Version 1.1
Revision Date: October 15, 2014
www.perfectron.com
OXY5737A
Intel® QM87 EBX SBC
User’s Manual
User’s Manual
OXY5737A User’s Manual V1.1
www.perfectron.com
Safety Information
1. Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables for the devices
are unplugged before the signal cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices could interrupt
the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
• If you are not sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or
your local distributor.
2. Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals that came
with the package.
• Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
• Place the product on a stable surface.
• If you encounter any technical problems with the product, contact your local distributor
Statement
• All rights reserved. No part of this publication may be reproduced in any form or by any means, without
prior written permission from the publisher.
• All trademarks are the properties of the respective owners.
• All product specifications are subject to change without prior notice
1
OXY5737A User’s Manual V1.1
www.perfectron.com
Revision History
Revision Date (yyyy/mm/dd) Changes
Version 1.0
2014/09/30
Initial release
Version 1.1 2014/10/15 BIOS function PCH IO configuration
Packing list
□ OXY5737A EBX
□ CD (Driver + user's manual)
Optional Accessories
• 1 x Terminal block
• Cable kit for OXY5737A: 1 x SATA, 1 x SATA power, 2 x COM
If any of the above items is damaged or missing, please contact your local
distributor.
2
OXY5737A User’s Manual V1.1
www.perfectron.com
Table of Contents
Safety Information ............................................................................................................................................. 1
1. Electrical safety ...................................................................................................................................... 1
2. Operation safety ..................................................................................................................................... 1
Statement ........................................................................................................................................................... 1
Revision History .................................................................................................................................................. 2
Packing list .......................................................................................................................................................... 2
Optional Accessories .......................................................................................................................................... 2
Table of Contents ............................................................................................................................................... 3
Chapter 1: Product Information ......................................................................................................................... 7
1.1 Block Diagram ...................................................................................................................................... 7
1.2 Key Features ......................................................................................................................................... 8
1.3 Board Placement ................................................................................................................................ 10
1.4 Mechanical Drawings ......................................................................................................................... 11
Chapter 2: Jumpers and Connectors ................................................................................................................ 12
2.1 Jumpers and connectors list............................................................................................................... 12
2.2 Jumper Settings .................................................................................................................................. 13
DIMMA1: DDR3 SO DIMM Socket .................................................................................................... 13
LVDS1: LVDS CONNECTOR ................................................................................................................ 14
MCARD1: Mini PCIE Card Slot<COLAY M SATA> ............................................................................... 14
MCARD_SEL1: mSATA and mPCIE selection ..................................................................................... 15
MINI MPCIE: Mini PCIE Card Slot ..................................................................................................... 15
SATA-CON CN3: Serial ATA Connectors ............................................................................................ 16
SATA-CON CN5: Serial ATA Connectors ............................................................................................ 16
PWR_S4P_H CN4: SATA POWER ....................................................................................................... 16
PWR_S4P_H CN6: SATA POWER ....................................................................................................... 16
LAN1: Intel I218LM ........................................................................................................................... 16
LAN2: Intel I210IT ............................................................................................................................. 16
LAN_SEL3: StackPC/I218 selection................................................................................................... 16
LAN_SEL2: StackPC/I210 selection................................................................................................... 17
F_USB1: USB..................................................................................................................................... 17
USB3.0 CN18: USB*2 ........................................................................................................................ 17
USB3.0 CN19: USB*2 ........................................................................................................................ 17
MIC 1: Audio Jacks Connector .......................................................................................................... 18
LOUT 1: Audio Jacks Connector ....................................................................................................... 18
DIO1: Digital I/O Box Head ............................................................................................................... 18
SW2: POWER On/Off Switch ............................................................................................................ 18
3
OXY5737A User’s Manual V1.1
www.perfectron.com
SW2: switch setting .......................................................................................................................... 18
PWRIN1: DC Adapter Power Input ................................................................................................... 19
CN11: Update BIOS .......................................................................................................................... 19
DP1: DISPLAY PORT .......................................................................................................................... 19
DP2: DISPLAY PORT .......................................................................................................................... 20
DVI: DVI-I .......................................................................................................................................... 20
SIM_CARD1: SIM card socket ........................................................................................................... 20
COM1: RS232/422/485 with 5V/12V selectable .............................................................................. 20
JV2,3: COM1 RS232/422/485 jumper setting .................................................................................. 21
JV4: COM1 RS485 autoflow setting ................................................................................................. 21
JP12: COM1 5V/12V selection .......................................................................................................... 21
JV2,3,4 and JP12 location: ................................................................................................................ 22
COM2: RS232/422/485 with 5V/12V selectable .............................................................................. 22
JV6,7: COM2 RS232/422/485 jumper setting .................................................................................. 22
JV5: COM2 RS485 autoflow setting ................................................................................................. 23
JP13: COM2 5V/12V selection .......................................................................................................... 23
