Phanteks PH-P750G Service Manual

EFFICIENCY AND NOISE

LEVEL CERTIFICATIONS

Anex

Phanteks PH-P750G (Sample #2)

Lab ID#: PH19750145

Report: 20PS1596A

Receipt Date: Aug 26, 2019

Test Date: Feb 11, 2020

Report Date:

Feb 14, 2020

DUT INFORMATION

DUT SPECIFICATIONS

Brand

Rated Voltage (Vrms)

Phanteks

100-240

Manufacturer (OEM)

Rated Current (Arms)

Seasonic

10-5

Series

Rated Frequency (Hz)

AMP

50-60

Model Number

Rated Power (W)

PH-P750G (Sample #2)

750

Serial Number

Type

R1906AA252140121

ATX12V

DUT Notes

Cooling

120mm Fluid Dynamic Bearing Fan

(HA1225H12F-Z)

Semi-Passive Operation

(selectable)

Cable Design

Fully Modular

POWER SPECIFICATIONS

Rail

3.3V

5V

12V

5VSB

-12V

20

20

62

3

0.3

Max. Power

Amps

Watts

100

744

15

3.6

Total Max. Power (W)

750

CABLES AND CONNECTORS

Modular Cables

Description	Cable Count	Connector Count (Total)	Gauge	In Cable Capacitors
ATX connector 20+4 pin (610mm)		1	18-22AWG	Yes
	1
4+4 pin EPS12V (650mm)		2	18AWG	No
	2
6+2 pin PCIe (680mm+80mm)		4	18AWG	No
	2
SATA (420mm+150mm+150mm+150mm)		8	18AWG	No
	2
SATA (300mm+150mm)		2	18AWG	No
	1
4 pin Molex (450mm+120mm+120mm)		3	18AWG	No
	1
4 pin Molex to SATA 3.3V Adapter (150mm+150mm)		2	18AWG	No
	1
AC Power Cord (1370mm) - C13 coupler		1	18AWG	-
	1

All data and graphs included in this test report can be used by any individual on the following conditions:

› It should be mentioned that the test results are provided by Cybenetics PAGE1/15 › The link to the original test results document should be provided in any case

Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient	www.cybenetics.com [e-mail]
and silent power supplies are promoted	4004 MESA GEITONIA, LIMASSOL, CYPRUS

EFFICIENCY AND NOISE

LEVEL CERTIFICATIONS

	Anex		Phanteks PH-P750G (Sample #2)
	General Data
	Manufacturer (OEM)
			Seasonic
	PCB Type
			Double Sided
	Primary Side
	Transient Filter
			4x Y caps, 2x X caps, 2x CM chokes, 1x MOV, 1x Discharge IC
	Inrush Protection
			NTC Thermistor & Relay
	Bridge Rectifier(s)
			2x GBU1508 (800V, 15A @ 100°C)
	APFC MOSFETS
			2x Infineon IPA50R190CE (550V, 15.7A @ 100°C, 0.19Ohm)
	APFC Boost Diode
			1x STMicroelectronics STTH8S06 (600V, 8A)
	Hold-up Cap(s)
			1x Rubycon (400V, 560uF, 2,000h @ 105°C, MXH)
	Main Switchers
			4x Champion GPT10N50AD (500V, 9.7A, 0.7Ohm)
	APFC Controller
			Champion CM6500UNX
	Resonant Controllers
			Champion CM6901T6
	Topology		Primary side: Full-Bridge & LLC converter
			Secondary side: Synchronous Rectification & DC-DC converters
	Secondary Side
	+12V MOSFETS		4x Nexperia PSMN2R6-40YS (40V, 100A @ 100°C, 5.3mOhm @ 175°C)
	5V & 3.3V
			DC-DC Converters
			Electrolytics: 6x Nippon Chemi-Con (4-10,000h @ 105°C, KY), 3x Nippon Chemi-Con (1-5,000h @ 105°C, KZE), 2x Nichicon (2-
	Filtering Capacitors		5,000h @ 105°C, HD), 3x Nichicon (4-10,000h @ 105°C, HE)
			Polymers: 9x FPCAP, 2x NIC, 6x United Chemi-Con
	Supervisor IC
			Weltrend WT7527V (OCP, OVP, UVP, SCP, PG)
	Fan Model
			Hong Hua HA1225H12F-Z (120mm, 12V, 0.58A, Fluid Dynamic Bearing Fan)
	5VSB Circuit
	Rectifier
			1xPFC P10V45SP SBR (45V, 10A)
	Standby PWM Controller
			Excelliance MOS EM8569

All data and graphs included in this test report can be used by any individual on the following conditions:

› It should be mentioned that the test results are provided by Cybenetics PAGE2/15 › The link to the original test results document should be provided in any case

Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient	www.cybenetics.com [e-mail]
and silent power supplies are promoted	4004 MESA GEITONIA, LIMASSOL, CYPRUS

