Penguin Computing Relion 2804e Technical Manual

Relion 2804e

Technical Guide
Rev. 1.0

PENGUIN

COMPUTING

www.penguincomputing.com | 1-888-PENGUIN (736-4846) | twitter:@PenguinHPC

Intel® Server System R2000LH2/LT2
Family Service Guide

A Guide for Technically Qualified Assemblers of Intel® identified Subassemblies/Products

Order Number: G42282-004

Disclaimer

ii Intel® Server System R2000LH2/LT2 Service Guide

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by

estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel®’s

Terms and Conditions of Sale for such products, Intel® assumes no liability whatsoever, and Intel® disclaims any

express or implied warranty, relating to sale and/or use of Intel® products including liability or warranties relating to
fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual

property right. Intel® products are not designed, intended or authorized for use in any medical, life-saving, or life

sustaining applications or for any other application in which the failure of the Intel® product could create a situation

where personal injury or death may occur. Intel® may make changes to specifications and product descriptions at
any time, without notice.

Intel® server boards contain a number of high-density VLSI and power delivery components that need adequate

airflow for cooling. Intel®’s own chassis are designed and tested to meet the intended thermal requirements of these
components when the fully integrated system is used together. It is the responsibility of the system integrator that

chooses not to use Intel® developed server building blocks to consult vendor datasheets and operating parameters to
determine the amount of airflow required for their specific application and environmental conditions. Intel
Corporation cannot be held responsible if components fail or the server board does not operate correctly when used
outside any of their published operating or non-operating limits.

Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries.

* Other names and brands may be claimed as the property of others.

Copyright © 2012 Intel Corporation. All Rights Reserved.

Safety Information

Intel® Server System R2000LH2/LT2 Service Guide iii

Safety Information

Important Safety Instructions

Read all caution and safety statements in this document before performing any of the instructions.
See also Intel® Server Boards and Server Chassis Safety Information on the Intel® Server
Deployment Toolkit 3.0 CD and/or at

http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.

Wichtige Sicherheitshinweise

Lesen Sie zunächst sämtliche Warnund Sicherheitshinweise in diesem Dokument, bevor Sie eine
der

Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel®-
Serverplatinen und Servergehäusen auf der Intel® Server Deployment Toolkit 3.0 CD oder unter

http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.

Consignes de sécurité

Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document
avant de suivre toute instruction. Consultez Intel® Server Boards and Server Chassis Safety
Information sur le Intel® Server Deployment Toolkit 3.0 CD ou bien rendez-vous sur le site

http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.

Instrucciones de seguridad importantes

Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar
cualquiera de las instrucciones. Vea Intel® Server Boards and Server Chassis Safety Information en
el Intel® Server Deployment Toolkit 3.0 CD y/o en

http://www.intel.com/support/motherboards/server/sb/cs-010770.htm.

重要安全指导

在执行任何指令之前，请阅读本文档中的所有注意事项及安全声明。和/或

http://www.intel.com/support/motherboards/server/sb/cs-010770.htm 上的 Intel® Server Boards

and Server Chassis Safety InformationIntel® 服务器主板与服务器机箱安全信息。

Warnings

iv Intel® Server System R2000LH2/LT2 Service Guide

Warnings

Heed safety instructions: B

efore working with your server product, whether
you are using this guide or any other resource as a reference, pay close
attention to the safety instructions. You must adhere to the assembly
instructions in this guide to ensure and maintain compliance with existing
product certifications and approvals. Use only the described, regulated
components specified in this guide. Use of other products/components will
void the UL listing and other regulatory approvals of the product and will
most likely result in noncompliance with product regulations in the region(s)
in which the product is sold.

System power on/off: The power button DOES NOT turn off the system AC
power. To remove power from the system, you must unplug the AC power
cord from the wall outlet. Make sure the AC power cord is unplugged before
you open the chassis, add, or remove any components.

Hazardous conditions, devices and cables: Hazardous electrical conditions
may be present on power, telephone, and communication cables. Turn off the
server and disconnect the power cord, telecommunications systems, networks,
and modems attached to the server before opening it. Otherwise, personal
injury or equipment damage can result.

Electrostatic discharge (ESD) and ESD protection: ESD can damage disk
drives, boards, and other parts. We recommend that you perform all
procedures in this chapter only at an ESD workstation. If one is not available,
provide some ESD protection by wearing an antistatic wrist strap attached to
chassis ground - any unpainted metal surface - on your server when handling
parts.

ESD and handling boards: Always handle boards carefully. They can be
extremely sensitive to ESD. Hold boards only by their edges. After removing
a board from its protective wrapper or from the server, place the board
component side up on a grounded, static free surface. Use a conductive foam
pad if available but not the board wrapper. Do not slide board over
any surface.

Installing or removing jumpers: A jumper is a small plastic encased
conductor that slips over two jumper pins. Some jumpers have a small tab on
top that you can grip with your fingertips or with a pair of fine needle nosed
pliers. If your jumpers do not have such a tab, take care when using needle
nosed pliers to remove or install a jumper; grip the narrow sides of the
jumper with the pliers, never the wide sides. Gripping the wide sides can
damage the contacts inside the jumper, causing intermittent problems with
the function controlled by that jumper. Take care to grip with, but not
squeeze, the pliers or other tool you use to remove a jumper, or you may
bend or break the pins on the board.

Preface

Intel® Server System R2000LH2/LT2 Service Guide v

Preface

About this Manual

This manual is written for system technicians who are responsible for troubleshooting, upgrading,
and repairing this server system. It provides a brief overview of the features of the server
board/chassis, a list of accessories or other components you may need, troubleshooting information,
and instructions on how to add and replace components on the Intel® Server System
R2000LH2/LT2 family products. For the latest revision of this manual, go to

http://www.intel.com/p/en_US/support.

Table 1. Intel® Server System R2000LH2/LT2 family product list

Product Code

Description

Intel® Server System R2208LT2HKC4

With Intel® Server Board S4600LT2 and 8" x 2.5" hot swap hard drive bay

Intel® Server System R2304LT2HVC

With Intel® Server Board S4600LT2 and 4" x 3.5" hot swap hard drive bay

Intel® Server System R2304LH2HKC

With Intel® Server Board S4600LH2 and 4" x 3.5" hot swap hard drive bay

Intel® Server System R2208LH2HKC2

With Intel® Server Board S4600LH2 and 8" x 2.5" hot swap hard drive bay

Manual Organization

Chapter 1 provides a brief overview of the Intel® Server System R2000LH2/LT2 family. In this
chapter, you will find a list of the server system features, and figures of the system and components
to help you identify your system components and their locations.

Chapter 2 provides instructions on adding and replacing components. Use this chapter for step-by-
step instructions and diagrams for installing or replacing components such as the fan, power supply,
and front panel board, among other components.

Chapter 3 provides instructions on using the utilities that are shipped with the board or that may be
required to update the system. This includes information for navigating through the BIOS Setup
screens, performing a BIOS update, and resetting the password or BIOS defaults.

At the back of this document, you will find appendices on safety, “getting help”, and
warranty information.

Additional Information and Software

For additional information about this family of products or any of their supported accessories, refer
to the following resources available at http://www.intel.com/p/en_US/support/.

Preface

vi Intel® Server System R2000LH2/LT2 Service Guide

Table 2. Server System References

For this information or software

Use this Document or Software

For in-depth technical information about
this product.

Intel® Server System R2000LH2/LT2 Family Technical Product Specification

See the section on the web page titled, “Architecture/Specifications”.

For supported Intel® spares and
accessories

Intel® Server System R2000LH2/LT2 Family Quick Installation User’s Guide

See the section on the web page titled, “System Integration/User
Guides/Compatibility”.

For supported Intel® spares and
accessories

Spares and Configuration Guide

See the section on the web page titled, “Documents & Guides”.

For server configuration guidance and
compatibility

Intel® Server Configurator tool

For system power budget guidance

Power Budget Analysis Tool

For software to manage your Intel® Server
System.

Intel® Server Management Software

See the section on the web page titled, “Software/Code”.

For system firmware updates and onboard
device drivers

Firmware and Drivers

See the section on the web page titled, “Software/Code”.

Product Safety and Regulatory document

Intel® Server Products - Product Safety and Regulatory Compliance Document

See the section on the web page titled, “Regulations/Certification/Compliance”.

Table of Contents

Intel® Server System R2000LH2/LT2 Service Guide vii

Table of Contents

Safety Information ....................................................................................................................................... iii

Preface .......................................................................................................................................................... v

1 Server System Features .......................................................................................................................... 1

Server System Feature Overview ........................................................................................................... 1

Wattage Limitation of the PCI Loading ................................................................................................. 3

Power Rating .......................................................................................................................................... 3

Server System Components .................................................................................................................... 4

Hot Swap Hard Drive Bay and Front Panel Options .............................................................................. 4

Front Panel ............................................................................................................................................. 5

Back Panel .............................................................................................................................................. 5

Server Board Components ...................................................................................................................... 6

System Recovery Jumpers ...................................................................................................................... 8

Peripheral Devices .................................................................................................................................. 9

2 Hardware Installations and Upgrades ................................................................................................... 13

Before You Begin ................................................................................................................................. 13

Tools and Supplies Needed ........................................................................................................ 13

System Reference ....................................................................................................................... 13

Cable Routing ....................................................................................................................................... 13

For system with 4 x 3.5" hot swap hard drive bay ...................................................................... 13

For system with 8 x 2.5" hot swap hard drive bay ...................................................................... 15

Fan Connections ................................................................................................................................... 16

Removing and Installing the Front Bezel (Optional) ........................................................................... 17

Removing the Front Bezel .......................................................................................................... 17

Installing the Front Bezel............................................................................................................ 17

Removing and Installing the Front Fan Bezel ...................................................................................... 18

Removing the Front Fan Bezel ................................................................................................... 18

Installing the Front Fan Bezel..................................................................................................... 18

Removing and Installing the Rack Handles ......................................................................................... 19

Removing the Rack Handles ...................................................................................................... 19

Installing the Rack Handles ........................................................................................................ 19

Removing and Installing the Power Supply Module(s) ........................................................................ 20

Removing the Power Supply Module(s) ..................................................................................... 20

Installing a Power Supply Module(s) ......................................................................................... 20

Removing and Installing the System Cover ......................................................................................... 20

Removing the System Cover ...................................................................................................... 20

Installing the System Cover ........................................................................................................ 21

Removing and Installing the Front End Module .................................................................................. 22

Removing the Front End Module ............................................................................................... 22

Installing the Front End Module ................................................................................................. 22

Removing and Installing the PCI Riser Assembly ............................................................................... 23

Removing the PCI Riser Assembly ............................................................................................ 23

Installing the PCI Riser Assembly .............................................................................................. 23

Installing and Removing a PCI Add-in Card........................................................................................ 24

Installing a PCI Add-in Card ...................................................................................................... 24

Removing a PCI Add-in Card..................................................................................................... 25

