Pelco C2429M User Manual

00546

BB5HD Series

Heavy-Duty Spectra

Back Box

Installation Manual

C2429M (3/01)

®

Pelco • 3500 Pelco Way • Clovis, CA 93612-5699 USA • www.pelco.com

In North America and Canada: Tel [phone] • FAX [phone]

International Customers: Tel [phone] • FAX [phone]

CONTENTS

IMPORTANT SAFEGUARDS AND WARNINGS ......................................................................................................... 3

DESCRIPTION ................................................................................................................................................................... 4

MODELS ........................................................................................................................................................................ 4

UNPACKING INSTRUCTIONS........................................................................................................................................4

INSTALLATION IN-CEILING MODELS .........................................................................................................................5

STEP 1 - PREPARE CEILING ....................................................................................................................................5

STEP 3 - INSTALL THE BACK BOX...........................................................................................................................5

STEP 2 - INSTALL THE MOUNTING PLATES .......................................................................................................... 5

STEP 5 - INSTALL DOME DRIVE ............................................................................................................................. 6

STEP 4 - WIRE CIRCUIT BOARD ............................................................................................................................. 6

STEP 6 - INSTALL LOWER DOME ........................................................................................................................... 6

INSTALLATION PENDANT MODELS .......................................................................................................................... 7

STEP 1 - MOUNT AND INSTALL THE BACK BOX ................................................................................................... 7

STEP 2 - WIRE CIRCUIT BOARD ............................................................................................................................. 7

STEP 3 - INSTALL DOME DRIVE ............................................................................................................................. 8

STEP 4 - INSTALL LOWER DOME ........................................................................................................................... 8

TROUBLESHOOTING ...................................................................................................................................................... 9

APPENDIX ......................................................................................................................................................................... 10

SPECIFICATIONS ............................................................................................................................................................. 14

WARRANTY AND RETURN INFORMATION .............................................................................................................. 16

LIST OF ILLUSTRATIONS

Figure 1. Dimension Drawing .................................................................................................................................................15

LIST OF TABLES

Ta ble A. Video Coaxial Cable Wiring Distances .................................................................................................................... 10

Ta ble B. 24 VAC Wiring Distances ........................................................................................................................................ 10

Ta ble C. Switch Settings for SW1 ..........................................................................................................................................10

Ta ble D. Switch Settings for SW2 – P-Type Control .............................................................................................................. 11

Ta ble E. Switch Settings for SW2 – D-Type Control ..............................................................................................................11

2 Pelco Installation Manual C2429M (3/01)

IMPORTANT SAFEGUARDS AND WARNINGS

Prior to installation and use of this product, the following WARNINGS should be observed.

1. Installation and servicing should only be done by qualified service personnel and conform to all local codes.

Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X, 6, or 6P enclosure, it is designed for indoor use only and it must

2.

not be installed where exposed to rain and moisture.

3. Only use replacement parts recommended by Pelco.

4. After replacement/repair of this unit’s electrical components, conduct a resistance measurement between line and exposed parts to
verify the exposed parts have not been connected to line circuitry.

5. The installation method and materials should be capable of supporting four times the weight of the enclosure, pan/tilt, camera and
lens combination.

The product and/or manual may bear the following marks:

This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within this unit.

This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.

Please thoroughly familiarize yourself with the information in this manual prior to installation and operation.

CAUTION:

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

Pelco Installation Manual C2429M (3/01) 3

DESCRIPTION

The Heavy-duty Spectra is perfect for installations where structural integrity and vandalism are a priority. The system features barrel
key locks, heavy-duty construction and a thick acrylic lower dome. The in-ceiling model has a reinforced bracket mounting system for
installation in a fixed ceiling. Pendant models can be mounted to a pole or wall using the IWM Spectra wall mount.

