Pentax ADEMCO LYNXR Setup Guide

ADEMCO LYNXR Series

Security Systems

LYNXR/LYNXR24 and LYNXR-EN

Installation and Setup Guide

K5963V3bx 5/04 Rev. A

DELETE

AUX

SELECT

STAY

ESCAPE

AWAY

ADD

OFF

LIGHTS ON

LIGHTS OFF

STATUS

RECORD

NO DELAY

CODE

VOLUME

TEST

ARMED

CHIME

FUNCTION

PLAY

BYPASS

READY

RECOMMENDATIONS FOR PROPER PROTECTION

The Following Recommendations for the Location of Fire and Burglary Detection Devices Help Provide Proper Coverage for the Protected Premises.

Recommendations for Smoke and Heat Detectors

With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

• Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and areas of the household as follows: For minimum protection a smoke detector should be installed outside of each separate sleeping area, and on each additional floor of a multi-floor family living unit, including basements. The installation of smoke detectors in kitchens, attics (finished or unfinished), or in garages is not normally recommended.

• For additional protection the NFPA recommends that you install heat room, bedroom(s), kitchen, hallway(s), attic, furnace room, utility and storage rooms, basements and attached garages.

In addition, we recommend the following:

• Install a smoke detector inside every bedroom where a smoker sleeps.

• Install a smoke detector inside every bedroom where someone sleeps with the door partly or completely closed. Smoke

could be blocked by the closed door. Also, an alarm in the hallway outside may not wake up the sleeper if the door is closed.

• Install a smoke detector inside bedrooms where electrical appliances (such as portable heaters, air conditioners or humidifiers) are used.

• Install a smoke detector at both ends of a hallway if the hallway is more than 40 feet (12 meters) long.

• Install smoke detectors in any room where an alarm control is located, or in any room where alarm control connections

to an AC source or phone lines are made. If detectors are not so located, a fire within the room could prevent the control from reporting a fire or an intrusion.

THIS CONTROL COMPLIES WITH NFPA REQUIREMENTS FOR TEMPORAL PULSE

SOUNDING OF FIRE NOTIFICATION APPLIANCES.

or smoke detectors in the living room, dining

KITCHEN

DINING

LIVING ROOM

BEDROOM

BEDROOMBEDROOM

LIVING ROOM

BEDROOM

BASEMENT

KTCHN

BEDROOMBEDROOM

BEDROOM

CLOSED

DOOR

TV ROOM

BEDROOM

Smoke Detectors for Minimum Protection

Smoke Detectors for Additional Protection

Heat-Activated Detectors

GARAGE

KITCHEN

DINING

LIVING ROOM

BEDROOM

01000-002-V0

Recommendations For Proper Intrusion Protection

• For proper intrusion coverage, sensors should be located at every possible point of entry to a home or premises. This would include any skylights that may be present, and the upper windows in a multi-level building.

• In addition, we recommend that radio backup be used in a security system. This will ensure that alarm signals can be

sent to the alarm monitoring station in the event that the telephone lines are out of order (alarm signals are normally sent over the phone lines, if connected to an alarm monitoring station).

–2–

Table of Contents

SYSTEM FEATURES ...............................................................................................................................................4

MOUNTING THE CONTROL..................................................................................................................................5

WIRING CONNECTIONS........................................................................................................................................6

AC POWER AND BACKUP BATTERY...................................................................................................................9

INSTALLING WIRELESS ZONES........................................................................................................................11

MECHANICS OF PROGRAMMING .....................................................................................................................14

ZONE RESPONSE TYPE DEFINITIONS ............................................................................................................15

DATA FIELD DESCRIPTIONS .............................................................................................................................17

✻55 ENABLING THE 5842 WIRLESS DIALER ..................................................................................................25

✻56 ENHANCED ZONE PROGRAMMING MODE .............................................................................................27

✻80 DEVICE PROGRAMMING MENU MODE ...................................................................................................31

✻81 ZONE LIST MENU MODE.............................................................................................................................34

✻83 ENHANCED SEQUENTIAL MODE .............................................................................................................35

✻84 ASSIGN ZONE VOICE DESCRIPTORS .......................................................................................................38

✻85 RECORD CUSTOM VOICE DESCRIPTORS................................................................................................40

VOICE PROMPT PROGRAMMING......................................................................................................................41

REMOTE PROGRAMMING/CONTROL (DOWNLOADING) .............................................................................45

SYSTEM OPERATION ...........................................................................................................................................47

TESTING THE SYSTEM........................................................................................................................................53

SYSTEM COMMUNICATION...............................................................................................................................54

TROUBLESHOOTING GUIDE .............................................................................................................................56

CONTACTING TECHNICAL SUPPORT..............................................................................................................58

REGULATORY AGENCY STATEMENTS ...........................................................................................................59

SPECIFICATIONS..................................................................................................................................................60

LYNXR/LYNXR24 PROGRAMMING DEFAULT TABLES.................................................................................61

LYNXR-EN PROGRAMMING DEFAULT TABLES ............................................................................................62

INDEX......................................................................................................................................................................65

LIMITATIONS OF THIS SYSTEM STATEMENT...............................................................................................69

WARRANTY ............................................................................................................................................................70

SUMMARY OF CONNECTIONS DIAGRAM .......................................................................................................71

–3–

System Features

LYNXR and LYNXR-EN are not intended for UL985 Household Fire applications unless a 24-hour backup

UUUU

The LYNXR-Series controls are self-contained, rechargeable wireless control/communicators that feature easy installation and usage. A built-in speaker provides voice annunciation of system status along with voice descriptors of each zone (LYNXR-EN if programmed). The following illustration highlights the main features of this system.

• 1 hardwire zone

• Up to 24 wireless zones

(5800 Series Transmitters)

• Up to 16 wireless button zones

• Up to 8 Powerline Carrier Devices

• Supports wireless keypads

8 USER CODES

• Installer code

• Master code

• 5 Secondary codes

• Duress code

• 3 Panic functions

battery (P/N LYNXRCHKIT-HC) is installed.

LLLL

Powerline Carrier Devices are not UL Listed for fire or burglary functions and are intended for home automation.

ZONES and DEVICES

FEATURES

• Real-time Clock display and Fixed-Word display

• Message Center (for user recorded messages)

• Voice announcement of system and zone status

• Voice chime

• Alarm Clock

• Reminder

• X-10 Scheduling

• Latch Key Reports

• Automatic Stay Arming

• Remote Phone Control

• “Follow Me” Reminder and System Announcements

SYSTEM POWER

• Primary Power: Ademco

1332/1332X10 Plug-in Transformer, 110VAC to 9VAC, 15VA output (1332CN in Canada)

• Backup battery: Six 1.2V

rechargeable nickel-metal hydride batteries.

COMMUNICATION

• Ademco Low Speed

• Sescoa/Radionics

• Ademco Express

• Ademco Contact ID

• Paging feature

PROGRAMMING

• Options stored in EEROM

• Can be uploaded, downloaded or

controlled via IBM-compatible computer using Compass downloader software and specified HAYES modem

• Voice Prompt programming mode

ARMED

READY

OFF

TEST

VOLUME

FUNCTION

CHIME

BYPASS

PLAY

ALARM OUTPUT

• Built-in sounder

AUX

SELECT

STAY

DELETE

AWAY

ADD

ESCAPE

LIGHTS ON

LIGHTS OFF

STATUS

RECORD

NO DELAY

CODE

• Piezo output (30mA max.)

• Bell output (120mA max.)

• Steady output for

burglary/panic

• Temporal pulse

output for fire alarms

• Long Range

Radio/Alarm audio verification

SPECIAL FEATURES

OTHER FEATURES

• Exit error feature (detects difference between an

actual alarm and exit alarm caused by leaving a door open after the exit delay expires)

• Event log stores up to 84 events

• Macro/ 1-button paging

• RF Jam Detection

• Remote phone control

• Compatible with 5842 Wireless Dialer

• Compatible with encrypted (high-security) devices

LYNXR24

• 24-hour backup

LYNXR-EN

• Two-way voice communication

• Speaker phone operation

–4–

Mounting the Control

Wall Mounting

The illustration below shows the front assembly separated from the back plate.

DO NOT disconnect the ribbon cable from the terminal strip board. Disconnect the cable only from the front assembly board. Certain features differ between the LYNXR/LYNXR24 and the LYNXR-EN models. Verify the specific model

being installed prior to programming the system.

1. Separate the front assembly from the

back plate by pressing on the two locking tabs at the top of the unit.

