WELCOME ASSEMBLY
Thank you for buying the KODAK CHERISH F670
Battery Operated Wi-Fi Video Home Monitor.
With your mobile device, now you can monitor your
baby sleeping in another room anywhere, anytime!
Please keep your original dated sales receipt. You will
need to produce a copy of your dated sales receipt to
conirm warranty status.
For product-related questions, please send an email
to: support@kodaksmarthome.com.
This User’s Guide covers all the information you’ll need
to get the most from your product.
Prior to using the Home Monitor, we recommend that
you fully charge the battery. This way, the device will
continue to work even if you disconnect it from the
power supply to carry it to another location.
Please read the Safety Instructions on page 12
carefully before installation.
Page | 2 Introduction
Check List:
1 x Home Unit(Camera)
1 x Power adapter for
Home Unit
HOME UNIT OVERVIEW
1
4
5
2
3
6
7
8
11
9
10
1. Camera Lens
2. IR Lens
3. Microphone
4. Pair Button
Page | 4 Home Unit Overview
5. SD Card Cover
6. Lens Frame
7. LED Power Indicator
8. Power ON/OFF Switch
9. Speaker
10. Charging Socket
11. Ball Joint Arm
LED Behaviors for Home Unit
Page | 6 Behaviors for Home Unit
Camera is OFF, battery is charging: Solid Red
Camera powering up: Solid Blue for irst few seconds
Camera locating router: Blue blinking every one second
Camera connected to router: Solid Blue
Camera in pair mode: Blinking Blue & Red
Firmware upgrading. DO NOT SWITCH OFF THE CAMERA:
Blinking Purple, Red & Blue
Camera is OFF, battery is fully charged: No Light
ESSENTIAL GUIDELINES FOR INSTALLING YOUR HOME MONITOR
• The signal strength may also be reduced by
other solid structures, like walls or electrical
equipment, such as radios, TVs, computers,
cordless or mobile phones, luorescent lights or
dimmer switches.
• Use of other 2.4 GHz products, such as wireless
networks (Wi-Fi routers), Bluetooth systems, or
microwave ovens, may cause interference with
this product, so keep the Home Monitor at least
5 feet from these types of products, or turn them
o if they appear to be causing interference.
Page | 8 Guidelines to Install Your Home Monitor
• If the signal is weak, try moving the Home
monitor to another position in the room.
TABLE OF CONTENTS
1. Safety Instructions
2. Getting Started
3. Using the Home Monitor
3.1 Setting Up
3.2 Power On or Off the Home Unit
4. Disposal of the Device (Environment)
5. Cleaning
6. Troubleshooting
7. “KODAK Smart Home” In-App Setup
Page | 10 Table of Contents
12
14
16
18
19
20
22
8. Monitoring Your Home Via App
9. Grant Access
10. Further Information
• Exclusion
• How to Obtain Warranty Service or Other
Information?
• FCC, IC And CE Regulations
• Warning
• EC Declaration of Conformity
11. Technical Speciications
34
38
42
56
1. SAFETY INSTRUCTION
WARNING:
Strangulation Hazard: Children have STRANGLED in
cords.
Keep this cord out of the reach of children (more than 3ft
away). Do not remove this tag. NEVER use extension cords
with AC Adapters. Only use the AC Adapters provided.
Home Unit Set Up & Use:
• Determine a location for the Home Unit that will
provide the best view of your monitoring area
• Place the Home Unit on a lat surface, such as a
dresser, bureau, or shelf or mount the Unit to a wall
securely using the keyhole slots in the underside of
the stand.
• NEVER place the Home Unit or cords within the cot.
This Home Monitor is compliant with all relevant standards
regarding electromagnetic ields and is, when handled
as described in the User’s Guide, safe to use. Therefore,
always read the instructions in this User’s Guide carefully
before using the device.
• Adult assembly required. Keep small parts away from
children when assembling.
Page | 12 Safety Instruction
• This product is not a toy. Do not allow children to
play with it.
• This Home Monitor is not a substitute for responsible
adult supervision.
• Keep this User’s Guide for future reference.
• Do not place the Home Unit or cords in the cot or
within reach of the sound (the Unit and cords should
be more than 3 feet away).
• Keep the cords out of reach of children.
• Do not cover the Home Monitor with a towel or
blanket.
