PRODUCT SPECIFICATION
video management solutions
VideoXpert
™
SCALABLE VIDEO MANAGEMENT AND SURVEILLANCE SYSTEM
Product Features
• Designed to eliminate single points of failure and ensure reliability
though fault-tolerant software, distributed architecture, and multiple
levels of redundancy
• Provides scalability and modular expansion
• Provides migration paths for Endura® and Digital Sentry® systems
• Aggregates VMS networks and manage all video through a single
system (VideoXpert Ultimate distributions)
• Available in hardware and software-only distributions, for measured
performance or convenient migration of customer-owned hardware
• Microsoft® Windows®-based for easy setup and maintenance
• VX Toolbox provides administration interface for device and system
management capabilities
• Supports up to 6 monitors per workstation, each driven by
independent CPUs, displaying up to 25 streams per monitor
• Workstations available with 3D mouse and programmable keyboard
accessories to maximize operator control
• Extensible through plug-ins including mapping, video information
overlays (eConnect), and license plate recognition (PlateSmart)
• Create and assign tags, organizing network resources as you see fit
• Native RAID 6 storage solution supports 3rd party and Pelco Optera
cameras
• ONVIF compliant: Supports ONVIF S compliant cameras and devices
• Investigation mode enables operators to synchronize video playback
and export investigative playlists covering scenes of interest
• Supported languages: German, Spanish, French, Italian, Korean,
Polish, Portuguese, Russian, Turkish, Arabic, Japanese and Chinese
(Simplified)
VideoXpert is a video management solution designed to fit
surveillance operations of any size. Whether your operation has 100
cameras or 10,000, VideoXpert presents a solution to display, record,
and manage your video resources.
VideoXpert servers can be clustered to provide redundancy and
scalability within a single environment, enabling the system to grow
in tune with your surveillance needs. As you add cameras, users, or
recording devices, you can add servers and storage, enabling the
system to support the additional resources and perform to your
expectations. VideoXpert Ultimate can even aggregate other
VideoXpert systems, tying multiple VideoXpert systems into a single
interface. Through aggregation, administrators can build and
maintain a concerted video management system containing multiple
sites.
Designed for Windows platforms, VideoXpert is easy to install, quick
to setup, and should be familiar to most users. The system supports
unicast and multicast transmission modes, making it easy to adapt to
your current network scheme. Simplified interfaces ensure that users
can adopt and use the system with relative ease. From the Webbased Admin Portal, you can configure the system, manage the
database of devices, configure users and permissions, and assign
cameras to recording devices. Through the Ops Center software,
operators gain access to high quality video and powerful
investigative tools.
Administrators can migrate current Endura and Digital Sentry
hardware and environments to VideoXpert, re-purposing hardware
and reusing current video management infrastructures while gaining
the benefits of VideoXpert. VideoXpert can also utilize
NSM5200/NSM5300 and Digital Sentry storage hardware as
recording solutions, preserving the video stored on those devices
while providing access to VideoXpert features.
As distributed systems, VideoXpert Ultimate and Enterprise
architecture ensure that there is no single point of failure that would
compromise the system or video recording services. The system is
designed with multiple levels of redundancy – through both purposebuilt hardware and sophisticated failover and redundant recording
schemes – maximizing system uptime. The architecture allows
individual components to continue operating in the event of failures
elsewhere in the system.
VideoXpert can integrate with physical security systems and other
building systems to deliver situational awareness and control. Built
around open standards, VideoXpert includes a complete application
programing interface (API), software development kits (SDKs), and
dedicated technical support, allowing other systems’ manufacturers
to develop interfaces leveraging VideoXpert’s capabilities.
VideoXpert also supports third-party IP cameras, allowing users to
choose across hundreds of camera options from Pelco and third-party
partners when configuring a system.
International Standards
Organization Registered Firm;
ISO 9001 Quality System
C4016 / REVISED 12-13-17
TECHNICAL SPECIFICATIONS
VideoXpert consists of four major components: Core, Media
Gateway, Ops Center, and Storage Server. The Core performs central
management operations, maintaining the system database,
administering user rights and permissions, routing traffic, and other
central operations. The Media Gateway handles all requests for
video, ensuring that users at all levels of network access, LAN, WAN
and even cellular, receive the right type of video for their application.