Table of Contents

viii Intel® Server System R2000LH2/LT2 Service Guide

Removing and Installing the Air Duct .................................................................................................. 26

Removing the Air Duct ............................................................................................................... 27

Installing the Air Duct ................................................................................................................ 27

Removing and Installing the Processor Heatsink(s) ............................................................................. 28

Removing Processor Heatsink(s) ................................................................................................ 28

Installing Processor Heatsink(s) ................................................................................................. 28

Installing or Replacing the Processor ................................................................................................... 29

Installing the Processor ............................................................................................................... 30

Installing and Removing the Memory .................................................................................................. 31

Installing Memory ...................................................................................................................... 32

Removing Memory ..................................................................................................................... 32

Installing and Removing Hard Drive ................................................................................................... 32

Installing a Hard Disk Drive into 3.5" Hot Swap Hard Drive Carrier ........................................ 33

Installing a Hard Disk Drive into 2.5" Hot Swap Hard Drive Carrier ........................................ 35

Installing and Removing a Slimline Optical Drive .............................................................................. 36

Installing a Slimline Optical Drive ............................................................................................. 36

Removing a Slimline Optical Drive ........................................................................................... 37

Installing and Removing the Intel® I/O Expansion Module ................................................................. 37

Before Installing Intel® I/O Expansion Module at the Left Edge of the Board (Optional) ........ 38

Installing Intel® I/O Expansion Module ..................................................................................... 39

Removing Intel® I/O Expansion Module .............................................................................................. 40

Installing and Removing the Intel® Remote Management Module 4 ................................................... 41

Installing the Intel® RMM4 Lite ................................................................................................. 41

Install the Intel® RMM4 NIC ..................................................................................................... 42

Removing the Intel® RMM4 Lite ............................................................................................... 42

Removing the Intel® RMM4 NIC ............................................................................................... 42

Installing and Removing an Internal Solid State Drive ........................................................................ 43

Installing a Solid State Drive ...................................................................................................... 43

Removing a Solid State Drive .................................................................................................... 44

Installing and Removing the Intel® RAID Smart Battery .................................................................... 45

Installing the Intel® RAID Smart Battery ................................................................................... 45

Removing the Intel® RAID Smart Battery ................................................................................. 46

Installing and Removing the Server Board .......................................................................................... 46

Removing the Server Board........................................................................................................ 47

Installing the Server Board ......................................................................................................... 47

Replacing the Backup Battery .............................................................................................................. 48

Replacing a Redundant Fan Module .................................................................................................... 49

Replacing the Backplane ...................................................................................................................... 50

Removing the Backplane ............................................................................................................ 50

Installing the Backplane ............................................................................................................. 50

Replacing the Lower Fan Board ........................................................................................................... 51

Removing the Lower Fan Board ................................................................................................. 51

Installing the Lower Fan Board .................................................................................................. 52

Replacing the Front Video and USB Module ....................................................................................... 52

Removing the Front Video and USB Module ............................................................................ 53

Installing the Front Video and USB Module .............................................................................. 54

Installing and Removing the LCP Module ........................................................................................... 54

Installing the LCP Module.......................................................................................................... 55

Removing the LCP Module ........................................................................................................ 56

Install the Bezel (Optional) .................................................................................................................. 57

Install the System into Rack (Optional) ............................................................................................... 57

Table of Contents

Intel® Server System R2000LH2/LT2 Service Guide ix

Installing the Chassis into Rack .................................................................................................. 58

Removing the Chassis from Rack ............................................................................................... 59

3 Server Utilities ...................................................................................................................................... 61

Using the BIOS Setup Utility ............................................................................................................... 61

Starting Setup ............................................................................................................................. 61

Setup Navigation Keyboard Commands .................................................................................... 61

Setup Screen Menu Selection Bar .............................................................................................. 62

BIOS Setup Utility Screens ........................................................................................................ 62

Map of Screens and Functionality .............................................................................................. 63

Appendix A: Regulatory and Compliance Information .............................................................................. 65

Appendix B: Safety Information ................................................................................................................. 66

Appendix C: Installation/Assembly Safety Instructions ............................................................................. 67

Appendix D: Getting Help .......................................................................................................................... 68

Warranty Information ................................................................................................................. 68

Appendix E: Intel® Server Issue Report Form ............................................................................................ 69

Appendix F: Warranty ................................................................................................................................ 73

Limited Warranty for Intel® Chassis Subassembly Products ............................................................... 73

Extent of Limited Warranty.................................................................................................................. 73

Warranty Limitations and Exclusions .................................................................................................. 73

Limitations of Liability ............................................................................................................... 74

How to Obtain Warranty Service ......................................................................................................... 74

Telephone Support ...................................................................................................................... 74

Returning a Defective Product.................................................................................................... 74

List of Figures

x Intel® Server System R2000LH2/LT2 Service Guide

List of Figures

Figure 1. Intel® Server System R2000LH2/LT2 ........................................................................................... 1

Figure 2. Intel® Server System R2000LH2/LT2 Components ...................................................................... 4

Figure 3. 3.5" Hot Swap Hard Drive Bay - 4 Drive Configuration .............................................................. 4

Figure 4. 2.5" Hot Swap Hard Drive Bay - 8 Drive Configuration .............................................................. 4

Figure 5. Front Panel Options ....................................................................................................................... 5

Figure 6. Back Panel Feature Identification .................................................................................................. 5

Figure 7. Server Board Connector and Component Locations ..................................................................... 7

Figure 8. Configuration Jumpers .................................................................................................................. 8

Figure 9. Optional Peripherals (4x3.5-inch hard drive bays as shown) ........................................................ 9

Figure 10. Front Bezel (Front View) .......................................................................................................... 10

Figure 11. 4 x 3.5-inch Hard Drive Backplane Components (Front View) ................................................ 10

Figure 12. 4 x 3.5-inch Hard Drive Backplane Components (Rear View) ................................................. 11

Figure 13. 8 x 2.5-inch Hard Drive Backplane Components (Front View) ................................................ 11

Figure 14. 8 x 2.5-inch Hard Drive Backplane Components (Rear View) ................................................. 11

Figure 15. Cable Routing – 4 x 3.5" Hot Swap HDD ................................................................................. 14

Figure 16. Cable Routing – 8 x 2.5" Hot Swap HDD ................................................................................. 15

Figure 17. System Fan Order ...................................................................................................................... 16

Figure 18. Connecting the Fan Power Cables to the Fan Board and PDB .................................................. 16

Figure 19. Removing the Front Bezel ......................................................................................................... 17

Figure 20. Installing the Front Bezel .......................................................................................................... 17

Figure 21. Removing the Front Fan Bezel .................................................................................................. 18

Figure 22. Installing the Front Fan Bezel ................................................................................................... 18

Figure 23. Removing the Rack Handle ....................................................................................................... 19

Figure 24. Installing the Rack Handle ........................................................................................................ 19

Figure 25. Removing the Power Supply Module ........................................................................................ 20

Figure 26. Installing the Power Supply Module ......................................................................................... 20

Figure 27. Removing the System Cover ..................................................................................................... 21

Figure 28. Installing the System Cover ....................................................................................................... 21

Figure 29. Removing the Front End Module .............................................................................................. 22

Figure 30. Installing the Front End Module ................................................................................................ 22

Figure 31. Removing the PCI Riser Assembly ........................................................................................... 23

Figure 32. Installing the PCI Riser Assembly ............................................................................................. 23

Figure 33. Installing a Half-Length PCI Add-In Card ................................................................................ 24

Figure 34. Installing a Full-Length PCI Add-In Card ................................................................................. 25

Figure 35. Removing a Half-Length PCI Add-In Card............................................................................... 25

Figure 36. Removing a Full-Length PCI Add-In Card ............................................................................... 26

Figure 37. Removing the Air Duct.............................................................................................................. 27

Figure 38. Installing the Air Duct ............................................................................................................... 27

Figure 39. Removing Processor Heatsink ................................................................................................... 28

Figure 40. Installing Processor Heatsink .................................................................................................... 29

Figure 41. Installing Processor – Remove the Cover .................................................................................. 30

Figure 42. Installing Processor – Open the Socket Lever ........................................................................... 30

Figure 43. Installing Processor – Open the Load Plate ............................................................................... 30

Figure 44. Installing Processor – Install the Processor ............................................................................... 31

Figure 45. Installing Processor – Close the Load Plate .............................................................................. 31

Figure 46. Installing Processor – Latch the Locking Lever ........................................................................ 31

Figure 47. Installing Memory ..................................................................................................................... 32

List of Figures

Intel® Server System R2000LH2/LT2 Service Guide xi

Figure 48. Installing Hard Disk Drive – Removing 3.5" HDD carrier ....................................................... 33

Figure 49. Installing Hard Disk Drive – Removing 3.5" HDD interface bracket ....................................... 33

Figure 50. Installing Hard Disk Drive – Installing 3.5" HDD .................................................................... 33

Figure 51. Installing Hard Disk Drive – Installing 2.5" HDD .................................................................... 34

Figure 52. Installing Hard Disk Drive – Inserting 3.5" HDD Assembly .................................................... 34

Figure 53. Installing Hard Disk Drive – Removing 2.5" HDD carrier ....................................................... 35

Figure 54. Installing Hard Disk Drive – Removing Plastic Drive Blank .................................................... 35

Figure 55. Installing Hard Disk Drive – Installing 2.5" HDD .................................................................... 35

Figure 56. Installing Hard Disk Drive – Inserting 2.5" HDD assembly ..................................................... 36

Figure 57. Installing the Plastic Guide to the Optical Drive ....................................................................... 36

Figure 58. Installing an Optical Drive ........................................................................................................ 37

Figure 59. Removing the Slimline Optical Drive ....................................................................................... 37

Figure 60. Installing Intel® I/O Expansion Module .................................................................................... 38

Figure 61. Installing Intel® I/O Expansion Module .................................................................................... 39

Figure 62. Removing Intel® I/O Expansion Module ................................................................................... 40

Figure 63. Installing the Intel® RMM4 Lite ................................................................................................ 41

Figure 64. Installing the Intel® RMM4 NIC ............................................................................................... 42

Figure 65. Removing the Intel® RMM4 NIC .............................................................................................. 42

Figure 66. Installing a SSD ......................................................................................................................... 43

Figure 67. Removing a SSD ....................................................................................................................... 44

Figure 68. Installing the Intel® RAID Smart Battery .................................................................................. 45

Figure 69. Removing the Intel® RAID Smart Battery ................................................................................ 46

Figure 70. Removing the Server Board ...................................................................................................... 47

Figure 71. Installing the Server Board ........................................................................................................ 47

Figure 72. Replacing the Backup Battery ................................................................................................... 48

Figure 73. Replacing a system fan .............................................................................................................. 49

Figure 74. Removing the backplane ........................................................................................................... 50

Figure 75. Installing the backplane ............................................................................................................. 50

Figure 76. Removing the Lower Fan Board ............................................................................................... 51

Figure 77. Installing the Lower Fan Board ................................................................................................. 52

Figure 78. Removing the front video and USB Module ............................................................................. 53

Figure 79. Installing the front video and USB Module ............................................................................... 54

Figure 80. Installing the LCP Module ........................................................................................................ 55

Figure 81. Removing the LCP Module ....................................................................................................... 56

Figure 82. Slides Component ...................................................................................................................... 57

Figure 83. Install Slides to Rack ................................................................................................................. 58

Figure 84. Install Inner Member to Chassis ................................................................................................ 58

Figure 85. Install Chassis to Fixed Slides ................................................................................................... 59

Figure 86. Extend Slides ............................................................................................................................. 59

Figure 87. Remove Inner Member from Chassis ........................................................................................ 60

List of Tables

xii Intel® Server System R2000LH2/LT2 Service Guide

List of Tables

Table 1. Intel® Server System R2000LH2/LT2 family product list .............................................................. v

Table 2. Server System References.............................................................................................................. vi

Table 3. Intel® Server System R2000LH2/LT2 Feature Summary ............................................................... 1

Table 4. Wattage Limitation of the PCIe Loading ........................................................................................ 3

Table 5. Power Rating of the Power Supply ................................................................................................. 3

Table 6. Hard Disk Drive Options ................................................................................................................ 9

Table 7. BIOS Setup: Keyboard Command Bar ......................................................................................... 61

Table 8. Screen Map ................................................................................................................................... 63

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 1

1 Server System Features

This chapter briefly describes the main features of the Intel® Server System R2000LH2/LT2

family. This includes illustrations of the products, a list of the server system features, and

diagrams showing the location of important components and connections on the server systems.

