MAINTENANCE/ SERVICE
DF8 Series
Pendant Dome
C2433SM-B (4/07)
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, the apparatus does not operate normally, or the apparatus has been dropped.
10. To reduce the risk of shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to
do so.
11. The installation method and materials should be capable of supporting four times the weight of the unit and equipment.
12. Only use replacement parts recommended by Pelco.
13. After replacement/repair of this unit’s electrical components, conduct a resistance measurement between line and exposed parts to verify
the exposed parts have not been connected to line circuitry.
The product and/or manual may bear the following marks:
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit.
This symbol indicates that there are important operating and maintenance instructions
in the literature accompanying this unit.
Please thoroughly familiarize yourself with the information in this manual prior to installation
and operation.
CAUTION:
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
2 C2433SM-B (4/07)
Description
DF8 Series pendant domes are discreet surveillance domes that are designed for indoor or outdoor use.
MODELS
DF8-PB-0 Indoor, black, fixed mount pendant dome, black opaque lower dome with smoked viewing window (0.7 F-stop of light loss)
DF8-PB-1 Same as DF8-PB-0, except clear viewing window (virtually no light loss)
DF8-PB-2 Same as DF8-PB-0, except chrome lower dome (2 F-stops of light loss)
DF8-PB-3 Same as DF8-PB-0, except gold lower dome (2 F-stops of light loss)
DF8-PG-0 Indoor, gray, fixed mount pendant dome, black opaque lower dome with smoked viewing window (0.7 F-stop of light loss)
DF8-PG-1 Same as DF8-PG-0, except clear viewing window (virtually no light loss)
DF8-PG-2 Same as DF8-PG-0, except chrome lower dome (2 F-stops of light loss)
DF8-PG-3 Same as DF8-PG-0, except gold lower dome (2 F-stops of light loss)
DF8-PG-E0 Outdoor, gray, fixed mount pendant dome, heater and blower, black opaque lower dome with smoked viewing window
(0.7 F-stop of light loss)
DF8-PG-E1 Same as DF8-PG-E0, except clear viewing window (virtually no light loss)
Maintenance
Clean the acrylic dome as necessary to maintain a clear picture. Be careful not to scratch the surfaces of the dome.
Exterior surface: Clean the dome’s exterior surface with a nonabrasive cleaning cloth and cleaning agent that is safe for acrylic plastic. Either
liquid or spray cleaner/wax suitable for fine furniture is acceptable.
Interior surface (except chrome or gold): Clean the same as the exterior surface.
Interior surface (chrome or gold): The inside surface of a chrome or gold dome is easily scratched. Use the following precautions to maintain
the dome’s surface.
1. Always handle the dome from the outside of its circular flange.
2. Never touch the coated inside surface. The acid in your fingerprints will eventually etch the coating if the fingerprints are not carefully
removed according to the recommended cleaning procedure in item 5.
3. If dust or other contaminants accumulate on the dome’s interior, remove the debris with compressed air. Compressed air cans are available
from photographic equipment or electronic supply dealers.
4. If heavy residue accumulates and cannot be removed with air pressure, rinse with water and immediately dry with air pressure so that
water spots will not remain. Avoid wiping the coated surface with direct hand pressure, it will easily abrade unless extreme care is taken.
Once scratched, the dome cannot be recoated.
5. If internal wiping is necessary, avoid hand rubbing. Instead, make a wick as follows:
Use a very soft paper towel. Roll a section into a tightly wound tube. Tear the tube in half, and wet the fuzzy end of the wick with a solution
of isopropyl alcohol diluted with water. Hold the dome with its opening facing downward and wipe the interior of the dome with the wet
end of the wick. Use a circular motion, starting from the outside and spiraling into the center. Use a new wick for each two passes over the
dome.
