Pepperl Fuchs PMI360D-F130-R2-V15 Data Sheet
Ind. angular measuring system PMI360D-F130-R2-V15
Technical data
General specifications
Model Number
PMI360D-F130-R2-V15
Position sensor for PAX001
Features
• Measuring range 0 ... 360°
• RS 232 transmission
Measurement range 0 ... 360 °
Rotational speed
Nominal ratings
Operating voltage U
Reverse polarity protection reverse polarity protected
Repeat accuracy R 0.5°
Resolution 0.2 °
Temperature drift 1.5° (-25 °C ... 70 °C)
No-load supply current I
Functional safety related parameters
MTTFd 450 a
Mission Time (T
Diagnostic Coverage (DC) 0 %
Indicators/operating means
LED yellow RS 232
LED PWR/ERR Status display LED, green/red (Power on / missing actuator)
Interface
Interface type RS 232, for communication with interface box PAX...
Ambient conditions
Ambient temperature -25 ... 70 °C (-13 ... 158 °F)
Mechanical specifications
Connection type 5-pin, M12 x 1 connector
Housing material PBT
Degree of protection IP67
Mass 180 g
Compliance with standards and
directives
Standard conformity
Standards EN 60947-5-2:2007
B
0
) 20 a
M
≤ 100 min
18 ... 30 V DC
≤ 45 mA
IEC 60947-5-2:2007
-1
Approvals and certificates
UL approval cULus Listed, General Purpose, Class 2 Power Source
CCC approval CCC approval / marking not required for products rated
≤36 V
Dimensions
ø 10
26
ø 5.2
110 10.3 ± 0.3
76.5
40
30
ø 41.5
Release date: 2015-01-30 17:19 Date of issue: 2015-01-30 214119_eng.xml
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
1
Ind. angular measuring system PMI360D-F130-R2-V15
Electrical Connection
1
4
2
5
3
L+
RxD
TxD
L-
Pinout
1
5
2
3
Accessories
BT-F130-A
Actuator for F130 series
V15-G-2M-PUR-V15-G
Connecting cable, M12 to M12, PUR cable 5-pin
4
Using a different actuating element
You can use a different actuator instead of the BT-F130-A actuator provided, which must be positioned centrally in the sensor opening. When using a different actuating element, the element must fulfill all requirements
relating to the material, dimensions and distance to the sensitive surface on the sensors (see table). Failing
to fulfill all of these requirements may reduce the accuracy/resolution of the sensor or even cause the sensor
to stop functioning.
Dimensions when using a different actuating element
d2
d1
t
C
L
A
B
D
w
d3
E
A Drive shaft
B Insulation ring made from non-conductive material
C Separate actuator (L ≥23 mm)
D Sensitive surface on the sensors (black, cylindrical inner surface)
E Sensor
Actuator (C) can be placed on the insulating ring made from non-conductive material (B) or inserted
in this ring.
Dimension
t2 mm
w7.5 mm
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
2
Release date: 2015-01-30 17:19 Date of issue: 2015-01-30 214119_eng.xml