The Ops Center Client is the operator console, providing an intuitive,
but powerful interface from which users can access and investigate
video throughout the system. The Storage Server (VXS) records video
and delivers recorded video to users.
CORE
The Core is the heart of the VideoXpert system, it maintains the
database of cameras and recording devices. The Core also hosts a
convenient Web interface called the Admin Portal, from which you
can configure and manage the system. Through the Admin Portal,
you can administer user accounts and permissions, determining the
system functions and devices users can access. You can create and
assign “tags” to quickly organize cameras and devices within the
system. You can also configure and respond to events within the
system.
The Core browser provides basic access to video streaming
resources, ensuring that users with appropriate permissions can
view video from the system even without a hard client, using just a
standard web browser.
The application provides mechanisms to sort cameras by tags and
other criteria, making it easy for users to find the cameras they need.
Users can switch between live and recorded video on the fly,
ensuring a seamless viewing experience. With appropriate
permissions, users can also share workspaces and even use the
same tabs simultaneously, enabling collaboration within your
surveillance operations.
The Ops Center also provides an Investigation Mode, through which
users can create playlists from multiple video clips encompassing
important scenes from an investigation. Users can export and
encrypt their investigations, storing clips relevant to their
investigation independent of the system’s network video storage for
evidentiary safe-keeping and quick access.
The Ops Center supports modular plug-ins, exposing additional
functionality for operators as required by your surveillance
operations. The Mapping plug-in enables operators to arrange and
find cameras on maps. Through mapping, operators can find and the
camera providing the view they need, when they need it. The
PlateSmart plug-in exposes license plate numbers, to track vehicles
as they come and go. The eConnect plug-in displays real-time
gaming information as a video overlay.
MEDIA GATEWAY
The Media Gateway routes video traffic to appropriate users as
requested. When a user requests a video stream, the Core fields the
request and determines whether the user possesses the appropriate
permissions to view the video stream. If the user can view the
stream, the Media Gateway connects the user with the appropriate
device — camera, encoder, or recorder as necessary.
Like Core servers, Media Gateways can be added to VideoXpert
modularly, allowing a system with 1000 cameras to support 20 users,
or a system with 100 cameras to support 200 users. You can add
Media Gateways to the system in tune with media delivery needs.
CORE/MEDIA GATEWAY COMBINATION
While you can leverage separate Core and Media Gateway servers
for systems of sufficient scale, most systems can easily support a
single server acting as a combined, Core and Media Gateway for
your VideoXpert server. The double-duty server provides the
complete range of VideoXpert functionality that you would expect for
systems with fewer than 2000 cameras and 100 simultaneous users.
OPS CENTER
The Ops Center is a Windows-based application, providing an
optimal environment from which users can watch live and recorded
video. With the support of Enhanced Decoders, the Ops Center
supports up to six monitors, each capable of displaying up to 25 video
streams simultaneously. Through the Ops Center, users can configure
and recall complete workspaces, enabling operators to quickly log in
and get to work.
STORAGE
VideoXpert Storage (VXS) is a RAID 6, high-availability recording
platform that captures recorded video for your VideoXpert system.
The system’s operating system is contained on an SSD, freeing more
space for video and ensuring higher reliability; hard drives belonging
to the RAID array are front-loading, making it easy to remove and
replace failed drives. Storage servers also maintain performance
levels in both normal and RAID error conditions, preventing dips in
performance and ensuring that users can always obtain the video
they need through VideoXpert.
VideoXpert Storage natively supports third-party IP cameras via
ONVIF S and driver packages, so you can bring your cameras into
VideoXpert without expensive translation interfaces.
You can configure Storage through Admin Portal or VX Toolbox,
making it easy to set recording schedules and assign cameras to your
storage servers. Storage supports motion, alarm, and bump-on-alarm
style recording, so you can always capture events relevant to your
environment at high quality. Storage also supports redundant
recording, ensuring that VideoXpert continues recording video even if
a single Storage server falls offline.
TECHNICAL SPECIFICATIONS
Y
SYSTEM TOPOLOGY
VideoXpert Ultimate allows for expansion at any level of your security environment. Your system begins with a single server hosting the Core and
Media Gateway. In addition your system requires the OPS Center and Storage Server. As your surveillance needs grow, you can add servers to expand
modularly within a single environment, or you can aggregate multiple VideoXpert systems to provide a single point of access for distributed video
management networks.
