PERFORMANCE

Precautions

Introduction

History, Benefits & Applications

Assembly Instructions

LCD Display & Computer Program

Operating Instructions

Using Your Machine Safely & Effectively

Frequency Guide

Amplitude Guide

Exercise Guide

Specifications & Features

Troubleshooting

Warranty Card

Contraindications

CONTENTS

PRECAUTIONS

There are a few things you should do before using your PERFORMANCE exercise machine:

INSTRUCTION MANUAL:

Familiarise yourself with this manual and look it over carefully. Be sure you understand the control panel operation and the safe exercise positions before using the PERFORMANCE. This manual includes basic information on starting an exercise program, and safety tips that will assist you in reaching your goals for a healthy lifestyle. If you suffer from any of the conditions that are not suitable for use on the PERFORMANCE please confirm with your doctor before using the machine.

Neither Hypervibe nor its representatives can accept responsibility for any damage or injury incurred as a result from information presented in the manual except under the terms of the product warranty.

ELECTRICAL

The PERFORMANCE should always be turned off at the wall outlet when not in use.

The PERFORMANCE should be always stored and used in a dry area, away from moisture, fumes and flammable substances.

The PERFORMANCE should only be used for intended purposes as outlined in this manual.

Do not attempt to repair or modify any of the electrical parts or components of the

PERFORMANCE. Only a Hypervibe authorised technician should do so, unauthorised work will void warranty.

Do not use the PERFORMANCE during lightning or electrical storms.

Always turn the rear base unit power switch off before disconnecting at the wall outlet.

Do not use the machine if the electrical cord or machine shows signs of damage.

MECHANICAL

Keep fingers clear of the PERFORMANCE moving platform at all times. Never leave children unattended around the machine. The PERFORMANCE platform moves with great speed and force, and could trap the feet or hands of children.

Select a firm, flat floor area to use your machine, the best surface would be a concrete slab floor. Be aware that the machine is designed to cause vibration, and therefore will transmit some vibration into the surface it is used on. Hypervibe will not be responsible for cosmetic and structural building damage caused by the vibrations from the PERFORMANCE. Ensure you place the machine on a surface that will be unaffected by the vibration of the machine. To help absorb some of these vibrations, place the machine onto a foam or rubber mat.

INTRODUCTION

The PERFORMANCE vibration machine has been developed here in Australia by a team of health and technical professionals. This model is suitable for home through to light commercial use, and has been designed for adults of all ages and all levels of fitness and abilities. This machine should be used similarly to other gym equipment, in the sense that everyone has their own preferences and capabilities and should become aware of them.

When training, we recommend you use the PERFORMANCE for no longer than 10 minutes a day and no more than 3-4 times a week, a 10 minute session gives you maximum results. We suggest you choose a program that is best suited to the goals you wish to achieve, and start using the machine gradually. Hold each position for a maximum of 30 seconds and increase the duration if you feel comfortable doing so, this will allow your body to explore its limitations. Please watch the instructional DVD before using the PERFORMANCE.

In today's age of fast food, automation, and convenience, as a society we are becoming increasingly inactive and overweight. The team at Hypervibe, are working to promote a healthy lifestyle through regular exercise and movement. The PERFORMANCE uses Whole Body Vibration Technology, and is designed for people who want to make exercise a part of their lifestyle, but may be limited by their time, equipment or ability to do so using conventional exercise. Others may want use the machine to compliment their regular exercise routine, and/or to accelerate and maximize results.

When we train in the gym using conventional training, we do this by contracting our muscles and relaxing them over and over again with some sort of load for resistance. That load can be created with weights, hydraulic machines or by simply using your own body weight to create a load e.g. push up's. When using the PERFORMANCE platform you can induce muscle contractions up to 27 times per second. This is why a full workout on a vibration platform can be achieved in a very short period of time, and also why you should not exceed the recommended workout durations.

Of course, the PERFORMANCE is not only designed for working out, but also has numerous therapeutic uses also. At low speeds, the gentle rocking action of the platform improves your balance, and is great for the elderly and injury rehabilitation. Likewise, speeds slightly higher, can be excellent for massage, circulation and recovery. At these lower therapeutic speeds, the machine can be used more often than the recommended 10 minutes per session, 3-4 times per week.

Because of the numerous applications and benefits of the PERFORMANCE, it makes an invaluable addition to your home gym, studio or practice, which cannot be matched by conventional training apparatus.

