Pelco VXP-E2-0-J-S, VXP-E2-12-J-S, VXP-E2-8-J-S, VXP-F2-28-6-S, VXP-F2-28-J-S Specsheet
...
VideoXpert Professional v 3.5
Product Specification video management solutions
VideoXpert Professional v 3.5
Scalable VideoManagement and Surveillance System
Product Features
l “VideoXpert in a box” functionality for small to
mid-sized sites
l Simple setup / IT-Friendly — designed for
Unicast or multicast environments using
Microsoft® Windows® for easy configuration
and maintenance
l Available in different hardware configurations to
support the needs of different sites
l Supports MJPEG, MPEG-4, H.264, and H.265
l Supports monitor walls, including cell layouts and cameras
l Up to 450 Mbps throughput per recorder
l Supports attached storage (NAS) to extend video retention
l Includes VxToolbox for simple configuration of one or more servers
l Includes pre-defined roles for easy user creation, and also supports granular editing of user
permissions
l Motion Pixel Search for server side motion detection and quick retrieval of events
l 4k/H.264 and H.265 support for live and playback modes for cameras that support streaming
through ONVIF, and the ability to export recorded segments
l HTTPS support for Pelco and third-party cameras
l Supports environments that use anti-virus and firewall software
l Imports users and roles from existing LDAP servers to reduce administrative overhead, and enables
single sign-on (SSO)
l Check on VMS and camera health using SNMP (VxSNMPis available as a free, separate
download)
l Capable of listening for ASCII commands on a serial and Ethernet port simultaneously (ASCII
Service is available as a free, separate download)
l Includes Event Monitor Service feature, capable of polling for alarms from devices and performing
specified actions when an alarm state change occurs (VideoXpert Event Monitor Service is
available as a free, separate download)
l Ability to expose video streams to third-party clients, with customizable RTSP endpoints that allow
a client application connection to a VideoXpert System stream via the VxConnect service
(VxConnect is available as a free separate download)
l VxPortal web based client allows viewing and exporting video without installing any software
l Check on VMS and camera health using SNMP (VxSNMPis available as a free, separate
download)
l Extensible through mapping and plugins, including video information overlays and license plate
recognition
l Supports aggregation through VideoXpert Enterprise system with aggregation
C4050S-H.a | 06/19 1
VideoXpert Professional v 3.5
Product Specification video management solutions
l Supports ONVIF S- and G-compliant cameras and devices
l Edge Storage Auto Gap Fill functionality detects when a gap in local camera recording occurs, and
automatically downloads video and audio (if present) to fill the gap
l Investigation mode enables operators to synchronize video playback and export investigative
playlists covering scenes of interest
l Monitor multiple VxPro sites with a single client
l The desktop workstation supports up to two 4k monitors or four 1080p monitors
l Supports shared displays so operators can send video to surveillance personnel who need it most
l Supports DNShostnames for ONVIF-compliant cameras and Pelco cameras
l Enables and supports Risk Management Framework (RMF) and FIPS 104-2
l Provides seamless transition to VideoXpert
l Provides a migration path for Digital Sentry® systems
l Server models support Dell iDRAC and OpenManage tools
TM
Enterprise
Overview
VideoXpert Professional is a video management system (VMS) in a single box, designed for easy setup
and robust monitoring in small or moderately sized applications. Designed for Windows platforms, VxPro is
easy to install, quick to setup, and provides an intuitive interface that helps operators use video captured by
the system.
VxPro is available in tailor-made hardware solutions or in software solutions to support your existing VMS
infrastructure, VxPro provides options to support the throughput you need, and different amounts of storage
in RAID 6, RAID 5, or JBOD arrangements to fit your needs for retention, redundancy, and fault tolerance.
Software licenses operate in terms of channels, so you don't overpay for the solution you need. The
system supports unicast and multicast transmission modes, easily adapting to your network scheme.
Server models also include Dell’s iDRAC (integrated Dell Remote Access Controller) platform and support
for Dell’s OpenManage tools, allowing administrators to remotely configure and support VxPro servers,
reducing the need for physical access to the server. Using the iDRAC controller, you can monitor hardware
and receive email alerts via SNMP.
VxPro includes VxToolbox, an easy-to-use Windows application enabling users to quickly and easily
configure an entire network of servers and cameras locally or remotely. VxPro has pre-defined roles,
designed around standard surveillance operations, making user creation and assignments quick and easy.
The included VxOpsCenter client software provides an easy to use interface, so you can use VideoXpert
with little to no training. You can operate VxOpsCenter clients in multi-system access mode, allowing one
workstation to access multiple servers, scaling your surveillance solution. VxOpsCenter also supports
modular plugins, providing integrated functionality from external systems, including informational overlays,
license plate recognition (LPR), analytics, and a built-in mapping application.
Built around open standards, VideoXpert includes a complete application programing interface (API),
software development kit (SDK), and dedicated technical support, allowing other systems' manufacturers
to develop interfaces leveraging VideoXpert's capabilities.
Administrators can migrate current Digital Sentry hardware environments to VideoXpert Professional,
repurposing hardware and reusing current video management infrastructure while gaining the benefits of
VideoXpert. VideoXpert Professional can also utilize Digital Sentry storage hardware as recording
C4050S-H.a | 06/19 2
VideoXpert Professional v 3.5
Product Specification video management solutions
solutions, preserving the video stored on those devices while providing access to VideoXpert Professional
features.
Technical Specifications
Hardware
Item Power 2 Server Flex 2 Server Eco 2 Server Workstation
Form Factor Rack (2RU) Tower
Processor Intel® Xeon®
Silver 4110
Intel® Xeon® E2134
Intel® Xeon® E2124
Intel® CoreTMi78700
Memory 16 GB DDR4
Operating System Microsoft® Windows®10 IoTEnterprise 64-bit (LTSB)
OSDrive 2x SSD 240 GB
M.2 SSD240 GB M.2 NVMe 256 GB
(RAID 1)
Storage
1
Max
RAIDLevel
2
96 TB (7200 RPM
SATA)
28 TB (7200 RPM
SATA)
12TB (7200RPM
SATA)
N/A
6/5/JBOD JBOD N/A
Optical Drive N/A DVR±RW
Dell iDRAC Controller iDRAC9 Basic N/A
USBPorts
USB 2.0 1x front 4x rear 2x front, 2x rear
USB 3.0 2x rear 1x front, 2x rear 1x front, 4x rear
USB 3.1 Type-C N/A 1x front
1
Maximum storage based on JBODconfiguration
2
RAIDlevel is user configurable
Power 2 Server Flex 2 Server
C4050S-H.a | 06/19 3
VideoXpert Professional v 3.5
Product Specification video management solutions
Eco 2 Server Desktop Workstation
Video
Power 2
Item
Video Outputs 4x Mini DisplayPort 1.4
Video system NVIDIA Quadro P620 (2 GB memory)
Maximum Video Resolution per output type
mDP 1.4 direct connect HDR 5120 x 2880 at 60 Hz (30-bit color)
Video Standards
NTSC N/A 60 Hz capable
PAL N/A 75 Hz capable
Server Flex 2 Server Eco 2 Server Workstation
Audio
Eco 2
Item Power 2 Server Flex 2 Server
Inputs N/A Universal Audio Jack (front)
Outputs DisplayPort Audio Universal Audio Jack (front), Line Out
Server Workstation
(rear), Internal Speaker, DisplayPort
Audio
Connector
Types
C4050S-H.a | 06/19 4
mDPCable (out) 3.5 mm 4 pole (In/Out), 3.5 mm 3 pole
(Out), mDP cable (Out)