OPS CENTER CLIENT
LOCAL
ADMINISTRATORS
Admin Portal/VX Toolbox
CUSTOMER
FACILITIES
LOCAL
OPERATORS
STORAGE
SERVER
ULTIMATE SYSTEM
CORE/
MEDIA GATEWA
3RD PARTY
SYSTEM
eConnect
REMOTE CLIENT
Admin Portal/VX Toolbox
REMOTE
OBSERVER
ENTERPRISE or professional
OPERATORS
CUSTOMER FACILITIES
LOCAL
VIDEOXPERT ACCESSORY SERVER
You can install the VideoXpert Accessory Server to provide NTP, basic DHCP, active failover, and load balancing services for smaller networks. The
Accessory Server offers a native, multipurpose solution to control your time and addressing services from within VideoXpert.
When acting as a load balancer, the Accessory Server bridges multiple Core/Media Gateway (CMG) servers, optimizing performance and providing
redundancy for your VideoXpert network. With the Accessory Server, you can easily increase your VideoXpert network’s capacity and ensure the
system’s uptime so that users always have access to video.
TECHNICAL SPECIFICATIONS
Ops Center
Monitor 5
Monitor 4
Monitor 3Monitor 2
Monitor 1
Monitor 6
Legend
CAT5e
HDMI, VGA,
or DisplayPort
DVI-D or DisplayPort
Enhanced
Decoder
Enhanced
Decoder
Enhanced
Decoder
Enhanced
Decoder
Enhanced
Decoder
OPERATOR WORKSPACE TOPOLOGY
The Ops Center supports up to six monitors: one connected directly to the Ops Center, and the other five driven independently by Enhanced Decoders.
The Enhanced Decoders enable each monitor connected through a workstation to display up to 25 video streams while maintaining a seamless user
experience.
Enhanced Decoder-driven monitors operate just like native monitors; users can move windows across monitors seamlessly. But, when the user
requests a video stream or plug-in, the Enhanced Decoder communicates directly with VideoXpert servers to get and decode video. This enables
operators to maximize the display-capabilities of the Ops Center without complicating the user experience.
ADVANCED OPERATOR CONTROLS
In addition to the standard keyboard and mouse, Ops Center workstations support an Enhanced Keyboard, and Enhanced Mouse, and the
KBD5000.The Enhanced keyboard includes programmable keys to which operators can map shortcuts to their favorite tabs and workspaces; The new
Enhanced Mouse or your existing KBD5000 are mapped to the full range of Ops Center controls; an operator can perform any and all operations using
either control.
TECHNICAL SPECIFICATIONS
HARDWARE
Core/CMG Media Gateway Ops Center Storage
Enhanced Decoder
Accessory Server
Shared Display Decoder
Processor Intel® Xeon® E3-1275 v3
Xeon®
E3-1276 v3
®
Intel
Core™ i7-7700T
®
Intel
Memory 32 GB DDR3 ECC 8 GB DDR3 Non-ECC 32 GB DDR3 ECC 8 GB DDR4
®
Operating System Microsoft
®
Windows® Server 2012
Windows 7 (64 bit),
Windows 10 (64 bit)
Microsoft
Windows
2012
®
Server
Windows 10 IOT Enterprise
(Shared Display Decoder)
SSD Storage 480 GB 120 GB 120 GB 200 GB 256 GB
Storage 1 TB N/A Up to 96 TB
RAID Level N/A RAID 6
HDD
Effective
Capacity
N/A N/A
VXS-48: 32.70 TB
VXS-72: 54.50 TB
VXS-96: 76.40 TB
N/A
Optical Drive N/A DVD±RW N/A
USB 2.0 1 front, 2 rear 2 front, 2 rear --
USB Ports
MINIMUM SYSTEM
REQUIREMENTS
Processor Intel i7 Intel i7 64-bit CPU
Memory 16 GB 8 GB
Operating System Microsoft
Video System Intel HD Graphics P4700 or better VGA interface
USB 3.0 2 rear 2 rear --
USB 3.1
USB 3.1 Type-C 1 front
1
Core/CMG Media Gateway
N/A
Ops Center &
Shared Display
Storage
Decoder
®
Intel
Xeon®
E3-1276 v3
®
Windows® Server 2012
8 GB (2x 4 GB dual-
channel)
2
Windows 7 SP1 or
later (64-bit) or
Windows 10 (64-bit)
32 GB DDR3 ECC
®
Microsoft
®
Windows
Server
2012
1 front, 4 rear
Enhanced Decoder
Accessory Server
Enhanced Decoder and
Accessory Server are not
available as a software
distribution.