HISTORY, BENEFITS & APPLICATIONS

Whole body vibration was developed by the Russian space program to meet the exercise needs of their Cosmonauts. The Cosmonauts were experiencing a zero gravity environment in space and their muscles and bone deteriorated when they were used much less. Researchers found that Whole Body Vibration technology, exerted forces on the cosmonauts many times that of gravity, and was used to rehabilitate their muscle and bone density.

Medical scientists and researchers then began to explore other successful applications of whole body vibration technology. Whole Body Vibration machines began to appear in hospitals and various medical clinics. Clinical studies revealed shorter recovery times for joint and muscle injuries, and other studies found whole body vibration improved flexibility and stability.

Whole Body Vibration has also expanded into the fitness industry. Athletes training with whole body vibration have documented an increase in strength, balance, speed, and endurance, and experienced swifter recovery from fatigue.

Today there is both scientific and anecdotal evidence that vibration exercise can…

Improve muscle strength and power Increase joint motion Increase muscle tone & muscle mass Increase flexibility & co-ordination Improve circulation (exercise increases blood flow) Strengthen pelvic floor muscles and improve pelvic floor function Improve balance & decrease risk of falling Improve core stability Accelerate weight loss (in conjunction with a healthy diet and lifestyle) Increase tendon strength

Improved bone density (via muscle pulling on bone) Increased jump height ability

CONTRAINDICATIONS

If you suffer from any of the following conditions please confirm with your doctor before using the machine.

Acute thrombosis Serious cardiovascular disease Metal implants Pacemaker Artificial joints Acute hernia Severe diabetes Recent infections Severe Migraines Malignant Tumors Recently placed IUD's, metal pins, or plate Recently implanted stents

Conditions that are not suitable for use on the Hypervibe machine include:

Pregnancy Epilepsy Gallbladder or kidney stones Recent wounds from an operation or surgery Recent fractures Acute inflammation/pain

If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately and consult your physician before continuing.

We do not recommend use for children unless your GP has been consulted

Possible side effects you may experience when using your hypervibe machine include; Skin lesions or blisters - these can be prevented by wearing shoes, socks or placing a foam mat on the platform.

Nausea, dizziness or temporary drop in blood pressure - Stop exercising immediately and reduce the intensity of your training program

A drop in blood sugar levels - Diabetics should be aware of this and should not exercise on an empty stomach.

ASSEMBLY INSTRUCTIONS

PARTS LIST

Item

1 2 3 4 5 6 7 8

9 10 11

C D

Part Name

Control Panel Right Handle Bar Left Handle Bar Bolt M6*50 Flat Washer 6mm Bolt M8*16 Spring Washer 8mm Flat Washer 8mm Post Vibration Absorber Base Unit

Base Unit Wire Connector Post Bottom Wire Connector Control Panel Wire Connector Post Top Wire Connector

Screw/Allen Key Wrench Allen Key Wrench

Qty

1 1 1 4 4

12 12

1 1 1

Bolt Cap Head M8*16

4 1 1 1 1

1 1

HOW TO ASSEMBLE

Step 1

Note, the vibration absorber (10) is already placed on the base, take this out and slide onto the post (9) then slide the post (9) into the base (11).”

Connect the base unit wire connector (A) to the post bottom wire connector (B).

Align the post (9) to the base unit (11), and fasten it using the screw/allen key wrench (S5), with flat washers (8), spring washers (7), and bolts (12).

See Fig.1

*Note – vibration absorber can be found already in place on the base unit.

Step 2

Place the control panel (1) near the post (9).

Connect the control panel wire connector (D) to the post top wire connector (C).

Align the control panel (1) to the post (9), and fasten it using the screw/allen key wrench (S5), with flat washers (5) and bolts (4).

See Fig. 2

Step 3

Place the right handle bar (2) near the post (9).

Align the right handle bar (2) to the post (9), and fasten it using the screw/allen key wrench (S5), with flat washers (8), spring washers (7), and bolts (6).

Place the left handle bar (3) near the post (9).

Align the left handle bar (2) to the post (9), and fasten it using the screw/allen key wrench (S5), with flat washers (8), spring washers (7), and bolts (6).

See Fig 3.

Step 4 (optional)

Attach optional stretch bands (included) at base. Adjust bands to change band resistance.