JV5,6,7 and JP13 location ................................................................................................................. 23
COM3: RS232 with 5V/12V selectable ............................................................................................. 24
JP7: COM3 +12V/+5V selection ........................................................................................................ 24
COM4: RS232 with 5V/12V selectable ............................................................................................. 24
JP14: COM4 +12V/+5V selection ...................................................................................................... 25
COM5: RS232 with 5V/12V selectable ............................................................................................. 25
JP15: COM5 +12V/+5V selection ...................................................................................................... 25
COM6: RS232 with 5V/12V selectable ............................................................................................. 26
JP16: COM6 +12V/+5V selection ...................................................................................................... 26
DC Jack ............................................................................................................................................. 26
CON A1: CONNECTOR A TOP ............................................................................................................ 27
CPU FAN: CPU FAN CONNECTOR ...................................................................................................... 27
SYSFAN1: SYSTEM FAN CONNECTOR ................................................................................................ 27
JV8,9,10,11: LVDS Panel selection jumper setting ........................................................................... 28
JV12: LVDS_VDD power select ......................................................................................................... 29
JV8,9,10,11,12 location: ................................................................................................................... 29
FPE1: StackPC FPE Top Connector .................................................................................................... 30
LED1: LAN1 LED STATUS ................................................................................................................... 31
LED2: LAN2 LED STATUS ................................................................................................................... 31
LED3: POWER/HDD LED ................................................................................................................... 31
SW1: POWER BUTTON ..................................................................................................................... 31
JBKL1: JBKL1: Inverter connector ..................................................................................................... 31
4
OXY5737A User’s Manual V1.1
www.perfectron.com
FP1: Front Panel ............................................................................................................................... 32
FP3: LAN LED .................................................................................................................................... 32
Plug LED cable to FP3 pin header .................................................................................................... 32
Chapter 3: Getting Started ............................................................................................................................... 33
3.1 Installing System Memory .................................................................................................................. 33
Chapter 4: AMI BIOS UTILITY ........................................................................................................................... 35
4.1 Starting ............................................................................................................................................... 35
4.2 Navigation Keys .................................................................................................................................. 35
4.3 Main Menu ......................................................................................................................................... 36
4.4 Advanced Menu ................................................................................................................................. 37
4.4.1 PCI Subsystem Settings ........................................................................................................... 38
PCI Express Settings ................................................................................................................. 39
4.4.2 ACPI Settings ........................................................................................................................... 40
4.4.3 CPU configuration ................................................................................................................... 41
4.4.4 SATA Configuration .................................................................................................................. 46
Software Feature Mask Configuration ..................................................................................... 48
4.4.5 Intel Rapid Start Technology ................................................................................................... 50
4.4.6 PCH-FW Configuration ............................................................................................................ 50
Firmware Update Configuration .............................................................................................. 51
4.4.7 Intel Anti-Theft Technology Configuration .............................................................................. 51
4.4.8 AMT Configuration .................................................................................................................. 52
4.4.9 USB Configuration ................................................................................................................... 54
4.4.10 IT8786 Super IO Configuration.............................................................................................. 55
Serial Port 1 Configuration ....................................................................................................... 55
Serial Port 2 Configuration ....................................................................................................... 56
Serial Port 3 Configuration ....................................................................................................... 56
Serial Port 4 Configuration ....................................................................................................... 56
Serial Port 5 Configuration ....................................................................................................... 56
Serial Port 6 Configuration ....................................................................................................... 56
4.4.11 IT8786 HW Monitor .............................................................................................................. 57
4.4.12 Serial Port Console Redirection ............................................................................................ 57
Console Redirection Setting ..................................................................................................... 58
4.4.13 Network Stack ....................................................................................................................... 58
4.4.14 Intel I210 Gigabit Network Connection ................................................................................ 59
4.5 Chipset ............................................................................................................................................... 60
4.5.1 PCH IO configuration ............................................................................................................... 60
PCI Express Configuration ........................................................................................................ 61
PCI Express Root Port1 ..................................................................................................... 61
5
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port2 ..................................................................................................... 62
PCI Express Root Port3 ..................................................................................................... 63
PCI Port 4 is assigned to LAN............................................................................................ 63
PCI Express Root Port5: .................................................................................................... 64
PCI Express Root Port6 ..................................................................................................... 65
