Pharos PTL600, GPS Phone 600 Series Hardware User Manual

Pharos GPS Phone 600 Series

Hardware User's Manual

GPRS / EDGE Settings for AT&T / Cingular

Step 1 Step 2

Step 3

♦ Tap Start, Settings, the

Connections tab,
Connections, and then the
Tasks tab.

♦ Tap Add a new modem

connection.

♦ Enter a new connection name

(i.e. Cingular GPRS).

♦ Select Cellular Line (GPRS).
♦ Tap Next.

Step 4

♦ Enter Access point name

wap.cingular.
♦ Tap Next.

♦ Tap Finish.

i

GPRS / EDGE Settings for T-Mobile

Step 1 Step 2

Step 3

♦ Tap Start, Settings, the

Connections tab,
Connections, and then the
Tasks tab.

♦ Tap Add a new modem

connection.

♦ Enter a new connection name

(i.e. T-Mobile GPRS).

♦ Select Cellular Line (GPRS).
♦ Tap Next.

Step 4

♦ Enter Access point name

wap.voicestream.com.
♦ Tap Next.

♦ Tap Finish.

ii

Table of Contents

GPRS / EDGE Settings for AT&T / CINGULAR i
GPRS / EDGE Settings for T-Mobile ii
Table of Contents 1
Please Read Before Proceeding 6
Important Safety Precautions 7
Chapter 1: Voice Command Satellite Navigation 9

Navigation Device Installation

1.1

GPS Navigation Software Installation

1.2

Conditions for Using GPS Car Navigation

1.3

Chapter 2: Getting Started 12

Package Contents

2.1

External Views

2.2

2.3

2.4

Chapter 3: Using the GPS Phone 600 24

3.1

3.2

• Hardware Hot Key Functions

• Rear Side

Using the GPS Phone 600 for the First Time

• Charging Power and Power Supply

• Re-installation or Replacing the Battery

Power On and Off

• Sleep Mode

• Turn on the Screen

• Restarting the GPS Phone 600

• Reset

• Cold Boot

Start Screen

• Today Screen

• Programs

• System Application Programs

Entering Information on Your GPS Phone 600

• Entering Text Using the Input Panel

• Typing with the Soft Keyboard

• Using Letter Recognizer

• Using Block Recognizer

• Using Transcriber

• Selecting Typed Text

• Writing on the Screen

9
10
10

12
13
14
15
16
16
18
19
19
20
21
21
22

24
25
27
29
31
31
32
32
33
33
33
34

1

• Selecting Writing

• Convert Writing to Text

• Drawing on the Screen

• Creating a Drawing

• Selecting a Drawing

• Recording a Message

• Creating a Recording

• Using My Text

34
35
36
36
37
37
38
39

Chapter 4: Using the Phone 40

Installing and Removing the SIM Card

4.1

• Installing the SIM Card and Battery

Using the Phone

4.2

4.3

4.4

4.5

• Adjusting the Phone Volume

Turning the Phone On / Off and Making Calls

• Phone Toolbar

• Calling from Contacts

• Calling from Speed Dial

• Calling from the Call History

Customizing Your Phone
Phone Application Programs

• SIM Tool Kit

• SMS Sender

41
41
42
43
44
45
45
46
46
47
48
48
48

Chapter 5: Customize Your GPS Phone 600 49

Adjusting Settings

5.1

5.2

5.3

5.4

5.5

5.6

5.7

5.8

5.9

5.10

Notifications
Power Preference Settings
Backlight
Microphone
Adjusting the Volume
Find and Organizing Information
Navigation Bar and Command Bar
Pop-Up Menus
Redefine Hot Keys

49
50
51
52
53
54
55
56
57
58

Chapter 6: Using Microsoft ActiveSync 59

Installing and Using ActiveSync

6.1

• ActiveSync Connection Troubleshooting

USB Synchronization

6.2

• USB Synchronization

Synchronizing Using Bluetooth

6.3

60
61
62
62
65

Chapter 7: Connections 66

Connecting to the Internet

7.1

66

2

7.2

7.3

7.4

7.5

• Setting the GPRS / EDGE Connection

• Starting GPRS / EDGE Connection

• Disconnecting GPRS / EDGE

Using Bluetooth

• Bluetooth Connection Wizard

• Bluetooth Connection Setting

• Service

• Serial Port

• Bluetooth Headset

• FTP Sharing

CSD Type
Connecting with a Personal Computer
Wireless LAN Transmission

67
68
69
70
70
72
73
74
75
75
76
77
77

Chapter 8: Using Wireless LAN 78

Connecting to Wireless LAN

8.1

Configure Your Wireless Network

8.2

(Reference for a Normal Network Setup)
Configure Your Wireless Network

8.3

(Reference for Proxy Setup)

78
80
82

Chapter 9: Sending and Receiving Messages 84

E-mails and SMS Messages

9.1

9.2

• Synchronizing E-mail Messages

• Connecting Directly to the Mail Server

• E-mail Server Setup

• Using E-mails and SMS

• Direct Push Technology Alert

• Direct Push Technology Alert Settings

MSN Messenger

• Setting Up

• Working with Contacts

• Chatting with Contacts

84
85
86
87
88
91
91
93
94
95
96

Chapter 10: Multimedia 97

10.1

10.2

Using Camera

• Camera Mode

• Camera Mode Using Wizard

• Managing Pictures Shot by Continuous Shutter

• Digital Video Mode

• Digital Video Mode Using Wizard

• Speed Shooting Using the Hardware Hot Keys

FM Tuner

97
98
99

100
101
103
104
105

Chapter 11: Companion Programs 107

3

11.1

11.2

11.3

11.4

11.5

11.6

11.7

11.8

11.9

Calendar: Scheduling Appointments and Meetings

• Create an Appointment

• Use the Summary Screen

• Create Meeting Requests

• Schedule a Meeting

Contacts: Tracking Friends and Colleagues

• Create a Contact

• Find a Contact

• Use the Summary Screen

Tasks: Keeping a To Do List

• Create a Task

• Use the Summary Screen

Notes: Capturing Thought and Ideals

• Create a Note
Word Mobile
Excel Mobile

• Tips for Working in Excel Mobile
PowerPoint Mobile
Windows Media Player
Internet Explorer

• Using Internet Explorer

• Browse the Internet

• View Mobile Favorites

• The Mobile Favorites Folder

• Favorite Links

• Synchronize Mobile Favorites

• Create a Mobile Favorite

• Save GPS Phone 600 Memory

108
109
110
110
110
111
112
113
113
114
115
116
117
117
118
120
122
123
124
125
125
126
127
127
128
128
128
129

Chapter 12: Maintaining the GPS Phone 600 130

12.1

12.2

12.3

Adding or Removing Programs

• Add Programs Using ActiveSync

• Add a Program Directly from the Internet

• Add a Program to the Start Menu

• Remove Programs

Manage Memory

• View Memory Status

• Find Available Memory

System Information

130
130
131
131
132
133
133
135

138
Chapter 13: Specifications 139
Appendix 140

Regulation Notices and Safety Declaration

A.1

• Health and Safety Information

140

140

4

A.2 FCC Regulations
A.3 RF Exposure Information (SAR)

• SAR Information

• Holster Information

• Where to Find Information

A.4 FAQ

142

143

143

143

144

145

5

PLEASE READ BEFORE PROCEEDING

♦ This device is not charged when you take it out of the box. When you use this

product the first time, we recommend that you install the battery as illustrated and
fully charge it for about 8 hours before use. Do not remove the battery pack when
the device is charging.

♦ Before you install the SIM card, make sure to tap the ALL OFF Button in Wireless

Manager to turn off your GPS Phone 600’s mobile phone, Bluetooth, and
wireless LAN functions. Press the “Power Button” of the GPS Phone 600 to turn
off the screen. Otherwise, disconnection problems or damage to the SIM card
may occur.

♦ When you are on a plane, in a medical facility or at a gas station where wireless

communications devices are not allowed and must be turned off, please go to
Wireless Manager and select the ALL OFF Button to turn off your GPS Phone
600’s mobile phone, Bluetooth, and wireless LAN functions. By pressing the
“Power Button” of the GPS Phone 600, you only turn off the display.

♦ In case the GPS Phone 600 is damaged, send it back to the dealer for repair. Do

not attempt to disassemble the GPS Phone 600 on your own; otherwise the
warranty will be void. Your warranty will be invalidated if you open or tamper with
the device’s outer casing.

♦ This document lists the functions, specifications, and illustrations for reference

only. Product specifications are subject to change.

6

Important Safety Precautions

When using this product the safety precautions below must be taken to offset possible
legal liabilities and damages.

Electrical Safety

This product is intended for use when supplied with power from the battery. Other
usage may be dangerous and will invalidate any approval given to this product.

Safety in Aircraft

Due to the possible interference caused by this product to an aircraft’s navigation
system and its communications network, using this product on board an airplane is
against the law in most countries.

Interference with Medical Equipment Functions

This product may cause medical equipment to malfunction. The use of this device is
forbidden in most hospitals and medial clinics.

Nonionizing Radiation

This product should be operated in the suggested normal condition only to ensure the
radioactive performance and safety of the interference. As with other mobile radio
transmitting equipment, users are advised that for satisfactory operation of the
equipment and for the safety of personnel, it is recommended that no part of the human

body be allowed to come too close to the antenna during operation of the equipment

Body-worn Operations

This device was tested for typical body-worn operations with the back of the phone kept

1.5 cm from the body. To maintain compliance with FCC RF exposure requirements,
use only belt-clips, holsters or similar accessories that maintain a 1.5 cm separation
distance between the user’s body and the back of the phone, including the antenna.
The use of belt-chips, holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and should be
avoided.

