VideoXpert Shared Display™
Product Specification, video management solutions
VideoXpert Shared Display™
Product Features
l Operators can send video to surveillance personnel who need it
most
l With the support of VxOpsCenter™ utilizing Shared Display mode,
the Shared Display Decoder provides monitor-wall functionality.
Users can send tabs and video to the Shared Display and control the
Shared Display remotely.
Technical Specifications
Hardware
Item Specification
Processor Intel® Core™ i7-10700T
Memory 16 GB DDR4
Operating System Windows 10 IoT Enterprise
SSD Storage 128 GB
USB Ports
USB 3.1 1x front, 4x rear
USB 3.1 Type-C 1x front
C5025S-B | 09/20 1
VideoXpert Shared Display™
Product Specification, video management solutions
Video
Item Specification
Video system Intel UHD Graphics
Memory Shared
Video Outputs 2x DisplayPort, HDMI
Max Resolution
DisplayPort 1920 x 1080 at 60 Hz
HDMI 1920 x 1080 at 60 Hz
Networking
Item Specification
Interface Gigabit Ethernet (1000Base-T) port (1x)
IPversion IPv4
Front Panel
Item Specification
Button Power
Indicators
Unit Status White, flashing white
Primary Network Green, orange, off
Hard Disk Status Flashing white
Power
Item Specification
Power Input 100 to 240 VAC 50/60 Hz, autoranging
Power Supply External,130 W
Power Consumption 19.5 VDC, 6.7 A
C5025S-B | 09/20 2
VideoXpert Shared Display™
Product Specification, video management solutions
Environmental
Item Specification
Operating Temperature 5° to 35°C (41° to 95°F)
Non-Operating Temperature –40° to 65°C (–40° to 149°F)
Operating Relative Humidity 20% to 80%, non-condensing
Non-Operating Relative Humidity 10% per hour
Operating Altitude –15 to 3,048 m (–50 to 10,000 ft)
Operating Vibration 0.66 GRMS
Note:The temperature at the unit air intake can be significantly higher than room temperature.
Temperature is affected by rack configuration, floor layout, air conditioning strategy, and other
issues. To prevent performance failure and unit damage, make sure the temperature at the unit is
continuously within the operating temperature range.
Physical
Item Specification
Construction Steel and plastic cabinet
Finish Black
Dimensions (D x W x H) 3.6 x 17.8 x 18.3 cm (1.4 x 7.0 x 7.2 in)
Mounting (RU) VESA mount included
Unit Weight 1.30 kg (2.87 lb)
Certifications
Item Specification
CE Class B
FCC, Part 15 Class B
ICES-003 Class B
UL/cUL Listed Yes
C-Tick Yes
CCC Yes
KC Yes
C5025S-B | 09/20 3
VideoXpert Shared Display™
Product Specification, video management solutions
Model Number
l VX-A5-SDD VideoXpert SharedDisplay with VESA mount; and US, Europe, and United Kingdom
power cords
C5025S-B | 09/20 4
VideoXpert Shared Display™
Product Specification, video management solutions
Pelco, Inc.
625 W. Alluvial Ave., Fresno, California 93711 United States
(800) 289-9100 Tel
(800) 289-9150 Fax
+1 (559) 292-1981 Inter national T el
+1 (559) 348-1120 Inter national F ax
www.pelco.com
Pelco, the Pelco logo, and other trademarks associated with Pelco products referred to in this publication are tr ademarks of Pelco, Inc.
or its affiliates. ONVIF and the ONVIF logo ar e trademarks of ONVIF Inc. All other product names and services are the property of their
respective companies. Product specifications and availabilityare subject to change without notice.
© Copyright 2020, Pelco, Inc. Allrights reserved.
