PERLICK | luxury undercounter refrigeration for the home

proudly designed, engineered and

manufactured in milwaukee since 1917

24” Signature Series Refrigerator Drawers, shown above

Quality & innovation thaT

inspires

Enjoy ice cold beverages, brewery-fresh draft beer, the perfectly chilled vintage, crisp fruits and vegetables bursting with avor, and even chilled face cream – all made possible with Perlick’s quality line of residential undercounter refrigeration.

Featuring the most innovative products in the industry, Perlick makes it easier than ever to add refrigeration to any room of the home – including the home bar, entertainment room, kitchen, family room and bathroom – no matter how much space you have.

For nearly 100 years, Perlick’s award-winning products have inspired our customers.

Get inspired. Choose Perlick.

100 years

of excellence in refrigeration

The Perlick name is synonymous with innovation and unparalleled quality. You’ve experienced the craftsmanship of a Perlick – at your favorite restaurant, your home team’s stadium or ﬁrst class resorts around the world. We’ve made a name for ourselves in refrigeration and beverage dispensing technology in the commercial world since opening our doors on Florida Street in Milwaukee, Wisconsin back in 1917. Since then, we’ve parlayed our expertise into a collection of awarding-winning premium undercounter refrigeration reﬁned for the home.

Digital Temperature Control provides

clear, accurate temperature readout

RAPIDcool™

Forced-Air

System

Perlick’s Front-vented, RAPIDcool™ Forced-Air Refrigeration System cools product quickly by continuously circulating cold

air throughout the cabinet – also providing consistent temperature and eliminating cold spots

Adjustable Cool Blue and Crisp White LED Lighting illuminates product beautifully

what makes it a

Perlick

There is a reason premier showrooms proudly feature Perlick on their showﬂoors. It’s because Perlick craftsmanship is second to none, because we build each and every cabinet by hand with only the ﬁnest materials available. Read on to learn more about what makes it a Perlick.

All models are available with choice of stainless

steel or fully integrated overlay. Fully integrated

overlay models come ready to accept custom

panel to match surrounding cabinetry or nishes.

We stand behind our products, that’s why

Perlick refrigeration comes with an industry

leading Full Three Year Warranty plus

additional 3 years on sealed system to

provide peace of mind for both residential

and light commercial applications

Stainless Steel Interiors provide the most sanitary surface

available to keep food and beverages fresher – longer.

Full-Extension Pullout Shelves are black

vinyl-coated and are height adjustable in one inch increments. Shelves glide smoothly in and out of the cabinet with ease thanks to stainless steel ball bearing glides. They are engineered to allow for proper air ow throughout the entire cabinet - which is something glass shelves cannot achieve

Two-Inch Thick Foamed-in-Place Insulation

provides industry leading protection against warm temperatures and vibration

find your perfect

perlick

15-, 24- & 48-INCH SIGNATURE SERIES

(Available in solid door, glass door and drawer models

with choice of stainless steel or fully integrated overlay)

• Robust refrigeration system powered by Perlick’s exclusive variable speed compressor* provides industry-leading cooling capabilities and intuitive temperature control – which means system will only run when it senses a temperature rise

• Front vented, RAPIDcool™ forced air refrigeration system pulls down product temperature in around 30 minutes

• Rated for beverages and open food storage

• Digital temperature control in all models

• Illuminated by dual-color LED lighting, giving you the option of Crisp White or Cool Blue lighting with just the press of a button

• All Signature Series products available as ULrated outdoor models

SIGNATURE SERIES SOTTILE

(Available in solid door and glass door models with choice of stainless steel

or fully integrated overlay)

• Industry Exclusive undercounter refrigeration that measures just 18” deep with recessed plug.

• Measuring 32” tall, the Sottile collection is ADA Compliant for universal design

• Robust, front vented, RAPIDcool™ forced air refrigeration system pulls down product temperature in around 30 minutes

• NSF rated for open package food

• Digital temperature control in all models

• Illuminated by dual-color LED lighting, giving you the option of Crisp White or Cool Blue lighting with just the press of a button

• All Signature Series products available as ULrated outdoor models

• Optional riser with 6” toe kick available for standard height cabinetry

*15” models and 24” Freezer models feature standard compressor

• Every single indoor and UL-rated outdoor Sottile model earned a 2015 Award for Design Excellence (ADEX)

Perlick proudly oers the widest selection of undercounter refrigeration products in the industry, making it easier than ever to add point-of-use refrigeration to any space inside – or outside – the home. All Perlick products feature robust refrigeration systems, stainless steel interiors, and our industry best three full year warranty. Below are the highlights of each series to start you o on your search for the perfect Perlick.