Figure 1. Intel®

Server System R2000LH2/LT2

Server System Feature Overview

Table 3 summarizes the features of the server systems.

Table 3. Intel® Server System R2000LH2/LT2 Feature Summary

Server System

Integrated Server Board

Intel® Server System R2000LH2 product family

Intel® Server Board S4600LH2

Intel® Server System R2000LT2 product family

Intel® Server Board S4600LT2

Feature

Description

Dimensions

 3.43 inches (87.3 mm) high
 17.24 inches (438.0 mm) wide
 28.0 inches (712.0 mm) deep

Processor Support

 Support up to four Intel® Xeon® processors E5-4600 product family with a Thermal Design Power

(TDP) of up to 130 W.

Memory

 48 DIMM slots – Three DIMMs/Channel – Four memory channels per processor
 Unbuffered DDR3 and registered DDR3 DIMMs
 Memory DDR3 data transfer rates of 800, 1066, 1333 MT/s and 1600 MT/s
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V

Chipset

Intel® C600-A chipset with support for optional Storage Option Select keys

External I/O
connections

 Video – Back Panel + Front Panel
 RJ-45 Serial- A Port
 S4600LH2 - 2 RJ-45 Network Interface Connectors supporting 10/100/1000Mb
 S4600LT2 - 2 RJ-45 Network Interface Connectors supporting 100/1000/10000Mb

Server System Features

2 Intel® Server System R2000LH2/LT2 Service Guide

Feature

Description

 USB 2.0 connectors - 4 on back panel + 2 on front panel

Internal I/O
connectors/headers

 One Type-A USB 2.0 connector
 One internal USB header
 One DH-10 Serial-B port connector

Optional I/O Module
Support

The following I/O modules utilize a single proprietary on-board connector. An installed I/O module
can be supported in addition to standard on-board features and any add-in expansion cards.

 Quad port 1 GbE based on Intel® Ethernet Controller I350
 Dual port 10GBase-T Ethernet module based on Intel® Ethernet Controller I350 –

AXX10GBTWLIOM

 Dual SFP+ port 10GbE module based on Intel® 82500 10 GbE controller – AXX10GBNIAIOM
 Single Port FDR speed InfiniBand* module with QSFP connector – AXX1FDRIBIOM

System Fans

 Eleven managed system fans
 One power supply fan for each installed power supply module

Riser Cards

Support for two riser card slots. Each riser card slot has support for three PCIe x16 slots

Video

 Integrated 2D Video Controller
 16 MB DDR3 Memory

On-board storage
controllers and
options

 One low-profile eUSB 2x5 pin connector to support low-profile eUSB solid state devices
 Two single port SATA connectors capable of supporting up to 6 GB/sec
 Two 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
 Intel® RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID capabilities

Security

Trusted Platform Module (Optional)

Server Management

 Integrated Baseboard Management Controller, IPMI 2.0 compliant
 Support for Intel® Server Management Software (version TBD)
 Intel® Remote Management Module 4 support (optional)
 Intel® Remote Management Module 4 Lite support (optional)

Power Supply Options

The system is shipped with two power supplies with support below options.

 1600W (1+1) Redundant Hot-swap Capable
 1600W (1+0 or 2+0) Non-Redundant

Storage Bay Options

 4" x 3.5" SATA/SAS Hot Swap Hard Drive Bays + Optical Drive support
 8" x 2.5" SATA/SAS Hot Swap Hard Drive Bays

Rack Mount Kit
Options

 Extended Value rack mount rail kit (AXXELVRAIL)
 Premium rack mount rail kit (AXXPRAIL), will be available at post launch

CAUTION: THE MAXIMUM RECOMMENDED SERVER WEIGHT FOR THE RACK RAILS CAN

BE FOUND at http://www.intel.com/support/motherboards/server/sb/CS-033655.htm.
EXCEEDING THE MAXIMUM RECOMMENDED WEIGHT OR MISALIGNMENT OF THE
SERVER MAY RESULT IN FAILURE OF THE RACK RAILS HOLDING THE SERVER. Use of a
mechanical assist to install and align server into the rack rails is recommended.

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 3

Wattage Limitation of the PCI Loading

Table 4 summarizes the wattage limitation of the PCI loading.

Table 4. Wa

ttage Limitation of the PCIe Loading

VIN

Power Supply Configuration

Maximum PCI Loading

90 – 140VAC

(AC low-Line)

1600W (1+1) Redundant Hot-swap Capable

260W

180 – 264VAC

(AC high-line)

1600W (1+1) Redundant Hot-swap Capable

1600W (1+0 or 2+0) Non-Redundant

450W

Power Rating

Table 5 summarizes the power rating of the power supply.

Table 5. Power Rating of the Power Supply

VIN

Total Available Power

100~127VAC

(AC low-Line)

1120W

200~240VAC

(AC high-line)

1600W

Server System Features

4 Intel® Server System R2000LH2/LT2 Service Guide

Server System Components

This section helps you identify the components of your server system. If you are near the

sy

stem, you can also use the Quick Reference Label provided on the inside of the chassis cover

to assist in identifying components.

Figure 2. Intel®

Server System R2000LH2/LT2 Components

Hot Swap Hard Drive Bay and Front Panel Options

Figure 3. 3.5" Hot Swap Hard Drive Bay - 4 Drive Configuration

Figure 4. 2.5" Hot Swap Hard Drive Bay - 8 Drive Configuration

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 5

Front Panel

Label

Description

Label

Description

A

System ID Button w/Integrated LED

F

System Status LED

B

NMI Button (recessed, tool required for use)

G

Power Button w/Integrated LED

C

NIC-1 Activity LED

H

Hard Drive Activity LED

D

I

E

System Cold Reset Button

J

NIC-2 Activity LED

Figure 5. Front Panel Options

Back Panel

Label

Description

Label

Description

A

USB Ports

H

I/O Module Ports/Connectors (Optional)

B

USB Ports

I

Add-in adapter slots from Riser Card

C

I/O Module Ports/Connectors (Optional)

J

RMM4 NIC Port (Optional)

D

Video Connector

K

Power Supply Module #2

E

NIC – 1

L

Power Supply Module #1

F

NIC – 2

M

Add-in adapter slots from Riser Card

G

RJ45 Serial-A Port

Figure 6. Back Panel Feature Identification

Server System Features

6 Intel® Server System R2000LH2/LT2 Service Guide

Server Board Components

This section helps you identify the components and connectors on the server board.

Description

Description

A

Manufacturing Mode jumper

AH

Riser Card slot #1

B

Serial ‘A’ Port (RJ45)

AI

CPU #4 DIMM slots – Memory Banks N and P

C

NIC 2

AJ

CPU #4 socket

D

NIC 1

AK

Front Panel Video connector

E

(Option) RMM4 Lite connector

AL

Front Panel header (SSI compatible)

F

Video connector

AM

CPU #1 Fan connector

G

CPU #2 DIMM slots – Memory Banks G and H

AN

CPU #4 Fan connector

H

CPU #1 DIMM slots – Memory Banks A and B

AO

CPU #4 DIMM slots – Memory Banks R and T

I

(Option) I/O Module connector

AP

Main Power Slot #2

J

(Option) eUSB Solid State Device (SSD) connector

AQ

Main Power Slot #1

K

Rear System Fan #2 connector

AR

CPU #3 DIMM slots – Memory Banks J and K

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 7

Description

Description

L

Rear System Fan #1 connector

AS

CPU #3 Fan connector

M

4 Port SATA/SAS connector (Drives 4-7)

AT

CPU #2 Fan connector

N

4 Port SATA/SAS connector (Drives 0-3)

AU

Fan board power connector

O

(Option) Intel® RAID C600 Upgrade Key connector

AV

PDB signal connector

P

Type-A USB 2.0 connector

AW

4-pin IPMB connector

Q

(Option) mSATA port

AX

LCP connector

R

2 Stacked USB 2.0 ports

AY

3-pin Hot Swap Backplane SMBus* connector

S

2 Stacked USB 2.0 ports

AZ

CPU #3 socket

T

System ID LED

BA

CPU #3 DIMM slots – Memory Banks L and M

U

System Status LED

BB

Riser Card slot #2

V

POST Code Diagnostic LEDs

BC

Backup Battery

W

SATA only port #0

BD

CPU #2 socket

X

Internal Serial Port

BE

CPU #2 DIMM slots – Memory Banks E and F

Y

SATA only port #1

BF

(Option) I/O Module connector

Z

Internal USB port

BG

(Option) RMM4 NIC connector

AA

Password Clear jumper

BH

(Option) TPM connector

AB

BIOS Recover jumper

BI

Serial A jumper

AC

BIOS Default jumper

BJ

BMC force update

AD

ME Force Update jumper

AE

CPU #1 DIMM slots – Memory Banks C and D

AF

CPU #1 socket

AG

CPLD programming header

Figure 7. Server Board Connector and Component Locations

Server System Features

8 Intel® Server System R2000LH2/LT2 Service Guide

System Recovery Jumpers

Jumper Name

Jumper Purpose

A

Serial A Jumper (J33)

If pins 2-3 are selected, the serial-A configuration is in Data Carrier
Detect (DCD) mode. These pins should be selected on 1-2 for
normal system operation.

B

BMC Force Update (J37)

If pins 2-3 are selected, the Integrated BMC Force Update Mode is
enabled. These pins should be selected on 1-2 for normal system
operation.