Road Safety

Vehicle drivers in motion are not permitted to use telephony services with handheld
devices, except in the case of emergency. In some countries, using hands-free devices

as an alternative is allowed.
Environment Restrictions

Do not use this product at gas or refueling stations. The use of this product is also
prohibited in fuel storehouses, chemical plants, and locations containing explosives.

7

Safety for Environments

Do not use this product in gas stations, fuel depots, chemical plants or where blasting
operations are in progress, or in potentially explosive atmospheres such as fueling
areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas
where the air contains chemicals or particles, such as grain, dust, or metal powders.
Please be aware that sparks in such areas could cause an explosion or fire resulting in
badly injury or even death.

Explosive Atmospheres

When in any area with a potentially explosive atmosphere or where flammable materials
exist, the product should be turned off and user should obey all signs and instructions.
Sparks in such areas could cause an explosion or resulting in bodily injury or even
death. Users are advised not to use the equipment at refueling points such as service or
gas stations. Users are reminded of the need to observe restrictions on the use of radio
equipment in fuel depots, chemical plants or where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked.
These include fueling areas, below desk on boats, fuel or chemical transfer or storage
facilities, and areas where the air contains chemicals or particles, such as grain, dust, or
metal powders.

8

Chapter 1

Voice Command Satellite Navigation

1.1 Navigation Device Installation

1. GPS Phone 600: Slide into the GPS Holder.

2. Car Charger: When GPS Phone 600 is low on power, recharge by
connecting one end to the car cigarette lighter/12 volt power outlet and
the other end to the socket on base of the GPS Holder.

3. Car Mount/Holder

 Attention:

The GPS signal receiver is built into the GPS Phone 600. If car windscreen has
heat reflective metallic film, or the GPS Phone 600 is obstructed by other

objects, reception of the GPS signals may be affected.

9

1.2 GPS Navigation Software Installation

Please refer to the Ostia User Manual for instructions on installing and operating Ostia
Navigation software.

1.3 Conditions for Using GPS Car Navigation

By using this system you are agreeing to the following conditions:

♦ When using this device, please use the included car mounting. Affix device

securely to the car mount. Please note that installation in the areas shown below
can be dangerous.

1. Do not place where it will obstruct driver vision.

♦ Please set navigation destination before driving. Do not operate the controls on this

system while driving. The responsibility for safe driving rests with you.

♦ GPS positioning is limited by weather and usage location (tall buildings, tunnels,

underpasses, trees, bridges). Most GPS do not work indoors, nor can GPS signals
penetrate buildings, car sun shades and heat reflective film with metallic content.
Please use your GPS where it has a clear view of the sky.

♦ The GPS system is built and operated by the U.S. Department of Defense which is

also responsible for its maintenance and calibration. Any changes made by them
may affect the operation and accuracy of the GPS system.

2. Do not place over air bag.

3. Do not place where it can not be securely attached.

4. Do not place in path of activated air bag.

10

♦ Wireless devices (mobile phones, speed radar detectors) may interfere with the

satellite signal and cause unreliable signal reception.

♦ The GPS position fix is provided for your reference and should not affect actual

driver behavior.

♦ The electronic map data provided in the navigation system is for reference only and

not intended for high precision applications. You should determine your exact
location based on actual road conditions.

♦ When not in use, please do not leave the device inside the car. If exposed directly

to sunlight, the battery may overheat and cause damage to this device. This may
endanger the vehicle as well.

11

2.1 Package Contents

Chapter 2

Getting Started

12

2.2 External Views

1. Volume control keys

2. Screen orientation / record hot key

3. Earphone and microphone jack

4. Hot key for Ostia

5. Cell Phone speaker

6. Today Screen hot key

7. Left LED

♦ WLAN active LED (Orange)
♦ Bluetooth active LED (Blue,

blinks once)

♦ GPS active LED (Blue,

blinks twice)

8. Right LED

♦ Power charging LED (Red)
♦ Cell phone active LED (Green)

9. Touch screen

10. Left Soft-Key

11. Right Soft-Key

12. Send button

13. End button

14. Navigation button.

Press the center of the button
to set as launch key.

15. Micro SD Slot

16. Microphone

17. Mini USB port

18. Stylus holder.

Slide the stylus out of the
holder. This is a two-stage
push-pull stylus.

19. Power button

20. Reset button

21. Camera shutter

22. Built-in camera lens / preview

mirror

23. Hidden antenna for cell phone

24. Speaker

25. Back cover. Battery is inside.

13

Hardware Hot Key Functions

Hardware

Button

1

♦ Adjust volume

(Press once and release)

♦ Zoom in/out during camera mode

2 Change screen orientation Voice recording

3 Hot key for Ostia N/A

4 Connect to Today Screen N/A

5 Connect to Phone/dial/redial/answer N/A

6 Left Soft-Key:

Soft-keys on the left.
To perform the command / function shown
above the button at the bottom of the screen
display.

7 Right Soft-Key:

Soft-keys on the right.
To perform the command / function shown
above the button at the bottom of the screen
display.

8

♦ Hang up during call
♦ Disconnect during GPRS connection
♦ Skip to Today’s screen while in other

programs.

9

♦ Power Button = open or close screen
♦ Power Button + Reset Button = Cold boot

10 Reset Button N/A
11

Camera N/A

Short Press

Long Press

(Press for a few

seconds and

release)

N/A

N/A

N/A

N/A

N/A

14

Installing the SIM Card

1. Insert the SIM card into the
SIM card slot with its golden
contacts facing down. Refer to

the picture on the right.

Installing the Battery

Rear Side

1. Insert the battery. Refer to the
picture on the right.

2. To keep the battery in place, push
the lock switch up. To take out the
battery, first pull the lock switch
down. Refer to the picture on the
right.

15

2.3 Using the GPS Phone 600 for the First Time

Charging Power and Power Supply

a. Connect the AC adapter plug to any household power outlet.

b. Connect the other plug from the AC adapter to the USB port. The

GPS Phone 600 starts to charge automatically.

c. If you need to connect GPS Phone 600 and a desktop computer,

connect the USB cable to the USB port on the GPS Phone 600
and connect the other end of the USB cable to the USB port on
the desktop computer. Your GPS Phone 600 will also charge at
the same time.

1. Remove the back cover. (If you are opening this product for the first time, the
main battery and the GPS Phone 600 are packed separately inside the product

package.)

2. Install the main battery properly and lock the battery securely (install the SIM card

first if you want to use the phone functions).

3. Connect the AC adapter to any household power outlet and connect the cord from
the AC adapter to the mini-USB port on the GPS Phone 600.

16

4. Cold Boot: Press and hold the “Power Button” with one hand, and use the stylus
tip to press the “Reset Button” with the other hand. Release the “Power Button”
and the “Reset Button” at the same time. Wait for the GPS Phone 600 to restart
and follow the instructions on the screen to complete screen alignment.

5. It will take about 8 hours to fully charge the battery the first time. Subsequent
charging will only take about 3 hours. After charging, you can disconnect the AC
Adapter and carry the GPS Phone 600 with you. To maintain reliable operation
charge the power regularly. View the battery icon on the upper right corner to
check the power usage condition.

6. The LED indicator on the upper left of the GPS Phone 600 displays the WLAN,
Bluetooth and GPS status.

WLAN Active Bluetooth Active GPS Active

Orange LED flashes Blue LED blinks once

every 4 seconds

Blue LED blinks twice

every 4 seconds

7. The LED indicator on the upper right of the GPS Phone 600 indicates the
charging status, cell phone status, and notices.

Charging Fully charged Insufficient power

Red LED lights up

Red LED goes off

Green LED lights up

Red LED flashes

Phone is on Caution or Warning

Green LED flashes Orange LED flashes

17

Re-installation or Replacing the Battery

If the phone, GPRS or wireless LAN connection function is already activated, deactivate
it first and then replace the battery.

1. Slide and remove the back

cover of the GPS Phone 600.

2. Press down to unlock the main

battery lock in order to remove
the battery.

3. Replace the main battery and

lock it properly. When you
remove the main battery, your
GPS Phone 600 will enter sleep
mode.

4. Slide the back cover into the

groove, and reinstall the back
cover.

18

2.4 Power On and Off

Sleep Mode

1. Press the “Power Button” of the GPS Phone 600 to enter the Sleep mode. When
you do so, the screen is turned off and all peripheral devices enter the power­saving mode. If the Phone application is activated it will remain in call waiting
mode (as indicated by the flashing of the green indicator).

2. To turn on the screen later, just press the “Power Button.”

3. Tap Start, Settings, the System tab, Power and then the Advanced tab to
set the device to turn off automatically after a specified time period.

19

Turn on the Screen

This product is designed with a power-saving feature. If the screen is turned off, press
the “Power Button” of the GPS Phone 600 to turn it on.

If the screen is too dark
and you cannot see
clearly, set the proper
brightness level for the
backlight.

Tap Start, Settings, the
System tab, Backlight and
then the Backlight Level

tab.

Using the Stylus to Touch the Screen

♦ Your GPS Phone 600 is designed for graphics-based

operation. Use the stylus to perform basic actions such as tap,
drag, and tap and hold on the touch screen. Other actions such
as reset and cold boot will require the use of the stylus tip.

♦ Pull the stylus to full-length to make it easier to tap the screen

during operation. When kept completely in the stylus holder,
the stylus length shortens.