C-SERIES

(Available in solid door, glass door and drawer models

with choice of stainless steel or fully integrated overlay)

• Powered by energy ecient compressor to oer commercial-grade cooling at an economical price

• Front vented, RAPIDcool™ forced air refrigeration system pulls down product temperature in around 30 minutes

• Rated for beverages and open food storage

• Digital temperature control in all models

• Select outdoor models available

ADA COMPLIANT SERIES

(Available in solid door, glass door and drawer models

with choice of stainless steel or fully integrated overlay)

• Measures 32” tall to adhere to ADA regulations for universal design

• Powered by energy ecient compressor to oer commercial-grade cooling

• Front vented, RAPIDcool™ forced air refrigeration system pulls down product temperature in laround 30 minutes

• Rated for beverages and open food storage

• Standard temperature control (excluding freezer models that are equipped with digital controller) and incandescent lighting

freezers

When it comes to stylish freezer solutions, Perlick has thought of it all. Quiet, powerful and energy ecient, all Perlick freezers featured forced-air refrigeration and hot gas defrost for maintenance free defrosting.

24” Signature Series Freezer Drawers w/Optional Lock, shown above

AVAILABLE MODELS | Freezers

freezers

series

refrigerators

Solid Door Drawers

24” Signature Series

For Perlick model numbers and available accessories, see pages 26 - 35

24” ADA Compliant

Solid Door Drawers

Maintenance-free automatic defrost makes owning and maintaining the freezer simple

Transform any door model freezer into the ultimate cocktail chiller with Perlick’s exclusive Martini Rack. Perfectly chill martini glasses and spirits for guests to enjoy at your next gathering.

centers

reserves

dispensers

ice makers

beverage

wine

beer

Temperature range:

Freezer

-10° – 10°F

Outdoor Model Available

Outdoor

models Accessories series

REFRIGERATORs

Perlick oers the industry’s widest selection of undercounter refrigerators, making it easier than ever to add fully customizable refrigeration to any room of the home.

15” Signature Series Refrigerator Drawers, shown above

AVAILABLE MODELS | Refrigerators

freezers

refrigerators

Signature Series

24” ADA Compliant

Solid Door Glass Door Drawers

15” Signature Series

sottile

Solid Door Glass Door

series

Solid Door Glass Door Drawers

Robust refrigeration system properly chills room-temperature product in just 30 minutes – far exceeding the temperature

pulldown – and temperature consistency – of any competitive models.

Solid Door Glass Door Drawers

24” Signature Series

24” C-Series

Solid Door Glass Door Drawers

For Perlick model numbers and available accessories, see pages 26 - 35

Glass doors feature Low E coated, Argon lled dual-pane thermal glass to limit

energy transfer through glass and add increased strength - indoors or outdoors.

centers

reserves

dispensers

ice makers

beverage

wine

beer

Temperature range:

refrigerator

33° – 42°F

Outdoor Model Available

This stainless steel solid door model – along with our fully integrated overlay solid door model – is ENERGY STAR qualied

Outdoor

models Accessories series

BEVERAGE CENTERS

The practicality of a refrigerator meets the elegance of a wine reserve in Perlick’s full line of beverage centers. Two full extension wine racks keep wine bottles chilled on top, while a refrigerator shelf accommodates goods below.

24” C-Series Beverage Center, shown above

AVAILABLE MODELS | Beverage Center

freezers

refrigerators

Solid Door Glass Door

15” Signature Series

sottile

Signature Series

Solid Door Glass Door

series

24” ADA Compliant

Solid Door Glass Door

24” Signature Series

24” C-Series

For Perlick model numbers and available accessories, see pages 26 - 35

Solid Door Glass Door

centers

reserves

dispensers

beverage

wine

beer

Robust refrigeration system properly chills room-temperature product in just 30 minutes – far exceeding the temperature

pulldown – and temperature consistency – of any competitive models.

Temperature range:

beverage center

33° – 48°F

Glass doors feature Low E coated, Argon lled dual-pane thermal glass to limit

energy transfer through glass and add increased strength - indoors or outdoors.

Outdoor Model Available

This stainless steel solid door model – along with our fully integrated overlay solid door model – is ENERGY STAR qualied

ice makers

Outdoor

models Accessories series

WINE RESERVES

For the serious wine connoisseur, Perlick manufactures the most well-built, skillfully designed wine storage in the world. Perlick’s wine reserves are simply designed and built to store vintages properly – and beautifully.

24” Signature Series Dual-Zone Wine Reserve, shown above

AVAILABLE MODELS | Wine Reserves

freezers

refrigerators

Solid Door Glass Door

15” Signature Series

sottile

Signature Series

Solid Door Glass Door

24” C-Series

Solid Door Glass Door

24” Signature Series

48” Signature Series

series

24” ADA Compliant

Perlick has storage options for up to 80 wine bottles in 15, 24 and 48 widths. See page 18 for bottles counts on all Perlick Wine Reserves.

