Pelco PMM1201 User Manual 2

®

PMM901/PMM1201

Monitors

Installation/Operation Manual

C931M (12/96)

Pelco • 3500 Pelco Way, Clovis, CA 93612-5699 • USA • [phone] or (1-559) 292-1981

FAX [phone] or (1-559) 292-3827

International Customers call (1-559) 292-1981 or FAX [phone]

TABLE OF CONTENTS

Section Page

1.0 WARNINGS ............................................................................................... 1

1.1 IMPORTANT SAFEGUARDS ............................................................ 1

2.0 DESCRIPTION .......................................................................................... 3

2.1 MODELS ............................................................................................ 3

3.0 INSTALLATION ..........................................................................................4

3.1 SURFACE MOUNT............................................................................4

3.2 RACK MOUNT ................................................................................... 4

3.3 CONNECTIONS ................................................................................ 4

3.3.1 Single-Monitor Installation ............................................................. 4

3.3.2 Multiple-Monitor Installation ........................................................... 5

4.0 OPERATION ..............................................................................................6

5.0 MAINTENANCE .........................................................................................8

6.0 SPECIFICATIONS .....................................................................................8

7.0 WARRANTY AND RETURN INFORMATION ...........................................10

LIST OF ILLUSTRATIONS

LIST OF TABLES

Figure Page

1 Single-Monitor Installation ................................................................. 4

2 Multiple Monitor Installation ............................................................... 5

3 Location of Controls ...........................................................................6

4Vertical Roll ........................................................................................7

5 Horizontal Tear ...................................................................................7

Table Page

AVideo Coaxial Cable Wiring Distances .............................................. 5

ii

12 Pelco Manual C931M (12/96)

1.1 IMPORTANT SAFEGUARDS

Before installing your equipment, please read the following important safeguards
as outlined by Underwriters Laboratories Inc.

Read Instructions

All the safety and operating instructions should be read before the appliance is operated.

Retain Instructions

The safety and operating instructions should be retained for future reference.

Heed Warnings

All warnings on the appliance and in the operating instructions should be followed.

Follow Instructions

All operating and use instructions should be followed.

Cleaning
Do not use liquid cleaners or aerosol cleaners. Use a Damp Cloth for cleaning.

Attachments

Do not use attachments not recommended by Pelco as they may cause hazards.

Water and Moisture

Do not use this CCTV product near water - for example, near a kitchen sink, wash
bowl, bath tub, sprinkler, in a wet basement or near a swimming pool, and the like
unless it is specifically marked “for use in wet locations”.

1.0 WARNINGS

Accessories

Do not place this CCTV product on an unstable cart, stand, tripod, bracket, or table.
The CCTV product may fall, causing serious injury to a child or adult, and serious
damage to the appliance. Use only with a cart, stand, tripod, bracket or table rec­ommended by Pelco, or supplied by Pelco with the product. When mounting the
appliance, follow Pelco’s installation instructions, and use only mounting accesso­ries recommended by Pelco.

Cart & Stand

An appliance and cart combination should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the appliance and cart combination to overturn.

Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the CCTV product, and to protect it from overheating. These openings
must not be blocked or covered. The openings should never be blocked by placing
the CCTV product on furniture, carpet, or similar surfaces. The CCTV product should
never be placed near or over radiators or heat registers. This CCTV product should
not be placed in a built-in installation, such as a book case or rack unless proper
ventilation is provided or Pelco’s installation instructions are adhered to.

Power Sources

This CCTV product should only be operated from the type of power source indi­cated on the marketing label. If you are not sure of the type of power supply to your
installation location, consult your local electrical building official or power company.
Refer to the operating instructions for appliances intended to operate from battery
or other power sources.

Grounding

This CCTV product is equipped with a “grounding” type plug. This plug will only fit into
a “grounding” type power outlet. This is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to replace your obsolete outlet. Do not
defeat the “grounding” type plug since it is provided to ensure your safety.

Pelco Manual C931M (12/96) 1

Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where they exit from the appliance.

Overloading

Do no overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.

Object and Liquid Entry

Never push objects of any kind into this CCTV product through openings as they
may touch dangerous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the CCTV product.

Servicing

Do not attempt to service this CCTV product yourself as opening or removing cov­ers may expose you to dangerous voltages or other hazards. Refer all servicing to
qualified service personnel.

Damage Requiring Servicing

Unplug this CCTV product from the wall outlet and refer servicing to qualified ser­vice personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the CCTV product.
c. If the CCTV product is not marked “Suitable for Wet Locations” and it has

been exposed to rain or water.

d. If the CCTV product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating in­structions as an improper adjustment of other controls may result in damage,
and will often require extensive work by a qualified technician to restore the

CCTV product to its normal operation.
e. If the CCTV product has been dropped or the cabinet has been damaged.
f. When the CCTV product exhibits a distinct change in performance - this indi-

cates a need for service.

Replacement Parts

When replacement parts are required, be sure the service technician has used re­placement parts specified by Pelco or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

Safety Checks

Upon completion of any service or repairs to this CCTV product, ask the service
technician to perform safety checks to determine that the CCTV product is in proper
operating condition.

WARNING

This product has been evaluated for INDOOR USE ONLY unless it bears the mark-
ing FOR USE IN WET LOCATIONS.

WARNING

To reduce the risk of electric shock hazard, do not remove the cover of the unit. This
unit can not be serviced by the user and must be sent to a qualified service person
for repair when it fails to function.

The Lightning Flash with an arrow head symbol within an equilateral
triangle means that if the enclosure is opened, electrical circuitry is ex­posed which imposes an electric shock hazard to persons present.

The Exclamation Point within an equilateral triangle means the operat­ing instructions contain important information on how to operate and
maintain the appliance.

2 Pelco Manual C931M (12/96)
