VideoXpert Professional v 3.1
Product Specification video management solutions
VideoXpert Professional v 3.1
Scalable Video Management and Surveillance Software
Product Features
l “VideoXpert in a box” functionality for small to
mid-sized sites
l Simple setup / IT-Friendly — designed for
Unicast or multicast environments using
Microsoft® Windows® for easy configuration
and maintenance
l Available in different hardware configurations to
support the needs of different sites
l Supports monitor walls, including cell layouts and cameras
l Up to 450 Mbps throughput per recorder
l Supports attached storage (NAS) to extend video retention
l Includes VxToolbox for simple configuration of one or more servers
l Includes pre-defined roles for easy user creation, and also supports granular editing of user
permissions
l Motion Pixel Search for server side motion detection and quick retrieval of events
l 4k/H.264 and H.265 support for live and playback modes for cameras that support streaming
through ONVIF, and the ability to export recorded segments from H.265 cameras
l HTTPS support for Pelco cameras
l VxPortal web based client allows viewing and exporting video without installing any software
l Reports can be run from VxToolbox
l Check on VMS and camera health using SNMP (available as a free, separate download)
l Legacy “device tree” view available in VxOpsCenter
l Extensible through plugins including mapping, video information overlays, and license plate
recognition
l Supports aggregation through VideoXpert Enterprise system with aggregation
l Supports ONVIF S-compliant cameras and devices
l Investigation mode enables operators to synchronize video playback and export investigative
playlists covering scenes of interest
l Monitor multiple VxPro sites with a single client
l A la carte design allows you to order software and/or hardware
l Supports shared displays so operators can send video to surveillance personnel who need it most
l Supports IPv4 and IPv6 cameras
l Supports DNShostnames for ONVIF-compliant cameras and Pelco cameras
C4050S-F | 12/18 1
VideoXpert Professional v 3.1
Product Specification video management solutions
l Enables and supports Risk Management Framework (RMF)
l Provides seamless transition to VideoXpert
l Server models support Dell iDRAC and OpenManage tools
VideoXpert Professional is a video management system (VMS) in a single box, designed for easy setup
and robust monitoring in small or moderately sized applications. Designed for Windows platforms, VxPro is
easy to install, quick to setup, and provides an intuitive interface that helps operators use video captured by
the system.
VxPro is available in tailor-made hardware solutions or in software distributions to support your existing
VMS infrastructure, VxPro provides options to support the throughput you need, and different amounts of
storage in RAID 6, RAID 5, or JBOD arrangements to fit your needs for retention, redundancy, and fault
tolerance. Software licenses operate in terms of channels, so you don't overpay for the solution you need.
The system supports unicast and multicast transmission modes, easily adapting to your network scheme.
Server models also include Dell’s iDRAC (integrated Dell Remote Access Controller) platform and support
for Dell’s OpenManage tools, allowing administrators to remotely configure and support VxPro servers,
reducing the need for physical access to the server. Using the iDRAC controller, you can monitor hardware
and receive email alerts via SNMP.
TM
Enterprise
VxPro includes VxToolbox, an easy-to-use Windows application enabling users to quickly and easily
configure an entire network of servers and cameras locally or remotely. VxPro has pre-defined roles,
designed around standard surveillance operations, making user creation and assignments quick and easy.
The included VxOpsCenter client software provides an easy to use interface, so you can use VideoXpert
with little to no training. You can operate VxOpsCenter clients in multi-system access mode, allowing one
workstation to access multiple servers, scaling your surveillance solution. VxOpsCenter also supports
modular plugins, providing integrated functionality from external systems, including informational overlays,
license plate recognition (LPR), analytics, and a built-in mapping application.
Built around open standards, VideoXpert includes a complete application programing interface (API),
software development kit (SDK), and dedicated technical support, allowing other systems' manufacturers
to develop interfaces leveraging VideoXpert's capabilities.