Solid Door,

Single- or Dual-Zone

Solid Door,

Single- or Two-Zone

Solid Door Glass Door

Glass Door,

Single-Zone

Glass Door, Dual-Zone

Glass Door,

Single- or Two-Zone

For Perlick model numbers and available accessories, see pages 26 - 35

Glass doors feature Low E coated, Argon lled dual-pane thermal glass to limit

energy transfer through glass and add increased strength - indoors or outdoors.

centers

reserves

dispensers

ice makers

beverage

wine

beer

Temperature range:

wine reserves

45° – 65°F*

See page 28 for Dual-Zone Wine Reserve temperatures (HP24DS/DO)

Outdoor Model Available

Outdoor

models Accessories series

A toast to the

Wine Reserve Model

Shelf Count Bottle Count

15” Signature Series 5 20

24” Signature Series (single-zone) 5 40

24” Signature Series Dual-Zone 4.5 32

48” Signature Series (single temp) 10 80

48” Signature Series (two temp) 10 80

Signature Series Sottile 4 20

24” C-Series 5 40

24” ADA Compliant Series 4 32

industry’s widest selection of

luxury wine reserves

With the most undercounter wine storage solutions in the industry, Perlick can accommodate any sized collection of Rieslings, Merlots and everything in between. Below are the shelf and bottle counts of each of our Wine Reserve models.

Industry exclusive black vinyl-coated, full-extension pullout shelves on

stainless steel ball bearing glides provide smooth movement of shelves in and out of the cabinet to reduce vibration. Shelves are height adjustable in 1” increments to accommodate magnum (oversized) bottles.

freezers

refrigerators

beverage

centers

reserves

wine

dispensers

ice makers

models Accessories series

beer

Outdoor

15” Signature Series Wine Reserve , shown

beer dispensers

Perlick is the brand professionals trust to dispense beer at their bars, restaurants and stadiums around the world. We’ve taken the same, innovative technology we’ve been developing since prohibition to bring you the industry’s best residential beer dispensers.

24” C-Series Two Faucet Beer Dispenser, shown above

AVAILABLE MODELS | Beer Dispensers

Series

Capacity:

One 1/6 barrel

1/6

24” Signature

15” Signature Series

1/6

1/4

SLIM

1/4

Capacity:

Two 1/6 barrels

One 1/4 barrel

One slim 1/4 barrel

freezers

refrigerators

Solid Door

24” C-Series

Single Faucet Two Faucet

Trust the brand that pros trust to serve the crowds

Single Faucet Two Faucet

Capacity:

1/6

1/4

SLIM

1/4

Two 1/6 barrels

One 1/4 barrel

One slim 1/4 barrel

1/6

Perlick proudly designs and manufactures refrigeration and beer dispensing systems for bars, restaurants, and professional stadiums around the world. The sames commercial-grade materials and innovative cooling and dispensing technology goes into every Perlick residential product we build.

650SS stainless steel ow control beer faucet(s) included with Signature Series Beer

Dispensers

630SS stainless steel beer faucet(s) included with C-Series Beer

Dispensers

For Perlick model numbers and available accessories, see pages 26 - 35

Outdoor Model Available

centers

reserves

dispensers

ice makers

beverage

wine

beer

(From left to right) Dodgers Stadium, Los Angeles, CA, Madison Square Garden, New York, New York, Lambeau Field, Green Bay, WI

We take great pride in being trusted by a majority of the professional sports stadiums and arenas in North America to pour the perfect beer and chill refreshing drinks for tens of thousands of fans.

Outdoor

models Accessories series

nearly a century’s worth of beer dispensing expertise –

right at your finger tips

The revolutionary new 650SS Flow Control Faucet is Perlick’s latest innovation in beverage dispensing – and it is now standard on all Signature Series Beer Dispensers. This newlydesigned industry exclusive faucet allows you to adjust the speed of the pour, which is important for pouring multiple styles of craft beer or when foaming is an issue.

• Bright, wheat beers – like Hefeweizen – are highly carbonated and tend to pour with an excessive head, requiring a slower pour. The ow control lever adjusts the rate of the pour right at the faucet, allowing you to control how fast beer enters the glass.

• In addition to accommodating a variety of beer styles, the 650SS eliminates waste that is normally caused by foaming in hotter temperatures. Perlick’s exclusive air-cooled tower keeps beer cold from the keg to the faucet, and the ow control lever allows you to dictate the rate of ow to prevent excessive foaming caused by cold beer coming in contact with the hot air.

The 650SS Flow Control Faucet won a 2014 GOOD DESIGN™ Award as awarded by the Chicago Athenaeum: Museum of Architecture and Design

2015 Award for Design Excellence (ADEX) winner

freezers

refrigerators

beverage

centers

reserves

wine

dispensers

ice makers

models Accessories series

beer

Outdoor

24” Signature Series Two Faucet Beer Dispenser with optional Adara Tower, shown above

clear ice makers

A beverage is only as good as the ice that keeps it cold. That’s why Perlick’s clear ice maker produces uniquely shaped top hat ice. The shape combined with the way the ice is made ensures each and every piece is free of impurities so that your signature cocktail is the star of the show.

