Philips
LCD monitor
48 cm (19")
SXGA
190B7CS
Large convenient display to
increase productivity
With a full range of convenient features, combined with SmartManage remote monitor
management and Philips Perfect Panel™ warranty, the 190B7 delivers an extremely
convenient display with an attractive total cost of ownership.
Best total cost of ownership solution
• Empowered for Windows Vista
• SmartManage compatibility enables LAN-based asset management
• Complies with RoHS standards to care for the environment
Outstanding front of screen performance
• ISO 13406-2 Class I compliant dot-defect-free display
• Fast 8ms On/off response time:Great text & graphics display
• SXGA 1280 x 1024 resolution for sharper display
• Dual input accepts both analog VGA and digital DVI signals
Maximum comfort for maximum productivity
• Tilt, swivel and height-adjust for an ideal viewing position
Great convenience
• USB port for convenient peripheral connections
• Easy to adjust display settings with Philips SmartControl
• Built-in speakers for audio without desktop clutter
190B7CS/05
LCD monitor
48 cm (19") SXGA
Highlights
Windows Vista ready
Philips Vista-ready monitors are empowered
for vi
brant, exciting display of this new, visually
sophisticated and demanding Windows
operating system, designed to enhance your
entertainment experience, make you more
productive and help you control your
computing experience at home and in the
office, making viewing, finding and organizing
information for work or play quick, efficient
and easy.
SmartManage enabled
SmartManage is a system for monitoring,
managing and
as well as delivering remote support to users
who experience difficulties - all accomplished
over a LAN.
Compliant with RoHS standards
Philips designs and produces display products
in
compliance with strict Restriction of
Hazardous Substances (RoHS) standards that
restrict lead and other toxic substances that
can harm the environment.
PerfectPanel™
Bright dots and dark dots are defe
panel. While some manufacturers still consider
bright and dark defects in a LCD panel an
inevitable part of the manufacturing process,
Philips doesn't. Philips monitors, compliant
checking status of display devices
cts in a LCD
with ISO 13406-2 Class I standard, are
produced with zero tolerance for LCD panel
defects and backed by Philips PerfectPanel™
globally valid warranty providing repair or
replacement of any LCD monitors that display
even a single defective bright or dark dot.
8ms response time (On/Off)
On-Off response time is the period required
for a liqui
to inactive (white) and back to active (black)
again. It is measured in milliseconds. Faster is
better: Lower response time means faster
transitions and, therefore, results in fewer
visible image artifacts in the display of
transition of text and graphics. On-Off
response time is a more important measure in
the display of business content like documents,
graphs and photos.
Dual input
Dual input provides connectors to
accommodat
digital DVI signals.
Compact Ergo Base
The Compact Ergo Base is a people-friendly
Phili
height-adjusts so each user can position the
monitor for maximum viewing comfort and
efficiency.
d crystal cell to go from active (black)
e input of both analog VGA and
ps monitor base that tilts, swivels and
USB 2.0 port
USB port allows user to convenie
their plug and play multimedia devices such as
USB memory devices, camera, portable HDD,
Web camera, PDA, Printer and many other
devices which has USB connection available.
The conveniently located USB 2.0 port on the
monitor allows USB 2.0 signals to pass thru to
the computer. Note that many devices like
cameras and HDD may need to be powered
On independently, as they have higher power
requirements than the monitor USB port can
provide
SmartControl
PC software for fine tuning display
p
erformance and settings. Philips offers users
two choices for display setting adjustment.
Either navigate the multilevel On Screen
Display menu through buttons on the display
itself or use the Philips SmartControl software
to easily adjust the various display settings in a
familiar way.
Built-in speakers
A pair of stereo speakers built into a display
device.