Technical Specifications
Hardware
Item Power Server Flex Server Eco Server Workstation
Form Factor Rack (2RU) Tower
Processor Intel® Xeon®
Silver 4110
Memory 16 GB DDR4
Operating System Microsoft® Windows®10 IoTEnterprise 64-bit (LTSB)
Intel® Xeon®
E3-1230 v6
Intel® Xeon® E31230 v5
Intel® CoreTMi76700
OSDrive 2x SSD 120 GB
SSD240 GB m.2 256 GB
(RAID 1)
Storage
1
Max
C4050S-F | 12/18 2
96 TB (7200 RPM SATA) 12TB (7200RPM) N/A
VideoXpert Professional v 3.1
Product Specification video management solutions
Item Power Server Flex Server Eco Server Workstation
RAIDLevel
Optical Drive N/A DVD±RW N/A
Dell iDRAC Controller iDRAC9 Basic Included N/A
USBPorts
USB 2.0 1x front 1x front, 4x rear 2x front, 2x rear
USB 3.0 2x rear 1x front, 2x rear 1x front, 4x rear
USB 3.1 Type-C N/A 1x front
1
Maximum storaged based on JBODconfiguration
2
RAIDlevel is user configurable
2
6/5/JBOD 5/JBOD N/A
Power Server Flex Server
EcoServer Workstation
C4050S-F | 12/18 3
VideoXpert Professional v 3.1
Product Specification video management solutions
Minimum System Requirements
Item
Power
Server
Flex
Server EcoServer Workstation
1
Processor Intel® CoreTMi5 64-bit CPU
Memory 16 GB
Operating
Microsoft® Windows® 7 64-bit, Windows® 10 64-bit, or Windows® Server 2012 or 2016
System
Browser Current version of Google Chrome, Mozilla Firefox, and Microsoft Edge
1
Software-only distributions tested without antivirus software installed.
2
Although server OS is supported, VxOpsCenter is not supported in the server OS.
Video
Item Power Server
Video Outputs 4x Mini DisplayPort
1.4
Video system NVIDIA Quadro P600
(2 GB memory)
Flex
Server
DisplayPort, DVI 2x DisplayPort, HDMI
NVIDIA Quadro K620 (2
GB memory)
Eco
Server Workstation
3
Intel HD Graphics 530
(shared memory)
Maximum Video Resolution per output type
HDMI 1.4 N/A 4096 x 2304 at 24 Hz
DP N/A 4096 x 2304 at 60 Hz
DP 1.2 direct connect N/A 3840 x 2160 at 60 Hz N/A
mDP 1.4 direct connect HDR 5120 x 2880 at
N/A
60 Hz (30-bit color)
DVI-D DL direct connect 3840 x 2160 at 30 Hz
2560 x 1600 at 60 Hz N/A
(HDMI via included
adapter)
DVI-I SL via adapter 2560 x 1600 at 60 Hz
1920 x 1200 at 60 Hz N/A
or 1920 x 1200 at 60
Hz
Video Standards
NTSC N/A 60 Hz capable
PAL N/A 75 Hz capable
C4050S-F | 12/18 4
VideoXpert Professional v 3.1
Product Specification video management solutions
Audio
Power
Item
Inputs N/A Microphone In, Line In Universal Audio Jack (front)
Outputs DisplayPort
Connector
Types
Server
Audio
mDPCable
(out)
Flex
Server Eco Server Workstation
Headphone/Front Out, Rear
Out, Center/Subwoofer,
DisplayPort Audio
3.5mm (In/Out), DP Cable
(Out)
Universal Audio Jack (front), Line Out
(rear), Internal Speaker, DisplayPort
Audio, HDMI Audio
3.5mm 4 pole (In/Out), 3.5mm 3 pole
(Out), DP cable (Out), HDMI Cable (Out)
Networking
Flex
Item Power Server
Gigabit Ethernet (1000Base-T) ports 2x dedicated iDRAC port 2x 1x
Recording Throughput Up to 450 Mbps Up to 200 Mbps N/A
IPversion IPv4 and IPv6
Server
Eco
Server Workstation
Power
Item Power Server Flex Server Eco Server Workstation
Input 100 to 240 VAC 50/60 Hz, autoranging 90-264 VAC, 47 Hz -
63 Hz, 3 A / 1.5 A
Supply Dual Hot Swappable
750 W (Platinum)
Note:
This system is also designed to be connected to IT power
systems with a phase-to-phase voltage not exceeding 230 V.