15” Signature Series Clear Ice Maker, shown above

AVAILABLE MODELS | Clear Ice Makers

• Enjoy up to 55 lbs. of ice production per 24 hours

• Storage capacity of 22 lbs. of ice ensures you’ll never run out

• Indoor/UL-approved for outdoor use

freezers

• Undercounter design features swing style door; wood overlay model

refrigerators

door is also reversible

15” Signature Series

Solid Door

• Easily disassemble water circuit for easy cleaning

• Durable stainless steel exterior

7/8”*

1”*

*approximate size, image not to scale

• Optional pump and stainless steel toe kick available

• Full one year warranty

For Perlick model numbers and available accessories, see pages 26 - 35

beverage

centers

reserves

wine

TIP YOUR CAP TO

PERFECT ICE

Each cube features a distinctive and stylish top hat shape which, like the Clear Ice Maker, is more than just attractive – it serves multiple functions. The “top hat” shaped ice is part of Perlick’s method of ensuring that each cube is absolutely free of impurities, for a ﬂawless look and taste.

dispensers

beer

ice makers

The unique shape is also extremely functional because the top hat design prevents the ice from clumping, guaranteeing that the perfect beverage is served each and every time.

models Accessories series

Outdoor

customize your perlick

SHELVING / shelving accessories

Perlick oers the industry’s widest selection of premium undercounter refrigeration for inside and outside the home, and for that, we have a wide variety of accessory items to create refrigeration that meets your every need and desire.

RS-15-15R Shelf,

Refrigerator 15”

RS-24-24M Shelf,

Martini Rack 24”

RS-24-24WD Shelf, Dual-Zone Wine 24”

hardware

RS-15-15WS Shelf, Wine

15” (stainless steel front)

RS-24-24DS Shelf,

Divider

65629 Wine Bottle

Display Rack 24”

RS-24-24R Shelf,

Refrigerator 24”

RS-18-18R Shelf,

Refrigerator (18” Depth)

67115-15 Wine Shelf

wood faces 15” (5) /

67115-24 Wine Shelf

wood faces 24” (7)

RS-24-24WS Shelf, Wine 24” (stainless steel front)

RS-18-18W Shelf, Wine

(18” Depth)

67964 24” Stainless Steel

Drawer Dividers (3)

(L) Factory Installed

Door Lock

66736 Casters (add -15 for

67439L/67439R Left (L)

or Right (R) Door Hinge Kit

15”, -24 for 24” units)

Modular Column Refrigeration Perlick’s redesigned 15-,

24- and 48-inch stacking kits let you design your own column refrigeration by mixing and matching pieces from our impressive lineup of undercounter refrigeration. Choose two pieces from the same series and stack them to create custom storage for anywhere inside or outside the home. A sleek, modern grill design creates a ush look from top to bottom, and can be designed fully integrated blend in with surrounding cabinetry.

See pages 34-35 for stacking kit

part numbers

handles / misc. accessory kits

freezers

65305-4 Drawer Handle (15” Signature Series Only)

65305-1 Door Handle (Signature Series Only)

65870 Door Handle (C-Series, ADA-Compliant)

6”

67164 6” Toe Kick Kit for

ADA-Compliant Series

67360 6” Toe Kick Kit for 18” Shallow-Depth Series

68117-1 Optional SS Toe

Kick for Ice Makers

67941-1 Designer Handle (Signature Series Only - shown)

67941-2 Designer Handle (24” Signature Series Drawers)

67941-3 Designer Handle (15” Signature Series Drawers)

63802A Pump for

Clear Ice Maker

refrigerators

centers

reserves

dispensers

beverage

wine

beer

beer dispenser accessories

The Industry Exclusive Adara Beer Tower

Perlick Adara one and two faucet beer dispensing towers feature chrome

nished handles for a sleek and modern look on any Signature Series Indoor Beer Dispenser.

The new

63797 Cleaning Kit

BLC4/BLC32 Sanitizer,

4- or 32-oz. bottle

67141-1 Perlick

Faucet Handle

63992 European Keg

Coupler, Kit

ice makers

Outdoor

models Accessories series

308-40C Faucet Lock

(C-Series 630SS

Facuets only)

67782 Drip Pan for Beer

Dispenser

QUICK REFERENCE

REFRIGERATORSBEVERAGE CENTERS

Model & Series

15” Signature Series

HP15RS-3

24” Signature Series

HP24RS-3

Signature Series Sottile

HH24RS-3

24” C-Series

HC24RB-3

24” ADA-Compliant Series

HA24RB-3

15” Signature Series

HP15BS-3

24” Signature Series

HP24BS-3

Signature Series Sottile

HH24BS-3

24” C-Series

HC24BB-3

24” ADA-Compliant Series

HA24BB-3

Overall Dimensions

(W x D x H)

14-7/8” x 24” x 34-1/4”

23-7/8” x 24” x 34-1/4”

23-7/8” x 18” x 32”

23-7/8” x 24” x 34-1/4”

23-7/8” x 24” x 32”

14-7/8” x 24” x 34-1/4”

23-7/8” x 24” x 34-1/4”

23-7/8” x 18” x 32”

23-7/8” x 24” x 34-1/4”

23-7/8” x 24” x 32”