PCI Express Root Port7 ..................................................................................................... 66
PCI Express Root Port8 ..................................................................................................... 67
USB Configuration .................................................................................................................... 67
PCH Azalia Configuration. ........................................................................................................ 67
4.5.2 System AGENT SA .................................................................................................................... 69
Graphics Configuration ............................................................................................................ 69
LCD Control ...................................................................................................................... 70
Memory Configuration ............................................................................................................. 70
GT- Power Management Control ............................................................................................. 70
4.6 Boot .................................................................................................................................................... 71
CSM16 Parameters ................................................................................................................... 72
4.7 Security .............................................................................................................................................. 72
4.8 Save and Exit ...................................................................................................................................... 73
6
OXY5737A User’s Manual V1.1
www.perfectron.com
Chapter 1: Product Information
1.1 Block Diagram
7
OXY5737A User’s Manual V1.1
www.perfectron.com
1.2 Key Features
System
CPU Type
Intel® Haswell Core™ i7/i3, BGA type
Core i7-4700EQ (4C x 2.4/1.7GHz), 6M Cache, (47W/37W)
Core i3-4102E (2C x 1.6 GHz), 3M Cache (25W)
Celeron 2000E (2C x 2.2 GHz), 2M Cache (37W)
Chipset
Intel® Haswell QM87 PCH
Memory Type
1 x DDR3 1600 Swissbit XR-DIMM up to 8 GB with ECC
BIOS
AMI® UEFI BIOS
Supoer I/O
ITE8786
Watchdog
1-255 sec. or 1-255 min. software programmable
can generate system reset
Expansion Slot
2 x mPCIe (1 x SIM card, 1 x colay with mSATA)
Display
Chipset
Integrated GFX in Haswell processor
DVI-I
Yes (Max. resolution 2048 x 1536)
LVDS
Dual channel 24-bit LVDS
Display Type
2 x DP, LVDS, DVI-I (DVI-D+VGA)
Audio
Codec
Realtek ALC887 High Definition Audio Codec
Ethernet
Chipset
Intel® I210IT & i218-LM GbE
WOL
Yes
Boot from LAN
Yes for PXE
Rear I/O
DP 1 DVI-D
1
Ethernet
2 x RJ45
COM Port
1 x RS232/422/485 with 5V/12V selectable
USB
2 x USB 3.0
Audio
1 x MIC, 1 x Line out
Power Connector
1 (Terminal Block)
Internal I/O
Touch Panel
1 x 5-pin
Front Panel
1 (2 x 5-pin)
Smart Fan
1 x CPU Fan, 1 x System Fan
Power Connector
2 (1 x 4-pin/ 2 x 2-pin)
SATA
2 x SATAIII (6 Gb/s)
USB
2 x USB 2.0 by pin header
COM
5 x COM ports: 4 x RS232, 1 x RS232/422/485, all with 5V/12V
selectable
LVDS
2 x 15-pin
DIO
2 x 10-pin, 8 in/8 out with isolation
SIM card holder
1
8
OXY5737A User’s Manual V1.1
www.perfectron.com
Power Requirements
Input Voltage
9 to 36 VDC (4-pin terminal block for V+, V+, V-, V-)
Power Consumption
without LVDS output
With No Load on 4
USB ports
4A@9VDC, 45W
1.6A@24VDC, 45W
1.1A@36VDC, 45W
With Full Load on 4
USB Ports
5A@9VDC, 45W
1.875A@24VDC, 45W
1.25A@36VDC, 45W
Mechanical and Environment
Form Factor
EBX
Power Type
9V to 36V DC-in, AT/ATX mode supports with power delay on/off
Dimension
203 x 146 mm (5.75" x 8")
Operating Temp.
-40 to 85°C
Storage Temp.
-40 to 85°C
Relative Humidity
10% to 90%, non-condensing
*All specifications and photos are subject to change without notice.
9
OXY5737A User’s Manual V1.1
www.perfectron.com
1.3 Board Placement
10
OXY5737A User’s Manual V1.1
www.perfectron.com
1.4 Mechanical Drawings
11
OXY5737A User’s Manual V1.1
www.perfectron.com
Chapter 2: Jumpers and Connectors
2.1 Jumpers and connectors list
Label
Function
BAT1
BATTERY connector
DIMMA1
DDR3 SO DIMM Socket
LVDS1
LVDS CONNECTOR
MCARD1
Mini PCIE Card Slot<COLAY M SATA>
MINI MPCIE
Mini PCIE Card Slot
SATA-CON CN3
Serial ATA Connectors
SATA-CON CN5
Serial ATA Connectors
PWR_S4P_H CN4
SATA POWER
PWR_S4P_H CN6
SATA POWER
LAN1
INTEL I218LM
LAN2
INTEL I210IT
F_USB1
USB2.0
CN18
USB3.0 X2
CN19
USB3.0 X2
MIC 1
Audio Jacks Connector
LOUT1
Audio Jacks Connector
DIO1
Digital I/O Box Head
SW2
POWER On/Off Switch
PWRIN1
DC Adapter Power Input
CN11
UPDATE BIOS
DP1
DISPLAY PORT
DP2
DISPLAY PORT
DVI
DVI-I
SIM_CARD_1
SIM card socket
JP7
COM3 +12/+5V selection
JP14
COM4 +12/+5V selection
JP15
COM5 +12/+5V selection
JP16
COM6 +12/+5V selection
COM1
RS232/422/485 with 5V/12V selectable
COM2
RS232/422/485 with 5V/12V selectable
COM3
RS232 with 5V/12V selectable
COM4
RS232 with 5V/12V selectable
COM5
RS232 with 5V/12V selectable
COM6
RS232 with 5V/12V selectable
DC JACK
DC connector
CON A1
CONNECTOE A TOP
CPU FAN
CPU FAN CONNECTOR
SYSFAN1
SYSTEM FAN CONNECTOR
JV8, JV9, JV10, JV11
LVDS Panel selection jumper setting
JV12
LVDS_VDD power select
LAN_SEL3
StackPC/I218 selection
LAN_SEL2
StackPC/I210 selection
MCARD_SEL1
mSATA and mPCIE selection
JV2, JV3
COM1 RS232/422/485 jumper setting
JV4
COM1 RS485 autoflow setting
JP12
COM1 5V/12V selection
JV7.JV6
COM2 RS232/422/485 jumper setting
JV5
COM2 RS485 autoflow setting
JP13
COM2 5V/12V selection
FPE1
StackPC FPE Top Connector
12
OXY5737A User’s Manual V1.1
www.perfectron.com
LED1
LAN1 LED STATUS
LED2
LAN2 LED STATUS
LED3
POWER/HDD LED
SW1
POWER BUTTON
FPR5
RESET POWER BUTTON
JBKL1
LVDA POWER BOX HEADER
FP1
Front Panel
FP3
LAN LED
2.2 Jumper Settings
DIMMA1: DDR3 SO DIMM Socket
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
1
VSS
41
DQ16
81
VSS
121
CK1
161
DQS4#
201
VSS 2 VSS
42
VSS
82
DM8
122
A1
162
VSS
202
DQ55
3
VSS
43
DQ17
83
DQS8#
123
CK1#
163
DQS4
203
DQ50
4
VSS
44
VREFDQ
84
VSS
124
VDD
164
DM4
204
VSS 5 DQ0
45
VSS
85
DQS8
125
VDD
165
VSS
205
DQ51
6
DQ4
46
NC(TEST)
86
CB6
126
CK0
166
VSS
206
DQ60
7
DQ1
47
DQS2#
87
VSS
127
VREFCA
167
DQ34
207
VSS 8 DQ5
48
VSS
88
CB7
128
CK0#
168
DQ38
208
DQ61
9
VSS
49
DQS2
89
CB2
129
PAR_IN
169
DQ35
209
DQ56
10
VSS
50
DM2
90
VSS
130
VDD
170
DQ39
210
VSS
11
DQS0#
51
VSS
91
CB3
131
VDD
171
VSS
211
DQ57
12
DM0
52
VSS
92
RESET#
132
EVENT#
172
VSS
212
DM7
13
DQS0
53
DQ18
93
VSS
133
A10
173
DQ40
213
VSS
14
VSS
54
DQ22
94
ERR_OUT#
134
A0
174
DQ44
214
VSS
15
VSS
55
DQ19
95
VTT
135
BA0
175
DQ41
215
DQS7#
16
DQ6
56
DQ23
96
VTT
136
VDD
176
DQ45
216
DQ62
17
DQ2
57
VSS
97
CKE0
137
VDD
177
VSS
217
DQS7
18
DQ7
58
VSS
98
CKE1
138
BA1
178
VSS
218
DQ63
19
DQ3
59
DQ24
99
VDD
139
WE#
179
DQS5#
219
VSS
20
VSS
60
DQ28
100
VDD
140
VDD
180
DM5
220
VSS
21
VSS
61
DQ25
101
BA2
141
CAS#
181
DQS5
221
DQ58
22
DQ12
62
DQ29
102
A15
142
RAS#
182
VSS
222
VDD_SPD
23
DQ8
63
VSS
103
VDD
143
VDD
183
VSS
223
DQ59
24
DQ13
64
VSS
104
A14
144
S0#
184
DQ46
224
SA0
25
DQ9
65
DQS3#
105
A11
145
S1#
185
DQ42
225
VSS
26
VSS
66
DM3
106
VDD
146
VDD
186
DQ47
226
SA1
27
VSS
67
DQS3
107
A7
147
ODT1
187
DQ43
227
SA2
28
DM1
68
VSS
108
A12
148
ODT0
188
VSS
228
SCL
29
DQS1#
69
VSS
109
VDD
149
VDD
189
VSS
229
VSS
30
VSS
70
DQ30
110
A9
150
A13
190
DQ52
230
SDA
31
DQS1
71
DQ26
111
A5
151
S3#
191
DQ48
231
SATA_TX0
32
DQ14
72
DQ31
112
VDD
152
VDD
192
DQ53
232
VSS
33
VSS
73
DQ27
113
A4
153
VSS
193
DQ49
233
SATA_TX0#
34
DQ15
74
VSS
114
A8
154
S2#
194
VSS
234
SATA_TX1#
35
DQ10
75
VSS
115
VDD
155
DQ32
195
VSS
235
VSS
36
VSS
76
CB4
116
A6
156
VSS
196
DM6
236
SATA_TX1
37
DQ11
77
CB0
117
A2
157
DQ33
197
DQS6#
237
VTT
38
DQ20
78
CB5
118
VDD
158
DQ36
198
VSS
238
VSS
39
VSS
79
CB1
119
VDD
159
VSS
199
DQS6
239
VTT
40
DQ21
80
VSS
120
A3
160
DQ37
200
DQ54
240
VTT
13
OXY5737A User’s Manual V1.1
www.perfectron.com
LVDS1: LVDS CONNECTOR
PIN
DEFINITION
PIN
DEFINITION
1
LVDS_BCLK
2
GND
3
LVDS_BCLK#
4
LVDS_A3
5
GND
6
LVDS_A3#
7
LVDS_B3
8
GND
9
LVDS_B3#
10
LVDS_ACLK
11
LVDS_B2
12
LVDS_ ACLK #
13
LVDS_B2#
14
GND
15
LVDS_B1
16
LVDS_A2
17
LVDS_B1#
18
LVDS_A2#
19
LVDS_B0
20
LVDS_A1
21
LVDS_B0#
22
LVDS_A1#
23
GND
24
LVDS_A0
25
LVDS_DCC_SC
26
LVDS_A0#
27
LVDS_DCC_SD
28
GND
29
LVDS_VDD
(define by JV12)
30
LVDS_VDD
(define by JV12)
MCARD1: Mini PCIE Card Slot<COLAY M SATA>
PIN
DEFINITION
PIN
DEFINITION
1
WAKE#
2
3.3VAUX
3
COEX1
4
GND
5
COEX2
6
1.5V
7
CLKREQ#
8
UIM_PWR
9
GND
10
UIM_DATA
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_RESET
15
GND
16
UIM_VPP
17
Reserved
18
GND
19
Reserved
20
W_Disable#
21
GND
22
PERST#
23
PERn0
24
+3.3Vaux
25
PERp0
26
GND
27
GND
28
1.5V
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
LED_WWAN#
43
GND
44
LED_WLAN#
45
Reserved
46
LED_WPAN#
47
Reserved
48
1.5V
49
Reserved
50
GND
51
Reserved
52
3.3VAUX
14
OXY5737A User’s Manual V1.1
www.perfectron.com
MCARD_SEL1: mSATA and mPCIE selection
Jumper
Function description
Setting
1-2
mPCIE
2-3
mSATA
Default setting: 2-3
MINI MPCIE: Mini PCIE Card Slot