Consumption 2891 BTU/hr max 1357 BTU/hr max
Note:
Heat dissipation is calculated by using the power supply
wattage rating.
Internal 350 W
(Bronze)
(350 W power
supply)
Internal 290 W
(Bronze)
989 BTU/hr max (290
Wpower supply)
Internal 180W
614 BTU/hr max (180
Wpower supply)
Environmental
Item Power Server
Operating Temperature 10° to 50°C (32° to 95°F) with no direct sunlight on the
equipment
Note:
Maximum temperature is reduced by 1°C/300 m
(33.8°F/984.25 ft) above 950 m (3,117 ft)
Non-Operating
Temperature
C4050S-F | 12/18 5
–40° to 65°C (–40° to 149°F)
Flex Server
EcoServer Workstation
0° to 35°C
(32° to 95°F)
VideoXpert Professional v 3.1
Product Specification video management solutions
Item Power Server
Operating Relative
Humidity
Non-Operating
Relative Humidity
Flex Server
10% to 80% RHwith 29°C (84.2°F) max dew point 5% to 95% (non
5% to 95% RH with 33°C (91°F) maximum dew point.
Atmosphere must be non-condensing at all times.
EcoServer Workstation
condensing)
10% to 90%,
noncondensing
Operating Altitude Maximum of 3048 m (10,000 ft) –15.2 m to 3048 m (–50
to 10,000 ft)
Operating Vibration 0.26 Grms at 5 Hz to 350 Hz (operation orientations) 0.66 GRMS
Physical
Item Power Server Flex Server Eco Server Workstation
Dimensions
(D x W x H)
Rack Mounting 2 RU N/A
Unit Weight
1
For each server type, the unit weight varies by configuration.
68.2 x 43.4 x 8.68
cm (26.8 x 17.1 x
3.4 in) without rack
55.86 x 21.8 x 43.03
cm (22.77 x 8.58 x
17.04 in)
36 x 17.5 x 43.5 cm
(14.17 x 6.89 x
17.12 in)
29.0 x 29.2 x 9.26 cm
(11.4 x 11.5 x 3.6 in)
ears
1
29.68 kg (65.43 lb) 26.02 kg (57.32 lb) 11.1 kg (24.47 lb) 5.14 kg (11.42 lb)
Software Licenses, Servers, and Workstation Models
With VxPro, you only pay for the devices you want to use with your system. Each camera in a VxPro
environment consumes a “channel” license. Each channel license includes a 1 year SUP. VxPro includes
four trail licenses to quickly get started. If five or more channels are needed, you must purchase the first
four channels plus the additional license(s).
License Description
VXP-1C 1 camera license for VideoXpert Pro plus one year SUP
VXP-1C-3Y 1 camera license for VideoXpert Pro plus three year SUP
VXP-SUP-1Y Software upgrade subscription; entitles you to upgrades for one year. One per channel
is required.
VXP-SUP-3Y Software upgrade subscription; entitles you to upgrades for three years. One per
channel is required.
