Description

Public view monitors (PVM) are units that contain a built-in camera that is pointed in the direction the monitor faces. The camera’s view is displayed on the same monitor so customers can see themselves. This feature makes the PVM ideal for commercial establishments because it creates interest, while discouraging theft.
The PVM also includes connections for additional camera inputs DVD players and inputs for media cards.
Some camera functions are controlled through menus; others are controlled through the DIP switches on the built-in camera located inside the monitor.

MODELS

PMP20B 20-inch (510 mm) LCD black monitor with wide dynamic range (WDR) camera
PMP20W 20-inch (510 mm) LCD white monitor with WDR camera
PMP26B 26-inch (660 mm) LCD black monitor with WDR camera
PMP26W 26-inch (660 mm) LCD white monitor with WDR camera

SPEAKERS

PVM models come with two internal speakers.

PACKAGE CONTENTS

1 20- or 26-inch LCD public view monitor (in black or white case) with WDR camera 1 Remote control unit 2 AAA batteries 1 Installation/Operation manual
REMOTE CONTROL
1 EA.
AAA BATTERIES
2 EA.
INSTALLATION/OPERATION MANUAL
PUBLIC VIEW MONITOR
Figure 1. Parts List
C2943M (1/08) 7
1 EA.

Installation

MOUNTING

The PVM accommodates mounts that adhere to the VESA® 100 x 100 standard.
For mounting from a ceiling, Pelco recommends using the PMCL-CM mount. This mount can be swiveled 360 degrees, and lets you tilt the monitor 35 degrees for the best viewing angle. This mount must be used with a pole to hang the monitor from a ceiling. The PMCL-CM can support a maximum load of 90 lb (40.8 kg).
For more information and instructions on mounting, refer to the PMCL-CM Monitor Mount Installation manual (C2226M).
For a list of additional mounts, refer to Specifications on page 23.

WIRING

1. On the back of the monitor, loosen the thumb screws and lower the access panel.
2. Attach the leads from the power supply (not supplied) to the left and right connectors, refer to callout 1 in Figure 2 on page 9. For more information about power supplies, refer to Recommended Power Supplies on page 25.
NOTE: Do not connect a ground to the center post.
3. Connect the camera output and any other devices using the connectors, refer to Figure 2 on page 9. Devices that can be connected include DVD players, time-lapse VCRs, and media cards.
4. When finished, secure the access panel.
Table A shows the recommended maximum wiring distances (transformer to load), and are calculated with a 10-percent voltage drop. (Ten percent is generally the maximum allowable voltage drop for AC-powered devices.)
NOTE: For the 26-inch PVM, the maximum VA requirement is 160.8; the maximum current draw is 6.7 A. For the 20-inch PVM, the maximum VA requirement is 96; the maximum current draw is 4.0 A.
Table A. Recommended Wiring Distances
Total VA
Consumed
100
160
20 AWG
(0.5 mm2)
28 ft (8 m)
17 ft (5 m)
18 AWG
(1.0 mm2)
45 ft
(13 m)
28 ft (8 m)
Wire Gauge
16 AWG
(1.5 mm2)
71 ft
(21 m)
44 ft
(13 m)
14 AWG
(2.5 mm2)
114 ft (34 m)
71 ft
(21 m)
12 AWG
(4.0 mm2)
181 ft
(55 m) 113 ft
(34 m)
10 AWG
(6.0 mm2)
288 ft
(87 m) 180 ft
(54 m)
8 C2943M (1/08)

REAR PANEL CONNECTORS

COVER
ACCESS DOOR
THUMBSCREW
24V AC~
INPUT
USB CF SD
OUTPUT
Figure 2. Rear Panel Connectors
24 V AC~: The 24 volt AC power.
ì
NOTE: The center post is not to be used.
î Camera Out: The internal camera’s video output signal. ï Video 2 (loop through): The input connections from a camera or a DVD player. Video loops through the BNC video output. ñ Video 1 (loop through): The input connections from a camera or a DVD player. Video loops through the BNC video output.
Media Input: The three media input ports for loading slide files: one USB port for flash drives and two card ports (CF card or SD card).
ó
NOTE: The USB media input port detects only USB flash memory, it cannot detect external USB devices, such as an external HDD.
C2943M (1/08) 9
