17" LCD Color Monitor Chassis: HUDSON 8
170S8FS/00
Service
170S8FB/00
Service
Service
170S8FB/27
170S8FS/62
170S8FB/62
170S8FB/78
Description Page Description Page
Table Of Contents........................................………….1
Revision List................................................…………….2
Important Safety Notice………….................................3
1. Monitor Specifications……...................................…..4
2. LCD Monitor Description………..…….........................6
3. Operation instructions…………….......................…....7
3.1General Instructions…………………..…..…………7
3.2 Control buttons…………..……………………………7
3.3 Adjusting the Picture……....................................…..9
3.4 Connecting to the PC ….........…….…........……....11
4. Input/Output Specification.........................………….12
4.1 Input Signal Connector...........................…………..12
4.2 Factory Preset Display Modes...............................13
4.3 Pixel Defect Policy……………………………………13
4.4 Failure Mode OF Panel………………………..…..16
5. Block Diagram……………………………................17
5.1 Software Flow Chart............................………….....17
5.2 Electrical Block Diagram..................……….........19
6. Schematic Diagram…….....................……….........21
6.1 Scalar Board…….……………..…………………………21
6.2 Power Board…………………………..…………………25
6.3 Key Board…….………………………..…………………27
7. PCB Layout.....……......................……………………..28
7.1 Scalar Board.....…….......................…….…………......28
7.2 Power Board.……................…..…………….............30
7.3 Key Board………...………………………………………32
8. Wiring Diagram……………………………………….…..33
9. Mechanical Instructions.....……...…………..…..........34
10.Trouble shooting…..…………………………...……..44
11. Repair Flow Chart…….…….……………………………46
12. ISP Instructions..…..........................………..............52
13. DDC Instructions……......…….............….................59
14. White Balance, Luminance Adjustment……............73
15. Monitor Exploded View………..…….………..............75
16. Recommended & Spare Parts List...…….....................76
17. Different Parts List...……….....………....................96
18. General Product Specification……………………….99
http://www.wjel.net
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Published by Philips CE Copyright reserved Subject to modification ○K Aug, 22, 2007
GB
312278517290
2
HUDSON 8
Revision List
Version Release Date Revision History
A00 Jul.05, 2007 Initial release, Draft Version
A01 Jul.17,2007 Add new BOM in Item 17
A02 Jul.27,2007 Add new BOM in Item 17
A03 Sep.12,2007 Add new BOM in Item 17
Add Second Panel Source
A04 Nov.07,2007
Update C907 in Item 16
A05 Nov.24,2007 Add Philips 12NC for 715GT039 A
A06 Dec.22,2007 Add Philips 12NC for Model 170S8FB/00 and 170S8FS/00
A07 Feb.02,2007 Add new BOM in Item 17
A08 Mar.05,2008 Add Second Panel Source
Add a new BOM for CTV Model 170S8FS/00 in Item16
A09 Apr.11,2008
Add a new BOM for CTV Model 170S8FB/00 in Item17
http://www.wjel.net
HUDSON 8
3
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all Philips Company Equipment. The service
procedures recommended by Philips and described in this service manual are effective methods of performing
service operations. Some of these service operations require the use of tools specially designed for the purpose.
The special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. Philips could not possibly know, evaluate and advise the service trade of all conceivable ways
in which service might be done or of the possible hazardous consequences of each way. Consequently, Philips has
not undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by Philips must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, Philips Company will be referred to as Philips.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from Philips.
Philips assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open. AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
http://www.wjel.net
damage the panel.)
4
1. Monitor Specifications
HUDSON 8
http://www.wjel.net
HUDSON 8
5
http://www.wjel.net
6
(
HUDSON 8
2. LCD Monitor Description
The LCD monitor will contain a scalar board, a power board and a key board which house the flat panel control logic,
brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Power board
Include: adapter, inverter)
AC-IN
100V-240V
Monitor Block Diagram
CCFL Drive.
Key Board
Flat Panel and
CCFL backlight
Main Board
HOST Computer
RS232 Connector
For white balance
adjustment in factory
mode
Video signal, DDC
http://www.wjel.net
HUDSON 8
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at the front of the
panel of the monitor.
By changing these settings, the picture can be adjusted to your personal preferences.
The power cord should be connected.
-
Connect the video cable from the monitor to the video card.
-
Press the power button to turn on the monitor, the power indicator will light up.
-
3.2 Control Buttons
Front View
7
http://www.wjel.net
8
Rear View
HUDSON 8
http://www.wjel.net
3.3 Adjusting the Picture
Description of the On Screen Display
On-Screen Display (OSD) is a feature in all Philips LCD monitors. It allows an end user to adjust screen
performance or select functions of the monitors directly through an on-screen instruction window. A user friendly on
screen display interface is shown as below:
HUDSON 8
9
In the OSD shown above users can press buttons at the front bezel of the monitor to move the cursor, to
confirm the choice or change.
To Lock/Unlock OSD function (User Mode)
The OSD function can be locked by pressing “MENU” button for more than 10 seconds.
Locked OSD function can be released by pressing “MENU” button for more than 10 seconds again.
http://www.wjel.net
10
The OSD Tree
Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want
to work your way around the different adjustments later on.
HUDSON 8
http://www.wjel.net
3.4 Connecting to the PC
1) Connect the power cord to the back of the monitor firmly. (Philips has pre-connected VGA cable for the first
installation.
HUDSON 8
11
2) Connect to PC
(a) Turn off your computer and unplug its power cable.
(b) Connect the monitor signal cable to the video connector on the back of your computer.
(c) Plug the power cord of your computer and your monitor into a nearby outlet.
(d) Turn on your computer and monitor. If the monitor displays an image,
installation is complete.
http://www.wjel.net
12
HUDSON 8
4. Input/Output Specification
4.1 Input Signal Connector
Analog connectors
Pin No. Description Pin No. Description
1. Red video input 9. DDC +3.3V or +5V
2. Green video input 10. Logic Ground
3. Blue video input 11. Ground
4. Sense (GND) 12. Serial data line (SDA)
5. Cable detect (GND) 13. H. Sync
6. Red video ground 14. V. Sync
7. Green video ground 15. Data clock line (SCL)
8. Blue video ground
VGA connector layout
DVI connectors
Pin
No.
1. T.M.D.S Data2- 9. T.M.D.S Data1- 17. T.M.D.S Data0-
2. T.M.D.S Data2+ 10. T.M.D.S Data1+ 18. T.M.D.S Data0+
3. T.M.D.S Data2 Shield 11. T.M.D.S Data1 Shield 19. T.M.D.S Data0 Shield
4. No connector 12. No connector 20. No connector
5. No connector 13. No connector 21. No connector
6. DDC Clock 14. +5V Power 22. T.M.D.S Clock Shield
Description
http://www.wjel.net
Pin
No.
Description
Pin
Description
No.
7. DDC Data 15. Ground (for +5V) 23. T.M.D.S Clock+
8. No connector 16. Hot Plug Detection 24. T.M.D.S Clock-
4.2 Factory Preset Display Modes
HUDSON 8
13
4.3 Pixel Defect Policy
http://www.wjel.net
14
HUDSON 8
http://www.wjel.net
HUDSON 8
15
http://www.wjel.net
16
g
g
g
g
g
HUDSON 8
4.4 Failure Mode Of Panel
Quick reference for failure mode of LCD panel
this pa
e presents problems that could be made by LCD panel.
It is not necessary to repair circuit board. Simply follow the mechanical
instruction on this manual to eliminate failure by replace LCD panel.
Polarizer has bubbles
Failure description
Vertical block defect
Vertical dim lines
Vertical lines defect
(Always bri
Horizontal block defect
ht or dark)
Phenomenon
Polarizer has bubbles
Foreign material inside
polarizer. It shows liner or
dot shape.
Concentric circle formed
Horizontal dim lines
Horizontal lines defect
(Always bri
Has bri
ht or dark)
ht or dark pixel
Bottom back light of LCD is
brighter than normal
Back light un-uniformity
http://www.wjel.net
ht has foreign material.
Backli
Black or white color, liner or
circular type
N
N
5. Block Diagram
5.1 Software Flow Chat
HUDSON 8
1
17
2
N
4
5
Y
6
7
Y
Y
3
9
10
Y
N
http://www.wjel.net
18
N
12
Y
14
19
N
13
15
11
17
N
Y
N
Y
16
Y
18
1) MCU initialize.
2) Is the EPROM blank?
3) Program the EPROM by default values.
4) Get the PWM value of brightness from EPROM.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EPROM.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are there any signals coming?
HUDSON 8
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappear.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?
http://www.wjel.net
5.2 Electrical Block Diagram
5.2.1 Main Board
HUDSON 8
19
Keypad Interface
(CN407)
Panel Interface
(CN402)
Scalar NT68665MFG
(Include MCU, ADC, OSD)
Crystal
12.000MHZ
(X201)
(U203)
RGB
H sync
V sync
VGA_SDA,
VGA SCL
D-Data
D-Clock
DVI_SDA,
DVI_SCL
EEPROM
M24C16
(U204)
D-Sub
Connector
(CN101)
DVI
Connector
(CN102)
http://www.wjel.net
20
5.2.2 Inverter/Power Board
HUDSON 8
AC input
EMI filter
Bridge
Rectifier
and Filter
Transformer
Rectifier
diodes
Start Circuit: R905
CN902
PWM Control IC
（IC901）
Feedback
Circuit
12V
5V
ON/OFF
Output
Circuit
Transformer MOSFET
Lamp
Over Voltage
PWM
ON/OFF
Control
Feedback
Circuit
Control IC
（IC801）
DIM
http://www.wjel.net
6. Schematic
6.1 Scalar Board
715G2561-1
HUDSON 8
1
DVI/D-SUB
A A
25
25
RX2-
RX2+
GND
RX4-
RX4+
SCL
SDA
VS
RX1-
RX1+
B B
C C
GND
RX3-
RX3+
5V
GND
HP
RX0-
RX0+
GND
RX5-
RX5+
GND
RXC+
RXC-
RED
GRN
BLU
HS
GND
26
26
CN102
JACK
RX2M
1
RX2P
2
3
4
5
DDCSCL_D
6
DDCSDA_D
7
8
RX1M
9
RX1P
10
11
12
13
14
15
16
RX0M
17
RX0P
18
19
20
21
22
RXCP
23
RXCM
24
C1
C2
C3
C4
C5
R106
10R 1/16W
R107
10R 1/16W
R110
10R 1/16W
R111
10R 1/16W
R115