VXP-SUP-1D 1 Day Software Upgrade Plan, 1CH
C4050S-F | 12/18 6
VideoXpert Professional v 3.1
Product Specification video management solutions
Hardware Models
Model Range Raw Capacity Effective Capacity RAIDLevel Power Supply
VXP-P2-96-6-D Power 96 TB 72.70 TB RAID 6 Dual
VXP-P2-96-5-D Power 96 TB 79.97 TB RAID 5 Dual
VXP-P2-96-J-D Power 96 TB 87.24 TB JBOD Dual
VXP P2-72-6-D Power 72 TB 50.89 TB RAID 6 Dual
VXP-P2-72-5-D Power 72 TB 58.16 TB RAID 5 Dual
VXP-P2-72-J-D Power 72 TB 65.43 TB JBOD Dual
VXP-P2-48-6-D Power 48 TB 29.08 TB RAID 6 Dual
VXP-P2-48-5-D Power 48 TB 36.35 TB RAID 5 Dual
VXP-P2-48-J-D Power 48 TB 43.62 TB JBOD Dual
VXP-P2-24-5-D Power 24 TB 14.54 TB RAID 5 Dual
VXP-P2-24-J-D Power 24 TB 21.81 TB JBOD Dual
VXP-P2-0-X-D Power 0 TB N/A Unconfigured Dual
VXP-F-28-6-S Flex 28 TB 18.15 TB RAID 6 Single
VXP-F-28-5-S Flex 28 TB 21.78 TB RAID 5 Single
VXP-F-28-J-S Flex 28 TB 25.41 TB JBOD Single
VXP-F-20-5-S Flex 20 TB 14.52 TB RAID 5 Single
VXP-F-20-J-S Flex 20 TB 18.15 TB JBOD Single
VXP-F-8-J-S Flex 8 TB 7.26 TB JBOD Single
VXP-F-4-J-S Flex 4 TB 3.63 TB JBOD Single
VXP-F-0-J-S Flex 0 TB N/A JBOD Single
VXP-E-12-J-S Eco 12 TB 10.89 TB JBOD Single
VXP-E-8-J-S Eco 8 TB 7.26 TB JBOD Single
VXP-E-4-J-S Eco 4 TB 3.63 TB JBOD Single
VXP-E-0-J-S Eco 0 TB N/A JBOD Single
VXP-WKS Workstation N/A
How to Order
Use the following table to create a model number for your VideoXpert hardware and/or software package.
Your model number consists of the VxPro range, capacity, RAID-level, single/dual power supply, and
quantity of licenses.
The chart below lists the full range of features. Capacity, RAID level, dual power supply, and channel
requirements may be limited by the product range you select. Workstations come in a single configuration
and do not require capacity, RAID, power supply, or channel designations.
C4050S-F | 12/18 7
VideoXpert Professional v 3.1
Product Specification video management solutions
VideoXpert Player
The VxPlayer decrypts, validates, and plays-back secured exports from VideoXpert. You can download the
player directly from VideoXpert along with an exported video file or you can download it from Pelco.com.
The following sections specify the minimum system requirements for non-VideoXpert machines running
the VxPlayer.
Hardware Requirements
l Dual Core i5 2.67 GHZ
l 4 GB RAM
l 200+ GB of free HDD space or more
l GPU that supports OpenGL 3.0 or higher
l 1024 x 768 or higher screen resolution
l 100/1000 Ethernet Network Interface Card
l Sound Card
Software Requirements
l Windows 7 Pro or Ultimate 64 bit or higher
l .NET 4.6.1 or higher
l OpenGL 3.0 or higher
l Direct3D 9 or higher
C4050S-F | 12/18 8
VideoXpert Professional v 3.1
Product Specification video management solutions
Security
VideoXpert includes the following security features:
l Client authentication
l Passwords stored in encrypted format only
l Configurable roles and permissions
l User action reports
l TLS-based encryption over HTTPS
l Support running with antivirus
l Ability to encrypt exports
l Synchronized system clocks using NTP
l Incorporates FIPS 140-2 validated cryptographic modules
l FISMA/NIST Configuration Guidance – This guide will help organizations documenting the system
through their RMF process with information about:
l How to categorize the system
l Which NIST-based security controls are applicable
l How VX implements NIST-based security controls
l FISMA/NIST Compliance Testing – VideoXpert is installed on a FISMA representative system with
applicable DISA STIGs (Defense Information Systems Agency, Secure Technical Implementation
Guidelines) and tested for functionality. Applicable STIGS include:
l Microsoft Windows 10 for VxOpsCenter and VxToolbox
l Microsoft .Net Framework 4
l Microsoft Internet Explorer 11
l Microsoft Windows Firewall and Advanced Security
l Postgres Database 9.x
Supported Languages
The VxOpsCenter and VxToolbox interfaces is are available in the following languages:
l Arabic
l Brazilian Portuguese
l German
l French
l Italian
l Korean
l Russian
l Simplified Chinese
l Spanish for Latin America
l Turkish
C4050S-F | 12/18 9
VideoXpert Professional v 3.1
Product Specification video management solutions
Supplied Accessories
l Keyboard
l Mouse
l USB drive containing resource and recovery information
l Rack mount kit (Power Series only)
l US, UK, and EU power cords (for applicable models)
*
Not included with Power Series (VXP-P)models.