EFFICIENCY AND NOISE

LEVEL CERTIFICATIONS

Anex		Phanteks PH-P750G (Sample #2)
RESULTS
Temperature Range (°C /°F)
	30-32 / 86-89.6
	ErP Lot 6	2010:
ErP Lot 3/6 Ready	ErP Lot 6	2013:
	ErP Lot 3	2014 & CEC: Partially

(EU) No 617/2013 Compliance

115V

Average Efficiency	88.622%
Efficiency With 10W (≤500W) or 2% (>500W)
	59.918
Average Efficiency 5VSB
	76.001%
Standby Power Consumption (W)
	0.0450366
Average PF
	0.976
Avg Noise Output
	33.13 dB(A)
Efficiency Rating (ETA)
	ETA-A
Noise Rating (LAMBDA)
	LAMBDA-S++

230V

Average Efficiency	90.413%
Average Efficiency 5VSB
	75.535%
Standby Power Consumption (W)
	0.0740516
Average PF
	0.935
Avg Noise Output
	33.10 dB(A)
Efficiency Rating (ETA)
	ETA-A
Noise Rating (LAMBDA)
	LAMBDA-S++

TEST EQUIPMENT

			Chroma 63601-5 x4
	Electronic Loads		Chroma 63600-2 x2
			63640-80-80 x20
			63610-80-20 x2
	AC Sources		Chroma 6530, Keysight AC6804B
	Power Analyzers
			N4L PPA1530 x2
	Sound Analyzer
			Bruel & Kjaer 2270 G4
	Microphone
			Bruel & Kjaer Type 4955-A
	Data Loggers
			Picoscope TC-08 x2, Labjack U3-HV x2
	Tachometer
			UNI-T UT372 x2
	Digital Multimeter
			Keysight U1273AX, Fluke 289, Keithley 2015 - THD
	UPS
			CyberPower OLS3000E 3kVA x2
	Transformer		3kVA x2

HOLD-UP TIME & POWER OK SIGNAL (230V)

Hold-Up Time (ms)	21.00
AC Loss to PWR_OK Hold Up Time (ms)
	17.50
PWR_OK Inactive to DC Loss Delay (ms)
	3.50

All data and graphs included in this test report can be used by any individual on the following conditions:

› It should be mentioned that the test results are provided by Cybenetics PAGE3/15 › The link to the original test results document should be provided in any case

Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient	www.cybenetics.com [e-mail]
and silent power supplies are promoted	4004 MESA GEITONIA, LIMASSOL, CYPRUS

EFFICIENCY AND NOISE

LEVEL CERTIFICATIONS

Anex	Phanteks PH-P750G (Sample #2)

EFFICIENCY UNDER HIGH AMBIENT TEMPERATURE

INFO

The PSU`s efficiency under high ambient temperatures with 115V and 230V input. For this graph the results of the 10-110% load regulation table are used

5VSB EFFICIENCY

INFO

This graph depicts the efficiency levels of the 5VSB rail with 115V and 230V input

All data and graphs included in this test report can be used by any individual on the following conditions:

› It should be mentioned that the test results are provided by Cybenetics PAGE4/15 › The link to the original test results document should be provided in any case

Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient	www.cybenetics.com [e-mail]
and silent power supplies are promoted	4004 MESA GEITONIA, LIMASSOL, CYPRUS

							EFFICIENCY AND NOISE
							LEVEL CERTIFICATIONS
Anex						Phanteks PH-P750G (Sample #2)
5VSB EFFICIENCY -115V (ERP LOT 3/6 & CEC)
Test #		5VSB		DC/AC (Watts)		Efficiency			PF/AC Volts
1		0.045A	0.231		67.941%		0.057
		5.135V		0.340					115.12V
2		0.090A	0.462			72.414%		0.103
		5.133V		0.638					115.12V
3		0.550A	2.818		76.472%		0.341
		5.122V		3.685					115.12V
4		1.000A	5.112		76.390%		0.409
		5.111V		6.692					115.12V
5		1.500A	7.650		76.500%		0.443
		5.099V		10.000					115.12V
6		3.000A	15.175		75.127%		0.487
		5.058V		20.199					115.12V
5VSB EFFICIENCY -230V (ERP LOT 3/6 & CEC)
Test #		5VSB		DC/AC (Watts)		Efficiency			PF/AC Volts
1		0.045A	0.231		60.789%		0.020
		5.135V		0.380					230.23V
2		0.090A	0.462			67.347%		0.035
		5.133V		0.686					230.24V
3		0.550A	2.818		74.967%		0.166
		5.122V		3.759					230.24V
4		1.000A	5.112		75.857%		0.247
		5.111V		6.739					230.23V
5		1.500A	7.650		76.508%		0.301
		5.099V		9.999					230.24V
6		3.000A	15.187		76.386%		0.375
		5.062V		19.882					230.24V