2. Carefully disconnect the ribbon cable from the front assembly, leaving the

ribbon cable connected to the terminal block PC board. The back

plate contains the terminal block for making wiring connections.

3. Mount the back plate to a sturdy wall, feeding the field wiring through the appropriate openings in the back plate.

4. After wiring connections are made, carefully reconnect the ribbon cable to the front assembly PC board connector (properly aligning the red wire).

5. Before closing the assembly, verify which LYNXR model is being installed by checking the model number printed on the PC Boards. (Example: SALYNXREN indicates the unit being installed is a LYNXR-EN.)

6. Snap the front assembly to the back plate so it is secured by the locking tabs.

Desktop Mounting

If desired, an optional mounting base (model LYNX-DM, purchased separately) allows the LYNXR-Series controls to be used on a desktop.

1. Slide the control panel onto the mounting base locking tabs

2. Bring all wiring through the bottom of the mounting base, using one of the three wire entry locations, before making connections to the control panel.

3. Use tie-wraps to secure the wiring to the built-in wire loops as needed. Use the two supplied screws to secure the control panel to the mounting base.

PC BOARD

PART NUMBER

LOCATION

DISCONNECT

THIS END ONLY!

OFF

ESCAPE

AWAY

ADD

STAY

DELETE

AUX

SELECT

LOCKING TABS

RED WIRE MARKING

MXXXX

K5108

PC BOARD PART NUMBER LOCATION

01009-003-V0

WIRE ENTRY

KNOCKOUT

(1 of 3)

01009-004-V1

–5–

)

Wiring Connections

Wiring Overview

The following summarizes the connections required. Refer to the Wiring Connections paragraph and the Summary of Connections diagram on the inside back cover when making connections.

HARDWIRE ZONE

Supports 1 EOLR supervised zone using either closed circuit or open circuit sensors.

TWO-WAY VOICE

The LYNXR-EN supports the two-wa voice feature/Alarm Audio Verification. The LYNXR and LYNXR24 require the installation of the LYNXAVM.

PHONE LINES

Use either the plug-in jacks or the screw terminals.

Compatible with the ALARMNET 7845C and 7720 Devices.

POWERLINE CARRIER DEVICES

Supports up to 8 Powerline Carrier Devices for turning on/off lights and appliances. Requires the use of an ADEMCO 1332X10 transformer.

LONG RANGE RADIO

MXXXX

K5108

AC TRANSFORMER

Use the supplied ADEMCO 1332X10 9VAC, 15VA Plug-in Transformer (1332CN in

EARTH GROUND

See Earth Ground paragraph.

LOCAL SOUNDER DISABLE JUMPER Remove the shorting jumper (shunt) to disable local sounder, leaving only the external sounder active.

UL NOTE: Do not remove the shorting jumper (the shunt)

for UL installations.

Canada

01009-005-V0

SOUNDERS

The system includes a built-in sounder in the master keypad. If desired, an external bell or piezo sounder can be connected.

Bell: Use a 6-14V bell with maximum current drain of 120mA. Piezo: Use a 6-14V piezo sounder with maximum current drain of

30mA. This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . .

Wiring Connections

1. Make Earth Ground Connection - The designated earth ground terminal (1) must be terminated in a good earth ground

for the lightning transient protective devices in this product to be effective. The following are examples of good earth grounds available at most installations: Metal Cold Water Pipe - Secure a non-corrosive metal strap (copper is recommended) to the pipe that is electrically connected and secured to which the ground lead. AC Power Outlet Ground - Available from 3-prong, 120VAC power outlets only. To test the integrity of the ground terminal, use a three-wire circuit tester with neon lamp indicators, such as the UL Listed Ideal Model 61–035, or equivalent, available at most electrical supply stores.

a. Connect terminal 1 to a good earth ground.

–6–

Wiring Connections

2. Make Phone Line Connections - For local or full line

seizure proceed to the appropriate steps below.

Local Seizure

a. Connect the incoming phone line to either the

8-position jack or terminals 2 (TIP) and 3 (RING) on the Lynx.

b. Connect the handset phone lines to either the RJ11

GREY

jack or terminals 4 (TIP) and 5 (RING).

Full Line Seizure: The control must be placed in series with the incoming phone line. Plugging the

Direct Connect Cord directly into the RJ31X jack, allows the control to seize the phone line when an alarm occurs and normal phone line usage by the premises phones if the plug needs to be removed.

a. Cut the incoming RING and TIP phone lines

(typically red and green, respectively) and connect them to RJ31X terminals 4 (red) and 5 (green).

b. Connect the premises end of the cut RING and TIP

wires to RJ31X terminals 1 (grey) and 8 (brown) respectively.

c. Wire the flying leads of a Direct Connect Cord to the

RED

GREEN

TIP RING TIP RING

}

INCOMING

PHONE LINE

control’s phone terminals as shown in the diagram or plug into the 8-position jack.

d. Plug the Direct Connect Cord into the RJ31X jack.

HARDWIRED ZONE: If the EOLR is not at the end of the loop, the zone will not be properly supervised, and the system may not respond to an open circuit on the zone.

3. Make Hardwired Zone Connections - Zone 1 is an EOLR supervised zone that supports both open circuit and closed

circuit devices and has a response time of 350msec. Maximum zone resistance: 300 ohms, plus EOLR

Note: The hardwire zone cannot be used as a fire zone.

a. Connect sensors/contacts to the hardwired zone terminals 6 (+) and 7 (–). Refer to the Summary of Connections

diagram.

b. Connect closed circuit devices in series in the high (+) side of the loop. The EOL resistor must be connected in

series with the devices, following the last device.

c. Connect open circuit devices in parallel across the loop. The 2000-ohm EOLR must be connected across the loop

at the last device.

4. Make External Sounder Connections - The control panel supports either a 6-14VDC piezo sounder (30mA max.) or 6-14VDC bell (120mA max.; e.g. ADEMCO WAVE2EX). a. Connect a piezo sounder to terminals 10 (+) and 11 (–); OR a bell to terminals 11 (–) and 12 (+).

LOCAL SOUNDER DISABLE: The Master Keypad’s built-in piezo sounder can be disabled by removing the shorting jumper (shunt) on the terminal board. If disabled, however, no sounding

UUUU

LLLL

will occur upon AC loss, since the external sounder does not operate when AC power is lost.

Do not remove shorting jumper (the shunt) for UL installations.

5. Disable Local Sounder Option - If required the Master Keypad’s built-in piezo sounder can be disabled.

a. Remove the shorting jumper (shunt) on the terminal board.

6. Make Powerline Carrier Device Connections - The control panel supports up to 8 Powerline Carrier Devices. If using these devices, they must be connected to the ADEMCO 1332X10 transformer, as shown in the SUMMARY OF CONNECTIONS diagram. a. Connect the com/data/sync/ lines from the ADEMCO 1332X10 transformer to terminals 9, 13, and 14, respectively.

Note: If not using the supplied Ademco connection cable, you may need to reverse the black and yellow wire connections. Refer to the

✻80 Device Programming Menu Mode section for details on programming Powerline Carrier Devices.

–7–

RJ31X

2 1

GREY

BROWN

}

PREMISES

PHONES

Full Line Seizure Connections

7 8

DIRECT CONNECT CORD

8-POSITION

JACK

INCOMING

PHONE LINE

RING TIP

GREENRED

PREMISES PHONES

RING TIP

BROWN

01000-008-V0

Wiring Connections

WARNING:

TO PREVENT RISK OF SHOCK

DISCONNECT TELEPHONE LINE

AT TELECOM JACK BEFORE

SERVICING THIS UNIT.

EARTH

GROUND

INCOMING

PHONE

REMOVE TO

DISABLE

POS

JACK

LINE

GROUND

RJ11

HANDSET

PHONE

LINE

LOCAL SOUNDER

DISABLE SHUNT

THE LYNX SERIES CONTROLS ARE EQUIPPED WITH AN INTEGRAL RECHARGEABLE BATTERY PACK. LYNXR: P/N LYNXRCHKIT-SC LYNXR24: P/N LYNXRCHKIT-HC LYNXR-EN: P/N LYNXRCHKIT-SC OR P/N LYNXRCHKIT-HC

REPLACE EVERY FOUR YEARS

EARTH

TIP

INCOMING

TELEPHONE

LINE

PHONE

TIP

RING

PREMISES

TELEPHONE

WEEKLY TESTING IS

REQUIRED TO ENSURE

PROPER OPERATION

OF THIS SYSTEM

ALL OUTPUT CIRCUITS ARE POWER LIMITED.

