VideoXpert® Storage Server R-Series
Product Specification, video management solutions
VideoXpert® Storage Server R-Series
Enterprise 2U8-Bay Rackmount
Product Features
l
Up to 160 TB of Raw Storage
l
Intel® Xeon® Silver Scalable Processor
l
Windows Server 2019 Operating System
l
iDRAC features include:
–
Remote Management
–
Disaster Recovery
–
Critical Resource Monitoring
l
SSD 24/7 Duty Cycle Drives
l
Redundant Power
l
RAID 6
l
5-Year, On-site, NBD, Keep Your Hard Drive Warranty
Enterprise, High Performance, and Video Processing
Benefit from scalable storage performance and video processing with this Enterprise server. This 2U
platform brings you scalability and performance to adapt to a variety of the most demanding and processintensive video surveillance applications.
Up to 160 TB of raw storage allows for long-term video storage and archiving. Paired with the latest
Intel® Xeon® Scalable processor, this provides high density storage with Enterprise throughput for the
most demanding applications.
Better performance is provided with dual SSDs for accelerated boot and application load times. Remote
management, provided by iDRAC, allows for constant system status and critical resource monitoring.
RAID 6 storage, in addition to redundant 800 W power supplies, provide system reliability and high
availability, while a five-year, on-site, next business day, Keep Your Hard Drive warranty ensures peace
of mind.
Technical Specifications
System
Item Description
Processors Intel® Xeon® Silver 4310 Scalable Processor (12 Cores, 24 Threads, 2.10
GHz)
Maximum storage Up to
Operating system Windows Server 2019
160
TB
Memory 32 GB (4x 8 GB)
C5061S-C | 01/23 1
VideoXpert® Storage Server R-Series
Product Specification, video management solutions
Item Description
RAID OS RAID 1; Data RAID 6
Networking (2) 1 GbE RJ45 Ports; (2) 10 GbE SFP+ Ports; (1) Dedicated iDRAC Port
USB(s) Rear (1) USB 3.0, (1) USB 2.0, Front (1) USB 2.0
Video outputs (1) VGA
Warranty 5-Year, On-site, NBD, Keep Your Hard Drive Warranty
Mechanical
Item Description
Form factor 2U Rackmount
Hard drive bays (8) 3.5 in
Power supply(s) (2)
Power information Input Power
SATA
Hot Swappable Bays & (2) M.2 SSD Slots
800 W (100-240 VAC)
3000 BTU/h Maximum
80 Plus Platinum
Operating temperature (Min) 50°F - (Max) 95° F [(Min) 10°C - (Max) 35°C]
Operating humidity 8% relative humidity with 10°F (-12°C) minimum dew point, to 80% relative
humidity with 70°F (21°C) maximum dew point
Dimensions (WxDxH) 17.1 in (434 mm) x
26.57 in (675 mm)
x 3.4 in (86.8 mm), without rack ears
and bezel
Maximum weight
54.67 lbs. (24.8 kg)
Throughput
Model Recording Throughput Playback Throughput
VXS2B-R:1 GbE Up to 700 Mbps
VXS2B-R:10 GbE Up to 1000 Mbps Up to 175 Mbps
1
Requires a network switch line rate capable of performing continuously at 700 Mbps while connected to
1 GbE.
1
Up to 175 Mbps
C5061S-C | 01/23 2
VideoXpert® Storage Server R-Series
Product Specification, video management solutions
Part Numbers (SKUs)
SKU Description
VXS2B-R0-N R-Series VxStorage, Windows Server 2019, 0 TB (no storage drives), 5-year
warranty
VXS2B-R96-N12 R-Series VxStorage, Windows Server 2019, 32 GB RAM, Intel Xeon Silver
(x1), 1 GbE NIC (x2), 10GbE SFP+ (x2), iDRAC, redundant power, RAID 6,
96 TB raw, 65.46 TB effective, 5-year warranty
VXS2B-R160-N20 R-Series VxStorage, Windows Server 2019, 32 GB RAM, Intel Xeon Silver
(x1), 1 GbE NIC (x2), 10 GbE SFP+ (x2), iDRAC, redundant power, RAID 6,
160 TB raw, 109.08 TB effective, 5-year warranty
Optional Accessories
SKU Description
HDDKIT-20TB-R550 20 TB SATA storage drive with carrier for VXS R-series recorders
HDDKIT-12TB-R550 12 TB SATA storage drive with carrier for VXS R-series and Power 3 series
recorders
C5061S-C | 01/23 3
VideoXpert® Storage Server R-Series
Product Specification, video management solutions
Pelco, Inc.
625 W. Alluvial Ave., Fresno, California 93711 United States
(800) 289-9100 Tel
(800) 289-9150 Fax
+1 (559) 292-1981 International Tel
+1 (559) 348-1120 International Fax
www.pelco.com
Pelco, the Pelco logo, and other trademarks associated with Pelco products referred to in this publication are trademarks of Pelco,
Inc. or its affiliates. ONVIF and the ONVIF logo are trademarks of ONVIF Inc. All other product names and services are the property of
their respective companies. Product specifications and availability are subject to change without notice.
© Copyright 2023, Pelco, Inc. All rights reserved.