10R 1/16W
R116 10R 1/16W
R117
10R 1/16W
R118
10R 1/16W
2
RX2- 3
RX2+ 3
RX1- 3
RX1+ 3
R113 1K 1/16W
RX0- 3
RX0+ 3
RXC+ 3
RXC- 3
ZD103
RLZ5.6B
ZD104
RLZ5.6B
R122
1K 1/16W
3
C132
470PF 50V
DVI-HPD 3
FB101
120 OHM
1 2
R108 100R 1/16W
R109 100R 1/16W
DVI_5V
R120
1K 1/16W
C114
0.1uF 16V
C106
0.1uF 16V
4
R105
DDC_WP3
DVI_SDA 3
DVI_SCL 3
DVI_CABLE 3
5
DVI_VDD
NC
R103
R104
4K7 1/16W
4K7 1/16W
C107
1uF 16V
U101
8
VCC
7
WC
6
SCL
NC/M24C02-WMN6TP
BAV70
D102
NC/NC/NC/E0/E0
NC/NC/E1/E1/E1
NC/E2/E2/E2/E2
VSSSDA
6
1 2
1
2
3
45
DVI_5V
FB107
120 OHM
+5V
+5V
1K 1/16W
R102
RLZ5.6B
C131
1000pF
ZD102
7
3
3
+5V_ESD
GRB
2
3
1
+5V_ESD
2
1
+5V_ESD
2
1
BAV99
D111
C116
0.1uF 16V
BAV99
D103
C102
0.1uF 16V
BAV99
D106
C110
0.1uF 16V
8
3
3
3
2
1
2
1
9
BAV99
D104
C103
0.1uF 16V
BAV99
D107
C111
0.1uF 16V
BAV99
2
D112
C117
0.1uF 16V
1
3
RXCPRX0MRX0P RXCM
3
2
1
2
1
3
BAV99
D101
C104
0.1uF 16V
BAV99
D108
C112
0.1uF 16V
10
2
1
RX1MRX2P RX1PRX2M
BAV99
D113
C118
0.1uF 16V
3
3
2
1
2
1
BAV99
D105
C105
0.1uF 16V
BAV99
D109
C113
0.1uF 16V
11
21
D D
BAV70
8
7
6
C115
1uF 16V
U102
VCC
WC
SCL
NC
ZD105
RLZ5.6B
ZD101
RLZ5.6B
D110
NC/NC/NC/E0/E0
NC/NC/E1/E1/E1
NC/E2/E2/E2/E2
VGA_VDD
NC
R125
HS
VS
VGA_SDA
VGA_SCL
DDC_WP
R134 100R 1/16W
R136 100R 1/16W
C127330pF 50V
C128
33pF
FB105
0R05 1/8W
R141
2K2 1/16W
RLZ5.6B
ZD106
E E
F F
G G
H H
R123
4K7 1/16W
R128
100R 1/16W
DDCSDA
DDCSCL
VIN
R142
2K2 1/16W
R124
4K7 1/16W
R127
100R 1/16W
ZD107
RLZ5.6B
VGA_5V
CN101 F3 CN102 A1
+5V
VGA_5V
1
2
3
45
VSSSDA
CN101
DB15
1716
11
12
13
14
15
12
FB102
120 OHM
1
6
2
7
3
8
4
9
5
10
1K 1/16W
C130
0.1uF 16V
C101
0.1uF 16V
FB103
30 OHM
R
1 2
FB104
30 OHM
G
1 2
http://www.wjel.net
R101
75R 1/16W
R144
FB106
30 OHM
B
1 2
R139
R140
75R 1/16W
75R 1/16W
VGA_CABLE
R126 100R 1/16W
R129 150 OHM 1/16W
R131
390R 1/16W
R132 100R 1/16W
R133 150 OHM 1/16W
R135 100R 1/16W
R138 150 OHM 1/16W
C121
0.047uF
C122
0.047uF
C123
1000pF
C124
0.047uF
C125
0.047uF
C126
0.047uF
C129
0.047uF
RIN+
RIN-
SOG
GIN+
GIN-
BIN+
BIN-
U101
U102
EXT_EDID
24C02
24C02 NC
INT_EDID
NC
Q201 NC 3906
R206 NC 4.7K
NCD201 BAV70
FB201 120 NC
C101 E4 C102 A8
C103 A9 C104 A10
C105 A11 C106 A4
C107 A5 C110 B8
C111 B9 C112 B10
C113 B11 C114 C3
C115 E3 C116 C8
C117 C9 C118 C10
C121 E6 C122 F6
C123 F6 C124 F6
C125 G6 C126 G6
C127 G1 C128 G1
C129 G6 C130 H4
C131 D6 C132 C3
D101 A9 D102 A6
D103 A7 D104 A8
D105 A10 D106 B7
D107 B8 D108 B9
D109 B10 D110 D3
D111 C7 D112 C9
D113 C10 FB101 A3
FB102 E4 FB103 E5
FB104 F5 FB105 G2
FB106 G5 FB107 A6
R101 G4 R102 C7
R103 A5 R104 A5
R105 A4 R106 A2
R107 A2 R108 B3
R109 B3 R110 B2
R111 B2 R113 B2
R115 B2 R116 B2
R117 C2 R118 C2
R120 C4 R122 C2
R123 E2 R124 E2
R125 E2 R126 E6
R127 E2 R128 E2
R129 F6 R131 F6
R132 F6 R133 G6
R134 G1 R135 G6
R136 G1 R138 G6
R139 G5 R140 G5
R141 G2 R142 G2
R144 H4 U101 B5
U102 E3 ZD101 G3
ZD102 C7 ZD103 A2
ZD104 B2 ZD105 F3
ZD106 G2 ZD107 G2
1
2
3
4
5
6
7
8
9
10
11
22
HUDSON 8
1
2
3
4
5
6
7
8
9
10
11
MCU+SCALAR
A A
NO. PARTS
1
LED_B/G
LF_LED
R201
1M 1/16W
MCU_VDD
2
3
4
5
6
103
104
105
106
107
108
109
110
111
C220
22pF
R225
100R 1/16W
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
R218
22R 1/16W
VSO
HSO
VGA_VDD
+5V
PANEL_IDX
DVI_VDD
ZD201
RLZ2.2B
R202
10K 1/16W
D201
BAV70
5V_DECT5V_DECT
INT_EDID MCU POWER
R233
NC
CVDD18
R234
220R 1/16W
CVDD18
C212
NC
5
R214
4K7 1/16W
C216
0.1uF 16V
MCU_VDD
Q201
2N3906S-RTK/PS
R206
4K7 1/16W
VGA cable
detect(high to
low)
VGA_CABLE
H_SCL
H_SDA
AUDIO_STDBY
DVI cable
detect(high to
low)
C219
TCLK
modify
part070102
(for flash )
5V_DECT
CVDD18
BRIGHTNESS
BL_CONTROL
DVI_CABLE
KEY2
KEY1
1 2
X201
12.000MHz
22pF
FB202
120OHM
1 2
FB203
120 OHM
B B
+3.3VCC
C C
1 2
FB204
120 OHM
1 2
FB205
120 OHM
1 2
FB201
NC
1 2
26
C203
0.1uF 16V
53
C204
0.1uF 16V
6
C206
0.1uF 16V
17
C208
0.1uF 16V
90
C205
0.1uF 16V
15
C207
0.1uF 16V
ADC_VAA
DVDD
AVCC
PVCC
MCU_VDD
EXT_EDID MCU POWER
+1.8VCC
FB206
120OHM
115
C209
0.1uF 16V
R213
MCU_VDD
C222
NC
OPTION(HDCP)
52
4K7 1/16W
C210
0.1uF 16V
R215
R231
NC/4K7 1/16W
R232
NC/0R05 1/16W
1 2
D D
MCU_VDD
C213
1uF 16V
U204
1
8
VCC
NC
2
7
NC
WC
3
6
NC
SCL
CN202
NC
4 5
VSS SDA
M24C16
SMT TYPE
U201
1
2
3
4
MCU_VDD
1
2
3
4
A0
A1A2WP
GND
NC
SMT TYPE
8
VCC
7
6
SCL
5
SDA
TX
RX
E E
F F
G G
4K7 1/16W
24C16_WP
IICSCL
IICSDA
R229
NC
R230
NC
CVDD18
NC
NC
R224
R223
DDC_WP
H_SCL
H_SDA
NONE OD OD
U203
NT68665 NT68670
NCR209 0R
R218
C212
C211 NC 0.1u
4
RX2+
RX2RX1+
RX1RX0+
RX0RXC+
RXC-
BIN+
BINSOG
GIN+
GINRIN+
RIN-
PC7
PD0
PD1
PD2
PD3
PD4
NC/(HSYNCI)
GPO1
AD0/GPO2
AD1/GPO3
INT_VSO/GPO4
INT_HSO/GPO5
CVDD
GPO6
PWMA/GPO7
PWMB/GPO8
NC/(VSYNCI)
PC0*
PC1*
PC3/PWM0
PC4/PWM1
PC5
PB1/ADC1
PB0/ADC0
OSCI
OSCO
MCU_VDD
22R NC
NC 0.1u
1
101
102
PC6
RSRB3M
DGND/CGND
RSTB
MCU_VCC
MCU_GND
12345
C201
0.1uF 16V
DVDD
MCU_VDD
99
RSRB2P
RSRB3P
RSRB2M
AVCC
RX2+
RX2-
678911
AVCC
RSRB1M
RX1+
NCR228 0R
R211
0R05 1/16W
R210
NC
949396959897100
RSRB1P
RX1-
RSGB3M
AGND
RSGB3P
RX0+
10
92
RSGB2M
RX0-
899091
88
SP
DVDD
RSGB2P
RSGB1P/T0P
RSGB1M/T0M
U203
NT68665MFG-128
AGND
RXC+
RXC-
REXT
AVCC
12
171819202122232425262728293031323334353637
131416
15
R221
470R 1/16W
PVCC
AVCC
858687
RSCLKBP/T1P
RSCLKBM/T1M
PVCC
PGND
RSBB3P/T2P
RSBB3M/T2M
BIN1+
BIN1-
8081828483
RSBB1M/T3M
RSBB2P/TCLK1P
RSBB2M/TCLK1M
SOG1I
GIN1+
GIN1-
78
79
RSBB1P/T3P
DGND/CGND
RIN1+
RIN1-
ADC_VAA
RSRA3P/T4P/RSRB0P
RSRA2P/T5P/RSGB0P
RSRA3M/T4M/RSRB0M
RSRA2M/T5M/RSGB0M
ADC_VAA
ADC_GNDA
PC2
PD6
72
7374757677
RSGA3P/TCLK2P
RSGA3M/TCLK2M
RSRA1P/T6P/RSBB0P
RSRA1M/T6M/RSBB0M
PB3/ADC3/INT1
P31/TXD
P30/RXD
PB2/ADC2/INT0
697071
68
RSGA2P/T7P
RSGA2M/T7M
PB7*/DDC_SDA1
PB6*/DDC_SCL1
RX
TX
HSO
24C16_WP
PA2/PWM4
PA1/PWM3
PA3/PWM5
PA4*/PWM6*
656667
PA0/PWM2
CGND/DGND
RSGA1M
RSGA1P/VCKI
RSCLKAM/V7
RSCLKAP/V6
RSBA3M/V5
RSBA3P/V4
RSBA2M/V3
RSBA2P/V2
RSBA1M/V1
RSBA1P/V0
DVDD
CVDD
SCL/P34
SDA/P35
RSTn/PD5
PB4*/DDC_SCL0
PB5*/DDC_SDA0
PLL_VDD
PLL_GND
TOUTP/VSYNCI1
HSYNCI1
PA7*/PWM9*
PA6*/PWM8*
PA5*/PWM7*
38
VSO
R228
0R05 1/16W
T0M
T0P
T1M
T1P
T2M
T2P
TCLK1M
TCLK1P
T3M
T3P
T4M
T4P
T5M
T5P
T6M
T6P
TCLK2M
TCLK2P
T7M
LED_R
CVDD18
VGA_SCL
VGA_SDA
LIGHT_SEN
modify
parts
1/18
NC
2
R207
DDC_WP
DVI-HPD
R209
NC
DVI_SCL
DVI_SDA
MCU_VDD
T7P
C215
0.1uF 16V
DVDD
1 2
+
R219
NC
R220
NC
C211
NC
FB207
1000OHM
C214
100uF/16V
VS
HS
+1.8VCC
+5V
modify
parts
1/18
6
VOLUME
PANEL_PWR
KEY_PWR
64
63
62
61
60
59
58
57
56
DVDD
55
54
53
52
IRQN
51
IRQn
TCLK
IICSCL
50
IICSDA
49
48
47
46
45
TCLK
44
43
42
41
40
39
IRQN
3
R205
NC
C202
NC
CN202 G2 C201 F5
C202 F8 C203 B3
C204 B3 C205 B3
C206 C3 C207 C3
C208 C3 C209 D2
C210 D3 C211 D9
C212 D4 C213 E2
C214 E9 C215 E9
C216 E4 C219 E4
C220 E5 C222 F2
D201 B4 FB201 C2
FB202 A2 FB203 B2
FB204 B2 FB205 C2
FB206 D2 FB207 D9
Q201 B4 R201 E5
R202 C3 R205 F8
R206 B4 R207 E9
R209 D9 R210 B6
R211 B6 R213 E2
R214 E4 R215 E3
R218 E5 R219 E9
R220 E9 R221 F6
R223 F3 R224 F3
R225 F5 R228 F8
R229 F3 R230 F3
R231 F3 R232 F3
R233 B4 R234 C4
U201 F2 U203 C5
U204 E2 X201 E5
TO RS232
H H
1
2
3
4
http://www.wjel.net
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
10
HUDSON 8
11
23
DC-DC
A A
+5V
C302
C304
1uF 16V
C317
0.1uF 16V
10uF/16V
Q302
AO3401
4K7 1/16W
2N3904S-RTK/PS
R305
10K 1/16W
R307
C308
1uF 16V
PANEL_IDX
FB303
120OHM
51K OHM 1/16W
Q301
2N3904S-RTK/PS
+5V
C315
100uF/16V
+
R309
100R 1/16W
+12V
R308 4K7 1/16W
R304
10K 1/16W
C316
0.1uF/25V
B B
C C
CN301
D D
CONN
E E
1
2
3
4
5
6
7
8
9
PANEL_PWR
R314
Q305
PANEL_VCC
+
+3.3VCC
C303
0.1uF 16V
FB302
120OHM
R301
1K 1/16W
R302
330 OHM 1/4W
+5V
R311
1K 1/16W
R316 4K7 1/16W
R303
330 OHM 1/4W
+3.3VCC
R312
1K 1/16W
BRIGHTNESS
modify
1/8
BL_CONTROL
+5V
D301
SM340A
+5V
C311
0.1uF 16V
C301
0.1uF 16V
+
+
C309
100uF/16V
C305
100uF/16V
U303
NC
3 2
VI VO
GND
1
AP1117D33LA
ADJ(GND)
VOUT
VIN
123
U304
AP1117E18LA
3 2
VI VO
GND
1
U302
NC
OUTPUT
INPUT
U301
ADJ/GND
123
+3.3VCC
C307
0.1uF 16V
C312
0.1uF 16V
+
C306
100uF/16V
+1.8VCC
+
C310
100uF/16V
CN301 D1
C301 B7
C302 A3
C303 A4
C304 B3
C305 B7
C306 B9
C307 B8
C308 B2
C309 E7
C310 E9
C311 E7
C312 E9
C315 D3
C316 E1
C317 D3
D301 E6
FB302 B4
FB303 D2
Q301 B2
Q302 B3
Q305 E4
R301 E4
R302 A4
R303 A4
R304 B1
R305 B2
R307 B2
R308 B2
R309 D1
R311 D4
R312 D5
R314 D3
R316 E4
U301 B8
U302 D8
U303 A8
U304 D8
F F
http://www.wjel.net
G G
H H
1
2
3
4
5
6
7
8
9
10
11
24
HUDSON 8
1
2
3
4
5
6
7
8
9
10
11
CONNECTOR
A A
CN402
T0M
T0P
T1M
T1P
T2M
T2P
TCLK1M
TCLK1P
T3M
T3P
R413
NC
EAR-SENSE
EAR-R
T4M
T4P
T5M
T5P
T6M
T6P
TCLK2M
TCLK2P
T7M
T7P
T0P
T0M
T1P
T1M
T2P
T2M
TCLK1P
TCLK1M
T3P
T3M
T4P
T4M
T5P
T5M
T6P
T6M
TCLK2P
TCLK2M
T7P
T7M
LVDS OUTPUT
+5V
+12V
B B
R411
0.1uF 16V
NC
C405
R437
NC
NC
+3.3VCC
R435
NC
R436
NC
11
R430
NC
+5V
CN403
9
7
5
3
1
NC/CONN
R438
NC
R433
NC
FB403
1 2
NC
12
10
8
6
4
2
BRIGHTNESS
VOLUME
OUT-L+
OUT-LEAR-L
PANEL_VCC
CN406
NC
R434
1
2
3
4
5
6
C C
D D
E E
F F
OPTION(AUDIO CONTROL)
R414
NC
R421
NC/10K 1/16W
OUT-R-
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
OUT-R+
CONN
R404
NC
modify
1/18
CN401
KEY1_PAD
1
KEY2_PAD
2
POWER
3
LED_G
4
LED_O
5
6
7
8
9
10
11
12
13
NC/CONN
CN407
KEY1_PAD
1
KEY2_PAD
2
POWER
3
LED_G
4
LED_O
5
6
LF_B
7
CONN
R432
NC/0R05 1/16W
http://www.wjel.net
LIGHT_SEN
5V_FB
OUT-L+
OUT-L-
EAR-R
EAR-L
R431
NC
AUDIO_STDBY
LF_B
CN405
CN404
NC
1
2
3
4
5
6
7
KEY1_PAD
KEY2_PAD
POWER
LED_G
LED_O
LF_B
KEY1_PAD
KEY2_PAD
POWER
LED_G
LED_O
LF_B
5V_FB
LIGHT_SEN
FB401
1 2
NC
1
2
3
4
5
6
7
8
9
C402
0.1uF 16V
C403
0.1uF 16V
C404
0.1uF 16V
R416 100R 1/16W
C406
0.1uF 16V
R418 100R 1/16W
C407
0.1uF 16V
+5V
NC
R424 NC
C401
R407
100R 1/16W
R410
100R 1/16W
R412 1K 1/16W
+3.3VCC
+3.3VCC
2N3906S-RTK/PS
+3.3VCC
Auto/Left/Right key
Menu/Up/Down key
Q402
2N3906S-RTK/PS
Q403
Q404
NC
+3.3VCC
R402
3.9K OHM 1/16W
R415 10K 1/16W
R417 10K 1/16W
R423 NC
R403
3.9K OHM 1/16W
KEY1
KEY2
KEY_PWR
LED_R
LED_B/G
LF_LED
CN401 B4 CN402 A4
CN403 F2 CN404 E6
CN405 F5 CN406 D1
CN407 D4 C401 F8
C402 C8 C403 C8
C404 D8 C405 C2
C406 D8 C407 E8
FB401 F7 FB403 E3
Q402 D8 Q403 E8
Q404 E8 R402 B9
R403 B9 R404 E4
R407 B8 R410 C8
R411 C2 R412 C8
R413 C3 R414 C3
R415 D9 R416 D8
R417 E9 R418 E8
R421 F3 R423 E9
R424 F8 R430 C2
R431 E5 R432 E4
R433 D2 R434 F2
R435 F2 R436 E2
R437 D2 R438 D2
NC
G G
H H
1
2
3
4
5
6
7
8
9
10
11
HUDSON 8
6.2 Power Board
715G2594-1
POWER
A A
B B
C C
D D
E E
BD901
KBP208G
3
!