Shelving (door models only) Capacity

2 full-extension pullout shelves

2 wine shelves + 1 full-extension pullout shelf

3.0 cu. ft. 33° - 42°F

5.2 cu. ft. 33° - 42°F

3.8 cu. ft. 33° - 42°F

5.2 cu. ft. 33° - 42°F

4.8 cu. ft. 33° - 42°F

3.0 cu. ft. 35° - 48°F

5.2 cu. ft. 35° - 48°F

3.8 cu. ft. 35° - 48°F

5.2 cu. ft. 35° - 48°F

4.8 cu. ft. 35° - 48°F

Temperature Range

Door Styles Available

1 2 3

4 5 6

1 2 3

4 5 6

1 2 3

4 5 6

1 2 3

4 5 6

1 2 3

Outdoor Model

HP15RO-3

HP24RO-3

HH24RO-3

HC24RO-3

HP15BO-3

HP24BO-3

HH24BO-3

15” Signature Series

HP15WS-3

24” Signature Series

HP24WS-3

24” Signature Series Dual-Zone

HP24DS-3

48” Signature Series (single zone)

HP48WO-3-S

48” Signature Series

WINE RESERVES

(two zone)

HP48WW-3-S

Signature Series Sottile

HH24WS-3

24” C-Series

HC24WB-3

24” ADA-Compliant Series

HA24WB-3

14-7/8” x 24” x 34-1/4” 5 wine shelves 3.0 cu. ft. 45° - 65°F

23-7/8” x 24” x 34-1/4” 5 wine shelves 5.2 cu. ft. 45° - 65°F

2 wine shelves

23-7/8” x 24” x 34-1/4”

47-7/8” x 24” x 34-1/4”

23-7/8” x 18” x 32” 4 wine shelves 3.8 cu. ft. 45° - 65°F

23-7/8” x 24” x 34-1/4” 5 wine shelves 5.2 cu. ft. 45° - 65°F

23-7/8” x 24” x 32” 4 wine shelves 4.8 cu. ft. 45° - 65°F

(top zone) + 2-1/2 (bottom zone)

4 wine shelves (left) + 6 (right)

5.0 cu. ft.

12 cu. ft. 45° - 65°F

11 cu. ft. 45° - 65°F

(U) 51-65°F (L) 45°-60°F

1 2 3

HP15WO-3

HP24WO-3

HP24DO-3

HH24WO-3

Model & Series

15” Signature Series

HP15TS-3

24” Signature Series

HP24TS-3

Overall Dimensions (W x D x H) Keg Capacity Capacity

(1) 1/6th

14-7/8” x 24” x 34-1/4”

3.0 cu. ft. 33° - 42°F

(2) 1/6th or

23-7/8” x 24” x 34-1/4”

(1) 1/4

5.2 cu. ft. 33° - 42°F

Temperature Range

Door Styles Available

1 2

freezers

Outdoor Model

HP15TO-3

refrigerators

HP24TO-3

CLEAR ICE

BEER DISPENSERSFREEZERS

HC24TB-3

Model & Series

24” Signature Series

HP24FS-3

23-7/8” x 24” x 34-1/4”

Overall Dimensions

(W x D x H)

23-7/8” x 24” x 34-1/4”

24” ADA-Compliant Series

24” C-Series

HA24FB-3

15” Signature Series

H50IMS

MAKERS

23-7/8” x 24” x 32”

14-7/8” x 22-5/8” x 33-1/2”

DOOR STYLES FOR EVERY DESIGN

(2) 1/6th or (1) 1/4

Shelving (door models only) Capacity

2 full-extension pullout shelves

5.2 cu. ft. 33° - 42°F

Temperature Range

5.2 cu. ft. -10° - 10°F

2 full-extension pullout shelves 4.8 cu. ft. -10° - 10°F

N/A 22 lbs of

ice

1 2

Door Styles Available

1 2

5 6

1 2

5 6

1 2

HC24TO-3

Outdoor Model

HP24FO-3

(same)

centers

reserves

dispensers

ice makers

beverage

wine

beer

solid stainless steel door

Perlick oers a variety of door styles to complement any design. The numbered image above coordinates with the ‘Door Styles Available’ column in the Quick Reference chart. All doors are available hinged left or right, and fully integrated overlay panels comes ready to accept a custom panel from your millworker to create a seamless look with cabinetry.

fully integrated solid door

1 2 3 4 5 6

stainless steel glass door

stainless steel drawers

fully integrated glass door

• Industry Exclusive convertible door design allows all doors to be converted to overlay from stainless steel

• All doors are eld reversible with accessory hinge kit (excluding ice maker models)