MODELS

BB5HD-F In-ceiling back box with reinforced bracket-mounting system
BB5HD-PG Indoor, pendant style back box with reinforced sun shroud
BB5HD-PG-E Environmental, pendant style back box with heater, fan and reinforced sun shroud

Lower dome models are not interchangeable. Each heavy-duty lower dome is designed for a specific back box model. Install the
correct lower dome to the right back box. See the following chart.

Back Box Model Lower Dome Model Lower Dome with Cage Model

BB5HD-F LD5HDF-1 LD5HDCF-1

BB5HD-PG LD5HDPG-1 LD5HDCPG-1

BB5HD-PG-E LD5HDPG-E1 LD5HDCPG-E1

Spectra Lite and all Spectra II model dome drives are compatible with all Heavy-Duty back box models.

UNPACKING INSTRUCTIONS

If an item needs to be returned to the factory, consult the WARRANTY AND RETURN section of this manual for instructions.

The following items are supplied:

IN-CEILING MODELS

1 Back box
1 Mounting plate
2 Back mounting plates
1 Parts bag

2 8-32 x .275-inch screws
1 Conduit fitting
1 Safety chain bracket
1 Lock nut
1 Compass tool

PENDANT MODELS

1 Back box
1Tube of thread compound

4 Pelco Installation Manual C2429M (3/01)

00535

SPRING CLIP

8-32X.275 INCH SCREW

00537

INSTALLATION IN-CEILING MODEL

STEP 1 - PREPARE CEILING

00530

00531

a. Locate the center point of the mount-

ing location. Drill a hole in the ceiling
using a 3/32-inch drill.

b. Insert the compass tool into the hole.

Draw a circle on the ceiling using the
compass tool and a pencil. Cut the
circle out of the ceiling.

STEP 2 - INSTALL THE MOUNTING PLATES

Use the eight 10-32 x 3-inch screws (supplied) and install the mounting ring and
two back mounting plates.

a. Line up the mount ring with the eight

fastener holes.

b. Feed one back mounting plate through

c. Install fasteners through the mount ring,

ceiling and out the back mounting plate.

d. Install second back mounting plate.
the hole in the ceiling and line up with
four fastener holes.

STEP 3 - INSTALL THE BACK BOX

ATTA CH SA FETY CHAIN HERE

c. Use the mounting ring as a template

and mark the hole pattern onto the
mounting surface. Prepare the holes.

S

MOUNTING
RING

00532

CEILING

00533

00534

a. Attach the conduit fitting, lock nut, and

safety chain bracket. Install a safety
chain/cable (not supplied) that will
support up to 16 pounds (7.3 kg).

b. Turn the thumbscrew and open the

hinged door to the back box. Pull wiring
into the back box through the conduit
fitting. Refer to Tables A and B in the
Appendix for wiring distances.

c. Compress the spring clips on the back

box and push it through the hole, until
the clips spring back. Tighten the screws
until you hear a clicking noise. Insert the
two 8-32 x .275-inch screws to secure
the back box to the mount ring.

Pelco Installation Manual C2429M (3/01) 5

STEP 4 - WIRE CIRCUIT BOARD

Attach the wiring to the circuit board inside the back box. When
finished, close the door to the back box and turn on the power.
The red LED will light.

IMPORTANT: If the LED does not light, refer to the

shooting section

.

NOTE: Aux 1 - Maximum 2A at low voltage (<40V)

Aux 2 - Maximum 150 vA at 32 VDC

Trouble-

COAXITRON

2 WIRE

+5 to +24 VDC

LOGIC GATE

(WIRING EXAMPLE)

CONTROLLER

CONTROLLER

CONTROLLER

SPECTRA II ONLY

24 VAC

TRANFORMER

VIDEO IN

TX­TX+

(WIRING EXAMPLE)

+5 VDC

NOT USED
NOT USED

SWITCHES

POWER

(24 VAC ONLY)

VIDEO OUT

RX-

CONTROL

RX+

(RS-422)

TX­TX+

1
2

ALARM

3

INPUTS

4
5
6
7
GROUND

(NO)
(NC)

GROUND

RELAY

(AUX 1)

AUX 2

STEP 5 - INSTALL DOME DRIVE

SW1

ON

1 2 3

6

4

5

7 8

ON

SW2

1

3

2

4

5 6

8

7

a. Set the DIP switches for SW1 and SW2 on the bottom of the

dome drive for the appropriate receiver address. Refer to the
labels on the dome drive or Tables C through E in the Appendix
in the back of this manual.

