Pepperl Fuchs DAD30-W Data Sheet
Optical data coupler
DAD30-W
Dimensions
Model Number
DAD30-W
Optical data coupler
Features
• Compact, flat aluminum housing
• 3 interfaces in a device can be selected via DIP switches
• Infrared light
• Mating connector with protective cover included delivery
View without connector
Emitter
Receiver
1
25
Receiver
Emitter
64
36
M4 (2 x)
36.4
25
1
56
16
13
50
Function display
Emitter
Receiver
Function display
Data sampling blanking
20
LED-data sampling blanking
Unit connector
Pg 7.5
138
150
100
VISOLUX
Release date: 2013-11-25 15:52 Date of issue: 2013-11-25 418448_eng.xml
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
1
Optical data coupler
Electrical connection
Option:
DAD30-W
2
3
6
7
9
10
11
12
13
14
15
16
17
18
19
RX232
TX232
Alarm 1
0 V
Analog
RX-DIS
+UB
Alarm 2
RX-DIS/TTL
RX-P
RX-N
TX-P
TX-N
CL-IN+
CL-IN-
RS 232 input
RS 232 output
(simple stability control)
Measuring output
Data sampling blanking
(sufficient stability control)
Data switch off
RS 422 (B-input)
RS 422 (A-input)
RS 422 (B-output)
RS 422 (A-output)
Current loop input
Current loop input
21
22
25
CL-OUT-
TX-DIS
CL-OUT+
Current loop output
Emitter deactivation
Current loop output
Refer to “General Notes Relating to Pepperl+Fuchs Product Information”.
2
Release date: 2013-11-25 15:52 Date of issue: 2013-11-25 418448_eng.xml
