PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
Before installation, these instructions must be carefully read and understood.
4. Inspection ...................................................... 4
5. Installation ..................................................... 4
5.1 Inspection and cleaning of glass ........... 4
5.2 Installation of unit to gauge ................... 4
5.3 Electrical installation ............................. 5
6. Operation ....................................................... 6
7. Maintenance .................................................. 6
7.1 Preventative maintenance ..................... 6
7.2 Maintenance procedures ....................... 6
7.3 Troubleshooting ..................................... 6
7.4 Allowable modifications ......................... 6
8. Removal - disassembly - reassembly ......... 6
8.1 Disassembly ........................................... 6
8.2 Reassembly ............................................ 7
9. Packaging, storage and transportation ....... 7
9.1 Packaging ............................................... 7
9.2 Storage .................................................... 7
9.3 Transportation ........................................ 7
10. Disposal at end of useful life ........................ 7
11. Warranty ........................................................ 7
12. Telephone assistance ................................... 7
13. Transparent Gauge ....................................... 8
14. Reflex Gauge .................................................. 9
TABLE OF CONTENTS
1. Safety information ......................................... 2
2. Introduction ................................................... 2
2.1 System description ................................. 2
3. Available models ........................................... 2
3.1 Power requirements and
specifications .......................................... 2
3.2 Approvals ................................................ 3
Tables and figures
Table 1 Model structure ............................... 3
Figure 1A LED illuminator exploded view ....... 8
Figure 1B LED illuminator ISO view ................ 8
Figure 1C LED illuminator top view ................. 8
Figure 2A LED illuminator exploded view ....... 9
Figure 2B LED illuminator ISO view ................ 9
Figure 2C LED illuminator top view ................. 9
Figure 3A LED illuminator exploded view ..... 10
Figure 3B LED illuminator ISO view .............. 10
Figure 3C LED illuminator TSL top view ....... 10
Figure 3D LED illuminator TSM top view ...... 10
Figure 4A Wiring installation - General
locations ......................................... 11
Figure 4B Wiring installation - Division
locations ......................................... 12
Figure 4C Wiring installation - ATEX/IECEx
locations ......................................... 13
Figure 5A Control drawing for division
locations ......................................... 14
Figure 5B Control drawing ATEX/IECEx ........ 14
Figure 6A Nameplate - General locations .... 15
Figure 6B Nameplate - Division locations .... 15
Figure 6C Nameplate - ATEX/IECEx .............. 16
Figure 6D Nameplate - LED Illuminator
body - ATEX/IECEx ......................... 16
VCIOM-04486-EN 22/07Emerson.com © 2017 Emerson. All Rights Reserved.
Page 2
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
1 SAFETY INFORMATION
IMPORTANT
It is the user's responsibility to ensure that all connections and wiring comply with all applicable codes, specifications, sales contracts or public laws.
IMPORTANT
The sales order lists the required operating voltage. Operation at a voltage other than specified will cause equipment damage.
The Flat Glass gauges operate at high temperatures. High surface temperature can be expected where this equipment connects to the gauge.
WARNING
Do not touch until the unit has cooled.
The Flat Glass gauge must be adequately supported to hold the weight of the LED illuminator. Shut-off LED illuminator before doing any maintenance or repairs.
2 INTRODUCTION
Penberthy LED illuminators are designed to be readily mounted and able to fit any style of Penberthy flat glass liquid level gauges, as well as most competitor’s flat glass gauges. Penberthy LED illuminators provide uniform light distribution over the entire length of liquid level gauge assemblies. Penberthy LED illuminators are available in lengths from 6" to 104" in multiples of 2" (for flat glass gauges).
2.1 System description
Penberthy LED illuminators are comprised of four main components. Use the exploded diagram view in Sections 13-15 as additional reference material. Illuminator: light source. It is composed of an anodized, rigid, extruded aluminum that protects the PC boards. Bracket: used to mount illuminator to level gauge. There are three types of brackets: standard transparent, reflex, and TSL/TSM. The brackets can be moved up and down along the extruded body making assembly and disassembly quick and easy.
Power supply: provides intrinsically safe power to the LED illuminator. Power supply is mounted inside an explosion proof enclosure that is mounted to the illuminator body. Cordset: used to connect the power supply to the illuminator. The cordset consists of a straight female connector and a straight male connector.