PIN
DEFINITION
PIN
DEFINITION
1
WAKE#
2
3.3V
3
Reserved
4
GND
5
Reserved
6
1.5V
7
CLKREQ#
8
UIM_PWR
9
GND
10
UIM_DATA
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_RESET
15
GND
16
UIM_VPP
17
Reserved
18
GND
19
Reserved
20
W_Disable#
21
GND
22
PERST#
23
PERn0
24
3.3Vaux
25
PERp0
26
GND
27
GND
28
1.5V
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
Reserved
38
USB_D+
39
Reserved
40
GND
41
Reserved
42
LED_WWAN#
43
Reserved
44
LED_WLAN#
45
Reserved
46
LED_WPAN#
47
Reserved
48
1.5V
49
Reserved
50
GND
51
Reserved
52
3.3V
15
OXY5737A User’s Manual V1.1
www.perfectron.com
SATA-CON CN3: Serial ATA Connectors
SATA-CON CN5: Serial ATA Connectors
PIN
DEFINITION
1
GND
2
TXP 3 TXN
4
GND
5
RXN
6
RXP
7
GND
PWR_S4P_H CN4: SATA POWER
PWR_S4P_H CN6: SATA POWER
PIN
DEFINITION
1
12V
2
GND
3
GND
4
5VS
LAN1: Intel I218LM
LAN2: Intel I210IT
LAN1
LAN2
PIN
DEFINITION
PIN
DEFINITION
A1
I218_LAN1_MDI0_DP
B1
LAN2_MDIP0
A2
I218_LAN1_MDI0_DN
B2
LAN2_MDIN0
A3
I218_LAN1_MDI1_DP
B3
LAN2_MDIP1
A4
I218_LAN1_MDI1_DN
B4
LAN2_MDIN1
A7
I218_LAN1_MDI2_DP
B7
LAN2_MDIP2
A8
I218_LAN1_MDI2_DN
B8
LAN2_MDIN2
A9
I218_LAN1_MDI3_DP
B9
LAN2_MDIP3
A10
I218_LAN1_MDI3_DN
B10
LAN2_MDIN3
LAN_SEL3: StackPC/I218 selection
Jumper
Function description
Setting
1-2
STACK PC
2-3
I218
Default setting: 2-3
16
OXY5737A User’s Manual V1.1
www.perfectron.com
LAN_SEL2: StackPC/I210 selection
Jumper
Function description
Setting
1-2
STACK PC
2-3
I210
Default setting: 2-3
F_USB1: USB
PIN
DEFINITION
PIN
DEFINITION
1
USBV4
2
USBV5
3
USBD4-
4
USBD5-
5
USBD4+
6
USBD5+
7
GND
8
GND
9
NC
10
GND
USB3.0 CN18: USB*2
LOWER USB
UPPER USB
PIN
DEFINITION
PIN
DEFINITION
1
USB_VCC0
10
USB_VCC1
2
USBD2-
11
USBD3-
3
USBD2+
12
USBD3+
4
GND
13
GND
5
USB_SSRX1N_C
14
USB_SSRX2N_C
6
USB_SSRX1P_C
15
USB_SSRX2P_C
7
GND
16
GND
8
USB3TN1
17
USB3TN2
9
USB3TP1
18
USB3TP2
USB3.0 CN19: USB*2
LOWER USB
UPPER USB
PIN
DEFINITION
PIN
DEFINITION
1
USB_VCC2
10
USB_VCC3
2
USBD0-
11
USBD1-
3
USBD0+
12
USBD1+
4
GND
13
GND
5
USB_SSRX3N_C
14
USB_SSRX4N_C
6
USB_SSRX3P_C
15
USB_SSRX4P_C
7
GND
16
GND
8
USB3TN3
17
USB3TN4
9
USB3TP3
18
USB3TP4
17
OXY5737A User’s Manual V1.1
www.perfectron.com
MIC 1: Audio Jacks Connector
PIN
DEFINITION
5
MIC_L
4
GND
3
NC 2 MIC1_R
1
GND
LOUT 1: Audio Jacks Connector
PIN
DEFINITION
5
FRONT_L
4
GND
3
NC 2 FRONT_R
1
GND
DIO1: Digital I/O Box Head
PIN
DEFINITION
PIN
DEFINITION
1
DIO0
2
DIO1
3
DIO2
4
DIO3
5
DIO4
6
DIO5
7
DIO6
8
DIO7
9
DIO8
10
DIO9
11
DIO10
12
DIO11
13
DIO12
14
DIO13
15
DIO14
16
DIO15
17
5VS
18
GND
19
5VS
20
GND
SW2: POWER On/Off Switch
PIN
DEFINITION
PIN
DEFINITION
1
AT/ATX
16
GND
2
DELAY_SETUP
15
GND
3
ON_TIME_0
14
GND
4
ON_TIME_1
13
GND
5
OFF_TIME_0
12
GND
6
OFF_TIME_1
11
GND
7
STACK0
10
GND
8
STACK1
9
GND
SW2: switch setting
Power on mode
PIN1
AT
switch to left
ATX
switch to right
PIN2
Delay on/off (AT mode)
switch to right: enable
switch to left: disable
18
OXY5737A User’s Manual V1.1
www.perfectron.com
ON TIME
PIN3
PIN4
4 S
0 0 8 S
0 1 12 S
1 0 16 S
1
1
0= switch to right
1= switch to left
OFF TIME
PIN5
PIN6
30 S
0 0 45 S
0 1 60 S
1 0 90 S
1
1
0= switch to right
1= switch to left
PWRIN1: DC Adapter Power Input
PIN
DEFINITION
1
+VIN
2
+VIN
3
GND
4
GND
CN11: Update BIOS
DP1: DISPLAY PORT
PIN
DEFINITION
PIN
DEFINITION
1
DPC_LANEP0
2
GND
3
DPC_LANEN0
4
DPC_LANEP1
5
GND
6
DPC_LANEN1
7
DPC_LANEP2
8
GND
9
DPC_LANEN2
10
DPC_LANEP3
11
GND
12
DPC_LANEN3
13
DDIC_DDC_AUX_SEL
14
GND
15
DPC_AUXP
16
GND
17
DPC_AUXN
18
DPC_DET
19
GND
20
DPC_PWR
PIN
DEFINITION
PIN
DEFINITION
1
SPI_CE0#_F
2
VCC
3
SPI_SI_F
4
-SPI_HOLD
5
SPI_WP#
6
SPI_CLK_F
7
GND
8
SPI_SO_F
19
OXY5737A User’s Manual V1.1
www.perfectron.com
DP2: DISPLAY PORT
PIN
DEFINITION
PIN
DEFINITION
1
DPD_LANEP0
2
GND
3
DPD_LANEN0
4
DPD_LANEP1
5
GND
6
DPD_LANEN1
7
DPD_LANEP2
8
GND
9
DPD_LANEN2
10
DPD_LANEP3
11
GND
12
DPD_LANEN3
13
DDID_DDC_AUX_SEL
14
GND
15
DDID_DDCCLK_AUX_P
16
GND
17
DDID_DDCDATA_AUX_N
18
DPD_DET
19
GND
20
DPD_PWR
DVI: DVI-I
PIN
DEFINITION
PIN
DEFINITION
1
TMDS Data2-
13
NC 2 TMDS Data2+
14
+5V Power
3
GND
15
GND
4
NC
16
Hot Plug Detect
5
NC
17
TMDS Data0-
6
DDC Clock
18
TMDS Data0+
7
DDC Data
19
GND
8
Analog VSYNC
20
NC 9 TMDS Data1-
21
NC
10
TMDS Data1+
22
GND
11
GND
23
TMDS Clock+
12
NC
24
TMDS Clock-
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog HYNC
C5
Analog GND0
C6
Analog GND1
SIM_CARD1: SIM card socket
PIN
DEFINITION
1
VCC
2
RESET
3
CLOCK
4
GND
5
VPP
6
DATA
COM1: RS232/422/485 with 5V/12V selectable
PIN
DEFINITION
PIN
DEFINITION
1
DCD1#_OPTO
6
DSR1#_OPTO
2
RXD1_OPTO
7
RTS1#_OPTO
3
TDX1_OPTO
8
CTS1#_OPTO
4
DRT1#_OPTO
9
COM1P9SEL
5
GND
10
GND
20
OXY5737A User’s Manual V1.1
www.perfectron.com
JV2,3: COM1 RS232/422/485 jumper setting
No.
Function Description
JV3
JV2
1
Loopback
(Default)
2
RS232
3
RS485 Half-Duplex
4
RS485/422 Full Duplex
JV4: COM1 RS485 autoflow setting
Jumper
Function description
Setting
1-2
Auto flow control disable
2-3
Auto flow control enable
Default setting: 1-2
JP12: COM1 5V/12V selection
PIN
DEFINITION
PIN
DEFINITION
1
RI1#_OPTO
2
COM1P9SEL
3
5V 4 COM1P9SEL
5
12V
6
COM1P9SEL
21
OXY5737A User’s Manual V1.1
www.perfectron.com
JV2,3,4 and JP12 location:
COM2: RS232/422/485 with 5V/12V selectable
PIN
DEFINITION
1
5VS 2 GND
3
COM2P9SEL
4
DTR2#_OPTO
5
CTS2#_OPTO
6
TXD2_OPTO
7
RTS2#_OPTO
8
RXD2_OPTO
9
DSR2#_OPTO
10
DCD2#_OPTO
JV6,7: COM2 RS232/422/485 jumper setting
No.
Function Description
JV6
JV7
1
Loopback
(Default)
2
RS232
3
RS485 Half-Duplex
4
RS485/422 Full-Duplex
22
OXY5737A User’s Manual V1.1
www.perfectron.com
JV5: COM2 RS485 autoflow setting
Jumper
Function description
Setting
1-2
Auto flow control
disable
2-3
Auto flow control
enable
Default setting: 1-2
JP13: COM2 5V/12V selection
PIN
DEFINITION
PIN
DEFINITION
1
RI2#_OPTO
2
COM2P9SEL
3
5V 4 COM2P9SEL
5
12V
6
COM2P9SEL
JV5,6,7 and JP13 location
23
OXY5737A User’s Manual V1.1
www.perfectron.com
COM3: RS232 with 5V/12V selectable
PIN
DEFINITION
1
5VS
2
GND
3
COM3P9SEL
4
COM3_DTR-
5
COM3_CTS-
6
COM3_TXD
7
COM3_RTS-
8
COM3_RXD
9
COM3_DSR-
10
COM3_DCD-
JP7: COM3 +12V/+5V selection
Jumper
Function description
Setting
1-2
COM3_RI
3-4
5VS
5-6
12V
COM4: RS232 with 5V/12V selectable
PIN
DEFINITION
1
5VS
2
GND
3
COM4P9SEL
4
COM4_DTR-
5
COM4_CTS-
6
COM4_TXD
7
COM4_RTS-
8
COM4_RXD
9
COM4_DSR-
10
COM4_DCD-
24
OXY5737A User’s Manual V1.1
www.perfectron.com
JP14: COM4 +12V/+5V selection
Jumper
Function description
Setting
1-2
COM4_RI-
3-4
5VS 5-6
12V
COM5: RS232 with 5V/12V selectable
PIN
DEFINITION
1
5VS 2 GND
3
COM5P9SEL
4
COM5_DTR-
5
COM5_CTS-
6
COM5_TXD
7
COM5_RTS-
8
COM5_RXD
9
COM5_DSR-
10
COM5_DCD-
JP15: COM5 +12V/+5V selection
Jumper
Function description
Setting
1-2
COM5_RI
3-4
5VS 5-6
12V
25
OXY5737A User’s Manual V1.1
www.perfectron.com
COM6: RS232 with 5V/12V selectable
PIN
DEFINITION
1
5VS
2
GND
3
COM6P9SEL
4
COM6_DTR-
5
COM6_CTS-
6
COM6_TXD
7
COM6_RTS-
8
COM6_RXD
9
COM6_DSR-
10
COM6_DCD-
JP16: COM6 +12V/+5V selection
Jumper
Function description
setting
1-2
COM6_RI-
3-4
5VS
5-6
12V
DC Jack
PIN
DEFINITION
PIN
DEFINITION
1
GND
2
GND
3
+VIN
4
+VIN
26
OXY5737A User’s Manual V1.1
www.perfectron.com
CON A1: CONNECTOR A TOP
CPU FAN: CPU FAN CONNECTOR
PIN
DEFINITION
1
CPUFAN_PWN
2
CPUFAN_IO
3
CPUFAN_VCC
4
GND
SYSFAN1: SYSTEM FAN CONNECTOR
PIN
DEFINITION
1
SYSFANIO
2
SYSFAN_VCC
3
GND
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
1
USB_OC#6
2
BUF_PLT_RST-
53
3V3_DU
54
3V3_DU
105
GND
106
CLK_LPC_UART
3
3.3V 4 3.3V
55
3V3_DU
56
GND
107
NC
108
GND
5
USBD7+
6
USBD6+
57
ST_LAN1_MDIP0
58
NC
109
ST_LAN1_MDIP2
110
7
USBD7-
8
USBD6-
59
ST_LAN1_MDIN0
60
NC
111
ST_LAN1_MDIN2
112
9
GND
10
GND
61
GND
62
GND
113
GND
114
GND
11
PCIE_TXP5
12
PCIE_TXP7
63
ST_LAN2_MDIP0
64
NC
115
ST_LAN2_MDIP2
116
13
PCIE_TXN5
14
PCIE_TXN7
65
ST_LAN2_MDIN0
66
NC
117
ST_LAN2_MDIN2
118
15
GND
16
GND
67
GND
68
GND
119
GND
120
GND
17
PCIE_TXP6
18
PCIE_TXP8
69
ST_LAN1_MDIP1
70
NC
121
ST_LAN1_MDIP3
122
19
PCIE_TXN6
20
PCIE_TXN8
71
ST_LAN1_MDIN1
72
NC
123
ST_LAN1_MDIN3
124
21
GND
22
GND
73
GND
74
GND
125
GND
126
GND
23
PCIE_RXP5
24
PCIE_RXP7
75
ST_LAN2_MDIP1
76
NC
127
ST_LAN2_MDIP3
128
ST_LAN2_MDIP3
25
PCIE_RXN5
26
PCIE_RXN7
77
ST_LAN2_MDIN1
78
NC
129
ST_LAN2_MDIN3
130
ST_LAN2_MDIN3
27
GND
28
GND
79
ST_LAN2_ACT#
80
ST_LAN1_ACT#
131
PE_PRSNT1_A-
132
PE_PRSNT0_A
29
PCIE_RXP6
30
PCIE_RXP8
81
SATATXP5
82
SATATXP4
133
SATSRXP5
134
SATARXP5
31
PCIE_RXN6
32
PCIE_RXN8
83
SATATXN5
84
SATATXN4
135
SATSRXN5
136
SATARXN5
33
GND
34
GND
85
GND
86
GND
137
GND
138
GND
35
PEX5_PCIE_CLK
36
PEX7_PCIE_CLK
87
USBD9+
88
USBD11+
139
NC
140
37
PEX5_PCIE_CLK#
38
PEX7_PCIE_CLK#
89
USBD9-
90
USBD11-
141
NC
142
39
5V_DU
40
5V_DU
91
GND
92
GND
143
GND
144
GND
41
PEX6_PCIE_CLK
42
PEX8_PCIE_CLK
93
NC
94
USBD10+
145
LPC_AD0
146
LPC_LDRO0
43
PEX6_PCIE_CLK#
44
PEX8_PCIE_CLK#
95
NC
96
USBD10-
147
LPC_AD1
148
INT_SERIRQ
45
GND
46
5VS
97
GND
98
GND
149
GND
150
GND
47
SMB_DATA_MAIN
48
NC
99
ETH_1_CTREF
100
ETH_0_CTREF
151
LPC_AD2
152
LPC_FRAME
49
SMB_CLK_MAIN
50
NC
101
SPI_MISO_AA
102
SPI_CE0#_F
153
LPC_AD3
154
VRTC
51
SMBALERT#
52
BUS_PS_ON#
103
SPI_SI_F
104
SPI_CE1#_F
155
FUSB_1RTS-
156
FUSB_ORTS
27
OXY5737A User’s Manual V1.1
www.perfectron.com
JV8,9,10,11: LVDS Panel selection jumper setting
No.
