Philips DiamondVision
Moto
Headlight bulb
Type of lamp: HS1
Pack of: 1
12 V,35/35 W
12636DVB1
Ride with style
5000K Ultimate white light for your stylish ride
Philips DiamondVision Moto halogen headlamp is the ultimate style upgrade for your
motorcycle with 5000K white light. With the specially designed blue coating,
DiamondVision Moto makes you stand out from the crowd.
5000 K white light for your stylish ride
• DiamondVision Moto lights up your motorcycle
State-of-the-art technology
• Philips moto lamps are made of high-quality quartz glass^
• Philips moto lamps are highly resistant against humidity^
• Philips car lamps are highly UV resistant
High quality and ultra resistant headlight
• Philips is the choice of major motorcylce manufacturers.
12636DVB1
Headlight bulb
Type of lamp: HS1 Pack of: 1, 12 V,35/35 W
Specifications
Marketing specifications
• Expected benefits: White light
• Product highlight: Ultimate 5000K
Product description
• Designation: HS1 DV
• Range: DiamondVision moto
•Technology: Halogen
• Base: P32d
• Application: High beam, Low beam
•Type: HS1
Electrical characteristics
• Voltage: 12 V
• Wattage: 35/35W W
Light characteristics
• Color temperature: up to 5000 K K
• Lumens: 390 ± 8% / 250 ± 8% lm
Lifetime
• Life time: 400h
white light
Packaging Data
• Packaging type: B1
• EAN1: 8711500781482
• EAN3: 8711500781499
Ordering information
• Ordering code: 78148230
• Order entry: 12636DVB1
Packed product information
• Gross weight per piece: 76.5 g
• Height: 12.9 cm
• Length: 9.5 cm
• Net weight per piece: 21.5 g
• Pack Quantity / MOQ: 1
• Width: 5 cm
Outerpack information
• Gross weight per piece: 0.765 g
• Height: 14.6 cm
• Length: 25.9 cm
• Net weight per piece: 215 g
• Width: 20.1 cm
•
Highlights
UV Resistant
Philips special anti-UV coating technology protects
the headlights against harmful ultraviolet radiation,
making Philips UV-coated quartz glass ideal for all
driving conditions and ensures their longevity at the
same time.
5000K for style upgrade
Based on the special complete blue coating design,
DiamondVision Moto is offering ultimate white light
of 5000K, bringing style to your headlights
High quality quartz glass
Issue date 2020-02-03
Version: 3.0.1
UV-Quartz glass is stronger than hard glass and
highly resistant to temperature extremes and
vibrations, which eliminates the risk of explosion.
Philips quartz-glass lamps (filament 2 650º C and
glass 800º C) are able to withstand severe thermal
shock. With the capability to withhold increased
pressure inside the lamp, UV-quartz glass is able to
produce more powerful lighting. ^Application varies
per bulb type.
Resistance against humidity
Only a burning bulb made of quartz glass (filament
2650°c, glass 800°c) can resist thermal shocks : such
as, if a drop of cold water touches the hot bulb,
which can happen when you drive through water
with a broken headlight unit. ^Application varies per
bulb type
Manufacturers' choice
For 100 years, Philips has been on the forefront of
the automotive lighting industry, introducing
technological innovations that have become
standards on modern automobiles. Today, one in
two cars in Europe and one in three worldwide, is
equipped with Philips lighting.
© 2020 Philips Lighting Holding B.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Philips Lighting Holding
B.V. or their respective owners.
12 NC: 8670 001 56374
www.philips.com