Bands will make a rattling sound on machine if not pulled tight.

See Fig 4.

*Note –

LCD DISPLAY & COMPUTER PROGRAM

Always consult a physician before beginning this or any exercise program.

The PERFORMANCE uses a sophisticated computer program designed here in Australia. The LCD display monitors the status of the machine and gives you live time and speed values. The control panel also features an audible warning alarm to warn you during program mode that the machine is about to run or pause.

Below we explain each reading on the display…..

TIME – When the TIME reading is showing, this means the digits displayed are in reference to time in minutes and/or seconds.

SPEED – When the SPEED reading is showing this means the digits displayed are in reference to the speed in Hz.

HYPERVIBE – The HYPERVIBE reading will always be displayed when the power is on. It will be the only thing displayed when the machine is in standby mode.

RUN – When the RUN reading is showing, this means the motor is running and the platform is moving. When selecting a run time during program mode, RUN will also be displayed.

PAUSE - When the PAUSE reading is showing, this means the motor is off and the platform is not moving. When selecting a pause time during program mode, PAUSE will also be displayed.

MAN – When the MAN reading is showing this means the machine is in manual mode. When in manual mode a user can select to run the machine at any selected time up to 10 minutes. The machine speed will start at 6Hz and can be adjusted from 6 to 28Hz and after the machine is running.

BALANCE – When the BALANCE reading is showing this means the machine is in balance program mode. Research suggests that low speeds of around 6Hz are best suited for balance and stability improvement. The destabilizing nature of the platform at these frequencies causes voluntary muscle contractions to react to this action.

RECOVERY – When the RECOVERY reading is showing, this means the machine is in recovery program mode. Research suggests that moderate speeds of around 11Hz are best suited for therapy purposes. At these frequencies the platform begins to cause involuntary muscle contractions, the gentle vibration is good for therapy purposes but not strong enough for training.

TRAIN – When the TRAIN reading is showing, this means the machine is in train program mode. Research suggests that higher speeds of around 19Hz start to produce training effects and have

some therapy purposes. At these frequencies the G forces produced by the platform become strong enough for strength training

TONE – When the TONE reading is showing, this means the machine is in tone program mode. Research suggests that highest speeds of around 26Hz provide numerous training and therapy benefits. At these frequencies the platform will produce the largest range of Whole Body Vibration benefits.

The PERFORMANCE computer program is what sets this machine apart from others. Each program requires pre-selection to your preferences and will start and stop “circuit style”. It is designed to target your goals, whilst giving safe and effective use.

After you select a specific program, you then tailor the program to suit your needs and ability. Hypervibe believes in safe and effective workouts, so our program allows you to select a RUN time, and then also a PAUSE time. When getting into posture position, or getting off a vibration machine, for safety reasons, it is not recommended that the machine be running. Our programs take this into account by stopping the machine and pausing between postures. Both the RUN time and PAUSE time are selected by you, and along with a countdown display on the LCD screen, an audible warning beep will sound 5 times before the machine goes into RUN or PAUSE mode. This allows you to be prepared for the machine starting, being in the correct posture, it also prepares you for the machine to stop and lets you know you only have to hold for a few more seconds.

Another reason for the PAUSE time, is that we recommend a short recovery period between postures, just as you would have a short recovery period between sets of weights at the gym. These times can be as long or as short as you set them to be.

The RUN and PAUSE time that can be selected for the four programs are as follows….

RUN

· 30 seconds X 10 sets

· 60 seconds X 10 sets

· 120 seconds X 5 sets

PAUSE

Choose 15 seconds, 30 seconds, 1 minute, 2 minute or 3 minute pause times.

It is important to note, you may not wish to run each program full a full amount of sets. Sometimes the full amount of sets is not required or is too much. If this is the case simply hit the OFF key when finished.

Exercise positions are provided with your machine, showing positions best suited for each program. Some exercises can be used on a number of programs. It is important that you do not exert yourself, if you find some postures too difficult at the program speed, either try them in a different program, or try them in manual mode in a speed you are comfortable with.

OPERATING INSTRUCTIONS

Before switching on the PERFORMANCE, ensure your machine is on a stable, solid, and dry surface. Please see assembly instructions to adjust the stability of the machine and see precautions to learn more about ideal floor construction. Plug the PERFORMANCE into any standard 240V wall outlet and switch the unit on at the base.

