Page 1
Perreaux
Model:
MC6100
Date of Manufacture:
Product Type:
Power Output
6-Channel Power Amplifier
per channel into 8Ω
(
1994
):
120W
rms
info@perreaux.com www.perreaux.com
Page 2
Specifications:
Power Output
Unbridged
6 x 120W
Harmonic Distortion
160W
rms
Bridged
3 x 275W
Harmonic Distortion
Frequency Response ........................................................................................20Hz-20kHz ±0.75dB
.....................................................................................................................-3dB @ 6Hz and 120kHz
Total Harmonic Distortion (unbridged)
Rated power ..............................................................................................................0.005% @ 1kHz
Worst case prior to clipping ...................................................................................................... 0.04%
Dynamic Headroom ...................................................................................................................2.5dB
Damping Factor............................................................................................................. 600 @ 100Hz
......................................................................................................................................... 400 @ 1kHz
Noise (inputs shorted, A weighted)............................................................................................. -97dB
continuous, driven into 8Ω from 20Hz to 20kHz at no more than 0.015% Total
rms
per channel into 4Ω
continuous, driven into 8Ω from 20Hz to 20kHz at no more than 0.04% Total
rms
Input Sensitivity .......................................................................................................................1.0V
rms
Input Impedance ........................................................................................................................ 47kΩ
Dimensions
Width...........................................................................................................................440mm (17.5”)
Height............................................................................................................................177mm (7.0”)
Depth...........................................................................................................................430mm (17.0”)
Weight ..........................................................................................................................20.0kg (44.0lb)
;
Schematic diagram
;
Product manual
info@perreaux.com www.perreaux.com
