

AV OUTPUT

COAXIAL

DVD DIGITAL OUTPUT

CONNECTING OTHER

EQUIPMENT TO THE TV/DVD

ou may want to connect a VCR,

Camcorder, or Video Game to this TV/DVD. After making this connection, press TV/AV/DVD to select VIDEO mode. The materials playing on the other equipment will show on the TV/DVD’s VIDEO channel. Audio and video cables are not supplied.

Connect a video cable to the

VIDEO OUT jack of the other equipment and to the yellow VIDEO AV INPUT jack on the back of the TV/DVD.

Connect audio cables to the

AUDIO OUT jacks of the other equipment and to the red and white AUDIO L/R AV INPUT jacks on the back of the TV/DVD.

Turn on the TV/DVD and the other equipment.

Press TV/AV/DVD on the

remote to set the TV/DVD to the VIDEO channel.VIDEO will appear in the top left corner of the TV screen.

Play the tape, game, etc. as usual on the other equipment.You will watch and hear it at the TV/DVD.

If the other equipment has only a single AUDIO OUT jack (usually white), connect it to only the white (left) AUDIO AV INPUT jack on the TV/DVD.The sound will come from a single channel (the left) and will not be in Stereo. Remember to match the cable colors to the jack colors. Connect OUT jacks on the other equipment to AV INPUTs on the TV/DVD.

HELPFUL HINT

ANTENNA

LRL

AUDIO

OUT

AUDIO

ANTENNA

OUT

VIDEO

OUT

75 OHM ANTENNA INPUT

VIDEO

AUDIO-R

AV INPUT

(MONO)

AV OUTPUT

COAXIAL

DVD DIGITAL

OUTPUT

From VCR’s AUDIO and VIDEO OUT jacks to VIDEO and AUDIO A/V INPUT jacks on TV/DVD

VCR

TV/DVD

CONNECTING THE

TV/DVD TO OTHE R SYSTEMS

ou may want to connect the TV/DVD

to other devices such as a VCR or a Stereo. For example, you can record a TV program from the TV/DVD to a VCR, or hear the sound from the TV/DVD on a Stereo. You will use the AV OUTPUTs on the back of the TV/DVD to send the picture and/or sound to another device.

Two different audio connections are possible - analog or digital.

If the VCR, Stereo, etc., has red and white Audio In jacks, this is an analog connection. Connect

audio cables to the red and white AUDIO AV OUTPUT jacks on the TV/DVD and to the AUDIO IN jacks on the Stereo,VCR, etc.

These cables are not supplied with the TV/DVD, but may come with the other equipment. Use RCA-style cables, matching cable colors to jack colors.

Or, if your Stereo has a Coaxial Digital Audio In jack, you can make a digital connection. Use a

coaxial digital audio cable (not supplied) to connect the TV/DVD’s DVD DIGITAL OUTPUT COAXIAL jack to the Stereo’s Coaxial Digital Audio In jack.

If you are connecting to a VCR or other video device, also connect a video cable from the TV/DVD’s VIDEO AV OUTPUT jack (yellow) to the VCR’s VIDEO IN jack.

There is no video connection to a stereo.

Set the Stereo,VCR, etc., to its Auxiliary In, Audio/Video In, or Source mode. See its

owner’s manual for details.

ANTENNA

AUDIO OUT

AUDIO

ANTENNA

OUT

VIDEO

VIDEO OUT

AUDIO

75 OHM ANTENNA

INPUT

VIDEO

AUDIO-R

AV INPUT

(MONO)

AV OUTPUT

COAXIAL

DVD DIGITAL

OUTPUT

From VIDEO and AUDIO A/V OUTPUT jacks on TV/DVD to AUDIO IN jacks on Stereo or VCR and VIDEO IN jacks on VCR

VCR

STEREO

TV/DVD

REMOTE

CONTROL

TV/AV/DVD Button

Press to select a Video In mode. Choose TV for regular TV programming, DVD for Disc play, or VIDEO to watch materials playing on other equipment connected to the TV/DVD (VCR, video games, etc.).