R900
330K 1/4W
1
L902
1
4
L
VAR901
NC
L901
3
4
4.0mH
C909 0.47uF
330K 1/4W
!
1
+
-
4
R901
!
3
!
2
3
2
!
1
CN901
SOCKET
2
!
!
R902
330K 1/4W
12
C902
1000pF
C901
1000pF
!
!
!
2
12
FB903
BEAD
+
C907
100uF/450V
!
C903
1000PF
!
!
C912
0.1uF 50V
C916
0.1uF 50V
!
1
RT
2
COMP
3
CS
4 5
GNDOUT
LD7575PS
C914
470pF/25V
GND1
GND
HS1
HEAT SINK(Q900)
NR901
NTCR
F901
FUSE
R911
ǂ
100K 1/8W
1
2
1
2
IC901
VCC
NC
3
R905
ǂ
10K 1/4W
D901
UF4003PT
+
C911
22uF/50V
ZD901
NC
1 2
8
HV
7
6
GND2
GND
1
2
HS5
HEAT SINK(D920)
1
2
D910 LL4148WP
R912
10R 1/4W
C913
220pF 50V
R915
10K 1/8W
R913
1K 1/8W
D911
NC
C915
NC
4
C910
1500PF/2KV
5
R95147 1/4W
R95247 1/4W
R95347 1/4W
3
1
D921
3
NC
2
1
R954 47 1/4W
R955 47 1/4W
R956 47 1/4W
ǂ
ǂ
ǂ
R909
ǂ
100K 2W
D900
BA159GPT
12
FB901
BEAD
!
Q900
STP10NK70ZFP
R916
ǂ
0.43 2W
R910
ǂ
2.2 1/4W
ZD902
1 2
T901
80GL17T-33-N2
4
5
6
4
6
1
3
NC
ǂ
ǂ
ǂ
!
9
7
11
10
8
12
!
12
IC902
PC123X2YFZOF
43
!
C900
FB902
2200PF
1 2
Jumper
Q910
NC
IC903
KIA431A-AT/P
http://www.wjel.net
6
C920
0.001uF/500V
D920
SBT150-10LST
2
D922
31DQ06FC3
C921
0.001uF/500V
R922
330R 1/8W
R925
1K 1/8W
LL4148WP
C928
0.1uF 50V
R928
1K 1/8W
ZD921
RLZ13B
1 2
D915
R927
1K 1/8W
+
C922
+
+
680uF/25V
C926
1000uF/16V
CHANGE 13X20mm
ZD922
RLZ5.1B
1 2
D916
LL4148WP
C923
680uF/25V
+
C924
R923
10K 1/8W
C929
0.1uF 50V
1K 1/8W
7
NC
R930
L921
3.5uH
L922
3.5uH
+
C925
470uF/25V
R924
3K6 1/8W
R929
ǂ
2.4K 1/8W
R931
10K 1/4W
ǂ
+
C927
470uF/16V
R926
33K 1/8W
8
R907
ǂ
150 1W
Q902
PMBS3904
CN902
CONNECTOR
1
2
3
4
5
6
7
8
9
10
C904
0.001uF 50V
C931
0.1uF 50V
ON/OFF
+5V
1 2
R908
470 1/8W
R903
1K 1/8W
9
F902
0R05 1/4W
ZD920
RLZ13B
ǂ
F903
JUMPER
DIM
C930
0.1uF 50V
+12V
12V
BD901 A1 CN901 E1
CN902 C8 C900 E4
C901 B2 C902 B2
C903 B2 C904 B8
C907 B2 C909 D1
C910 B4 C911 B3
C912 B2 C913 D3
C914 D2 C915 F4
C916 B2 C920 A6
C921 C6 C922 B6
C923 B6 C924 B7
C925 B7 C926 C6
C927 C8 C928 E6
C929 E7 C930 D9
C931 D8 D900 B4
D901 B4 D910 C3
D911 E4 D915 D6
D916 D6 D920 A6
D921 B5 D922 C6
+5V
FB901 C4 FB902 E5
FB903 A2 F901 E2
F902 A9 F903 C9
GND1 E2 GND2 E3
HS1 F2 HS5 F3
IC901 C3 IC902 D5
IC903 E5 L901 C1
L902 B1 L921 A7
L922 B7 NR901 D2
Q900 C4 Q902 B8
Q910 E4 R900 D1
R901 D1 R902 D2
R903 B9 R905 B3
R907 B8 R908 B9
R909 B4 R910 C4
R911 C2 R912 C3
R913 D4 R915 C4
R916 D4 R922 D6
R923 E7 R924 D7
R925 D6 R926 E8
R927 E6 R928 E6
R929 E7 R930 E7
R931 B8 R951 A6
R952 A6 R953 A6
R954 C5 R955 C5
R956 C5 S1 A1
S2 B1 S3 B2
S4 C2 S5 C1
S6 D1 S7 D2
S8 E2 S9 E1
S10 B2 S11 A5
S12 C4 S13 D5
S16 E4 S17 B3
S19 C1 S20 D2
S21 D1 T901 B5
VAR901 B1 ZD901 C3
ZD902 D4 ZD920 B9
ZD921 D6 ZD922 D6
10
25
F F
1
2
3
4
5
6
7
8
9
10
26
A A
B B
C C
HUDSON 8
1
INVERTER
+12V
ON/OFF
DIM
R827
1K 1/10W 1%
R808
10K 1/10W 1%
R809
NC
R813
100 1/10W 5%
2
Q802
PDTC144WK
C819
R816
NC
ǂ
68K 1% 1/10W
R820
ǂ
560K 1/10W 5%
D811
LL4148WP
R821 1M 1/10W 5%
C802
1uF 16V
R818
NC
LL4148WP
C808 2.2uF/16V
D803
LL4148WP
Q803
PMBS3904
D812
10K 1/10W
R822 47K 1/10W 1%
R823
3
R802
100R 1/8W 5%
Q801
PDTA144WK
C806
1uF/16V
R824
R817
NC
R819
10K 1/10W 1%
C807
0.1uF/16V
10K 1/10W 1%
C809 220pF
R815
47K 1/10W 1%
DTC
R842
47K 1/10W 1%
ǂ
R825 51K 1% 1/8W
R843 NC
4
R814
75K 1/10W 1%
C804
0.1uF/16V
ǂ
180K 1% 1/8W
D813
DTC
1
2
3
4
5
6
7
8 9
R826
LL4148WP
FB
IC801
1IN+
1INFEEDBACK
DTC
OUTPUT CTRL
CT
RT
GND
C1 E1
TL494IDR
RK7002
2IN+
2IN-
REF
VCC
C2
E2
Q812
5
R805
4.7K 1/10W 5%
16
15
14
13
12
11
10
ZD801
10K 1/4W 5%
1 2
R803
ǂ
2.4K 1/10W
R853
10K 1/10W 1%
C810
0.1uF/25V
R852
10K 1/10W 1%
6
15 1/4W
Q804
AM9945N-T1-PF
Q810
PMBS3904
Q805
PMBS3906
R844
22R 1/10W 5%
R848
1K 1/10W 1%
R850
ǂ
C821
1500PF/50V
8
D
S
1
R845
22R 1/10W 5%
7
PT801
POWER X'FMR
6
3
4
R810
ǂ
15 1/4W
C803
1500PF/50V
7
6
5
D
D
D
G
S
G
4
C805
470uF/25V
+
C823
0.1uF/25V
Q811
PMBS3904
Q806
PMBS3906
R846
22R 1/10W 5%
R847
22R 1/10W 5%
R849
1K 1/10W 1%
2
3
!
FB
7
81
D801
BAV99
2
8
10pF/3KV
3
C801
R806
1K 1/10W 1%
1
9
R801 0R05 1/10W 5%
1
4
R804 0R05 1/10W 5%
R807
1K 1/10W 1%
OLP1 OLP2
D802
3
BAV99
R811
1K 1/10W 1%
2
R812
1
1
2
2
3
1K 1/10W 1%
CN801
L801
CONN
NC
1
2
CN802
CONN
CN801 A10 CN802 A10 CN803 D10
CN804 E10 C801 A8 C802 A2
C803 B7 C804 B4 C805 B7
C806 C3 C807 C3 C808 C2
C809 D3 C810 D6 C811 E7
C812 D8 C813 E3 C814 E1
C815 E3 C816 D7 C817 E3
C818 E3 C819 B2 C820 D4
C821 B6 C822 E7 C823 B7
C824 E7 D801 B8 D802 B9
D803 B3 D806 D2 D807 D1
D808 E2 D809 E8 D810 E9
D811 C2 D812 C3 D813 B5
IC801 C4 L801 A9 L802 D9
PT801 A7 PT802 D7 Q801 A3
Q802 A2 Q803 B2 Q804 B6
Q805 C6 Q806 C7 Q807 D4
Q808 D1 Q809 E6 Q810 C6
Q811 C7 Q812 B5 R801 A9
R802 A3 R803 B5 R804 A9
R805 A5 R806 A8 R807 A9
R808 A2 R809 A2 R810 A6
R811 B8 R812 B9 R813 B2
R814 B4 R815 B3 R816 B2
R817 B3 R818 C3 R819 C3
R820 C2 R821 C2 R822 C3
R823 C3 R824 C3 R825 D4
R826 D4 R827 D1 R828 D2
R829 D3 R830 D9 R831 D3
R832 D9 R833 D3 R834 E8
R835 E9 R836 E1 R837 D7
R838 E3 R839 E8 R840 E3
R841 E9 R842 C4 R843 D4
R844 C6 R845 C6 R846 C7
R847 C7 R848 D6 R849 D7
R850 A6 R851 E7 R852 D5
R853 C5 S14 A8 S15 D8
10
D D
Q808
RK7002
C814
E E
F F
0.1uF/16V
R828
47K 1/10W 1%
D807
LL4148WP
R836
1M 1/10W 5%
D806
BAW56
B
3
C
E
D808
BAW56
B
3
C
E
ǂ
68K 1% 1/10W
1
2
1
2
R829
C815
0.0022uF
C818
0.0022uF
R831
10K 1/10W 1%
R833
10K 1/10W 1%
C813
0.0022uF
R838
10K 1/10W 1%
R840
10K 1/10W 1%
C817
0.0022uF
OLP1
OLP2
OLP3
OLP4
C820
NC
!
Q807
PMBS3904
1
2
3
4
S
S
G
Q809
AM9945N-T1-PF
D
8
G
0.1uF/25V
D
D
D
7
6
5
http://www.wjel.net
C824
C816
1500PF/50V
R837
ǂ
15 1/4W
+
470uF/25V
R851
ǂ
15 1/4W
C822
1500PF/50V
C811
CHANGE UPDATE
POWER X'FMR
6
3
4
PT802
7
C812
10pF/3KV
81
R834
1K 1/10W 1%
OLP3
D809
3
BAV99
R839
1K 1/10W 1%
1
2
FB
D810
BAV99
R830 0R05 1/10W 5%
1
4
R832 0R05 1/10W 5%
R835
1K 1/10W 1%
3
1
2
2
3
OLP4
R841
1K 1/10W 1%
L802
NC
1
2
1
2
CN803
CONN
CN804
CONN
1
2
3
4
5
6
7
8
9
10
HUDSON 8
6.3 Key Board
715G1755-2
A A
B B
C C
1
CN101
CONN
1
2
3
4
5
6
C101
0.01uF
C102
0.01uF
LED-G
1
2
LED-O
3
LED1
LED
C103
0.01uF
2
R101
100R 1/10W 5%
C104
0.01uF
C105
0.01uF
LED-G
LED-O
K-PWR
KEY1
KEY2
SW8
3 4
3
R108
2.4Kȍ 1/10W
SW7
21
5
SW
3 4
KEY1
R107
910ȍ 1/10W
21
5
SW
SW6
SW
3 4
R106
4K3 1/10W
21
5
4
SW5
SW
3 4
K-PWR
R105
NC
R109
0R05 1/10W 5%
21
5
SW4
SW
3 4
21
5
2.4Kȍ 1/10W
SW3
SW
3 4
R104
21
5
5
KEY2
SW2
3 4
R100
0R05 1/8W
R103
910ȍ 1/10W
21
5
SW
3 4
add on Mar.-31-07
R102
4K3 1/10W
SW1
21
5
SW
6
CN101 B1
C101 B1
C102 B2
C103 B2
C104 B2
C105 B3
LED1 C1
R100 B5
R101 B2
R102 B6
R103 B5
R104 B5
R105 C4
R106 C3
R107 C3
R108 C3
R109 C4
SW1 C6
SW2 C5
SW3 C5
SW4 C4
SW5 C4
SW6 C3
SW7 C3
SW8 C3
7
8
KEY-MENU/ENTERKEY-SOURCE
KEY-BRIGHTNESS
KEY-SMART IMAGE
KEY-VOLUME
KEY-POWER
KEY-AUTO/BACK
27
KEY-LIGHT FRAME
D D
http://www.wjel.net
E E
1
2
3
4
5
6
7
8
28
HUDSON 8
7. PCB Layout
7.1 Scalar Board
715G2561-1
C101 B3 C215 B3 D105 C1 Q301 A3 R144 C2 R410 B1
C102 C1 C216 A1 D106 C2 Q302 A3 R201 B2 R411 A3
C103 C1 C219 B2 D107 C2 Q305 A1 R202 A2 R412 B1
C104 B1 C220 B2 D108 C2 Q402 B2 R205 A1 R413 A3
C105 C2 C222 B3 D109 C2 Q403 B2 R206 B3 R414 A3
C106 C2 C301 B2 D110 B3 Q404 B1 R207 B3 R415 B2
C107 C2 C302 A3 D111 C3 R101 C3 R209 B3 R416 B2
C110 B1 C303 A3 D112 C3 R102 C1 R210 A2 R417 B2
C111 B2 C304 A3 D113 C2 R103 C2 R211 A2 R418 B1
C112 B2 C305 B2 D201 B3 R104 C2 R213 B3 R421 B2
C113 C2 C306 B1 D301 A2 R105 C2 R214 B2 R423 B1
C114 B2 C307 B1 FB101 C2 R106 C1 R215 B3 R424 B1
C115 C3 C308 A3 FB102 B3 R107 C1 R218 B2 R430 A3
C116 C3 C309 A2 FB103 C3 R108 C2 R219 B3 R431 B1
C117 C3 C310 A2 FB104 C3 R109 B2 R220 A1 R432 A1
C118 C2 C311 A2 FB105 C3 R110 B1 R221 B2 R433 A1
C121 B3 C312 A2 FB106 C2 R111 B1 R223 B3 R434 B1
C122 B3 C315 A1 FB107 C1 R113 C2 R224 A3 R435 B1
C123 B2 C316 A1 FB201 B3 R115 C2 R225 B2 R436 B1
C124 B3 C317 A1 FB202 B3 R116 C2 R228 B3 R437 A1
C125 B3 C401 B1 FB203 B3 R117 B2 R229 B3 R438 A1
C126 B2 C402 B1 FB204 B2 R118 B2 R230 B3 R439 B1
C127 B3 C403 B1 FB205 B2 R120 B2 R231 B3 U101 B2
C128 C3 C404 B1 FB206 B2 R122 C2 R232 B3 U102 B3
C129 B2 C405 A3 FB207 B3 R123 B3 R233 B3 U201 B3
C130 C2 C406 B2 FB302 A3 R124 B3 R234 B2 U203 B2
C131 C1 C407 B1 FB303 A1 R125 B3 R301 A1 U204 B3
C132 C1 CN101 C3 FB401 B1 R126 C3 R302 A3 U301 B1
C201 B2 CN102 C2 FB403 A1 R127 C3 R303 A3 U302 A2
C202 A1 CN202 B3 FDT1 B3 R128 C3 R304 A3 U303 B1
C203 B2 CN301 A2 FDT10 <1 R129 C3 R305 A3 U304 A2
C204 B3 CN401 B1 FDT11 C8 R131 C2 R307 A3 X201 B2
C205 B3 CN402 A2 FDT12 <8 R132 C3 R308 A3 ZD101 C3
C206 B2 CN403 B1 FDT13 C1 R133 C3 R309 A1 ZD102 B1
http://www.wjel.net
C207 B2 CN404 B1 FDT2 A2 R134 C3 R311 A1 ZD103 B2
C208 B2 CN405 B1 FDT3 A3 R135 C2 R312 A1 ZD104 B2
C209 B3 CN406 A1 FDT4 C1 R136 C3 R314 A1 ZD105 C3
C210 B2 CN407 B1 FDT5 C1 R138 C2 R316 A1 ZD106 C3
C211 A2 D101 C1 FDT6 <1 R139 C3 R402 B1 ZD107 C3
C212 B2 D102 C2 FDT7 C8 R140 C2 R403 B1 ZD201 B2
C213 B3 D103 C1 FDT8 <8 R141 C3 R404 A1
C214 B3 D104 C1 Q201 B3 R142 C3 R407 B1
HUDSON 8
29
http://www.wjel.net
30
HUDSON 8
7.2 Power Board
715G2594-1
BD901 D4 J802 C2
C801 A1 J803 B1
C805 B2 J804 B1
C811 C2 J805 B2
C812 D1 J806 B1
C900 B4 J808 C2
C901 D3 J809 C2
C902 D3 J810 C2
C903 D4 J811 C2
C907 C4 J812 B2
C909 D3 J817 C2
C910 C4 J819 B2
C911 C3 J901 D3
C920 B3 J903 C3
C921 B4 J904 A3
C922 B3 J905 A3
C923 B3 J906 A4
C924 B3 J909 A2
C925 A3 J910 A2
C926 B3 L801 B1
C927 A4 L802 C1
C932 B4 L901 D3
CN801 A1 L902 D4
CN802 A1 L921 A3