• Test this monitor and all its functions so that you are
familiar with it prior to actual use.
• Do not use the Home Monitor in damp areas or close
to water.
• Only use the chargers and power adapters provided.
Do not use other chargers or power adapters as this
may damage the device and battery pack.
• Only insert a battery pack of the same type.
• Do not touch the plug contacts with sharp or metal
objects.
• Connect the power adapters to easily accessible
electrical outlets.
CAUTION:
• Risk of explosion if battery is replaced by an
incorrect type.
• Dispose of used batteries according to their
instructions.
2. GETTING STARTED
Home Unit Power Supply
1. Insert the small end (USB) of the Home Unit’s power
adapter (Output 5V, 1500mA) into the USB socket
in the back of the Home Unit.
2. Insert the other end of the power adapter into a
suitable electrical outlet.
3. Slide the ON/OFF switch to the ON position to
switch on the Home Unit. The power indicator
lights up in blue.
4. Slide the ON/OFF switch to the OFF position to
switch o the Home Unit. The power indicator
lights up in red, indicating that the battery is being
charged.
*IMPORTANT: Only use the supplied power
adapter.*
Page | 14 Getting Started
3. USING THE HOME MONITOR
Please read these instructions carefully, and be aware
that Home Monitor is only intended as an aid.
It is not a substitute for responsible adult supervision.
3.1 Setting Up 3.2 Power On or Off the Home Unit
• Make sure that the Home Unit is switched on.
• Slide the ON/OFF switch to the ON position to
switch on the Home Unit. The power indicator
• Place the Home Unit in a convenient location (e.g.
lights up in blue.
on a table) and point the camera lens towards the
area you want to monitor.
• Slide the ON/OFF switch to the OFF position to
switch o the Home Unit. The power indicator goes
NOTE:
• Do not place the Home Unit within reach of a child
o if the battery is not being charged, or lights up
in red if it is charging.
or baby! If there is interference with the picture or
sound, try moving the units to dierent locations,
and ensure that they are not close to any other
electrical equipment.
• If you hear a high pitched noise. This is not a fault.
The unit is designed to be operated at some
distance apart. So move the units further apart.
• It is recommended to use a Class 10 SD Card.
(Insert the SD card with the labels facing towards
you)
Page | 16 Using the Home Monitor
4. PROPER DISPOSAL OF THE DEVICE
5. CLEANING YOUR DEVICE
When the product comes to the
end of its lifecycle, you should not
dispose of it with normal household
waste. Take the product to a
collection point for the recycling
of its electrical and electronic
components.
This is indicated by the symbol on the product,
User’s Guide and/or packaging.
Some of the product materials may be reused if you
take them to a recycling point. By reusing some parts
or raw materials from used products, you make a
signiicant contribution to environmental conservancy.
Please contact your local authorities if you required
any further information on the collection points in your
area.
Please dispose of the battery pack in an
environmentally-friendly manner in accordance with
your local regulations.
Page | 18 Disposal of The Device Cleaning
Wipe your Home Monitor with a slightly moistened or
anti-static cloth. Refrain from using cleaning agents or
abrasive solvents.
Cleaning and Maintenance
• Never clean any part of the product with thinners
or other solvents and chemicals – this may result
in permanent damage to the product which is out
of the scope of coverage of the Warranty.
• Make sure that your Home Monitor stays away
from hot, humid areas or conditions, strong
sunlight and avoid moisture.
• We have made every eort to ensure that your
Home Monitor is highly reliable. Yet, if anything
goes wrong, please do not try to repair it yourself
– instead, contact our Customer Service for help.
Note:
Always turn o and disconnect the power adapter prior
to cleaning your Home Monitor.
6. TROUBLESHOOTING
Power Indicator on the Home Unit does not turn on
• Check whether the Home Unit is powered on.
• Check whether the battery is charged.
• Recharge the Home Unit by connecting it to the
power supply.
Page | 20 Troubleshooting
7. “KODAK SMART HOME” INAPP SETUP
You can connect the Home Unit with your mobile
device. Read on for a step-by-step guide.