SW2

LABEL

SW1

RS-422 TERMINATION SWITCH

L

A

B

E

L

S

W

2

00538

EXTERNAL RELAY

(WIRING EXAMPLE)

GREEN

TAB

AUX 2

HEATER/FAN (NOT USED)

RED

TAB

00539

b. Line up the green and red tabs with the green and red labels.

Push in on the tabs. Insert the side with the green tab, then the
side with red tab. Continue pushing on the ends of the tabs
until both sides click into place.

00542

STEP 6 - INSTALL LOWER DOME

a. Attach the lower dome trim leash to one of the 8-32 x .275-

inch screws that secure the back box to the mounting ring.

b. Insert both keys in the barrel locks. Turn keys clockwise to the

unlocked position. Keys can not be removed from lock in the
unlocked position.

c. Align pegs (located on the mount ring) with the peg recep-

tacles (located on the inside of the lower dome).

TRIM LEASH

d. Place lower dome over back box. Hold and turn both keys to

the locked position.

TO USE YOUR DOME, REFER TO THE OPERATION AND

PROGRAMMING MANUAL.

BARREL
KEY LOCK

6 Pelco Installation Manual C2429M (3/01)

00497

BALL STUD

BALL STUD
RECEIVER

INSTALLATION PENDANT MODELS

STEP 1 - MOUNT AND INSTALL THE BACK BOX

NOTE: If installing outdoors make sure the installation is properly sealed to keep moisture out.

00540

a. Install the mount for the pendant dome. Refer to the instruc-

tions supplied with the mount. Bring the wiring for the dome
through the mount. Refer to Tables A and B in the Appendix for
wiring distances.

c. Pull wiring from the mount into the back box.

STEP 2 - WIRE CIRCUIT BOARD

Attach the wiring to the interconnect circuit board inside the back
box. Close the door to the back box. Turn on power to the back
box. The red LED will light.

IMPORTANT: If the LED does not light, refer to the

shooting section

.

NOTE: Aux 1 - Maximum 2A at low voltage (<40V)

Aux 2 - Maximum 150 vA at 32 VDC

Trouble-

00535

b. Turn the thumbscrew and open the hinged door located inside

the back box.

00541

d. Screw the back box into the mount. If outdoors, apply thread

compound (provided) to the threads on the back box.

COAXITRON

2 WIRE

+5 to +24 VDC

LOGIC GATE

(WIRING EXAMPLE)

CONTROLLER

CONTROLLER

CONTROLLER

SPECTRA II ONLY

24 VAC

TRANFORMER

VIDEO IN

TX­TX+

(WIRING EXAMPLE)

+5 VDC

NOT USED
NOT USED

SWITCHES

POWER

(24 VAC ONLY)

VIDEO OUT

RX-

CONTROL

RX+

(RS-422)

TX­TX+

1
2

ALARM

3

INPUTS

4
5
6
7
GROUND

(NO)
(NC)

GROUND

RELAY
(AUX 1)

AUX 2

EXTERNAL RELAY

(WIRING EXAMPLE)

AUX 2

HEATER/FAN (NOT USED)

00542

Pelco Installation Manual C2429M (3/01) 7

STEP 3 - INSTALL DOME DRIVE

3

SW1

ON

1 2 3

6

4

5

7 8

ON

SW2

1

3

2

4

5 6

8

7

SW2

LABEL

SW1

RS-422 TERMINATION SWITCH

L

A

B

E

L

S

W

2

00538

a. Set the DIP switches for SW1 and SW2 on the bottom of the

dome drive for the appropriate receiver address. Refer to the
labels on the dome drive or tables C through E in the Appendix
in the back of this manual.