CN803 D1 L922 A4
CN804 D1 NR901 C2
CN901 D2 PT801 B1
CN902 A4 PT802 C2
D804 B1 Q900 C4
D805 B1 R907 A3
D814 C1 R909 C3
D815 C2 R916 C4
D900 C3 SG11 C4
D901 C3 SG12 D2
D920 A3 SG19 D2
D921 B4 SG22 D4
D922 A4 SG25 D4
F901 D2 SG27 D3
F903 A4 SG28 C3
FB901 C4 SG31 D3
FB902 B4 SG33 A1
FB903 C4 SG34 A1
http://www.wjel.net
HS10 A3 SG35 A1
HS13 A3 SG36 A1
HS14 A2 SG39 A1
HS16 A2 SG40 D1
HS17 B4 SG42 D1
HS20 A8 SG44 D1
HS28 A7 SG45 D1
HS29 B1 SG46 C4
HS31 B4 SG47 C4
IC902 B3 SG49 C4
IC903 B3 T901 C3
J801 B2 VAR901 D3
C802 A2 J907 C3 R843 B2
C803 B1 J908 C3 R844 B2
C804 B2 Q801 A2 R845 B1
C806 B2 Q802 A2 R846 B1
C807 C2 Q803 A2 R847 C2
C808 B2 Q804 B1 R848 B2
C809 C2 Q805 B1 R849 B2
C810 A2 Q806 B1 R850 B2
C813 B1 Q807 B2 R851 C2
C814 B2 Q808 B2 R852 B2
C815 B1 Q809 C1 R853 B2
C816 C1 Q810 C2 R900 D3
C817 C1 Q811 B1 R901 D3
C818 C1 Q812 A2 R902 C2
C819 A2 Q902 A3 R903 A3
C820 B2 Q910 C3 R905 C3
C821 B2 R801 B1 R908 A3
C822 C2 R802 B2 R910 C3
C823 B2 R803 A2 R911 C3
C824 C2 R804 B1 R912 C3
C904 A3 R805 B2 R913 C3
C912 C3 R806 B1 R915 C3
C913 C3 R807 B1 R922 A3
C914 C3 R808 A2 R923 A2
C915 C3 R809 A2 R924 A2
C916 C3 R810 B1 R925 B3
C928 B3 R811 B1 R926 A3
C929 B2 R812 B1 R927 B2
C930 A4 R813 A2 R928 B3
C931 A4 R814 C2 R929 B2
D801 B1 R815 B2 R930 B2
D802 B1 R816 B2 R931 A3
D803 A2 R817 B2 R951 B3
D806 B1 R818 B2 R952 B3
D807 B2 R819 B2 R953 B3
D808 C1 R820 B2 R954 B4
D809 C1 R821 B2 R955 B4
D810 C1 R822 C2 R956 B4
D811 B2 R823 B2 SG10 C3
D812 B2 R824 C2 SG15 D3
D813 B2 R825 B2 SG17 D3
D910 C3 R826 B2 SG18 D4
D911 C3 R827 B2 SG20 D4
D915 A2 R828 B2 SG21 D3
D916 A2 R829 B2 SG23 D4
http://www.wjel.net
F902 A3 R830 C1 SG24 D3
HS11 D4 R831 B1 SG26 D4
HS15 A1 R832 C1 SG29 C3
HS21 A7 R833 B1 SG30 D3
HS22 A1 R834 C1 SG32 D3
IC801 B2 R835 C1 SG37 D2
IC901 C3 R836 B2 SG38 D2
J807 C2 R837 C2 ZD801 A2
J813 C1 R838 C1 ZD901 C3
J814 C1 R839 C1 ZD902 C4
J815 C1 R840 C1 ZD920 A3
J816 B2 R841 C1 ZD921 A2
J818 A2 R842 C2 ZD922 A2
HUDSON 8
31
32
HUDSON 8
7.3 Key Board
715G1755-2
CN101 A1
LED1 A4
SW1 A5
SW2 A5
SW3 A5
SW4 A4
SW5 A4
SW6 A3
SW7 A3
SW8 A3
GND A2
C101 A1
C102 A1
C103 A4
C104 A4
C105 A5
R100 A4
R101 A4
R102 A5
R103 A5
R104 A4
R105 A4
R106 A3
R107 A3
R108 A2
R109 A4
http://www.wjel.net
HUDSON 8
33
8. Wiring Diagram
Lamp Wire Harness
CN402
Lamp Wire Harness
CN801
CN802
Power Board
CN902
Panel
Power Wire Harness
FFC
Panel Interface
CN301 CN402
CN804
CN803
CN901
CN407
Main Board
CN102
CN101
D-SUB
AC-IN
Key Board Wire
DVI
CN101
http://www.wjel.net
Key Board
34
HUDSON 8
9. Mechanical Instructions
1. Back View as Fig1
Place the monitor face down on a smooth surface as Fig 1. Be careful to avoid scratch and injury during the
uninstallation.
Fig1
2. Remove the cable management as Fig2.
http://www.wjel.net
Fig2
3. Remove the base as Fig3~Fig4.
Fig3
HUDSON 8
35
http://www.wjel.net
Fig4
36
4. Remove the stand as Fig5 and Fig6.
Remove the four screws to remove the stand.
HUDSON 8
Fig5
Fig6
http://www.wjel.net
5. Remove the hinge as Fig7.
HUDSON 8
37
Remove the three screws to remove the hinge.
Fig7
6. Remove rear cover as Fig8~Fig11
a. Remove 2 screws to remove rear cover as Fig8.
b. Use plastic putty knife to release 3 snaps on the bottom as Fig. 9 - Fig.11
http://www.wjel.net
Fig8
38
HUDSON 8
3 snaps on the bottom
Fig9
Plastic putty knife
Fig.10
http://www.wjel.net
Fig11
c. Insert plastic putty knife into the gap between front bezel and back cover to release 4 snaps on the left, 4 snaps on
the right and 4 snaps on the top as Fig12 - Fig15
Insert plastic
putty knife into
the gap between
front bezel and
back cover
HUDSON 8
39
Front Bezel
Back cover
Fig12
4 snaps on the left
Fig13
4 snaps on the right
http://www.wjel.net
Fig14
40
7. Remove shielding as Fig16.
Remove 8 screws as Fig16.
HUDSON 8
4 snaps on the top
Fig15
Fig16
http://www.wjel.net
8. Remove main board and power board as Fig17.
Remove 7 screws to remove main board and power board as Fig17.
HUDSON 8
41
Fig17
9. Remove the bezel as Fig18- Fig20
a. Remove 2 screws to remove the key board as Fig18
b. Remove 2 screws at the left of bezel as Fig19
c. Remove 2 screws at the right of bezel as Fig20
http://www.wjel.net
Fig18
42
HUDSON 8
Fig19
Fig20
10. Remove the main frame as Fig21- Fig22
a. Remove 2 screws at the right of main frame Fig21.
b. Remove 2 screws at the left and 1screw at the bottom of the main frame Fig22.
http://www.wjel.net
Fig21
Fig22
11. The end as Fig23.
HUDSON 8
43
Fig23
http://www.wjel.net
44
10. Trouble Shooting
This page deals with problems that can be corrected by a user. If the problem still persists after you
have tried these solutions, contact Philips customer service representative.
HUDSON 8
http://www.wjel.net
HUDSON 8
45
http://www.wjel.net
46
HUDSON 8
11. Repair Flow Chart
11.1 Main Board
(1). No Power
Press power key and look
if the picture is normal
Please reinsert and make sure
the AC of 100-240 is normal
Measure U301 PIN2=3.3V
Measure U304 PIN2=1.8V
X201 oscillate waveforms
are normal
http://www.wjel.net
No power
NG
OK
OK
OK
Replace U203
NG
NG
NG
Reinsert or check the
Adapter/Inverter
section
Replace D301, U301 or
U304
Replace X201
(2). No Picture
Measure U301 PIN2=3.3V
Measure U304 PIN2=1.8V
X201 oscillate waveforms are normal
Check if the sync signal from
computer is output and video cable
is connected normally
No picture
OK
OK
OK
NG
NG
NG
Replace D301, U301 or U304
Replace X201
Input the sync signal of
computer, or change
the cable
HUDSON 8
47
Replace U203
http://www.wjel.net
48
p
p
(3). White screen
HUDSON 8
White screen
Measure Q301 base
is high level?
NG
X201 oscillate
waveform is normal
OK
OK
NG
Replace X201
Check Q301, Q302 is broken
or CN402 solder?
Check reset circuit of
U203 is normal
Check Correspondent
com
onent.
NG
OK
OK
NG
Check Correspondent
com
onent.
Replace Panel
Replace U203
http://www.wjel.net
HUDSON 8
49
11.2. Power/Inverter Board
(1) No power
Check CN902 pin4, 5 = 12V
NG
Check AC line volt 110V or 220V
OK
NG
Check AC input
Check the voltage of C907 (+)
OK
NG
Check bridge rectified circuit and F901 circuit
Check start voltage for the pin8 of IC901
NG
OK
Check R905 and Change IC901
Check the auxiliary voltage is bigger than
10V and smaller than 20V
OK
NG
1) Check IC901
2) Check R910, D901 circuit
Check IC901 pin5 PWM wave
OK
http://www.wjel.net
NG
Check IC901
Check D910, Q900, D900, IC902, F902, ZD921, ZD922, D915, D916
50
(2) W / LED, No Backlight
HUDSON 8
Check CN902 pin4, 5 = 12V
OK
NG
Check adapter or MB
Check ON/OFF signal
OK
NG
Check Interface board
Check IC801 PIN12=12V
OK
NG
Change Q801
Check IC801 PIN10, 9 have the output of square wave at short time
NG
OK
Change IC801
Check Q804, Q809 PIN5, 6, 7, 8 have the output of square wave at short time.
OK
NG
Check Q804, Q805, Q806, Q809, Q810, Q811
Check the output of PT801, PT802
OK
http://www.wjel.net
NG
Change PT801, PT802
Check connecter & lamp
11.3 Key Board
OSD is unstable or not working
Is Key Pad Board connecting normally?
Y
Is Button Switch normally?
Y
Is Key Pad Board normally?
Y
Check Main Board
http://www.wjel.net
N
Connect Key Pad Board
N
Replace Button Switch
N
Replace Key Pad Board
HUDSON 8
51
52
12. ISP Instruction
HUDSON 8
(1). Install the program software
a. First decompressing files , as follow:
http://www.wjel.net
b. Double – click , start to install as follows:
HUDSON 8
53
http://www.wjel.net
54
HUDSON 8
http://www.wjel.net
HUDSON 8
55
http://www.wjel.net
56
c. There will be a shortcut key appears on the desktop.
(2). Connect the ISP board as follow:
HUDSON 8
a. Double-click
Connect to
the PC LPT
，running the program as follows:
Connect to the
Philips 170S8
http://www.wjel.net
b. Click icon, search the program” PHILIPS_170S_CPT_CLAA170EA07P_V.29.hex”, and click
open:
HUDSON 8
57
http://www.wjel.net
58
c. Click icon, the writer is in processing…
HUDSON 8
d. Until appears the follow Fig, writer completed.
http://www.wjel.net
HUDSON 8
59
13. DDC Instruction
General
DDC Data Re-programming
In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect,
repaired monitor’ the serial numbers have to be re-programmed.
It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if
circuit board have been replaced, in this case the DDC data does not need to be re-programmed.
Additional information about DDC (Display Data Channel) may be obtained from Video Electronics Standards
Association (VESA). Extended Display Identification Data (EDID) information may be also obtained from
VESA.
1. An i486 (or above) personal computer or compatible.
2. Microsoft operation system Windows 95/98/2000/XP.
3. “ PORT95NT.exe, WinDDC_ setup” program.
4. Software OSD SN Alignment kits
The kit contents:
a. OSD SN BOARD x1
b. Printer cablex1
c. VGA cable x1
d. Digital cable x1
e. 12V DC power source
1. Install the “PORT95NT.EXE”, and restart the computer.
You must install the
at the first. The processing as follows:
http://www.wjel.net
60
HUDSON 8
http://www.wjel.net
HUDSON 8
61
http://www.wjel.net
62
HUDSON 8
http://www.wjel.net
HUDSON 8
63
Click to complete the installation.
http://www.wjel.net
Note: After installation, you must restart the PC to take the setup to effect.