Refer to Ops Center minimum
system requirements for Shared
Display Decoder requirements.
Interface Gigabit Ethernet (1000Base-T)
1
Software distributions tested without antivirus software installed.
2
Failing to use dual-channel memory may result in lowered performance when viewing video on local monitors.
VIDEO
Core/CMG Media Gateway Ops Center Storage
Enhanced Decoder
Accessory Server
Shared Display Decoder
Video System Intel HD Graphics P4700
Memory Shared
Video Outputs 2x DisplayPort, DVI-D, VGA
Max Resolution
Video Standards
DisplayPort 3840 x 2160 at 60 hz 3840 x 2160 at 60 hz
DVI-D and VGA 1920 x 1200 at 60 hz 1920 x 1200 at 60 hz
NTSC 60 Hz 60 Hz
PAL 75 Hz 50 Hz
NETWORKING
Core/CMG Media Gateway Ops Center Storage
Intel HD Graphics
P4700; supports
optional upgrade
Shared; 1 GB for OPS-
WKS6
2x DisplayPort, DVI-D,
VGA; Supports up to 6
outputs for OPS-
WKS6
VGA interface; VXS
models are designed
to be configured
remotely through web
interface.
Intel HD
Shared
DisplayPort, HDMI
Enhanced Decoder
Accessory Server
Shared Display Decoder
Interface Gigabit Ethernet (1000Base-T) ports (2x)
Throughput N/A
450 Mbps recording /
176 Mbps playback
(Simultaneously)
Gigabit Ethernet (1000Base-T)
port (1x)
N/A
TECHNICAL SPECIFICATIONS
FRONT PANEL
Core/CMG Media Gateway Ops Center Storage
Enhanced Decoder
Accessory Server
Shared Display Decoder
Buttons Power, configuration/reset Power
Unit Status Green, amber, red Blue, red, off White, flashing white
Primary Network Green, amber, red Green, off Green, orange, off
Secondary
Network
Software Status Green, amber, red (based on diagnostics) N/A
Indicators
Hard Disk Status Green, red, off (behind bezel)
Power Status N/A Green, off N/A
Power Fail Status N/A Red, off N/A
POWER
Core/CMG Media Gateway Ops Center Storage
Green, amber, red Green, off
OS Drive (SSD):
Amber, off
RAID Drives:
Blue, red, off
N/A
Flashing white
Enhanced Decoder
Accessory Server
Shared Display Decoder
Power Input 100 to 240 VAC 50/60 Hz, autoranging
Power Supply Internal
100 VAC 160 W, 1.60 A, 547 BTU/H N/A
Power
Consumption
* Power consumption is based upon maximum capacity.
115 VAC 160 W, 1.39 A, 547 BTU/H N/A
120 VAC N/A
220 VAC 160 W, 0.72 A, 547 BTU/H N/A
240 VAC N/A
Internal, Redundant
Power Supply
414W, 3.45A,
1411 BTU/H *
406W, 1.69A,
1386 BTU/H *
External, 65 W
19.5 VDC, 3.34 A
ENVIRONMENTAL
Core/CMG Media Gateway Ops Center Storage
Enhanced Decoder
Accessory Server
Shared Display Decoder
Operating Temperature 10° to 35°C (32° to 95°F) at unit air intake (front of unit) 5° to 35°C (41° to 95°F)
Non-Operating Temperature –40° to 65°C (–40° to 149°F)
Operating Relative Humidity 20% to 80%, noncondensing
Non-Operating Relative Humidity 10% per hour
Operating Altitude –15 to 3,048 m (–50 to 10,000 ft)
Operating Vibration 0.25 G at 3 Hz to 200 Hz at a sweep rate of 0.5 octave/minute 0.66 GRMS
Note: The temperature at the unit air intake can be significantly higher than room temperature. Temperature is affected by rack configuration, floor layout, air
conditioning strategy, and other issues. To prevent performance failure and unit damage, make sure the temperature at the unit is continuously within the operating
temperature range.