STEP 4 - INSTALL LOWER DOME

RED

GREEN

TAB

TAB

00539

b. Line up the green and red tabs with the green and red labels.

Push in on the tabs. Insert the side with the green tab, then the
side with red tab. Continue pushing on the ends of the tabs
until both sides click into place.

0054

a. Lightly apply O-ring lubricant to the O-ring. Install the O-ring in

the groove on the trim ring of the lower dome.

Attach the back box trim leash to a retainer screw inside the
lower dome.

Environmental Model only: Plug the two-pin heater
connection in the lower dome into the mating connector in the
back box.

HEATER
CONNECTORS

BARREL
LOCK

TRIM
LEASH

O-RING

CENTER
PIN

00496

b. Align barrel locks in lower dome with the holes located on each

side of the back box. Push lower dome onto back box. Press
the pins of the barrel locks IN to secure the
lower dome.

TO USE YOUR DOME, REFER TO THE OPERATION AND

PROGRAMMING MANUAL.

8 Pelco Installation Manual C2429M (3/01)

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTION

Unit does not operate.
The controller is not
communicating with
the Spectra unit.

Check to see if the red LED on the circuit
board in the back box is lit.

1. The red LED is not lit.

a. Fuse is bad.

b. 24 VAC power source is not con-

nected or back box is bad.

2. The red LED is lit.

a. Wiring is incorrect or is not fully

seated.

b. DIP switch settings are incorrect.

a. Check fuse on the circuit board. Replace fuse if it is

bad. To order a fuse from Pelco, specify the part
number FUS1.6-5X20FAST. This is a 1.6-ampere
fuse, 5 x 20 mm, fast blow.

b. Use a voltmeter to check if 24 VAC is getting to the

power connector on the circuit board. If NO, check
your power supply. If YES, return the back box to
the factory for repair.

a. Check all connections to the circuit board.

Make sure that all connections are fully seated and
the board is wired correctly.

b. Check the DIP switch settings on the dome drive

(refer to Tables C, D, and E). If the unit still does
not operate, turn off power and replace the dome
drive with a good unit, if you have a spare. Check
the switch settings on the substitute dome drive
before installing it. (If you do not have a spare,
return the dome drive and back box to the factory.)
If you substituted a dome drive and the unit
operates, the original dome drive is bad (return
the dome drive to the factory). If the unit still
does not operate, then the circuit board is bad
(return the back box to the factory).

Fan does not
operate.

Ver tical roll on monitor
when switching
between cameras.

Fan connections are not fully seated.

Cameras are out of phase.

Make sure the connector for the fan is fully seated. If
the fan still does not operate, return the back box and
dome drive to the factory for repair.

If you are wiring more than one dome to the same
transformer, it is important to wire the power connec­tor in each dome the same way. That is, the wiring
from one side of the transformer must be connected
to the same connector on each dome.

WARNING: Make
sure you wire power
to the outer connec­tors of the terminal
block and ground to
the middle connec­tor. Otherwise, you
could damage the
dome.

DOME 1
POWER

DOME 2
POWER

DOME 3
POWER

00095

Pelco Installation Manual C2429M (3/01) 9

APPENDIX

Table A. Video Coaxial Cable Wiring Distances

Cable Type* Maximum Distance

RG59/U 750 ft (229 m)
RG6/U 1,000 ft (305 m)
RG11/U 1,500 ft (457 m)

* Minimum cable requirements:

75 ohms impedance. All-copper center conductor.
95% braided copper shield.