AAV / LRR

TRIGGER

(LYNXR/LYNR24)

LRR

TRIGGER

HARD

ZONE

EOLR

(LYNXR-EN)

TRIGGER

SIGNAL

(NEG)

SOUNDERS

865

( )

USE ONLY 1332/1332X10 OR 1332CN

(+)( )

( )

(+)

PIEZO

BELL

6-14VDC 30mA max.

TRANSFORMERS PROVIDED

6-14VDC

120mA max.

(e.g. WAVE2EX)

NOTE

ZONE

(+)

WIRED

2k OHMS

PLCD

DATA

SYNC

OUT

POWERLINE

CARRIER DEVICES

1332/

1332X10/

1332CN

PLUG-IN

TRANSFORMER

9VAC, 15VA

SYNC

COM

DATA

1332X10

ONLY

CONNECTIONS

01009-009-V0

–8–

AC Power and Backup Battery

The system is powered by a 9VAC, 15VA Plug-in Transformer, ADEMCO 1332/1332X10 (1332CN in Canada). Refer to the wiring table below for wire gauge and length.

Use only the provided ADEMCO 1332/1332X10 or 1332CN Transformer

Distance from Transformer

to Control

Up to 75 feet #20

Wire Gauge

75 to 150 feet #18

150 to 300 feet #16

Wiring to the AC Transformer must not exceed 300 feet using 16-gauge wire. The voltage reading between terminals 15 and 16 of the control must not fall below 9.00VAC.

Do not plug the transformer into the AC outlet until after all wiring connections have been made.

Backup battery. In the event of an AC power loss, the system is supported by a long life backup battery that is supervised for connection and for low voltage conditions. If the battery is missing, or a low battery condition is detected, a “low battery” message is displayed and a report is sent to the central station. In addition, the system will beep once every 45 seconds to audibly indicate a low battery condition (press any key to stop the beeping).

AC Power and Rechargeable Backup Battery

Connecting AC Power and backup battery

1. Connect wires from the 1332/1332X10 (1332CN in

Canada) AC Transformer to terminals 15 and 16 as shown in the wiring diagram.

2. Remove battery retainer.

3. Peel the backing from tape on the back plate.

4. Insert battery pack into back plate.

5. Install battery retainer.

6. Connect battery connector to receptacle on

terminal block PC board.

7. After all wiring connections have been made, snap the front assembly to the back plate and plug the transformer into a 24-hour, 110VAC unswitched outlet.

Note: Rechargeable batteries may take up to 48-hours to

fully charge. The “LOW BAT” message should clear within four hours or by entering Test Mode.

BATTERY

PACK

BATTERY

RECEPTACLE

RETAINER

TAPE

WIRING

TERMINALS

NOTE

LYNXRCHKIT-HC

BATTERY PACK SHOWN

MXXXX

K5108

01009-007-V0

Ensure the cover is snapped closed prior to applying AC power.

–9–

AC Power and Backup Battery

AC Power and Rechargeable Backup Battery

The LYNXR Series is equipped with an integral, replaceable, rechargeable battery pack composed of six (6) rechargeable 1.2-volt nickel-metal hydride batteries. Select the appropriate battery pack, based on the installation’s requirement, and install the battery pack.

Model

LYNXRCHKIT-SC 4-hours (minimum) Approximately 1-hour before battery depletion

LYNXRCHKIT-HC 24-hours (minimum) At least 1-hour before battery depletion

Replacing the Rechargeable Battery

1. When battery replacement is required, unplug

the transformer from the wall outlet, and open the control panel cover.

2. Remove the battery retainer and disconnect the battery pack connector from the receptacle on the terminal block PC board.

3. Remove the battery pack from the back plate.

4. If required, replace the tape that secures the

battery pack.

5. Install a replacement battery pack (P/N LYNXRCHKIT-SC or LYNXRCHKIT-HC) into the back plate.

6. Install the battery retainer.

7. Connect the battery connector to the

receptacle on the terminal block PC board.

8. After the wiring connection has been made, snap the front assembly to the back plate.

9. Plug the transformer into a 24-hour, 110VAC unswitched outlet.

10. Rechargeable batteries may take up to 48hours to fully charge. The “LOW BAT” message should clear within four hours or by entering Test Mode.

Part Number

Battery StandbyTime

RETAINER

BATTERY

PACK

BATTERY

RECEPTACLE

Low Battery Notification

LYNXRCHKIT-HC OR LYNXRCHKIT-SC

BATTERY CONNECTOR

TAPE

MXXXX

K5108

01009-006-V0

Ensure the control panel assembly is snapped closed prior to applying AC power.

–10–

Installing Wireless Zones

General Information

Zones: The control supports up to 24 wireless zones using 5800 Series transmitters, and up to 16 wireless buttons. Range: The built-in RF receiver can detect signals from wireless transmitters within a nominal range of 200 feet. Transmitters: 5800 Series transmitters have built-in serial numbers that must be entered into the

system using the ✻56 or ✻83 interactive mode, or input to the control via the downloader. 5800 Series transmitters (except the 5800RL and 5827, described separately) do not have DIP switches. Each transmitter's zone number is programmed into the system in ✻56 mode. Some transmitters, such as the 5816 and 5817, can support more than one "zone" (referred to as loops or inputs). On the 5816, for example, the wire connection terminal block is loop 1,the reed contact is loop 2. Each loop must be assigned a different zone number.

The 5816 and 5817 Transmitters do not have EOL supervision of their loop wiring. Therefore, for UL Household Burglary installations, the loop wiring may not exceed 3 feet.

The 5800RL, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E, 5804WATCH, 5814, 5816TEMP, 5819, 5819S(WHS & BRS), and 5850(GBD) transmitters are not intended for any UL installations.

For button transmitters (RF "keys") such as the 5804 and 5801, you must assign a unique zone number to each individual button used on the transmitter. Each button on the transmitter also has a pre-designated loop or input number, which is automatically displayed.

House Identification If you are using a 5804BD/5804BDV, or 5827 Wireless Keypad with the system, you must program a House ID Code (01–31) in field ✻24 to establish proper communication, and the keypad must be set to the same ID. House ID 00 disables all wireless keypads. An RF House ID is not necessary for other 5800 Series transmitters; the entry should be left at “00” (default) in those cases. The 5827 reports low battery status as zone “00”.

Transmitter Supervision

Except for some transmitters/keypads that may be carried offpremises (5804, 5804BD, 5804BDV, 5804E, 5804WATCH, and

5827), each transmitter is supervised by a check-in signal that is sent to the receiver at 70–90 minute intervals. If at least one checkin is not received from each supervised transmitter within a 12hour period, the "missing" transmitter number(s) and "FAULT" will be displayed. The supervision for a particular transmitter in the system that may also be carried off the premises (5801, 5802MN) may be turned off by entering it as a "UR" (unsupervised RF) type, as described in the ✻56 Enhanced Zone Programming Mode section. 5800 Series transmitters have built-in tamper protection and will annunciate as a fault condition if covers are removed.

Transmitter Input Types

Each of the following transmitters has one or more unique factory-assigned input (loop) ID codes. Each of the inputs requires a programming zone Transmitters can be entered as one of the following types

input type)

Type Description

"RF" (Supervised RF) Sends periodic check-in signals, as well as fault, restore, and low battery signals. The

"UR" (Unsupervised RF) Sends all the signals that the "RF" type does, but the control does not supervise the

"BR" (Unsupervised Button RF) These only send fault signals. They do not send low battery signals until they are

•

58275804BD/5804BDV

5806/5807/5808 5890 / 5890PI5816

(e.g., a 5804's four inputs require four button zones).

(see transmitter’s instructions for appropriate

transmitter must remain within the receiver's range.

check-in signals. The transmitter may therefore be carried off-premises.

activated. The transmitter may be carried off-premises.

01009-010-V1

–11–

Installing Wireless Zones

Transmitter Battery Life

• Batteries in the wireless transmitters may last from 4–7 years,

depending on the environment, usage, and the specific wireless device being used. Factors such as humidity, high or low temperatures, as well as large swings in temperature may all reduce the actual battery life in a given installation. The wireless system can identify a true low battery situation, thus allowing the dealer or user of the system time to arrange a change of battery and maintain protection for that point within the system.

• Button-type transmitters should be periodically tested for battery life.

The 5801, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E, and 5804WATCH button transmitters have replaceable batteries.