3 AVAILABLE MODELS
Penberthy LED illuminators are available with white LED’s only and are made to fit/cover the whole length of the gauge up to 104 inches. One power supply is required per 208 LED’s (104 inches). On average an LED will give the user 100,000 hours of use compared to 1000 hours for a standard light bulb.
3.1 Power requirements and specifications Input: 115/230 VAC ±10%, 50/60 Hz Power consumption:
up to 400 mA max at 115/230 VAC
Max distance from power supply to LED illuminator: 200 ft. (consult Emerson if longer
distance is required)
Ambient temperature range for general location:
-40 to 158°F (-40 to 70°C)
Ambient temperature range for hazardous location:
-40°F Ta +140°F (-40°C Ta
Ingress protection: IP66 Max altitude: 6.561 ft. Electrical connection size:
¾" FNPT for US and Canada M20 for ATEX and IECEx
• Unit must be wired with 14 AWG wire
minimum, with a maximum wire length of 1000 feet.
• An external switch or circuit-breaker
and external overcurrent protection is recommended to be installed near the unit.
• Unit can be use indoors and outdoors.
• Maximum relative humidity 80% for
temperatures up to 88°F (31°C) decreasing linearly to 50% relative humidity at 104°F (40°C).
WARNING
Do not tamper with Penberthy’s power supply or its components.
+60°C)
2
Page 3
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
3.2 Approvals General location
UL61010-1/CSA C22.2 No. 61010-1
ATEX Approved
II 2G (Power Supply) Ex d [ia Ga IIC] IIC T4 Gb II 1G (Illuminator)
Explosion-proof with intrinsically safe output
MET Certified for US and Canada
Class I Division 1 Groups A*, B, C, D T4
* only for Mounting Option 2
Ex ia IIC T4 Ga
IECEx Approved
Ex d [ia Ga IIC] IIC T4 Gb (Power Supply) Ex ia IIC T4 Ga (Illuminator)
When installed in accordance with Emerson Control Drawings:
• For Division Locations - 18WL4-009
(Figure 5A)
• For ATEX/IECEx - 18WR6-009 (Figure 5B)
Conditions of Use for Ex Component
1 Tserv according to use seal:
TPE: -40÷100/85°C - lower temperature for housing with sight glass VMO: -40÷100/85°C - lower temperature for housing with sight glass
FKM: -20÷200/85°C - lower temperature for housing with sight glass 2 Max number, size and position of apertures - are given in Application manual N-L2237 dated 31.03.2016 3 For information on the dimensions of the flameproof joints the manufacturer shall be contacted. 4 Apparatus installed inside of enclosure can have any lay-out, which ensures that in any cross section
area will be at least 40% (group IIC) of area free 5 The enclosure with Ex component certificate can be applicate only by assumption of filling requests of
the standard IEC 60079-1:2014, cl. D.3.10 6 Appropriately certified cable glands for direct entry have to be used 7 IP 68 max (h=1 m) 8 The max overpressure static test of housing: 50 bar/10 s 9 Max power dissipation for temperature class, see ANNEX to IECEx Certificate No. IECEx FTZU 12.0017U
Issue No. 0
TABLE 1 - MODEL STRUCTURE
Example: ILFG 1 T 1 S 1 D S Model description ILFG Illuminator LED flat glass ILFGO Illuminator LED flat glass offshore No of sections (1-7)
Number of gauge sections (1-7)
Gauge type R Reflex L TSL T Transparent M TSM Glass size (1-9)
Glass size of gauge (1-9)
Extension type S Standard F Frost Input power 1 115 V AC 50/60 Hz (¾ NPT inlet) 3 115 V AC 50/60 Hz (M20 inlet) 2 230 V AC 50/60 Hz (M20 inlet) 4 230 V AC 50/60 Hz (¾ NPT inlet) Application location G General locations D Division locations (MET for US and Canada) Z Zone locations (ATEX and IECEx) Installation configuration S Standard C Chain connection (staggered gauges) R Remote mount power supply A Chain connection (staggered gauges) and remote mount power supply
3
Page 4
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
4 INSPECTION
SAFETY INSTRUCTIONS
Exercise care in handling illuminator parts to avoid scratching, denting or otherwise damaging the protective glass. Any marks on the protective glass, as well as dirt, paint or tape will result in a reduction of light output. Upon receipt of an illuminator, check all components carefully for damage incurred in shipping. If damage is evident or suspected, do not attempt installation. Notify carrier immediately and request damage inspection. Refer to the exploded view diagram in Sections 13-15 to inventory parts.