HA
(Pixel)
VA
(Line)
Color depth
JV10
JV8
JV11
JV9
1
800
600
18-bit
2
1024
768
24-bit
3
1024
768
18-bit
4
1280
800
18-bit
5
1280
1024
24-bit
6
1366
768
24-bit
7
1440
900
24-bit
8
1920
1080
24-bit
28
OXY5737A User’s Manual V1.1
www.perfectron.com
JV12: LVDS_VDD power select
Jumper
Function description
Setting
1-2
3.3V
2-3
5.0V
Default setting: 1-2
JV8,9,10,11,12 location:
29
OXY5737A User’s Manual V1.1
www.perfectron.com
FPE1: StackPC FPE Top Connector
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
PIN
DEFINITION
1
NC 2 NC 3 NC 4 NC 5 NC
11
GND
12
NC
13
GND
14
NC
15
GND
21
NC
22
NC
23
NC
24
GND
25
NC
31
NC
32
NC
33
NC
34
NC
35
NC
41
GND
42
NC
43
GND
44
NC
45
GND
51
NC
52
GND
53
NC
54
GND
55
NC
61
NC
62
NC
63
NC
64
NC
65
NC
71
GND
72
NC
73
GND
74
NC
75
GND
81
PEG_TXP0
82
NC
83
PEG_TXP2
84
GND
85
PEG_TXP4
91
PEG_TXN0
92
PEG_TXP1
93
PEG_TXN2
94
PEG_TXP3
95
PEG_TXN4
101
GND
102
PEG_TXN1
103
GND
104
PEG_TXN3
105
GND
111
PEG_RXP_0
112
GND
113
PEG_RXP_2
114
GND
115
PEG_RXP_4
121
PEG_RXN_0
122
PEG_RXP_1
123
PEG_RXN_2
124
PEG_RXP_3
125
PEG_RXN_4
131
GND
132
PEG_RXN_1
133
GND
134
PEG_RXN_3
135
GND
141
PEG_TXP8
142
GND
143
PEG_TXP10
144
GND
145
PEG_TXP12
151
PEG_TXN8
152
PEG_TXP9
153
PEG_TXN10
154
PEG_TXP11
155
PEG_TXN12
161
GND
162
PEG_TXN9
163
GND
164
PEG_TXN11
165
GND
171
PEG_RXP_8
172
GND
173
PEG_RXP_10
174
GND
175
PEG_RXP_12
181
PEG_RXN_8
182
PEG_RXP_9
183
PEG_RXN_10
184
PEG_RXP_11
185
PEG_RXN_12
191
GND
192
PEG_RXN_9
193
GND
194
PEG_RXN_11
195
GND
PIN
NAME
PIN
NAME
PIN
NAME
PIN
NAME
PIN
NAME
6
NC 7 NC 8 NC 9 NC
10
NC
16
NC
17
GND
18
NC
19
NC
20
NC
26
GND
27
NC
28
GND
29
NC
30
NC
36
NC
37
NC
38
NC
39
NC
40
NC
46
NC
47
GND
48
NC
49
GND
50
NC
56
GND
57
NC
58
GND
59
NC
60
NC
66
NC
67
NC
68
NC
69
SPKR
70
NC
76
NC
77
GND
78
NC
79
GND
80
NC
86
GND
87
PEG_TXP6
88
GND
89
NC
90
CFG5
96
PEG_TXP5
97
PEG_TXN6
98
PEG_TXP7
99
NC
100
CFG6
106
PEG_TXN5
107
GND
108
PEG_TXN7
109
GND
110
BUF_PLT_RST-
116
GND
117
PEG_RXP_6
118
GND
119
PEG_A_CLK_P
120
GND
126
PEG_RXP_5
127
PEG_RXN_6
128
PEG_RXP_7
129
PEG_A_CLK_N
130
3V3_DU
136
PEG_RXN_5
137
GND
138
PEG_RXN_7
139
GND
140
3V3_DU
146
GND
147
PEG_TXP14
148
GND
149
PEG_B_CLK_P
150
GND
156
PEG_TXP13
157
PEG_TXN14
158
PEG_TXP15
159
PEG_B_CLK_N
160
GND
166
PEG_TXN13
167
GND
168
PEG_TXN15
169
GND
170
NC
176
GND
177
PEG_RXP_14
178
GND
179
NC
180
12V
186
PEG_RXP_13
187
PEG_RXN_14
188
PEG_RXP_15
189
NC
190
12V
196
PEG_RXN_13
197
GND
198
PEG_RXN_15
199
NC
200
12V
30
OXY5737A User’s Manual V1.1
www.perfectron.com
LED1: LAN1 LED STATUS
LED1
Light
Dark
Flash
RED
1000M
100M
NA
GREEN
LINK
UNLINK
ACTIVITY
LED2: LAN2 LED STATUS
LED2
Light
Dark
Flash
RED
1000M
100M
NA
GREEN
Link
Un-link
Activity
LED3: POWER/HDD LED
LED2
Light
Dark
Flash
RED
NA
HDD un-access
HDD access
GREEN
Power On
Power Off
NA
SW1: POWER BUTTON
PIN
DEFINITION
ON
NO LIGHT
OFF
BLUE LIGHT
JBKL1: JBKL1: Inverter connector
PIN
DEFINITION
1
12V
2
12V
3
12V
4
5VS
5
5VS 6 GND
7
GND
8
BL_EN
9
LVDS0_BKL_CTRL_R
10
GND
31
OXY5737A User’s Manual V1.1
www.perfectron.com
FP1: Front Panel
PIN
DEFINITION
PIN
DEFINITION
1
HDLED+
2
PLED+
3
HDLED-
4
GND
5
GND
6
EC_PWR_BTN
7
EXT_RESET#
8
GND
9
NC
10
NC
FP3: LAN LED
PIN
DEFINITION
PIN
DEFINITION
1
3V3M
2
3V3M
3
LAN_LED_LNK#_ACT
4
LAN2_ACT#
5
LAN_LED_LNK_1000#
6
LAN2_LED_1000-
7
LAN_LED_LNK_100#
8
LAN2_LED_100-
Plug LED cable to FP3 pin header
Active LED: plug 1-3 pin
Single 1000M LED: plug 1-5 pin
Single 100M LED: plug 1-7 pin
Dual 1000M LED: plug 5-7 pin
32
OXY5737A User’s Manual V1.1
www.perfectron.com
Chapter 3: Getting Started
3.1 Installing System Memory
The OXY5737A supports 1 x DDR3 1333 Swissbit XR-DIMM up to 8GB w/ECC (Top Side)
Disconnect all power supplies to the board before installing a memory module to
prevent damage to the board and memory module.
To install a memory module:
1. Located the memory module slots on the motherboard.
2. Align the memory module with the socket to make sure the notch aligns with the slot key on the
socket.
33
OXY5737A User’s Manual V1.1
www.perfectron.com
3. Insert the module firmly into the desired slot until the slot lock and secure the memory module.
4. After insert the module to the desire slot, drive screws tighten with memory module’s crew hole and
bolt on PCB board.