5801

OFF

Using the Transmitter Sniffer Mode

Use this mode after all transmitters have been entered to check that all transmitters have been properly programmed.

1. Enter Installer code (4112) + [#] + 3.

Note: If the communicator is in the process of sending a report to the central station, the system will not go into the Sniffer mode.

If so, wait a few minutes and try again.

5804 /5804E

2. The keypad will display all zone numbers, which have a non-zero Zone Type (even if serial numbers were not learned yet). Fault each transmitter in turn, causing each one to send a signal. As the system receives a signal from each of the transmitters, the zone number of that transmitter will disappear from the display. The transmitters may be checked upon installation, or in an installed system.

3. When all transmitters have been checked, exit Sniffer mode. Enter Installer Code (4112) +

OFF.

Notes: (1) Sniffer mode does not automatically expire. You must manually exit (Installer Code + OFF) Sniffer mode to return to normal

(2) All BR-type units must physically be activated to clear the display, since they do not automatically send check-in signals.

(3) When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other buttons on that transmitter are

(4) Any transmitter that is not “entered” will not turn off its zone number.

operation.

cleared. This also applies to 5816 and 5817 transmitters that have multiple loops (zones).

Go/No Go Test Mode

Note: Encrypted (high-security) devices must be activated while the system is in Go/No Go Test Mode. Refer to the transmitter’s

installation instructions for complete details.

The Go/No Go tests will verify adequate RF signal strength from the proposed transmitter location, and allow you to reorient or relocate transmitters if necessary, before mounting the transmitters permanently. This mode is similar to the transmitter Test mode, except that the wireless receiver gain is reduced. This will enable you to make sure that the RF signal from each transmitter is received with sufficient signal amplitude when the system is in the normal operating mode.

1. Enter Installer Code (4112) + [#] + 8.

2. Once you have placed transmitters in their desired locations and the approximate length of wire to be run to sensors is connected to the transmitter's screw terminals (if used), fault each transmitter.

Conducting this test with your hand wrapped around the transmitter will cause inaccurate results.

Note: On button type transmitters that have been programmed to set ARM AWAY, ARM STAY, or DISARM, pressing a button will take the

system out of the Go/No Go Test mode and cause the programmed action.

a. The keypad will beep three times indicating signal reception and will display the appropriate

zone number.

b. If the keypad does not beep, reorient or move the transmitter to another location. Usually a

few inches in either direction is all that is required.

4. If each transmitter produces the proper keypad response when it is faulted, you can then permanently mount each of the transmitters according to the instructions provided with them.

5. Exit the Go/No Go Test mode by entering: Installer Code (4112) + OFF.

5802MN

01009-011-V0

–12–

Installing Wireless Zones

5800 Series Transmitter Loop Numbers (Refer to this information when programming transmitters)

The following illustration shows the compatible transmitters, their associated input types and loop

designations.

5800RL

SET

HOUSE ID

5806/5807/5808/5808LST

ENROLL AS

LOOP 2 (REED)

LOOP 3

(TERMINALS)

LOOP 1

"RF"

5819

ENROLL AS

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

LOOP 1 (TERMINALS)

"RF"

5801

ENROLL AS

"UR" OR "RF"

5809

ENROLL AS

LOOP 2

(TERMINALS)

LOOP 3

LOOP 2

LOOP 1

"RF"

(REED)

LOOP 3

5819S (WHS & BRS)

ENROLL AS

5802 MN

ENROLL AS

"UR" OR "RF"

ENROLL AS

LOOP 1 (INTERNAL SHOCK SENSOR

"RF"

5814

LOOP

"RF"

LOOP 1

5827

PROGRAM

HOUSE ID

7 6

LOOP

5802 MN2

ENROLL AS

"UR" OR "RF"

ENROLL AS

5816

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

5827BD

PROGRAM HOUSE ID

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

ALTERNATE

FOR LOOP 2

ENROLL AS "BR"

POSITION

ENROLL AS

ARMED

READY

OFF

5804/5804E

5816MN

5828V

PROGRAM HOUSE ID

LOOP 3

LOOP 2

LOOP 1

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

MIC

MESSAGE

LOOP 3

5816TEMP

ENROLL AS

5849

ENROLL AS

LOOP 2

•

5804BD/5804BDV

ENROLL AS

"BR"

PROGRAM HOUSE ID

LOOP 1 (TEMP SENSOR)

"RF"

LOOP 1 (SOUND)

"RF"

LOOP 4 YOU MUST ENROLL THIS BUTTON

LOOP 1

ENROLL AS

5850 (GBD)

ENROLL AS

Note: Loop 4 must be enrolled on the 5801, 5804, 5804BD, 5804BDV, 5804E and 5804WATCH transmitters, whether or not the loop is used.

The 5800RL, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E, 5804WATCH, 5814, 5816TEMP, 5819, 5819S(WHS & BRS), and 5850(GBD) wireless transmitters are not intended for any UL installations.

Setting DIP Switches on the 5800RL and 5827 Transmitter(s)

Set the 5800RL and 5827 Transmitters to the programmed House ID, by using the DIP switches.

(OFF position is indicated by ---)

Notes: (1) The 5827 transmitter cannot be used in conjunction with the ✻58 RF Jam Detection feature. (2) The 5800RL cannot be used in conjunction with the Auto Arm (scheduled arming) feature.

234561

SW-1 ACTIVATES

MODE SETTING

2-6 SETS HOUSE ID

SHOWN SET FOR HOUSE ID# 12

SWITCH UP FOR "ON"

SW-6 SETS

MODE

SWITCH DOWN

FOR "OFF"

01000-014-V1

0 --- --- --- --- --- 16 ON --- --- --- --1 --- --- --- --- ON 17 ON --- --- --- ON 2 --- --- --- ON --- 18 ON --- --- ON --3 --- --- --- ON ON 19 ON --- --- ON ON 4 --- --- ON --- --- 20 ON --- ON --- --5 --- --- ON --- ON 21 ON --- ON --- ON 6 --- --- ON ON --- 22 ON --- ON ON --7 --- --- ON ON ON 23 ON --- ON ON ON 8 --- ON --- --- --- 24 ON ON --- --- ---

9 --- ON --- --- ON 25 ON ON --- --- ON 10 --- ON --- ON --- 26 ON ON --- ON --11 --- ON --- ON ON 27 ON ON --- ON ON 12 --- ON ON --- --- 28 ON ON ON --- --13 --- ON ON --- ON 29 ON ON ON --- ON 14 --- ON ON ON --- 30 ON ON ON ON --15 --- ON ON ON ON 31 ON ON ON ON ON

DIP SWITCH POSITIONS DIP SWITCH POSITIONS House

2 3 4 5 6

Setting 5800RL DIP Switches

SWITCH UP FOR "ON"

2 3 4

HOUSE ID

SHOWN SET FOR HOUSE ID# 30

SWITCH DOWN FOR "OFF"

01000-013-VO

1 --- --- --- --- ON 17 ON --- --- --- ON

2 --- --- --- ON --- 18 ON --- --- ON ---

3 --- --- --- ON ON 19 ON --- --- ON ON

4 --- --- ON --- --- 20 ON --- ON --- ---

5 --- --- ON --- ON 21 ON --- ON --- ON

6 --- --- ON ON --- 22 ON --- ON ON ---

7 --- --- ON ON ON 23 ON --- O N ON ON

8 --- ON --- --- --- 24 ON ON --- --- ---

9 --- ON --- --- ON 25 ON ON --- --- ON 10 --- ON --- ON --- 26 ON ON --- O N --11 --- ON --- ON ON 27 ON ON --- ON ON 12 --- ON ON --- --- 28 ON ON ON --- --13 --- ON ON --- ON 29 ON ON ON --- ON 14 --- ON ON ON --- 30 ON ON ON ON --15 --- ON ON ON ON 31 ON ON ON ON ON 16 ON --- --- --- ---

5827 WIRELESS KEYPAD DIP SWITCH TABLE

DIP SWITCH POSITIONS DIP SWITCH POSITIONS House

1 2 3 4 5

Setting 5827 DIP Switches

5800RL DIP SWITCH TABLE

House

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

1:15:00 1:13:16

LOOP 3

5804WATCH

LOOP 1 (PRIMARY)

LOOP 2 (AUX. CENTER)

LOOP 3 (AUX. RIGHT)

5817

"RF"

(Green)

(Red)

(Yellow)

"RF"

2 3 4 5 6

1 2 3 4 5

ENROLL AS

5890/5890PI

ENROLL AS

LOOP 1

LOOP 2

LOOP 1

5818

LOOP 1 (MOTION)

"RF"

01009-012-V3

"RF"

–13–

Mechanics of Programming

General Programming Information

Programming options are stored in non-removable, electrically erasable, nonvolatile EEROM memory. The system can be programmed at any time, even at the installer's premises prior to the actual installation. Simply apply power temporarily to the Control and then program the unit as desired. There are two programming modes:

Data field programming (used for setting various system options)

•

• Interactive menu mode programming (used for programming zone information, programming Powerline Carrier

Devices, and for entering transmitter serial numbers) The system can also be programmed remotely, using an IBM Personal Computer, a modem, and Compass Downloader for Windows. See the Remote Programming/Control (Downloading) section.