5 INSTALLATION
Installation should only be undertaken by qualified personnel who are familiar with this equipment. They should have read and understood all of the instructions in this manual. The user should refer to Penberthy dimension sheets or Penberthy product proposal to obtain dimensional information for the specific size and model illuminator. It is the user’s responsibility to assure that knowledgeable installation personnel plan and carry out the installation in a safe manner. The following procedures are some of the guidelines that should be employed.
5.1 Inspection and cleaning of glass
Penberthy recommends that prior to installation of an illuminator to a gauge, that the gauge glass be cleaned and inspected per instructions as follows:
1. Clean glass within vision slot using a non­abrasive household cleaner. DO NOT use a wire brush, metal scraper or any devise which could scratch the glass.
2. Inspect the surface of the glass for any signs of clouding, etching, scratching or physical damage such as bruises, chips or erosion that penetrates the outer surface of the glass. Shining a light at approximately a 45º angle will aid in detecting some of these conditions. Light will glisten more brightly on glass imperfections than the surrounding glass when reflecting light. Detection of any such problem areas or surface wear is sufficient evidence of damage. Do not proceed with installation with damaged glass. See appropriate Installation, operation and maintenance manual and replace glass.
5.2 Installation of unit to gauge
Become familiar with the illuminator components before proceeding with installation. Refer to the exploded parts diagram, ISO and top views in Section 13 for transparent gauges, Section 14 for reflex gauges, and Section 15 for TSL/TSM gauges. As well as Figure 4A for general locations, 4B for division locations, and 4C for ATEX/ IECEx when performing the following installation instructions. To assemble the illuminator to a transparent style gauge, follow the steps below:
1. Screw the attachment plate to the slider bracket (leave two slider brackets in the middle-lower half of the illuminator for the power supply).
2. Insert the eyebolt/wire assembly on one side of the attachment plate only and fix with the nut/wing-nut provided.
3. Position the illuminator on the gauge so that the top end cap of the illuminator rests on the top end of the gauge cover.
4. Position the mounting brackets with wires where desired (3 ft. max distance between brackets is suggested) and wrap the wire around the gauge. Insert the other eyebolt on the opposite side of the attachment plate and fix with the nut/wing-nut provided.
5. Center the illuminator and firmly tighten down the wire to hold the illuminator to the gauge.
6. Open the cover of the power supply enclosure and make sure the AC input voltage selector switch in the power supply matches the input voltage provided to the unit (115 VAC or 230 VAC).
7. After voltage selector switch is selecting the correct input voltage, connect/plug in the AC wires to Terminal Block 1.
8. Fully close the cover of the enclosure by hand tightening it.
9. Mount power supply to the illuminator body using the last two slider brackets you set aside from step 1.
10. Connect the power supply to the LED illuminator using the cordset provided.
IMPORTANT For Hazardous Location Only
• A flame path seal-off shall be installed
within 18 in. of enclosure, see Figure 5A for Division Locations.
• A flame path seal-off shall be installed directly
to threaded entry of enclosure, see or Figure 5B for ATEX/IECEx.
• The LED Illuminator contains material
composition capable of igniting the explosive atmosphere due to physical impact or friction. Installation shall provide inherent protection from potential impacts risks by means of installation location, guards, and/or barriers.
4
Page 5
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
To assemble the illuminator to a reflex style gauge, follow the steps below:
1. Mount illuminator to reflex style flat glass gauge as shown in Figures 2B and 2C.
2. Remove the appropriate nuts from the gauge bolts. There are two gauge brackets, one will be mounted on the top and the other one on the bottom part of the gauge. If the illuminator length is over 48 inches, make sure to space the extra gauge brackets evenly (3 ft. max distance between brackets is suggested). Each gauge bracket is mounted onto 2 gauge bolts.
3. Install gauge bracket over gauge bolts and secure to gauge cover with gauge nuts. Torque gauge nuts to the proper torque as specified in the gauge Installation, Operation and Maintenance Instructions provided with the gauge.
