Premier Collection
The Value of Handcrafted Quality
Slim On-Wall Speaker O ffers New Placement Options
Slim-line styling and dynamic performance is what sets the PC 6.1 apart. Its sleek
profile is perfect for on-wall mounted applications where maximum perf o rmance is
d e s i red with minimal visibility and can be used as front main, center or rear channel
speakers. The PC 6.1 is an unobtrusive five inches deep, features an innovative
b r a c k e t that allows the speaker to be aimed toward the listening position by pivoting
f rom side to side and has a user adjustable switch to compensate for on-wall or in-ro o m
placement of the speaker .
Specifications PC - 6.1
Tweeter
Woofer
Frequency Response
Sensitivity
Impedance
Recommended
Amplifier Power
Dimensions
Grille
Finishes
Shipping Weight
1" low distortion user-adjustable variable-axis soft dome with
Unicell anti-diffraction treatment
6 1/2" RPF Kevlar-laminated solid flat-piston driver with butyl
rubber surround in a cast aluminum alloy basket
80-22,000 Hz (± 3 dB)
91 dB
6 Ohms nominal
20w - 150w
13 3/4"h x 8 1/4"w x 5 3/8"d
Geometric tapered black or white fabric
Natural Cherry, Honey Oak, White and Black Ash furn i t u re-grade
real wood veneers
20 lbs. each
PC 6.1; Oak finish
P o w e red Subwoofer Enables Dynamic System Upgrades
The Premier Collection Subwoofer delivers the deep, floor-shaking bass that brings
added realism and unparalleled impact to movie soundtracks and music. Adding
one of these powered subwoofers is the single most impactful upgrade to any
h o m e - t h e a t e r speaker system.
This stand-alone sub was designed to complement the PC series of speakers. It cre a t e s
the added dimension and extreme sonic effects that only true deep bass can deliver.
This model features automatic-on circ u i t ry to activate the subwoofer’s amplifier when
a music source is detected and deactivates the sub when finished listening. Va r i a b l e
c rossover points and a phase switch enable this subwoofer to blend precisely and
seamlessly with all Phase Technology Premier Collection speaker systems.
Specifications PC - Subwoofer
Amplifier Power
Woofer
Phase Switch
Crossover Slope
Frequency Response
Inputs/ Outputs
Dimensions
Grille
Finishes
Shipping Weight
300-watt internal servo amp with auto-on and level controls
10" mica/graphite/poly cone with large roll rubber surround
0°/180° user adjustable
24 dB/Octave variable low pass
20-180 Hz adjustable
High/low level
1 6"h x 15 1/2"w x 19"d
Geometric tapered black fabric
Natural Cherry, Honey Oak, and Black Ash furn i t u re-grade real
wood veneers
65 lbs.each
Model PC Subwoofer; Black finish
Model PC Subwoofer; Black finish
Phase Technology Corporation
6400 Yo u n g e rman Circle
Jacksonville, FL 32244
For Product and Local Dealer Inform a t i o n :
1-888-PHASE TK www. p h a s e t e c h . c o m
Absolute Phase™, Unicell™, and RPF™ are trademarks of
Phase Technology Corp. Kevlar™ is a trademark of DuPont.
Specifications are subject to change without notice.
P a rt #218-2019
The New PC-9.1 Tower
The Value of
Handcrafted Quality
Thank you for considering Phase Technology home
e n t e rtainment speakers. We know that you have many
choices as you evaluate new speakers, and so we sincere l y
a p p reciate your interest in our pro d u c t s .
Speaker Design Patents
Our speakers reflect over four decades of experience
in speaker design and manufacturing. Phase Te c h n o l o g y
holds several key patents in loudspeaker technology,
including the industry - s t a n d a rd soft-dome tweeter, and
we are dedicated to constantly advancing the art and
science of audio re p ro d u c t i o n .