Note: You may find it convenient to adjust the volume setting before entering the Program Mode. This will allow you to clearly hear the

feedback announcements or system beeps in the Programming Mode, of the system’s built-in speaker. To adjust the volume, press FUNCTION + VOLUME+ [3] or [6]. Upon exiting the Program Mode, the system will reset the volume to the default value (mid level).

Certain features differ between the LYNXR/LYNXR24 and the LYNXR-EN models. Verify the specific model being installed prior to the system programming.

Entering Program Mode - Use one of the following methods to enter Programming Mode:

1. Press both the [✻] and [#] keys at the same time, within 50 seconds after power is applied to the Control or from

exiting Programming mode, OR

2. After power-up, enter the Installer Code (4112) + 800 (This method disabled if Program mode is exited using

to enter Expert Programming mode or Installer Code (4112) + 888 to enter Voice Prompt Programming mode.

Notes: 1. If a different Installer Code has been programmed, use that code to enter the Programming mode. Once you have entered the

Program mode, data field

2. Entering Programming mode may take up to 18 seconds if the 5842 Wireless Dialer has been enabled. The system will display “ - - “ until the Lynx enters Programming mode.

Programming a Data Field

1. Press [✻] + Field No. (for example, ✻21), followed by the required entry.

2. When you have completely programmed a data field, the keypad will “beep” three times and then automatically

display the next data field in sequence. To go to a different field, press [

3. If the number of digits that will be entered in a data field is less than the maximum number of digits available (e.g.

phone number field), enter the desired data, then press [

4. If a nonexistent field has been entered, the keypad will display “EE”. Simply re-enter [

To view a data field without making changes: Enter [#] + Field No. Data will be displayed for that field. To delete an entry in a field: Enter [ Interactive Mode Programming (✻56, ✻80, ✻81, ✻83, ✻84, ✻85)

Press [✻] + interactive mode No. (for example, ✻56). The keypad will display the first of a series of prompts. A detailed procedure (with displays of prompts) is provided in later sections of this manual.

56 Enhanced Zone Programming Mode

✻ ✻80 Device Programming Menu Mode ✻81 Zone List Menu Mode

83 Enhanced Sequential Mode

✻ ✻84 Assign Zone Voice Descriptors ✻85 Record Custom Voice Descriptors

Loading Factory Defaults

To load the factory defaults, enter the Programming mode, press ✻97, then press number 1, 2, 3, or 4 to select from default tables 1-4 at the back of this manual, or press “0” if you are not selecting a default table.

If a default table is loaded, any data that has already been programmed into the system will be changed according to the default table selected!

✻96 resets all subscriber account numbers and CSID in preparation for an initial download. Exiting Program Mode

98 inhibits re-entry into the Expert or Voice Prompt Programming modes using the Installer Code.

✻ ✻99 allows re-entry into the Expert Program mode using Installer Code (4112) + 800 or into the Voice Prompt

Programming mode using Installer Code (4112) + 888.

Note: After exiting program mode (or upon power-up), the system takes up to a minute to reset. To bypass the reset delay, press [#] + [0].

✻20 (the first data field in the system) will be displayed and both keypad LEDs will flash.

✻] plus the desired field number.

✻] to advance to the next data field.

✻] + Field No. + [✻]. (Applies only to fields ✻40–✻44, ✻88 and ✻94).

Interactive Mode Used to Program

Zone characteristics, report codes, and serial numbers Powerline Carrier Devices Zone Lists for powerline carrier activation 5800 Series transmitter serial numbers Voice descriptors for each zone Up to 5 custom voice descriptors for zones

✻98.)

✻] plus a valid field number.

–14–

Zone Response Type Definitions

General Information

During programming, you must assign a zone type to each zone, which defines the way in which the system responds to faults in that zone. Zone types are defined below.

Type 00

Zone Not Used

Type 01

Entry/Exit Burglary #1

01000-017-V0

Type 02

Entry/Exit Burglary #2

01000-017-V0

Type 03

Perimeter

Burglary

01000-018-V0

Type 04

Interior, Follower

5890 / 5890PI

01000-019-V1

Type 05

Trouble by Day/

Alarm by Night

Type 06 24-hour

Silent Alarm

Zone type 00 is used to program a zone that is not used.

Zone type 01 is usually assigned to sensors or contacts on primary entry and exit doors.

Zone Characteristics:

• Entry delay #1 is programmable from 0-99 seconds (field

• Exit delay is independently programmable from 0-99 seconds (field

• Exit and entry delays when armed in AWAY or STAY mode.

• No entry delay when armed in STAY NO DELAY or AWAY NO DELAY mode.

• Exit delay regardless of the arming mode selected.

Zone type 02 is usually assigned to sensors or contacts on which secondary entry and exit doors that might be further from the keypad (typically used for a garage, loading dock, or basement door).

Zone Characteristics:

• Entry delay #2 is programmable from 0-99 seconds (field ✻36).

• Exit delay is independently programmable from 0-99 seconds (field

• Secondary entry delay, if armed in the AWAY or STAY mode.

• No entry delay when armed in the STAY NO DELAY or AWAY NO DELAY mode.

• Exit delay begins regardless of the arming mode selected.

Zone type 03 is usually assigned to all sensors or contacts on exterior doors and windows. Zone Characteristics:

• Instant alarm, when armed in AWAY, STAY, STAY NO DELAY, or AWAY NO

DELAY mode.

Zone type 04 is usually assigned to a zone covering an entry area (i.e.: foyer, lobby, or hallway) that one must pass upon entry (after faulting the entry/exit zone) to reach the keypad. It provides an instant alarm if the entry/exit zone is not violated first, and protects an area in the event an intruder has hidden on the premises before the system is armed, or gains access to the premises through an unprotected area.

Zone Characteristics:

• Delayed alarm (using the programmed entry/exit time) if entry/exit (types 01 or

02) or interior-with-delay (type 10) zone is faulted first.

• Instant alarm in all other situations.

• Active when armed in AWAY or AWAY NO DELAY mode.

• Bypassed automatically when armed in STAY or STAY NO DELAY mode.

Zone type 05 is usually assigned to a zone that contains foil-protected doors or windows or covers a sensitive area (i.e.: stock room, drug supply room, etc.) It can also be used on a sensor or contact in an area where immediate notification of an entry is desired.

Zone Characteristics:

• Instant alarm, when armed in AWAY, STAY, STAY NO DELAY, or AWAY NO

DELAY (night) mode.

• Provides a latched trouble sounding from the keypad and, if desired, a central

station report during the disarmed state (day).

Zone type 06 is usually assigned to a zone containing an Emergency button (silent emergency). Zone Characteristics:

• Sends a report to the central station but provides no keypad display or

sounding.

✻35).

✻34).

–15–

Zone Response Type Definitions

Zone type 07 is usually assigned to a zone containing an Emergency button (audible emergency). Zone Characteristics:

• Sends a report to the central station, and provides alarm sounds

externally and at the keypad.

Zone type 08 is usually assigned to a zone containing a button for use in personal emergencies or to a zone containing monitoring devices (i.e.: water or temperature sensors, etc.). Zone Characteristics:

• Sends a report to the central station and provides an alarm sound at

the keypad. (No bell output is provided and there is no keypad timeout.)

Zone type 09 can be assigned to any wireless zone used as a fire zone. This zone type is always active and cannot be bypassed. Zone Characteristics:

• Bell output will pulse when this zone type is alarmed.

Zone type 10 is bypassed when the panel is armed in the STAY or STA NO DELAY mode. Zone Characteristics:

• Entry delay #1 (with programmed entry time) when armed in the

AWAY mode.

• Entry delay begins whenever sensors in this zone are violated,

regardless of whether an entry/exit delay zone was tripped first.

