Page 1
Philips
LCD widescreen monitor
20.1" wide
WSXGA
200XW7EB
Wide screen enjoyment plus
great convenience
View all your favourite entertainment on a single wide screen display with the Philips
200XW7 featuring a bigger, high resolution screen, fast response time, dual input options
and great viewing comfort in an easy-to-use package.
Outstanding front of screen performance
• Empowered for Windows Vista
• Big, wide screen: IM, write mail, watch videos on one screen
•Fast 8ms On/off response time:Great text & graphics display
Ergonomic design
• 90 degree screen rotation and smart cable management
• Screen tilt and swivel adjustment for an ideal viewing angle
Green design
• For your safety: Aerospace composite fire retardant case
• Lead-free design safeguards our environment
Great convenience
• Dual input accepts both analogue VGA and digital DVI signals
• USB port for convenient peripheral connections
• Easy to adjust display settings with Philips SmartControl
• Convenient, built in holder for notes, cards or photos
Page 2
LCD widescreen monitor
200XW7EB/05
20.1" wide WSXGA
Specifications Product highlights
Picture/Display
• LCD panel type: 1680 x 1050 pixels, Anti-glare
polarizer, RGB vertical stripe
• Panel Size: 20.1"/ 51 cm
• Effective viewing area: 433.4 x 270.9 mm
• Pixel pitch: 0.258 x 0.258 mm
• Brightness: 300 cd/m²
• Contrast ratio (typical): 600:1
• Display colours: 16.2 M
• Viewing angle: 160º (H) / 145º (V), @ C/R > 5
• Response time (typical): 8 ms
• Maximum Resolution: 1680 x 1050 @ 60Hz
(digital input)
• Recommended Resolution: 1680 x 1050 @ 60Hz
(digital input)
• Video Dot Rate: 205 MHz
• Horizontal Scanning Frequency: 30 - 98 kHz
• Vertical Scanning Frequency: 56 - 76 Hz
• Aspect ratio: 16:10
•sRGB
Connectivity
• Signal Input: Analogue (VGA), DVI-D
• USB: 1 x USB 2.0
• Video Sync Input Signal: Composite Sync, Separate
Sync, Sync on Green
• Video input impedance: 75 ohm
• Sync input impedance: 2.2k ohm
• Video input signal levels: 0.7 Vpp
Convenience
• Convenience Enhancements: On-screen Display,
SmartManage enabled
• Monitor Controls: Auto, Brightness Control (Up/
Down), Left/Right, Menu (OK), Power On/Off
• OSD Languages: English, French, German, Italian,
Russian, Spanish
• Other convenience: Kensington lock compatible
• Plug & Play Compatibility: DDC/CI, sRGB,
Windows 98/ME/2000/XP/Vista
• Regulatory Approvals: CE Mark, Energy Star,
FCC-B, UL, CSA, SEMKO, TCO '03, TÜV/GS,
TÜV Ergo
• Swivel: +/- 45°
• Tilt: -5° to 25°
• Height Adjustment: 130 mm
• Pivot: 90° (clockwise)
• VESA Mount: 100 x 100 mm
Accessories
• Included Accessories: AC Power Cord, DVI-D
cable, USB cable, VGA cable
•User Manual
Dimensions
• Box dimensions (W x H x D):
579
x 513 x 267 mm
• Box dimensions in inch (W x H x D):
22.8
x 20.2 x 10.5 inch
• Set dimensions (W x H x D):
483
x 338.5 x 68.7 mm
• Set dimensions in inch (W x H x D):
19
x 13.3 x 2.7 inch
• Set dimensions with stand (W x H x D):
483
x 402 x 215.3 mm
• Set dimensions with stand in inch (W x H x D):
19
x 15.8 x 8.5 inch
• MTBF: 50,000 hrs
• Relative Humidity: 20% - 80%
• Temperature range (operation): 0°C to 35°C
• Temperature range (storage): -20°C to 60°C
• Product weight (+stand): 8.6 kg
• Product weight (+stand) (lb): 18.9 lb
• Weight incl. Packaging: 10.7 kg
• Weight incl. Packaging (lb): 23.6 lb
Power
• Complies with: Energy Star
• Consumption: 48 W (Typical)
• Off Mode: < 1 W
• Power LED indicator: Operation - green, Stand
by/sleep - Amber
• Power supply: Built-in, 100-240VAC, 50/60Hz
•
Windows Vista ready
Philips Vista-ready monitors are empowered for vibrant,
exciting display of this new, visually sophisticated and
demanding Windows operating system, designed to
enhance your entertainment experience, make you more
productive and help you control your computing
experience at home and in the office, making viewing,
finding and organizing information for work or play quick,
efficient and easy.
Widescreen design
A wide screen has a wider aspect ratio for displaying
mo re enter tainmen t or info rmation to have m ore fun and
get more done.
8ms response time (On/Off)
On-Off response time is the period required for a liquid
crystal cell to go from active (black) to inactive (white)
and back to active (black) again. It is measured in
milliseconds. Faster is better: Lower response time means
faster transitions and therefore, results in fewer visible
image artefacts in the display of transition of text and
graphics. On-Off response time is a more important
measure in the display of business content like
documents, graphs and photos.
Super Ergo Base
The Super Ergo base is a monitor base that delivers
ergonomic display comfort and provides intelligent cable
management. The base's people-friendly height, swivel,
tilt and rotation angle adjustments position the monitor
for maximum comfort that can ease the physical strains
of a long workday; intelligent cable management reduces
cable clutter and keeps the workspace neat and
professional.
Screen tilt and swivel
Screen tilt and swivel is a mechanism built into the base
permits the monitor to swivel and tilt backward or
forward.
Flame retardant cabinet
PC/ABS plastic composite is the industry's best and
toughest flame-retardant casing material; and is a spaceage compound deployed in the aerospace and
automotive industries as well as in fire detectors that is
compliant with most stringent fire safety standards.
Lead-free
Lead-free display products are designed and produced in
compliance with strict European Community Restriction
of Hazardous Substances (RoHS) standards that restrict
lead and other toxic substances that can harm the
environment.
Dual input
Dual input provides connectors to accommodate input of
both analogue VGA and digital DVI signals.
USB 2.0 port
The universal serial bus or USB is a standard protocol for
linking PCs and peripherals. Because it delivers high
speed at a low cost, USB has become the most popular
method for connecting peripheral devices to a computer.
A port located on a monitor directly in the user's line of
sight provides easy, high-speed connectivity for USB
devices at a convenient location. (USB 2.0 support is
dependent on your PC's USB configuration; when
connected to a PC that supports USB 2.0, your monitor is
USB 2.0 compatible)
SmartControl
Issue date 2009-02-12
Version: 3.0.4
12 NC: 8670 000 28349
EAN: 87 12581 32479 7
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
PC software for fine tuning display performance and
settings. Philips offers users two choices for display setting
adjustment. Either navigate the multilevel On Screen
Display menu through buttons on the display itself or use
the Philips SmartControl software to easily adjust the
various display settings in a familiar way.
