Pentair Everpure EV4339-31 Specifications

B E N E F I T S

A P P L I C A T I O N / S I Z I N G

I N S T A L L A T I O N T I P S

O P E R A T I O N T I P S

EV4339-31

Everpure Claris Flowmeter

Monitoring system for Claris filter cartridge systems

The CLARIS Flow Sensor has been developed
specifically to monitor the usage rate of the
CLARIS water filter system and to determine
the optimum cartridge replacement interval. After
setting the programming unit to monitor the
specific filter size, the Claris Flow Sensor
continually measures the filtrate volume to
calculate and display the remaining filtration
capacity in litres. Once the available filtration
capacity is exhausted or the maximum operation
time has been reached the display unit indicates
the filter cartridge replacement. The
programming and display unit provides the
following information:

If mounting display to a wall, securely connect
the display to the wall using suitable screws or
mounting hardware

Shut off valve must be installed upstream of
the filter

Refer to Installation, Operation & Maintenance
Manual for flowmeter start up and programing

Everpure Claris Flowmeter: EV4339-31

Change Claris cartridge when its pre-calculated water
volume has been reached or at least once a year

Change cartridges when capacity is reached

 Residual capacity of installed filter cartridge
 Filtrate volume of the last five installed

filter cartridges

 Operation time of the last five installed

filter cartridges

 Total filtrate volume since Flow Sensor

installation

S P E C I F I C A T I O N S

WA R R A N T Y

SENSOR UNIT:

Connection:
In 3/8“ BSP F nut / out 3/8“ BSP M

Operating Pressure:
2 - 8 bar (29 - 116 PSI)

Flow rate:
10 - 100 (.04 - .44 gpm)

Pressure loss (up to 100l/h flow rate) [bar]:
0,2 (3 PSI)

Precision (horizontal installation):
[%] +/-5
Water Temperature (min/max):
39 - 86 °F (+4 - +30 °C)

Ambient Temperature (min/max):
39 - 104 °F (+4 - +40 °C)

Everpure Claris Flowmeter

1.75 oz. (50 grams) Individually Wrapped Packets

Dimensions (BxHxT):

3.15" x 1.81" x 1.69" (80 x 46 x 43 mm)

Installation position:
Horizontal recommended

PROGRAMMING AND DISPLAY UNIT:

Splash proof:
IP X4

Display 5 digits
Counter 99999 - 9999 Gal.
(Downwards 99999 to -9999 L )

Dimensions (BxHxT):

1.97" x 2.95" x .67" (50 x 75 x 17 mm)

Cable:
59" (1.5 meters)

Everpure Claris water treatment systems are covered by a limited
warranty against defects in material and workmanship for a period
of one year after date of purchase. Everpure replaceable elements
(filter cartridges and water treatment cartridges) are covered by a
limited warranty against defects in material and workmanship
for a period of one year after date of purchase. See printed warranty
for details. Everpure will provide a copy of the warranty upon request.

EVERPURE, LLC
1040 Muirfield Drive
Hanover Park, IL 60133
Toll Free [phone]
Tel [phone]
Fax [phone]
www.everpure.com