♦ To avoid damage to the screen, avoid pressing too heavily on

the touch screen with the stylus or your fingers.

20

Restarting the GPS Phone 600

If the GPS Phone 600 is unable to maintain normal operation, has no response, or if the
screen is frozen.
Try the following steps in order. If the problem is solved, skip the remaining steps.

Option Procedure

Reset Press the “Reset Button” of GPS Phone 600 with the tip of

the stylus.
Default
Settings
procedure
Clean Boot Hold the “Power Button” and press once on the “Reset

If the touch screen is functional, please tap Start,

Programs, Utilities, and then Default Settings.

Button” with the tip of the stylus, and release both buttons

simultaneously. Next, continually hold the End Button

until the system inquiry screen is displayed, then

release the End Button. Answer the question(s).

Reset

♦ Reset method: Press the “Reset Button” of GPS Phone 600 with tip of the stylus.
♦ Appropriate situation: If the GPS Phone 600 is unable to maintain normal

operation, has no response, or if the screen is frozen.

♦ Result: In a moment, when GPS Phone 600 automatically completes the system

startup process, the last display will be the Today screen. This will retain all of
your data, settings, and any programs you may have installed.

21

Cold Boot

Cold boot method

Hold the “Power Button” of the GPS Phone 600 with one hand while using the
stylus tip to push in the “Reset Button.” Simultaneously release both the
“Power Button” and “Reset Button”

Appropriate situation

If a previous reset has already been attempted and the GPS Phone 600 is still unable
to maintain normal operations, has no response, or if the screen is frozen.

Before executing the preceding “Cold boot method”, please carefully consider the
following instructions and then decide on the cold boot method.

1. After a cold boot is performed, if no buttons are pressed, the result is identical
to the reset result.

2. If a previous reset has already been attempted but the GPS Phone 600 is still
unable to maintain normal operation, consider the following solution: After
cold boot, hold the End Button

on the bottom right of the GPS Phone
600 until the system inquiry screen is shown, and then release the End
Button. Next, please read thoroughly through the instructions on cold booting
before continuing.

22

Perform cold boot and hold the End Button . The system will display a two
question inquiry screen. Please carefully refer to following instructions.

♦ Erase all data and load default? (The default is “No.” If Yes or

No was not selected, after a few seconds the system will
automatically execute the default No).

♦ If you press the Left Soft-Key for a few seconds to select

“Yes” then the system will erase all data and load the default
settings. After your GPS Phone 600 restarts, follow the
instructions on the screen to complete.

♦ Delete registry only? (The default is “No.” If Yes or No was

not selected, after a few seconds the system will
automatically execute the default No).

♦ If you press the Left Soft-Key for a few seconds to select

“Yes” then the system will delete the registry only.

Caution

1. After performing a cold boot, the system will retain Microsoft
Windows and pre-installed programs. If you answer “Yes” to the two
questions displayed after a cold boot, other items such as your data,
any programs you have installed, and any custom settings will be lost.

2. There are two ways to retain your data, loaded default and registry:

♦ Perform a Reset.
♦ Performing a Cold Boot, and answer “No” when the above two

questions display.

23

Chapter 3

Using the GPS Phone 600

3.1 Start Screen

Tap Start, Settings, the System tab, and then Screen.

The first time you use or cold boot the GPS Phone 600, the system will ask you to align
the screen. Continue to tap the center of each cross (+) that appears and follow the
screen instructions to complete the operation. If you feel that the position is not quite
accurate while tapping on the screen, you can align the screen again at any time.

1. Orientation:

♦ Portrait (default)
♦ Landscape (right-handed)
♦ Landscape (left-handed)

2. Tap the Align Screen button to calibrate the

screen. When Align Screen appears, use the
stylus to tap the center of the cross (+) until
the next cross appears, and then follow the
screen instructions to complete the
operation. Finally, tap to exit.

3. Text Size tab:

For selecting the desired text size.

If you are unable to use the stylus, use the following steps to open the touch screen
calibration mode.

1. Simultaneously press the Left Soft-Key on the bottom-left of the GPS Phone

600 and the execution button in the center of the navigation pad.

2. Release these two buttons at the same time, and you will enter the calibration
screen.

24

Today Screen

The Today screen displays important information, such as upcoming appointments and

status indicators. You can access it by tapping

Start and then Today or by pressing

the Today button on the upper-right of your GPS Phone 600.

1.

Start. Tap to switch to a program.

2. Tap to enable or disable the GPRS

connection feature.

3. Antenna icon. Tap to turn the phone on or

off.

4. Speaker icon. For adjusting volume.

5. Time. Tap to display the current date, time, and upcoming appointments.

Tap and hold the time area to select analog or digital clock display from the
list.

6. Today screen. Display important information for the day. Tap on any item to

enter its relevant setup screen. For example, tap to sign in to Pocket
MSN.

7. The icons mean you can tap to quick link to programs, such as Wireless
Manager, etc.

8. Tap to quick link to Contacts.

25

The following table lists the icons that you may see. Refer to the “Meaning” column for

explanation or tap on the icon to access the instant message.

Icon Meaning

Speaker is on.

Speaker is off.

Main battery is charging.

Main battery power is low.

Main battery power is very low.

Main battery is fully charged.

Notify you that you have one or more MSN instant messages.

Notify you that you have one or more e-mails, text messages or SMS.

Notify you that you have one or more voice mails.

If there is not enough space on the screen to display all notification icons,
tap this icon to view all icons.
PowerPoint slide show.

Active connection to computer.

Active Sync is synchronizing.

SIM card unavailable.

Phone is powered off.

Signal strength indicator for phone function.

No data sessions active.

GPRS in use.

The G is replaced by an E when the EDGE signal is detected.

GPRS available.

The G is replaced by an E when the EDGE signal is detected.

Wireless LAN Active.

Wireless LAN Data Calling.

Wireless LAN in use.

26

Programs

You can switch from one program to another by selecting it from the Start menu.

(You can customize which programs you see on this menu. For information, see

“Adjusting Settings” section.) To access some programs, you’ll need to tap Start,

Programs, and then the program name.

Icon Programs Description

Games Group Bubble Breaker, Solitaire.

Multimedia
Group

Phone Group SIM Tool Kit, SMS Sender.

Utilities Group Application Recovery, Bluetooth Manager,

ActiveSync Synchronize information between your GPS Phone 600

Calendar Keep track of your appointments and create meeting

Camera, FM Tuner.

Default Settings, WLAN Utility.

and desktop computer.

requests.

Contacts Keep track of your friends and colleagues.

Notes Create handwritten or typed notes, drawings, and

recordings.

Tasks Keep track of your tasks.

Messaging Send and receive e-mail messages.

Internet
Explorer

Browse Web and WAP sites, and download new
programs and files from the Internet.

Pocket MSN MSN related programs. For example, send and receive

instant messages with your MSN Messenger contacts.

Word Mobile Create new documents or view and edit Word documents

created on your desktop computer.

Excel Mobile Create new workbooks or view and edit Excel workbooks

PowerPoint
Mobile

created on your desktop computer.
View PowerPoint slide shows created on your desktop
computer.

Calculator Performs basic calculations.

Pictures &
Videos

Take, view, and edit pictures.

27

Icon Programs Description

Windows Media
Player

Plays movies or sound files.

File Explorer Manages files or folders.

Wireless
Manager

Manage the mobile phone, Bluetooth, and wireless LAN
functions.

 You can also switch to some programs by pressing a program button. Your GPS

Phone 600 has one or more programs buttons located on the front or side of the
unit. The icons on the buttons help to identify the programs they activate. For more
information, refer to “Redefine Hot Keys” section.

28

System Application Programs

♦ Tap

♦ Tap Start, Settings, the System tab.

Start, Settings, the Personal tab.

Programs Description

Buttons Set the hot key for GPS Phone 600 hardware button.
Input Set the details about the input method.
Menus

Set the items displaying on the Start menu
MSN Options Set the details about Pocket MSN.
Owner

Input owner information.
Information
Lock Set the access rights and password of GPS Phone 600.
Phone Set the details about the phone.
Sounds &

Set the volume and notification method.
Notifications
Today Set the look of Today screen and display information.

Program Description

About Display the important information about the GPS Phone

600.
Backlight Set the details about the backlight and brightness.
Certificates For network identification to prevent unauthorized access.
Clock &

Set the time and alarms.
Alarms
Memory View the memory usage, and the list of running programs,

etc.
Microphone Set the microphone volume.
Power View the power usage condition, whether or not to power off

after a waiting period.
Regional
Settings
Remove

Set the region and information display formats such as date,

time, etc.

Remove programs that are no longer used.
Programs
Screen Aligning the screen is helpful in improving the touch

accuracy. You can select the portrait or landscape

orientation.
System

View the system information.
information

29

♦ Tap Start, Setting, the Connections tab.

Program Description

Beam Set if receiving end will accept Bluetooth beam data

automatically or not.
Connections Set the network connection.
CSD Type Set GPS Phone 600 to simulate a modem and access the

Internet through the built-in GSM device.
Network
Cards
USB to PC Change the type of USB connection.

Set the details about network cards.

30

3.2 Entering Information on Your GPS Phone 600

You have several options for entering new information:

1. Use the input panel to enter typed text, either by using the soft keyboard or
other input method.

2. Write directly on the screen.

3. Draw pictures on the screen.

4. Speak into your GPS Phone 600 microphone to record a message.

5. Use Microsoft® ActiveSync® to synchronize or copy information from your
desktop computer to your GPS Phone 600. For more information on
ActiveSync, see ActiveSync Help on your desktop computer.

