Phaesun Battery Box

Charge Plus

The Charge Plus Battery Box is a combination of a durable battery box
and the Eco charge controller and therefore enables any installation
to be housed in a tidy professional way. It is ideal to keep a battery
(up to 110 Ah) and in a dry and safe environment. The Snap-Top
battery boxes are manufactured using the highest quality injection
molded polypropylene plastic. They effectively collect electrolytes
and allow ventilation. The secure and lockable lid prevents accidental
contact of underground battery terminals. All included connectors are
fitted with easy to mount Cage Clamp 2-Wires with 1 x input socket
(for the solar panel), 1 x socket (for the battery) and 1 x output
sockets (for the loads. The Eco solar charge controller is designed for
small solar systems requiring low-battery disconnect. The Eco series
is fully electronically protected and offers an LED display showing
charge and load status.

500067• 6/2015

Features

Polypropylene Snap-Top battery box
Allows ventilation
Effectively collects electrolytes
Eco charge controller with LED display, IP68
Easy to mount Cage Clamp 2-Wire
Battery Box Strap included

Amount Components

Battery Box HM318BK

1

Charge controller Phocos Eco 10

1

Ring terminals 25 mm² 25-10

6

Art.No. 500067