Standby mode

When powered up, the machine will be in standby mode. When in standby mode the LCD display will be lit up, and display the word HYPERVIBE only. The machine will return to standby mode anytime the machine is idle for more than 30 seconds.

Quick start mode

From the standby screen, select the ON/OFF key

Select the ON/OFF key again

The machine will now start at the lowest speed of 6Hz at a countdown of 10 minutes.

Use the + or – key to increase or decrease the speed.

Use the DISPLAY key to change the display from speed to time, and from time to speed.

Press the ON/OFF key at anytime to stop the machine.

Manual mode

From the standby screen, select the ON/OFF key then select the ENTER key to select manual use.

Next you will be prompted to set the UXQQLQJGXUDWLRQRIWKHPDFKLQH, from 15VHFRQGVXSWR a maximum of minutes.

Using the + or – key increase or decrease the UXQGXUDWLRQ between  seconds and  VHFRQGs.

Select the ENTER key to confirm.

Select the minutes, use the + or – key to increase or decrease the minutes by increments of 1 minute.

Select the ENTER key to confirm and start the machine.

The machine will now start at the lowest speed of 6Hz.

Use the + or – key to increase or decrease the speed.

Use the DISPLAY key to change the display from speed to time, and from time to speed.

Press the ON/OFF key at anytime to stop the machine.

Program Mode

From the standby screen, select the ON/OFF key then select the PROGRAM key and press it one or more times to cycle through the 4 programs or back to manual mode.

Select the ENTER key to select your chosen program.

Next you will be prompted to select the time you intend to run the machine for whilst holding postures, up to a maximum of 2 minutes.

Using the + or – key increase or decrease the run time between 30 seconds and 2 minutes.

Select the ENTER key to confirm.

Next you will be prompted to select the time you intend to break for between postures, up to a maximum of 3 minutes.

Select the seconds, use the + or – key to increase or decrease the time from 15 seconds up to 3 minutes.

Select the ENTER key to confirm and start the machine.

The machine will now start at the program specic speed

The LCD display will show a countdown timer for the run time you selected and will display the

word RUN. After the run countdown has ended and the audible beeps are heard, the machine will stop and the LCD display will show the word PAUSE. After the pause countdown has ended and the audible beeps are heard, the machine will restart another run countdown. This pattern will repeat until the program is complete.

Use the DISPLAY key to change the display from time to speed, and from speed to time.

Press the ON/OFF key at anytime to stop the machine.

Turn the PERFORMANCE off at the rear base unit power switch, then off at the wall when you have finished with the machine and it is not in use.

USING YOUR MACHINE SAFELY & EFFECTIVELY

The key to success when using the PERFORMANCE is using correct and safe postures, which are frequency specific to your needs. It is important to read this manual and understand the effects of whole body vibration before attempting to use this machine, as incorrect posture can modify its effectiveness and cause injury. We have developed a range of postures which allows you to train and tone muscles, develop balance and core stability, aid in the rehabilitation of injuries and improve circulation and relaxation.

The PERFORMANCE has a pivotal platform, which means the platform tilts from side to side from a central axis. When standing on the platform your feet must always be at equal distance from the central axis. When using a vibration platform the variable settings are the speed (frequency) and the amplitude. Amplitude refers to the distance your feet are travelling up and down on the platform. You can increase the amplitude by simply moving your feet further away from the center axis, and therefore increasing the force and difficulty of the posture.

We recommend you use a mat when lying on the floor in front for your comfort and protection. You may want to use a towel to cushion your body when sitting on the platform or placing your hands or elbows on the platform. Some exercises demonstrated in the manual incorporate weight bands, these do not come with the machine. You may want to incorporate hand weights or use a weight vest to maximize your workout. Always consult your doctor before starting a new exercise program.

The PERFORMANCE platform should always be stationary when getting on and off the platform. Do not attempt to change position when the platform is moving.

Remember to read the exercise guide before each session and check each position before beginning. Recheck your posture once on the platform and if you feel your muscles fatigue or you move out of the posture stop the machine and get off. It is important you hold each posture correctly as incorrect posture can cause harm and injury. Switching on your core muscles, by sucking your belly button in towards your spine, will increase core stability and help maintain your posture.

We recommend you use the PERFORMANCE for a maximum of 10 minutes a session and 3-4 times a week. Try to incorporate a ten minute workout on the PERFORMANCE into your weekly exercise schedule to help maximize your fitness levels. At lower therapy frequencies the 10 minute limitations do not apply and therapy could be used more often and for longer periods.

