INSTALLATION/OPERATION MANUAL
WLV500 SERIES WIRELESS VIDEO
TRANSMISSION SYSTEMS
®
1.0 SCOPE
The information contained within this manual covers
the installation and operation of the PELCO WLV500
Series wireless control link system.
Installation should be in accordance with FCC regulations and all applicable local and national electric codes,
utilizing approved materials only.
Please thoroughly familiarize yourself with the information in this manual prior to installation and operation.
2.0 DESCRIPTION
PELCO's WLV500 Series wireless control link system
is designed to provide wireless remote control of camera positioning and zoom functions. The system is
compatible with coaxitron remote control systems such
as a PELCO Coaxitron System 2000 and operates in
conjunction with the WLV1000 wireless video system.
2.2 MODELS
WLV500-1 Channel 1
WLV500-2 Channel 2
WLV500-3 Channel 3
WLV500-4 Channel 4
Transmitter (WLV500TX)
Receiver (WLV500RX)
Power Supplies (TRFDP15VDC-500M)
Mounting Hardware (WLVHRDWRKIT)
2.3 ANTENNA OPTIONS
WLVAN-2R Medium Gain CP Patch (RH), 6 dB
WLVAN-2L Medium Gain CP Patch (LH), 6 dB
WLVAN-3R High Gain CP Panel (RH), 13 dB
WLVAN-3L High Gain CP Panel (LH), 13 dB
3.0 SYSTEM SPECIFICATIONS
Data
2.1 WLV500 SYSTEM COMPONENTS
1 WLV500TX Transmitter
1 WLV500RX Receiver
2 15 volt AC/DC converters
1 Set mounting hardware kit
Pelco Manual C901M – 1/94 1
Format: NRZ
Pulse Width: 1V p-p
Duty Cycle: 50%
Levels
(Video Compatible): 0.0 to 0.7 V
Impedance 75 ohms
Connectors BNC
RF
Case Finish
Transmitter
Radiated Power: FCC Part 15 (15.249)
Transmit Antenna: Attached circular polarized
patch
Receive Connector: TNC
Receive Input
Impedance: 50 ohms
Frequency
Operating Range: 2400 to 2483 MHz
System Frequency
Options: (Factory Set)
WLV500KT-1 2401 MHz
WLV500KT-2 2428 MHz
WLV500KT-3 2455 MHz
WLV500KT-4 2482 MHz
Frequency Stability: ±0.005%
Modulation: Wideband FM
Operating
Distance: 1,000 feet maximum line-of-
sight
(Consult factory for extended
operating range)
Power (Each Unit)
Input Voltage: 12 to 16 VDC
Input Current: <350 mA
Terminal/Barrier Strip
Reverse Polarity Protection
Mechanical
Weight (Each Unit): <16 oz.
Cover: Black paint
Base: Alodine aluminum
Environmental
Operating
Temperature: -20° to 65° C
Storage
Temperature: -50° to 85° C
Humidity
(Non-condensing): 90%
4.0 INSTALLATION
4.1 VIDEO AND POWER CONNECTIONS
The following instructions are for use with the
PELCO Coaxitron System 2000.
1. Refer to Figure 1. The output port labeled
“INPUT FROM RECEIVER” of the Coaxitron
System 2000 transmitter should be connected
to the BNC connector indicated on the label as
“DATA IN/VIDEO OUT” of the WLV500TX
control link transmitter. The video signal that
originated from the WLV1000RX wireless
video receiver (or directly from a camera or
other video source) should be connected to the
BNC connector labeled “VIDEO IN” of the
WLV500TX. The port labeled “OUTPUT TO
MONITOR” of the Coaxitron System 2000
transmitter should be connected to a video
monitor.
2. The port labeled “OUT” of the Coaxitron Sys-
tem 2000 receiver should be connected to the
BNC connector labeled “DATA OUT” of the
WLV500RX control link receiver.
Dimensions: (D x W x H Inches)
Transmitter (w/Antenna)
5.00 x 3.50 x 1.80
Receiver (w/o Antenna)
5.60 x 3.50 x 1.30
2 Pelco Manual C901M - 1/94
3. The wall mounted power supplies (15 VDC)
included in the system should be connected to
the power strips of each unit labeled “11-16
V”. The striped lead with a red connector
should be connected to the positive “+” terminal and the ground lead with the black connector should be connected to the negative “–”
terminal. The power supplies should then be
plugged into a 120 volt (AC) power outlet.