C

Password Clear (J73)

If pins 2-3 are selected, administrator and user passwords are cleared
within five to ten seconds after the system is powered on. These pins
should be selected on 1-2 for normal system operation.

D

BIOS Recover (J74)

If pins 2-3 are selected, the system can only boot from EFI-bootable
recovery media with the recovery BIOS image. The main system
BIOS will not boot. These pins should be selected on 1-2 for normal
system operation.

E

BIOS Default (J75)

If pins 2-3 are selected, the BIOS settings are cleared on the next
reset. These pins should be selected on 1-2 for normal system
operation.

F

ME Force Update (J81)

If pins 2-3 are selected, the ME Force Update Mode is enabled.
These pins should be selected on 1-2 for normal system operation.

Figure 8. Configuration Jumpers

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 9

Peripheral Devices

The Intel® Ser

ver System R2000LH2/LT2 provides locations and hardware for installing hard

drives, CD-ROM drive, or DVD-ROM drive. The following figure shows the available options:

A

Asset Tag

B

Slimline Optical Drive Bay

C

Video Port

D

USB Ports

E

Front Control Panel

F

Hard Disk Drive Bays

Figure 9. Optional Peripherals (4x3.5-inch hard drive bays as shown)

Hard Disk Drive Carriers

The Intel® Server System R2000LH2/LT2 ships with either 3.5" or 2.5" hard disk drive carrier,

and with different maximum number of hard disk drives; see the table below for details:

Table 6. Hard Disk Drive Options

Intel® Server System

Supported Hard Drive Type

Maximum Hard Drive Number

R2304LH2/LT2

3.5" or 2.5"

4

R2208LH2/LT2

2.5"

8

Note: SAS drives are only supported when proper Intel

®

RAID C600 Upgrade Key or Intel® Integrated

RAID Module is installed.

For instructions on installing hard drives, see Installing and Removing Hard Drive.

Note: Drives can consume up to 17 watts of power each. Drives must be specified to run at a maximum

ambient temperature of 45°C.

Note: The Intel

®

Server System R2000LH2/LT2 does not support all SAS or Serial ATA (SATA) hard

drives. For a web link to a list of supported hard drives, see

Additional Information and Software.

Server System Features

10 Intel® Server System R2000LH2/LT2 Service Guide

Slimline Optical Drive Carrier

The slimline optical drive carrier can be used with a single slimline optical drive. One sliml

ine

carrier is included with your server system; the optical drive must be purchased separately.

The drive in the optical drive carrier is NOT hot-swappable. The system power must be turned off to
insert or remove the slimline optical drive carrier. For instructions on installing an optical drive, see

Installing and Removing a Slimline Optical Drive.

To use one of the drives provided by Intel®, use the following order codes:

 Slimline DVD-ROM Drive: AXXSATADVDROM
 Slimline DVD-RW Drive: AXXSATADVDRWROM

Note: For a complete list of supported peripherals, go to http://serverconfigurator.intel.com/sct_app.aspx.

Bezel

The front bezel is available as optional accessory for the server system:

Figure 10. F

ront Bezel (Front View)

Hot-Swap SAS/SATA Backplane

The Hot-Swap SAS/SATA backplane serves as an interface between the mother board and the
system drives. The following diagrams show the location for each connector found on
the backplane.

4 x 3.5" Hard Drive Backplane

A

SAS/SATA Hot-swap Connectors

Figure 11. 4 x 3.5-inch Hard Drive Backplane Components (Front View)

Server System Features

Intel® Server System R2000LH2/LT2 Service Guide 11

A

Power Connector

B

SGPIO Connector

C

I2C Connector

D

SATA Connectors

Figure 12. 4 x 3.5-inch Hard Drive Backplane Components (Rear View)

8 x 2.5" Hard Drive Backplane

A

SAS/SATA Hot-swap Connectors

Figure 13. 8 x 2.5-inch Hard Drive Backplane Components (Front View)

A

Power Connectors

B

Mini-SAS Connectors

C

I2C Connector

Figure 14. 8 x 2.5-inch Hard Drive Backplane Components (Rear View)

Server System Features

12 Intel® Server System R2000LH2/LT2 Service Guide

Advanced Management Options

Intel® Remote Management Module 4

The Intel

®

R

emote Management Module 4 plugs into a dedicated connector on the server board

and provides additional server management functionality to the server board.

This module provides a dedicated web server for viewing server information and remote control

of the system. It also provides Remote KVM Redirection and USB Media Redirection allowing

USB devices attached to the remote system to be used on the managed server.

For instructions on installing the Intel® Remote Management Module 4, see Installing and

Removing the Intel® Remote Management Module 4.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 13

2 Hardware Installations and Upgrades

Before You Begin

Before working with your server product, pay close attention to the Safety Information at the

beginning of this manual.

Note: Whenever you service the system, you must first power down the server and unplug all peripheral

devices and the AC power cord.

Tools and Supplies Needed

 Phil

lips* (cross head) screwdriver (#1 bit and #2 bit)

 Needle nosed pliers

 Anti-static wrist strap and conductive foam pad (recommended)

System Reference

All references to left, right, front, top, and bottom assume the reader is facing the front of the

chassis as it would be positioned for normal operation.

Note: The Intel® Server System R2304LH2 is shown for illustration purposes in this document.

Cable Routing

When you add or remove components from your server system, make sure your cables are routed
correctly before reinstalling the server system cover. Use caution to make sure no cables or wires
are pinched and that the airflow from the fans is not blocked. Use the figures below to determine
the correct cable routing.

Note: Red lines are for power connection, dot lines are for optional device connection.

For system with 4 x 3.5"

hot swap hard drive bay

Note:

1. To activate the port SCU1 (4-7) on the server board, a proper Intel

®

RAID C600 Upgrade Key

must be installed. For instructions, see Intel® RAID C600 Upgrade Key Installation Guide.

2. A second SSD is supported when the optical drive is NOT in use.

Hardware Installations and Upgrades

14 Intel® Server System R2000LH2/LT2 Service Guide

Figure 15. Cable Routing – 4 x 3.5" Hot Swap HDD

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 15

For system with 8 x 2.5" hot swap hard drive bay

Note:

1. To activate the port SCU1 (4-7) on the server board, a proper Intel

®

RAID C600 Upgrade Key

must be installed. For instructions, see Intel® RAID C600 Upgrade Key Installation Guide.

2. A second SSD is supported when the optical drive is NOT in use.

Figure 16.

Cable Routing – 8 x 2.5" Hot Swap HDD

Hardware Installations and Upgrades

16 Intel® Server System R2000LH2/LT2 Service Guide

Fan Connections

Use the figures below to determine the proper fan connections.

Figure 17. Sy

stem Fan Order

Figure 18.

Connecting the Fan Power Cables to the Fan Board and PDB

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 17

Removing and Installing the Front Bezel (Optional)

Removing the Front Bezel

If your system includes a front bezel, follow these steps to remove the front bezel:

1. U

nlock the bezel if it is locked.

2. Remove the left end of front bezel from rack handle (see letter A).

3. Rotate the front bezel anticlockwise to release the latches on the right end from the rack

handle (see letter B).

Figure 19. Removing the Front Bezel

Installing the Front Bezel

Note: Before installing the bezel, you must install the rack handles.

1. Lock the right end of the front bezel to the rack handle (see letter A).

2. Rotate the front bezel clockwise till the left end clicks into place (see letter B).

3. Lock the bezel if needed.

Figure 20. Installing the Front Bezel

Hardware Installations and Upgrades

18 Intel® Server System R2000LH2/LT2 Service Guide

Removing and Installing the Front Fan Bezel

Removing the Front Fan Bezel

Follow these steps to remove the front fan bezel:

1. Loosi

ng the two screws on left and right end (see letter A).

2. Remove the front fan bezel from the chassis (see letter B)

Figure 21. Removing the Front Fan Bezel

Installing the Front Fan Bezel

1. Slide in the bezel (see letter A). .

2. Secure the bezel to the chassis with the two screws on left and right end as shown (see

letter B).

Figure 22. I

nstalling the Front Fan Bezel

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 19

Removing and Installing the Rack Handles

Removing the Rack Handles

Remove the two screws holding the rack handle in place, and remove the rack handle from the
server system as shown.

Figure 23. Re

moving the Rack Handle

Installing the Rack Handles

Align the rack handle with the two holes on the side of the server system and attach the rack handle
to the server system with two screws as shown.

Figure 24. I

nstalling the Rack Handle

Hardware Installations and Upgrades

20 Intel® Server System R2000LH2/LT2 Service Guide

Removing and Installing the Power Supply Module(s)

Removing the Power Supply Module(s)

1. P

ush the green latch in the direction shown while pulling out of the system by the handle.

Figure 25. Removing the Power Supply Module

2. Repeat step 1 to remove the second power supply module.

Installing a Power Supply Module(s)

1. I

nsert the power supply module into the power supply cage and push all the way until it clicks

into place.

Figure 26. I

nstalling the Power Supply Module

2. Repeat step 1 to install the second power supply module.

Removing and Installing the System Cover

Rem

oving the System Cover

The server system must be operated with the system cover in place to ensure proper cooling.

You will need to remove the top cover to add or replace components inside of the server.

Before removing the top cover, power down the server and unplug all peripheral devices and

the power cable(s).

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 21

Note: A non-skid surface or a stop behind the server system may be needed to prevent the server

system from sliding on your work surface.

1. Observe the safety and ESD precautions at the beginning of this book.

2. Turn off all peripheral devices connected to the server. Turn off the server.

3. Disconnect the power cord.

4. Remove the screws (see letter A).

5. Depress the latches (see letter B).

6. Slide the cover back and lift upward.

Figure 27. Removing the System Cover

Installing the System Cover

1. Place system cover onto the chassis and slide forward to engage recessed edge at front of

cover (see letter A).

2. Tighten the screw at front (see letter B).

Figure 28. Installing the System Cover

Hardware Installations and Upgrades

22 Intel® Server System R2000LH2/LT2 Service Guide

Removing and Installing the Front End Module

Before removing or installing the PCI riser assembly, please make sure following steps are perform

ed:

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the rack handles. For instructions, see Removing the Rack Handles.

3. Remove the system cover. For instructions, see Removing the System Cover.

Removing the Front End Module

1. Disconnect any cables attached to the front end module.

2. Removing the six screws securing the front end module from the chassis (see letter A).

3. Slide the front end module in forward and remove it from the chassis (see letter B).

Figure 29. Removing the Front End Module

Installing the Front End Module

1. Push the front end module into place (see letter A).

2. Secure the front end module with six screws (see letter B).

Figure 30. Installing the Front End Module

3. Connect any required cables, please refer to Cable Routing.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 23

Removing and Installing the PCI Riser Assembly

Before removing or installing the PCI riser assembly, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

Removing the PCI Riser Assembly

1. Disconnect any cables attached to any add-in cards, pull up the release lever (see letter A).

2. Grasp the riser assembly with both hands and pull up to remove from system (see letter B).

Figure 31. Removing the PCI Riser Assembly

Warning: Place the riser assembly upside down or sideway to avoid damage to the riser card

connector.