Entering Text Using the Input Panel

Use the input panel to enter information in any program on your GPS Phone 600. You

can either type using the soft keyboard or write using Letter Recognizer, Block
Recognizer, or Transcriber. In either case, the characters appear as typed text on

the screen.

To show or hide the input panel, tap the Input Panel button. Tap the arrow next to the
Input Panel button to see your choices.

1. Select an input method.

2. Tap to see your choices.

3. Input Panel button.

31

When you use the input panel, your GPS Phone 600 anticipates the word you are
typing or writing and displays it above the input panel. When you tap the displayed
word, it is inserted into your text at the insertion point. The more you use your GPS
Phone 600, the more words it learns to anticipate.

 To change word suggestion options, such as the number of words suggested at

one time, tap Start, Settings, the Personal tab, Input, and then the Word
Completion tab.

1. Tap here if this is the right word.

Typing with the Soft Keyboard

1. Tap the arrow next to the Input Panel button and then Keyboard.

2. On the soft keyboard that is displayed, tap the keys with your stylus.

Using Letter Recognizer

With Letter Recognizer you can write letters using the stylus just as you would on paper.

1. Tap the arrow next to the Input Panel button and then Letter Recognizer.

2. Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For

specific instructions on using Letter Recognizer, with Letter Recognizer open, tap the

question mark next to the writing area.

32

Using Block Recognizer

With Block Recognizer you can input character strokes using the stylus that are similar
to those used on the other PDA’s.

1. Tap the arrow next to the Input Panel button and then Block Recognizer.

2. Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For

specific instructions on using Block Recognizer, with Block Recognizer open, tap the

question mark next to the writing area.

Using Transcriber

With Transcriber you can write anywhere on the screen using the stylus just as you
would on paper. Unlike Letter Recognizer and Block Recognizer, you can write a
sentence or more of information. Then, pause and let Transcriber change the written

characters to typed characters.

1. Tap the arrow next to the Input Panel button and then Transcriber.

2. Write anywhere on the screen.

For specific instructions on using Transcriber, with Transcriber open, tap the question

mark in the lower right hand corner of the screen.

Selecting Typed Text

If you want to edit or format typed text, you must select it first. Drag the stylus across

the text you want to select. You can cut, copy, and paste text by tapping and holding the
selected words and then tapping an editing command on the pop-up menu, or by
tapping the command on the menu.

33

Writing on the Screen

In any program that accepts writing, such as the Notes program, and in the Notes tab
in Calendar, Contacts, and Tasks, you can use your stylus to write directly on the

screen. Write the way you do on paper. You can edit and format what you’ve written

and convert the information to text at a later time.
Tap Menu and then check Draw to switch to writing mode. This action displays lines on

the screen to help you write.

1. Tap Menu and then check
Draw. Use your stylus like a

pen now.

Some programs that accept writing may not have the Draw function. See the

documentation for the program to find out how to switch to writing mode.

Selecting Writing

If you want to edit or format writing, you must select it first.

1. Tap and hold the stylus next to the text you want to select.

2. Without lifting, drag the stylus across the text you want to select.

If you accidentally write on the screen, tap Menu, then Undo and try again. You can
also select text by tapping Menu and then Draw to deselect it and then dragging the

stylus across the screen.

You can cut, copy, and paste written text in the same way you work with typed text: tap
and hold the selected words and then tap an editing command on the pop-up menu, or

tap the command on the Menu menu.

34

Convert Writing to Text

Tap Menu, Tools, and then Recognize. If you want to convert only certain words,
select them before tapping Recognize on the Tools menu (or tap and hold the selected
words and then tap Recognize on the pop-up menu). If a word is not recognized, it is

left as writing.

1. Select the text you want to convert and tap Recognize on the pop-up

menu.

2. The writing is turned into text.

If the conversion is incorrect, you can select different words from a list of alternates or
return to the original writing. To do so, tap and hold the incorrect word (tap one word at

a time). On the pop-up menu, tap Alternates. A menu with a list of alternate words

appears. Tap the word you want to use, or tap the writing at the top of the menu to
return to the original writing.

1. Tap to return to your original
writing.

2. Or, tap the word you want to
use.

35

Tips for getting good recognition:

1. Write neatly.

2. Write on the lines and draw the descenders below the line. Write the cross of the
“t” and apostrophes below the top line so that they are not confused with the
word above. Write periods and commas above the line.

3. For better recognition, try increasing the zoom level using the Zoom menu.

4. Write the letters of a word closely and leave big gaps between words so that the
GPS Phone 600 can easily tell where words begin and end.

5. Hyphenated words, foreign words that use special characters such as accents,
and some punctuation cannot be converted.

6. If you add writing to a word to change it (such as changing a “3” to an “8” ) after
you attempt to recognize the word, the writing you add will not be included if you
attempt to recognize the writing again.

Drawing on the Screen

You can draw on the screen in the same way that you write on the screen. The
difference between writing and drawing on the screen is how you select items and how
they can be edited. For example, selected drawings can be resized, while writing
cannot.

Creating a Drawing

Cross three ruled lines on your first stroke. A drawing box appears. Subsequent
strokes in or touching the drawing box become part of the drawing. Drawings that
do not cross three ruled lines will be treated as writing

You may want to change the zoom level so that you can more easily work on or

view your drawing. Tap Menu, Zoom and then a zoom level.

1. The drawing box indicates the
boundaries of the drawing.

2. Tap Menu and then check Draw.

36

Selecting a Drawing

If you want to edit or format a drawing, you must select it first. Tap and hold the
stylus on the drawing until selection handle appears. To select multiple drawings,

tapping Menu and then Draw to deselect it and then drag to select the drawings

you want.

You can cut, copy, and paste selected drawings by tapping and holding the
selected drawing and then tapping an editing command on the pop-up menu, or by

tapping the command on the Menu menu. To resize a drawing, make sure the

Draw function is not selected, and drag a selection handle.

Recording a Message

In any program where you can write or draw on the screen, you can also quickly capture

thoughts, reminders, and phone numbers by recording a message. In Calendar, Tasks,
and Contacts, you can include a recording in the Notes tab. Refer to “Voice Recordings

Format” section.

In the Notes program, you can either create a stand-alone recording or include a

recording in a written note. If you want to include the recording in a note, open the note
first. In the Inbox program, you can add a recording to an e-mail message.

37

Creating a Recording

1. Hold your GPS Phone 600’s microphone near your mouth or other source of
sound.

2. Press and hold the Record hardware button on your GPS Phone 600 until you hear
a beep.

3. While holding down the Record button, make your recording.

4. To stop recording, release the Record button. Two beeps will sound. The new
recording appears in the note list or as an embedded icon.

♦ You can also make a recording by tapping the Record button on the

Recording toolbar.

♦ To play a recording, tap it in the list or tap its icon in the note.

1. Indicates an embedded recording.

2. Tap to begin recording.

3. Recording toolbar.

4. Tap Menu and then check View
Recording Toolbar.

38

Using My Text

When using Messaging or MSN Messenger, use My Text to quickly insert preset or
frequently used messages into the text entry area. To insert a message, tap My Text
and tap a message.

You can add text after inserting a My Text message before sending it. To edit a My
Text message, select Edit My Text Messages. Select the message you wish to edit

and make desired changes.

39

Chapter 4

Using the Phone

The Phone feature on the GPS Phone 600 allows you to perform the following tasks:

1. Make and receive calls

2. Quickly make calls or listen to voice mail without entering phone numbers using

Contacts, Speed Dial, or your Call Log.

3. Check the Call Log to see who has called, whom you have called, add a new
number to Contacts, and access notes taken while you were on a call.

4. Receive calls and easily take notes during the call.

5. Send SMS messages.

6. Customize how your phone rings.

To switch to the Phone function, press the button on the lower part of the GPS
Phone 600 or tap start and then Phone.

Caution

♦ To avoid distraction and affecting driving safety, never use your GPS

Phone 600 will driving an automobile or any other moving vehicle.

♦ Make sure that the SIM card is properly installed in your GPS Phone 600

and the Phone is already turned on before you use the functions
described in this section.

♦ When you are on a plane, in a medical facility or at a gas station where

wireless communications devices are not allowed and must be turned
off, please go to Wireless Manager and select the ALL OFF button to
turn off your GPS Phone 600 mobile phone, Bluetooth, and wireless LAN
functions. By pressing the “Power Button” of the GPS Phone 600, you
only turn off the display.

♦ The Phone function relies on the GPS Phone 600 main battery for

power. Maintain the main battery power level to assure call quality and
the normal operation.

40

4.1 Installing and Removing the SIM Card

1. Tap the ALL OFF button in Wireless Manager to turn off your GPS Phone

600’s mobile phone, Bluetooth, and wireless LAN functions

2. Press the “Power Button” of the GPS Phone 600 to turn off the screen.

3. Remove the back cover, unlock the main battery lock and remove the battery.

4. Insert the SIM card into the SIM card slot with the golden contacts facing down.
Use according to the picture labeled on the GPS Phone 600, or remove the SIM
card horizontally.

5. Reinstall the main battery and then lock the main battery lock.

6. Slide the back cover into the groove, and reinstall the back cover.

Installing the SIM Card and Battery

1. Insert the SIM card into the SIM
card slot with its golden contacts
facing down. Follow the picture
indicated on the GPS Phone 600.