C2433SM-B (4/07) 3
Exploded Assembly Diagrams
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Figure 1. Exploded Assembly Diagram, DF8 Pendant Models
Table A. Exploded Assembly Parts List, DF8 Pendant Models
Item Qty Description Part Number
1 3 Screw, 6-32 x 5/16-inch, pan head, Phillips, gray, with plastic washer
ZH6-32X.312GRAY
(outdoor models only)
2 3 Internal tooth lock washer, #6 (outdoor models only) ZH6LWSIS
3 1 Sun shield (outdoor models only) MF02-3020-007B
4 1 Top mount, black MF03-7050-241A
Top mount, gray MF02-7050-241A
5 1 Gasket 70610012
6 3 Internal tooth lock washer, #8 ZH8LWSIS
7 3 Screw, 8-32 x 3/8-inch, pan head, Phillips ZH8-32X.375SPP
8 1 Back box, black MF76-3021-056A
Back box, gray MF79-3021-056A
9 1 Base plate PDF54000COMP
10 3 Flat washer, #8 ZH188X435X60C
11 3 Nut, 8-32, hex, Nylock ZH10-0301-0400
12 1 Tilt table support leg MF03-3020-002A
13 2 Fender washer, 1/4-inch ZH255X1.50X62
14 3 Split lock washer, 1/4-inch ZH1/4LWSSL
15 2 Nut, 1/4-20 ZH1/4-20NUTCH
16 1 Tilt table MF03-3021-003A
17 1 Flat washer, 3/16-inch ZH260X562X65C
18 1 Screw, 1/4-20 x 1/2-inch ZH1/4-20X.500CH
NS 1 Trim leash assembly attached to side of back box
Leash
Internal tooth lock washer, #6
Nut, 6-32
MF00-3020-054A
ZH6LWSIS
ZH6-32NUTSH
NS = Not shown
4 C2433SM-B (4/07)
2
1
7
6
3
5674
Figure 2. Exploded Assembly Diagram, Heater and Fan Assembly (Outdoor Models Only)
Table B. Exploded Assembly Parts List, Heater and Fan Assembly (Outdoor Models Only)
Item Qty Description Part Number
1 1 Circuit board, fan rectifier PCB9000277BASSY
2 1 Spacer, 3/16-inch diameter x .125-inch, #4 SPA9015
3 2 Fan/heater shroud MF01-1041-013A
4 2 Heater pad, 24 VAC, 15W HT01-0321-0202
5 2 Fan, 12 VDC, .7W, 7 cfm ZH65-1240-1044
6 7 Nut, 4-40 ZH4-40NUTSH
7 7 Internal tooth lock washer, #4 ZH4LWSIS
NS 1 Power/heater circuit board on side of back box
Includes thermostat
PCB9000302ASSY
On at 40°F (4°C)
Off at 60°F (16°C)
Spacer, .250-inch outside diameter x .125-inch, #6
Internal tooth lock washer, #6
Nut, 6-32
SPA8500
ZH6LWSIS
ZH6-32NUTSH
NS = Not shown
C2433SM-B (4/07) 5
1
2
3
4
5
6
7
8
9
Figure 3. Exploded Assembly Diagram, Pendant Lower Dome
Table C. Exploded Assembly Parts List, Pendant Lower Dome
Item Qty Description Part Number
1 5 Screw, 6-32 x 1/4-inch, Phillips head with lock washer ZH01-2001-0603
2 1 DF8 Heater Ring Assembly (outdoor models only) 3023-004A
24 VAC, 60W
Includes thermostat
On at 70°F (21°C)
Off at 85°F (29°C)
3 1 Screw, 6-32 x 1/4-inch, Phillips head with lock washer ZH01-2001-0603
4 1 Lower dome retainer MF00-3020-053A
5 1 O-ring ZH69-0105-2756
6 1 Trim ring gasket GS01-0002-0430
7 2 Screw, 6-32 x 5/16 inch, pan head, ZH6-32X.312GRAY
Phillips, gray, with plastic washer
8 1 Trim ring, black MF03-3020-120A
Trim ring, gray
MF02-3020-120A
9 1 Acrylic dome, black opaque with smoked viewing window MF00-8080-000B
Acrylic dome, black opaque with clear viewing window MF00-8080-001B
Acrylic dome (chrome) MF00-8080-002B
Acrylic dome (gold) MF00-8080-003B
6 C2433SM-B (4/07)
PRODUCT WARRANTY AND RETURN INFORMATION
WARRANTY
Pelco will repair or replace, without charge, any merchandise proved defective in material or
workmanship for a period of one year after the date of shipment.
Exceptions to this warranty are as noted below:
• Five years on fiber optic products and TW3000 Series unshielded twisted pair transmission
products.
• Three years on Spectra
• Three years on Genex
• Three years on Camclosure
CC3701H-2X, CC3751H-2, CC3651H-2X, MC3651H-2, and MC3651H-2X camera models,
which have a five-year warranty.
• Three years on PMCL200/300/400 Series LCD monitors.
• Two years on standard motorized or fixed focal length lenses.
• Two years on Legacy
dome products.
• Two years on Spectra III
continuous motion applications.
• Two years on Esprit and WW5700 Series window wiper (excluding wiper blades).
• Two years (except lamp and color wheel) on Digital Light Processing (DLP
The lamp and color wheel will be covered for a period of 90 days. The air filter is not
covered under warranty.