64
2. Install the “WinDDC_ setup”
HUDSON 8
Second, you must install the
. The processing as follows:
http://www.wjel.net
HUDSON 8
65
http://www.wjel.net
66
Click to complete the installation.
HUDSON 8
3. Connect the DDC board as follow:
When you write analog
EDID, Connect this port
to the Philips 170S8’s
VGA port
12V Input
http://www.wjel.net
Connect to the
PC LPT
When you write digital
EDID, Connect this port
to the Philips 170S8’s DVI
port
4. Take analog DDC write for example, as follow
HUDSON 8
67
a. Double-click
，appear as follow Figs：
http://www.wjel.net
68
b. Click .
c. Key 14 numbers in the Serial Number blank, then click “OK”. Now analog DDC Write completes, as follow.
HUDSON 8
Note: The way of digital DDC write is the same as analog DDC write.
http://www.wjel.net
HUDSON 8
69
170S8 EDID
Analog
128 bytes EDID Data (Hex):
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
0: 00 FF FF FF FF FF FF 00 41 0C 59 08 01 01 01 01
16: 0C 0D 01 03 0E 26 1E 78 EE A1 50 A3 57 4C 9D 25
32: 11 50 54 BF EF 80 71 4F 81 40 81 80 01 01 01 01
48: 01 01 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70
64: 13 00 78 2D 11 00 00 1E 00 00 00 FF 00 32 31 33
80: 32 33 31 32 33 32 31 33 32 33 00 00 00 FC 00 50
96: 68 69 6C 69 70 73 20 31 39 30 53 0A 00 00 00 FD
112: 00 38 4C 1E 53 0E 00 0A 20 20 20 20 20 20 00 A2
Decoded EDID data
<---Header--->
Header: 00 FF FF FF FF FF FF 00
<-x-Header-x->
<---Vendor/Product Identification--->
ID Manufacturer Name: PHL
ID Product Code: 0859
ID Serial Number: 01010101
Week of Manufacture: 12
Year of Manufacture: 2003
<-x-Vendor/Product Identification-x->
<---EDID Structure Version/Revision--->
EDID Version#: 01
EDID Revision#: 03
<-x-EDID Structure Version/Revision-x->
<---Basic Display Parameters/Features--->
Video i/p definition: Analog
Signal Level Standard: 0.700V/0.300V(0.700Vpp)
Setup: Blank-to-Black not expected
Separate Sync Support: Yes
Composite Sync Support: Yes
Sync. on green video supported:Yes
Serration of the Vsync.Pulse is not required.
Max. H. Image Size : 38cm.
Max. V. Image Size : 30cm.
Display Gamma: 2.2
DPMS Features, Stand-by: Yes.
DPMS Features, Suspend: Yes.
DPMS Features, Active off: Yes.
Display Type: R/G/B color display.
Standard Default Color Space: Yes.
Preferred Timing Mode: Yes.
<---Basic Display Parameters/Features--->
<---Color Characteristics--->
Red x: 0.6386718750
Red y: 0.3417968750
Green x: 0.2968750000
Green y: 0.6142578125
Blue x: 0.1455078125
Blue y: 0.0673828125
http://www.wjel.net
70
White x: 0.3125000000
White y: 0.3291015625
<-x-Color Characteristics-x->
<---Established Timings--->
Established Timings 1: BF
-720x400 @70Hz VGA,IBM
-640x480 @60Hz VGA,IBM
-640x480 @67Hz Apple,Mac II
-640x480 @72Hz VESA
-640x480 @75Hz VESA
-800x600 @56Hz VESA
-800x600 @60Hz VESA
Established Timings 2: EF
-800x600 @72Hz VESA
-800x600 @75Hz VESA
-832x624 @75Hz Apple,Mac II
-1024x768 @60Hz VESA
-1024x768 @70Hz VESA
-1024x768 @75Hz VESA
-1280x1024 @75Hz VESA
Established Timings 3: 80
-1152x870 @75Hz Apple,Mac II
<-x-Established Timings-x->
<---Standard Timing Identification--->
-1152x864 @75
-1280x960 @60
-1280x1024 @60
<-x-Standard Timing Identification-x->
<---Detailed Timing Descriptions--->
Detailed Timing: 1280x1024 @ 60Hz.
<-x-Detailed Timing Descriptions-x->
<---Detailed Timing Descriptions--->
Detailed Timing: FF (Monitor SN) '213231232132'
Detailed Timing: FC (Monitor Name) 'Philips 190S'
Detailed Timing: FD (Monitor limits)
Min. V. rate: 56Hz
Max. V. rate: 76Hz
Min. H. rate: 30KHz
Max. H. rate: 83KHz
Max. Pixel Clock: 140MHz
<-x-Detailed Timing Descriptions-x->
Extension Flag: 00
Checksum: A2
HUDSON 8
http://www.wjel.net
HUDSON 8
71
170S8 EDID
Digital
128 bytes EDID Data (Hex):
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
0: 00 FF FF FF FF FF FF 00 41 0C 56 08 FD E0 01 00
16: 17 0B 01 03 80 22 1B 78 EE AD B0 A2 57 4A 9C 25
32: 11 50 54 BF EF 80 71 4F 81 40 81 80 01 01 01 01
48: 01 01 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70
64: 13 00 52 0E 11 00 00 1E 00 00 00 FF 00 32 33 31
80: 33 31 32 33 31 32 33 31 33 33 00 00 00 FC 00 50
96: 68 69 6C 69 70 73 20 31 37 30 53 0A 00 00 00 FD
112: 00 38 4C 1E 53 0E 00 0A 20 20 20 20 20 20 00 36
Decoded EDID data
<---Header--->
Header: 00 FF FF FF FF FF FF 00
<-x-Header-x->
<---Vendor/Product Identification--->
ID Manufacturer Name: PHL
ID Product Code: 0856
ID Serial Number: 0001e0fd
Week of Manufacture: 23
Year of Manufacture: 2001
<-x-Vendor/Product Identification-x->
<---EDID Structure Version/Revision--->
EDID Version#: 01
EDID Revision#: 03
<-x-EDID Structure Version/Revision-x->
<---Basic Display Parameters/Features--->
Video i/p definition: Digital
Max. H. Image Size : 34cm.
Max. V. Image Size : 27cm.
Display Gamma: 2.2
DPMS Features, Stand-by: Yes.
DPMS Features, Suspend: Yes.
DPMS Features, Active off: Yes.
Display Type: R/G/B color display.
Standard Default Color Space: Yes.
Preferred Timing Mode: Yes.
<---Basic Display Parameters/Features--->
<---Color Characteristics--->
Red x: 0.6347656250
Red y: 0.3417968750
Green x: 0.2929687500
Green y: 0.6103515625
Blue x: 0.1464843750
Blue y: 0.0693359375
White x: 0.3125000000
White y: 0.3291015625
<-x-Color Characteristics-x->
<---Established Timings--->
Established Timings 1: BF
-720x400 @70Hz VGA,IBM
http://www.wjel.net
72
-640x480 @60Hz VGA,IBM
-640x480 @67Hz Apple,Mac II
-640x480 @72Hz VESA
-640x480 @75Hz VESA
-800x600 @56Hz VESA
-800x600 @60Hz VESA
Established Timings 2: EF
-800x600 @72Hz VESA
-800x600 @75Hz VESA
-832x624 @75Hz Apple,Mac II
-1024x768 @60Hz VESA
-1024x768 @70Hz VESA
-1024x768 @75Hz VESA
-1280x1024 @75Hz VESA
Established Timings 3: 80
-1152x870 @75Hz Apple,Mac II
<-x-Established Timings-x->
<---Standard Timing Identification--->
-1152x864 @75
-1280x960 @60
-1280x1024 @60
<-x-Standard Timing Identification-x->
<---Detailed Timing Descriptions--->
Detailed Timing: 1280x1024 @ 60Hz.
<-x-Detailed Timing Descriptions-x->
<---Detailed Timing Descriptions--->
Detailed Timing: FF (Monitor SN) '231312312313'
Detailed Timing: FC (Monitor Name) 'Philips 170S'
Detailed Timing: FD (Monitor limits)
Min. V. rate: 56Hz
Max. V. rate: 76Hz
Min. H. rate: 30KHz
Max. H. rate: 83KHz
Max. Pixel Clock: 140MHz
<-x-Detailed Timing Descriptions-x->
Extension Flag: 00
Checksum: 36
HUDSON 8
http://www.wjel.net
HUDSON 8
73
14. White Balance, Luminance Adjustment
1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (FGAWB0.15SN), Pattern
generator.
2. Equipment installation:
a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and
restart PC after finish installing.
b. Install Port95NT drive program, set PC printer connector mode as ECP mode and restart PC after finish
installing.
c. Connect tools as follow:
(Note: It is not necessary to connect Port2 )
3. Adjustment
Preparation before adjustment:
(1) Monitor should be warmed up for more than half an hour.
(2) Make sure that the tools are connected right and drive programs have been installed OK.
Adjustment process:
(1) Press the power of CA-210, shut off the lens, press 0-Cal and open the lens after analyzer reset.
(2) Start white balance adjustment program, select the right parameter according with the program and click OK.
(3) Make sure that the lens of CA-210 aims at the center of the screen, then click Start and start adjusting.
(4) After finish adjusting, the adjustment program displays pass, and the Start Button is changed to Next, which
means you can adjust another monitor.
http://www.wjel.net
74
HUDSON 8
4. Color Temp confirmation
Connect the signal to the monitor, the monitor display white-picture, use CA-210 to measure the Color Temp of the
screen center and select the OSD to make sure whether the Color Temps accord with the SPEC.
http://www.wjel.net
15. Monitor Exploded View
http://www.wjel.net
76
HUDSON 8
16. Recommended & Spare Parts List
170S8FS/00
Recommended Parts List
Item
1 FQ010 P34G1846 VOE1T BEZEL L17-7phb1 996510010270
1 FQ010 P34G1846 VOE1B BEZEL L17-7phb1
2 FQ009 P33G4989 VPB1C CONTROL BUTTON 996510010269
3 FQ005 750GLG70E3L12M000F PANEL LM170E03-TLL1 PHILIPS 996510006277
3 FQ006 750GLG70E3L42M000F PANEL LM170E03-TLL4 PHILIPS LPL 996510006278
3 FQ005 750GLG170E3G23M0PH PANEL LM170E03-TLG2 GZ LPL Second Source
3 FQ006 750GLG170E3G43M0PH PANEL LM170E03-TLG4 GZ LPL Second Source
3 FQ006 750GLC70A7P43M000F PANEL CLAA170EA07P 040 FZ 996510006441
3 FQ022 750GLB70A7P41M000F PANEL CLAA170EA07P 040 FQ CTOC 996510010276 Second Source
3 FQ022 750GLC70A7P43N CPT-CLAA170EA07P-040 Second Source
3 FQ022 750GLB70A7P41N CTOC-CLAA170EA07P-040 Second Source
3 FQ023 750GLB70A7P51M000F PANEL CLAA170EA07P 050 FQ CTOC 996510010261 Second Source
3 FQ023 750GLC70A7P53N CPT-CLAA170EA07P-050 Second Source
3 FQ023 750GLB70A7P51N CTOC-CLAA170EA07P-050 Second Source
Location Part No. Description Philips 12NC
Remark
4 FQ011 P34G1850 VB 2T REAR COVER(17") 996510008030
4 FQ011 P34G1850 VB 2B REAR COVER(17")
5 FQ008 A33G0259 VB 1L0100 COVER HINGE 996510006443
6 FQ004 705GQ734307 STAND&BASE ASS'Y 996510006439
7 FQ029 A34G0484 VB 1B0133 BASE_170A8/170S8
8 FQ030 A34G0443 VB 1B0100 STAND HEAD
9 FQ031 A34G0461 VB 1B0100 STAND BOTTOM
http://www.wjel.net
HUDSON 8
77
10 FQ032 A37G0045 1 PHILIPS 170S8 HINGE ASSY
11 FQ017 CBPC7CNAPHQ4 SCALAR BOARD ASSY (CPT) 996510010263
11 FQ018 CBPC7GNAPHQ6 SCALAR BOARD ASSY (LG) 996510010260
11 FQ017 CBPC7GNAPHQ1 SCALER BOARD ASSY
12 FQ020 PWPC942GR1P POWER BOARD ASSY (CPT)
12 FQ021 PWPC742GR3 POWER BOARD ASSY (LG) 996510010274
E089B 089G 728LAA 21 SIGNAL CABLE 996510005683
FQ001 089G179E30H 4 FFC CABLE 996500042351
FQ002 089G404A18N YH POWER CABLE 996500037502
E08901 089G404A18N IS POWER CORD 32E1818018
FQ003 095G8014 7D514 WIRE HARNESS
E09502 095G8014 7X514 WIRE HARNESS
E089B 089G 728HAA 21 SIGNAL CABLE 996510005679
FQ012 Q40G 17N81322A RATING LABEL
FQ012 Q40G 17N81322B RATING LABEL
FQ013 Q44G7057 1 EPS 996510010257
FQ014 Q44G7057 2 EPS 996510010258
FQ028 705TQ7CS067 CUSHION ASSY
FQ027 P45G 88609 36 R EPE BAG FOR MONITOR
FQ015 Q44G7057813 1A CARTON
FQ015 Q44G7057813 1C CARTON
FQ016 Q70G170081312A 170S8 DVI CD
FQ016 Q70G170081312B CD MANUAL
FQ019 KEPC7QS5 KEY BOARD ASSY 996510010272
U301 056G 563 52 IC AP1117D33LA TO252-3L ATC 996510005697
http://www.wjel.net
78
HUDSON 8
U304 056G 56327A IC AP1117E18LA SOT223-3L 996510005698
U204 056G1133 56 M24C16-WMN6TP 996500037783
U203 705GQ756024 MCU ASS'Y 996510010271
IC902 056G 139 3A IC PC123Y22FZ0F 996500036055
IC801 056G 379 22 IC TL494IDR SOIC-16 996510006256
IC901 056G 379 61 LD7575PS SOP-8 996500039747
IC903 056G 158 12 KIA431A-AT/P TO-92 996500036054
http://www.wjel.net
Service Kit
170S8FS/00
Spare Parts List
Description Part No. Philips 12NC Remark
DDC Kit 715L2005C2 9965 000 43197 for all model
OSD SN Kit 715GT033 C 9965 000 43252 for all model
for all hudson 7
HUDSON 8
79
Panel
NOVATEK ISP Kit 715LT035A 9965 000 43198
MSTAR ISP Kit 715GT039 A 996510010027 200CW8
REALTEK ISP Kit 715GT039 A 996510010027 170CW8
Location Part No. Description Philips 12NC Remark
FQ005 750GLG70E3L12M000F PANEL LM170E03-TLL1 PHILIPS 996510006277
FQ005 750GLG170E3G23M0PH PANEL LM170E03-TLG2 GZ LPL Second Source
FQ006 750GLG70E3L42M000F PANEL LM170E03-TLL4 PHILIPS LPL 996510006278
FQ006 750GLG170E3G43M0PH PANEL LM170E03-TLG4 GZ LPL Second Source
FQ006 750GLC70A7P43M000F PANEL CLAA170EA07P 040 FZ 996510006441
FQ022 750GLB70A7P41M000F PANEL CLAA170EA07P 040 FQ CTOC 996510010276 Second Source
FQ022 750GLC70A7P43N CPT-CLAA170EA07P-040
FQ022 750GLB70A7P41N CTOC-CLAA170EA07P-040
FQ023 750GLB70A7P51M000F PANEL CLAA170EA07P 050 FQ CTOC 996510010261 Second Source
FQ023 750GLC70A7P53N CPT-CLAA170EA07P-050
for 170A8, 190B8, 150S8,
170S8,190S8, 170V8,190V8
Second Source
Second Source
Second Source
FQ023 750GLB70A7P51N CTOC-CLAA170EA07P-050
http://www.wjel.net
Second Source
80
Board ASS’Y
Accessory and Mechanical
HUDSON 8
Location Part No. Description Philips 12NC
FQ017 CBPC7CNAPHQ4 SCALAR BOARD ASSY (CPT) 996510010263
FQ018 CBPC7GNAPHQ6 SCALAR BOARD ASSY (LG) 996510010260
FQ017 CBPC7GNAPHQ1 SCALER BOARD ASSY
FQ020 PWPC942GR1P POWER BOARD ASSY (CPT)
FQ021 PWPC742GR3 POWER BOARD ASSY (LG) 996510010274
FQ019 KEPC7QS5 KEY BOARD ASSY 996510010272
Location Part No. Description Philips 12NC Remark
E089B 089G 728LAA 21 SIGNAL CABLE 996510005683
FQ001 089G179E30H 4 FFC CABLE 996500042351
FQ002 089G404A18N YH POWER CABLE 996500037502
E08901 089G404A18N IS POWER CORD 32E1818018
FQ003 095G8014 7D514 WIRE HARNESS
E09502 095G8014 7X514 WIRE HARNESS
FQ004 705GQ734307 STAND&BASE ASS'Y 996510006439
FQ005 750GLG70E3L12M000F PANEL LM170E03-TLL1 PHILIPS 996510006277
FQ005 750GLG170E3G23M0PH PANEL LM170E03-TLG2 GZ LPL Second Source
FQ006 750GLG70E3L42M000F PANEL LM170E03-TLL4 PHILIPS LPL 996510006278
FQ006 750GLG170E3G43M0PH PANEL LM170E03-TLG4 GZ LPL Second Source
FQ006 750GLC70A7P43M000F PANEL CLAA170EA07P 040 FZ 996510006441
FQ022 750GLB70A7P41M000F PANEL CLAA170EA07P 040 FQ CTOC 996510010276 Second Source
FQ022 750GLC70A7P43N CPT-CLAA170EA07P-040
FQ022 750GLB70A7P41N CTOC-CLAA170EA07P-040
FQ023 750GLB70A7P51M000F PANEL CLAA170EA07P 050 FQ CTOC 996510010261 Second Source
http://www.wjel.net
Second Source
Second Source
HUDSON 8
81
FQ023 750GLC70A7P53N CPT-CLAA170EA07P-050
FQ023 750GLB70A7P51N CTOC-CLAA170EA07P-050