–40° to 60°C
(–40° to 140°F)
20% to 95%,
noncondensing
5% to 95%,
noncondensing
PHYSICAL
Core/CMG Media Gateway Ops Center Storage
–40° to 65°C
(–40° to 149°F)
20% to 80%, noncondensing
10% per hour
Enhanced Decoder
Accessory Server
Shared Display Decoder
Construction Steel and plastic cabinet
Finish
Dimensions (D x W x H) 50.8 x 43.4 x 8.9 cm (20 x 17.1 x 3.5 in)
Mounting (RU) 2 RU 3 RU N/A (mount included)
Unit Weight 13.06 kg (28.8 lb) 12.38 kg (27.29 lb) 12.38 kg (27.29 lb) 35.5 kg (78 lb) 1.41 kg (3.12 lb)
Front Panel Dark gray with metallic silver end caps Black
Chassis Dark gray Silver Black
64.8 x 43.7 x 13.2 cm
(25 x 17.2 x 5.2 in)
3.6 x 17.8 x 18.2 cm (1.14 x 7.0
x 7.2 in)
TECHNICAL SPECIFICATIONS
SOFTWARE LICENSES, SERVERS, AND WORKSTATION MODELS
While Pelco servers, workstations, and recorders do not require activation licenses, certain software features and platform upgrades do. Aggregated cameras and
cameras recorded to VideoXpert Storage require a single license per channel. Consult Pelco Sales to ensure you obtain all the necessary equipment and licenses
required to support your environment.
Due to the complexity of network and system design for larger distributions, VideoXpert Ultimate requires either training certification, or that the installation be
performed by Pelco Professional Services. While not required for Enterprise distributions, it is strongly recommended that system installers and administrators be Pelcocertified.
Distribution Model Description
CMG-SVRP VideoXpert Core and Media Gateway all-in-one hardware; EU, US, and UK power cords included
COR-SVRP VideoXpert Core server hardware; EU, US, and UK power cords included
MGW-SVRP Media Gateway server hardware; EU, US, and UK power cords included
(Ultimate) U1
or
(Enterprise) E1
E1 OPS-WKSP Ops Center workstation; EU, US, and UK power cords included
E1 OPS-WKS6P
E1 BASE Enterprise base license, including one Core, one Media Gateway, one VXS license, and 32 camera licenses
U1 AGG-1C Ultimate site upgrade license for managing one camera
NSM-1UP Upgrade license enabling NSM5200/5300 models to support VideoXpert systems, 100 channel licenses included
DSS-1UP Upgrade license enabling DS servers to serve as recorders within VideoXpert, 50 channel licenses included
1C-SUP1 Software upgrade subscription; entitles you to upgrades for one year
1C-SUP3 Software upgrade subscription; entitles you to upgrades for three years
1C Camera license
32C 32 camera licenses
Ops Center workstation with upgraded graphics card, enabling use of up to 6 monitors using Enhanced Decoders
(D10U-A2-DEC). EU, US, and UK power cords included
STORAGE MODELS
Use the table below to find the model number for your VideoXpert Storage Server. The model number consists of the VideoXpert distribution, model, the amount of
storage, and the country-code (where applicable). Models ending in US and EUK include power cords for their respective regions; models without a country code do
not. For example, an Enterprise Storage Server with 48 TB of storage for the US is labeled E1-VXS-48-US.
