Philips
LED Monitor
15.6''w (39.6 cm) E-line
1366x768 HD
160EL1SB
LED display: Contrast has
never been better!!
This Eco friendly LED display comes with a superb 1000000:1 contrast ratio. With
Natural colors, SmartContrast and Glossy finish, the 160EL1 is a great choice for all your
needs
Great picture quality
• LED technology ensures natural colors
• SmartContrast 1,000,000:1 for incredible rich black details
• Fast 8ms On/off response time:Great text & graphics display
• 16:9 display for best widescreen gaming and video
Design that complements any interior
• Glossy finish to enhance your decor
• Small footprint to blend into any lifestyle
Environmentally friendly green design
• Mercury Free eco-friendly display
• Energy Star for energy efficiency and low power consumption
• Complies with RoHS standards to care for the environment
Great convenience
• Easy picture format control switching in wide and 4:3 format
• sRGB ensures color matching between display and printouts
Page 2
LED Monitor
1,000,000:1
SmartContrast
15.6''w (39.6 cm) E-line 1366x768 HD
160EL1SB/70
Specifications
Picture/Display
• LCD panel type: TFT-LCD
• Backlight type: W-LED system
• Panel Size: 15.6 inch / 39.6 cm
• Aspect ratio: 16:9
• Optimum resolution: 1366 x 768 @ 60 Hz
• Response time (typical): 8 ms
• Brightness: 250 cd/m²
• SmartContrast: 1,000,000:1
• Pixel pitch: 0.252 x 0.252 mm
• Viewing angle: 110º (H) / 85º (V), @ C/R > 5
• Display colors: 16.7 M
• Scanning Frequency: 30 - 60 kHz (H) / 56 - 76 Hz
(V)
•sRGB
Connectivity
• Signal Input: VGA (Analog )
• Sync Input: Separate Sync, Sync on Green
Convenience
• User convenience: Brightness, Menu, Auto, Power
On/Off
• OSD Languages: English, French, Russi
Chinese, Spanish, Portuguese, Korean
• Other convenience: VESA mount (75x75mm),
nsington lock
Ke
• Plug & Play Compatibility: DDC/CI, Windows 7/
sta/XP/2000/98, sRGB
Vi
Stand
• Tilt: -5/20 degree
Power
• On mode: 9.5W (EnergyStar 5.0 test method)
an, Simplified
• Standby mode: <0.8W
• Off mode: <0.5W
• Power LED indicator: Operation - green, Stand by/
eep - Amber
sl
• Power supply: Built-in, 100-240VAC, 50/60Hz
Dimensions
• Product with stand (mm): 303 x 376 x 156 mm
• Product without stand (mm): 244 x 376 x 59 mm
• Packaging in mm (WxHxD): 323 x 439 x 145 mm
Weight
• Product without stand (kg): 2.51 kg
• Product with packaging (kg): 4.08 kg
• Product with stand (kg): 2.7 kg
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Temperature Range (storage): -20 - 60 °C
• Relative humidity: 20 - 80 %
• MTBF: 40,000 hour(s)
Sustainability
• Environmental and energy: EPEAT Silver, RoHS,
EnergyStar 5.0
Compliance and standards
• Regulatory Approvals: CE Mark, FCC, Class B, UL/
cUL
Cabinet
• Color: Black
•Finish: Glossy
•
Highlights
LED technology
White LED's are solid state devices which light up to
full, consistent brightness faster saving startup time.
LED's are free from mercury content which allows
for eco-friendly recycling and disposal process. LED's
allow for better dimming control of LCD backlight,
resulting in super high contrast ratio. It also gives
superior color reproduction thanks to consistent
brightness across the screen.
SmartContrast ratio 1000000:1
You want the LCD flat display with the highest
contrast and most vibrant images. Philips advanced
video processing combined with unique extreme
dimming and backlight boosting technology results in
vibrant images. SmartContrast will increase the
contrast with excellent blacklevel and accurate
rendition of dark shades and colors. It gives a bright,
lifelike picture with high contrast and vibrant colors.
Mercury Free
Philips monitors with LED backlighting are free of
Mercury content, one of the most toxic natural
substances which affects humans and animals. This
allows for a eco-friendly display through out its lifecycle from manufacturing to disposal.
Issue date 2011-10-18
Version: 1.0.1
12 NC: 8670 000 74787
EAN: 87 12581 59591 3
Energy Star 5.0
Energy Star is a US EPA sponsored energy efficiency
program also adopted by many other countries.
Energy Star certification ensures that you are buying
a product which meets the latest power efficiency
standards which operates with maximum power
efficiency at all operational levels. New Philips
monitors are certified for Energy Star 5.0
specifications and meet or exceed the standard. For
example, in sleep mode Energy Star 5.0 requires less
than 1watt power consumption, whereas Philips
monitors consume less than 0.5watts. Further details
can be obtained from www.energystar.gov
Easy picture format control
Philips easy picture format control on OSD is to
switch from the 4:3 aspect ratio to the widescreen
mode and back again to match the display's aspect
ratio with your content for working with wide
documents without scrolling or viewing widescreen
media in the widescreen mode and distortion-free,
native mode display of 4:3 ratio content.
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