Before training you should select a series of exercise positions and plan to hold each position for as little as 30 seconds or up to 3 minutes. Keep your total time on the platform under 10 minutes but allow additional time for breaks between positions.

Whole Body Vibration is Frequency Specific

When using a pivotal whole body vibration platform the safe frequencies recommended for the human body range from 0-30 Hz. There are two variables which can be adjusted on a Whole Body Vibration platform, the amplitude (the distance the platform travels in a vertical direction), and also the frequency (the speed at which the platform cycles). By adjusting either of these two variables we also change things such as, the number of times per second our muscles contract, the amount G force exerted on our body, the degree of difficulty in stabilizing and the flow of blood through our body. Research and common sense tell us that different frequencies will have different effects on our body. Depending on what effects you are hoping to benefit from, will determine what frequency you should run your machine.

Frequency Optimum range for

Balance and Stability

Relaxation of muscles Blood circulation (exercise increases blood flow)

Blood circulation (exercise increases blood flow)

Mobilization of joints

Muscle strength Improved Co-ordination

Muscle strength Improved muscle tone Increased bone density (due to the effects of muscle pulling on bone)

6-8Hz

9-14Hz

15-22Hz

23-28Hz

9-14Hz RECOVERY

6-8Hz BALANCE

15-22Hz TRAIN

23-28Hz Tone

Amplitude Guide

Located in front of your feet/hands whilst on the platform on your HyperVibe machine, is an amplitude foot/hand placement guide. Throughout our instructions, we provide recommended positions for your hands or feet when performing various exercises. For example, the lower back position works best with a nice wide foot placement, so we recommend you place your feet at position 4. For other exercises, we recommend a minimum amplitude position and a greater amplitude position can be selected as per a user’s level of ability.

HyperVibe machines have 4 amplitude positions, the approximate vertical displacement for each position is shown below.

2.5mm 5mm 8mm 11mm

For some exercises, we recommend a minimum amplitude which can be increased to suit your ability. For such exercises we will give the following indication.

When you see these graphics shown in any of our exercise guides, you should use them as a guide as to where we recommend you place your hands or feet onto the platform.

Minimum

Place one foot in the middle of the platform with your knee slightly bent, then raise your other leg as shown. To ensure correct posture, keep your hips square for pelvic stability. Remember to alternate legs.

Single Leg

Place one foot in the middle of the platform with your knee slightly bent, then raise your other leg as shown. Place your hands on your hips for balance. To ensure correct posture, keep your hips square for pelvic stability. Remember to alternate legs.

Single Leg Balance

Place both of your feet on the platform at equal distance from the tilting centre axis, and rise straight up onto your toes. To ensure correct posture, keep your hips square for pelvic stability, and make sure you don’t lean forward.

Calf Raise

Place both of your feet on the platform at equal distance from the tilting centre axis, and rise straight up onto your toes. Place your hands on your hips for balance. To ensure correct posture, keep your hips square for pelvic stability, and make sure you don’t lean forward.

Calf Raise Balance

Place both of your feet on the platform at equal distance from the tilting centre axis. Bend at the knees, move your buttocks toward floor, and place your weight through your heels. Place your hands out in front of you for balance. To ensure correct posture, make sure your toes do not lift off the platform and keep your knees bent, making sure your knees do not come out past your toes. Keep your hips square for pelvic stability.

Squat Balance

Place both of your feet on the platform at equal distance from the tilting centre axis. Bend at the knees, move your buttocks toward the floor, and place your weight through your heels. To ensure correct posture, make sure your toes do not lift off the platform, and keep your knees bent, making sure your knees do not come out past your toes. Keep your hips square for pelvic stability.

Squat

EXERCISE GUIDE

Squat Balance Hips

Place both of your feet on the platform at equal distance from the platform center axis. Bend slightly at the knees and place your weight through your heels. To ensure correct posture, keep your knees slightly bent and keep your hips square for pelvic stability.

Basic Stance

6-8Hz

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

6-8Hz BALANCE

9-14Hz RECOVERY

15-22Hz TRAIN

23-28Hz TONE

Transverse Balance

Hold Position

6-8Hz

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

6-8Hz

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

Place both of your feet on the platform at equal distance from the tilting centre axis. Bend at the knees, move your buttocks toward floor, and place your weight through your heels. Place your hands on your hips for balance. To ensure correct posture, make sure your toes do not lift off the platform, and keep your knees bent, making sure your knees do not come out past your toes. Keep your hips square for pelvic stability.