OPEN/CLOSE Button

Press to open or close the disc tray.This automatically puts the unit in DVD mode.

MUTE Button

Press to silence the sound. The H will appear on the screen. Press MUTE again to restore the volume to its previous level.

Number (0-9) Buttons

Use to select TV channels, to select Disc chapters or tracks, or to enter information in menus. When choosing one- or two-digit TV channels (i.e. 6 or 12), there will be a pause before the channel changes.

TITLE Button

Press to access a DVD’s title menu.

SETUP Button

Press to access the SETUP menu of the DVD Player.

REPEAT Button

Press to repeatedly play a Disc portion (Track, Chapter, etc.).

REPEAT A-B Button

Press to play a specific Disc segment repeatedly.

POWER yyButton

Press to turn the unit on or off.

SLEEP Button

Press to have the TV/DVD turn itself off after a set amount of time.

CLOCK Button

In TV mode, press to go directly to the Timer menu to set up clock or timer features.

S. EFFECT Button

Press to choose a sound effect (Personal,Voice, Music, or Theatre).

MTS Button

Press to choose an audio option (MONO, STEREO, SAP-second audio program, or MONO+SAP), depending on the TV channel. MTS will not function if the volume is muted.

VOL. +,VOL. - Buttons

Use to increase or decrease the volume.

MENU Button

Press to access or remove the TV menu. It will disappear after 15-20 seconds of inactivity.

ZOOM Button

Press to enlarge or reduce a DVD or Video CD image during play.

STOP C Button

Press to stop Disc play.

TV/AV/DVD

DISPLAY

MTS

POWER

SLEEP

CLOCK

S.EFFECT

PICTURE/DEL.

VOL+

VOL-

MUTE

OPEN/CLOSE

DVD10+

FAV.

TITLE

RECALL

MENU/PBC SETUP

LANGUAGE

REPEAT

CH+

ENTER

CH-

SCAN

SLOW

ANGLE

REPEAT

A-B

SKIP

R/L

SUBTITLE ZOOM

STOP

PLAY/PAUSE

MODE

REMOTE CONTROL

RECALL

Press to switch between the last channel and the current channel.

FAV./DVD10+ Button

Press to move through your five favorite TV channels. In DVD mode, use to select a Track or Chapter.

MENU/PBC Button

Press to access a DVD’s menu or to enable Playback Control (PBC) on a Video CD.

ENTER Button

Press to confirm a menu selection.

CH+o, CH-p, 2, 3 Buttons

Use to select items in the on-screen menu. Use CH+o and CH-p to change TV channels.

SCAN 1h, g6 Buttons

Press to fast forward or fast reverse a Disc during play.

SLOW Buttons

Press to play a Disc forward or backward in slow motion.

LANGUAGE Button

Press to select a language for the audio of a DVD.

ANGLE Button

Press to select a different camera angle or perspective during DVD play.

DISPLAY Button

Press to see the current TV channel number or time or to see Disc information.

PICTURE/DEL Button

Press to choose a predefined picture setting (Multimedia, Personal, Movies, Sports,Weak Signal).

SKIP j, G Buttons

Press to skip to the next or previous Disc Chapter or Track.

SEARCH MODE Button

Press to access or remove the search menu for a DVD or Video CD.

R/L Button

Press to hear sound from the right or left channel of a Video CD or Audio CD.

SUBTITLE Button

Press to select a language for subtitles during DVD play.

PLAY/PAUSE M Button

Press to play a Disc. Press to pause or freeze the picture during play; press again to resume play.

OPEN/CLOSE

DVD10+

FAV.