2. Main Battery. 5. Main battery lock

3. Back cover.

4. Follow the direction in the
picture to install the main
battery.

41

4.2 Using the Phone

1. Microphone 3. Phone Speaker

2. Earphones 4. Phone Microphone (Bottom of GPS Phone 600)

Combination

Method

Hold the GPS
Phone manually
for calls.

Install the
external headset.

Operation Answer or End a Call Adjust Earphones

Hold the GPS
Phone 600 and
position the
speaker close to
your ear and the
microphone close
to your lips.
Place the
earphone in your
ear and position
the microphone to
your lips.

Press Send Button
or End Button on
the lower part of the
GPS Phone 600.

Use the line control
function. Press the
button on the headset
answer or end the call.

Volume

While answering a
call, push the volume
control key on the
side of the GPS
Phone 600 to test
the earphones
volume.
Use the knob on the
headset to adjust the
volume of the
earphones during a
call.

42

Adjusting the Phone Volume

Tap on the top and adjust all programs’ sound
functions under . Adjust the phone sound volume

under .

When there is no call, you can push the volume
control key on the side of the GPS Phone 600 or
use the stylus to tap the speaker icon. Tap and
then to adjust the ring volume of the incoming
call.

Push the volume control key on the side of the GPS
Phone 600 or tap and then to adjust the
phone volume. You can only do this during a call.

♦ Vibration mode: The speaker icon on the top changes to .
♦ Mute mode: The speaker icon on the top changes to .

Adjusting for proper volume:
If earphones are used with the GPS Phone 600 to make calls, set the volume according
to your personal needs.

1. If you are not using earphones, you can set the volume to the top two levels for
hands-free operation.

2. For holding the GPS Phone 600 close to the ear directly for calls, set the volume to
the lower four levels. It is recommended not to use the top two levels because the
volume is high and may affect your hearing.

Turn on / off the speakerphone:

1. Enable the speakerphone: While answering a call, tap Speaker on to turn on.

2. Disable the speakerphone: Tap Speaker off to turn off.

43

4.3 Turning the Phone On / Off and Making Calls

The following table shows the icons that you may see on the Navigation Bar on the top
of the screen.

Signal

Indicator

SIM card unavailable.
The phone is turned off. To turn it on, tap this icon.

Network is searching or unavailable.

Phone connection unavailable or network error. To turn it off, tap
this icon.
The phone is turned on and signal reception is normal. To turn
off, tap this icon.
Active call. To switch back from other programs, tap this icon.

Call forwarding active.
Calls are forwarded.
Missed call.
Roaming mode.

Make certain that the SIM card is properly installed
before attempting to make calls.

1. Turn on the phone: Tap the icon. When the
message window appears, tap “Turn off flight
mode,” and input the PIN and wait for the phone to
turn on. The icon changes to .

2. Dial: Press
stylus to tap the telephone number and then tap the
Enter Button.

3. Answer a call: Press

4. End a call: Press .

5. Turn off the phone: Tap the icon. When the
message window appears, tap “Turn on flight
mode.”

to enter the phone screen. Use the

.

Description

44

Phone Toolbar

1. Contacts Button: Link to Contacts.

2. Menu Button:
♦ Save to Contacts: Save the dialed phone number

to Contacts.

♦ Create Note: While making a call, you can enter

Notes to use the panel as the memo pad for writing

down notes, pictures or recording.

♦ Options: Change the phone setup such as ring

tone, vibration mode, PIN cod, etc.

3. Keypad Button: Tap to return to the keypad.

4. Speaker on Button: While answering a call, tap to
enable the speakerphone.

Calling from Contacts

Phone numbers entered in Contacts can be used to quickly locate phone numbers and
make calls.

1. In the contact list, tap and hold the contact to

display a pop-menu.

2. Tap Call Mobile or Call Work on the pop-up menu.

3. Tap a contact to display the details.

45

Calling from Speed Dial

On the Phone screen, tap Speed Dial Button to enter the following screen.

1. Tap and hold on a contact. The pop-up menu provides the

Delete and Edit options for phone setup.

2. Tap to redial this number. Remember that this code (for
example, “2”) you want to dial can also be dialed from the
number area in the Phone screen by tapping on “2”.

3. Tap Menu and the New to show the Contacts name and

number will add it to the Speed Dial list. A maximum of 99
numbers are allowed.

Calling from the Call History

Tap Call History Button on the phone screen to enter the following screen.

1. Tap Menu and then Filter to list the categories. To
search, tap By Caller and follow the screen

instructions to complete the operation.

2. Tap this icon to redial this number immediately.

3. Tap and hold the phone number area and tap the
option you need on the pop-up menu. For example,

tap Call to redial this number, tap Save to Contacts

to add this number to the Phonebook.

4. Tap Menu and then Delete All Calls to delete all call
records. Or tap Call Timers to view the number of

calls, call time and manage call records as shown in
the figure on the left.

46

4.4 Customizing Your Phone

Tap Menu, Options, and then the Phone, Services, Network, or Others tabs to modify

the relevant service setup. Note that the setup values you can change here depend on the

services provided by your telephone company.

♦ Tap the Others tab.

1. GPRS Setting: You can set the

option for GPRS connection.

2. Broadcast Channels: If your telephone

company provides this service, you can
activate it.

3. Band: You can set the band for different

regions.

♦ Tap Menu Options, and then the Phone tab.

1. You can set the ring type as ring, vibration or
mute.

2. If you want to use a customized ring tone file,
use the ActiveSync program, on your desktop
computer to copy the .wav, .mid, or .mp3 ring
tone file to the /Windows/Rings folder on the
GPS Phone 600. You can then select this ring
tone from the Ring tone list.

3. Set the key sound for dialing.

4. You can set a PIN (Personal Identity Number)
to block unauthorized access to your phone.
Your first PIN is provided by your phone
service provider.

47

4.5 Phone Application Programs

Caution

Before you can use the functions described in the Phone Group. Make sure that
the SIM card is properly installed in your GPS Phone 600 and the Phone is
turned on.

SIM Tool Kit

Tap Start, Programs, Phone, and then SIM Tool Kit.

This screen is for reference only. The actual screen is
based on the service items provided by your telecom
company.

1. Tap any service item.

2. Select Button: Launch service item. Follow the

screen or voice instructions.

SMS Sender

Tap Start, Programs, Phone, and the SMS Sender.

Tap

Start, Messaging and then New.

Enter the composing SMS screen in Messaging.

1. “Text Messages” means you are editing SMS.

2. Input the mobile phone number.

3. Input the messages you want to send.

4. Tap Menu and then My Text to select canned

messages or to edit your Text Messages.

5. Tap to send SMS message.

48

Chapter 5

Customize Your GPS Phone 600

You can adjust the GPS Phone 600 settings according to your personal preferences
and install other programs.

5.1 Adjusting Settings

To see available options, tap Start, Settings, then the Personal or System tab
located at the bottom of the screen. The following utilities allow you to adjust the
settings based on your personal work style.

♦ Clock & Alarms
To change the time or to set alarms.

♦ Menus
To customize what appears on the

from the New button.

♦ Owner Information
To enter your contact information.

♦ Lock

To limit access to your GPS Phone 600.

♦ Power

To maximize battery life.

♦ Today
To customize the look and the information that is displayed on the Today

screen.

Start menu, and to enable a pop up menu

49

5.2 Notifications

Your GPS Phone 600 reminds you in a variety of ways when you have something to

do. For example, if you’ve set up an appointment in Calendar, a task with a due date in
Tasks, or an alarm in Clock & Alarms, you’ll be notified in any of the following ways:

♦ A Message box appears on the screen.

♦ A sound, which you can specify, is played.

♦ A light flashes on your GPS Phone 600.

♦ The GPS Phone 600 vibrates.

To choose reminder types and sounds for your GPS Phone 600, tap Start and
then Settings. In the Personal tab, tap Sounds & Notifications. The options you choose

here apply throughout the GPS Phone 600.

50

5.3 Power Preference Settings

Tap Start, Settings, the System tab, and then Power.

View the power usage condition or perform the relevant power management settings.

1. Key Lock

With Key Lock checked, when you
accidentally press the hardware buttons
on the GPS Phone 600, the GPS Phone
600 will not exit the sleep mode. This will
prevent unnecessary power

consumption if a button is accidentally

pressed.

2. Battery Icon

Checking this item displays the power
icon on the upper right side of the
screen.

3. Advanced tab

Set the GPS Phone 600 to turn off
automatically after a period of
inactivity.

51

5.4 Backlight

Tap Start, Settings, the System tab, and then Backlight.

1. Battery Power or External Power tab: Set

the relevant backlight functions.

2. Backlight Level tab: Adjust the backlight

level.

52

5.5 Microphone

Voice Commander

voice c o ntrol volume setting for better recognition of system.
Speech recording Turn the volume up.

Tap Start, Settings, the System tab, and then Microphone.

Profile Microphone

Turn the volume down and find the proper

1. Use the slider to adjust volume of the recording
microphone.

2. Default Button: Restore to default system

settings.

53

5.6 Adjusting the Volume

Push the volume control key on the side of the GPS Phone 600 or use the stylus to tap
the icon on the top of the screen to adjust all program sound functions under .
Adjust the phone volume under .

1. Adjust volume: When set to  On, use the stylus

to tap and drag the slider up and down to adjust the

volume. You can also push + or -- on the side of

the GPS Phone 600.

2. Vibrate: Under  Vibrate mode, the sound

function of all programs will be replaced by
vibration, including incoming call rings. The icon
on the top changes to .