• Template available to create a matching overlay toe kick

fully integrated drawers

models Accessories series

Outdoor

15” Signature Series 15” Outdoor Signature Series

15” Signature Series REFRIGERATORS

HP15RS-3-1L* solid stainless steel door, hinge left

HP15RS-3-2L* solid fully integrated door, hinge left

HP15RS-3-3L* stainless steel glass door, hinge left

HP15RS-3-4L* fully integrated glass door, hinge left

HP15RS-3-5 stainless steel drawers

HP15RS-3-6 fully integrated drawers

15” Signature Series BEVERAGE CENTER

HP15BS-3-1L* solid stainless steel door, hinge left

HP15BS-3-2L* solid fully integrated door, hinge left

HP15BS-3-3L* stainless steel glass door, hinge left

HP15BS-3-4L* fully integrated glass door, hinge left

15” Signature Series WINE RESERVE

HP15WS-3-1L* solid stainless steel door, hinge left

HP15WS-3-2L* solid fully integrated door, hinge left

HP15WS-3-3L* stainless steel glass door, hinge left

HP15WS-3-4L* fully integrated glass door, hinge left

15” Signature Series beer dispensers

HP15TS-3-1L* solid stainless steel door, hinge left

HP15TS-3-2L* solid fully integrated door, hinge left

15” outdoor Signature Series

REFRIGERATORS

HP15RO-3-1L* solid stainless steel door, hinge left

HP15RO-3-2L* solid fully integrated door, hinge left

HP15RO-3-3L* stainless steel glass door, hinge left

HP15RO-3-4L* fully integrated glass door, hinge left

HP15RO-3-5 stainless steel drawers

HP15RO-3-6 fully integrated drawers

15” outdoor Signature Series

BEVERAGE CENTER

HP15BO-3-1L* solid stainless steel door, hinge left

HP15BO-3-2L* solid fully integrated door, hinge left

HP15BO-3-3L* stainless steel glass door, hinge left

HP15BO-3-4L* fully integrated glass door, hinge left

15” outdoor Signature Series

WINE RESERVES

HP15WO-3-1L* solid stainless steel door, hinge left

HP15WO-3-2L* solid fully integrated door, hinge left

HP15WO-3-3L* stainless steel glass door, hinge left

HP15WO-3-4L* fully integrated glass door, hinge left

15” outdoor Signature Series

BEER DISPENSERS

HP15TO-3-1L* solid stainless steel door, hinge left

HP15TO-3-2L* solid fully integrated door, hinge left

15” Signature Series clear ice makers (FOR

INDOOR AND OUTDOOR USE)

H50IMS-L solid stainless steel door, hinge left

H50IMS-R solid stainless steel door, hinge right

H50IMW fully integrated door, hinge reversible

* Also available hinged right (R)

24” Signature Series

24” Outdoor Signature Series

freezers

refrigerators

beverage

centers

24” Signature Series FREEZERS

HP24FS-3-1L* solid stainless steel door, hinge left

HP24FS-3-2L* solid fully integrated door, hinge left

HP24FS-3-5 stainless steel drawers

HP24FS-3-6 fully integrated drawers

24” Signature Series REFRIGERATORS

HP24RS-3-1L* solid stainless steel door, hinge left

HP24RS-3-2L* solid fully integrated door, hinge left

HP24RS-3-3L* stainless steel glass door, hinge left

HP24RS-3-4L* fully integrated glass door, hinge left

HP24RS-3-5 stainless steel drawers

HP24RS-3-6 fully integrated drawers

24” Signature Series BEVERAGE CENTER

HP24BS-3-1L* solid stainless steel door, hinge left

HP24BS-3-2L* solid fully integrated door, hinge left

HP24BS-3-3L* stainless steel glass door, hinge left

HP24BS-3-4L* fully integrated glass door, hinge left

24” Signature Series WINE RESERVE

HP24WS-3-1L* solid stainless steel door, hinge left

HP24WS-3-2L* solid fully integrated door, hinge left

HP24WS-3-3L* stainless steel glass door, hinge left

HP24WS-3-4L* fully integrated glass door, hinge left

24” Signature Series dual-zone WINE RESERVE

HP24DS-3-1L* solid stainless steel door, hinge left

HP24DS-3-2L* solid fully integrated door, hinge left

HP24DS-3-3L* stainless steel glass door, hinge left

HP24DS-3-4L* fully integrated glass door, hinge left

24” Signature Series BEER DISPENSERS

HP24TS-3-1L*1 solid SS door, hinge left (one faucet)

HP24TS-3-2L*1 solid FI door, hinge left (one faucet)

HP24TS-3-1L*2 SS glass door, hinge left (two faucet)

HP24TS-3-2L*2 FI glass door, hinge left (two faucet)