*
*
Optional Accessories
l VXP-KIT-4TB 4 TB hard disk drive with carrier for Eco or Flex Servers only
l VXP-KIT-8TB 8 TB hard disk drive with carrier for 2nd generation Power Servers only
VXP-WKS Client Optional Accessories
l VX-A3-SDD Shared Display Decoder with US, Europe, and United Kingdom power cords
l 3DX-600-3DMOUSE Enhanced 3D Mouse and Joystick
l Y-U0023-G910KBD Enhanced Keyboard
l A1-KBD-3D-KIT2 Enhanced Keyboard and 3D Mouse Combination Kit
Optional Power Accessories
l PWRCRD-S-AR Standard power cord, Argentina
l PWRCRD-S-AU Standard power cord, Australia
l PWRCRD-S-EU Standard power cord, Europe
l PWRCRD-S-UK Standard power cord, United Kingdom
l PWRCRD-S-US Standard power cord, United States
l PWRCRD-R-AR Round power cord, Argentina
l PWRCRD-R-AU Round power cord, Australia
l PWRCRD-R-EU Round power cord, Europe
l PWRCRD-R-UK Round power cord, United Kingdom
l VXP-KIT-P2-PSU Hot-swappable power supply for the VXP-P2 series.
Certifications
l CE (Class A)
l FCC, Part 15 (Class A)
l ICES-003 (Class A)
l UL/cUL Listed
l C-Tick
l CCC
l KCC
l NOM
C4050S-F | 12/18 10
VideoXpert Professional v 3.1
Product Specification video management solutions
Standards/Organizations
l Pelco is a member of the MPEG-4 Industry Forum
l Pelco is a member of the Universal Plug and Play (UPnP) Forum, Steering Committee
l Pelco is a member of the Universal Serial Bus (USB) Implementers Forum
l Pelco is a contributor to the International Standards for Organization / Electrotechnical Commission
(ISO/IEC) Joint Technical Committee 1 (JTC1), “Information Technology,” Subcommittee 29,
Working Group 11
l Compliance, ISO/IEC 14496 standard (also known as MPEG-4)
l Compliance, International Telecommunication Union (ITU) Recommendation G.711, “Pulse Code
Modulation (PCM) of Voice Frequencies”
l Compliance, Open Network Video Interface Forum (ONVIF) Profile S
C4050S-F | 12/18 11
VideoXpert Professional v 3.1
Product Specification video management solutions
International Standards Organization
Registered Firm; ISO9001 QualitySystem
Pelco by Schneider Electric
625 W. Alluvial, Fresno, California 93711 United States
(800) 289-9100 Tel
(800) 289-9150 Fax
+1 (559) 292-1981 International Tel
+1 (559) 348-1120 International Fax
www.pelco.com
Pelco, the Pelco logo, and other tr ademarks associated with Pelco products referred to in this publication are trademarks of Pelco, Inc.
or its affiliates. ONVIF and the ONVIF logo are trademarks of ONVIF Inc. All other product names and servicesare the pr operty of their
respective companies. Product specifications and availability are subject to change without notice.
© Copyright 2018, Pelco, Inc. Allrights reserved.
Loading...