3. Mute: Under  Off mode, the sound function of all

programs will be turned off, including incoming call
rings. The icon on the top changes to .

54

5.7 Finding and Organizing Information

The Search feature on your GPS Phone 600 helps you quickly locate information.

You can also use the File Explorer to search for files and place these files into folders

systematically. Just tap Start, Programs, and then File Explorer.

 You can move files in File Explorer by tapping and holding the items you want to

move, and then tapping Cut, Copy, or Paste on the pop-up menu.

1. Tap Start, Programs, and then Search.

Input

the text you want to find and then select the

data type. Tap on Search to start the search.

2. To find information that occupies a larger

space, select Larger than 64 KB for Type.

1. Tap to change folders.

2. Select the sort order for the list.

3. Tap the folder name to open folder.

4. Tap Menu and then New Folder to
create a new folder.

55

5.8 Navigation Bar and Command Bar

The navigation bar is located at the top of the screen. It displays the active program and
current time, and allows you to switch to programs and close screens.

Use the command bar at the bottom of the screen to perform tasks in programs. The
command bar includes menu names, buttons, and the Input Panel button. To create a

new item in the current program, tap New. To see the name of a button, tap and hold the

stylus on the button. Drag the stylus off the button so that the command is not carried
out.

1. Tap to change volume or mute the GPS

Phone 600.

2. Tap to select a program.

3. Tap to quickly select a program you have
recently used.

4. Tap to see additional programs.

5. Tap to customize the GPS Phone 600.

6. Menu button.

7. Input panel button.

8. New button

56

5.9 Pop-up Menus

With pop-up menus, you can quickly choose an action for an item. For example, you
can use the pop-up menu in the contact list to quickly delete a contact, make a copy of a
contact, or send an e-mail message to a contact. The actions in the pop-up menus vary
from program to program. To access a pop-up menu, tap and hold the stylus on the item
name that you want to perform the action on. When the menu appears, lift the stylus, and
tap the action you want to perform. Or tap anywhere outside the menu to close the menu
without performing an action.

1. Tap and hold to display the pop-

up menu.

2. Lift the stylus and tap the action

you want.

3. Tap outside the menu to close it

without performing an action.

57

5.10 Redefine Hot Keys

Tap Start, Settings, the Personal tab, and then Buttons.

These hot keys can be redefined as launch
keys for frequently used programs.

 End Button

exclusive phone functions so they cannot
be redefined.

and Send Button are

58

Chapter 6

Using Microsoft ActiveSync

Using Microsoft® ActiveSync®, you can synchronize the information on your desktop
computer with the information on your GPS Phone 600. Synchronization compares the
data on your GPS Phone 600 with your desktop computer and updates both computers
with the most recent information. For example:

♦ Keep Pocket Outlook data up-to- date by synchronizing your GPS Phone 600

with Microsoft Outlook data on your desktop computer.

♦ Synchronize Microsoft Word and Microsoft Excel files between your GPS Phone

600 and desktop computer. Your files are automatically converted to the correct
format.

By default, ActiveSync does not automatically synchronize all types of information. Use
ActiveSync options to turn synchronization on and off for specific information types.

With ActiveSync, you can also:

♦ Back up and restore your GPS Phone 600.

♦ Copy (rather synchronize) files between your device and your desktop computer.

♦ Control when synchronization occurs by selecting a synchronization mode. For

example, you can synchronize continually while connected to your desktop
computer or only when you choose the synchronize command.

♦ Select which information types are synchronized and control how much data is

synchronized. For example, you can choose how many weeks of past
appointments you want synchronized.

59

6.1 Installing and Using ActiveSync

Important Installation Notice

Before you install ActiveSync, make sure that the USB cable on the GPS Phone
600 is not connected to the personal computer. Connect the USB cable only
after ActiveSync is installed.

1. Installing ActiveSync: You could use the Getting Started CD to install Microsoft
ActiveSync version 4.1 or above on the personal computer. ActiveSync is already
installed on your GPS Phone 600.

2. Hardware installation: The USB cable is a plug-and-play device. Use the USB
cable to connect your GPS Phone 600 to your personal computer.

60

3. Using ActiveSync

♦ After installation is complete, the ActiveSync Setup Wizard

helps you customize your synchronization settings.

♦ Once you use the USB cable to connect the two devices properly,

the Set Up a Partnership screen appears on the personal
computer. Set it up according to your requirements. The green

icon appears on the status bar of your personal computer to
indicate that it is connected.

♦ Click Explore on the Microsoft ActiveSync window on the personal

computer to access files in the GPS Phone 600. You can then use
Windows Explorer to manage the files on your GPS Phone 600.

 Windows 95 and Windows NT do not support USB connections.

ActiveSync Connection Troubleshooting

Tap Start, Settings, the Connections tab, and then USB to PC.

1. Factory setting defaults to checking the box.

2. If you have followed the above installation and

operation procedures and find that the connection

between your GPS Phone 600 and desktop PC still

cannot be established, uncheck the box shown on

the left.

61

6.2 USB Synchronization

Before you start to synchronize, use the GPS Phone 600 Getting Started CD to
install ActiveSync on your personal computer. For more information on how to
install ActiveSync, please refer to the ActiveSync CD or online help. ActiveSync is

already installed on your GPS Phone 600.

USB Synchronization

1. After installation is complete, the Setup Wizard will continue to guide you. Adjust
the options according to your actual needs.

2. Use the USB cable to connect the two devices properly and the Set Up a

Partnership screen appears on the personal computer. Set it up according to

your requirements.

1. If this message appears, you
may want to disconnect your
GPS Phone 600 and install
Outlook on your PC before
continuing. In any event,

click OK to close the

message box.

2. Click Next.

3. Check the items you want to
synchronize.

4. Click Next.

62

5. Click Finish.

After installation is complete, the ActiveSync Setup Wizard helps you connect
your GPS Phone 600 to your desktop computer, set up a partnership so you can
synchronize information between your GPS Phone 600 and your desktop
computer, and customize your synchronization settings. Your first synchronization
process will automatically begin when you finish using the wizard.

The green icon appears on the status bar of the personal computer to indicate
that it is connected.

After your first synchronization, take a look at Calendar, Contacts, and Tasks on
your GPS Phone 600. You’ll notice that information you’ve stored in Microsoft Outlook
on your desktop computer has been copied to your device, and you didn’t have to type
a word. Disconnect your GPS Phone 600 from your computer and you’re ready to go!

63

Once you have set up ActiveSync and completed the first synchronization process, you
can initiate synchronization from your GPS Phone 600. To switch to ActiveSync on your

GPS Phone 600, tap Start and then tap ActiveSync.
For more information on how to use ActiveSync on your personal computer, run

ActiveSync and refer to the ActiveSync online help. To learn more about the GPS Phone
600 ActiveSync, switch to ActiveSync and tap Start and then Help. Just refer to the
Help for more information.

After the synchronization is complete, tap Calendar, Contacts, and Tasks on the

GPS Phone 600 to view if the information saved in Microsoft Outlook on the
personal computer is already copied to the GPS Phone 600.

On the GPS Phone 600:

Tap Start, Programs and then
ActiveSync.

1. View synchronization status.

2. View connection status.

3. Tap to connect and synchronize.

4. Tap to synchronize via Bluetooth or
change synchronization settings.

64

6.3 Synchronizing Using Bluetooth

Without using the USB cable to connect the two devices, you can still synchronize using
Bluetooth. The greatest advantage is that you don’t have to plug in and detach from the
USB cable so often. This is especially useful for managing several GPS Phone 600s.
For details on Bluetooth devices, refer to “Using Bluetooth” section.

65

Chapter 7

Connections

7.1 Connecting to the Internet

This section teaches you how to use GPRS wireless network connection. GPRS
wireless networking is a convenient function for working at home or while traveling. You
can use the GPS Phone 600 to browse websites and read or send E-mails, SMS or
MSN messages.

Make sure that your telecom company provides this service and apply for a SIM with
GPRS function. If you already have a SIM card, all you need to do is apply for the
GPRS function from your service provider. Current SIM cards can support GPRS
networking functions.

Generally, you will only need to install the SIM card to your GPS Phone 600 to use the
mobile phone function. The system will automatically add the connection items for this
SIM card. To verify, Tap Start, Settings, the Connections tab, Connections, and then
“Manage existing connections,” the list will show the newly added network name.

If the system is unable to successfully add the connection to your SIM card, use the
Connection Wizard as shown next.

66

Setting the GPRS / EDGE Connection

Tap Start, Settings, the Connections tab, Connections, and then the Tasks tab.

1. As shown in the screen on the left tap “Add a new
modem connection.”

2. Enter the “Make New Connection” screen as shown
in the screen on the left.

♦ Input a new connection name for

convenience in making connections in the
future.

♦ Select “Cellular Line (GPRS)”.

♦ Lastly tap Next.

3. Input the Access Point Name provided by your
telecom company (this may appear as APN in the

information provided by your carrier) and tap Next.

4. Input your personal information such as account

number, and tap Finish.

67

Starting the GPRS / EDGE Connection

1. Tap the or icon at the top of the
screen and when a message window
appears tap “Turn off flight mode” and input
your PIN to turn on the Phone. The icon

will change to while the icon changes

to .

2. Tap , then tap Settings to link to
Connections. You are ready to connect

GPRS / EDGE.

3. Select “Message existing connections” in

Connections. Tap and hold on the newly

created connection name, and then select

Connect to finish GPRS / EDGE

connection.

4. Input your account information in the Logon
Network screen and tap to login to the
Network.

5. After the connection is established, the

icon will change to .