4. Attach illuminator mounting bracket to gauge bracket using screws, lock washers and nuts provided.
5. Attach the LED illuminator body to the reflex mounting bracket using the screws and the slider bracket provided (leave two slider brackets in the middle-lower half of the illuminator for the power supply). The Illuminator should be centered with respect to the vision slot of the gauge.
6. Open the cover of the power supply enclosure and make sure the AC input voltage selector switch in the power supply matches the input voltage provided to the unit (115 VAC or 230 VAC).
7. After voltage selector switch is selecting the correct input voltage, connect/plug in the AC wires to Terminal Block 1.
8. Fully close the cover of the enclosure by hand tightening it.
9. Mount power supply to the illuminator body using the last two slider brackets you set aside from step 5.
10. Connect the power supply to the LED illuminator using the cordset provided.
IMPORTANT For Hazardous Location Only
• A flame path seal-off shall be installed
within 18 in. of enclosure, see Figure 5A for Division Locations.
• A flame path seal-off shall be installed directly
to threaded entry of enclosure, see or Figure 5B for ATEX/IECEx.
• The LED Illuminator contains material
composition capable of igniting the explosive atmosphere due to physical impact or friction. Installation shall provide inherent protection from potential impacts risks by means of installation location, guards, and/or barriers.
To assemble the illuminator to a TSL/TSM gauge, follow the steps below:
1. Attach the TSL/TSM mounting bracket, plate bracket, and power supply to the illuminator body using the screws and the slider brackets provided. Power supply should be mounted to the illuminator body that will be mounted to the lower gauge section.
2. Hand tight the screws to prevent TSL/TSM bracket from sliding.
3. Insert the eyebolt/wire assembly on one side of the plate bracket only and fix with the nut/ wing-nut provided.
4. Position the illuminator on the gauge so that is centered with respect to the vision slot of the gauge.
5. Wrap the SAS wire around the gauge and the TSL/TSM mounting bracket (place wire rope through the tabs on the bracket to keep it straight) . Insert the other eyebolt on the opposite side of the plate bracket and fix with the nut/wing-nut provided.
6. Center the illuminator and firmly tighten down the wire assembly to hold the illuminator to the gauge.
7. Open the cover of the power supply enclosure and make sure the AC input voltage selector switch in the power supply matches the input voltage provided to the unit (115 or 230 VAC).
8. After voltage selector switch is selecting the correct input voltage, connect/plug in the AC wires to Terminal Block 1.
9. Fully close the cover of the enclosure by hand tightening it.
10. Connect the power supply to the LED illuminator using the cordset provided.
IMPORTANT For Hazardous Location Only
• A flame path seal-off shall be installed
within 18 in. of enclosure, see Figure 5A for Division Locations.
• A flame path seal-off shall be installed directly
to threaded entry of enclosure, see or Figure 5B for ATEX/IECEx.
• The LED Illuminator contains material
composition capable of igniting the explosive atmosphere due to physical impact or friction. Installation shall provide inherent protection from potential impacts risks by means of installation location, guards, and/or barriers.
5.3 Electrical installation
WARNING
DO NOT proceed with electrical installation unless the illuminator has been mounted to the gauge according to instructions in Section 5.2. Only qualified electricians who have read and understood local and national electrical code should connect the illuminator to an electrical
source. Failure to follow any of these instructions may result in death, severe personal injury, property damage or damage to the illuminator and gauge.
The electrical installation should be performed by a qualified electrician and comply with applicable codes (U.S. - refer to National Electrical Code NFPA current edition; Canada­refer to Electrical Code CSA C22) or other regulations as applicable. The conduit must run in such a manner that it is not supported by or does not serve as a support for the illuminator. Unit must be grounded before it is operated.
5
Page 6
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
6 OPERATION
Check that all installation procedures have been completed. Use only qualified, experienced personnel who are familiar with illuminators and thoroughly understand the implications of all the instructions. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
7 MAINTENANCE
The user must create maintenance schedules, safety manuals, and inspection details for each specific installation of an illuminator.