It can be visible front firing, or invisible
down firing, top firing, rear firing, etc
depending on model and design.
ntly connect
190B7CS/05
LCD monitor
48 cm (19") SXGA
Specifications
Picture/Display
• LCD panel type: 1280 x 1024 pixels, Anti-glare
polarizer, RGB vertical stripe
• Panel Size: 19"/ 48cm
• Effective viewing area: 376.3 x 301.1 mm
• Pixel pitch: 0.294 x 0.294 mm
• Brightness: 300 cd/m²
• Contrast ratio (typical): 700:1
• Display colors: 16.2 M
• Viewing angle: @ C/R > 5
• Viewing angle (H / V): 176 / 170 degree
• Response time (typical): 8 ms
• White Chromaticity, 6500K: x = 0.313 / y = 0.329
• White Chromaticity, 9300K: x = 0.283 / y = 0.297
• Maximum Resolution: 1280 x 1024 @ 75 Hz
al input)
(digit
• Optimum resolution: 1280 x 1024 @ 60 Hz (digital
t)
inpu
• Video Dot Rate: 140 MHz
• Horizontal Scanning Frequency: 30 - 83 kHz
• Vertical Scanning Frequency: 56 - 76 Hz
•sRGB
Connectivity
• Signal Input: VGA (Analog ), DVI-D, PC Audio in
• Audio output: Stereo Audio (3.5 mm jack) 1x
• USB: USB 2.0 x 1
• Sync Input: Composite Sync,
on Green
• Video input impedance: 75 ohm
• Sync input impedance: 2.2k ohm
• Video input signal levels: 0.7 Vpp
Separate Sync, Sync
Convenience
• Built-in Audio: 2W RMS x 2 stereo speakers
• User convenience: On-screen Display,
SmartManag
• Monitor Controls: Auto, Brightness Control (Up/
Down
Volume control
• OSD Languages: English, Fr
Russian, Spanish
• Other convenience: Kensingto
• Plug & Play Compatibility: DDC/CI, sRGB,
Windo
e enabled
), Left/Right, Menu (OK), Power On/Off,
ench, German, Italian,
n lock compatible
ws 98/ME/2000/XP/Vista
• Regulatory approvals: CE Mark, EMC,
FCC-B, UL, CSA, SEMKO, TCO '03, TÜV/GS,
TÜV Ergo
•Swivel: +/- 60°
• Tilt: -5° to 25°
• VESA Mount: 100 x 100 mm
Energy Star,
Accessories
• Included accessories: AC Power Cord, Audio
Cable, USB cable, VGA cable
• Optional accessories: Super Ergo Base
• User Manual
Dimensions
•Box dimensions (W x H x D):
503 x 198 x 507 mm
• Box dimensions in inch (W x H x D):
.8 x 7.8 x 20 inch
19
•Set dimensions (W x H x D):
x 374.2 x 68.7 mm
2
42
• Set dimensions in inch (W x H x D):
.6 x 14.7 x 2.7 inch
16
• Set dimensions with stand (W x H x D):
2 x 405 x 198.8 mm
42
•Set dimensions with st
16.6 x 15.9 x 7.8 inch
• Height adjustment range: 60 mm
• Height adjustment range (inch): 2.4 inch
• MTBF: 50,000 hrs
• Relative humidity: 20% - 80%
• Temperature range (operation): 5°C to 40°C
• Temperature range (storage): -20°C to 60°C
• Product weight (+stand): 6.14 kg
• Product weight (+stand) (lb): 13.5 lb
• Weight incl. Packaging: 7.55 kg
• Weight incl. Packaging (lb): 16.6 lb
and in inch (W x H x D):
Power
• Complies with: Energy Star
•Consumption (On mode):
•Consumption (Off Mo
• Power LED indicator: Operation - green, Stand by/
eep - Amber
sl
• Power supply: Built-in, 100-240VAC, 50/60Hz
•
40 W (Typical)
de): < 1 W
Issue date 2022-04-21
Version: 6.0.12
12 NC: 8639 000 17029
EAN: 87 10895 96592 7
© 2022 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
