Flexis™ Microcontroller Series
DEMOJM
Cost-effective USB development
• Quick Start Guide
• Lab Tutorials
• CodeWarrior® Manual
• Getting Started DVD
DEMOJM—Quick Start Guide
Introduction
DEMOJM is a cost-effective kit targeting quick
microcontroller evaluation. The kit includes a
DEMOJM base board, a red MCF51JM128
daughter card and a green MC9S08JM60
daughter card. The included kit can first be used
to demonstrate the features of the MC9S08JM60
devices, starting with an on-chip USB device
controller and transceiver. Then, move to
MCF51JM128 with an on-chip USB On-The-Go
(OTG) dual-role controller. The USB features are
supported in hardware through a dedicated USB
mini-AB connector and in software through the
included complimentary USB-LITE stack
by CMX.
This Quick Start Guide includes two sections
and is designed to get you ready to develop your
next USB application using the MC9S08JM60
and MCF51JM128 within minutes.
DEMOJM—Quick Start Guide
Quick Start Guide for MC9S08JM60
Step-by-step instructions
Please take a look at the DEMO9S08JM60 Labs document (DEMO9S08JM60LAB)
included in the “Training” section of the DVD to learn more about the key USB benefits
that JM60 gives your application.
STEP
1
Install CodeWarrior®
for Microcontrollers
and JM60 Service Pack
CodeWarrior is a powerful tool designed
to help you maximize your time to market.
The CodeWarrior Service Pack will install
the appropriate support files for the
MC9S08JM60 to the existing CodeWarrior
installation. CodeWarrior installation is a
one-time required step before connecting
the board to your computer.
1. Insert provided DVD into computer and a menu
will appear.
2. Click on appropriate board and “Install
CodeWarrior.”
3. Follow the on-screen instructions until
installation is complete.
4. Return to DVD menu and click on “Install JM60
Service Pack.”
5. Follow the on-screen instructions until
installation is complete.
STEP
2
Install USB-LITE Stack by CMX
for MC9S08JM60
USB-LITE stack by CMX for MC9S08JM60
is a complimentary stack with the
appropriate JM60 USB device mode
low-level drivers and top-level HID class
and CDC class examples. To exercise
the various USB examples packaged
with the stack follow the step-by-step
DEMO9S08JM60 Labs document
(DEMO9S08JM60LAB) included in the
“Training” section of the DVD. Stack
installation is a one-time required step
before developing with this software.
1. Insert provided DVD into computer and a menu
will appear.
2. Click on “8-bit Flexis JM60” under “Install
Complimentary Freescale USB-LITE by CMX”.
This will launch the stack installer.
3. Follow on-screen instructions until installation
is complete.
Once installation is complete, take advantage
of several CodeWarrior tutorials that will
walk you through various development
tool features, such as “C Programming,”
“Assembly Programming,” “Using
Processor Expert™” and more. Simply open
CodeWarrior via the “Programs>Freescale
CodeWarrior>CW for Microcontroller
V6.x>CodeWarrior IDE.exe” path. Click “Run
Getting Started Tutorial” from the startup
dialog, select a tutorial and follow the onscreen instructions.
STEP
3
Install PEMICRO Embedded
Multilink Toolkit
PEMICRO Embedded Multilink Toolkit
includes graphical utilities that run
on your computer and help speed up
your development. These utilities take
development beyond the hardware and
interact with the target microcontroller over
the same USB multilink reference design on
the board that allows you to debug using
CodeWarrior. Best of all, you can debug
your microcontroller in CodeWarrior while
simultaneously using one of the following
utilities: Logic Analyzer, Serial Grapher,
Terminal Window and Accelerometer Demo
Grapher. PEMICRO Embedded Multilink
Toolkit install is a one-time required step.
1. Insert provided DVD into computer and a menu
will appear.
2. Click on “Install PEMICRO Toolkit.” This will
launch the toolkit installer.
3. Follow the on-screen instructions to complete
installation.
STEP
4
Connect Board to Computer
USB driver installation is a one-time
required step, to be completed after
CodeWarrior installation.
1. Remove DEMOJM base board and green
MC9S08JM60 daughter from anti-static bags.
2. Plug in the green daughter card to DEMOJM
base board aligning pin 1 arrows.
3. Connect provided A to B gray USB cable from
a free USB port on your computer to the USB
connector on the board.
4. Operating system will recognize your board
as new hardware and will prompt you to
install the USB drivers. Choose recommended
option to install the software automatically.
USB drivers for your board were pre-loaded in
CodeWarrior installation.
5. Follow on-screen instructions until all USB
driver installations are complete. The green
USB LED on-board should illuminate.