Do one of the following:

— If you need to add or replace a PCI add-in card, see Installing and Removing a PCI Add-in Card.

— If you removed the PCI riser assembly for another procedure, continue with that procedure.

Installing the PCI Riser Assembly

1. Posi

tion the riser card connector edge over the server board riser socket (see letter A).

2. Press down the release lever to install the riser assembly into the riser socket (see letter B).

3. Push on the board edge above the connector to ensure the connector is seated.

Figure 32. Installing the PCI Riser Assembly

Hardware Installations and Upgrades

24 Intel® Server System R2000LH2/LT2 Service Guide

4. Connect any cables to add-in cards that require them. See your add-in card documentation for

information and add-in card requirements.

Installing and Removing a PCI Add-in Card

Before removing or installing a PCI add-in card, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

Installing a PCI Add-in Card

Installin

g a Half-Length PCI Add-in Card

1. Remove the filler panel from the add-in card slot and install the provided proper bracket as

shown (see letter A).

2. Insert add-in card until it sits in the riser connector (see letter B).

3. Secure add-in card with screw as shown (see letter C).

Figure 33. Installing a Half-Length PCI Add-In Card

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 25

Installing a Full-length PCI Add-in Card

1. Remove the screw (See letter A), install and secure the provided proper bracket as shown (see

letter B)

2. Remove the filler panel from the add-in card slot and remove the screw as shown (see letter C).

3. Insert add-in card until it sits in the riser connector (see letter D).

4. Secure the add-in card with screw as shown (see letter E).

Figure 34.

Installing a Full-Length PCI Add-In Card

Removing a PCI Add-in Card

Removing a Half-Length PCI Add-in Card

1. Remove the screw as shown (see letter A).

2. Remove the PCI add-in card from the riser card connector (see letter B).

Figure 35. Re

moving a Half-Length PCI Add-In Card

Note: Make sure that all empty add-in card slots have filler panels installed.

Hardware Installations and Upgrades

26 Intel® Server System R2000LH2/LT2 Service Guide

Removing a Full-Length PCI Add-in Card

1. Remove the screw as shown (see letter A).

2. Remove the PCI add-in card from the riser card connector (see letter B).

3. Remove the screw and the bracket for full-length PCI add-in card as shown (see letter C)

4. Install the screw as shown (see letter D)

Figure 36.

Removing a Full-Length PCI Add-In Card

Note: Make sure that all empty add-in card slots have filler panels installed.

Removing

and Installing the Air Duct

Always operate your server system with the air duct in place. The air duct is required for proper airflow
within the server system.

Before removing or installing the air duct, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

4. Remove the power supply modules. For instructions, see Removing the Power Supply Module(s).

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 27

Removing the Air Duct

1. Loosen the thumbscrew under the power supply cage at the rear of the system.

2. Lift up the tilt bay and fully open it to 110 degrees (see letter A).

3. Bend and slide out the air duct (see letter B).

4. Remove the air duct from the chassis (see letter C).

Figure 37. Removing the Air Duct

Installing the Air Duct

1. Bend and slide in the air duct (see letter A).

2. Install air duct into the chassis (see letter B).

3. Flip down the power supply (see letter C).

Figure 38. Installing the Air Duct

Hardware Installations and Upgrades

28 Intel® Server System R2000LH2/LT2 Service Guide

Removing and Installing the Processor Heatsink(s)

The heatsink has Thermal Interface Material (TIM) on the underside of it. Use caution so t

hat you do not

damage the thermal interface material. Use gloves to avoid sharp edges.

Before removing processor the heatsink(s), please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

Removing Processor Heatsink(s)

The heatsink is attached to the server board/processor socket with captive fasteners. Using a #2

Phil

lips* screwdriver, loosen the four screws located on the heatsink corners in a diagonal

manner using the following procedure:

1. Using a #2 Phillips* screwdriver, start with screw 1 and loosen it by giving it two rotations

and stop (see letter A). (IMPORTANT: Do not fully loosen.)

2. Proceed to screw 2 and loosen it by giving it two rotations and stop (see letter B). Similarly,

loosen screws 3 and 4. Repeat steps A and B by giving each screw two rotations each time
until all screws are loosened.

3. Lift the heatsink straight up (see letter C).

Figure 39. Re

moving Processor Heatsink

Installing Processor Heatsink(s)

1. Remove the protective film on the TIM if present (see letter A).

2. Align heatsink fins to the front and back of the chassis for correct airflow. Airflow goes from

front-to-back of chassis (see letter B).

Each heatsink has four captive fasteners and should be tightened in a diagonal manner using the

following procedure:

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 29

1. Using a #2 Phillips* screwdriver, start with screw 1 and engage screw threads by giving it two

rotations and stop (see letter C). (Do not fully tighten.)

2. Proceed to screw 2 and engage screw threads by giving it two rotations and stop (see letter D).

Similarly, engage screws 3 and 4.

3. Repeat steps C and D by giving each screw two rotations each time until each screw is lightly

tightened up to a maximum of eight inch-lbs torque (see letter E).

Figure 40. Installing Processor Heatsink

Installing or Replacing the Processor

Caution: Processor must be appropriate: You may damage the server board if you install a processor

that is inappropriate for your server. For a web link to the list of compatible processor(s), see
“Additional Information and Software” on page 4.

Caution: ESD and handling processors: Reduce the risk of electrostatic discharge (ESD) damage to the

processor by doing the following:

 Touch the metal chassis before touching the processor or server board. Keep part of your body

in contact with the metal chassis to dissipate the static charge while handling the
processor.

 Avoid moving around unnecessarily.

Caution: Protective socket cover needs to be removed for proper cooling of the processor; failure to

remove the cover could result in damage to the system.

Note: To avoid unexpected damage to the processor socket(s), Intel strongly recommends using

Processor Insertion/ Removal Tool (IPN: G21819-003) to install or replace the processor(s).

Before removing or replacing the processor, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

Hardware Installations and Upgrades

30 Intel® Server System R2000LH2/LT2 Service Guide

3. Remove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

6. R

emove the processor heatsink(s). For instructions, see Removing Processor Heatsink(s).

Installing the Processor

1. Remove the cover as shown. Save the protective cover.

Figure 41.

Installing Processor – Remove the Cover

2. Open the Socket Lever. Push down the lever handle on the OPEN first side and away from the

socket to release it (see letter A). Repeat the steps to release the lever on the other side (see

letter B).

Figure 42. Installing Processor – Open the Socket Lever

3. Open the Load Plate. Press the locking lever slightly to raise the load plate (see letter A). Open

the load plate all the way (see letter B).

Figure 43. Installing Processor – Open the Load Plate

4. Install the Processor. Take the processor out of the box and remove the protective shipping

cover (see letter A). Orient the processor with the socket so that the processor cutouts match the

four orientation posts on the socket (see letter B). Note location of gold key at corner of

processor (see letter C).

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 31

Figure 44. Installing Processor – Install the Processor

Note: The underside of the processor has components that may damage the socket pins if installed

improperly. Processor must align correctly with the socket opening before installation. DO NOT
DROP processor into socket!

5. Close the Load Plate. Carefully lower the load plate over the processor.

Figure 45. Installing Processor – Close the Load Plate

6. Latch the Locking Lever. Push down on the locking lever on the CLOSE 1st side (see letter A).

Slide the tip of the lever under the notch in the load plate (see letter B). Make sure the load

plate tab engages under the socket lever when fully closed. Repeat the steps to latch the locking

lever on the other side (see letter C). Latch the levers in the order as shown.

Figure 46. Installing Processor – Latch the Locking Lever

Installing and Removing the Memory

Before installing or removing the memory, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

Hardware Installations and Upgrades

32 Intel® Server System R2000LH2/LT2 Service Guide

Installing Memory

1. Locate the DIMM sockets. Make sure the clips at either end of the DIMM socket(s) are pushed

outward to the open position (see letter A).

2. Holding the DIMM by the edges, remove it from its anti-static package. Position the DIMM

above the socket. Align the notch on the bottom edge of the DIMM with the key in the DIMM

socket (see letter B).

3. Insert the bottom edge of the DIMM into the socket (see letter C). When the DIMM is inserted,

push down on the top edge of the DIMM until the retaining clips snap into place (see letter D).

Make sure the clips are firmly in place (see letter E).

Figure 47. Installing Memory

Removing Memory

1. Locate the DIMM sockets. Gently spread the retaining clips at each end of the socket. The

DIMM lifts from the socket.

2. Holding the DIMM by the edges, lift it from the socket, and store it in an anti-static package.

Installing and Removing Hard Drive

Caution:

If you do not install all drives, empty drive bays must be occupied by carriers with plastic

drive blank provided to maintain proper system cooling.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 33

Installing a Hard Disk Drive into 3.5" Hot Swap Hard Drive Carrier

1. R

emove the drive carrier by pressing the green button and opening the lever (see letter A).

Slide the carrier out (see letter B).

Figure 48. Installing Hard Disk Drive – Removing 3.5" HDD carrier

2. Remove the four screws securing the HDD interface bracket and remove the HDD interface

bracket (see letter C).

Figure 49. I

nstalling Hard Disk Drive – Removing 3.5" HDD interface bracket

3. Install the hard disk drive using the same four screws as shown. Make sure the connector end of

the drive matches the backplane connector (see letter D).

Figure 50. Installing Hard Disk Drive – Installing 3.5" HDD

For installing 2.5" Hard Disk Drive as an option:

Break off the tab on the HDD interface bracket (see letter d1). Install the HDD interface bracket

from top. Secure the bracket with three screws as shown (see letter d2). Slide the 2.5" HDD

Hardware Installations and Upgrades

34 Intel® Server System R2000LH2/LT2 Service Guide

into the bracket to align the screw holes with the right and left rail (see letter d3). Secure the

hard disk drive using the four screws for 2.5" HDD (see letter d4).

Figure 51. Installing Hard Disk Drive – Installing 2.5" HDD

4. With the lever open, insert the hard disk drive assembly into the chassis (see letter E). Push in

the lever to lock it into place (see letter F).

Figure 52. Installing Hard Disk Drive – Inserting 3.5" HDD Assembly

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 35

Installing a Hard Disk Drive into 2.5" Hot Swap Hard Drive Carrier

1. R

emove the drive carrier by pressing the green latch to unlock (see letter A). Pull out the black

lever and slide the carrier out (see letter B).

Figure 53. I

nstalling Hard Disk Drive – Removing 2.5" HDD carrier

2. Remove the four screws securing the plastic drive blank from the 2.5" HDD carrier (see letter

C). Disengage the plastic drive blank from the HDD carrier. Remove the plastic drive blank

from the 2.5" HDD carrier (see letter D).

Figure 54. Installing Hard Disk Drive – Removing Plastic Drive Blank

3. Install the hard disk drive using the four screws as shown. Make Sure the connector end of the

drive matches the backplane connector (see letter E).