Distribution Model Storage (in TB) Country Code (optional) Description
(Ultimate) U1
(Enterprise) E1
VXS
48
72 VXS with 72 TB storage (54.50 TB effective storage)
96 VXS with 96 TB storage (76.40 TB effective storage)
US = North America
EUK = Europe/United Kingdom
VXS with 48 TB storage (32.70 TB effective storage)
VIDEOXPORT PLAYER
The VideoXport player decrypts, validates, and plays-back secured exports from VideoXpert. You can download the player directly from VideoXpert along with an
exported video file or you can download it from Pelco.com. These are the minimum system requirements for non-VideoXpert machines running the VideoXport player:
Hardware Requirements Dual Core i5 2.67 GHZ
Software Requirements Windows 7 Pro or Ultimate 64 bit or higher
4 GB RAM
200+ GB of free HDD space or more
GPU that supports OpenGL 3.0 or higher
1024 x 768 or higher screen resolution
100/1000 Ethernet Network Interface Card
Sound Card
.NET 4.6.1 or higher
OpenGL 3.0 or higher
Direct3D 9 or higher
TECHNICAL SPECIFICATIONS
SUPPORTED LANGUAGES
The Admin Portal and Ops Center interfaces are available in:
•German
• Spanish
• French
•Italian
• Korean
• Polish
• Portuguese
• Russian
•Turkish
•Arabic
• Chinese (simplified)
• Japanese
SUPPLIED ACCESSORIES
Keyboard (Core, Media Gateway, CMG, and Ops Center models)
Mouse (Core, Media Gateway, CMG, and Ops Center models)
USB drive containing resource and recovery information
Rack mount kit
Power cord (for applicable models)
OPTIONAL POWER ACCESSORIES
PWRCRD-S-AR Standard power cord, Argentina
PWRCRD-S-AU Standard power cord, Australia
PWRCRD-S-EU Standard power cord, Europe
PWRCRD-S-UK Standard power cord, United Kingdom
PWRCRD-S-US Standard power cord, United States
PWRCRD-R-AR Round power cord, Argentina
PWRCRD-R-AU Round power cord, Australia
PWRCRD-R-EU Round power cord, Europe
PWRCRD-R-UK Round power cord, United Kingdom
PWRCRD-R-US Round power cord, United States
OPS CENTER CLIENT OPTIONAL ACCESSORIES
VX-A3-DEC Enhanced Decoder and mount with US,
Europe, and United Kingdom power cords
VX-A3-SDD Shared Display Decoder with US, Europe, and
United Kingdom power cords
3DX-600-3DMOUSE Enhanced 3D Mouse and Joystick
Y-U0023-G910KBD Enhanced Keyboard
A1-KBD-3D-KIT2 Enhanced Keyboard and 3D Mouse
Combination Kit
STORAGE SERVER ACCESSORIES
VXS-HDD-6TB Replacement 6 TB hard drive and carrier for
VXS Models
STANDARDS/ORGANIZATIONS
• Pelco is a member of the MPEG-4 Industry Forum
• Pelco is a member of the Universal Plug and Play (UPnP) Forum, Steering
Committee
• Pelco is a member of the Universal Serial Bus (USB) Implementers Forum
• Pelco is a contributor to the International Standards for Organization /
Electrotechnical Commission (ISO/IEC) Joint Technical Committee 1
(JTC1), “Information Technology,” Subcommittee 29, Working Group 11
• Compliance, ISO/IEC 14496 standard (also known as MPEG-4)
• Compliance, International Telecommunication Union (ITU)
Recommendation G.711, “Pulse Code Modulation (PCM) of Voice
Frequencies”
• Compliance, Open Network Video Interface Forum (ONVIF) Profile S
VIDEOXPERT ACCESSORY SERVER
VX-A3-ACC VideoXpert Accessory Server with US,
Europe, and United Kingdom power cords
CERTIFICATIONS
At the time of this publication, certifications for Class A products are pending. Consult the factory, our Web site (www.pelco.com), or the most recent B.O.S.S.® update
for the current status of certifications.
Enhanced Decoder
Accessory Server
Media
Core/CMG
CE
Class A Class A Class A Class A Class B Class B Class BFCC, Part 15
ICES-003
UL/cUL Listed
C-Tick
CCC
KC
Gateway Ops Center Storage
Shared Display
Decoder
Enhanced 3D
Mouse
3DX-600-3DMOUSE
Enhanced
Keyboard
Y-U0023-G910KBD
Pelco by Schneider Electric
625 W. Alluvial, Fresno, California 93711 United States
USA & Canada Tel (800) 289-9100 Fax (800) 289-9150
International Tel +1 (559) 292-1981
www.pelco.com www.pelco.com/community
Pelco, the Pelco logo, and other trademar ks associated with Pelco products referred
to in this publication are trademarks of P elco, Inc. or its affiliates. ONVIF and the
ONVIF logo are trademarks of ONVIF Inc. All other product nam es and
Product specifications and availability are subject to change without notice.
services are the property of their respective companies.
©Copyright 2017, Pelco, Inc. All rights reserved.
Loading...