7.1 Preventative maintenance
On all installations the following items should be regularly evaluated by the user for purposes of maintenance:
1. Protective glass, for signs of dirt build up, scratches or breakage.
2. Mounting bracket for signs of loosening.
The user must determine upon evaluation of his or her own operating experience an appropriate maintenance schedule necessary for his or her specific application. Realistic maintenance schedules can only be determined with full knowledge of the services and application situation involved.
7.2 Maintenance procedures
Cleaning the protective glass - wash with a non-abrasive soap or detergent and water using a soft, grit-free cloth or sponge. When cleaning grease and oil from the protective glass, use a chemical compatible with silicone rubber only and a soft, grit-free cloth. DO NOT use solvents such as acetone, benzene, carbon tetrachloride, dry cleaning fluid or lacquer thinners since they will attack the surface of the protective glass and or the gaskets. After surface has been cleaned and rinsed of foreign particles, it may be dried with a clean, soft, damp chamois or grit-free cloth.
7.3 Troubleshooting
1. Internal or external corrosion could be an indication of a harsh service environment. An investigation should immediately be carried out to determine the cause of the problem. It is the user’s responsibility to choose a material of construction compatible with both the contained fluid and the surrounding atmosphere.
2. All LED’s off could be an indication of power failure. Check the power supply and connections.
IMPORTANT
Contact manufacturer if any part needs to be replaced.
7.4 Allowable modifications
The LED illuminator are not to be modified in any way. Any modifications will void warranty and could result in equipment damage or serious personal injury.
8 REMOVAL - DISASSEMBLY - REASSEMBLY
8.1 Disassembly
Refer to the exploded parts diagram in Sections13-15 for additional reference during disassembly and reassembly of the illuminator.
Transparent gauge
1. Disconnect the electrical power source from the illuminator.
2. Hold the illuminator firmly. Loosen the wire assembly. Completely remove the eyebolts from the plate bracket (one side only).
3. Move wires out of the way and remove the illuminator.
Reflex gauge
1. Disconnect the electrical power source from the illuminator.
2. Hold the illuminator firmly. Remove the screws on the back of the illuminator body that hold the mounting bracket.
3. Remove the illuminator from the mounting bracket.
IMPORTANT
DO NOT use hard, rough cloths on edge of protective glass because they can scratch the surface. The scratches will result in reduced light output from the illuminator.
TSL/TSM gauge
1. Disconnect the electrical power source from the illuminator
2. Hold the illuminator firmly. Loosen the wire assembly. Completely remove the eyebolts for the plate bracket (only side only).
3. Move wires out of the way and remove the illuminator.
6
Page 7
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
8.2 Reassembly
Refer to the exploded parts diagram in Sections13-15 for additional reference during disassembly and reassembly of the illuminator.
Transparent gauge
1. Position the illuminator on the gauge so that the top end cap of the illuminator rests on the top end of the gauge cover.
2. Position the mounting brackets with wires where desired and wrap wire around the gauge. Insert other eyebolt on opposite side of attachment plate.
3. Center the illuminator and firmly tighten down the wire to hold the illuminator to the gauge.
4. Connect electrical power source to the illuminator.
Reflex gauge
1. Replace the screws on the back of the LED illuminator body.
2. Illuminator should be centered with respect to the vision slot of the gauge. Tighten screws to secure illuminator to the bracket.
3. Connect electrical power source to the illuminator.
TSL/TSM gauge
1. Position the illuminator on the gauge so that is centered with respect to the vision slot of the gauge.
2. Wrap the SAS wire around the gauge and the TSL/TSM mounting bracket (place wire rope through the tabs on the bracket to keep it straight) . Insert the other eyebolt on the opposite side of the plate bracket and fix with the nut/wing-nut provided.
3. Center the illuminator and firmly tighten down the wire assembly to hold the illuminator to the gauge.
4. Connect electrical power source to the illuminator.
9 PACKAGING, STORAGE AND TRANSPORTATION
9.1 Packaging
The LED illuminator contains fragile components and must be handled with care. These units must be packed to prevent damage during transportation. If damage to the glass should occur during shipment contact the factory.
9.2 Storage
The LED illuminator can be stored outside. These units are not affected by temperature or humidity.
9.3 Transportation
Since the LED illuminator contains fragile parts, care should be taken to ensure that the unit arrives undamaged. After unpacking unit, it should be inspected and any damaged parts should be replaced before assembly and installation.
