PerTronix 1864AN6 User Manual

6-Volt Negative Ground Installation Instructions

For Part Number: 1864AN6

CAUTION!!! Before installing, please read the following important information....

1. The Ignitor is designed for 6-Volt negative ground systems.

2. Leaving the ignition “ON” with the engine “OFF” for an extended period could result in permanent damage to
the Ignitor.

3. See Chart on back page for coil recommendations.

4. Four & Six cylinder engines require a minimum of 1.5 ohms of primary resistance. Do not remove resistors if
the coil primary resistance is less than 1.5 ohms.

5. If your Ignition coil has the recommended primary resistance, remove or bypass all external resistors.

DISASSEMBLY

1. PRIOR TO INSTALLATION TURN IGNITION SWITCH OFF OR DISCONNECT THE BATTERY

2. Remove the distributor cap, and rotor. Do not disconnect spark plug wires. Examine cap and rotor for wear
or damage. Replace as needed.

3. Disconnect the point wire from the negative (-) terminal of the coil.

4. Remove the point wire, point, and condenser.

5. The Ignitor does not require any modification to the distributor. Therefore the point, condenser and hardware
can be used as backup. Note: 1864AN6 requires a minor modification. See Figure 1.

6. Clean all dirt and excess oil from the breaker plate and point cam.

IGNITOR INSTALLATION

1. Part numbers 1864AN6 modification required. (See Figure 1).

2. Remove module from adapter plate before proceeding to next step.

3. Place adapter plate over point pivot pin, line up adapter plate to screw hole on breaker plate.

Confirm
that the adapter plate is flat and fits without modifications and fasten the plate into place using the screw
provided.

4. Place the Ignitor module on the adapter plate studs. Secure module to adapter plate with the nuts and lock
washers provided.

5. If the distirbutor ground wire was removed during the installation process be sure it is re-attached securely.

NOTE: If the ground wire is missing, one needs to be installed and
attached from the point breaker plate to the distirbutor housing.

6. Insert wires through the wire exit hole in distributor housing. Pull
the rubber grommet into place. Make sure wires do not interfere

Point Cam

with any moving parts.

7. Install magnet sleeve over the distributor shaft, onto point cam.
Rotate the sleeve until a slight locating position is felt before
applying pressure. Press down firmly insuring sleeve is fully
seated.

8. Module and magnet sleeve air gap is not adjustable.

9. Reinstall the rotor, and the distributor cap. Make sure all spark plug
wires are securely attached.

10. See Wiring Instructions.

1864AN6

Grind away or cut corner of bracket for

magnet sleeve clearance.

Figure 1

909-599-5955 www.pertronix.com

909-599-5955 www.pertronix.com

Page 1 of 4

Page 1 of 4

Page 1 of 4

A. Recommended Wiring Installation:

The Ignitor ignition can be used in conjunction with most ignition coils rated at 0.6 ohms of primary resistance on eight cylinder

engines and 1.5 ohms on four and six cylinder engines. For optimum performance purchase and install the recommended

Flamethrower high performance coil.

Many vehicles came equipped with ballast resistor or resistance wire. To achieve optimum performance from the Ignitor ignition

system, we recommend the removal of these components.

• To remove a ballast resistor, (normally white ceramic blocks 3 to 4 inches long), disconnect all wires on both ends of the ballast

resistor. Remove the resistor from the vehicle and splice the disconnected wires together at a single point.

• To remove a resistance wire, trace the coil power wire, which was previously connected to the positive coil terminal, back to the fuse

block. Bypass this wire with a 12-gauge copper stranded wire.

1. Attach the black Ignitor wire to the negative coil terminal. (See Figure A)

2. Attach the red Ignitor wire to the positive coil terminal. (See Figure A)

3. Check to insure that the polarity is correct, and that all connections are tight.

4. Re-connect the battery.

5. Start the engine and allow it to reach normal operating temperature. Check ignition timing, and adjust to the desired setting.

COIL WIRE

BLACK WIRE

TO IGNITION

(FIGURE A)

RED WIRE

B. Alternative Wiring Installation:

The Ignitor can also be installed in applications retaining the ballast resistor or resistance wire.

1. Attach the Ignitor black wire to the negative coil terminal. (See Figure B)

2. Attach the Ignitor red wire to the ignition side of resistance, or any 6-volt ignition power source. (See Figure B)

3. Check to insure that the polarity is correct, and that all connections are tight.

4. Re-connect the battery.

5. Start the engine and allow it to reach normal operating temperature. Check ignition timing, and adjust to the desired setting.

COIL WIRE

BALLAST RESISTOR

TO IGNITION SWITCH

(FIGURE B)

BLACK WIRE

RESISTANCE WIRE

RED WIRE
