Petsafe PBC17-13475, PBC45-13476 Operating Manual

PBC17-13475
PBC45-13476

Deluxe Outdoor Bark Control

Système de contrôle des aboiements
de luxe pour l’extérieur

Deluxe blafbeheersing voor buitenshuis

Control de los ladridos deluxe
paraexteriores

Dispositivo per il controllo
dell’abbaio all’aperto Deluxe

Bellkontrolle Deluxe für
Aussenbereiche

Operating Guide

Manuel d’utilisation

Gebruiksaanwijzing

Manual de funcionamiento

Guida all’uso

Gebrauchsanweisung

Please read this entire guide before beginning

Veuillez lire ce manuel en entier avant de commencer

Gelieve deze gids volledig door te lezen voordat u begint

Por favor, lea detenidamente este manual antes de empezar

Si prega di leggere attentamente la guida all’uso prima di utilizzare il collare

Bitte lesen Sie die ganze Gebrauchsanleitung vor der Inbetriebnahme aufmerksam durch

2 www.petsafe.net

ENFRNLESITDE

IMPORTANT SAFETY INFORMATION

Explanation of Attention Words and Symbols Used in this Guide

This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible
injury or death.

WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.

CAUTION, used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.

CAUTION, used without the safety alert symbol, indicates a hazardous
situation which, if not avoided, could result in harm to your pet.

• Risk of explosion. Do not short circuit, mix old and new batteries, dispose
of in fi re, or expose to water. When batteries are stored or disposed, they
must be protected from shorting. Dispose of spent batteries properly.

• Not for use with aggressive dogs. Do not use this Product if your dog is
aggressive, or if your dog is prone to aggressive behaviour. Aggressive
dogs can cause severe injury and even death to their owner and others.
If you are unsure whether this product is appropriate for your dog, please
consult your veterinarian or certifi ed.

• Humans cannot hear the ultrasonic sound; however, precautions should be
taken when preparing the Deluxe Outdoor Bark Control for use.

• Keep at arms length away from the human ear to avoid hearing damage if
a dog begins barking while you are setting up, mounting, or hanging the
Outdoor Bark Control.

• Humans should avoid standing very close to the Deluxe Outdoor Bark
Control when it is turned on.

• This device is intended for use only with dogs. Never attempt to use it for
any purpose not described in this manual.

• For outdoor use only. Please visit our website or contact the Customer Care
Centre for information on PetSafe® Bark Control products appropriate for
indoor use.

• The Deluxe Outdoor Bark Control is not a toy. Keep it out of the reach of
children. Use it only for its bark control purpose.

www.petsafe.net 3

DEITESNLFREN

Thank you for choosing the PetSafe® brand. You and your pet deserve a companionship that
includes memorable moments and a shared understanding together. Our products and training
tools promote a lifestyle of protection, teaching, and love - essentials that infl uence memories
for a lifetime. If you have any questions about our products or training your pet, please visit our
website at www.petsafe.net or contact our Customer Care Centre. For a listing of Customer Care
Centre telephone numbers in your area, visit our website at www.petsafe.net.

To get the most protection out of your warranty, please register your product within 30 days
at www.petsafe.net. By registering and keeping your receipt you will enjoy the product’s full
warranty and, should you ever need to call the Customer Care Centre, we will be able to help
you faster. Most importantly, your valuable information will never be given or sold to anyone.
Complete warranty information is available online at www.petsafe.net.

Table of Contents

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Possible Uses for the Deluxe Outdoor Bark Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

How the System Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Key Defi nitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

To Insert and Remove the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Three Colour LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operating the Clock/Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Set the Time Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Set the Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Set Timer 1 OFF/ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Set Timer 2 OFF/ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Reset the Clock and Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Test the Deluxe Outdoor Bark Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

What to Expect During Use of the Deluxe Outdoor Bark Control . . . . . . . . . . . . . . . . . . . . .11

Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Frequently Asked Questions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Battery Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Terms of Use and Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4 www.petsafe.net

ENFRNLESITDE

Components

Operating Guide

PetSafe

®

Deluxe Outdoor

Bark Control

Features

• Built in timer for two OFF/ON presets

• Uses ultrasonic sound to disrupt nuisance barking

• Detects barking up to 15 m away

• Durable and weatherproof

• Three colour LED shows good or low battery, is an indicator for the Timer 1 and Timer 2 OFF,
and indicates ultrasonic stimulations

Possible Uses for the Deluxe Outdoor
Bark Control

• Stop your barking dog

• Stop your neighbours’ barking dogs

• Stop barking at specifi c times of day

• Train puppies not to bark

• Deter barking dogs on camping trips

www.petsafe.net 5

DEITESNLFREN

How the System Works

When the PetSafe® Deluxe Outdoor Bark Control is within range of a barking dog, an internal
microphone picks up the sound and the unit is automatically activated. The Deluxe Outdoor Bark
Control emits an ultrasonic sound. The ultrasonic sound can be heard by dogs but is silent to most
humans. Startled by the high-pitched sound that is safe and effective, the dog should stop barking
as it will associate its bark with this unpleasant noise. When the dog stops barking the ultrasonic
sound also stops. Programmable timers let you curb barking at certain times of day, for example,
after school as children pass by. Setting the timer(s) also helps conserve battery life. The Deluxe
Outdoor Bark Control includes a timer for two OFF/ON presets. It is effective up to 15 m.

Note: If the dog is deaf or hearing impaired, he may not react to the Deluxe Outdoor Bark Control.

Key Defi nitions

Front

Metal Hanger: For hanging the Deluxe

Outdoor Bark Control.

Microphone: Used to detect barking.
Sound Activated Speaker: Produces the

ultrasonic sound.

Back

Select Button: Used to rotate through and

select a menu item.
Hour Button: Used to set the time format,
clock, Timer 1, and Timer 2 hour(s).
Minute Button: Used to set the time format,
clock, Timer 1, and Timer 2 minute(s).
Three Colour LED: Shows good or low
battery, is an indicator for the Timer 1
and Timer 2 OFF, and indicates ultrasonic
stimulations.
LCD Display: Used to show the time format,
clock, timers, test, and reset functions.

Bottom

Battery Door: Used to enclose the Battery.

Three Colour
LED

Microphone

Minute

Back
View

Front
View

Bottom
View

Sound Activated
Speaker

Metal Hanger

Select

Battery Door

Hour

LCD
Display