For more information on PEMICRO
Embedded Multilink Toolkit read the
DEMOJM User Manual (DEMOJMUM.pdf)
included in the “Documentation” section of
DVD. For new and upgraded utilities to the
PEMICRO Embedded Multilink Toolkit, visit
www.pemicro.com.
DEMOJM—Quick Start Guide
STEP
5
Test Board by Running
Quick Start Application
Now that you have successfully completed
the software and hardware setup, test your
board by running the Quick Start Application
pre-loaded in the microcontroller’s on-chip
flash memory.
The programmed application is the HID class
software included in the complimentary
USB-LITE stack by CMX for MC9S08JM60.
The HID class software includes several
examples (mouse, keyboard, etc.) with the
default example, turning your board and
making it a simple HID mouse by exercising
the JM60 on-chip USB 2.0 full-speed device
controller and transceiver. The example takes
control of your computer’s mouse cursor and
moves it continuously in a back and forth
motion following USB enumeration.
1. Turn the SYSTEM POWER switch to the “on”
position. The red POWER LED will illuminate and
the application will start.
3. Your computer will recognize the MC9S08JM60
as an HID mouse device and begin installation
(no user interaction needed). When hardware
installation is complete, the MC9S08JM60 will
control your mouse cursor by moving it back
and forth.
4. Now that your board is functional, try out the
labs discussed in the DEMO9S08JM60 Labs
document (DEMO9S08JM60LAB) included in
the “Training” section of the DVD. These labs
will guide you step by step through the all the
HID and CDC class examples included in the
complimentary USB-LITE stack by CMX for
MC9S08JM60.
2. Connect provided A to mini-B black USB cable
from a free USB port on your computer to the
mini-AB USB connector on the board.
Quick Start Guide for MCF51JM128
Step-by-step instructions
Please take a look at the DEMO51JM128 Labs document (DEMO51JM128LAB) included
in the “Training” section of the DVD to learn more about the key USB benefits that JM128
gives your application.
STEP
1
Install CodeWarrior for
Microcontrollers and JM128
Service Pack
CodeWarrior is a powerful tool designed
to help you maximize your time to market.
The CodeWarrior Service Pack will install
the appropriate support files for the
MCF51JM128 to the existing CodeWarrior
installation. CodeWarrior installation is a
one-time required step before connecting
the board to your computer.
1. Insert provided DVD into computer and a menu
will appear.
2. Click on appropriate board and “Install
CodeWarrior.”
3. Follow the on-screen instructions until
installation is complete.
4. Return to DVD menu and click on “Install
JM128 Service Pack.”
5. Follow the on-screen instructions until
installation is complete.
STEP
2
Install USB-LITE Stack by CMX
for MCF51JM128
USB-LITE stack by CMX for MCF51JM128
is a complimentary stack with the
appropriate JM128 USB OTG dual-mode
low-level drivers and top-level HID class
and CDC class examples. To exercise
the various USB examples packaged
with the
DEMO51JM128
(DEMO51JM128LAB) included in the
“Training” section of the DVD. Stack
installation is a one-time required step
before developing with this software.
1. Insert provided DVD into computer and a menu
2. Click on “32-bit Flexis JM” under “Install
3. Follow on-screen instructions until installation
stack follow the step-by-step
Labs document
will appear.
Complimentary Freescale USB-LITE by CMX.”
This will launch the stack installer.
is complete.
Once installation is complete, take
advantage of several CodeWarrior
tutorials that will walk you through
various development tool features,
such as “C Programming,” “Assembly
Programming,” “Using Processor Expert”
and more. Simply open CodeWarrior via the
“Programs>Freescale CodeWarrior>CW for
Microcontroller V6.x>CodeWarrior IDE.exe”
path. Click “Run Getting Started Tutorial”
from the startup dialog, select a tutorial and
follow the on-screen instructions.
DEMOJM—Quick Start Guide
STEP
3
Install PEMICRO Embedded
Multilink Toolkit
PEMICRO Embedded Multilink Toolkit
includes graphical utilities that run
on your computer and help speed up
your development. These utilities take
development beyond the hardware and
interact with the target microcontroller over
the same USB multilink reference design on
the board that allows you to debug using
CodeWarrior. Best of all, you can debug
your microcontroller in CodeWarrior while
simultaneously using one of the following
utilities: Logic Analyzer, Serial Grapher,
Terminal Window and Accelerometer Demo
Grapher. PEMICRO Embedded Multilink
Toolkit install is a one-time required step.
1. Insert provided DVD into computer and a menu
will appear.
2. Click on “Install PEMICRO Toolkit.” This will
launch the toolkit installer.
3. Follow the on-screen instructions to
complete installation.