Figure 55. Installing Hard Disk Drive – Installing 2.5" HDD

Hardware Installations and Upgrades

36 Intel® Server System R2000LH2/LT2 Service Guide

4. With the lever open, insert the hard disk drive assembly into the chassis, then push in the lever

to lock it into place (see letter F).

Figure 56. Installing Hard Disk Drive – Inserting 2.5" HDD assembly

Installing and Removing a Slimline Optical Drive

Cautions: The slimline optical drive is NOT hot-swappable. Before removing or replacing the drive, you

must first take the server out of service, turn off all peripheral devices connected to the system, turn off
the system by pressing the power button, and unplug the AC power cord from the system or wall outlet.

To maintain proper system cooling, a filler panel must be installed if you do not install a device at this
location.

Before installing or removing the slimline optical drive, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see

Removing the System Cover.

Installing a Slimline Optical Drive

1. I

nstall the plastic guide onto the back of the drive and attach with two screws as shown (see

letter A).

Figure 57. I

nstalling the Plastic Guide to the Optical Drive

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 37

2. Insert the optical drive into chassis opening and push all the way until it stops (see letter B).

Connect the cables as shown (see letter C).

Figure 58. Installing an Optical Drive

Removing a Slimline Optical Drive

1. Remove the cables (see letter A). Slide the optical drive out (see letter B and C).

Figure 59. Re

moving the Slimline Optical Drive

2. If no device will be installed in this location, install a filler panel in this location.

Installing and Removing the Intel®

I/O Expansion Module

Before installing or removing the Intel® I/O expansion module, please make sure following steps are
performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

Hardware Installations and Upgrades

38 Intel® Server System R2000LH2/LT2 Service Guide

3. Remove the power supply modules. For instructions, see Removing the Power Supply

Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. R

emove the air duct. For instructions, see Removing the Air Duct.

Before Installing Intel® I/O Expansion Module at the Left Edge of the
Board (Optional)

1. Install the module to the provided bracket (see letter A).

2. Secure the module to the bracket with the three screws (see letter B).

3. Install the provided connector converter (see letter C).

F

igure 60. Installing Intel® I/O Expansion Module

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 39

Installing Intel® I/O Expansion Module

1. Remove the screw securing the filler panel from the chassis and remove the filler panel (see

letter A).

2. Position the module over the server board, fit the front of the module into the back panel slot

(see letter B).

3. Attach the module to the server board connector (see letter C).

4. Secure the module with the two screws as shown (see letter D).

F

igure 61. Installing Intel® I/O Expansion Module

Hardware Installations and Upgrades

40 Intel® Server System R2000LH2/LT2 Service Guide

Removing Intel® I/O Expansion Module

1. Remove the two screws as shown (see letter A).

2. Remove the module out of the server system (see letter B and C).

3. Install the I/O expansion module filler panel into the system back panel and secure it to the

chassis with the screw (see letter D).

Figure 62. Removing Intel® I/O Expansion Module

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 41

Installing and Removing the Intel® Remote Management
Module 4

Before installing or removing the Intel® R

emote Management Module 4, please make sure following

steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the power supply modules. For instructions, see Removing the Power Supply

Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

Installing the Intel®

RMM4 Lite

Locate the RMM4 Lite connector next to onboard NIC port, carefully pick up the Intel® RMM4

Lite module, and match the alignment pin of the module and the connector on server board.

Press to install.

Figure 63. I

nstalling the Intel® RMM4 Lite

Hardware Installations and Upgrades

42 Intel® Server System R2000LH2/LT2 Service Guide

Install the Intel® RMM4 NIC

1. Connect the cable to the server board (see letter A).

2. Secure the module with the two screws as shown (see letter B).

3. Connect the cable to the module (see letter C).

Figure 64.

Installing the Intel® RMM4 NIC

Removing the Intel® RMM4 Lite

Pull up the RMM4 Lite module to remove it from the mother board.

Removing the Intel® RMM4 NIC

1. Remove the cable to the module (see letter A).

2. Remove the two screws as shown and remove the module out of the server system (see letter B).

3. Remove the cable to the server board (see letter C).

Figure 65. Removing the Intel® RMM4 NIC

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 43

Installing and Removing an Internal Solid State Drive

Before installing or removing the Solid State Drive, please make sure following steps are perform

ed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the rack handles. For instructions, see Removing the Rack Handles.

4. Slide the front end module in forward a bit. For instructions, see Removing the Front End Module.

Installing a Solid State Drive

1. Remove the two screws to release the Solid State Drive carrier (see letter A)

2. Place the Solid State Drive in the carrier (see letter B).

3. Secure the Solid State Drive with the four screws (see letter C).

4. Slide the Solid State Drive carrier into the chassis (see letter D).

5. Secure the Solid State Drive carrier with the two screws (see letter E).

6. Connect cables (see letter F).

Figure 66. Installing a SSD

Hardware Installations and Upgrades

44 Intel® Server System R2000LH2/LT2 Service Guide

Removing a Solid State Drive

1. Disconnect cables (see letter A).

2. Remove the two screws to release the Solid State Drive carrier (see letter B).

3. Pull the Solid State Drive up to remove from the air duct (see letter C).

4. Remove the four screws to release the Solid State Drive (see letter D).

5. Pull the Solid State Drive up to remove from the carrier (see letter E).

6. Secure the Solid State Drive carrier to chassis with the two screws.

Figure 67. Removing a SSD

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 45

Installing and Removing the Intel® RAID Smart Battery

Before installing or removing the Intel® R

AID Smart Battery, please make sure following steps are

performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

Installing the Intel® RAID Smart Battery

1. Connect the cable between the BBU and the RAID card. For details, see Intel® RAID Smart

Battery User’s Guide.

2. Position the battery against chassis (see letter A).

3. Align the tabs on the plastic battery holder with the mounting holes in the chassis and slide in

the plastic battery holder until the tabs engage with the mounting holes (see letter B).

Figure 68. Installing the Intel® RAID Smart Battery

Hardware Installations and Upgrades

46 Intel® Server System R2000LH2/LT2 Service Guide

Removing the Intel® RAID Smart Battery

1. Slide out the plastic battery holder (see letter A).

2. Lift the battery up to remove it from the server chassis (see letter B).

Figure 69. Removing the Intel® RAID Smart Battery

Installing and Removing the Server Board

Before installing or removing the server board, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. R

emove the air duct. For instructions, see Removing the Air Duct.

6. Remove the processor heatsink(s). For instructions, see Removing Processor Heatsink(s).

7. Remove the processor(s). For instructions, see Installing or Replacing the Processor.

8. Remove the memory. For instructions, see Removing Memory.

9. Remove all the Intel® I/O expansion module(s). For instructions, see Removing Intel® I/O Expansion

Module.

10. Remove Intel® Remote Management Module 4. For instructions, see Installing and Removing the

Intel® Remote Management Module 4.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 47

Removing the Server Board

1. Disconnect all cables from the server board.

2. Remove the thirteen screws from the server board (see letter A).

3. Lift the server board from the server system (see letter B).

Figure 70. Re

moving the Server Board

Installing the Server Board

1. Place the server board into the server system (see letter A).

2. Secure the server board with thirteen screws (see letter B).

Figure 71. I

nstalling the Server Board

3. Connect all power cables to the server board.

Hardware Installations and Upgrades

48 Intel® Server System R2000LH2/LT2 Service Guide

Replacing the Backup Battery

The lithium battery on the server board powers the RTC for up to 10 years in the absence of power.
Whe

n the battery starts to weaken, it loses voltage, and the server settings stored in CMOS RAM in
the RTC (for example, the date and time) may be wrong. Contact your customer service
representative or dealer for a list of approved devices.

Warning: Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the equipment manufacturer. Discard used batteries according to
manufacturer's instructions.

Advarsel: Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med

batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren.

Advarsel: Lithiumbatteri - Eksplosjonsfare. Ved utskifting benyttes kun batteri som anbefalt av

apparatfabrikanten. Brukt batteri returneres apparatleverandøren.

Varning: Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller en ekvivalent typ

som rekommenderas av apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion.

Varoitus: Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan

laitevalmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. R

emove the power supply modules. For instructions, see Removing the Power Supply

Modu

le(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see

Removing the Air Duct.

6. Locate the battery on the server board.

7. Gently press the metal clip as shown to release the battery (see letter A).

8. Remove the battery from the plastic socket (see letter B).

Figure 72.

Replacing the Backup Battery

9. Dispose of the battery according to local ordinance.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 49

10. Remove the new lithium battery from its package, and, being careful to observe the correct

polarity, insert it in the battery socket.

Note: You will need to run the BIOS Setup to restore the configuration settings to the RTC.

Replacing a Redundant Fan Module

1. Remove the system cover if needed. For instructions, see Removing the System Cover.

2. Pull system fan straight up to remove it from the fan holder.

3. Replace the system fan by guiding it into the slot and firmly pressing down to ensure that it is

properly seated.

Figure 73.

Replacing a system fan

Hardware Installations and Upgrades

50 Intel® Server System R2000LH2/LT2 Service Guide

Replacing the Backplane

Before removing or installing the backplane, please make sure following steps are performed.

1. Ensur

e the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove all hot-swap drive carriers, regardless of whether or not a drive is installed in the carrier.

Removing the Backplane

1. Disconnect all cables from the backplane.

2. Remove the screw (see letter A).

3. Pull up the backplane (see letter B).

4. Remove the backplane from the server chassis (see letter C).

Figure 74.

Removing the backplane

Installing the Backplane

1. Hold the backplane only by the edges. Do not push or pull on any components on the backplane.

Position the backplane in place at the front of the server system (see letter A).

2. Slide the backplane into the server system guides (see letter B).

3. Secure the backplane with the screw as shown (see letter C).

Figure 75.

Installing the backplane

4. Connect cables to backplane, please refer to Cable Routing.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 51

Replacing the Lower Fan Board

Before removing or installing the lower fan board, please make sure following steps are performed.

1. Ensur

e the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. Remove system the fan modules connected to the lower fan board. For instructions, see Replacing

a Redundant Fan Module.

4. Remove the rack handles. For instructions, see Removing the Rack Handles.

5. Remove the front end module. For instructions, see Removing the Front End Module.

Removing the Lower Fan Board

1. D

isconnect all cables from the lower fan board.

2. Remove the screws (see letter A).

3. Remove the lower fan board from the server chassis (see letter B).

Figure 76.

Removing the Lower Fan Board

Hardware Installations and Upgrades

52 Intel® Server System R2000LH2/LT2 Service Guide

Installing the Lower Fan Board

1. H

old the lower fan board only by the edges. Do not push or pull on any components on the
lower fan board. Position the lower fan board in place at the front of the server system (see
letter A).

2. Secure the lower fan board with the screws as shown (see letter B).

Figure 77.