E089B 089G 728HAA 21 SIGNAL CABLE 996510005679
FQ008 A33G0259 VB 1L0100 COVER HINGE 996510006443
FQ009 P33G4989 VPB1C CONTROL BUTTON 996510010269
FQ010 P34G1846 VOE1T BEZEL L17-7phb1 996510010270
FQ010 P34G1846 VOE1B BEZEL L17-7phb1
FQ011 P34G1850 VB 2T REAR COVER(17") 996510008030
FQ011 P34G1850 VB 2B REAR COVER(17")
FQ012 Q40G 17N81322A RATING LABEL
FQ012 Q40G 17N81322B RATING LABEL
FQ013 Q44G7057 1 EPS 996510010257
FQ014 Q44G7057 2 EPS 996510010258
FQ028 705TQ7CS067 CUSHION ASSY
FQ015 Q44G7057813 1A CARTON
FQ015 Q44G7057813 1C CARTON
Second Source
Second Source
FQ027 P45G 88609 36 R EPE BAG FOR MONITOR
FQ016 Q70G170081312A 170S8 DVI CD
FQ016 Q70G170081312B CD MANUAL
http://www.wjel.net
82
Board Parts
HUDSON 8
Location Part No. Description Philips 12NC
FQ017 CBPC7GNAPHQ6 SCALER BOARD ASSY(LPL) 996510010260
FQ017 CBPC7GNAPHQ1 SCALER BOARD ASSY
CN402 033G801930F H FPC CONN. 1.0MM 30P
C101 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C102 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C103 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C104 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C105 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C106 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C107 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V 996510005722
C110 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C111 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C112 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C113 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C115 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V 996510005722
C116 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C117 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C118 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C121 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C122 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C123 065G0402102 32 1000PF +-10% 50V X7R 996510005715
C124 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C125 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C126 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C127 065G0402331 32 CHIP 330PF 50V X7R 996510005719
C128 065G0402330 31 33PF +-50% 50V NPO 996510005718
C129 065G0402473 12 CHIP 0.047UF 16V X7R 996510005721
C130 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C131 065G0402102 32 1000PF +-10% 50V X7R 996510005715
C132 065G040247132K T CAP CHIP 0402 470PF 50V X7R 996510005720
C201 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
http://www.wjel.net
C203 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C204 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C205 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C206 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C207 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C208 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C209 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C210 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C213 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V 996510005722
C214 067G305V101 3 105C 10UF +-20% 16V 996510005694
C215 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C216 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C219 065G0402220 31 CHIP 22PF 50V NPO 996510005717
C220 065G0402220 31 CHIP 22PF 50V NPO 996510005717
C301 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C302 067G305V100 3 105DEG 10UF -20% 16V 996500037413
C303 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C304 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V 996510005722
C305 067G305V101 3 105C 10UF +-20% 16V 996510005694
C306 067G305V101 3 105C 10UF +-20% 16V 996510005694
C307 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C308 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V 996510005722
C309 067G305V101 3 105C 10UF +-20% 16V 996510005694
C310 067G305V101 3 105C 10UF +-20% 16V 996510005694
C311 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C312 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
HUDSON 8
83
C315 067G305V101 3 105C 10UF +-20% 16V 996510005694
C316 065G0603104 22 CHIP 0.1UF 25V X7R 996500042674
C317 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C402 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C403 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
C405 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
D101 093G 6433S DIODE BAV99 SEMTECH 996510005726
D102 093G 64 42 PP BAV70 SOT-23 996500035995
D103 093G 6433S DIODE BAV99 SEMTECH 996510005726
D104 093G 6433S DIODE BAV99 SEMTECH 996510005726
D105 093G 6433S DIODE BAV99 SEMTECH 996510005726
D106 093G 6433S DIODE BAV99 SEMTECH 996510005726
D107 093G 6433S DIODE BAV99 SEMTECH 996510005726
D108 093G 6433S DIODE BAV99 SEMTECH 996510005726
D109 093G 6433S DIODE BAV99 SEMTECH 996510005726
D110 093G 64 42 PP BAV70 SOT-23 996500035995
D111 093G 6433S DIODE BAV99 SEMTECH 996510005726
http://www.wjel.net
D112 093G 6433S DIODE BAV99 SEMTECH 996510005726
D113 093G 6433S DIODE BAV99 SEMTECH 996510005726
D201 093G 64 42 PP BAV70 SOT-23 996500035995
D301 093G3004 3 SM340A 996510005728
Q201 057G 417 13 T KEC 2N3906S-RTK/PS 996500035967
Q301 057G 417 12 T PMBS3904 SOT23 CHIP 996510002429
Q302 057G 763 1 A03401 SOT23 BY AOS(A1) 996500035968
Q305 057G 417 12 T PMBS3904 SOT23 CHIP 996510002429
Q402 057G 417 13 T KEC 2N3906S-RTK/PS 996500035967
Q403 057G 417 13 T KEC 2N3906S-RTK/PS 996500035967
84
HUDSON 8
R101 061G0402750 RST CHIPR 75 OHM +-5% 1/16W 996510005713
R102 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R103 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R104 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R106 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R107 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R108 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R109 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R110 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R111 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R113 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R115 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R116 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R117 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R118 061G0402100 RST CHIPR 10 OHM +-5% 1/16W 996510005700
R120 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R122 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R123 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R124 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R126 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R127 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R128 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R129 061G0402151 RST CHIP 150R 1/16W 5% 996510005704
R131 061G0402391 RST CHIPR 390 OHM +-5% 1/16W 996510005708
R132 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R133 061G0402151 RST CHIP 150R 1/16W 5% 996510005704
R134 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R135 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R136 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R138 061G0402151 RST CHIP 150R 1/16W 5% 996510005704
R139 061G0402750 RST CHIPR 75 OHM +-5% 1/16W 996510005713
R140 061G0402750 RST CHIPR 75 OHM +-5% 1/16W 996510005713
R141 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W 996510005707
http://www.wjel.net
R142 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W 996510005707
R144 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R201 061G0402105 RST CHIPR 1MOHM +-5% 1/16W 996510005703
R202 061G0402103 RST CHIPR 10 KOHM -5% 1/16W 996500044984
R206 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R211 061G0402000 RST CHIPR 0 OHM +-5% 1/16W 996510005699
R213 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R214 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R215 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R218 061G0402220 RST CHIPR 22 OHM +-5% 1/16W 996510005705
R221 061G0402471 RST CHIPR 470 OHM +-5% 1/16W 996510005710
R225 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R228 061G0402000 RST CHIPR 0 OHM +-5% 1/16W 996510005699
R234 061G0402221 RST CHIPR 220 OHM +-5% 1/16W 996510005706
R301 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R302 061G1206331 RST CHIPR 330 OHM +-5% 1/4W 996510005714
R303 061G1206331 RST CHIPR 330 OHM +-5% 1/4W 996510005714
R304 061G0402103 RST CHIPR 10 KOHM -5% 1/16W 996500044984
R305 061G0402103 RST CHIPR 10 KOHM -5% 1/16W 996500044984
R307 061G0402513 RST CHIP 51K 1/16W 5% 996510005712
R308 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R309 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R311 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R312 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R314 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
R316 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W 996510005711
HUDSON 8
85
R402 061G0402392 RST CHIP 3.9K 1/16W 5% 996510005709
R403 061G0402392 RST CHIP 3.9K 1/16W 5% 996510005709
R407 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R410 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R412 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W 996510005702
R415 061G0402103 RST CHIPR 10 KOHM -5% 1/16W 996500044984
R416 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
R417 061G0402103 RST CHIPR 10 KOHM -5% 1/16W 996500044984
R418 061G0402101 RST CHIPR 100 OHM +-5% 1/16W 996510005701
U203 705GQ756024 MCU ASSY(LPL) 996510010271
U203 705GQ756098 MCU ASS'Y(17")
U204 056G1133 56 M24C16-WMN6TP 996500037783
U301 056G 563 52 IC AP1117D33LA TO252-3L ATC 996510005697
U304 056G 56327A IC AP1117E18LA SOT223-3L 996510005698
X201 093G 2251B MXS12.000AC20F-KAB5 HC-49/US 996510005696
CN101 088G 35315F H D-SUB 15PIN 996500035960
CN102 088G 35424F N DVI 24PIN CONN F 996510005695
http://www.wjel.net
FB101 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB102 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB103 071G 59B300 K BEAD 30 996500036934
FB104 071G 59B300 K BEAD 30 996500036934
FB105 061G0805000 0 OHM 1/10W 996500042284
FB106 071G 59B300 K BEAD 30 996500036934
FB107 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB202 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB203 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB204 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
86
HUDSON 8
FB205 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB206 071G 56D121 JA CHIP BEAD 120 OHM 0805 1A 996510005725
FB207 071G 56D102 MA CHIP HEAD 1000OHM 0805 1A 996510005723
FB302 071G 56K121 M CHIP BEAD 996500036567
FB303 071G 56K121 M CHIP BEAD 996500036567
ZD101 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD102 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD103 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD104 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD105 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD106 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD107 093G 39S 24 T RLZ 5.6B LLDS 996510004052
ZD201 093G 39G586 RLZ2.2B 996510005727
FQ018 KEPC7QS5 KEY BOARD ASSY 996510010272
SW1 077G 600 1GCJ TACT SWITCH 996510002796
SW2 077G 600 1GCJ TACT SWITCH 996510002796
SW3 077G 600 1GCJ TACT SWITCH 996510002796
SW4 077G 600 1GCJ TACT SWITCH 996510002796
SW5 077G 600 1GCJ TACT SWITCH 996510002796
SW6 077G 600 1GCJ TACT SWITCH 996510002796
SW7 077G 600 1GCJ TACT SWITCH 996510002796
SW8 077G 600 1GCJ TACT SWITCH 996510002796
C101 065G0603103 32 0.01UF -10% 50V X7R 996500036004
C102 065G0603103 32 0.01UF -10% 50V X7R 996500036004
C103 065G0603103 32 0.01UF -10% 50V X7R 996500036004
C104 065G0603103 32 0.01UF -10% 50V X7R 996500036004
C105 065G0603103 32 0.01UF -10% 50V X7R 996500036004
LED1 081G 12 1F GP LED GP32032M/G307-ZY-50 996510006457
R100 061G0805000 0 OHM 1/10W 996500042284
R101 061G0603101 RST CHIPR 100 OHM -5% 1/10W 996500042213
R102 061G0603432 RST CHIPR 4.3 KOHM -5% 1/10W 996500044045
R103 061G0603911 RST CHIPR 910 OHM +-5% 1/10W 996510006459
R104 061G0603242 RST CHIPR 2.4 KOHM +-5% 1/10W 996510006258
http://www.wjel.net
R106 061G0603432 RST CHIPR 4.3 KOHM -5% 1/10W 996500044045
R107 061G0603911 RST CHIPR 910 OHM +-5% 1/10W 996510006459
R108 061G0603242 RST CHIPR 2.4 KOHM +-5% 1/10W 996510006258
R109 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
CN101 033G3802 6H WAFER 6P RIGHT ANGLE PITCH 2.0 996510010273
FQ019 PWPC742GR3 POWER BOARD ASSY(LPL) 996510010274
C801 065G 6J1006ET 10PF 5% SL 6KV 996500036942
C802 065G0603105 12 CHIP 1UF 16VX7R 0603 996510002499
C803 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C804 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C805 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
C806 065G0603105 12 CHIP 1UF 16VX7R 0603 996510002499
C807 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C808 065G0805225 12 CHIP 2.2UF 16V X7R 0805 996510006267
C809 065G080522131G 220PF 50V NPO 2% 996510007400
C810 065G0603104 22 CHIP 0.1UF 25V X7R 996500042674
C811 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
C812 065G 6J1006ET 10PF 5% SL 6KV 996500036942
