Penn Scale HH120D User Manual

Hand-Held Series

Portable Electronic Scales Models HH120D, HH120 and HH320

Convenient, compact and portable weighing capability in the palm of your hand! These little scales
with sleek styling and convenient size are ideal to take anywhere–throw it in a brief case or drop it in
a backpack. Whether you choose the HH120D model with basic grams weighing or the HH120 and
HH320 models with multiple weighing units, the OHAUS Hand-Held series offers outstanding
performance and exceptional value.

Standard Features Include:

• Unique hand-held design

• Energy-saving auto shut-off feature

• Protective snap on cover for storage and transport

• Large high contrast display

• Backlit display on HH120 and HH320 models

• Rugged plastic construction

Hand-Held Series Portable Scales

Specifications

Model HH120D HH120 HH320

Capacity x Readability (g)

Linearity (g)

Weighing units g g, oz, dwt, oz t

Zero range To capacity by subtraction

Calibration User calibration

Stabilization time 3 seconds

Maximum overload 150% of capacity

Auto shut-off 5 minutes no activity

Optimum operating temperature 64°-77°F / 18°-25°C

Display (in/mm) LCD (0.4/11)

Weigh pan size L x W (in/cm) 3.25 x 3.0 / 8.3 x 7.6

Power requirements 2-AAA alkaline batteries (included)

Dimensions L x W x H (in/cm) 5.35 x 3.25 x 0.8/13.6 x 8.3 x 2.0

Net Weight (lb/kg) 0.34 / 0.16

0-60 x 0.1

60-120 x 0.2

0 - 60g: ±0.1

60 - 120g: ±0.2

120 x 0.1 320 x 0.1

±0.1 ±0.2

Standard Features

Low battery indicator, overload and underload indicators, 2-AAA batteries, rugged plastic construction, protective
snap-on cover, easy calibration. Button activated luminescent display on HH120 and HH320.

Industry Leading Quality and Support

All OHAUS Hand-Held Scales are manufactured under an ISO 9001:2008 Registered Quality Management System.
Our rugged con struc tion and stringent quality control have been hallmarks of all OHAUS products for over a century.

OHAUS CORPORATION

* 7 Campus Drive
Suite 310
Parsippany, NJ 07054 USA

Tel: [phone]

973.377.9000
Fax: [phone]

www.ohaus.com

With offices throughout Europe,
Asia, and Latin America

* ISO 9001

Registered Quality Management System

80774394_A © Copyright OHAUS Corporation