Installing the Lower Fan Board

3. Connect cables to the lower fan board; please refer to Cable Routing.

Replacing the Front Video and USB Module

Before removing or installing the front video and USB module, please make sure following steps are
performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. R

emove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 53

Removing the Front Video and USB Module

1. Disconnect video and USB cables from server board (see letter A).

2. Remove the two screws as shown (see letter B).

3. Slide the module out (see letter C).

4. Remove the two screws as shown, slide the front USB header out (see letter D).

Figure 78. Removing the front video and USB Module

Hardware Installations and Upgrades

54 Intel® Server System R2000LH2/LT2 Service Guide

Installing the Front Video and USB Module

1. Secure the front USB header to the module with two screws as shown (see letter A).

2. Insert the front video and USB module into chassis (see letter B).

3. Secure the front video and USB module to chassis with two screws (see letter C).

4. Install the video and USB cables to the server board as shown (see letter D).

Figure 79. Installing the front video and USB Module

Installing and Removing the LCP Module

Before installing or removing the LCP module, please make sure following steps are performed.

1. Ensure the AC power cord(s) are disconnected from the system.

2. Remove the system cover. For instructions, see Removing the System Cover.

3. R

emove the power supply modules. For instructions, see Removing the Power Supply Module(s).

4. Remove the PCI riser assemblies. For instructions, see Removing the PCI Riser Assembly.

5. Remove the air duct. For instructions, see Removing the Air Duct.

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 55

Installing the LCP Module

1. Remove the front video and USB module. For instructions, see Removing the Front Video and

USB Module.

2. Secur

e the front USB header to the module with two screws as shown (see letter A).

3. Insert the LCP module into chassis (see letter B).

4. Secure the LCP module to chassis with two screws (see letter C).

5. Install the LCP and USB cables to the server board as shown (see letter D).

Figure 80. Installing the LCP Module

Hardware Installations and Upgrades

56 Intel® Server System R2000LH2/LT2 Service Guide

Removing the LCP Module

1. Disconnect LCP and USB cables from server board (see letter A).

2. Remove the two screws as shown (see letter B).

3. Slide the module out (see letter C).

4. Remove the two screws as shown, slide the front USB header out (see letter D).

5. Install the front video and USB module. For instructions, see

Installing the Front Video and

USB Module.

Figure 81.

Removing the LCP Module

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 57

Install the Bezel (Optional)

Install the System into Rack (Optional)

Caution:

The maximum recommended server weight for the rack rails can be found at

http://www.intel.com/support/motherboards/server/sb/CS-033655.htm. Exceeding the maximum

recommended weight or misalignment of the server may result in failure of the rack rails holding
the server. Use of a mechanical assist to install and align server into the rack rails is
recommended.

Note: The Extended Value rack mount rail kit (AXXELVRAIL) supports the system weight of ~65lbs

fully loaded. However, the rail travel limitation does not allow removal of the top cover during
normal operation, impacting hot swapping of the system fans. The Premium rack mount rail kit
(AXXPRAIL) will be available at post launch to eliminate the hot swap fan limitation.

This section helps you to install the system into a rack with AXXELVRAIL.

Label

Description

Label

Description

A

Front Bracket

D

Inner Member

B

Outer Member

E

Safety Locking Pin

C

Rear Bracket

F

Release Button

Figure 82. Slides Component

Hardware Installations and Upgrades

58 Intel® Server System R2000LH2/LT2 Service Guide

Installing the Chassis into Rack

1. Pull release button to remove inner member from slides.

2. Align brackets to desired vertical position on rack and insert fasteners.

3. Move ball retainer to the front of slides.

F

igure 83. Install Slides to Rack

4. Align inner member key holes to standoffs on chassis, move inner member as shown below.

Figure 84.

Install Inner Member to Chassis

Hardware Installations and Upgrades

Intel® Server System R2000LH2/LT2 Service Guide 59

5. Pull the release button in the inner member to release the lock and allow the chassis to close.

Figure 85. Install Chassis to Fixed Slides

Removing the Chassis from Rack

1. Full

y extend the slides until it is in the locked position, pull the release button to release lock

and disconnect inner member from slides.

Figure 86.

Extend Slides

Hardware Installations and Upgrades

60 Intel® Server System R2000LH2/LT2 Service Guide

2. Press safety locking pin to release inner member from chassis.

Figure 87. Remove Inner Member from Chassis

Server Utilities

Intel® Server System R2000LH2/LT2 Service Guide 61

3 Server Utilities

Using the BIOS Setup Utility

This section describes the BIOS Setup Utility options, which is used to change server
configuration defaults. You can run BIOS Setup with or without an operating system
being present.

Starting Setup

To enter the BIOS Setup using a keyboard (or emulated keyboard); press the <F2> function key
during boot time when the OEM or Intel® logo is displayed. The following message is
displayed on the diagnostics screen and under the Quiet Boot logo screen:

Press <F2> to enter setup

When the Setup Utility is entered, the Main screen is displayed. However, serious errors cause
the system to display the Error Manager screen instead of the Main screen.

Setup Navigation Keyboard Commands

The bottom right portion of the Setup screen provides a list of commands that are used to
nav

igate through the Setup utility. These commands are displayed at all times.

Each Setup menu page contains a number of features. Each feature is associated with a value
field, except those used for informative purposes. Each value field contains configurable
parameters. Depending on the security option chosen and in effect by the password, a menu
feature’s value may or may not be changed. If a value cannot be changed, its field is made
inaccessible and appears grayed out.

Table 7. B

IOS Setup: Keyboard Command Bar

Key

Option

Description

<Enter>

Execute Command

The <Enter> key is used to activate submenus when the selected feature is a submenu, or to
display a pick list if a selected option has a value field, or to select a subfield for multi-
valued features like time and date. If a pick list is displayed, the <Enter> key selects the
currently highlighted item, undoes the pick list, and returns the focus to the parent menu.

<Esc>

Exit

The <Esc> key provides a mechanism for backing out of any field. When the <Esc> key is
pressed while editing any field or selecting features of a menu, the parent menu is re-
entered.

When the <Esc> key is pressed in any submenu, the parent menu is re-entered. When the
<Esc> key is pressed in any major menu, the exit confirmation window is displayed and the

user is asked whether changes can be discarded. If “No” is selected and the <Enter> key is

pressed, or if the <Esc> key is pressed, the user is returned to where they were before
<Esc> was pressed, without affecting any existing settings. If “Yes” is selected and the
<Enter> key is pressed, the setup is exited and the BIOS returns to the main System
Options Menu screen.



Select Item

The up arrow is used to select the previous value in a pick list, or the previous option in a
menu item's option list. The selected item must then be activated by pressing the <Enter>
key.

Select Item

The down arrow is used to select the next value in a menu item’s option list, or a value
field’s pick list. The selected item must then be activated by pressing the <Enter> key.

Select Menu

The left and right arrow keys are used to move between the major menu pages. The keys
have no effect if a sub-menu or pick list is displayed.

Server Utilities

62 Intel® Server System R2000LH2/LT2 Service Guide

Key

Option

Description

<Tab>

Select Field

The <Tab> key is used to move between fields. For example, <Tab> can be used to move
from hours to minutes in the time item in the main menu.

-

Change Value

The minus key on the keypad is used to change the value of the current item to the previous
value. This key scrolls through the values in the associated pick list without displaying the
full list.

+

Change Value

The plus key on the keypad is used to change the value of the current menu item to the next
value. This key scrolls through the values in the associated pick list without displaying the
full list. On 106-key Japanese keyboards, the plus key has a different scan code than the
plus key on the other keyboards, but will have the same effect.

<F9>

Setup Defaults

Pressing the <F9> key causes the following to display:

Load Optimized Defaults?

Yes No

If “Yes” is highlighted and <Enter> is pressed, all Setup fields are set to their default
values. If “No” is highlighted and <Enter> is pressed, or if the <Esc> key is pressed, the

user is returned to where they were before <F9> was pressed without affecting any existing
field values.

<F10>

Save and Exit

Pressing the <F10> key causes the following message to display:

Save configuration and reset?

Yes No

If “Yes” is highlighted and <Enter> is pressed, all changes are saved and the Setup is
exited. If “No” is highlighted and <Enter> is pressed, or the <Esc> key is pressed, the user

is returned to where they were before <F10> was pressed without affecting any existing
values.

Setup Screen Menu Selection Bar

The Setup Screen Menu selection bar is located at the top of the BIOS Setup Utility screen. It
displays tabs showing the major screen selections available to the user. By using the left and
right arrow keys, the user can select the listed screens. Some screen selections are out of the
visible menu space, and become available by scrolling to the left or right of the current
selections displayed.

BIOS Setup Utility Screens

The following sections describe the screens available in the BIOS Setup utility for the
conf

iguration of the server platform.

For each of these screens, there is an image of the screen with a list of Field Descriptions which
describe the contents of each item on the screen. Each item on the screen is hyperlinked to the
relevant Field Description. Each Field Description is hyperlinked back to the screen image.

These lists follow the following guidelines:

 The text heading for each Field Description is the actual text as displayed on the BIOS Setup

screen. This screen text is a hyperlink to its corresponding Field Description.

 The text shown in the Option Values and Help Text entries in each Field Description are the

actual text and values are displayed on the BIOS Setup screens.

Server Utilities

Intel® Server System R2000LH2/LT2 Service Guide 63

 In the Option Values entries, the text for default values is shown with an underline. These values

do not appear underline on the BIOS Setup screen. The underlined text in this document is to
serve as a reference to which value is the default value.

 The Help Text entry is the actual text which appears on the screen to accompany the item when

the item is the one in focus (active on the screen).

 The Comments entry provides additional information where it may be helpful. This information

does not appear on the BIOS Setup screens.

 Information enclosed in angular brackets (< >) in the screen shots identifies text that can vary,

depending on the option(s) installed. For example, <Amount of memory installed> is replaced by
the actual value for “Total Memory”.

 Information enclosed in square brackets ([ ]) in the tables identifies areas where the user must

type in text instead of selecting from a provided option.

 Whenever information is changed (except Date and Time), the systems requires a save and reboot

to take place in order for the changes to take effect. Alternatively, pressing <ESC> discards the
changes and resumes POST to continue to boot the system according to the boot order set from
the last boot.

Map of Screens and Functionality

There are a number of screens in the entire Setup collection. They are organized into major
categories. Each category has a hierarchy beginning with a top-level screen from which lower-
level screens may be selected. Each top-level screen appears as a tab, arranged across the top of
the Setup screen image of all top-level screens.

There are more categories than will fit across the top of the screen, so at any given time there
will be some categories which will not appear until the user has scrolled across the tabs which
are present.

The categories and the screens included in each category are listed below, with links to each of
the screens named.