• No entry delay when armed in the AWAY NO DELAY mode.

• Exit delay regardless of the arming mode selected.

Zone type 20 is a special-purpose zone type used with 5800 Series wireless pushbutton units. Zone Characteristics:

• Exit delay regardless of the arming mode selected.

• System is armed in the STAY mode when the zone is activated.

• Zone number is sent to the central station as a user number when

arming or disarming.

5806/5807/5808

01000-020-V0

Type 07 24-hour

Audible

Alarm

Type 08 24-hour

Auxiliary Alarm

Type 09

Supervised

Fire

Type 10

Interior w/Delay

Type 20

Arm–Stay

Type 21

Arm–Away

Type 22

Disarm

Type 23

No Alarm Response

Type 24

Silent Burglary

Zone type 21 is a special-purpose zone type used with 5800 Series wireless pushbutton units. Zone Characteristics:

• System is armed in the AWAY mode when the zone is activated.

• Zone number is sent to the central station as a user number when

arming or disarming.

Zone type 22 is a special-purpose zone type used with 5800 series wireless pushbutton. Zone Characteristics:

• Disarms the system when the zone is activated.

Zone type 23 can be used on a zone when a Powerline Carrier Device (e.g., X-10) action is desired, but with no accompanying alarm (e.g., front door light).

Zone type 24 is usually assigned sensors or contacts on exterior doors and windows where bells and/or sirens are NOT desired. Zone Characteristics:

• Instant alarm, with NO audible indication when is armed in the

AWAY, STAY, STAY NO DELAY, or AWAY NO DELAY mode.

• Report sent to the central station.

Note: Keypad beeps if the zone is faulted when system is disarmed and Chime

mode is on.

–16–

Data Field Descriptions

Defaults (where applicable) are Indicated in Text.

The following pages list all data fields in this Control (in numerical order). Use the blank programming form to record the data for this installation. Note that both keypad LEDs flash while in Programming mode.

Note: Entering a number other than the one specified will give unpredictable results.

✻

✻21

✻22

✻23

✻24

✻25

✻26

✻27

✻29

✻30

✻31

✻32

✻33

✻34

Installer Code

Enter 4 digits, 0-9

Quick Arm Enable

0 = do not allow quick arm 1 = allow quick arm

Keypad Backlight Timeout

0 = no timeout; always backlight keys 1 = turn backlighting off after inactivity

Forced Bypass

0 = no forced bypass 1 = provide automatic bypass of all open (faulted)

zones

RF House ID Code

00 = disable all wireless keypad usage 01-31 = House ID

Powerline Carrier Device (X-10) House ID

0 = A 4 = E 8 = I # + 12 = M 1 = B 5 = F 9 = J # + 13 = N 2 = C 6 = G # + 10 = K # + 14 = O 3 = D 7 = H # + 11 = L # + 15 = P

Chime by Zone

0 = no (chimes on fault of any entry/exit or perimeter

zone when Chime mode is activated

1 = yes (chimes on fault of those zones assigned to

Zone List 3 when Chime mode on)

Real Time Clock Display

0 = do not display the time 1 = display the time

Daylight Savings Time Start/End Month

0, 0 = no daylight saving time used 1-12 = start month and end month

Daylight Savings Time Start/End Week

0 = disable 4 = fourth weekend 1 = first weekend of month 5 = last weekend 2 = second weekend 6 = next to last 3 = third weekend 7 = 3

from last

Single Alarm Sounding Per Zone

(per armed period)

0 = no limit on alarm sounding per zone 1 = limit alarm sounding to once per arming period for

a given zone

LYNXR/LYNXR24 - Applies to Long Range Radio Output if “0” is selected in field ✻91 LYNXR-EN - Applies to Long Range Radio Output if Long Range Radio is connected to the Trigger Single (Neg.) terminal #8.

Fire Sounder Timeout

0 = yes, fire sounder timeout after time programmed in

field

✻33

1 = no fire sounder timeout; continue sounding until

manually turned off

Alarm Bell Timeout

0 = No timeout 2 = 8 min 4 = 16 min 1 = 4 min 3 = 12 min

Exit Delay

00-99 = exit delay time in seconds

–17–

The Installer Code is used to enter the 4-digit Master Security Code. See "Master Code" in the System Operation section for procedure.

If enabled, security code is not required to arm the system. The user simply presses and holds down the AWAY or STAY key to arm.

This option allows the choice of either always backlighting the keypad or turning the backlighting off after 10 seconds of keypad inactivity.

All zones bypassed by this function will be displayed after the bypass is initiated.

Note: UL installations: must be 0 (no forced bypass)

The House ID identifies receivers and wireless keypads. If a 5827 Wireless Keypad or 5804BD/5804BDV Transmitter is to be used, a House ID Code MUST be entered, and the keypad should be set to the same ID. Powerline Carrier Devices require a House ID. This field identifies this House ID to the Control. The Powerline Carrier Devices are programmed in field ✻80.

This option allows the installer to define the specific zones intended to chime when faulted while the system is in Chime mode. If enabled, these zones are defined in zone list 3 (see ✻81 Zone List Menu Mode).

Refer to the User’s Manual for setting the clock time and date.

Enter # + 10 for 10, # + 11 for 11, and # + 12 for 12.

Enter the appropriate start and end weekend of the month.

UL installations: must be 0 (no limit) This field applies only to burglary zones (zone response types 1-5, 10), and affects long range radio reporting but does not affect central station reporting.

Note: This field applies only to the bell and does not affect keypad

sounds.

This Control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . .

This field determines whether the external sounder will shut off after time allowed, or continue until manually turned off. UL installations: must be set for a minimum of 4 min (option 1)

The system will wait the time entered before sounding an alarm if the exit door is left open after the system has been armed. UL installations: must be set for a maximum of 60 seconds

Data Field Descriptions

✻35

✻36

✻37

Entry Delay 01

00-99 = entry delay time in seconds.

Entry Delay 02

00-99 = entry delay time in seconds.

Audible Exit Warning/Quick Exit

Exit Warning Quick Exit

✻38

0 = no exit warning

sound

1 = provide exit

warning sound when armed AWAY

Confirmation of Arming Ding

0 = no ding

0 = no quick

exit

1 = allow quick

exit

1 = confirmation ding after arming system 2 = confirmation ding after arming from RF button or

RF keypad only

✻39

Power Up In Previous State

0 = always power up in a disarmed state 1 = assume the system status prior to power-down

DIALER PROGRAMMING (✻40–✻50)

Fields ✻40, ✻41, ✻42: Enter up to the number of digits shown. Enter 0–9, # + 11 for ‘*’; # + 12 for ‘#’; # + 13 for a pause

(2 seconds)

NOTE: Whenever AAV is used, primary (field ✻41) and secondary (field ✻42) phone numbers should be preceded with the call waiting disable command. Otherwise, there is the possibility of connection of the third party to LYNX during AAV mode.

✻40

✻41

PABX Access Code

Enter up to 6 digits if PABX is needed to access an outside line.

Primary Phone No.

Enter up to 20 digits.

✻42

Secondary Phone No.

Enter up to 24 digits.

All four digits of the Subscriber Account number must be entered in Fields ✻43 and ✻44. If ten digit format is selected in ✻48 (option 5), all ten digits of the Subscriber Account number must be entered.

The system will wait the time entered before sounding alarm upon entering if system is not disarmed. UL installations: must be set for a maximum of 45 seconds

The system will wait the time entered before sounding alarm upon entering. UL installations: must be set for a maximum of 45 seconds

Exit Warning: Sound consists of slow continuous beeps until last 5 seconds, when it changes to fast beeps. The warning sound will end at the termination of exit delay.

Quick Exit: If enabled, user can restart the exit delay time after arming in STAY mode by entering the user code and pressing the STAY key, or by pressing the STAY key if Quick Arm is enabled. This avoids having the user disarm then re-arm the system after allowing someone to enter or exit

Confirmation of arming is provided by a 1/2 second external sounder “ding” that sounds when closing report is sent, or at the end of exit delay.

If Option 2 is selected the external sounder “ding” occurs immediately after the system receives the RF transmission.

When the system powers up armed, an alarm will occur 1 minute after arming if a zone is faulted, and any bypassed zones will be unbypassed. Note: If the previous state was armed AWAY or STAY, the system will not respond to sensor changes for 1 minute, which allows time for sensors such as PIRs to stabilize. UL installations: must be 1 (power up in previous state)

If fewer than 6 digits need to be entered, exit by pressing [✻]. To clear entries from field, press

If fewer than 20 digits entered, exit by pressing [✻]. To clear entries from field, press Note: Backup reporting (8 attempts are made to the secondary phone

If fewer than 24 digits entered, exit by pressing [✻]. To clear entries from field, press paging feature, enter the pager phone number here.

