Penclic wireless Keyboard Quick guide

EN

Quick guide

2

Smile.

EN

Welcome to the quick guide.
Penclic wireless Keyboard combines ergonomically
sound design with modern keyboard technology
to bring you comfort and efficiency.

2

Penclic wireless Keyboard setup

Insert the rechargeable batteries and start

charging with the included USB charging
cable, the USB port supports only charging function.

then set the keyboard power switch on the bottom
of the keyboard to ON.
Driver installation starts automatically.
The wireless connection activates automatically.

How to use your Penclic wirelessss
Keyboard

Penclic wireless Keyboard K2 (wireless) has 1 LED

indicating battery status.

LED behavior Indication

1 red flash The keyboard on/

LED flashes red
repeatedly

LED flashes
green repeatedly

LED is
constantly green

off switch was set
to on.

Recharge your
battery. (NOTE:Do
not recharge
non-rechargeable
batteries.)

Battery is currently
being recharged.

Battery is currently
being recharged.

Num Lock actives the numpad functions which
is the smaller orange numbers.

Special functions (blue text) activated by holding

the Fn key and then pressing:

Fn + Function

F2 Mute

F3 Lower volume

F4 Higher volume

F9 Pause/Break

F10 Scroll Lock

F11 Num Lock

F12 Print Screen

Delete Insert

Up arrow Page Up

Left arrow Home

Down Arrow Page Down

Right Arrow End

3

Technical specifications

·

The supported platforms for Penclic wireless

Keyboard are all operating systems that
support HID 1.1. These include Windows XP or
later, Mac OSX version 10.1 or later and most
Linux/BSD flavors. No extra software/driver
installation is needed.

Connection USB.

·

·

AAA 1.2V NiMH Recharging battery (Everyday
use last approximately 2 months before
charging is needed).

-Charging via USB .

· LR 03/AAA/1.5V Alkaline None rechargeable
battery can be used. NOTE: DO NOT
RECHARGE.

· USB-receiver 2,4GHz.

-Wireless reach, minimum 5 metres

-Connection via USB .

· Energy saving mode starts after 10 min, press
a button to start.

· MAC operating systems do not support all the
special functions.

Measurements

· Height: 6 mm (21 mm at top),
Base: 285 x 162 mm.

· Weight: 381g including 1.4m cable.

Troubleshooting

· Make sure the Penclic wireless Keyboard USB

connector is firmly attached to the computer’s
USB port.

· Un-plug and re-plug the USB receiver.

· Connect to another USB port.

· · Connect to another computer.

Check the battery.

Technical support

Should you require additional technical support
with your Penclic®, please use our Web site
(www.penclic.se) for further information or contact
our support group through e-mail. Call Technical
Support during business hours, Central European
time (UTC+1).

Contact

+ 46 8 544 98 995
[e-mail]

5

6

FCC Warning

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

-Consult the dealer or an experienced radio/TV technician for help.

NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