10 DISPOSAL AT END OF USEFUL LIFE
Penberthy illuminator’s metal and polymers should be recycled whenever possible. Refer to order and Penberthy’s material specification sheets for materials of construction.
11 WARRANTY
See sales order acknowledgements for terms and conditions of sale.
12 TELEPHONE ASSISTANCE
If you are having difficulty with your illuminator, notify your local Penberthy distributor. You may also contact the factory direct at (281) 274-4400 and ask for an applications engineer. So that we may assist you more effectively, please have as much of the following information as possible when you call: ∙ Model # ∙ Name of the company from whom you
purchased your illuminator ∙ Invoice # and date ∙ Operating temperatures ∙ A brief description of the problem ∙ Troubleshooting procedures that failed
If attempts to solve your problem fail, you may be requested to return your illuminator to the factory for intensive testing. You must obtain a Return Authorization (RA) number from Penberthy prior to returning anything. Failure to do so will result in the unit being returned to you, without being tested, freight collect. To obtain a R.A. number, the following information (in addition to that above) is needed: ∙ Reason for return ∙ Person to contact at your company ∙ 'Ship-to' address
There is a minimum charge for evaluation of non-warranty units. You will be contacted before any repairs are initiated should the cost exceed the minimum charge. If you return a unit under warranty, but is not defective, the minimum charge will apply.
7
Page 8
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
13 TRANSPARENT GAUGE
FIGURE 1A LED ILLUMINATOR EXPLODED VIEW
Plate bracket
Slider bracket
LED illuminator body
SAS wire
FIGURE 1B LED ILLUMINATOR ISO VIEW
Screw ¼-20
Power supply
Cordset
FIGURE 1C LED ILLUMINATOR TOP VIEW
8
Page 9
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
14 REFLEX GAUGE
FIGURE 2A LED ILLUMINATOR EXPLODED VIEW
Reflex mounting bracket
Slider bracket
LED illuminator body
FIGURE 2B LED ILLUMINATOR ISO VIEW
Screw ¼-20
Power supply
FIGURE 2C LED ILLUMINATOR TOP VIEW
Cordset
9
Page 10
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
15 TSL/TSM GAUGE
FIGURE 3A LED ILLUMINATOR EXPLODED VIEW
TSL/TSM mounting bracket
Slider bracket
LED illuminator body
FIGURE 3B LED ILLUMINATOR ISO VIEW
Power supply Screw ¼-20
Plate bracket
SAS wire
FIGURE 3C LED ILLUMINATOR TSL TOP VIEW
FIGURE 3D LED ILLUMINATOR TSM TOP VIEW
Cordset
10
Page 11
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 4A WIRING INSTALLATION - GENERAL LOCATIONS
AC input connector (Terminal Block 1)
AC input voltage selector switch 115 or 230 V
AC input ¾" NPT or M20
Fuse (0216.100MXP, from Little Fuse)
Power supply
Plug
DC output connector
Output power indicator
Instrument housing
11
Page 12
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 4B WIRING INSTALLATION - DIVISION LOCATIONS
AC input ¾" NPT
Fuse (0216.100MXP from Little Fuse
AC input connector (Terminal Block 1)
AC input voltage selector switch 115 or 230 V
Output power indicator
Explosion proof instrument housing
IS ground quick connect tab
Power supply
Plug
DC output connector
CSA/UL explosion proof seal
12
Page 13
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 4C WIRING INSTALLATION - ATEX/IECEX LOCATIONS
AC input M20
Fuse (0216.100MXP, from Little Fuse
AC input connector (Terminal Block 1)
AC input voltage selector switch 115 or 230 V
Shield bracket
Power supply
Output power indicator
Explosion proof instrument housing
IS ground quick connect tab
Plug
ATEX/IECEx explosion proof seal
DC output connector
13
Page 14
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 5A CONTROL DRAWING FOR DIVISION LOCATIONS
HAZARDOUS AREA CLASS I DIV 1 GROUPS B, C, D T4
FLAME PROOF MOUNTING
Explosion
proof
enclosure
power supply
Integral seal-off
NON-HAZARDOUS AREA
HAZARDOUS AREA CLASS I DIV 1 GROUPS A, B, C, D T4
FLAME PROOF MOUNTING
I.S. LED
illuminator
NON-HAZARDOUS AREA
Explosion
proof
enclosure
power supply
FIELD
WIRING
I.S. LED
illuminator
INTRINSIC SAFETY MOUNTING
LED
illuminator
C
LEADS
L
LEADS
Intrinsic safety ground must gave R < 1Ω
ENCLOSURE
V
out
I.S. SIGNAL
A flame path seal -off shall be installed within 18 in. of enclosure
Intrinsic
safety
barrier
circuit
Nominal voltage
Power supply
CONTROL DRAWING
OR
INTRINSIC SAFETY MOUNTING
LED
illuminator
Intrinsic safety ground must gave R < 1Ω
MOUNT OPTION 1 MOUNT OPTION 2
NOTES: Equipment supplying intrinsic system must not produce more than 125/250 V
Loop wire distance not to exceed 200 ft. using C Consult Emerson if longer distance needed. Barrier ground shall be connected to a grounding electrode by redundant, 12 AWG or larger insulated conductors. The installation must be in accordance with Canadian Electric Code CSA C22.1 Part 1, Appendix F. The installation must be in accordance with National Electric Code, NFPA 70, Articles 504 and 505, and ANSI/ISA-RP12.06.01.
