HEADER INSTALLATION INSTRUCTIONS

D3336

APPLICATION

64-72 BUICK SKYLARK, GRAN SPORT & WAGONS, LS1/LS6

64-72 CHEVROLET CHEVELLE, PASSENGER CARS & WAGONS, LS1/LS6

64-72 PONTIAC GTO & LE MANS, LS1/LS6

Note: Requires LS1 adapter plate kit P/N SK100

PerTronix

to realize the full potential of our good fit, please read and understand these instructions completely prior to starting work.
CHECK TO MAKE SURE YOU RECEIVED THE PROPER PARTS FOR YOUR APPLICATION. THE HEADER NUMBER WILL

BE STAMPED ON THE ENGINE FLANGE. IF YOU ARE UNSURE YOU HAVE RECEIVED THE PROPER PARTS CALL
BEFORE YOU START WORK.

BE SURE TO WORK SAFE! WHENEVER YOU WORK UNDER THE VEHICLE BE SURE THAT IT IS LOCATED ON LEVEL,
SOLID GROUND AND IS SUPPORTED BY ADEQUATE SAFETY STANDS!

REMEMBER: HOT ASPHALT WILL NOT SUPPORT MOST JACK STANDS!

Many factors affect the installation of headers, some of which are broken or aftermarket motor mounts, accidents that impact the
configuration of the frame, and/or the installation of different engines or aftermarket cylinder heads. Most installations require
some welding. If you are uncomfortable with welding operations, we recommend that you contact a professional exhaust
system specialist to install your new headers.

Attention Customers breaking in new engines: Due to the extreme heat generated during the break-in process, the
appearance of the ceramic coating may be altered in certain areas. The protection characteristics and thermal barrier properties
of the coating is never compromised. It is recommended that a cast iron manifold or old set of headers be used for this process.

Notice: The coating of these headers can be marred or scratched during installation. If the header needs to be returned and is
damaged, you will be charged for recoat.

©

thanks you for choosing

DOUG’S HEADERS

, the best fitting, highest quality header on the market. In order

DISASSEMBLY / ASSEMBLY

1. Disconnect the negative battery cable from the battery.

2. If a car lift is not available, raise the vehicle 2 feet or higher and support it with
adequate safety stands. Make sure the vehicle is on a flat solid surface and is stable.

3. Apply penetrating oil to all nuts and bolts to be removed.

4. Remove bolts from headpipe to exhaust manifolds.

Part No. 0110-003117
Page 1 of 3 rev.1 9-6-13 DSL

5. Note the spark plug wire locations and remove them from the spark plugs. Use a
twisting motion while pulling the spark plug boot off of the spark plug. Be very careful
not to damage the spark plug boot and do not pull on the wire itself.

6. Remove spark plug wire looms, plugs and any brackets attached to the manifolds.

7. Disconnect the O2 sensor wiring.

8. Remove the O2 sensors.

9. Remove the oil dipstick and tube.

10. Remove both of the exhaust manifolds.

RIGHT SIDE:

1. Apply anti-seize to all header bolts being used.

2. Starting from below, work the header and gasket up through the chassis into
position.

3. Start all header bolts.

4. Tighten all header bolts evenly (most restricted first) 18 ft./lbs on aluminum heads
or 25 ft/lbs on Iron Heads.

5. Reinstall the right side spark plugs, wire looms, and dipstick tube and dipstick.

6. Reinstall the O2 sensor.

7. Reconnect the O2 sensor to the O2 harness with the supplied extension.

8. Install the V Band clamp and reducer.

9. Cut the old exhaust pipe and weld as necessary to the new reducer.

LEFT SIDE:

1. Apply anti-seize to all header bolts being used.

2. Starting from below, work the header and gasket up through the chassis into
position.

3. Start all header bolts.

4. Tighten all header bolts evenly (most restricted first) 18 ft./lbs on aluminum heads
or 25 ft/lbs on Iron Heads.

5. Reinstall the left side spark plugs, wire looms and any brackets.

6. Reinstall the O2 sensor.

7. Reconnect the O2 sensor to the O2 harness with the supplied extension.

a. Install the V Band clamp and reducer.

8. Cut the old exhaust pipe and weld as necessary to the new reducer.

9. Connect the negative battery cable.