34
OXY5737A User’s Manual V1.1
www.perfectron.com
Chapter 4: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration
through the AMI BIOS setup utility.
4.1 Starting
To enter the setup screens, perform the following steps:
• Turn on the computer and press the <Del> key immediately.
• After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
4.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility
hot keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.
Some of the navigation keys may differ from one screen to another.
Left/Right
The Left and Right <Arrow> keys moves the cursor to select a
menu.
Up/Down The Up and Down <Arrow> keys moves the cursor to select a
setup screen or sub-screen.
+− Plus/Minus
The Plus and Minus <Arrow> keys changes the field value of a
particular setup setting.
Tab The <Tab> key selects the setup fields.
F1
The <F1> key displays the General Help screen.
F10 The <F10> key saves any changes made and exits the BIOS setup
utility.
Esc
The <Esc> key discards any changes made and exits the BIOS
setup utility.
Enter The <Enter> key displays a sub-screen or changes a selected or
highlighted option in each menu.
35
OXY5737A User’s Manual V1.1
www.perfectron.com
4.3 Main Menu
The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred.
You could setup these items on the Main menu:
System Language: Choose the system default language.
System Date: Set the date. Use Tab to switch between date elements.
36
OXY5737A User’s Manual V1.1
www.perfectron.com
System Time: Set the time. Use Tab to switch between time elements.
Access Level
Displays the access level of the current user in the BIOS.
4.4 Advanced Menu
This section allows you to configure and improve your system and allows you to set up some system
features according to your preference.
37
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.1 PCI Subsystem Settings
PCI, PCI-X and PCI Express settings.
PCI Common Settings
PCI Latency Timer: Value to be programed into PCI Latency Timer Register.
VGA Palette Snoop: Enable or disable VGA Palette Registers Snooping.
PERR# Generation: Enables or Disables PCI Device to Generate PERR#.
SERR# Generation: Enables or Disables PCI Device to Generate SERR#.
38
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Settings
Change PCI Express Devices Settings.
PCI Express Device Register Settings
Relaxed Ordering: Enables or Disables PCI Express Device Relaxed Ordering.
Extended Tag: If ENABLED allows Device to use 8-bit Tag field as a requester.
No Snoop: Enabled or Disables PCI Express Device No Snoop option.
Maximum Payload: Set Maximum Payload of PCI Express Device or allow System BIOS to select
the value.
Maximum Read Request: Set Maximum Read Request Size of PCI Express Device or allow System
BIOS to select value.
PCI Express Link Register Settings
ASPM Support: Set the ASPM level: Force L0s - Force all links to L0s state: AUTO - BIOS auto
configure: DISABLE- Disables ASPM. WARNING: Enabling ASPM may cause some PCI-E devices to
fail.
Extended Synch: If ENBLED allows generation of extended synchronization patterns.
Link Training Retry
Defines number of retry attempts software will take to retrain the link if previous training attempt was
unsuccessful.
Link Training Time out (uS)
Defines number of Microseconds software will wait before polling “Link training” bit in link status register.
Value range from 10 to 10000 uS.
Unpopulated Links
In order to save power, software will disable unpopulated PCI Express Links. If this option save to “Disable
Link”.
Restore PCIE Registers
On non-PCI Express aware OS’s some device may not be correctly reinitial after S3. Enableling this restore
PCI Express device configurations on S3 resume.
Warning: Enabling this may cause issues with other hardware after S3 resume.
39
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.2 ACPI Settings
System ACPI Parameters.
Enable ACPI Auto Configuration
Enable/disable BIOS ACPI Auto Configuration.
Enable Hibernation
Enables or Disables system ability to hibernate (OS/S4 sleep state). This option may be not effective with
some OS.
ACPI Sleep State
Select ACPI sleep state the system will enter when the suspend button is pressed.
Lock Legacy Resources
Enable or disable lock of legacy resource.
S3 Video Repost
Enable or disable S3 Video Repost.
40
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.3 CPU configuration
CPU Configuration Parameters.
41
OXY5737A User’s Manual V1.1
www.perfectron.com
Hyper-threading
Enable for windows XP and Linux(OS optimized for Hyper-Threading Technology) and Disabled for other OS
(OS not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is
enabled.
42
OXY5737A User’s Manual V1.1
www.perfectron.com
Active Processor Cores
Number of cores to enable in each processor package.
Overclocking lock
FLEX_RATIO(194) MSR.
Limit CPUID Maximum
Disable for Windows XP.
Execute Disable Bit
XD can prevent certain classes of malicious buffer overflow attecks when combined with a supporting OS.
Intel Virtualization Technology
When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.
Hardware Prefetcher
Enable the mid level cache(L2) streamer prefetcher.
Adjacent Cache Line Prefetcher
Enable the mid level cache(L2) prefetching of adjacent cache lines.
CPU AES
Enable/disable CPU advanced encryption standard instruction.
Boot performance mode
Select the performance state that the BIOS will set before OS handoff.
EIST
Enable/Disable Intel speed step.
Turbo Mode
Enable/Disable CPU turbo mode
43
OXY5737A User’s Manual V1.1
www.perfectron.com
Energy performance
Optimize between performance and power savings.
Package power limit lock: When enabled PACKAGE_POWER_LIMIT MSR will be locked and a reset
will be required to unlock the register.
CPU Power limit1: CPU power limit1 value
CPU Power limit1 time: Time window which the power limit1 is maintained
CPU Power limit2: CPU power limit2 value
Platform power limit lock: When enable, PLATFORM_POWER_LIMIT MSD will be locked and a reset
will be required to unlock the register.
CPU Power Limit3: CPU Power Limit3 value
CPU Power Limit3 Time: Time window which the power limit3 is maintained
CPU Power Limit3 Duty Cycle: Specify the duty cycle in percentage that the CPU is required to
maintain over the configured Power Limit3 time windows.
DDR Power Limit1: DDR Power limit1 value
DDR Power Limit1 Time: Time window which the DDR Power Limit1 is maintained.
DDR Power Limit2: DDR Power limit2 value
1-Core Ratio Limit: This limit is for 1 core active. 0 means using the factory-configured value.
2-Core Ratio Limit: This limit is for 2 cores active. 0 means using the factory-configured value.
3-Core Ratio Limit: This limit is for 3 cores active. 0 means using the factory-configured value.
4-Core Ratio Limit: This limit is for 4 cores active. 0 means using the factory-configured value.
VR Current value lock
Locks VR Current value from further writes until a reset.
VR Current value
Voltage regulator current limit. 0 means AUTO.
CPU C States
Enable or disable CPU C states.
Enhanced C1 State: Enhanced C1 State
CPU C3 Report: Enable /disable CPU C3 report to OS
CPU C6 Report: Enable /disable CPU C6 report to OS
C6 Latency: Configure short/long latency for C6
CPU C7 Report: Enable /disable CPU C7 report to OS
C7 Latency: Configure short/long latency for C7
C1 state auto demotion: processor will conditionally demote C3/C6/C7 requests to C1 based on
uncore auto-demote information.
C3 state auto demotion: processor will conditionally demote C6/C7 requests to C3 based on uncore
44
OXY5737A User’s Manual V1.1
www.perfectron.com
auto-demote information.
Package C state demotion: enable package C state demotion
C1 state auto undemotion: undemotion from demoted C1.
C3 state auto undemotion: undemotion from demoted C1.
Package C state undemotion: enable package C state undemotion
C state Pre-wake: Enable or disable C state Pre-Wake feature.
CFG lock
Configure MSR 0xE2[15], CFG lock bit.
Package C State limit
C0/C1, C2, C3, C6, C7, C7s, AUTO
LakeTiny Feature
Enable/Disable LakeTiny for C state configuration.
ACPI CTDP BIOS
Enable/Disable ACPI CTDP BIOS support.
Configurable TDP level
Allows reconfiguration of TDP levels base on current power and thermal delivery capabilities of the system.
Configure TDP lock
Lock the Config TDP control register.
TCC activation offset
Offset from the factory TCC activation temperature.
Intel TXT(LT) Support
Only Disable
ACPI T state
Enable/Disable ACPI T state support.
45
OXY5737A User’s Manual V1.1
www.perfectron.com
CPU DTS
Disabled: ACPI thermal management uses EC reported temperature value.
Enabled: ACPI thermal management uses DTS SMM mechanism to obtain CPU temperature values.
Out of Spec: ACPI Thermal Management uses EC reported temperature values and DTS SMM is used to
handle Out of spec.
Debug interface
Enable/Disable CPU debug feature.
Debug interface lock
Lock CPU debug interface setting.
IOUT OFFSET Sign
0 positive offset. 1 negative offset.
IOUT OFFSET
VR IOUT OFFSET configuration 0~625.
IOUT SLOPE
VR IOUT SLOPE configuration range 0~1023.
4.4.4 SATA Configuration
This section is used to configure the SATA drives.
46
OXY5737A User’s Manual V1.1
www.perfectron.com
SATA Controller(s)
Enable or disable SATA device.
