Inductive sensor NMB1,5-8GM35-E2-C-FE-150MM-V1
Dimensions
Model Number
NMB1,5-8GM35-E2-C-FE-150MM-V1
Features
• Stainless steel sensing face
• 1.5 mm flush
•3-wire DC
• Weld field immune
• Weld slag resistant coating
• Ferrous targets
Connection
1
4
3
L+
L-
Pinout
1
4
3
Wire colors in accordance with EN 60947-5-2
1 BN
3 BU
4 BK
(brown)
(blue)
(black)
Accessories
BF 8
Mounting flange, 8 mm
V1-G-OR2M-POC
Female cordset, M12, 4-pin, TPE cable, welding-bead resistant
M8x1
4
13
LED
M12 x 1
25
35
150
Technical Data
General specifications
Switching element function PNP NO
Rated operating distance s
Installation flush in mild steel
Output polarity DC
Assured operating distance sa0 ... 1.215 mm
Actuating element Ferrous targets
Reduction factor rAl 0
Reduction factor r
Reduction factor r
Reduction factor r
Reduction factor r
Nominal ratings
Operating voltage UB10 ... 30 V DC
Switching frequency f 0 ... 5 Hz
Hysteresis H 5 ... 15 typ. 10 %
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop U
Operating current I
Current consumption ≤ 10 mA
Off-state current I
Switching state indication LED, red
Mag. Field strength, AC fields 250 mT
Mag. Field strength, DC fields 250 mT
Ambient conditions
Ambient temperature -25 ... 75 °C (-13 ... 167 °F)
Mechanical specifications
Connection type Cable connector M12 x 1 , 3-pin with PVC Cable, 150 mm
Core cross-section 0.14 mm
Housing material Xylan coated - Stainless steel 1.4305 / AISI 303
Sensing face Xylan coated - Stainless steel 1.4305 / AISI 303
Protection degree IP67
Compliance with standards and directives
Standard conformity
Standards
Approvals and certificates
UL approval cULus Listed, General Purpose
CSA approval cCSAus Listed, General Purpose
CCC approval Products with a maximum operating voltage of ≤36 V do not bear a
0
Cu
0.4 - 0.7
304
1
St37
0
Brass
1. 5 m m
n
≤ 2 V
d
0 ... 100 mA
L
≤ 10 µA
r
2
EN 60947-5-2:2007
IEC 60947-5-2:2007
CCC marking because they do not require approval.
Release date: 2013-01-21 12:12 Date of issue: 2013-01-21 909311_eng.xml
Subject to modifications without notice
Copyright Pepperl+Fuchs