• Eighteen months on DX Series digital video recorders, NVR300 Series network video
recorders, and Endura
• One year (except video heads) on video cassette recorders (VCRs). Video heads will be
covered for a period of six months.
• Six months on all pan and tilts, scanners or preset lenses used in continuous motion
applications (that is, preset scan, tour and auto scan modes).
Pelco will warrant all replacement parts and repairs for 90 days from the date of Pelco
shipment. All goods requiring warranty repair shall be sent freight prepaid to Pelco, Clovis,
California. Repairs made necessary by reason of misuse, alteration, normal wear, or accident
are not covered under this warranty.
Pelco assumes no risk and shall be subject to no liability for damages or loss resulting from
the specific use or application made of the Products. Pelco’s liability for any claim, whether
based on breach of contract, negligence, infringement of any rights of any party or product liability, relating to the Products shall not exceed the price paid by the Dealer to Pelco for such
Products. In no event will Pelco be liable for any special, incidental or consequential damages
(including loss of use, loss of profit and claims of third parties) however caused, whether by
the negligence of Pelco or otherwise.
The above warranty provides the Dealer with specific legal rights. The Dealer may also have
additional rights, which are subject to variation from state to state.
®
IV products.
®
Series products (multiplexers, server, and keyboard).
®
and fixed camera models, except the CC3701H-2,
®
, CM6700/CM6800/CM9700 Series matrix, and DF5/DF8 Series fixed
™
, Esprit®, ExSite®, and PS20 scanners, including when used in
®
) displays.
™
Series distributed network-based video products.
If a warranty repair is required, the Dealer must contact Pelco at (800) 289-9100 or
(559) 292-1981 to obtain a Repair Authorization number (RA), and provide the following
information:
1. Model and serial number
2. Date of shipment, P.O. number, Sales Order number, or Pelco invoice number
3. Details of the defect or problem
If there is a dispute regarding the warranty of a product which does not fall under the
warranty conditions stated above, please include a written explanation with the product when
returned.
Method of return shipment shall be the same or equal to the method by which the item was
received by Pelco.
RETURNS
In order to expedite parts returned to the factory for repair or credit, please call the factory at
(800) 289-9100 or (559) 292-1981 to obtain an authorization number (CA number if returned for
credit, and RA number if returned for repair).
All merchandise returned for credit may be subject to a 20% restocking and refurbishing
charge.
Goods returned for repair or credit should be clearly identified with the assigned CA or RA
number and freight should be prepaid. Ship to the appropriate address below.
If you are located within the continental U.S., Alaska, Hawaii or Puerto Rico, send goods to:
Service Department
Pelco
3500 Pelco Way
Clovis, CA 93612-5699
If you are located outside the continental U.S., Alaska, Hawaii or Puerto Rico and are instructed
to return goods to the USA, you may do one of the following:
If the goods are to be sent by a COURIER SERVICE, send the goods to:
Pelco
3500 Pelco Way
Clovis, CA 93612-5699 USA
If the goods are to be sent by a FREIGHT FORWARDER, send the goods to:
Pelco c/o Expeditors
473 Eccles Avenue
South San Francisco, CA 94080 USA
Phone: 650-737-1700
Fax: 650-737-0933
The materials used in the manufacture of this document and its components are compliant to the requirements of Directive 2002/95/EC.
This equipment contains electrical or electronic components that must be recycled properly to comply with Directive 2002/96/EC of the European Union
regarding the disposal of waste electrical and electronic equipment (WEEE). Contact your local dealer for procedures for recycling this equipment.
REVISION HISTORY
Manual # Date Comments
C2433SM 9/01 Original version.
C2433SM-A 8/02 Added certifications. Revised Important Safeguards and Warnings.
C2433SM-B 4/07 Update parts lists and formatting.
Pelco, the Pelco logo, Camclosure, Esprit, ExSite, Genex, Legacy, and Spectra are registe red trademarks of Pelco. ©Copyright 2007, Pelco. All rights reserved.
Endura and Spectra III are trademarks of Pelco.
DLP is a registered trademark of Texas Instruments, Inc.
Worldwide Headquarters
3500 Pelco Way
Clovis, California 93612 USA
USA & Canada
Tel: 800/289-9100
Fax: 800/289-9150
International
Tel: 1-559/292-1981
Fax: 1-559/348-1120
www.pelco.com
ISO9001
Australia|Canada|Finland|France|Germany|Italy|Macau|The Netherlands|Russia|Singapore
South Africa
Spain|Sweden|United Arab Emirates|United Kingdom|United States
|
Loading...