SATA Mode Selection
Determines how SATA controller(s) operate. The options are: IDE, AHCI, RAID
SATA Test Selection
Enable or disable Test Mode
Aggressive LPM Support
Enable PCH to aggressively enter link power state.
SATA Controller Speed
Indicates the maximum speed the SATA controllers can support. The options are default, Gen1, Gen2, Gen3.
47
OXY5737A User’s Manual V1.1
www.perfectron.com
Software Feature Mask Configuration
RADI OROM/RST driver will refer to the SWFW configuration to enable or disable the storage features.
RAID0: Enable or disable RAID0 feature.
RAID1: Enable or disable RAID1 feature.
RAID10: Enable or disable RAID10 feature.
RAID5: Enable or disable RAID5 feature.
Intel Rapid Recovery Technology: Enable or disable Intel Rapid Recovery Technology.
OROM UI and Banner: If enabled, then the OROM UI is shown. Otherwise, no OROM banner
or information will be displayed if all disks and RAID volumes are Normal.
HDD unlock: If enabled, indicates that the HDD password unlock in the OS is enabled.
LED Locate: If enabled, indicates that the LED/SGPIO hardware is attached and ping yo locate features
is enabled on the OS.
IRRT Only on eSATA: If enabled, then only IRRT volumes can span internal and eSATA drives. If disabled,
then any RAID volume can span internal and eSATA drives.
Smart Response Technology: Enabled or disable Smart Response Technology.
OROM UI Delay: If enabled, indicates the delay of the OROM UI Splash Screen in a normal status. The
options are 2 seconds, 4 seconds, 6 seconds, 8 seconds.
Serial ATA Port 0
Port 0: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
Serial ATA Port 1
Port 1: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
48
OXY5737A User’s Manual V1.1
www.perfectron.com
Serial ATA Port 2
Port 2: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
Serial ATA Port 3
Port 3: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
Serial ATA Port 4
Port 4: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
Serial ATA Port 5
Port 5: Enable or disable SATA port
Hot Plug: Designates this port as Hot Pluggable.
External SATA: External SATA support.
SATA device type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
Spin Up Device: On an edge detec from 0 to 1, the PCH starts a COMRESET initialization sequence to
the device.
49
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.5 Intel Rapid Start Technology
Enable or disable Intel Rapid Start Technology
4.4.6 PCH-FW Configuration
Configure Management Engine Technology Parameters.
50
OXY5737A User’s Manual V1.1
www.perfectron.com
MDES BIOS Status Code
Enable/Disable MDES BIOS Status Code.
Firmware Update Configuration
Configure Management Engine Technology Parameters.
Me FW Image Re-Flash: Enable/Disable Me FW Image Re-Flash function.
4.4.7 Intel Anti-Theft Technology Configuration
Disabling Intel AT allow user to login to platform. This is strictly for testing only. This does not disable Intel
AT services in ME.
Intel Anti-Theft Technology
Enable/Disable Intel AT in BIOS for testing. On
Enter Intel AT Suspend Mode
Only Disabled
51
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.8 AMT Configuration
Configure Active Management Technology Parameters.
Intel AMT
Enable/Disable Intel Active Management Technology BIOS Extension.
Note: iAMT H/W is always enabled.
This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the
SPI device.
BIOS Hotkey Pressed
OEMFlag Bit 1: Enable/Disable BIOS hotkey press.
MEBx Selection Screen
OEMFlag Bit 2: Enable/Disable MEBx selection screen.
Hide Un-Configure ME Confirmation
OEMFlag Bit 6: Hide Un-Configure ME without password Configuration prompt.
MEBx Debug Message Output
OEMFlag Bit 14: Enable MEBx debug message output.
52
OXY5737A User’s Manual V1.1
www.perfectron.com
Un-Configure ME
OEMFlag Bit 15: Un-Configure ME without password.
Amt Wait Timer
Set Timer to wait before sending ASF_GET_BOOT_OPTIONS.
Disable ME
Set ME to Soft Temporary Disabled.
ASF
Enable/Disable Alert Specification Format.
Activate Remote Assistance Process
Trigger CIRA boot.
USB Configure
Enable/Disable USB Configure function.
PET Progress
User can Enable/Disable PET Events progress to receive PET events or not.
WatchDog
Enable/Disable WatchDog Timer.
53
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.9 USB Configuration
USB Configuration Parameters.
Legacy USB Support
Enables legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE
option will keep USB devices available only for EFI applications.
USB3.0 Support
Enable/Disable USB3.0 (XHCI) Controller support.
XHCI Hand-off
This is a workaround for OSes without XHCI hand-off support. The XHCI ownership change should be
claimed by XHCI driver.
EHCI Hand-off
This is a workaround for OSes without EHCI hand-off support. The EHCI ownership change should be
claimed by EHCI driver.
USB Mass Storage Driver Support
Enable/Disable USB Mass Storage Driver Support.
54
OXY5737A User’s Manual V1.1
www.perfectron.com
USB hardware delays and time-outs:
USB transfer time-out: The time-out value for Control, Bulk, and Interrupt transfers. The options are 1
sec, 5 sec, 10 sec, 20 sec.
Device reset time-out: USB mass storage device Start Unit command time-out. The options are 10 sec,
20 sec, 30 sec, 40 sec.
Device power-up delay: Maximum time the device will take before it properly reports itself to the
Host Controller. ‘Auto’ uses default value: for a Hub port the delay is taken from Hub descriptor. The
options are Auto, manual.
4.4.10 IT8786 Super IO Configuration
System Super IO Chip Parameters.
Serial Port 1 Configuration
Set Parameters of Serial Port 0 (COMA).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=3F8h, IRQ=4
Change Settings: Select an optimal setting for Super IO device.
55
OXY5737A User’s Manual V1.1
www.perfectron.com
Serial Port 2 Configuration
Set Parameters of Serial Port 1 (COMB).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=2F8h, IRQ=3
Change Settings: Select an optimal setting for Super IO device.
Serial Port 3 Configuration
Set Parameters of Serial Port 2 (COMC).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=3E8h, IRQ=7
Change Settings: Select an optimal setting for Super IO device.
Serial Port 4 Configuration
Set Parameters of Serial Port 3 (COMD).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=2E8h, IRQ=7
Change Settings: Select an optimal setting for Super IO device.
Serial Port 5 Configuration
Set Parameters of Serial Port 4 (COME).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=2F0h, IRQ=7
Change Settings: Select an optimal setting for Super IO device.
Serial Port 6 Configuration
Set Parameters of Serial Port 5 (COMF).
Serial Port: Enable or Disable Serial Port (COM).
Device Settings: IO=2E0h, IRQ=7
Change Settings: Select an optimal setting for Super IO device.
56
OXY5737A User’s Manual V1.1
www.perfectron.com
4.4.11 IT8786 HW Monitor
Monitor hardware status.
4.4.12 Serial Port Console Redirection
Console Redirection
Console Redirection Enable or Disable.
57
OXY5737A User’s Manual V1.1
www.perfectron.com
Console Redirection Setting
The Settings specify how the host computer and the remote computer will exchange data. Both computers
should have the same or compatible setting.
Out-of-Band Mgmt Port: Microsoft Windows Emergency Management Service allows for remote
management of a Windows Server OS through a serial port. The options are COM0 (Disabled),
COM1(Pci Bus0, Dev0, Func0) (Disabled)
Terminal Type: VT-UTF8 is the preferred terminal type for out-of-band management. The next best
choice is VT100+ and then VT100. See above, in Console Redirection Settings page, for more Help with
Terminal Type/Emulation. The options are VT100, VT100+, VT-UTF8, ANSI.
Bits per second: selects serial port transmission speed. The speed must be matched on the other side.
Long or noisy lines may require lower speeds. The options are 9600, 19200, 57600, 115200.
Flow Control: Flow control can prevent data loss from buffer overflow. When sending data, if the
receiving buffers are full, a “stop” signal can be sent to stop the data flow. Once the buffers are empty,
a “star” signal can be sent to re-start the flow. Hardware flow control uses two wires to send
start/stop signals. The options are None, Hardware RTS/CTS, Software Xon/xoff
Data bits: 8
Parity: None
Stop bits: 1
4.4.13 Network Stack
Network stack settings
58
OXY5737A User’s Manual V1.1
www.perfectron.com
Network Stack
Enable/Disable UEFI network stack
4.4.14 Intel I210 Gigabit Network Connection
Configure Gigabit Ethernet device parameters.
PORT CONFIGURATION MENU
NIC Configuration: Configure Boot Protocol, wake on LAN, Link Speed, and VLAN.
Blink LEDs: Identify the physical network port by blinking the associated LED.
PORT CONFIGURATION INFORMATION
Link Status: Link Status.
Virtual MAC Address: Programmatically assignable MAC address for port.
59
OXY5737A User’s Manual V1.1
www.perfectron.com
4.5 Chipset
This section gives you functions to configure the system based on the specific features of
the chipset. The chipset manages bus speeds and access to system memory resources.