✻41✻

number if no kissoff is received after 8 attempts to the primary number) is automatic only if there is a secondary phone number

✻

42).

(field

✻42✻

✻40✻

. See backup reporting note for field ✻41. If using the

Fields ✻43 and ✻44:

Enter [✻] as the fourth digit if a 3-digit account number (for 3+1 dialer reporting format) is used. Enter 0 as the first digit of a 4-digit account number for Nos. 0000–0999. Enter [ CID®) is used. Exit field by pressing [✻] if only 3 digits are used. To clear entries from field, press ✻43 blank Programming Form for examples of account number entries. If using the paging feature, do not enter a leading 0 in the subscriber account number, and do not use digits A-F anywhere in the number. Some paging systems provide voice mail capability, which is activated by a leading 0 in the message. Enter digits 0–9; # +11=B; # +12=C; # +13=D; # +14=E; or # +15=F.

✻43

✻44

Primary Subs Account No.

Enter a four or ten digit account number.

Secondary Subs Account No.

Enter a four or ten digit account number.

✻

] as the fifth digit if a 4-digit account number (for 3+1,

✻ or ✻44✻

Enter the primary subscriber account number. To clear entries from field, press

Enter the secondary subscriber account number. To clear entries from field, press

✻43✻

✻44✻

. See

–18–

Data Field Descriptions

Field 46: Enter up to 24 digits. Do not fill unused spaces. Enter 0-9, #+11 for ‘*’; #+12 for’#’; #+13 for a pause (2 seconds).

“Follow Me Reminder” Phone Number

✻46

✻47

✻48

✻49

Enter up to 24 digits.

Phone System Select

Note: For LYNXR/LYNXR24 only options 0, 1, 2, and 3

are applicable. For LYNXR-EN all options apply.

Central Dialing Mode

Station Pulse Tone Pulse Tone

No WATS 0 = No

WATS 2 = No

Report Format for Primary/Secondary

Speaker Phone

Primary Secondary See choices below See choices below

0 = 3+1; 4+1 ADEMCO Low Speed Standard 1 = 3+1; 4+1 Radionics Standard 2 = 4+2 ADEMCO Low Speed Standard 3 = 4+2 Radionics Standard 5 = ADEMCO Contact ID® Reporting with 10-digit

subscriber account number 6 = 4+2 ADEMCO Express 7 = ADEMCO Contact ID® Reporting with 7-digit

subscriber account number 8 = 3+1; 4+1 ADEMCO Low Speed Expanded 9 = 3+1; 4+1 Radionics Expanded

Split/Dual Reporting

To Primary To Secondary

0 = All reports None, unless primary fails, then all 1 = Alarms, Restore, Cancel Others 2 = All except Open/Close, Test Open/Close, Test 3 = Alarms, Restore, Cancel All 4 = All except Open/Close, Test All

5 = All reports All

To Primary To Paging Number

6 = All reports except Open/Close Alarms, Open/Close ‡, Troubles 7 = All reports Alarms, Troubles

8 = All reports Alar ms, Open/Close ‡, Troubles

9 = All reports except Open/Close Open/Close

To Primary To Follow Me System Phone Number

10=All reports except Open/Close Alarms, Open/Close ‡, Troubles 11 = All reports Alarms, Troubles

12=All reports Alarms, Open/Close ‡, Troubles

13=All reports except Open/Close Open/Close ‡

‡

Will report Users 0, 5-8, and, if using wireless button-type devices, will report the zone number of the arm or disarm button 26-33. All other zones and users are not reported.

1 = No Speaker Phone

3 = No Speaker Phone

4 = With

Speaker

Phone

6 = With

Speaker

Phone

5 = With Speaker Phone

7 = With Speaker Phone

‡

This option allows the user to schedule a time driven message. When activated the system will dial the phone number programmed and deliver a voice message (custom words 72, 73 and 74). This option is only supported when the pager or follow me feature is enabled in field 10-13). If using the Follow Me Reminder feat ure, enter the phone number here. If fewer than 24 digits are entered, exit by pressing [ the field press

The telephone message can be terminated (acknowledged) by pressing any key on the telephone keypad. Pressing any key on the local LYNXR keypad will terminate (acknowledge) bot h the follow me and the local reminder announcements. Note: The follow me reminder announcement will be terminated if any

This option is used to enter the correct type of phone dialing (pulse or tone), and to select the correct WATS line option for the Central Station. For LYNXR-EN this option is used to activate the speaker phone option.

Note: If using pulse dialing, you must enter the numbers slowly in order to

Enter ✻ as the 4th digit of ✻43 through ✻44, if 3+1 dialer reporting is to be used. (For an explanation of these formats, see the System Communication section of this manual.) Notes: (1) The maximum number of alarm and alarm restore reports

(2) If Option 5 is selected a 10-digit account number must be

(3) Option 5 or 7 (ADEMCO Contact ID® Reporting) must be

(4) Option 5 or 7 (ADEMCO Contact ID® Reporting) must be

This field is used to select a reporting option as follows:

Enter: 0 - 5 when reporting to telephone receivers.

6 - 9 when reporting to a pager is desired.

10 - 13 when reporting to an auxiliary telephone receiver.

Pager Report Format

Options 6-9 send reports to the primary phone number, in a format defined

in Field

entered as the secondary phone number in Field 7-digit code, with optional 16-digit prefix, in the following format: AAAAAAAAAAAAAAAA-EEE–00NN where:

AAA = Optional 16 digits for PIN number, etc. See Field

EEE = 3-digit Event Code as follows: 911 = Alarm (NN = zone number) 101 = Open, system disarmed (NN = user no.) 102 = Close, system armed (NN = user no.) 811 = Trouble (NN = zone no.) 00 = Always displayed before 2-digit user/zone no. NN = 2-digit user number or zone number, depending on the type of

Follow Me System Report Format

Options 10-13 send reports to the primary phone number, in a format

defined in Field

number entered in Field

The message is a repeatable system status announcement. If the manual

paging option has been programmed in Field “system, system…..”.

The message can be terminated by pressing any key on the telephone

keypad.

✻46✻

other event requires the system to dial out or if and audible alarm has occurred.

allow the pulse dialer time to operate.

during one armed period is determined by field ✻92.

✻

42.

43 or ✻44.

entered in Fields

selected for AVM.

selected if installing the 5842 Wireless Dialer.

✻

48, and send reports to a pager, which has its phone number

description of these characters.

event (EEE) that occurred. NN=00 indicates AC loss, system low battery, or low battery in 5827.

✻

48, and sends voice message to the secondary phone

✻

49 (option 6-9 or

✻

]. To clear entries from

✻

42. The pager report is a

✻

87, the message will repeat

88 for full

–19–

Data Field Descriptions

✻50

✻51

✻52

✻53

✻

✻58

15-Second Dialer Delay (Burglary)

0 = no dialer delay 1 = provide 15-second delay of burglary alarm report when armed away

Periodic Test Report

0 = no test report 2 = weekly 1 = once every 24 hrs 3 = once every 30 days

First test Report Offset

0 = 24 hrs after exit program mode or download 1 = 6 hours after exit program mode or download 2 = 12 hrs after exit program mode or download 3 = 18 hrs after exit program mode or download

Sescoa/Radionics Select

0 = Radionics (0–9, B–F reporting) 1 = SESCOA (0–9 only reporting)

Lack of Usage Notification

0 = Disabled 4 = 90 days 1 = 1 day 5 = 180 days 2 = 7 days 6 = 365 days 3 = 27 days

Note: There will be no local annunciation indicating that

this report has been sent to the Central Station.

RF Jam Detection

0 = no jam detection 1 = RF jam detection with event logging, but no

central station report

2 = RF jam detection with event logging and with

central station report (if trouble/restore report is enabled in fields ✻60, ✻71)

SYSTEM STATUS AND RESTORE REPORT CODES PROGRAMMING (✻59 –

Program Report Codes using the interactive ✻56 Enhanced Zone Programming Mode, or codes can be entered in data fields ✻59-✻76, ✻89. The following is a set of guidelines when programming report codes. The actual report code digits that you enter depend upon the particular installation, and should be in agreement with you and the central station office receiving the signals.