24” OUTDOOR Signature Series FREEZERS

HP24FO-3-1L* solid stainless steel door, hinge left

HP24FO-3-2L* solid fully integrated door, hinge left

HP24FO-3-5 stainless steel drawers

HP24FO-3-6 fully integrated drawers

24” OUTDOOR Signature Series REFRIGERATORS

HP24RO-3-1L* solid stainless steel door, hinge left

HP24RO-3-2L* solid fully integrated door, hinge left

HP24RO-3-3L* stainless steel glass door, hinge left

HP24RO-3-4L* fully integrated glass door, hinge left

HP24RO-3-5 stainless steel drawers

HP24RO-3-6 fully integrated drawers

24” OUTDOOR Signature Series

BEVERAGE CENTER

HP24BO-3-1L* solid stainless steel door, hinge left

HP24BO-3-2L* solid fully integrated door, hinge left

HP24BO-3-3L* stainless steel glass door, hinge left

HP24BO-3-4L* fully integrated glass door, hinge left

24” OUTDOOR Signature Series WINE RESERVE

HP24WO-3-1L* solid stainless steel door, hinge left

HP24WO-3-2L* solid fully integrated door, hinge left

HP24WO-3-3L* stainless steel glass door, hinge left

HP24WO-3-4L* fully integrated glass door, hinge left

24” OUTDOOR Signature Series

dual-zone WINE RESERVE

HP24DO-3-1L* solid stainless steel door, hinge left

HP24DO-3-2L* solid fully integrated door, hinge left

HP24DO-3-3L* stainless steel glass door, hinge left

HP24DO-3-4L* fully integrated glass door, hinge left

24” OUTDOOR Signature Series

BEER DISPENSERS

HP24TO-3-1L*1 solid SS door, hinge left (one faucet)

HP24TO-3-2L*1 solid FI door, hinge left (one faucet)

HP24TO-3-1L*2 SS glass door, hinge left (two faucet)

HP24TO-3-2L*2 FI glass door, hinge left (two faucet)

reserves

dispensers

ice makers

models Accessories series

wine

beer

Outdoor

* Also available hinged right (R)

Signature Series Sottile

Outdoor Signature Series Sottile

Signature Series SOTTILE REFRIGERATORS

HH24RS-3-1L* solid stainless steel door, hinge left

HH24RS-3-2L* solid fully integrated door, hinge left

HH24RS-3-3L* stainless steel glass door, hinge left

HH24RS-3-4L* fully integrated glass door, hinge left

Signature Series SOTTILE beverage centers

HH24BS-3-1L* solid stainless steel door, hinge left

HH24BS-3-2L* solid fully integrated door, hinge left

HH24BS-3-3L* stainless steel glass door, hinge left

HH24BS-3-4L* fully integrated glass door, hinge left

Signature Series SOTTILE wine reserves

HH24WS-3-1L* solid stainless steel door, hinge left

HH24WS-3-2L* solid fully integrated door, hinge left

HH24WS-3-3L* stainless steel glass door, hinge left

HH24WS-3-4L* fully integrated glass door, hinge left

outdoor Signature Series SOTTILE

REFRIGERATORS

HH24RO-3-1L* solid stainless steel door, hinge left

HH24RO-3-2L* solid fully integrated door, hinge left

HH24RO-3-3L* stainless steel glass door, hinge left

HH24RO-3-4L* fully integrated glass door, hinge left

outdoor Signature Series SOTTILE

beverage centers

HH24BO-3-1L* solid stainless steel door, hinge left

HH24BO-3-2L* solid fully integrated door, hinge left

HH24BO-3-3L* stainless steel glass door, hinge left

HH24BO-3-4L* fully integrated glass door, hinge left

outdoor Signature Series SOTTILE

wine reserves

HH24WO-3-1L* solid stainless steel door, hinge left

HH24WO-3-2L* solid fully integrated door, hinge left

HH24WO-3-3L* stainless steel glass door, hinge left

HH24WO-3-4L* fully integrated glass door, hinge left

48” Signature Series

48” Signature Series Wine reserves

HP48WO Wine Reserve (one temperature)

HP48WW Wine Reserve (two temperature)

* Also available hinged right (R)

24” C-Series

24” C-Series REFRIGERATORS

HC24RB-3-1L* solid stainless steel door, hinge left

HC24RB-3-2L* solid fully integrated door, hinge left

HC24RB-3-3L* stainless steel glass door, hinge left

HC24RB-3-4L* fully integrated glass door, hinge left

HC24RB-3-5 stainless steel drawers

HC24RB-3-6 fully integrated drawers

24” C-Series beverage centers

HC24BB-3-1L* solid stainless steel door, hinge left

HC24BB-3-2L* solid fully integrated door, hinge left

HC24BB-3-3L* stainless steel glass door, hinge left

HC24BB-3-4L* fully integrated glass door, hinge left

24” C-Series WINE RESERVES

HC24WB-3-1L* solid stainless steel door, hinge left

HC24WB-3-2L* solid fully integrated door, hinge left

HC24WB-3-3L* stainless steel glass door, hinge left

HC24WB-3-4L* fully integrated glass door, hinge left

24” Outdoor C-Series

24” OUTDOOR C-Series REFRIGERATORS

HC24RO-3-1L* solid stainless steel door, hinge left

HC24RO-3-2L* solid fully integrated door, hinge left

HC24RO-3-5 stainless steel drawers

HC24RO-3-6 fully integrated drawers

24” OUTDOOR C-Series BEER DISPENSERS

HC24TO-3-1L*1 solid stainless steel door, hinge left (one

faucet)

HC24TO-3-2L*1 solid fully integrated door, hinge left (one

faucet)

HC24TO-3-1L*2 stainless steel glass door, hinge left (two

faucet)

HC24TO-3-2L*2 fully integrated glass door, hinge left (two

faucet)

freezers

refrigerators

centers

reserves

dispensers

ice makers

beverage

wine

beer

24” c-Series BEER DISPENSERS

HC24TB-3-1L*1 solid stainless steel door, hinge left (one

faucet)