Step 1: Download the “KODAK Smart Home” App
To download the “KODAK Smart Home” app:
• On your mobile device, visit the App Store
(iOS) or Google Play (Android)
• Search for “KODAK Smart Home”
• Download and install the “KODAK Smart
Home” app on your mobile device
Page | 22 KODAK Smart Home
Step 2: Create or Login to Your Account
If this is your irst KODAK Smart Home product,
you will be asked to create an account. To set up an
account:
• On your mobile device, open the “KODAK Smart
Home” app
• Tap SIGN UP
• Follow the in-app instructions to create a new
account
Page | 24 KODAK Smart Home
If you already have another KODAK Smart Home
product installed, simply select LOGIN:
Step 3: Add the Home Monitor to Your App
Having your Wi-Fi network name and password
handy, you will now pair your Home Monitor near your
wireless router with the “KODAK Smart Home” app:
• Select Add new device…
• Select Home Series > KODAK CHERISH F670
• The app will then walk you through the setup
process
Page | 26 KODAK Smart Home
Step 4: Get Your Home Unit
(Camera) into the Setup Mode
Step 4.1: Connect to the Camera’s Wi-Fi
from Your Phone(For IOS Only)
In the middle of the setup process, you will be
required to get your KODAK CHERISH F670 Wi-Fi
Home Monitor into the setup mode. To do this:
• Press and hold the Pair button for 3 seconds until
you hear a beep sound
• You will then hear “Start Pairing Mode,” indicating
that the Home Unit has entered the setup mode.
You may now release the Pair button and tap
Continue on your mobile device
Page | 28 KODAK Smart Home
For IOS devices, you will have to connect to the
camera’s Wi-Fi through your Wi-Fi settings of your
phone.
To do this:
• Tap the Go To Settings button to access to the
Wi-Fi settings on your phone
• In the Wi-Fi settings of your phone, connect to
KodakCam-FXXXXXXXXX and return to the
app.
Step 5: Wait While Pairing is in Progress
Your Home Monitor should now start pairing with your
mobile device automatically:
• You will hear “Setup Completed” when the Home
Monitor is successfully paired
• You may choose one of the recommended names or
rename your Home Monitor by selecting Custom.
Page | 30 KODAK Smart Home
Step 6: Test Your Home Monitor
The Home Monitor is now added to the Dashboard of
the “KODAK Smart Home” app:
• You may now run a test
• You should be able to see video from your Home
Monitor in the “KODAK Smart Home” app
Page | 32 KODAK Smart Home
8. MONITORING YOUR HOME VIA THE APP
• When you turn on the Home Unit (Camera), if you
have not yet opened the “KODAK Smart Home”
app, you’ll be alerted on your mobile device.
• You may double-click on the window to view the
screen below:
Page | 34 KODAK Smart Home
• You can pinch outwards to zoom in on the video
image, or pinch inwards to zoom out.
KODAK Smart Home Icons
You may also perform one or more of the following
actions by clicking on the MENU icon:
Menu
Click to open/close menu
Mute
Press this button to toggle
between mute/unmute
Talk
Press this button to talk to
your baby
Record a Video
Press this button to record
a video
Take a Photo
Press this button to take
a photo
Lullaby
Press this to play music to
your baby
Zoom in/out
Press this to zoom in/out
For additional help and further information about our products, visit
www.kodaksmarthome.com or email to support@kodaksmarthome.com.
Page | 36 KODAK Smart Home
Dashboard
Tap here to return to the
“Home” screen
Video Gallery
Tap here to view your
recorded footage
Events
Tap here to check history
of your actions
Add New Device
Tap to add new device
Side Menu
Press this open/close the
side menu
Camera Settings
Tap to open and edit the
settings of a device
Hints
Tap to open hints on the
operations of the app
9. GRANT ACCESS
9.1 Add Friend
You may grant access to your family and friends using
feature called “Grant Access” which is located on the
side menu of the Dashboard.
1. Click on “ ”
which was
located on the
Dashboard
Page | 38 KODAK Smart Home
2. Select “Grant
Access” under
Device
3. Click on “
which is located
on the top right
+”
4. Simply follow the
directions on the app
and click “Save” to
add friend
9.2 Edit Friend
You can edit friends and make changes the settings
anytime you want.
1. Click on the
email of the
person that
you’d like to
make changes on
Page | 40 KODAK Smart Home
2. Click “Save” to
save changes
3. Click on “
remove friend
” to
4. Click “Remove”
to conirm
10. FURTHER INFORMATION
If your product is not operating properly:
• Consult this User’s Guide or the Quick Start Guide.