Hold Position

6-8Hz

15-22Hz TRAIN

23-28Hz TONE

BALANCE 6-8Hz

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

6-8Hz

9-14Hz RECOVERY

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

6-8Hz

9-14Hz RECOVERY

15-22Hz TRAIN

23-28Hz TONE

BALANCE

Hold Position

6-8Hz BALANCE

Hold Position

Place both of your feet on the platform at 90 degrees to the front of the machine, with heels placed on the center of the tilting axis. Keep your knees slightly bent. Activate your core by drawing your belly button in toward your spine, and a ctivate your b uttocks b y gentl y squeezing.

Minimum Minimum

Minimum

Sit with your buttocks in the middle of the platform, and place your hands lightly on the side of the platform or place them on the platform next to you, and relax into the position. To ensure correct posture keep your back straight and draw your belly button in toward your spine.

Buttocks Massage

Sit in front of the platform on bent knees, place your palms on the platform as shown, and drop your head in between your arms looking down at the floor. Relax into the position. Do not drop your head too far towards the floor, and do not attempt this posture if you suffer from back or knee pain.

Preacher stretch

Place one foot in the middle of the platform with your knee slightly bent. Place your other foot on the platform and drop your heel down to feel the stretch through your calf muscle, and relax into the position. To ensure correct posture keep your hips square for pelvic stability. Do not drop your heel to extreme depths. Remember to alternate legs.

Calf Strech

9-14Hz RECOVERY

Hold Position

Quadrecep Strech

Sit with your buttocks in the middle of the platform, place the leg you want to stretch, out in front of you, and keep your knee slightly bent. Bend the other leg as shown and lean forward from the waist with a straight back, and relax into the position. To ensure correct posture, keep your back straight. Remember to alternate legs.

Hamstring Strech

Lie on your back in front of the machine, and place your calf muscles on the platform at equal distance apart as shown. Keep your pelvis still, relax into the position.

Calf Massage

Place one foot in the middle of the platform with your knee slightly bent. Curl the nonweight bearing leg so your heel is pointing towards your buttocks and hold with your hand. Place your other hand on the handle for balance and relax into the position. You should feel the stretch in the front of the thigh of the non weight bearing leg. Remember to alternate legs.

9-14Hz RECOVERY

Hold Position

9-14Hz RECOVERY

Hold Position

9-14Hz RECOVERY

Hold Position

9-14Hz RECOVERY

Hold Position

9-14Hz RECOVERY

Hold Position

Groin stretch

Sit on the machine with your buttocks in the middle of the platform. Place the soles of your feet together and rest your hands on the inside of your knees. Place slight pressure on your knees and relax into the position.

9-14Hz RECOVERY

Hold PositionHold PositionHold Position

Hamstring Massage

Quadricep Massage

9-14Hz RECOVERY

Lie on your stomach in front of the machine, and place your quadricep muscles on the platform at equal distance apart as shown. Keep your pelvis still, relax into the position.

Lie on your back in front of the machine, and place your hamstring muscles on the platform at equal distance apart as shown. Keep your pelvis still, relax into the position.

9-14Hz RECOVERY

Minimum Minimum

Deep Lunge Advanced

Place one foot in the middle of the platform with your knee slightly bent and place hands on your hips for balance. Place your other foot away from the machine as shown, with your heel slightly raised, whilst bending at the knee. Dip with your buttocks moving toward the floor, but not in a forward motion. To ensure correct posture, centre your load. This exercise should not be felt through the knee joint of the leg on the platform. Remember to alternate legs.

Sit on a chair that is high enough for both of your feet to be placed on the platform, making an angle of approximately 90 degrees through your knee. Place both of your feet on the platform at equal distance from the tilting center axis. Place your hands on your thighs and activate your core by drawing in your belly button in toward your spine. Lift one foot off the platform by bending at the knee and keep your hips square for pelvic stability.

Place both of your feet on the platform at equal distance from the platform center axis.Rest your forearms on the machine as shown and lean over the top of the console from the waist with a straight back and slowly straightne legs until you feel the vibrations on your lower back.