Table 8. Scre

en Map

Categories (Top Tabs)

2nd Level Screens

3rd Level Screens

Main Screen (Tab)

Advanced Screen (Tab)



Processor Configuration

 Memory Configuration

[Except S1200BT]

Memory RAS and Performance
Configuration



Mass Storage Controller
Configuration



PCI Configuration



Serial Port Configuration



USB Configuration

[With BMC Only]

System Acoustic and Performance
Configuration

[Non-BMC Only]

Hardware Monitor

[Non-BMC Only]

Realtime Temperature and Voltage
Status

Security Screen (Tab)

Server Utilities

64 Intel® Server System R2000LH2/LT2 Service Guide

Categories (Top Tabs)

2nd Level Screens

3rd Level Screens

Server Management Screen (Tab)



Console Redirection



System Information

[With BMC Only]

BMC LAN Configuration

Boot Options Screen (Tab)



CDROM Order

 Hard Disk Order



Floppy Order



Network Device Order



BEV Device Order



Add EFI Boot Option



Delete EFI Boot Option

Boot Manager Screen (Tab)

Error Manager Screen (Tab)

[Non-BMC Only]

View Event Log Screen

Exit Screen (Tab)

Appendix A: Regulatory and Compliance Information

Intel® Server System R2000LH2/LT2 Service Guide 65

Appendix A: Regulatory and Compliance Information

Please refer to the Server Products Regulatory and Safety document for the product regulatory
compliance reference. The document can be downloaded from

http://www.intel.com/support/motherboards/server/.

Appendix B: Safety Information

66 Intel® Server System R2000LH2/LT2 Service Guide

Appendix B: Safety Information

Please refer to the Server Products Regulatory and Safety document for the Safety Information.
The document can be downloaded from http://www.intel.com/support/motherboards/server/.

Appendix C: Installation/Assembly Safety Instructions

Intel® Server System R2000LH2/LT2 Service Guide 67

Appendix C: Installation/Assembly Safety Instructions

Please refer to the Server Products Regulatory and Safety document for the
Installation/Assembly Safety Instructions. The document can be downloaded from

http://www.intel.com/support/motherboards/server/.

Appendix D: Getting Help

68 Intel® Server System R2000LH2/LT2 Service Guide

Appendix D: Getting Help

If you encounter an issue with your server platform, please follow these steps
to obtain support on your product.

1 Get connected to our support web page for 24x7 support when you need it to get the latest and

most complete technical support information on all Intel® Enterprise Server and Storage
Platforms. Information available at the support site includes:

 Latest BIOS, firmware, drivers, and utilities
 Product documentation, Installation, and Quick Start Guides
 Full product specifications, technical advisories, and errata
 Compatibility documentation for memory, hardware add-in cards, chassis support matrix,

and operating systems

 Server and chassis accessory parts list for ordering upgrades or spare parts
 A searchable knowledgebase to search for product information throughout the support site

2 Send an email to Intel®’s technical support center using the following online form if you still

cannot obtain a solution to your issue.

3 Lastly, you can contact an Intel® support representative using one of the following support

phone numbers. Charges may apply. Intel® customer support suggests filling out the issue
report form to better service the issue.

Intel® now offers Channel Program members around-the-clock 24x7 technical phone support on
Intel® server boards, server chassis, server RAID controller cards, and Intel® Server
Management.

Note: You must login in to the reseller site to obtain the 24x7 number.

Warranty Information

To obtain warranty information, visit the following Intel® w

ebsite:

http://www.intel.com/support/motherboards/server/sb/cs-010807.htm

Appendix E: Intel® Server Issue Report Form

Intel® Server System R2000LH2/LT2 Service Guide 69

Appendix E: Intel® Server Issue Report Form

Issue Report Form (Rev 3.6)

Note: Filling out this form completely is required for any escalation.

Customer Contact Information:

Customer Support Case#:

Intel® Server Board or System:

(Example: S2400BB, R2000BB)

Server Chassis:

(Example P4000M. If third-party chassis used, indicate make and model.)

Base Board Information: (Some information maybe found by accessing BIOS & going through
the Server Management menu > System Information)

Baseboard PBA/TA/AA # (Example: 123456-789):

- can be found on the white sticker label on the baseboard.

System BIOS Version:

Intel® Remote Management Module Firmware Version (if applicable):

BMC Version:

FRU/SDR Version:

Has the latest BIOS been tried? (Yes/No):

Has the latest BMC been tried? (Yes/No):

Has the latest RMM Firmware been tried? (Yes/No):

Has the latest FRU/SDR been tried? (Yes/No):

Processor information:

Type

Speed

sSpec

Thermal Solution

Processor 1

Processor 2

Appendix E: Intel® Server Issue Report Form

70 Intel® Server System R2000LH2/LT2 Service Guide

Thermal solution (heatsink) examples:

(1U, Passive w/air ducting, and so on)

Memory:

Manufacturer

Part Number

DRAM Part Number

On Intel tested list?

Add-in adapters (Example: NICs, Management Adapters, Serial Expansion Cards, PCI-Express*
Adapters, RAID Controllers, SCSI Controllers, and so on):

Type

Slot

Manufacturer

Model

Firmware

Other third party hardware (Example: Example: KVM, Chassis, and so on):

Description/Use

Manufacturer

Model

Firmware

Storage Devices (Example: SCSI, SATA, SAS, USB, Tape, and so on):

Manufacturer

Model

Type

Size

Firmware

In Hot Swap Bay?

Appendix E: Intel® Server Issue Report Form

Intel® Server System R2000LH2/LT2 Service Guide 71

Manufacturer

Model

Type

Size

Firmware

In Hot Swap Bay?

Operating System Information (Example: RedHat* Enterprise Linux, Microsoft Windows Server
2003* Service pack 1, OEM CD):

Manufacturer:

Version:

Language version (English, Arabic, and Chinese (Simplified)):

Service Pack Level or Kernel Revision:

Distribution (OEM/Retail):

Intel® RAID Controller: (Example SRCU42E)

RAID controller part number (PBA number):

RAID controller firmware version:

Has the latest RAID firmware been tried? (Yes/No):

RAID driver version:

Has the latest RAID driver been tried? (Yes/No):

RAID volumes configuration (disks & RAID level):

RAID volume use (Boot device/Data Volume):

Is BBU (Battery Backup Unit) installed? (Yes/No):

BBU part number:

Detailed description of issue:

Appendix E: Intel® Server Issue Report Form

72 Intel® Server System R2000LH2/LT2 Service Guide

Troubleshooting tried:

Steps to replicate the issue:

Issue impact statements:

Do you have any potential Intel system, or component purchases that this issue is holding up? If
yes, please provide a brief description below.

Do you have systems already purchased that are not being delivered to your customers because of
this issue? If yes, please provide a brief description below.

Have you returned systems or components to your place of purchase because of this issue? If yes,
please provide a brief description below.

*All other brands and names are property of their respective owners.

Appendix F: Warranty

Intel® Server System R2000LH2/LT2 Service Guide 73

Appendix F: Warranty

Limited Warranty for Intel® Chassis Subassembly Products

Intel® warrants that the Products (defined herein as the Intel® chassis subassembly and all of its
various components and software delivered with or as part of the Products) to be delivered
hereunder, if properly used and installed, will be free from defects in material and workmanship
and will substantially conform to Intel®'s publicly available specifications for a period of three
(3) years after the date the Product was purchased from an Intel® authorized distributor.
Software of any kind delivered with or as part of products is expressly provided "as is" unless
specifically provided for otherwise in any software license accompanying the software.

If any Product furnished by Intel® which is the subject of this Limited Warranty fails during the
warranty period for reasons covered by this Limited Warranty, Intel®, at its option, will:

 REPAIR the Product by means of hardware and/or software; OR
 REPLACE the Product with another Product; OR
 REFUND the then-current value of the Product if Intel® is unable to repair or replace

the Product.

If such Product is defective, transportation charges for the return of Product to buyer within the
USA will be paid by Intel®. For all other locations, the warranty excludes all costs of shipping,
customs clearance, and other related charges. Intel® will have reasonable time to make repairs
or to replace Product or to refund the then-current value of the Product.

In no event will Intel® be liable for any other costs associated with the replacement or repair of
Product, including labor, installation or other costs incurred by buyer and in particular, any
costs relating to the removal or replacement of any product soldered or otherwise permanently
affixed to any printed circuit board.

This Limited Warranty, and any implied warranties that may exist under state law, apply only
to the original purchaser of the Product.

Extent of Limited Warranty

Intel® does

not warrant that Products to be delivered hereunder, whether delivered standalone
or integrated with other Products, including without limitation semiconductor components, will
be free from design defects or errors known as “errata”. Current characterized errata are
available upon request.

This Limited Warranty does not cover damages due to external causes, including accident,
problems with electrical power, usage not in accordance with product instructions, misuse,
neglect, alteration, repair, improper installation, or improper testing.

Warranty Limitations and Exclusions

These warranties replace all other warranties, expressed or implied including, but not limited

to,
the implied warranties of merchantability and fitness for a particular purpose. Intel® makes no
expressed warranties beyond those stated here. Intel® disclaims all other warranties, expressed
or implied including, without limitation, implied warranties of merchantability and fitness for a

Appendix F: Warranty

74 Intel® Server System R2000LH2/LT2 Service Guide

particular purpose. Some jurisdictions do not allow the exclusion of implied warranties, so this
limitation may not apply.

All expressed and implied warranties are limited in duration to the limited warranty period. No
warranties apply after that period. Some jurisdictions do not allow limitations on how long an
implied warranty lasts, so this limitation may not apply to you.

Limitations of Liability

Intel®’s responsibility under this, or any other warranty, implied or expressed, is limited to
repair, replacement, or refund, as set forth above. These remedies are the sole and exclusive
remedies for any breach of warranty. Intel® is not responsible for direct, special, incidental, or
consequential damages resulting from any breach of warranty under another legal theory
including, but not limited to, lost profits, downtime, goodwill, damage to or replacement of
equipment and property, and any costs of recovering, reprogramming, or reproducing any
program or data stored in or used with a system containing this product. Some jurisdictions do
not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.

This limited warranty gives you specific legal rights, and you may also have other rights that
vary from jurisdiction to jurisdiction.

Any and all disputes arising under or related to this Limited Warranty shall be adjudicated in
the following forums and governed by the following laws: for the United States of America,
Canada, North America, and South America, the forum shall be Santa Clara, California, USA,
and the applicable law shall be that of the State of California, USA; for the Asia Pacific region,
the forum shall be Singapore and the applicable law shall be that of Singapore; for Europe and
the rest of the world, the forum shall be London and the applicable law shall be that of the
United Kingdom. In the event of any conflict between the English language version and any
other translated version(s) of this Limited Warranty, the English language version shall control.

How to Obtain Warranty Service

To obtain warranty service for this Product, you may contact Intel® or

your authorized

distributor.

 North America and Latin America: To obtain warranty repair for the product, please go

to the following website to obtain instructions:

http://www.intel.com/support/motherboards/warrantysupport.htm

 In Europe and in Asia: Contact your original authorized distributor for warranty service.

Any replacement Product is warranted under this written warranty and is subject to the same
limitations and exclusions for the remainder of the original warranty period.

Telephone Support

If you cannot find the information you need on Intel®'

s website (http://www.intel.com), call

your local distributor or an Intel® Customer Support representative.

See Appendix D: Getting Help for telephone numbers.

Returning a Defective Product

Before returning any product, call your authorized dealer/distribution authority.