With a 3+1 or 4+1 Standard Format: Enter a code in the first box: 1–9, A, B, C, D, E, or F. Enter "#+10" for A (reports a “0” on some receivers), "#+11" for B, "#+12" for C, "#+13" for D, "#+14" for E, "#+15" for F. Entering "0" in the first box will disable a report. Entering "0" in the second box results in automatic advance to the next field.

With an Expanded or 4+2 Format: Enter codes in both boxes (1st and 2nd digits) for 1–9, or A–F, as described above. Entering "0" in the first box will disable a report. Entering "0" in the second box will eliminate the expanded message for that report.

With ADEMCO Contact ID® Reporting: Enter a digit in the first box to enable the zone to report. Use a different digit for each zone until you have used up available digits. If the number of zones exceeds the number of available digits, begin with digit 1 again. This is an "enabling" code only and is not the actual code sent to the central station office. Entries in the second boxes will be ignored. For system status (non-alarm) codes, enter a “1” in the first box for all the system conditions you want to send to the central station. A "0" in the first box disables the report.

If enabled, provides communication delay to the central station and allows the subscriber time to avoid a false alarm transmission. Delay does not apply to zone type 6, 7, 8, and 9 alarms, which are always sent as soon as they occur. UL installations: must be 0 (no delay)

Test report code entered in field ✻64 is sent.

This is the time to first report from programming or downloading.

Select 0 for all other formats.

If enabled, notifies the central station if an end user is not operating their security system by sending a System Inactivity report 654. The report will be sent only to the Primary phone number and only if Contact ID® format was selected. Note: The report will follow the

was made in

For Event Logging, Option 2 must be selected.

If the control detects an RF jam condition, a “FAULT” message appears for zone 90. The Contact ID® code for RF Jam is 344. Note: This feature cannot be used in conjunction with the 5827 wireless

keypad.

✻

49.

✻

49 = 0 rules, no matter which selection

✻

76, & ✻89)

–20–

SYSTEM STATUS REPORT CODES (✻59–✻68)

✻59

Exit Error Report Code

(See notes above)

✻60

✻61

✻62

✻63

✻64

✻65

✻66

✻67

✻68

Trouble Report Code

(See notes above)

Bypass Report Code

(See notes above)

AC Loss Report Code

(See notes above)

Low Battery Report Code

(See notes above)

Test Report Code

(See notes above)

Open Report Code

(See notes above)

Arm AWAY/STAY Report Code

(See notes above)

RF transmitter Low Batt. Report Code

(See notes above)

Cancel Report Code

(See notes above)

RESTORE REPORT CODES (✻70–✻76)

✻70

✻71

✻72

✻73

✻74

Alarm Restore Report Code, 1st Digit

(See notes above)

Trouble Restore Report Code

(See notes above)

Bypass Restore Report Code

(See notes above)

AC Restore Report Code

(See notes above)

Low Battery Restore Report Code

(See notes above)

Data Field Descriptions

If the system is armed and an entry/exit or interior zone is still open after the exit delay time has expired, an alarm will sound at the keypad and external sounder. If the system is disarmed before the end of the entry delay that immediately follows, the alarm sounding will stop and no message will be sent to the central station. The keypad will display “CA (CANCELED ALARM).” If the system is not disarmed before the end of the entry delay mentioned above, and an entry/exit or interior zone is still open, an “exit alarm” message will be sent to the central station if an Exit Error report code is selected in this field. The keypad will display “EA (EXIT ALARM),” and the alarm sounding will continue until the system is disarmed (or timeout occurs). An Exit Alarm condition will also result if a fault occurs in an exit or interior zone within 2 minutes following the end of the exit delay, and an “Exit Alarm” message will be sent to the central station. If Contact ID® format has been programmed, the message will contain the zone number and error code 374 (Trouble–Exit Error). If 4+2 format is used, the digit entered in this field will be sent followed by the second digit of the programmed alarm code for that zone. If 3+1 or 4+1 format is used, only the digit entered in this field will be sent. This message will go to the primary phone no. Under any of these conditions, no restore message will be sent. If “0” is entered in this field, no special message will be sent, only the regular alarm and alarm restore code for the zone.

This will be sent if a zone goes into trouble.

This will be sent when a zone is manually bypassed.

Timing of this report is random with up to a 4-hour delay. If AC restores before the report goes out, there is no AC restore report.

This will be sent when a low battery condition exists in the system’s standby battery.

This is sent periodically to test that the communicator and phone lines are operational (frequency of report is selected in field

This is sent upon disarming of the system. 2nd digit = user number, if expanded or 4+2 reporting is selected.

This option allows for independent programming of AWAY and STAY reports. 2nd digit of report is user number if expanded or 4+2 reporting is selected. NOTE: OPEN reports are not sent if the associated closing report is not enabled.

This is sent in the event that a wireless transmitter low battery condition exists.

This is sent upon disarming of the system after an alarm condition was reported.

Sent when the zone that caused an alarm is restored to its nonfaulted condition. 2nd digit is automatically sent as the 2nd digit of the zone alarm report code programmed in field 4+2 reporting is selected.

Sent when a trouble in a zone is restored.

Sent when a zone that has been bypassed is unbypassed.

Sent when AC power has been restored after an AC power outage.

Sent when a system low battery condition is restored to normal.

✻

56, if expanded or

✻

51).

–21–

Data Field Descriptions

RESTORE REPORT CODES (✻70–✻76) Continued

✻75

✻76

✻87

✻88

✻89

✻90

RF Transmitter Low Batt. Restore Code

(See notes above)

Test Restore Report Code

(See notes above)

AUX Function/1-Button Paging

0 = Aux key performs defined function (macro) 1 = Aux key sends predefined message to pager or a

voice message to Follow Me system phone number

Pager Characters

Enter up to 16 digits that will appear in front of the 7digit pager message. Enter [#] + [11] for “*” Enter [#] + [12] for “#” Enter [#] + [13] for 2-second pause

NOTES: Verify that the pager supports [*] and [#]

characters before using them. Some pagers require an additional delay [pause] in order to receive the entire message.

Event Log 80% Full Report Code

(See notes above)

Event Logging Options

0 = No event logging 1 = log Alarm/Alarm Restore 2 = log Trouble/Trouble Restore 4 = log Bypass/Bypass Restore 8 = log Open/Close x = log combination of events (add value of entries)

Sent when a transmitter that previously sent in a “low battery” message has sent a message indicating it no longer has a low battery condition.

Sent when the test mode is exited. A restore code entered here will cause a restore message to be sent when Test mode is exited.

If “0” is entered, user can define a macro function for the AUX key. See user manual for description of the use of this key. If “1” is entered, you must also select an option in field are 6-9 for the pager or 10-13 for the follow me system announcement. The actual pager message is 999-9999. Note that the hyphen may not be displayed, depending on the pager service. The manual follow me system announcement is a repeatable “System, System…..”.

Note: A macro cannot be run from the Test mode.

If entered, these digits will appear in front of the 7-digit pager message sent by the control (either upon a system event or upon pressing the AUX key [if programmed for paging]), and during latch key report (if enabled during scheduling). These digits can consist of a PIN number, account number, pauses or special digits needed by the pager (these types of characters are not displayed), or any other characters the user chooses that will be displayed (eg., using a character code to distinguish between control panel messages and other pager messages).

You do not need to fill all 16 digits. Press [ the field. To clear the field, press

See field ✻87 to select the AUX key Paging feature. See field ✻49, which must have an option 6-9 selected to enable paging messages, for description of the pager message.

If an Event Logging selection is made in field ✻90, a message can be sent to the central station receiver when the log is 80% full. If the log becomes full, a new message will overwrite the oldest message in the log. Note: All control and readout from the log, aside from the selection made

by the installer in field ✻90, is accomplished via the downloader.

Example: To select “Alarm/Alarm Restore” and “Open/Close,” enter 9 (1 +

8); to select all events, enter #15. Default “3” = alarm/alarm restore (1) plus trouble/trouble restore (2). The system has the ability to record various events in a history log (84event capacity). The types of events to be logged can be selected as indicated. At any time, the downloader operator can then upload the log and view or print out all or selected categories of the log. The log can also be cleared by the download operator. The display/printout at the central station will show the date, time, event, and description of the occurrences. Note: System messages are logged when any non-zero selection is made.

✻88✻.

✻

] + next field number to exit

✻

49. The options

–22–

+ 50 hidden pages

Pentax ADEMCO LYNXR Setup Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