Phase Technology is one of the few fully vert i c a l l y
integrated American speaker manufacturers. We
p roduce virtually all of our own sub-assemblies
(including constructing woofers, tweeters and cro s s o v e r s ,
and even winding voice coils) and also build all of our
wood speaker cabinets. All Phase Technology speakers
a re constructed at our company’s 6 0 , 0 0 0 - s q u a re - f o o t
Jacksonville, Florida headquarters facility.
Absolute Phase™ Cro s s o v e r s
All Phase Technology Speakers are distinguished
by our company’s exclusive Absolute Phase cro s s o v e r
t e c h n o l o g y.
These crossovers ensure that the speaker drivers are
acoustically and electronically “in phase” and thus
moving in unison. This is especially apparent when a
sound effect moves from left-to-center-to-right or vice
versa. The transition is heard as a smooth flow fro m
one speaker to the next, creating a large, well-defined
soundstage with precise imaging and increased depth
of field.
This enables every listener to hear every musical n o t e
and soundtrack passage clearly re g a rdless of seating
position. It allows any Phase Technology speaker to
be positioned vertically or horizontally and all modelsc a n
be mixed for center, main and rear applications. The
result is a seamless, wide sound stage throughout your
home theater.
Ve rtical-axis dispersion is also maintained no matter
where the speakers are positioned. This is especially
n o t e w o rthy for center-channel speakers placed horiz o n t a l l y, enabling listeners to be off-axis, on either side
of center, and hear clear, intelligible dialogue.
Sets the Standard for the
P remier Collection
The newest premium speaker in the signature
P remier Collection is a handsome, floor-
s t a n d i n gt h ree-way model. PC-9.1 re p re s e n t s
the company’s most advanced technology and
design profile, reflecting Phase Te c h n o l o g y ’s
b y w o rds, “The Value of Handcrafted Quality.”
This series incorporates the state-of-the-art
in loudspeaker development for unsurpassed
sound re p roduction. Included are advanced
technologies developed by Phase Te c h n o l o g y
like solid-flat piston drivers (patent #4566178)
which inhibit the “break up modes” that
degrade clarity and smoothness. Our Unicell™
a n t i - d i ffraction treatment, a pro p r i e t a ry unif o rm density foam, surrounds every tweeter
(and midrange on the PC9.1 and PC3.1) to
Model PC-9.1,
Floor Standing Main Speakers,
C h e rry finish
patented (patent #3328537) Phase Technology invention, that can be aimed by
the user to create a wide soundstage.
Model PC-9.1 expresses the highly stylized design of the entire Premier Collection
with its softly rounded edges that invite a finger’s touch. Three furn i t u re-grade re a l
wood finishes are off e red: Natural Cherry, Honey Oak, and Black Ash. New,
s t r i k i n g geometric black grilles narrow at top and bottom and flare in the middle,
and floor spikes with removable carpet pins are included.
Specifications PC - 9.1
Tweeter/ Midrange
Woofer/ Midrange
Frequency Response
Sensitivity
Impedance
Recommended
Amplifier Power
Dimensions
Grille
Finishes
1" low distortion user-adjustable variable-axis soft dome and a 1 1/2"
soft-dome midrange driver surrounded by Unicell anti-diff r a c t i o n
t re a t m e n t .
T h ree 61/2" RPF solid flat-piston drivers with butyl rubber surro u n d s
in cast aluminum alloy baskets
32-22,000 Hz (± 3 dB)
92 dB
4 Ohms nominal
20w - 350w
451 / 2"h x 81 / 4"w x 14"d, Base 9"x 15
Geometric tapered black fabric
Natural Cherry, Honey Oak, and Black Ash furn i t u re-grade real
wood veneers
absorb stray sound waves before they can re f l e c t
o ff the cabinet and grille surfaces to cre a t e
d i ff r a c t i o n d i s t o rtions. Also feature da re useradjustable variable-axis soft-dome tweeters, a
"
Shipping Weight
84 lbs. each
Multi-Purpose Speakers
B o o k s h e l f
Expand Your
Home Entertainment Choices
Two full-range, multi-purpose
P remier Collection speakers, the
t o p - p e rf o rming Model PC-3.1 II
and the mid-priced Model PC-33.1,
offer a choice of speaker solutions
for your home entertainment center.