• Check out our website:
www.kodaksmarthome.com
• To get in touch with our Customer Service, simply
email us at support@kodaksmarthome.com
• To order a replacement battery pack, please get in
touch with our Customer Service.
To order a replacement battery pack, contact Customer
Service. Consumer Products and Accessories Limited
Warranty (“Warranty”)
Page | 42 General Information
What does this warranty cover?
• Subject to the exclusions contained below,
eBuyNow warrants that this product or certiied
accessory sold for use with this product is
manufactured to be free from defects in materials
and workmanship under normal consumer usage
for the period outlined below. This Warranty is your
exclusive warranty and is non-transferable.
Who is covered?
• This Warranty extends only to the irst consumer
purchaser, and is non-transferable.
What will eBuyNow do?
• eBuyNow or its authorised distributor at its option
and within a commercially reasonable time, will
at no charge repair or replace any Products or
Accessories that do not conform to this Warranty.
We may use functionally equivalent reconditioned/
refurbished/ pre-owned or new Products,
Accessories or parts.
What other limitations are there?
• Some jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages,
• ANY IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY,
or limitation on the length of an implied warranty,
so the above limitations or exclusions may not
apply to you. This Warranty gives you speciic legal
rights, and you may also have other rights that vary
from one jurisdiction to another.
OTHERWISE THE REPAIR OR REPLACEMENT
PROVIDED UNDER THIS EXPRESS LIMITED
WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER, AND IS PROVIDED IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED. IN NO EVENT SHALL EBUYNOW OR
ITS AUTHORISED DISTRIBUTOR BE LIABLE,
WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF
THE PURCHASE PRICE OF THE PRODUCT OR
ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF
ANY KIND, OR LOSS OF REVENUE OR PROFITS,
LOSS OF BUSINESS, LOSS OF INFORMATION OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY
TO USE THE PRODUCTS OR ACCESSORIES TO
THE FULL EXTENT THESE DAMAGES MAY BE
DISCLAIMED BY LAW.
Products Covered Length of Coverage
Consumer Products Two (2) years from the date
of the Products’ original
purchase by the irst consumer
purchaser of the product.
Consumer Accessories
One (1) year from the date
of the Accessories’ original
purchase by the irst consumer
purchaser of the product.
Consumer Products
and Accessories that
are Repaired and
Replace
The balance of the original
warranty or for Ninety (90)
days from the date returned
to the consumer, whichever is
longer.
Page | 44 General Information
EXCLUSION
• Use of Non-eBuyNow branded Products and
• Normal Wear and Tear. Regular maintenance,
repair and replacement of parts and components
due to normal wear and tear are not covered.
• Batteries. Only batteries whose fully charged
capacity falls below 80% of their rated capacity
and batteries that leak are within the coverage of
this Warranty.
• Abuse & Misuse. Defects or damage due to:
(a) improper operation, storage, misuse or abuse,
accident or neglect, such as physical damage
(such as cracks and scratches) to the surface of
the product resulting from misuse;
(b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the
like, extreme heat, or food;
(c) use of the Products or Accessories for
commercial purposes or subjecting the Product
or any Accessory to abnormal usage or
conditions; or
(d) other acts which are not the fault of eBuyNow or
its authorised distributor, are not covered.
Page | 46 Exclusions
Accessories. Defects or damage due to the use
of non-eBuyNow branded or certiied Products or
Accessories or other peripheral equipment are not
covered.
• Unauthorised Service or Modiication. Defects
or damage due to service, testing, adjustment,
installation, maintenance, alteration, or modiication
in any way by someone other than eBuyNow, or its
authorised service centers, are not covered.
• Altered Products. Products or Accessories with
(a) serial numbers or date tags that have been
removed, altered or obliterated;
(b) broken seals or that show evidence of tampering;
(c) mismatched board serial numbers; or
(d) nonconforming or eBuyNow branded housings,
or parts, are not covered.
• Communication Services. Defects, damages, or the
failure of Products or Accessories resulting from any
communication service or signal you may subscribe
to or use with the Products or Accessories are not
covered.
HOW TO OBTAIN WARRANTY SERVICE OR OTHER INFORMATION?