C813 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C814 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C815 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C816 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C817 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C818 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C821 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C822 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
HUDSON 8
87
C823 065G0805104 22 0.1UF -10% 25V X7R 080 996500036040
C824 065G0805104 22 0.1UF -10% 25V X7R 080 996500036040
C900 065G306M2222BP 2200PF -20% 400VAC 996500036050
C901 065G305M1022EM Y2 1000PF -20% 250VAC 996500036006
C902 065G305M1022EM Y2 1000PF -20% 250VAC 996500036006
C903 065G306M1022BP 1000PF Y1.CAP 996510006237
C904 065G0603102 32 1000PF -10% 50V X7R 996500037517
C907 067G 40Z10115K CAP 105 J 100UF M 450V 996510007388
C909 063G107K474 US 0.47UF +-10% 996510007384
C910 065G 2K152 1T6921 CAP 1.5NF/2KV Y5P +-10% 996510006274
C911 067G 2152207NT KY50VB22M-TP5 5*11 996510006275
C912 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C913 065G0805221 31 220PF 50V NPO 996500039769
C914 065G0805471 21 CHIP 470PF 25V NPO 996510002754
C916 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C920 065G517K102 5T 1000PF 10% Y5P 500V 996500036077
C921 065G517K102 5T 1000PF 10% Y5P 500V 996500036077
http://www.wjel.net
C922 067G215D6814KV CAP 105_J 680UF M 25V 996510006240
C923 067G215D6814KV CAP 105_J 680UF M 25V 996510006240
C925 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
C926 067G215S1023KV 105 J 1000UF M 16V 996510007389
C927 067G215S4713KV EC 105_J CAP 470UF M 16V 996510006242
C928 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C929 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C930 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C931 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C932 067G215S1023KV
105℃ 1000UF M 16V
88
HUDSON 8
CN901 087G 501 32 DL AC SOCKET DIP 3PIN+2PIN GROUND
PT802 S80GL17T40V TRANSFORMER ASSY
PT801 S80GL17T40V TRANSFORMER ASSY
Q809 057G 600 55 P5506 HVG SO-8
Q804 057G 600 55 P5506 HVG SO-8
D900 093G1100 1152T DIODE PR1007R 1A/1000V DO-41
D801 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D802 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D803 093G 64S511SEM IN4148W 996500039779
D806 093G 64S 10 DIODE BAW56PT SOT-23 CHENMKO 996510006271
D807 093G 64S511SEM IN4148W 996500039779
D808 093G 64S 10 DIODE BAW56PT SOT-23 CHENMKO 996510006271
D809 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D810 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D811 093G 64S511SEM IN4148W 996500039779
D812 093G 64S511SEM IN4148W 996500039779
D813 093G 64S511SEM IN4148W 996500039779
D900 093G1100 1052T BA159GPT DO-41 CHENMKO 996510007274
D901 093G 6038T52T FR103 996500036095
D910 093G 64S511SEM IN4148W 996500039779
D915 093G 64S511SEM IN4148W 996500039779
D916 093G 64S511SEM IN4148W 996500039779
D920 093G 60276 DIODE SBT150-10LST SANYO 996510006255
D922 093G3006 1 1 31DQ06FC3 NIHON INTER 996510006253
F901 084G 56 4W FUSE 4.0A 250V 996510006276
F902 061G1206000 4 RST CHIPR 0 OHM +-5% 1/4W 996510010275
J807 061G1206000 0 OHM 1/8W 996500039751
J813 061G1206000 0 OHM 1/8W 996500039751
J814 061G1206000 0 OHM 1/8W 996500039751
J815 061G1206000 0 OHM 1/8W 996500039751
J816 061G1206000 0 OHM 1/8W 996500039751
J818 061G1206000 0 OHM 1/8W 996500039751
J907 061G1206000 0 OHM 1/8W 996500039751
http://www.wjel.net
J908 061G1206000 0 OHM 1/8W 996500039751
L901 S73G17476V LINE FILTER ASSY 996510007403
L902 073G 174 65 H LINE FILTER 996500036088
L921 073G 253 91 H CHOKE COIL 996500036026
L922 073G 253 91 H CHOKE COIL 996500036026
Q801 057G 760 4B PDTA144WK SOT346 996500036962
Q802 057G 760 5B PDTC144WK SOT346 996510006257
Q803 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q804 057G 763 14 AM9945N 996500036100
Q805 057G 417 6 PMBS3906/PHILIPS-SMT(06) 996510002478
Q806 057G 417 6 PMBS3906/PHILIPS-SMT(06) 996510002478
Q807 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q808 057G 759 2 RK7002 SOT-23 BY ROHM 996510003293
Q809 057G 763 14 AM9945N 996500036100
Q810 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q811 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q812 057G 759 2 RK7002 SOT-23 BY ROHM 996510003293
Q902 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
R801 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R802 061G0805101 RST CHIPR 100 OHM -5% 1/8W 996500043379
R803 061G0603362 RST CHIPR 3.6 KOHM -5% 1/10W 996500042734
R804 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R805 061G0603472 RST CHIPR 4.7KOHM -5% 1/10W 996500042225
R806 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R807 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R808 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
HUDSON 8
89
R810 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R811 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R812 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R813 061G0603101 RST CHIPR 100 OHM -5% 1/10W 996500042213
R814 061G0603680 2F RST CHIPR 68 KOHM +-1% 1/10W 996510006225
R815 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
R816 061G0603680 2F RST CHIPR 68 KOHM +-1% 1/10W 996510006225
R819 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R820 061G0603564 RST CHIPR 560 KOHM +-5% 1/10W 996510006224
R821 061G0603105 RST CHIPR 1 MOHM -5% 1/10W 996500042216
R822 061G0603473 RST CHIPR 47 KOHM -5% 1/10W 996500042277
R823 061G0603103 RST CHIPR 10 KOHM -5% 1/10W 996500042214
R824 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R825 061G0805510 2F RST CHIPR 51 KOHM +-1% 1/8W 996510006262
R826 061G0805180 3F RST CHIPR 180 KOHM +-1% 1/8W 996510006259
R827 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R828 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
http://www.wjel.net
R829 061G0603680 2F RST CHIPR 68 KOHM +-1% 1/10W 996510006225
R830 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R831 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R832 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R833 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R834 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R835 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R836 061G0603105 RST CHIPR 1 MOHM -5% 1/10W 996500042216
R837 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R838 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
90
HUDSON 8
R839 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R840 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R841 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R842 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
R844 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R845 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R846 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R847 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R848 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R849 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R850 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R851 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R852 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R853 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R900 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R901 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R902 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R903 061G0805102 CHIP 1KOHM 1/10W 996500043380
R905 061G1206103 10 KOHM 1/8W 996500040048
R907 061G 208151 64 RST MOFR 150 OHM +-5% 1W 996510006232
R908 061G0805471 470&8 1/10W 996500043397
R909 061G152M104 64 100KOHM 5% 2W 996500036939
R910 061G1206229 RST CHIP 2R2 1/4W 5% 996500044647
R911 061G0805100 3F RST CHIPR 100KOHM +-1% 1/8W 996510006227
R912 061G1206100 RST CHIP 10R 1/4W 5% 996500043976
R913 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R915 061G0805100 2F RST CHIPR 10KOHM -1% 1/8W 996500044853
R916 061G152M43852T RST MOF 0R43 5% 2W 996510009151
R922 061G0805331 RST CHIPR 330 OHM -5% 1/8W 996500043393
R923 061G0805100 2F RST CHIPR 10KOHM -1% 1/8W 996500044853
R924 061G0805360 1F RST CHIPR 3.6KOHM +-1% 1/8W 996510006261
R925 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R926 061G0805330 2F RST CHIPR 33 KOHM +-1% 1/8W 996510006260
http://www.wjel.net
R927 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R928 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R929 061G0805240 1F RST CHIPR 2.4 KOHM +-1% 1/8W 996510004364
R930 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R931 061G1206103 10 KOHM 1/8W 996500040048
R951 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R952 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R953 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R954 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R955 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R956 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
T901 080GL17T 33 N2 XFMR POWER 550UH YUVA 996510006247
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON 996500039742
FB901 071G 55 29 FERRITE BEAD 996500036053
FB903 071G 55 29 FERRITE BEAD 996500036053
IC801 056G 379 22 IC TL494IDR SOIC-16 996510006256
IC901 056G 379 61 LD7575PS SOP-8 996500039747
IC902 056G 139 3A PC123Y22FZOF 996500036055
IC903 056G 158 12 KIA431A-AT/P TO-92 996500036054
NR901 061G 58100 W RST NTCR 10 OHM +20% 5A 996510007230
PT801 080GL17T 40 DN X'FMR TK.2001U.101 996510006252
PT802 080GL17T 40 DN X'FMR TK.2001U.101 996510006252
ZD801 061G1206103 10 KOHM 1/8W 996500040048
ZD920 093G 39S 40 T RLZ 13B LLDS 996500039777
ZD921 093G 39S 40 T RLZ 13B LLDS 996500039777
ZD922 093G 39S 25 T RLZ5.1B LLDS 996500037002
HUDSON 8
91
FQ020 750GLC70A7P43M000F PANEL CLAA170EA07P 040 CPT 996510006441
FQ021 750GLB70A7P41M000F PANEL CLAA170EA07P 040 FQ CTOC 996510010276
FQ022 750GLB70A7P51M000F PANEL CLAA170EA07P 050 FQ CTOC 996510010261
FQ023 750GLC70A7P53M000F PANEL CLAA170EA07P 050 FZ CPT 996510010262
FQ024 CBPC7CNAPHQ4 SCALER BOARD ASSY(CPT,CTOC) 996510010263
U203 705GQ756023 MCU ASSY(CPT,CTOC) 996510010264
FQ025 PWPC942GR1 POWER BOARD ASSY 996510010288
C802 065G0603105 12 CHIP 1UF 16VX7R 0603 996510002499
C803 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C804 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C805 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
C806 065G0603105 12 CHIP 1UF 16VX7R 0603 996510002499
C807 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C808 065G0805225 12 CHIP 2.2UF 16V X7R 0805 996510006267
C809 065G080522131G 220PF 50V NPO 2% 996510007400
C810 065G0603104 22 CHIP 0.1UF 25V X7R 996500042674
C811 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
http://www.wjel.net
C812 065G 6J1006ET 10PF 5% SL 6KV 996500036942
C813 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C814 065G0603104 12 CER2 0603 X7R 16V 100N PM10 R 996500036918
C815 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C816 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C817 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C818 065G0603222 22 CHIP 2200PF 25V X7R 996510006266
C821 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C822 065G0805152 32 CHIP 1500PF 50V X7R 0805 996500044871
C823 065G0805104 22 0.1UF -10% 25V X7R 080 996500036040
92
HUDSON 8
C824 065G0805104 22 0.1UF -10% 25V X7R 080 996500036040
C900 065G306M2222BP 2200PF -20% 400VAC 996500036050
C901 065G305M1022EM Y2 1000PF -20% 250VAC 996500036006
C902 065G305M1022EM Y2 1000PF -20% 250VAC 996500036006
C903 065G306M1022BP 1000PF Y1.CAP 996510006237
C904 065G0603102 32 1000PF -10% 50V X7R 996500037517
C907 067G 40Z10115K CAP 105 J 100UF M 450V 996510007388
C909 063G107K474 US 0.47UF +-10% 996510007384
C910 065G 2K152 1T6921 CAP 1.5NF/2KV Y5P +-10% 996510006274
C911 067G 2152207NT KY50VB22M-TP5 5*11 996510006275
C912 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C913 065G0805221 31 220PF 50V NPO 996500039769
C914 065G0805471 21 CHIP 470PF 25V NPO 996510002754
C916 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C920 065G517K102 5T 1000PF 10% Y5P 500V 996500036077
C921 065G517K102 5T 1000PF 10% Y5P 500V 996500036077
C922 067G215D6814KV CAP 105_J 680UF M 25V 996510006240
C923 067G215D6814KV CAP 105_J 680UF M 25V 996510006240
C925 067G215D4714KV E.C 105_J CAP 470UF M 25V 996510006239
C926 067G215S1023KV 105 J 1000UF M 16V 996510007389
C927 067G215S4713KV EC 105_J CAP 470UF M 16V 996510006242
C928 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C929 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C930 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
C931 065G0805104 32 CHIP 0.1U 50V X7R 996500036041
D801 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D802 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D803 093G 64S511SEM IN4148W 996500039779
D806 093G 64S 10 DIODE BAW56PT SOT-23 CHENMKO 996510006271
D807 093G 64S511SEM IN4148W 996500039779
D808 093G 64S 10 DIODE BAW56PT SOT-23 CHENMKO 996510006271
D809 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
D810 093G 64 33 DIO SIG SM BAV99 (PHSE)R 996500035994
http://www.wjel.net
D811 093G 64S511SEM IN4148W 996500039779
D812 093G 64S511SEM IN4148W 996500039779
D813 093G 64S511SEM IN4148W 996500039779
