19 inch CRT Monitor 19 inch CRT Monitor
when screen size and the environment
when screen size and the environment
matter
matter
See more, do more: With high resolution SUXGA performance, a big screen that displays more without
scrolling, great features and environmentally friendly lead-free design, this 109E5 CRT monitor delivers
an outstanding return on investment.
Outstanding front of screen performance
• SUXGA 1920 x 1440 resolution for shaper display
• Flat square tube reduces distortion and reflection
• sRGB ensures color matching between display and printouts
Great convenience
• Compatibility with PC, Mac and workstation platforms
• Quick and easy to personalize On-Screen-Display control
• Plug and play for easy and friendly installation
• Large viewing area for seeing more images without scrolling
109E50
Green design
• Lead-free display protects your health and our environment
• Lower power consumption than the industry average
• TCO guarantees the highest safety and ergonomics standards
• Environmentally responsible Energy Star Partner
• Flame retardant case safeguards the display from fire
Commercial Specifications
Product Highlights
Picture/Display
• Display Screen Type Flat Square Tube
Panel Size 19"/ 46 cm
•
Phosphor P22
•
Recommended Display Area 355 x 265 mm
•
(14" x 10.4")
Dot Pitch 0.27 mm
•
Horizontal Dot Pitch 0.23 mm
•
White Chromaticity, 5500º K x = 0.332 / y = 0.347
•
White Chromaticity, 6500º K x = 0.313 / y = 0.329
•
White Chromaticity, 9300º K x = 0.283 / y = 0.297
•
• Maximum Resolution 1920 x 1440 @ 60 Hz
Recommended Resolution 1280 x 1024 @ 85 Hz
•
Factory Preset Modes 7 modes
•
720 x 400 @ 70 Hz,
800 x 600 @ 75 Hz,
800 x 600 @ 85 Hz,
1024 x 768 @ 75 Hz,
1024 x 768 @ 85 Hz,
1280 x 1024 @ 75 Hz,
1280 x 1024 @ 85 Hz
• Factory Preload Modes 24 modes
• Video Dot Rate 240 MHz
Horizontal Scanning Frequency 30 - 92 KHz
•
Vertical Scanning Frequency 50 - 160 Hz
•
Recommended Refresh Rate 85 Hz
•
Screen Enhancements Anti-glare Polarizer,
•
Anti-Reflection, Anti-Static
sRGB Yes
•
GTF Yes
•
Connectivity
• Cables D-sub Video Cable,
Power Cord
• Sync Input Impedance (ohm) 2.2 k
• Video Input Impedance (ohm) 75
• Video Input Signal Levels 0.7 Vpp
• Video Sync Input Signal Composite Sync,
Separate Sync,
Sync on Green
• Video Sync Polarities Positive and Negative
• Cable Connection AC Power in, D-sub
Accessories
• Included Accessories AC Power Cord
• User Manual Yes
Dimensions
• Depth (with base) 437 mm
• Height (with base) 433 mm
• Width (with base) 440 mm
• Temperature Range (Operation) 0°C to 35°C
• Temperature Range (Storage) -25°C to 65°C
• Weight 17.8 kg
Power
• Comply With E2000, Energy Star, NUTEK
• Consumption 65 W (Typical)
• Off Mode 1 W
• Power LED Indicator Off, Amber;
Operation, Green
• Power Supply Built-in
SUXGA, 1920 x 1440 resolution
SUXGA (Super Ultra Extended Graphics Array) is a screen
resolution of 1920 x 1440 pixels.
Flat square tube
A tube designed to reduce distortion and reflection.
sRGB ready
Calibrated RGB that is optimized for the vast majority of computer
peripherals, monitors, operating systems and browsers, allowing
accurate color mapping with very little data overhead.
Platform compatibility
The ability to work with a variety of platforms; Philips monitors
are compatible with PCs and workstations by employing a VGA
connection and connect with Macintoshes.
OSD On-Screen-Display control
An on-screen panel for adjusting a monitor. The OSD is used for
contrast, brightness, horizontal and vertical positioning and other
monitor adjustments.
Easy plug and play
The ability of display device to plug in a PC and operate without
requiring user intervention to adjust complicated settings.
Large viewing area
The visible portion of a monitor screen available to display data.
Lead free
Lead-free display products are designed and produced in
compliance with strict European Community Restriction of
Hazardous Substances (RoHS) standards that restrict lead and
other toxic substances that can harm health and the environment.
Energy efficiency
Reduction of the electrical power required to operate a device to
achieve real savings.
TCO compliance
A TCO (Swedish confederation of Professional Employees) standard
even more stringent than MPR-II for safety and ergonomics,
especially concerning alternating electric fields (AEF).
Convenience
• Convenience Enhancements Menu Languages,
On-screen Display
• Monitor Controls Brightness Control,
Contrast Control,
Left/Right, Menu,
Power On/Off,
Up/Down
• OSD Languages English, French, German,
Italian, Simplified Chinese,
Spanish, Portuguese,
Korean
• Plug & Play Compatibility DDC 2B, sRGB,
Windows 98/ME/2000/XP
• Regulatory Approvals CE Mark, FCC-B, UL, CSA,
SEMKO, TCO'03, TÜV/GS,
TÜV Ergo, FDA, E2000,
NUTEK, Energy Star
• Swivel +/- 90°
• Tilt -5° to 25°
Energy Star Partner
Power conservation requirements set forth by the Environmental
Protection Agency of the U.S. government.
Flame retardant case
A system of limiting accidental fires by engineering flame retardants
into the monitor's case.
Trademarks owned by Royal Philips Electronics
2004 © Royal Philips Electronics - All rights reserved
As an Energy Star partner, Philips has determined that
this product meets the Energy Star guidelines for
energy efficiency.
Microsoft and Windows are registered trademarks of
Microsoft Corporation.
All data subject to change without notice
Release date: November 2004, v.2