= 60 pF/ft. L
Leads
Leads
= μH/ft.
.
rms
FIGURE 5B CONTROL DRAWING ATEX/IECEX
HAZARDOUS AREA Zone 1
FLAME PROOF MOUNTING
Explosion
proof
enclosure
power supply
Integral seal-off
I.S. LED
Illuminator
INTRINSIC SAFETY MOUNTING
LED
illuminator
ENCLOSURE
Intrinsic
V
out
barrier
I.S.
circuit
SIGNAL
A suitably certified flame path seal-off shall be installed directly to threaded entry of enclosure
safety
NON-HAZARDOUS AREA
Nominal voltage
Power supply
CONTROL DRAWING
OR
HAZARDOUS AREA Zone 0
FLAME PROOF MOUNTING
I.S. LED
illuminator
INTRINSIC SAFETY MOUNTING
LED
illuminator
Integral seal-off
ENCLOSURE
Intrinsic
V
out
safety
barrier
I.S.
circuit
SIGNAL
C
LEADS
L
LEADS
Nominal voltage
Power supply
NON-HAZARDOUS AREA
Explosion
proof
enclosure
power supply
Integral seal-off
ENCLOSURE
Intrinsic
V
safety
out
barrier
I.S.
circuit
SIGNAL
FIELD
WIRING
Nominal voltage
Power supply
C
LEADS
L
C
LEADS
L
LEADS
Intrinsic safety ground must gave R < 1Ω
LEADS
Intrinsic safety ground must gave R < 1Ω
MOUNT OPTION 1 MOUNT OPTION 2
NOTES: Equipment supplying intrinsic system must not produce more than 125/250 V
Loop wire distance not to exceed 200 ft. using C Consult Emerson if longer distance needed. The installation must be in accordance with National Electric Code, NFPA 70, Articles 504 and 505, and ANSI/ISA-RP12.06.01.
= 60 pF/ft. L
Leads
Leads
= μH/ft.
.
rms
14
Page 15
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 6A NAMEPLATE - GENERAL LOCATIONS
STAFFORD, TX. USA 77477
FIGURE 6B NAMEPLATE - DIVISION LOCATIONS
STAFFORD, TX. USA 77477
15
Page 16
PENBERTHY LED ILLUMINATOR FOR FLAT GLASS GAUGES, HAZARDOUS LOCATION
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FIGURE 6C NAMEPLATE - ATEX/IECEX
STAFFORD, TX. USA 77477
2813
FIGURE 6D NAMEPLATE - LED ILLUMINATOR BODY - ATEX/IECEX
STAFFORD, TX. USA 77477
2813
VCIOM-04486 © 2017, 2022 Emerson Electric Co. All rights reserved 07/22. Penberthy is a mark owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective owners.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are governed by our terms and conditions, which are available upon request. We reserve the right to modify or improve the designs or specifications of such products at any time without notice.
Emerson Electric Co. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and maintenance of any Emerson Electric Co. product remains solely with the purchaser.
Emerson.com
16
Loading...