D900 093G1100 1052T BA159GPT DO-41 CHENMKO 996510007274
D901 093G 6038T52T FR103 996500036095
D910 093G 64S511SEM IN4148W 996500039779
D915 093G 64S511SEM IN4148W 996500039779
D916 093G 64S511SEM IN4148W 996500039779
D920 093G 60276 DIODE SBT150-10LST SANYO 996510006255
D922 093G3006 1 1 31DQ06FC3 NIHON INTER 996510006253
F901 084G 56 4W FUSE 4.0A 250V 996510006276
F902 061G1206000 4 RST CHIPR 0 OHM +-5% 1/4W 996510010275
J807 061G1206000 0 OHM 1/8W 996500039751
J813 061G1206000 0 OHM 1/8W 996500039751
J814 061G1206000 0 OHM 1/8W 996500039751
J815 061G1206000 0 OHM 1/8W 996500039751
J816 061G1206000 0 OHM 1/8W 996500039751
J818 061G1206000 0 OHM 1/8W 996500039751
J907 061G1206000 0 OHM 1/8W 996500039751
J908 061G1206000 0 OHM 1/8W 996500039751
L901 S73G17476V LINE FILTER ASSY 996510007403
L902 073G 174 65 H LINE FILTER 996500036088
L921 073G 253 91 H CHOKE COIL 996500036026
L922 073G 253 91 H CHOKE COIL 996500036026
Q801 057G 760 4B PDTA144WK SOT346 996500036962
Q802 057G 760 5B PDTC144WK SOT346 996510006257
HUDSON 8
93
Q803 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q804 057G 763 14 AM9945N 996500036100
Q805 057G 417 6 PMBS3906/PHILIPS-SMT(06) 996510002478
Q806 057G 417 6 PMBS3906/PHILIPS-SMT(06) 996510002478
Q807 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q808 057G 759 2 RK7002 SOT-23 BY ROHM 996510003293
Q809 057G 763 14 AM9945N 996500036100
Q810 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q811 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
Q812 057G 759 2 RK7002 SOT-23 BY ROHM 996510003293
Q900 057G 667 21 STP10NK70ZFP 996500039743
Q902 057G 417 4 PMBS3904/PHILIPS-SMT(04) 996500035966
R801 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R802 061G0805101 RST CHIPR 100 OHM -5% 1/8W 996500043379
R803 061G0603362 RST CHIPR 3.6 KOHM -5% 1/10W 996500042734
R804 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R805 061G0603472 RST CHIPR 4.7KOHM -5% 1/10W 996500042225
http://www.wjel.net
R806 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R807 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R808 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R810 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R811 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R812 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R813 061G0603101 RST CHIPR 100 OHM -5% 1/10W 996500042213
R814 061G0603750 2F RST CHIPR 75KOHM -1% 1/10W 996500042257
R815 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
R816 061G0603680 2F RST CHIPR 68 KOHM +-1% 1/10W 996510006225
94
HUDSON 8
R819 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R820 061G0603564 RST CHIPR 560 KOHM +-5% 1/10W 996510006224
R821 061G0603105 RST CHIPR 1 MOHM -5% 1/10W 996500042216
R822 061G0603473 RST CHIPR 47 KOHM -5% 1/10W 996500042277
R823 061G0603103 RST CHIPR 10 KOHM -5% 1/10W 996500042214
R824 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R825 061G0805510 2F RST CHIPR 51 KOHM +-1% 1/8W 996510006262
R826 061G0805180 3F RST CHIPR 180 KOHM +-1% 1/8W 996510006259
R827 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R828 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
R829 061G0603680 2F RST CHIPR 68 KOHM +-1% 1/10W 996510006225
R830 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R831 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R832 061G0603000 RST CHIPR 0 OHM -5% 1/10W 996500042212
R833 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R834 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R835 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R836 061G0603105 RST CHIPR 1 MOHM -5% 1/10W 996500042216
R837 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R838 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R839 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R840 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R841 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R842 061G0603470 2F RSTR 47 KOHM +-1% 1/10W 996510005994
R844 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R845 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R846 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R847 061G0603220 RST CHIPR 22 OHM -5% 1/10W 996500042217
R848 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R849 061G0603100 1F RST CHIPR 1 KOHM -1% 1/10W 996500043955
R850 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R851 061G1206150 RST CHIPR 15 OHM +-5% 1/4W 996510006263
R852 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
http://www.wjel.net
R853 061G0603100 2F RST CHIPR 10 KOHM -1% 1/10W 996500042395
R900 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R901 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R902 061G1206334 RST CHIPR 330KOHM +-5% 1/4W 996510006264
R903 061G0805102 CHIP 1KOHM 1/10W 996500043380
R905 061G1206103 10 KOHM 1/8W 996500040048
R907 061G 208151 64 RST MOFR 150 OHM +-5% 1W 996510006232
R908 061G0805471 470&8 1/10W 996500043397
R909 061G152M104 64 100KOHM 5% 2W 996500036939
R910 061G1206229 RST CHIP 2R2 1/4W 5% 996500044647
R911 061G0805100 3F RST CHIPR 100KOHM +-1% 1/8W 996510006227
R912 061G1206100 RST CHIP 10R 1/4W 5% 996500043976
R913 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R915 061G0805100 2F RST CHIPR 10KOHM -1% 1/8W 996500044853
R916 061G152M43852T RST MOF 0R43 5% 2W 996510009151
R922 061G0805331 RST CHIPR 330 OHM -5% 1/8W 996500043393
R923 061G0805100 2F RST CHIPR 10KOHM -1% 1/8W 996500044853
R924 061G0805360 1F RST CHIPR 3.6KOHM +-1% 1/8W 996510006261
R925 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R926 061G0805330 2F RST CHIPR 33 KOHM +-1% 1/8W 996510006260
R927 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R928 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R929 061G0805240 1F RST CHIPR 2.4 KOHM +-1% 1/8W 996510004364
R930 061G0805100 1F RST CHIPR 1KOHM +-1% 1/8W 996510006226
R931 061G1206103 10 KOHM 1/8W 996500040048
R951 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
HUDSON 8
95
R952 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R953 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R954 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R955 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
R956 061G1206470 RST CHIPR 47 OHM +-5% 1/4W 996510006265
T901 080GL17T 33 N2 XFMR POWER 550UH YUVA 996510006247
BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON 996500039742
FB903 071G 55 29 FERRITE BEAD 996500036053
IC801 056G 379 22 IC TL494IDR SOIC-16 996510006256
IC901 056G 379 61 LD7575PS SOP-8 996500039747
IC903 056G 158 12 KIA431A-AT/P TO-92 996500036054
NR901 061G 58100 W RST NTCR 10 OHM +20% 5A 996510007230
PT801 080GL17T 40 DN X'FMR TK.2001U.101 996510006252
PT802 080GL17T 40 DN X'FMR TK.2001U.101 996510006252
ZD801 061G1206103 10 KOHM 1/8W 996500040048
ZD920 093G 39S 40 T RLZ 13B LLDS 996500039777
ZD921 093G 39S 40 T RLZ 13B LLDS 996500039777
http://www.wjel.net
ZD922 093G 39S 25 T RLZ5.1B LLDS 996500037002
FQ026 CBPC7ANAPHQ1 SCALER BOARD ASSY(AUO) 996510010267
C404 065G0402104 12 CHIP 0.1UF 50V X7R 996510005716
Q900 057G 667 21 STP10NK70ZFP 996500039743
R814 061G0603750 2F RST CHIPR 75KOHM -1% 1/10W 996500042257
U203 705GQ756048 MCU ASSY(AUO) 996510010268
E08902 089G 728HAA 21 SIGNAL CABLE 996510005679
96
HUDSON 8
17. Different Parts List
Diversity of 170S8FB/00 compared with 170S8FS/00
Location
FQ009 P33G4989 VQB1C CONTROL BUTTON 996510010255 P33G4989 VPB1C CONTROL BUTTON 996510010269
FQ010 P34G1846 VBF1T BEZEL L17-7PHB1 996510010256 P34G1846 VOE1T BEZEL L17-7PHB1 996510010270
FQ010 P34G1846 VBF1B BEZEL L17-7PHB1 P34G1846 VOE1B BEZEL L17-7PHB1
Diversity of 170S8FB/27 compared with 170S8FS/00
Location
FQ002 089G402A18N IS POWER CORD 089G404A18N YH POWER CABLE 996500037502
FQ009 P33G4989 VQB1C CONTROL BUTTON P33G4989 VPB1C CONTROL BUTTON 996510010269
FQ010 P34G1846 VBF1T BEZEL L17-7phb1 P34G1846 VOE1T BEZEL L17-7phb1 996510010270
FQ012 Q40G 17N81325B RATING LABEL Q40G 17N81322A RATING LABEL
FQ012 Q40G 17N81325C RATING LABEL (Second source) Q40G 17N81322A RATING LABEL
FQ022 089G1748GAA AC
Part No. Description Philips 12NC Part No. Description Philips 12NC
Part No. Description Philips 12NC Part No. Description Philips 12NC
SIGNAL CABLE DVI
GREATLAND
170S8FB/00 170S8FS/00
170S8FB/27 170S8FS/00
http://www.wjel.net
Diversity of 170S8FS/62 compared with 170S8FS/00
HUDSON 8
97
Location
Part No. Description Philips 12NC Part No. Description Philips 12NC
FQ011 P34G1850 VB 1T REAR COVER P34G1850 VB 2T REAR COVER(17") 996510008030
FQ015 Q44G7057813 4A CARTON Q44G7057813 1A CARTON
FQ015 Q44G7057813 5A CARTON (Second source) Q44G7057813 1A CARTON
FQ018 CBPC7GNAPHQ8 SCALAR BOARD ASSY(LPL) CBPC7GNAPHQ6 SCALAR BOARD ASSY (LG) 996510010260
FQ017 CBPC7CNAPHQ8 SCALAR BOARD ASSY(CPT) CBPC7CNAPHQ4 SCALAR BOARD ASSY(CPT) 996510010263
U203 705GQ756032 MCU ASS'Y (17")(LPL) 705GQ756024
U203 705GQ756031 MCU ASS'Y (17")(CPT) 705GQ756023
170S8FS/62 170S8FS/00
MCU ASS'Y （LG）
MCU ASS'Y （CPT）
996510010271
996510010264
Diversity of 170S8FB/62 compared with 170S8FS/00
Location
Part No. Description Philips 12NC Part No. Description Philips 12NC
FQ009 P33G4989 VQB1C CONTROL BUTTON P33G4989 VPB1C CONTROL BUTTON 996510010269
FQ010 P34G1846 VBF1T BEZEL L17-7phb1 P34G1846 VOE1T BEZEL L17-7phb1 996510010270
170S8FB/62 170S8FS/00
FQ011 P34G1850 VB 1T REAR COVER P34G1850 VB 2T REAR COVER(17") 996510008030
FQ015 Q44G7057813 4A CARTON Q44G7057813 1A CARTON
FQ018 CBPC7GNAPHQ8 SCALAR BOARD ASSY(LPL) CBPC7GNAPHQ6 SCALAR BOARD ASSY (LG) 996510010260
FQ017 CBPC7CNAPHQ8 SCALAR BOARD ASSY(CPT) CBPC7CNAPHQ4 SCALAR BOARD ASSY(CPT) 996510010263
U203 705GQ756032 MCU ASS'Y (17")(LPL) 705GQ756024
U203 705GQ756031 MCU ASS'Y (17")(CPT) 705GQ756023
http://www.wjel.net
MCU ASS'Y （LG）
MCU ASS'Y （CPT）
996510010271
996510010264
98
Diversity of 170S8FB/78 compared with 170S8FS/00
HUDSON 8
Location
Part No. Description Philips 12NC Part No. Description Philips 12NC
E08902 089G402A18NIS1 POWER CORD
E08902 089G402A18NLS1 POWER CORD
FQ004 705GQ734427
FQ009 P33G4989 VQB1C CONTROL BUTTON P33G4989 VPB1C CONTROL BUTTON 996510010269
FQ010 P34G1846 VBF1B BEZEL L17-7phb1 P34G1846 VOE1T BEZEL L17-7phb1 996510010270
FQ012 Q40G 17N81328A RATING LABEL Q40G 17N81322A RATING LABEL
FQ017 CBPC7CNAPHQA SCALER BOARD CBPC7CNAPHQ4 SCALER BOARD ASSY (CPT) 996510010263
FQ019 PWPC7942GQA8 POWER BOARD ASSY PWPC942GR1P POWER BOARD(CPT) 996510006441
CN801 033G8021 2E U INVERT CONNECTOR
CN802 033G8021 2E U INVERT CONNECTOR
CN803 033G8021 2E U INVERT CONNECTOR
CN804 033G8021 2E U INVERT CONNECTOR
C909 063G107K474 TS CAP X2 0.47UF K 275VAC 063G107K474 HS 0.47UF +-10% 996510007384
C907 067G305T10115H
170S8FB/78 170S8FS/00
170S8 STAND&BASE SKD
ASS'Y
ELCAP 105℃ 100UF M 450V
705GQ734307 STAND&BASE ASS'Y 996510006439
L902 073G 174 65 T LINE FILTER 7mH MIN TDK
T901 080GL17T 33 T2
L902 S73G17465VW LINE FILTER ASS'Y 073G 174 65 H LINE FILTER 996500036088
L921 S73G25391V CHOKE COIL ASS'Y 073G 253 91 H CHOKE COIL 996500036026
L922 S73G25391V CHOKE COIL ASS'Y 073G 253 91 H CHOKE COIL 996500036026
T901 S80GL17T33V2 TRANSFORMER ASS'Y 080GL17T 33 N2 XFMR POWER 550uH YUVA 996510006247
X'FMR 550uH
SRW28EC-T147H015
http://www.wjel.net
IC903 056G 158 10 T IC AZ431AZ-AE1 TO-92 BY AAC 056G 158 12 KIA431A-AT/P TO-92 996500036054
FQ018 KEPC7QS6 KEY BOARD ASSY KEPC7QS5 KEY BOARD ASSY 996510010272
HUDSON 8
99
18. General Product Specification
CONTENTS
ANALOG AND DIGITAL DUAL INPUT
1 FOREWORD
2 PRODUCT PROFILE
2.1 LCD
2.2 SCANNING FREQUENCIES
2.3 AMBIENT TEMPERATURE: 0 °C - 35 °C
3 ELECTRICAL CHARACTERISTICS
3.1 INTERFACE SIGNALS
VIDEO: 0.7 Vp-p, INPUT IMPEDANCE, 75 OHM @DC
3.2 INTERFACE
3.3 TIMING REQUIREMENT
3.4 HORIZONTAL SCANNING
3.5 VERTICAL SCANNING
3.6 POWER INPUT CONNECTION
3.7 POWER MANAGEMENT
3.8 DISPLAY IDENTIFICATION
3.9 DISPLAY IDENTIFECATION
3.10 USB SUPPORT: NOTE
3.11 DDC/CI SUPPORT
3.12 EDID
3.13 HOT-KEY DEFINITION
3.14 SMART CONTRAST (DYNAMIC CONTRAST RATIO)
3.16 SMART IMAGE
4 VISUAL CHARACTERISTICS
4.1 TEST CONDITIONS
4.2 BRIGHTNESS
4.3 IMAGE SIZE
4.4 BRIGHTNESS UNIFORMITY
4.5 CHECK CROSS TALK (S)
4.6 WHITE COLOR ADJUSTMENT
5 MECHANICAL CHARACTERISTICS
5.1 COSMETIC PHILIPS ID
http://www.wjel.net
5.2 MECHANICAL DATA FILES PROE FILES REQUIRED
5.3 LOCATION OF PHILIPS LOGO PER PHILIPS MAKE-UP SHEET
5.4 GAP BETWEEN PANEL AND FRONT BEZEL <0.8 (TYP) MM
5.5 LOCATION OF CONTROL ICONS PER PHILIPS GRAPHIC SHEET
5.6 COLOR FOR RESIN/PAINT PER PHILIPS MAKE-UP SHEET
5.7 RESINS
5.8 IF RAINT IS USED
5.9 PLASITIC MOLD TOOLING
5.10 PLASTICS FLAMMABILITY
100
5.11 TEXTURE/GLOSSING OF HOUSING
5.12 TILT AND SWIVEL BASE
5.13 KENSINGTON LOCK
5.14 LABEL
5.15 PRODUCT DIMENSION/WEIGHT (PREFER TO SHT 191)
5.16 TRANSPORTATION
5.17 PALLET/CONTAINER LOADING
6. ENVIRONMENTAL CHARACTERISTICS
6.1 SUSCEPTIBILITY OF DISPLAY TO EXTERNAL ENVIRONMENT
6.2 TRANSPORTATION TESTS
6.3 DISPLAY DISTURBANCES FROM EXTERNAL ENVIRONMENT
6.4 DISPLAY DISTURBANCES TO EXTERNAL ENVIRONMENT
7. RELIABILITY
7.1 MEAN TIME BETWEEN FAILURES
8. QUALITY ASSURANCE REQUIREMENTS
8.1 ACCEPTANCE TEST
HUDSON 8
9. PHILIPS’ FLAT PANEL MONITORS PIXEL DEFECT POLICY
10 REGULATORY COMPLIANCE
10.1 WORLDWIDE REGULATORY
10.2 EMC REQUIREMENTS
10.3 ROHS
10.4 WEEE
10.5 ONGOING REGULATORY
http://www.wjel.net
Loading...