6. Now you can use the appropriate program
to access the Internet, receive or send

E-mails, etc.

68

Disconnecting GPRS / EDGE

1. Disconnect GPRS / EDGE

♦ Tap

appear.

♦ Tap Disconnect.

2. Turn off Phone
♦ Tap and the message window

appear.

♦ Tap “Turn on flight mode.”

and the message window

69

7.2 Using Bluetooth

Bluetooth is a short-distance wireless communication technology with an effective range
under 10 meters (30 feet). When you enable Bluetooth function, the blue LED blinks
once every 4 seconds.

1. Tap Wireless

Manager.

2. Tap to enable

Bluetooth LED

indicator (Blue)

Bluetooth.

Bluetooth Connection Wizard

Tap Start, Programs, Utilities, and then Bluetooth Manager.

1. Tap on any one of the icons on the left
side of the Wizard screen, the system will
ask you if you would like to activate
Bluetooth. After activation, the LED
indicator on the upper left will flash blue.

2. Tap here and the system will search for all
nearby Bluetooth headsets.

3. Tap to configure your Bluetooth device.

4. Tap to enter the Bluetooth device pairing

screen.

70

All nearby Bluetooth devices found by the
system.

1. Tap on any one the shortcut icons and
you will be able to follow the on-screen
instructions to pair with that particular
device. Devices that have already been
paired with are shown with a 5.

2. Tap on one of the icons which represent
a Bluetooth headset, when a 5 is
shown, it means that you may use that
particular Bluetooth headset.

3. Refresh Search Button: re-scan for all

nearby Bluetooth devices.

4. Change viewing method.

Tap Bluetooth Manger Button in the

Wizard Mode screen to enter this screen.

1. The system will search once again and
add to the number of the devices that
you may pair with.

2. Return to Bluetooth Wizard.

3. Tap to configure your Bluetooth

device.

71

Bluetooth Connection Setting

Tap Settings Button in the Bluetooth Wizard screen to display the Bluetooth Settings
screen.

Tap the General tab.

1. Bluetooth Status

♦ Tap Open to enable Bluetooth function.

♦ Tap Close to disable Bluetooth function.

 Make sure that you disable Bluetooth function

when you need to save power or if you are in
locations such as an airplane or hospital that
ban the use of wireless devices.

2. Device Identification

♦ Name
Other devices supporting Bluetooth can identify your GPS Phone 600 by

this name.

♦ Address
This is the unique address of your GPS Phone 600.

3. Access

♦ Check “Discoverable”

Within an effective range of 10 meters (30 feet), all devices supporting
Bluetooth can detect your GPS Phone 600 and data transmission is
performed with confirmation from the other party.

♦ Uncheck “Discoverable”

Your GPS Phone 600 can transmit data to other devices but other
devices cannot detect your GPS phone 600.

72

Service

Tap the Service tab.

Provide the settings about
services of serial port, file
transport and exchange vCard

73

Serial Port

If you have other Bluetooth software or hardware that uses a serial port, use the product
as instructed and refer to the accompanied documentation and this section to register
your GPS Phone 600 as a serial port or search for other serial ports.

Tap the Serial Port tab.

1. Tap Add to enter the Settings screen.

 If you no longer need to use a registered

serial port, tap this serial port under the
“Name” column to highlight and then tap
Delete to delete it.

2. The figure on the left shows the settings screen
for registering a new serial port.

♦ If you select COM for the “Name” field then

the valid options for the “Index” field are 0,
2, 4, 6, and 7.

♦ If you select BTS for the “Name” field, then

the valid options for the “Index” field are 0
to 9.

74

Bluetooth Headset

Tap the Bluetooth Headset tab.

1. Select a headset from the period list.

2. Check “Use Headset.”

FTP Sharing

Tap the FTP tab.

Specify one of the folders on your GPS
Phone 600 as a shared directory.

75

7.3 CSD Type

Tap Start, Settings, the Connections tab, and then CSD Type.

You must first apply for Circuit-Switched Data (CSD) service from your telecom
company before you can use this function. In short, this function is similar to the modem
dial-up in a personal computer. By simulating the GPS Phone 600 as a modem and
connecting through the built-in GSM device, you can use the GPS Phone 600 to access
the web.

 This figure is for reference only.

The parameters shown in the screen will be
based on the settings provided by your
telecom company. The charge rate is
regulated by your telecom company.

76

7.4 Connecting with a Personal Computer

For more information, refer to “Microsoft ActiveSync” section.

7.5 Wireless LAN Transmission

Tap the Wireless Manger icon on the lower right corner of the Today screen. For

more information, refer to “Using Wireless LAN” section.

Wireless LAN LED
indicator (Orange)

Tap

Wireless Manager

77

Chapter 8

Using Wireless LAN

8.1 Connecting to Wireless LAN

This section teaches you how to use the GPS Phone 600’s built-in wireless LAN
function to connect to the Internet. It is convenient for you to browse websites and send
/ receive E-mails through wireless networks at certain locations where wireless
networking services are provided.

When you purchase credits for connecting to the Internet through a wireless LAN, you
may be given some or all of the following information: an IP address, DNS name server
address, Proxy server, port, and network key, etc. You need this information to setup
and activate your connection. In some cases, you may need additional information to
use a company’s wireless connection, please confirm with the network administrator in
your company.

If this is your first time using the wireless LAN function, firstly you should refer to the
following “Configure Your Wireless Network” section for instructions for the necessary
configuration settings. After you have completed the one-time configuration process,

you only need to select the icon in the Wireless Manager main menu for

subsequent connections.

78

Select the icon on the bottom right of the Today screen or Tap Start, Programs
and then Wireless Manager.

1. This icon will show up on your screen whenever your
GPS Phone 600 has detected a usable wireless network
and has connected to that network, indicating that your
GPS Phone 600 has successfully connected to the
network hotspot (Access Point). At this point, the
indicator on the upper left of your GPS Phone 600 will
flash orange.

2. Tap to enter the setup screen.

3. Tap to connect or disconnect to your wireless network, a
means that this function has been disabled.

.

When the screen shown on the left appears, please choose

a wireless network that you can use, and then tap OK
button. Then, select Work, and tap Connect button.

The first time you use the wireless LAN function, your
system will ask you to set the above mentioned settings,
after that, your system will continue to use the settings from
your most recent successful connection

79

8.2 Configure Your Wireless Network

(Reference for a normal network setup)

You will need a correct IP address, DNS name server address, Proxy server, and
connection port number to setup your connection. If you have purchased a wireless
Internet service account, then the service desk at the location where you will be
connecting will provide you with this information, or, you should obtain this information
from the network administrator of your company.

When your GPS Phone 600 is unable to
automatically detect or connect to a usable
wireless network, please try to configure the
network manually. Please refer to this section’s
settings instructions.

1. Select the icon in the Wireless Manager

main menu, an icon will display on the
navigation bar.



2. Then Tap

Connections tab, Connections, and then
the Advanced tab, the screen displays shown

on the left.

3. Select the Select Networks Button.

4. As shown on the left, make sure that My Work
Network is selected for both items, and finally

tap

 My Work Network is the WLAN connection

method. The next time you need to use the
GPRS connection, you will have to refer to the
above listed steps, select My ISP for the first
item.

to save and exit.

Start, Settings, the

80

5. Tap Start, Programs, Utilities, and then
WLAN Utility or in the Wireless Manager
main menu, select to enter the WLAN
Utility screen.

6. Then select the Configure Button to enter

the WLAN setup screen.

7. Select name of a currently available network
to enter the WLAN authorization setup screen.

8. Set according to the rules and information
provided by the hotspot location.

a. Authentication: Select Open
b. Data Encryption: Select WEP to enable

the entry bar about Network key

c. Network key
d. Network key index

9. Tap and hold on the name of the network
connection that you can currently use, and then

select Connect. When the

icon appears on
the top of the screen, your wireless network
has been successfully connected.

81

8.3 Configure Your Wireless Network

(Reference for Proxy setup)

To successfully configure your network, you will need the following information: a
correct IP address, DNS name server address, Proxy server, and connection port
number, etc. Please obtain the above listed information from your company’s network
administrator. If your company’s networking environment doesn’t need Proxy server
settings, please close the proxy connection.

Tap Start, Settings, the Connections tab, Connections, and then the Tasks tab.

If your GPS Phone 600 fails to automatically detect or
connect to a usable wireless network, please try using the
manual method to configure your network settings. Refer
to the settings information in this section.

1. Select “Setup my proxy server” or” Edit my proxy
server,” as shown on the left.

2. In the Proxy Settings tab screen, make sure that the

following items have been checked:

a. This network connects to the Internet

b. This network uses a proxy server to connect to the

Internet

 The above is applicable to an office environment that requires a Proxy setup.

For networks that do not use a proxy server, skip the following procedures.

3. Enter the name into the “Proxy server” field.

4. Select the Advanced button and enter the advanced settings screen.

82

5. You can modify the settings by tapping the HTTP
type.

6. Enter the number into the “Port” field. Finally, tap

to save and exit.

83

Chapter 9

Sending and Receiving Messages

9.1 E-mails and SMS Messages

Refer to “Connecting to the Internet” section to learn how to connect the GPS Phone

600 to the Internet and start using Messaging to send and receive E-mails and SMS

messages.

This section explains the basics. For additional information, see the online help.

Use Messaging to send and receive E-mails messages in either of these ways:

1. Send and receive e-mail messages by connecting directly to an e-mail server
through an Internet service provider (ISP) or a network.

