Pentair T40-B Installation Instructions

AUTOMATIC POOL FILLER

INSTALLATION MANUAL

Model # T40-B

Installation Instructions

Prior to installation, check local building codes for exceptions to these

instructions

1. Install leveler bucket so top of bucket is flush with bond beam of pool (See Fig. A). Ring and
Lid then should be installed flush with deck. Use rebar mounting flanges provided on bucket

to insure and aid in keeping bucket level during concrete pour.

2. Install 1 1/2" equalizer pipe. IMPORTANT: Equalizer pipe must be straight, as shown in

Figure A. The use of any 45

PVC to ABS joint cement for this application.

o

or 90o could cause air lock and void warranty. Use only

3. Connect 3/4" fresh water supply pipe to side leveler bucket. (See Fig. A).

4. You can pressure test auto-fill by plugging threaded hole where brass valve is to be installed

with 3/8" standard threaded plug. CAUTION: Do not over tighten.

5. Remove test plug and flush supply line for approximately 60 seconds or until all debris has
cleared.

6. Connect 3/4" overflow pipe in port (See Fig. A), using a PVC to ABS joint cement.

7. Install Brass Valve assembly with Teflon tape. IMPORTANT: Do not use liquid or past

sealers. Pentair Pool Products Inc, does not cover warranty. If damaged because of
over tightening or cross threading.

8. Adjust water level by loosening the wing screw on brass float arm and adjust up or down and

tighten when water level is achieved.

REV. A 03-09-04

www.pentairpool.com

Part #YYLEVB

Model # T40-B

INSTALLATION GUIDES

AUTOMATIC POOL FILLER