Flexibility is the keyword as these
speakers are ideal for horizontal
and/or vertical positioning for main
and center-channel use. Model PC-
3.1 II adds a user-adjustable speaker
a rray to change the positioning of the
drivers. These magnetically shielded
speakers continue the Pre m i e r
C o l l e c t i o n ’s grille styling cues and
wood-finish choices.
These full-range models are designed
to accurately handle the rapid volume
changes and breadth of f re q u e n c y
response that is the h a l lmark of
digital multi-channel p ro g r a m
s o u rces. Their Absolute Phase
c rossovers offer wide latitude in
speaker system placement and
positioning.
Enjoy truly breathtaking homet h e a t e r realism with these models,
and, the experts agree, they’re
o u t s t a n d i n g for music, too!
Specifications PC - 3.1 II PC - 33.1
Tweeter
Woofer
Midrange
Frequency Response
Sensitivity
Impedance
Recommended
Amplifier Power
Dimensions
Grille
Finishes
Shipping Weight
1" low distortion user- a d j u s t a b l e
variable-axis soft dome with
Unicell anti-diffraction tre a t m e n t
Dual 61/2" RPF solid flat-piston
drivers w/butyl rubber surro u n d
in cast aluminum alloy baskets
11/2" soft-dome
38-22,000 Hz (
92 dB
6 Ohms nominal
20w - 250w
2 2"h x 81 / 4"w x 11 3/4"d
Geometric tapered black fabric
Natural Cherry, Honey Oak, and
Black Ash furn i t u re-grade re a l
wood veneers
40 lbs. each
Model PC-3.1 II; Cherry finish
Model PC-3.1 II; Black finish in
center channel configuration
Model PC-33.1; Black finish
1" low distortion user- a d j u s t a b l e
variable-axis soft dome with
Unicell anti-diffraction tre a t m e n t
Dual 51/4" RPF solid flat-piston
drivers w/butyl rubber surro u n d
N / A
± 3dB)
60-22,000 Hz (
90 dB
4 Ohms nominal
20w - 150w
171 / 4"h x 61 / 4"w x 10"d
Geometric tapered black fabric
Black Ash woodgrain laminate
18 lbs. each
± 3dB)
M o d e l O f f e r s
More Speaker
S o l u t i o n s
The Premier Collection also includes
a small-sized bookshelf speaker to fit
your home entertainment needs.
G reat dynamics and deep bass
response makes the Model PC-1.1 II
the perfect choice for building a multichannel system or upgrading a twochannel stereo system. For full
home-theater realism, add a Phase
Technology powered subwoofer and Premier Collection
c e n t e r-channel speaker to four fro n t / rear bookshelf models.
Model PC-1.1 II features a Kevlar-laminated solid flat-piston
woofer in a cast aluminum alloy basket for enhanced
p e rf o rmance. There ’s also a user-adjustable low distort i o n ,
variable axis soft dome tweeter for flexibility in speaker
placement and precise soundstage positioning. For full-range
p e rf o rmance that belies its small size, audition the Model
PC-1.1 II - it must be heard to be believed!
Specifications PC - 1.1 II
Tweeter
Wo o f e r
Frequency
Response
Sensitivity
Impedance
Dimensions
Grille
Finishes
Shipping Weight
1" low distortion
u s e r-adjustable variable-axis
soft dome with Unicell
anti-diffraction treatment
6 1/2" RPF Kevlar- l a m i n a t e d
solid flat-piston driver with
butyl rubber surround in a
cast aluminum alloy basket
40-22,000 Hz (± 3 dB)
91 dB
6 Ohms nominal
13 1/4"h x 8 1/4"w x 10"d
Geometric tapered
black fabric
Natural Cherry, Honey Oak,
and Black Ash furn i t u re - g r a d e
real wood veneers
43 lbs. pair
Model PC-1.1 II;
C h e rry finish