2. Synchronize e-mail messages with Microsoft Exchange or Microsoft Outlook on

your desktop computer.

 Inbox synchronization does not support synchronization with Microsoft Outlook

Express.

Reference for using E-mail:

1. Refer to “E-mail Server Setup” section.

2. Refer to “Using E-mails and SMS”.

Reference for using SMS:

1. Refer to “Using E-mails and SMS” section.

2. To send and receive SMS only, you only need to turn on the Phone (antenna icon
on the Navigation Bar is
nor is it necessary to establish a new E-mail account and connection in

Messaging.

). It is not necessary to connect GPRS to the network

84

Synchronizing E-mail Messages

If you want to synchronize e-mails with company or home usage, please refer to this
section. E-mail messages can be synchronized as part of the general synchronization
process. You will need to enable Inbox synchronization in ActiveSync. For information
on enabling Inbox synchronization, see ActiveSync Help on the desktop computer.

During synchronization:

1. Refer to “Connecting to the Internet” section. Select the partnership you want to
establish under “Set up a Partnership” and you can start to synchronize data. If
you choose not to synchronize data, you can manually copy or move E-mails
between the GPS Phone 600 and a personal computer.

2. E-mail messages in the “Outbox” folder on your GPS Phone 600 are transferred
to Exchange or Outlook, and then sent from those programs.

3. Exchange or Outlook E-mail is supported.

4. Messages in the GPS Phone 600 Inbox folder will be transmitted to the personal
computer.

5. If you delete mail in the GPS Phone 600, this mail will also be deleted from the
personal computer the next time the two devices perform synchronization.

6. SMS messages are not synchronized.

85

Connecting Directly to the Mail Server

For single-machine use, not combining office and home E-mails, please refer to “E-mail
Server Setup” section.

You will receive messages directly from the mail server without using a PC. You can
work online or offline. When working online, you read and respond to messages while
connected to the e-mail server. Messages are sent as soon as you tap Send, which
saves space on your GPS Phone 600.

When working offline, once you’ve downloaded new message headers or partial
messages, you can disconnect from the e-mail server and then decide which messages
to download completely. The next time you connect, Inbox downloads the complete
messages you’ve marked for retrieval and sends the messages you’ve composed.

Based on your preference, you can program the GPS Phone 600 to receive mail for the
last few days, receive subjects only or the entire mail, or just receive mail with file
attachments smaller than a specified size. If you want to receive more or less mail, tap

Menu, Tools and then Options to adjust the E-mail account settings according to your

needs.

86

E-mail Server Setup

Refer to this section if you are preparing for single-machine use and not combining
office and home E-mails. If you already have an E-mail account from your ISP or

company network, you can use Messaging to send and receive mails and messages.
To establish a new Messaging E-mail server on your GPS Phone 600, refer to the

following sections.

1. Obtain the following information from your ISP or company’s network administrator
for convenience in setting up the E-mail service.

♦ E-mail address, account name and password.
♦ POP3 or IMAP4 server name for internal mail.
♦ SMTP server name for sending mail.

For AT&T / Cingular, use cwmx.com as the outgoing mail server.

2. E-mail Setup

♦ Tap Start, Messaging, Menu, Tools, and

then New Account to display the screen on the

left.

♦ Follow the screen instructions to set up the

E-mail service.

3. Refer to “Connecting to the Internet” section to
connect the GPS Phone 600 to the Internet and you
can start sending and receiving E-mails and SMS
messages.

4. Connecting to the E-mail server

♦ Tap Messaging, Menu, Switch Accounts, and

then check POP3.

♦ Tap Menu and then Send / Receive.

 Tap Menu, Tools and then Options to change the E-mail setup.

87

Using E-mails and SMS

Below is a brief description of the Messaging screen functions:

1. Select the service and folder you want to
display.

2. Select the sort order for messages.

3. Tap to open a message.

4. Tap and hold to display a pop-up menu of
actions.

5. Status bar.

6. Tap to change the account settings.

7. Tap to compose a message.

88

Brief description on writing, sending, reading and replying (to) mail:

1. Send and Receive Mail:

Tap New to compose a message and then tap Send to send it.



2. Tap To, Cc or Bcc to open the Contacts screen. As long as you have set up
Contacts beforehand, you can just tap to select.

3. Tap the data area to input the E-mail address, mobile phone number and subject
directly. If there is more than one contact, use a semi-colon (;) to separate the
addresses.

4. POP3 means to send E-mail, and Text Messages means to send an SMS

message. Note that the same message cannot be sent as E-mail and SMS
message at the same time.

5. Use the scroll bar to view the header.

6. Menu Button: Provides frequently-used functions for writing mail such as request

return receipt, attach files to E-mail, select canned messages, edit canned

messages or cancel mail.

7. Send Button: Send your messages.

89

8. Read and Reply:

Receive new mails by tapping Menu and then Send/Receive. Switch to the “Inbox”

folder and tap to open. The following figure shows the open mail screen.

The menu provides additional functions for
replying to or forwarding message.

9. Change preference settings.

♦ Set the Inbox Synchronization option under ActiveSync.

♦ Tap Messaging, Menu, Tools, Options, and then the Accounts,

Message ... tabs on the GPS Phone 600 to set the appropriate options.

90

Direct Push Technology Alert

The Direct Push Technology alert function will enable you as a corporate user to never
miss another e-mail. Through the ActiveSync feature, your GPS Phone 600 can
instantly and automatically receive important e-mails from Microsoft Exchange Server.

Direct Push Technology Alert Settings

The following description will explain how to setup the ActiveSync program on the GPS

Phone 600 end, and to directly synchronize the GPS Phone 600 with Exchange Server.
This way, your device under GPRS or wireless network connections will be able to
receive in-coming e-mail alerts, and be able to instantly read the messages.

A reminder that if you selected the connection method to be wireless network, for power
saving purposes when the GPS Phone 600 enters sleep mode the connection will be
broken. During this time you will not be able to receive instant e-mail. However, you will
only need to press the “Power Button” to automatically complete the connection to the
wireless network.

Tap

Configure Sever.

1. If the Exchange Server synchronization has not been

Start, Programs, ActiveSync, Menu, and then

setup before, please select Add Server Source.

1) Tap to connect and synchronize.

2) Tap to modify the synchronization settings.

91

2. Obtain the server address, user name, network
etc. from the company network administrator to
successfully setup the server data

3. Tap Menu and then Schedule. The Peak times
and Off-peak times provide an As items arrive

option, this is the direct push technology alert
function.

92

9.2 MSN Messenger

On the Today screen, tap to display the MSN Messenger sign-in screen.

Tap Start, Programs, Pocket MSN, and then MSN Messenger.
To switch to MSN Messenger, tap Start, Programs, and then tap Pocket MSN.

MSN Messenger on your GPS Phone 600 is an instant messaging program that lets
you:

♦ See who is online.
♦ Send and receive instant messages.
♦ Have instant message conversations with groups of contacts.

For more information on using MSN Messenger, tap Start and then Help.

To use MSN Messenger, you must have a Microsoft Passport™ account or a
Microsoft Exchange e-mail account. You must have a Passport to use MSN
Messenger Service. If you have a Hotmail® or MSN account, you already have a
Passport. Once you have obtained either a Microsoft Passport or a Microsoft Exchange
account, you are ready to set up your account.

 Sign up for a Microsoft Passport account at http://www.passport.com. Get a free

Microsoft Hotmail e-mail address at http://www.hotmail.com.

93

Setting Up

Before you can connect, you must enter Passport or Exchange account information.

To sign in, enter your e-mail address and password.



 If you already use MSN Messenger on your desktop computer, your contacts will

show up on your GPS Phone 600 without being added again.

94

Working with Contacts

The MSN Messenger window shows all of your messenger contacts at a glance, divided
into Online and Not Online categories. From this view, while connected, you can chat,
send an e-mail, block the contact from chatting with you, or delete contacts from your
list using the pop-up menu.

1. Tap a contact to start a chat.

2. Tap and hold to display a pop-up menu of
actions

 To see others online wit hout being seen, tap Menu, My Status, and then select

Appear Offline.

If you block a contact, you will appear offline but will remain on the blocked contact’s

list. To unblock a contact, tap and hold the contact, then tap Unblock on the pop-up

menu.

95

Chatting with Contacts

1. View full chat.

2. Enter message.

3. Tap to send message.

4. View status of the chat. To know if the contact
you are chatting with is responding, look for the
message under the text entry area.

Tap a contact name to open a chat window. Enter your message in the text entry area,

and tap Send. Or tap Menu and then My Text to select a preset message. To invite
another contact to a multi-user chat, tap Menu and then Invite and tap the contact you

want to invite.

To switch back to the main window without closing a chat, tap Menu and then My
Contacts. To revert back to your chat window, tap Menu and then Chats and select the

person whom you were chatting with.

96

Chapter 10

Multimedia

10.1 Using Camera

Tap Start, Programs, Multimedia, and then Camera.

♦ To take photos of scenery or of other people, turn the GPS Phone 600 so the
screen is facing you and when you are satisfied with the composition, press

the button on the side of the GPS Phone 600.

♦ To take a picture of yourself, turn the GPS Phone 600 around so that the
preview mirror is facing you.

♦ Tap Start and then Messaging to send the picture as an attachment in an

E-mail.

1. Shutter

2. Lens

3. Preview Mirror

4. Zoom In / Out

To take a self-portrait, it is best to face into the light. For best photo
results, avoid backlit or dark areas.

Shooting Tips

97