Lower Back

Place your palms on the platform at equal distance from the tilting center axis, then rise up onto your toes as shown. Allow your elbows to bend slightly, so your chest moves towards the platform, then hold. To ensure correct posture, keep your shoulder and neck posture as shown and keep your trunk rigid so your pelvis does not sag.

Advanced Push Up

Place your palms on the platform at equal distance from the tilting center axis, and place your legs out in front of you as shown. Drop your buttocks straight to the floor and bend at your elbows. Ensure correct posture through your shoulders by keeping them back and down, and make sure your head does not lean forward.

Tricep Dip

Modified Push Up

Hold Position

9-14Hz RECOVERY

15-22Hz TRAIN

23-28Hz TONE

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold Position

Kneel on the floor and place your palms on the platform at equal distance from the tilting center axis, as shown. Allow your elbows to bend slightly, so your chest moves towards the platform, then hold. To ensure correct posture, keep your shoulder and neck posture as shown and keep your trunk rigid so your pelvis does not sag.

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold Position

Seated

Basic Lunge

Place one foot in the middle of the platform and bend at the knee. Place your other foot away from the machine as shown, with your heel slightly raised, whilst bending at the knee. Place your hands on your hips for balance. Dip with your buttocks moving toward the floor, but not in a forward motion. To ensure correct posture, centre your load. This exercise should not be felt through the knee joint, of the leg on the platform. Remember to alternate legs. To ensure correct posture center your load with a straight back and bend your hips slightly.

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Pelvic Lift

Lie on your back in front of the machine, and place feet on the platform at equal distance from the tilting center axis as shown. Keep your pelvis still. Rise through your hips and pelvis, maintaining a rigid core.

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Single Leg Seated

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Minimum

Minimum Minimum

Minimum Minimum Minimum

Place both of your feet on the platform at equal distance from the tilting center axis. Keep knees slightly bent and for correct posture, keep hips square for pelvic stability. Grip the band with your hands, then bring your hands up to chest by bending at the elbow. To ensure correct posture, make sure your knees do not come out past your toes and keep your hips square for pelvic stability.

Bicep Curl

Advanced Tricep Dip

Place both of your feet on the platform at equal distance from the tilting center axis. Rise up onto your toes and keep your body rigid, placing your hands onto the ground as shown. To ensure correct posture, keep your shoulder and neck posture as shown and keep your trunk rigid so your pelvis does not sag. Maintain shoulder stability by squeezing your shoulder blades together gently. Remember to alternate leg

Reverse Push up

Rise up onto your toes, with your forearms on the platform at equal distance from the tilting center axis. Maintain shoulder stability by squeezing your shoulder blades together gently. To ensure correct posture, keep your shoulder and neck posture as shown and keep your trunk rigid so your pelvis does not sag.

Plank

Kneel on the floor with your forearms placed on the platform at equal distance from the tilting centre axis. Maintain shoulder stability by squeezing your shoulder blades together gently. To ensure correct posture, make sure your shoulder and neck posture is as shown, and keep trunk rigid so your pelvis does not sag.

Modified Plank

Place both of your feet on the platform at equal distance from the tilting center axis. Grip the band with your hands, and pull back by squeezing your shoulder blades together gently, whilst bending slightly at the knees. To ensure correct posture, keep your knees slightly bent, making sure your knees do not come out past your toes and keep your hips square for pelvic stability.

Shoulder Blade Retraction

Place one foot in the middle of the platform and distribute your weight evenly through your foot. Raise your other leg slightly, whilst bending at the knee for balance. Grip the band with your hands, and pull back by squeezing your shoulder blades together gently, whilst bending slightly at the knees. To ensure correct posture, keep your knees slightly bent, making sure your knees do not come out past your toes and keep your hips square for pelvic stability.

Shoulder Blade Retraction Single Leg

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Hold PositionHold Position

15-22Hz TRAIN

23-28Hz TONE

15-22Hz TRAIN

23-28Hz TONE

Hold Position

Lateral Raise

15-22Hz TRAIN

23-28Hz TONE

Hold Position

Place both of your feet on the platform at equal distance from the tilting center axis. Keep knees slightly bent and place weight through the heels. Grip the band with your hands, raise arms in a lateral movement as shown. To ensure correct posture, make sure your knees do not come out past your toes and keep your hips square for pelvic stability.