4.5.1 PCH IO configuration
60
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Configuration
PCI Express Configuration settings
PCIE Root Port Function Swapping: Enable or disable PCI Express PCI Express Root Port Function
Swapping.
Subtractive Decode: Enable or disable PCI Express Subtractive Decode.
PCI Express Root Port1
PCI Express Root Port1 setting. Only enabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure : DISABLE – Disables ASPM. The options are Disabled, L0s, L1, L0SL1, Auto
L1 Substates: PCI Express L1 Substates setting. The options are Disabled, L1.1, L1.2, L1.1 & L1.2
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR configuration lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
61
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port2
control the PCI Express Root port, the options are enabled/disabled.
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR configuration lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
62
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port3
control the PCI Express Root port, the options are enabled/disabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non-Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR Configuration Lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
PCI Port 4 is assigned to LAN
63
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port5:
control the PCI Express Root port, the options are enabled/disabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non-Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR Configuration Lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
64
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port6
control the PCI Express Root port, the options are enabled/disabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non-Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR Configuration Lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
65
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port7
control the PCI Express Root port, the options are enabled/disabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non-Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR Configuration Lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
66
OXY5737A User’s Manual V1.1
www.perfectron.com
PCI Express Root Port8
control the PCI Express Root port, the options are enabled/disabled
ASPM Support: Set the ASPM Level: Force L0s – Force all links to L0s State: AUTO – BIOS auto
configure: DISABLE – Disables ASPM.
L1 Substates: PCI Express L1 Substates setting.
URR: Enable or disable PCI Express Unsupported Request Reporting.
FER: Enable or disable PCI Express Device Fatal Error Reporting.
NFER: Enable or disable PCI Express Device Non-Fatal Error Reporting.
CER: Enable or disable PCI Express Device Correctable Error Reporting.
CTO: Enable or disable PCI Express Completion Timer TO.
SEFE: Enable or disable Root PCI Express System Error on Fatal Error.
SENFE: Enable or disable Root PCI Express System Error on Non-Fatal Error.
SECE: Enable or disable Root PCI Express System Error on Correctable Error.
PME SCI: Enable or disable PCI Express PME SCI.
Hot Plug: Enable or disable PCI Express Hot Plug.
PCIe Speed: Select PCI Express port speed.
Detect Non-Compliance Device: Detect Non-Compliance PCI Express Device. If enable, it will take
more time at POST time.
Extra Bus Reserved: Extra Bus Reserved (0-7) for bridges behind this Root Bridge.
Reseved Memory: Reserved Memory Range for this Root Bridge.
Prefetchable Memory: Prefetchable Memory Range for this Root Bridge.
Reserved I/O: Reserved I/O (4K/8K/12K/16K/…/48K) Range for this Root Bridge.
PCIE LTR: PCIE Latency Reporting Enable/Disable.
PCIE LTR Lock: PCIE LTR Configuration Lock.
Snoop Latency Ocerride: Snoop Latency Ocerride for PCH PCIE.
Non Snoop Latency Ocerride: Non Snoop Latency Ocerride for PCH PCIE.
USB Configuration
USB Precondition: Precondition work on USB host controller and root ports for faster enumeration.
XHCI Mode: Mode of operation of xHCI controller.
BTCG: Enabling/disabling trunk clock gating.
USB Ports Per-Port Disable Control: Control each of the USB ports (0~13) disabling.
PCH Azalia Configuration.
Azalia: Control Detection of the Azalia device.
Disabled=Azalia will be unconditionally disabled.
Enabled=Azalia will be unconditionally Enabled.
Auto=Azalia will be enabled if present, disabled otherwise.
67
OXY5737A User’s Manual V1.1
www.perfectron.com
Azalia Docking Support: Enable or disable Azalia Docking Support of Audio Controller.
Azalia PME: Enable or disable Power Management capability of Audio Controller.
PCH LAN Controller
Enable or disable onboard NIC.
Wake on LAN: Enable or disable integrated LAN to wake the system. (The Wake On LAN cannot be
disabled if ME is on at Sx state.)
SLP_LAN# Low on DC Power: Enable/Disable SLP_LAN# Low on DC Power.
Board Capability
Board Capability-SUS_PWR_DN_ACK->Send Disabled to PCH, DeepSx->Show DeepSx Policies.
GP27 Wake From DeepSx
Wake from DeepSx by the assertion of GP27 pin.
PCIE Wake From DeepSx
Wake from DeepSx by the assertion of PCIE.
Serial IRQ Mode
Configure Serial IRQ Mode.
SLP_S4 Assertion Width
Select a minimum assertion width of the SLP_S4# signal.
Port 80h Redirection
Control where the Port 80h cycles are sent.
68
OXY5737A User’s Manual V1.1
www.perfectron.com
4.5.2 System AGENT SA
VT-d
Check to enable VT-d function on MCH.
Graphics Configuration
Graphics Turbo IMON Current: Graphics turbo IMON current values supported (14-31).
Primary Display: select which of AUTO/IGFX/PEG/SG graphics device should be primary display or
select SG for switchable GFX
Primary PEG: Select Auto/PEG1/PEG2 Graphics device should be Primary PEG.
Primary PCIE: Select Auto/PCIE1/PCIE2/PCIE3/PCIE4PCIE5/PCIE6/PCIE7 Graphics device should
be Primary PCIE.
Internal Graphics: Keep IGD enabled based on the setup options
Aperture Size: Select the Aperture Size.
DVMT Pre-Allocated: Select DVMT 5.0 Pre-Allocated (fixed) Graphics memory size used by the internal
graphics device.
DVMT Total Gfx Mem: Select DVMT5.0 total graphic memory size used by the internal graphics device.
Gfx Low Power Enable: this option is applicable for SFF only.
Panel Power Enable: Enable/Disable forcing of Panel Power in the BIOS.
69
OXY5737A User’s Manual V1.1
www.perfectron.com
LCD Control
Primary IGFX Boot Display: Select the Video Device which will be activated during POST. This has no
effect if external graphics present. Secondary boot display selection will appear based on your
selection. VGA modes will be supported only on primary display.
LCD Panel Type: Select LCD panel used by Internal Graphics Device by selecting the appropriate setup
item.
SDVO-LFP Panel Type: Select SDVO panel used by Internal Graphics Device by selecting the
appropriate setup item.
Panel Scaling: Select the LCD panel scaling option used by the Internal Graphics Device.
Backlight control: backlight control setting
Panel Color Depth: select the LFP panel color depth.
Memory Configuration
DIMM profile: Select DIMM timing profile that should be used.
Memory Frequency Limiter: maximum memory frequency selections in Mhz.
DDR Reset Wait Time: The value of ns to wait for switch DDR voltage, minimum 20ns.
ECC Support: Enable or disable DDR Ecc support
Max TOLUD: Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically
based on largest MMIO length of installed graphic controller.
GT- Power Management Control
RC6 (render standby): check to enable render standby support.
GT OverClocking Support: enable or disable GT overclocking support
70
OXY5737A User’s Manual V1.1
www.perfectron.com
4.6 Boot
This section is used to configure the boot features.
Setup Prompt Timeout
Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.
Bootup NumLock State
Select the keyboard NumLock state.
Quiet Boot
Enables or disables Quiet Boot option.
Fast Boot
Enables or disables boot with initialization of a minimal set of devices required to launch active boot option.
Has no effect for BBS boot options.
Boot option priorities
Boot Option #1: Sets the system boot order.
71
OXY5737A User’s Manual V1.1
www.perfectron.com
Hard Drive BBS Priorities
Set the order of the legacy devices in this group
CSM16 Parameters
Set the order of the legacy devices in this group
GateA20 Active: UPON REQUEST – GA20 can be disabled using BIOS serices.ALWAYS-do not allow
disabling GA20; this option is useful when any RT code is executed above 1MB.
Option ROM Messages: Set display mode for option ROM.
INT19 Trap Response: BIOS reaction on INT19 trapping by option ROM: IMMEDIATE-execute the trap
right away; POSTPONES-execute the trap during legacy boot.
CSM Parameters
OpROM execution, boot options filter, etc.
4.7 Security
Use the Security Menu to establish system passwords
Administrator Password
Set Administartor Password.
User Password
Set User Password.
HDD Security Configuration
Set HDD Password.
72
OXY5737A User’s Manual V1.1
www.perfectron.com
4.8 Save and Exit
This screen provides functions for handling changes made to the BIOS settings and the
exiting of the Setup program.
Save Changes and Exit
Exit system setup after saving the changes.
Discard Changes and Exit
Exit system setup without saving any changes.
Save Changes and Reset
Reset the system after saving the changes.
Discard Changes and Reset
Reset system setup without saving any changes.
Save Options
Save Changes: Save Changes done so far to any of the setup options.
Discard Changes: Discard Changes done so far to any of the setup options.
73
OXY5737A User’s Manual V1.1
www.perfectron.com
Restore Defaults
Restore/Load Default values for all the setup options.
Save as User Defaults
Save the changes done so far as User Defaults.
Restore user Defaults
Restore the User Defaults to all the setup options.
Launch EFI Shell from filesystem device
Attempts to launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices.
74
Loading...
