Phase Linear CD-1211 Owners Manual

CD1211

Owner's Manual

AM/FM/CD Receiver

MONO

CD1211 CD RECEIVER

SCAN

TUNE

AUX IN

PREPARATION

CD1211

Getting Started

Congratulations on your purchase of the Phase Linear CD1211 Mobile AM/FM/CD Receiver. It’s a good idea to read all of the instructions before beginning the installation. We recommend having your Phase Linear CD1211 installed by a reputable installation shop.

Contents

Installation Instructions.............................. 3

Wiring ........................................................ 6

Operating Instructions ............................... 7

Tuner Operation ...................................... 10

CD Player Operation ............................... 12

Remote Control ....................................... 14

Care and Maintenance ............................ 15

Troubleshooting....................................... 16

Specifications .......................................... 17

Installation Requirements

This unit is designed for installation in cars, trucks and vans with an existing radio opening. In many cases, a special installation kit will be required to mount the radio to the dashboard. These kits are available at electronics supply stores and car stereo specialty shops. Always check the kit application before purchasing to make sure the kit works with your vehicle. If you need a kit but cannot locate one, call our

customer support line at 1-800-323-4815. (U.S.A. and Canada only.)

Tools and Supplies

The following tools and supplies are needed to install the radio.

• Torx type, flathead and Philips screwdrivers

• Wire cutters and strippers

• Tools to remove existing radio (screwdriver, socket wrench set or other tools)

• Electrical tape

• Crimping tool

• Volt meter/test light

• Crimp connections

• 18 gauge wire for power connections

• 16-18 gauge speaker wire

Speaker Requirements

Only connect speakers rated with a load impedance of 4 ohms. Speakers with a load impedance of less than 4 ohms could damage the unit.

Disconnect Battery

Before you begin, disconnect the battery negative terminal.

Toll-Free Installation Assistance

If you require assistance, contact Technical Support at 1-800-323-4815 from 8:30 a.m. to 7:00 p.m. EST Monday through Friday and from 9:00 a.m. to 5:00 p.m. EST on Saturday. (U.S.A. and Canada only.)

CD1211

INSTALLATION INSTRUCTIONS

Pre-installation

1. Disconnect Battery

Before you begin, always disconnect the battery negative terminal.

2. Remove Transport Screws

IVE

Universal Installation Using Mounting Sleeve

1. Remove the detachable front panel, if it is

attached to the chassis, by pushing the “Release” button.

2. Slide the mounting sleeve off of the

chassis if it has not already been removed. If it is locked into position, use the removal keys (supplied) to disengage it. The removal keys are depicted on page 5.

3. Check the dashboard opening size by

sliding the mounting sleeve into it. If the opening is not large enough, carefully cut or file as necessary until the sleeve easily slides into the opening. Do not force the sleeve into the opening or cause it to bend or bow. Check that there will be sufficient space behind the dashboard for the radio chassis.

4. Locate the series of bend tabs along the

top, bottom and sides of the mounting sleeve. With the sleeve fully inserted into the dashboard opening, bend as many of the tabs outward as necessary to firmly secure the sleeve to the dashboard.

5. Place the radio in front of the dashboard

opening so the wiring can be brought through the mounting sleeve.

6. Follow the wiring diagram carefully and make certain all connections are secure and insulated with crimp connectors or electrical tape to ensure proper operation.

7. After completing the wiring connections, attach the front panel and turn the unit on to confirm operation (vehicle ignition switch must be on). If the unit does not operate, recheck all wiring until the problem is corrected. Once proper operation is achieved, turn the ignition switch off and proceed with final mounting of the chassis.

8. Carefully slide the radio into the mounting sleeve, making sure it is right-side-up, until it is fully seated and the spring clips lock it into place.

CD1211

9. Attach one end of the perforated support strap (supplied) to the screw stud on the rear of the chassis using the hex nut provided. Fasten the other end of the perforated strap to a secure part of the dashboard, either above or below the radio, using the screw and hex nut provided. Bend the strap, as necessary, to position it. CAUTION: The rear of the radio must be supported with the strap to prevent damage to the dashboard from the weight of the radio or improper operation due to vibration.

10. Re-attach the front panel to the chassis and test radio operation by referring to the operating instructions for the unit.

NOTE: For proper operation of the CD player, the chassis must be mounted within 20° of horizontal. Make sure the unit is mounted within this limitation.

Kit Installation

If your vehicle requires the use of an installation kit to mount this radio, follow the instructions included with the installation kit to attach the radio to the mounting plate supplied with the kit.

2. Install the radio/mounting plate assembly to the sub-dashboard according to the instructions in the installation kit.

3. Attach the support strap to the radio and dashboard as described in the Universal Installation instructions.

4. Replace the dashboard trim panel.

ISO Installation

This unit has threaded holes in the chassis side panels which may be used with the original factory mounting brackets of some vehicles to mount the radio to the dashboard. Please consult with your local car stereo shop for assistance on this type of installation.

1. Remove the existing factory radio from the dashboard or center console mounting. Save all hardware and brackets as they will be used to mount the new radio.

2. Carefully unsnap the plastic frame from the front of the new radio chassis. Remove and discard the frame.

3. Remove the factory mounting brackets and hardware from the existing radio and attach them to the new radio. Do not exceed M5 x 9 MM maximum screw size.

Longer screws may damage components inside the chassis.

4. Wire the new radio to the vehicle as outlined in the Universal Installation instructions.

5. Mount the new radio assembly to the dashboard or center console using the reverse procedure of step 1.

Reconnect Battery

When wiring is complete, reconnect the battery negative terminal.

1. Wire and test the radio as outlined in the Universal Installation instructions.

CD1211

Remove Radio

To remove the radio after installation, remove the trim ring by lifting in the center and pulling it off from either side. Insert the removal keys straight back until they lock, and then pull the radio out. If removal keys are inserted at an angle, they will not lock properly to release the unit.

Removal Key

WIRING

CD1211

1. Power Antenna (dark blue wire) - Connect to power antenna or amplifier. If not used, tape bare end of wire.

2. Accessory/Ignition (red wire) - Connect to existing radio wire or radio fuse.

3. Ground (black wire) - Connect to ground terminal or clean, unpainted part of chassis.

4. Memory/Battery (yellow wire) - Connect to battery or 12 volt power source that is always live. The radio will not work if this wire is not connected.

5. Antenna Connector - Connect the antenna plug from the existing antenna cable (some vehicles require an adaptor).

6. Outputs to Amplifier (gray RCA cables) Connect line out for optional external amplifiers. The red connector is for the right and the white connector is for the left.

7. Left Front Speaker

8. Right Front Speaker

9. Left Rear Speaker

10. Right Rear Speaker

Fuses

When replacing a fuse, make sure the new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The CD1211 uses one 15 amp fuse located below the wiring connector (15 amp fast blow ATO).

Dark Blue

Black

Gray

Yellow

Red

NOTE: The amplifiers in this radio are only designed for use with four speakers. Never combine (bridge) outputs for use with two speakers. Never ground negative speaker leads to chassis ground. Failure to wire exactly as shown may cause electrical

White/Black (-)

White (+)

Gray/Black (-)

Gray (+)

damage to the radio.

Green/Black (-)

Green (+)

Violet/Black (-)

Violet (+)