Place both of your feet on the platform at equal distance from the tilting center axis. Keep your knees slightly bent and for correct posture, keep your hips square. Grip the band with your hands and pull back by squeezing your shoulder blades together gently. To ensure correct posture make sure your knees do not come out past your toes and keep your hips square for pelvic stability. Makes sure you do not lift or shrug your shoulders while you are in this position.

Bent Over Row

Hold Position

15-22Hz TRAIN

23-28Hz TONE

Minimum Minimum

Minimum

Minimum Minimum

15-22Hz TRAIN

23-28Hz TONE

SPECIFICATIONS & FEATURES

TROUBLE SHOOTING

PROBLEM

There is no power to the LCD display.

The machine won’t turn off.

The machine is loud and rocks around on the floor.

The platform won’t move and I can hear the motor running, or there is a squealing sound.

The post is quite loose, especially at higher speeds.

SOLUTION

Check the connection to the wall outlet. Turn the power off and then back on again at the base unit. Check both the base unit wire connector, and the control panel wire connector.

The control panel LCD will always be illuminated when the power is on. If the motor will not stop, turn the power off and then back on again at the base unit.

Ensure the machine is on a firm stable surface.

The internal fan belt may require adjustment, please contact Hypervibe.

Some movement in the post is normal. It can become loose over time, and the bolts which attach the post to the base may require tightening.

Machine weight 48Kg

Maximum user weight 180Kg

Rear wheels for easy moving

Adjustable feet for stability

Anti jamming, anti static, and current overload protection

CE, ROHS and C tick certification

Input 220-240V AC~ 50Hz

900W DC motor

Platform speed to 6-28 Hz

Amplitude 11mm

G Force – 17.4 max

Steel frame construction

WARRANTY CARD

2 YEAR LIMITED HOME WARRANTY 1 YEAR LIMITED LIGHT COMMERCIAL WARRANTY

Customer Name: Date of Purchase:

Limited Product Warranty and Exclusions:

Hypervibe provides a limited warranty that covers defects of your Performance caused by material or manufacturing faults. The warranty period is for 2 years and begins on the date of purchase by the original end user. This limited warranty is made only to the original purchaser of the Hypervibe machine, and is not transferable to any subsequent owner. Hypervibe will, at its option, repair or replace the defective component(s) free of charge, provided that Hypervibe is notified of the defect during the warranty period and a dated proof of purchase is furnished. Hypervibe reserves the right to inspect the faulty component(s) and determine if the defect is due to material or manufacturing flaws. Hypervibe also reserves the right to charge for service time expended if the defect is not due to material or manufacturing flaws or is not for some other reason subject to this limited warranty.

Hypervibe does not warrant Vibration machines from any and all defects or damage caused by:

a) Normal wear and tear b) Shipping or transportation damages c) Improper installation d) Exposure to unsuitable

environmental conditions (including but not limited to damage due to lightning strikes) e) Unauthorised or abnormal use or operation f) Negligence or accidents g) Material or workmanship not provided by Hypervibe or its service agents

Hypervibe will, at its option, use new and/or reconditioned parts in performing warranty repair and in building replacement products. Hypervibe reserves the right to use parts or products of original or improved design in the repair or replacement. If Hypervibe repairs or replaces a product, its warranty continues for the remaining portion of the original warranty period or 90 days from the date of the return shipment to the customer, whichever period expires later. All replaced products and all parts removed from repaired products become the property of Hypervibe. Hypervibe products must only be serviced by an authorised service contractor, who will service the product onsite unless the product is located outside of a service area. In such cases, Hypervibe will cover costs of shipment to an authorised service agent and return shipment to the customer, via a Hypervibe selected non-expedited freight carrier within Australia and New Zealand. Hypervibe covers both parts and labour necessary to repair the product. Should a replacement machine be required, the warranty does not

cover any cost associated with installation, or reinstallation of the Hypervibe machine. This warranty is limited to home and light commercial use only. Hypervibe defines home use as, non-commercial use within a domestic residence. HyperVibe warrants all commercial use excluding:

1.A commercial premises, in which Whole Body Vibration is the primary business

2.Any commercial or public gyms

3.Commercial hiring

4.Any commercial premises where the machines are run for longer than 2hrs a day

Please email warranty@hypervibe.com.au for any further questions regarding the warranty.

Performance HyperVibe User Instructions

Specifications and Main Features

Frequently Asked Questions

User Manual