HC24TB-3-2L*1 solid fully integrated door, hinge left (one

faucet)

HC24TB-3-1L*2 stainless steel glass door, hinge left (two

faucet)

HC24TB-3-2L*2 fully integrated glass door, hinge left (two

faucet)

* Also available hinged right (R)

models Accessories series

Outdoor

24” ADA-Compliant Series

Accessories

24” aDA -Compliant Series freezers

HA24FB-3-1L* solid stainless steel door, hinge left

HA24FB-3-2L* solid fully integrated door, hinge left

HA24FB-3-5 stainless steel drawers

HA24FB-3-6 fully integrated drawers

24” aDA -Compliant Series REFRIGERATORS

HA24RB-3-1L* solid stainless steel door, hinge left

HA24RB-3-2L* solid fully integrated door, hinge left

HA24RB-3-3L* stainless steel glass door, hinge left

HA24RB-3-4L* fully integrated glass door, hinge left

HA24RB-3-5 stainless steel drawers

HA24RB-3-6 fully integrated drawers

24” aDA -Compliant Series

BEVERAGE CENTERS

HA24BB-3-1L* solid stainless steel door, hinge left

HA24BB-3-2L* solid fully integrated door, hinge left

HA24BB-3-3L* stainless steel glass door, hinge left

HA24BB-3-4L* fully integrated glass door, hinge left

24” aDA -Compliant Series WINE RESERVES

HA24WB-3-1L* solid stainless steel door, hinge left

HA24WB-3-2L* solid fully integrated door, hinge left

HA24WB-3-3L* stainless steel glass door, hinge left

HA24WB-3-4L* fully integrated glass door, hinge left

full extension shelves

RS-15-15R Shelf, Refrigerator, 15”

RS-15-15W Shelf, Wine, 15”

RS-24-24R Shelf, Refrigerator, 24”

RS-24-24WS Shelf, Wine, 24”

RS-24-24DW Shelf, Dual-Zone Wine, 24”

RS-24-24M Shelf, Martini Rack, 24”

RS-24-24DS Shelf, Divider Shelf, 24”

RS-18-18R Shelf, Refrigerator, Sottile

RS-18-18W Shelf, Wine, Sottile

displays/wOOD fronts for wine reserves

65629 Wine/Liquor Bottle Display Rack

67115-15 Wine Shelf Wood Faces, 15” (pack/5)

67115-24 Wine Shelf Wood Faces, 24” (pack/7)

displays/comparTment accessories

65629 Wine/Liquor Bottle Display Rack

67115-15 Wine Shelf Wood Faces, 15” (pack/6)

67115-24 Wine Shelf Wood Faces, 24” (pack/6)

67964 24” Stainless Steel Drawer Dividers (pack/3)

handles door/drawer

65305-1 Door Handle, Signature Series only

65305-4 Door Handle, 15” Signatue Series only

65305-5 Drawer Handles, 24” Signature Series only

(set/2)

67941-1 Designer Door Handle, Signature Series

only

67941-2 Designer Drawer Handles, 24”

Signature Series only (set/2)

67941-3 Designer Drawer Handles, 15”

Signature Series only (set/2)

65870 Door Handle, C-Series and ADA Series only

* Also available hinged right (R)

misc. hardware & accessory kits

(L) Factory

Door/Drawer Lock

installed

67439L Door Hinge Kit, Left

67439R Door Hinge Kit, Right

67164 6” Toe Kick and Riser, ADA Series

67360 6” Toe Kick and Riser, Sottile Series

66736-15 Casters, 15”

66736 Casters, 24”

67990-L Stacking Kit, HP15 models, left hinge

67990-R Stacking Kit, HP15 models, right hinge

67991-L Stacking Kit for HP24 models, left hinge

67991-R Stacking Kit for HP24 models, right hinge

67992-L Stacking Kit for HH24 models, left hinge

67992-R Stacking Kit for HH24 models, right hinge

67993-LR Stacking Kit for HP48 models, left hinge (on

left) and right hinge (on right)

freezers

refrigerators

beverage

centers

beer dispenser accessories

63797 Cleaning Kit (includes pump, sanitizer and

tools to clean lines)

BLC4 Sanitizer, 4 oz.

BLC32 Sanitizer, 32 oz.

63992 European Keg Coupler Kit

308-40C Faucet Lock (compatible with standard

630SS faucet on C-Series Beer Dispensers only)

67141-1 Perlick Faucet Handle

67782 Drip Pan

66585-2 Dual Faucet Tapping Kit (if sold

separately)

ice maker accessories

63802A Pump for H50 Ice Makers

68117-1 SS Toe Kick for Ice Makers (Optional)

reserves

dispensers

ice makers

models Accessories series

wine

beer

Outdoor

8300 West Good Hope Road

Milwaukee, WI 53223

phone 800.558.5592

web perlick.com/residential-products

FORM NO. 67721P

REV. 03.09.2015

Perlick HP15TS32RA, HP24TS31R2A Design manual

Specifications and Main Features

Frequently Asked Questions

User Manual