TITLE

MENU/PBC SETUP

SCAN

SLOW

LANGUAGE

REPEAT

RECALL

MUTE

ANGLE

REPEAT

A-B

CH+

ENTER

CH-

TV/AV/DVD

DISPLAY

PICTURE/DEL.

MTS

SKIP

R/L

SUBTITLE ZOOM

STOP

PLAY/PAUSE

S.EFFECT

POWER

SLEEP

CLOCK

VOL+

VOL-

MODE

BASIC FEATURES

Watching TV

Press POWER yyto turn on the TV/DVD.

Press TV/AV/DVD to select TV mode. The current channel num-

ber will appear in the top left corner.

Use CH+o and CH-p to select TV channels.

Playing a Disc

Press TV/AV/DVD to select DVD mode. The large DVD Video logo

will appear on the screen.

Press OPEN/CLOSE to open the disc tray. Insert a Disc with

the label facing up. If a DVD has movies on both sides of the Disc, make sure the label of the side you want to play is facing up. In this case, the labelling is probably on the inner ring of the Disc.

Press OPEN/CLOSE again to close the tray.

Play may begin automatically. If not, press PLAY/PAUSE M.

Remote Control Batteries

Remove the battery compartment lid on the back of the

remote by sliding the lid down and off.

Insert two AAA batteries. Install

them as marked inside the compartment.

Replace the compartment lid.

POWER button

HEADPHONE jack

Connect headphones (not supplied) here for personal listening.

TV/AV/DVD, MENU, VOL(ume), CH(annel), (ENTER, PLAY/PAUSE) buttons

2,4

5,6

OPEN/CLOSE

DVD10+

FAV.

TITLE

MENU/PBC SETUP

SCAN

SLOW

LANGUAGE

REPEAT

POWER

MUTE

TV/AV/DVD

SLEEP

CLOCK

S.EFFECT

DISPLAY

PICTURE/DEL.

RECALL

MTS

VOL+

VOL-

CH+

ENTER

CH-

SKIP

R/L

MODE

SUBTITLE ZOOM

ANGLE

REPEAT

STOP

PLAY/PAUSE

A-B

PROGRAMMING

TV CHANNELS

he TV can receive channels via an

Antenna or Cable TV signal, then memorize the available channels.This makes it easy for you to select only available TV stations when you use CH+o and CH-p. Make sure the Antenna or Cable TV signal is connected securely to the 75 OHM ANTENNA INPUT before you begin.

Press MENU. Press 2 or 3 to choose the Preset menu.

Press CH+o or CH-p to select Tuner Mode.

Press 2 or 3 to choose Antenna or Cable. Choose Cable if you have Cable TV service. Channels 1-125 will be possible. Choose Antenna if you connected an indoor or outdoor antenna to the TV/DVD. Channels 2-69 will be possible.

Press CH+o or CH-p to select Auto Search.

Press 3 to start scanning channels.The channels will count up on the screen during the search. When finished, the TV will go to the lowest available channel. “Completed” will appear briefly.

In this same Preset menu, choose Manual and use 2 or 3 to change TV channels Up or Down.

You cannot select the Preset menu if CH lock is On or when the unit is in AV or DVD mode.

You can start Auto Search directly by pressing and holding the MENU button on the top of the TV/DVD.

HELPFUL HINTS

1-5

OPEN/CLOSE

DVD10+

FAV.

TITLE

MENU/PBC SETUP

SCAN

SLOW

LANGUAGE

REPEAT

Tuner Mode

• Cable

• Channel 3

• Skipped Off

• Manual Up

• Auto Search ·

• Favorite list

POWER

MUTE

TV/AV/DVD

SLEEP

CLOCK

S.EFFECT

DISPLAY

PICTURE/DEL.

VOL+

RECALL

MTS

VOL-

CH+

ENTER

CH-

SKIP

R/L

MODE

SUBTITLE ZOOM

ANGLE

REPEAT

STOP

PLAY/PAUSE

A-B

+ 25 hidden pages