To obtain service or information, please email to
support@kodaksmarthome.com.
You will receive instructions on how to ship the
Products or Accessories at your expense and risk,
to an eBuyNow Authorised Repair Center.
To obtain service, you must include:
(a) the Product or Accessory;
(b) the original proof of purchase (receipt) which
includes the date, place and seller of the
Product;
(c) if a warranty card was included in your box,
a completed warranty card showing the serial
number of the Product;
(d) a written description of the problem; and,
most importantly;
(e) your address and telephone number.
Page | 48 Warranty Service
These Terms and Conditions constitute the complete
warranty agreement between you and eBuyNow
regarding the Products or Accessories purchased
by you, and supersede any prior agreement or
representations, including representations made in
any literature publications or promotional materials
issued by eBuyNow or representations made by any
agent employee or sta of eBuyNow, that may have
been made in connection with the said purchase.
FCC, IC AND CE REGULATIONS
FCC Part l5
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the Federal Communications
Commission (FCC) rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Page | 50 FCC, IC And CE Regulations
Changes or modiications to this equipment not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
• This device complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful
interference,and
(2) this device must accept any interference
received, including interference that may cause
undesired operation. Privacy of communication
may not be ensured when using this device.
To ensure safety of users, the FCC has established
criteria for the amount of radio frequency energy
that can be safely absorbed by a user or bystander
according to the intended usage of the product. This
product has been tested and found to comply with the
FCC criteria.
This Class B digital apparatus complies with Canadian
ICES003. CAN ICES3(B)/NMB3(B)
WARNING
Changes or modiications, to this equipment not
expressively approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
The socket-outlet shall be installed near the
equipment and shall be easily accessible.
Industry Canada
This device complies with Industry Canada licenseexempt RSS standard(s): Operation is subject to the
following Two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
The term “IC:” before the certiication/registration
number only signiies that the Industry Canada
technical speciications were met. This product
meets the applicable Industry Canada technical
speciications.
Page | 52 Warning
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux
conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
FCC RF Radiation Exposure Statement Caution:
This Transmitter must be installed to provide a
separation distance of at least 20cm from all persons.
IC Radiation Déclaration d’exposition Attention:
Cet émetteur doit être installé pour fournir une
distance de séparation d’au moins 20cm de toute
personne.
EC DECLARATION OF CONFORMITY
We the manufacturer/ Importer: PerimeterSafe/eBuyNow
declare under our sole responsibility that the following
product
Type of equipment: Battery-Operated Video Home
Monitor
Model Name: F670
Brand: KODAK
complies with the essential protection requirements of
RED Directive 2014/53/EU on the approximation of the
laws of the Member States relating to Radio Spectrum
Matters, the Council Directive 2004/108/EC on the
approximation of the laws of the Member States relating
to electromagnetic compatibility (EMC) and the European
Community Directive 2006/95/EC relating to Electrical
Safety. Directive 2011/65/EC on the restriction of use of
hazardous substances (RoHS) and 2009/125/EC relating to
eco-design requirement for Energy-Related Products (ErP).
Page | 54 EC Declaration of Conformity
Assessment of compliance of the product with the
requirements relating to the essential requirements
according to Article 3 R&TTE was based on Annex III of
the Directive 1999/5/EC and the following standards:
Radio Spectrum: EN300328 V2.1.1
EMC: EN30148917 V3.2.0
EN3014891 V2.2.2
Electrical Safety: EN609502006+A11+A1+A12+A2
RF Safety: EN62311:2008
ErP: EN50564:2011
The product is labelled with the European Approval
Marking CE as shown. Any unauthorised modiication of
the product voids this Declaration.
11. TECHNICAL SPECIFICATIONS
Home Unit
Camera Sensor color CMOS 2Mpixel
Lens Viewing Angle
Power Adapter Input: 100240V AC,
Frequency Band 24002483.5 MHz
Operating Temperature 0°C - 40°C
Maximum RF Power 20dBm (for CE)
Page | 56 Technical Speciications
1080p sensor
M12 lens FOV 110 degrees
Output: 5.0V DC, 1500mA
WARNING
Use only with supplied
power supply.
Battery: 3.7V, 2100mAh
Lithium-Ion Polymer,
rechargeable battery pack
Loading...
