PRODUCT SPECIFICATION

IMS0 Sarix® IP Mini Indoor Fixed Dome

0.5 MEGAPIXEL STANDARD DEFINITION INTEGRATED CAMERA

Product Features

• Up to 0.5 Megapixel Resolution (800 x 600)

• Up to 30 Images per Second (ips) at All Resolutions

• Compact Size with 3-inch Bubble

• Varifocal 2.8 ~ 10 mm Lens

• Easy Installation

• H.264, MPEG-4 and MJPEG Compression

• Sensitivity Down to 0.12 lux

• Power over Ethernet (PoE), IEEE 802.3af

• Video Setup Jack Accessible with Dome Installed

• Up to 2 Simultaneous Video Streams

• Electronic PTZ Through the Web Browser

• Open IP Standards

camera solutions

The
fixed dome camera designed with industry-leading image quality and
high performance processing power. From back box wiring to
focusing the lens, the

Sarix

imaging performance, delivering high resolution, advanced low-light
capabilities, consistent color science, and fast processing power.
The H.264 compression video files are considerably smaller, making
network video storage more affordable.

®

Sarix

IMS0 Series

technology defines the next generation of video security

is a standard definition network indoor

IMS0

is designed to install quickly and easily.

Fixed Dome Camera

The

IMS0

contains an integrated varifocal 2.8 ~ 10 mm lens. All
models include a camera in a compact indoor enclosure that is ready
to install.

The

IMS0

supports two simultaneous video streams. The two
streams can be compressed in MJPEG, MPEG4, and H.264 formats
across several resolution configurations. The streams can be
configured in a variety of frame rates, bit rates, and group of pictures
(GOP) structures for additional bandwidth administration.

Built-In Analytics

The

Pelco Camera Sabotage

IMS0. This behavior detects contrast changes in the field of view. An
alarm is triggered if the lens is obstructed with spray paint, a cloth,
or covered with a lens cap. Any unauthorized repositioning of the
camera also triggers an alarm.

behavior is a standard feature of the

Web Interface

The

IMS0

uses a standard Web browser for powerful remote setup

and administration.

Window Blanking

Window blanking is used to conceal user-defined privacy areas that
cannot be viewed by an operator. The
blanked windows. A blanked area will appear on the screen as a
solid gray window.

IMS0

supports up to four

Video Systemization

The

IMS0

easily connects to Pelco IP and hybrid systems such as

®

version 2.0 (or later) and Digital Sentry® version 4.3 (or

Endura
later). The camera is also compatible with Digital Sentry NVs
(DS NVs), a full-featured video management software, which is
available as a free download at
four free Pelco IP licenses and allows for the management of video
from up to 64 cameras.

The IMS0 Series features open architecture connectivity to
third-party software. Pelco offers an application programming
interface (API) for interfacing with Pelco’s network cameras.

www.pelco.com

. DS NVs includes

International Standards

Organization Registered Firm;

ISO 9001 Quality System

C2973 / REVISED 7-8-11

TECHNICAL SPECIFICATIONS

SARIX

SARIX

GENERAL

Imaging Device 1/3-inch (effective)
Imager Type CMOS
Imager Readout Progressive scan
Maximum Resolution
Signal-to-Noise Ratio 50 dB
Auto Iris Lens Type DC drive
Electronic Shutter Range 1 ~ 1/100,000 sec
Wide Dynamic Range 60 dB
White Balance Range 2,000° to 10,000°K
Sensitivity f/1.3; 2,850°K; SNR >24 dB

Color (1x/33 ms) 0.5 lux
Color SENS (15x/500 ms) 0.12 lux

Dome Attenuation

Clear Zero light loss
Smoked f/1.0 light loss

Construction

Back-box Cast aluminum and polycarbonate plastic
Trim ring Polycarbonate plastic
Bubble Acrylic plastic
Finish White

Weight

Unit 0.35 kg (0.77 lb)
Shipping 0.91 kg (2.00 lb)

Available Languages Chinese, English, French, German, Italian,

800 x 600

Portuguese, Russian, Spanish, and Turkish

NOTE: VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE CENTIMETERS.

IN-CEILING

Ø 9.07

(3.57)

9.37

(3.69)

5.26

(2.07)

Ø 8.18

(3.22)

SURFACE MOUNT

(Mounting Ring Included)

Ø 12.95

(5.10)

ELECTRICAL

Port RJ-45 connector for 100Base-TX

Auto MDI/MDI-X
Cable Type Cat5 or better for 100Base-TX
Power Input PoE (IEEE 802.3af class 2)
Power Consumption <6 W
Current Consumption

PoE <200 mA maximum

Service Port External 3-connector, 2.5 mm provides

NTSC/PAL video output
Accessory Port Connects Pelco accessories

MECHANICAL

Pan/Tilt Adjustment Manual

Pan 355°
Tilt 180°
Rotate 220°

ENVIRONMENTAL

Operational Temperature 0° to 50°C (32° to 122°F)
Operational Humidity 20% to 80%, noncondensing

9.40

(3.70)

Ø 8.18
(3.22)

COMPACT SIZE. EASY TO INSTALL.
