Philips 160VW9FB User Manual
Philips
LCD widescreen monitor
16" wide
15.6" viewing area WXGA
160VW9FB
WideScreen
Great value, best savings
on widescreen display
This Vista-ready 160VW9 delivers 16:9 widescreen HD quality display and built-in stereo
audio without costly extras that strain your budget and without compromising on quality.
Great convenience
• Screen tilts to your ideal, individualized viewing angle
• sRGB ensures color matching between display and printouts
• Embedded power supply eliminates external power adaptors
• Kensington anti-theft lock-ready for added security
Best Value for Money
• Built in stereo audio for a clutter-free desktop
• 16:9 display for best widescreen gaming and video
• Energy Star for energy efficiency and low power consumption
• Complies with RoHS standards to care for the environment
• Empowered for Windows Vista
LCD widescreen monitor
160VW9FB/78
16" wide 15.6" viewing area WXGA
Specifications Product highlights
Picture/Display
• Panel Size: 15.6" / 39.5 cm
• LCD panel type: 1366 x 768 pixels, Anti-glare
polarizer, RGB vertical stripe
• Recommended Resolution: 1366 x 768 @ 60 Hz
• Maximum Resolution: 1366 x 768 @ 60 Hz
• Display colors: 16.7 M
• Aspect ratio: 16:9
• Brightness: 210 cd/m²
• Contrast ratio (typical): 500:1
• Viewing angle: 90º (H) / 65º (V), @ C/R > 10
• Response time (typical): 8 ms
• Effective viewing area: 344.2 x 193.5 mm
• Horizontal Scanning Frequency: 30 - 60 kHz
• Vertical Scanning Frequency: 55 -75 Hz
• Pixel pitch: 0.252 x 0.252 mm
• Video Dot Rate: 85.5 MHz
•sRGB
Connectivity
• Signal Input: Analog (VGA)
• Video Sync Input Signal: Composite Sync, Separate
Sync, Sync on Green
Convenience
• Built-in Audio: 1W x 2
• Convenience Enhancements: On-screen Display
• Monitor Controls: Auto, Menu, Power On/Off
• OSD Languages: English, French, Russian,
Simplified Chinese, Spanish, Portuguese, Korean
• Plug & Play Compatibility: DDC/CI, sRGB,
Windows Vista
• Regulatory Approvals: CE Mark, Energy Star, FCC
Class B, UL
• Tilt: -5° to 20°
• Other convenience: Kensington lock compatible
• VESA Mount: 100 x 100 mm
Dimensions
• Set dimensions with stand (W x H x D):
361
x 293 x 190 mm
• Set dimensions with stand in inch (W x H x D):
14.2
x 14.2 x 7.4 inch
• Relative humidity: 20% - 80%
• MTBF: 50,000 hrs
• Temperature range (operation): 0°C to 40°C
• Temperature range (storage): -20°C to 60°C
• Box dimensions (W x H x D):
442
x 130 x 328 mm
• Box dimensions in inch (W x H x D):
17.4
x 5.1 x 12.9 inch
• Product weight (+stand): 2.7 kg
• Product weight (+stand) (lb): 5.9 lb
• Weight incl. Packaging: 3.7 kg
• Weight incl. Packaging (lb): 8.1 lb
Power
• Consumption: < 32 W
• Off Mode: < 1 W
• Complies with: Energy Star
• Power LED indicator: Operation - green, Stand
by/sleep - Amber
• Power supply: Built-in, 100-240VAC, 50/60Hz
•
Adjustable tilt
Adjustable tilt is backward and forward movement of a
screen on its base to achieve custom positioning for an
ideal viewing angle and more comfort for people who
spend long hours working on the computer.
sRGB ready
sRGB is an industry standard that ensures the best
possible match between the colors displayed on your
screen and those in your printouts.
Embedded power supply
An embedded power supply is a power adaptor built into
the body of a display device that replaces a bulky external
power adaptor.
Energy Star
Energy Star-labeled home electrical products are
designed to use less energy - saving you money while
reducing environmental pollution. In fact, Energy Starcompliant products consume less than 1 watt of power
while in standby mode. As an Energy Star partner, Philips
develops products that meet the Energy Star guidelines
for energy efficiency. This is achieved by having low
standby power consumption through innovatively
designed standby circuitry and stringent selection of
components made with high efficiency materials.
Compliant with RoHS standards
Philips designs and produces display products in
compliance with strict Restriction of Hazardous
Substances (RoHS) standards that restrict lead and other
toxic substances that can harm the environment.
Kensington lock compatible
Small apertures built into the display's frame for use with
a locking device that secures a display to a fixed object
for added protection against theft.
Built-in stereo audio
A pair of high quality stereo audio built into a display
device.
Windows Vista ready
Philips Vista-ready monitors are empowered for vibrant,
exciting display of this new, visually sophisticated and
demanding Windows operating system, designed to
enhance your entertainment experience, make you more
productive and help you control your computing
experience at home and in the office, making viewing,
finding and organizing information for work or play quick,
efficient and easy.
Issue date 2008-11-18
Version: 1.0.8
12 NC: 8670 000 48451
EAN: 87 12581 45754 9
© 2008 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