STEP
4
Connect Board to Computer
USB driver installation is a one-time
required step, to be completed after
CodeWarrior installation.
1. Remove DEMOJM base board and the red
MCF51JM128 daughter card from
anti-static bags.
2. Plug in the red daughter card to DEMOJM base
board aligning pin 1 arrows.
3. Connect provided A to B gray USB cable from
a free USB port on your computer to the USB
connector on the board.
4. Operating system will recognize your board
as new hardware and will prompt you to
install the USB drivers. Choose recommended
option to install the software automatically.
USB drivers for your board were pre-loaded in
CodeWarrior installation.
5. Follow on-screen instructions until all USB
driver installations are complete. The green
USB LED on-board should illuminate.
For more information on PEMICRO Embedded
Multilink Toolkit read the DEMOJM User
Manual (DEMOJMUM.pdf) included in the
“Documentation” section of DVD. For new and
upgraded utilities to PEMICRO Embedded
Multilink Toolkit, visit www.pemicro.com.
STEP
5
Test Board by Running Quick
Start Application
Now that you have successfully
completed the software and hardware
setup, test your board by running the
Quick Start Application pre-loaded in the
microcontroller’s on-chip flash memory.
The programmed application is the
HID class software included in the
complimentary USB-LITE stack by CMX
for MCF51JM128. The HID class software
includes several examples (mouse,
keyboard, etc.) with the default example
turning your board and making it a simple
HID mouse by exercising the JM128
on-chip USB 2.0 OTG controller.
The example takes control of your
computer’s mouse cursor and moves
it continuously in a back and forth
motion following USB enumeration.
1. Turn the SYSTEM POWER switch to the “on”
position. The red POWER LED will illuminate
and application will start.
2. Connect provided A to mini-B black USB cable
from a free USB port on your computer to the
mini-AB USB connector on the board.
3. Your computer will recognize the MCF51JM128
as an HID mouse device and begin installation
(no user interaction needed). When hardware
installation is complete, the MCF51JM128 will
control your mouse cursor by moving it back
and forth.
4. Now that your board is functional, try out the
labs discussed in the DEMO51JM128 Labs
document (DEMO51JM128LAB) included in
the “Training” section of the DVD. These labs
will guide you step by step through the all the
HID (device & host), CDC, and Mass Storage
examples included in the complimentary
USB-LITE stack by CMX for MCF51JM128.
For more information on PEMICRO Embedded
Multilink Toolkit read the DEMOJM User
Manual (DEMOJMUM.pdf) included in the
“Documentation” section of DVD. For new and
upgraded utilities to PEMICRO Embedded
Multilink Toolkit, visit www.pemicro.com.
DEMOJM—Quick Start Guide
Accelerometer
Demo Grapher
This utility will graph data from the
virtual serial port on the DEMOJM
board. The state of the on-board threeaxis accelerometer can be sampled by
the microcontroller’s analog-to-digital
converter channels and results can be
graphed by transmitting over the virtual
serial port using the microcontroller’s
serial communication interface.
Virtual Serial Port
The DEMOJM board has the capability
of implementing a virtual serial port
on the PC. This allows the PC to send
and receive serial data via the serial
communication pins of P&E’s Embedded
Multilink design. Using jumper J4, this
virtual serial port may be configured
to connect to the SCI port on the
JM60 or JM128 processor.
Freescale USB-LITE
Stack by CMX
Freescale is providing a comprehensive
USB software solution through a
complimentary USB stack. The
Freescale USB-LITE stack by CMX
enables USB device/host/OTG modes
of operation. The USB stack supports
several HID (device & host), CDC,
and Mass Storage projects. The
complimentary stack also interfaces
with CodeWarrior Development Studio,
providing a productive, comprehensive
development environment for designing
embedded applications.
DEMOJM—Quick Start Guide
Get to Know the DEMOJM Board
Switch
External
Power
Connector
Pemicro
Embedded
Multilink USB
Connector
CAN port
Mini-AB USB Connector
Figure 1. DEMOJM baseboard with MC9S08JM60 daughter card
LEDs
Push Buttons
Speaker
Potentiometer
MC9S08JM60
Daughter Card
Accelerometer
DEMOJM—Quick Start Guide
Learn More:
Freescale and the Freescale logo are trademarks or
registered trademarks of Freescale Semiconductor,
Inc. in the U.S. and other countries. All other product
or service names are the property of their respective
owners. © Freescale Semiconductor, Inc. 2008
Agile Number: 926-21876 / REV A
Document Number: DEMOJMQSG / REV 0
For more information about
the JM family, please visit
www.freescale.com/flexis.
Loading...
