Penclic Mouse R2．１™ Quickguide
EN
Quickguide
2
EN
Welcome to the quick guide.
Penclic Mouse™ combines ergonomically
sound design with modern mouse technology
to bring you unparalleled precision,
comfort and effi ciency.
Mouse setup
Remove plastic fi lm from the installed battery., then set
the mouse power
switch on the bottom of the mouse to ON. The wireless
connection activates automatically.
How to use your Penclic Mouse™
1. Hold Penclic Mouse™ like a pen, the bottom part acts
like a traditional mouse.
2. Let your forearm and your hand rest on a surface,
while keeping your shoulders relaxed.
3. The pen par can be adjusted to suit specifi c grips.
Fixate the bottom part with one hand and rotate the pen to
the preferred angle with the other.
1
Left click
2
Right click
3
Middle click
4
Backward click
5
Forward click
6
Scroll wheel
7
On-off switch
Troubleshooting
www.Penclic.se/troubleshooting
· Connect to another computer.
· Cursor movement may be effected by very
glossy surfaces.
· Check the battery.
·
· When the battery needs charging the LED on the mouse
will show red. When the battery is fully charged a green
light will be displayed.
3
QG-Wireless.indd 2-3
2011-06-27 21.27
Technical specifi cations
The supported platforms for Penclic Mouse™ are all
operating systems that support HID 1.1. These include
Windows XP or later, Mac OSX version 10.1 or later
and most Linux/BSD fl avors. No extra software/driver
installation is needed.
· Operates on almost any surface without any
pad or tablet.
· Implements a 5-button and scroll wheel.
·
· AAA 1.2V NiMH Recharging battery (Everyday use last
approximately 3 months before charging is needed).
· Charging via USB.
· LR 03/AAA/1.5V Alkaline None rechargeable battery
can be used. NOTE: do not recharge.
· Energy saving mode starts after 10 min, press a
button to start.
· Wireless reach, minimum 5 metres.
· Dpi setting 800-1200-1600-2400.
NOTE: the dpi setting can be ch anged by holding in the
left and right button at the same time for 3 sec , the
cursor will move faster for each setting. It will rotate
around from 800-2400 and then go back to low 800.
Once the power is shut of the dpi setting will return to
its default setting, 1200 dpi.
Measurements:
Height: 140 mm, Base: 44.1 x 20 mm.
Weight: 41 g
4
QG-Wireless.indd 4-5
QG-Wireless.indd 50-5 2011-06-27 21.27
Technical support
Should you require additional technical support with
your Penclic Mouse™ , please use our Web site for further
information or contact our support group through e-mail.
Call Technical Support during business hours, central
European time plus one hour.
Contact:
0046 8 544 98 995
email: contact@penclic.se
2011-06-27 21.27
5
PenClic Technology AB
Vendevägen. 90 / 182 32 DANDERYD
contact@penclic.se / www.penclic.se
QG-Wireless.indd 54
tel: 0046 8 544 98 995
2011-06-27 21.27
FCC WARNING
This device complies with Par t 15 of the F CC Rules. Operation is subject to the fol lowing two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired oper ati on.
NOTE: Any changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