Table B. 24 VAC Wiring Distances

The following are the recommended maximum distances for 24 VAC with a
10-percent voltage drop. (Ten percent is generally the maximum allowable
voltage drop for AC-powered devices.)

Wire Gauge

20 18 16 14 12 10

30 vA 94 ft 150 ft 238 ft 380 ft 603 ft 960 ft

(28 m) (45 m (115 m) (72 m) (183 m) (292 m)

75 vA 37 ft 60 ft 95 ft 152 ft 241 ft 384 ft

(11 m) (18 m) (29 m) (46 m) (73 m) (117 m)

NOTE: Input power for the dome is 24 VAC only. Power consumption is 30 vA

per dome for indoor models and 75 vA for outdoor models.

Use a 24 VAC transformer with the following minimum vA:
40 vA per dome For indoor models (without heater)
100 vA per dome For outdoor models (with heater)

Table C. Switch Settings for SW1

Control Type Switch Setting

SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8

Coaxitron

P-Type Control ON OFF OFF OFF OFF OFF OFF OFF**

D-Type Control OFF ON OFF OFF OFF OFF OFF* OFF**

NOTES: Switches SW 1-3 through SW 1-6 MUST be OFF.

®

OFF OFF OFF OFF OFF OFF OFF OFF**

D-type control is RS-422 that is compatible with Pelco’s CM6700, MPT9500, CM8500, and Genex
American Dynamics control systems using the AD2083 Translator.
P-type control is RS-422 that is compatible with Pelco’s CM6700/CM9750/CM9760 and Genex

* OFF- Use with controllers that have more than 32 presets.

ON- Use with American Dynamics controllers (32 presets).

** OFF - Use with all control systems except CM9502 with variable speed keyboards.

For CM9502 with fixed speed keyboards, set switch OFF.

ON - Use with CM9502 with variable speed keyboards for smoother joystick control.

®

controllers or with

control systems.

10 Pelco Installation Manual C2429M (3/01)

Table D. Switch Settings for SW2 – P-Type Control

NOTE: For Coaxitron controls, SW2 is not used; set all switches OFF. For D-type control systems, refer to Table E.

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5

1 OFF OFF OFF OFF OFF

2ONOFF OFF OFF OFF

3 OFF ON OFF OFF OFF

4ONONOFF OFF OFF

5 OFF OFF ON OFF OFF

6ONOFF ON OFF OFF

7 OFF ON ON OFF OFF

8ONONON OFF OFF

9 OFF OFF OFF ON OFF

10 ON OFF OFF ON OFF

11 OFF ON OFF ON OFF

12 ON ON OFF ON OFF

13 OFF OFF ON ON OFF

14 ON OFF ON ON OFF

15 OFF ON ON ON OFF

16 ON ON ON ON OFF

Baud Rate Switch Setting

SW2-6 SW2-7 SW2-8

2400 OFF OFF OFF

4800 ON OFF OFF

9600 OFF ON OFF

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5

17 OFF OFF OFF OFF ON

18 ON OFF OFF OFF ON

19 OFF ON OFF OFF ON

20 ON ON OFF OFF ON

21 OFF OFF ON OFF ON

22 ON OFF ON OFF ON

23 OFF ON ON OFF ON

24 ON ON ON OFF ON

25 OFF OFF OFF ON ON

26 ON OFF OFF ON ON

27 OFF ON OFF ON ON

28 ON ON OFF ON ON

29 OFF OFF ON ON ON

30 ON OFF ON ON ON

31 OFF ON ON ON ON

32 ON ON ON ON ON

Table E. Switch Settings for SW2 – D-Type Control

NOTE: For Coaxitron controls, SW2 is not used; set all switches OFF. For P-type control systems, refer to Table D.

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

1ONOFF OFF OFF OFF OFF OFF OFF

2 OFF ON OFF OFF OFF OFF OFF OFF

3ONONOFF OFF OFF OFF OFF OFF

4 OFF OFF ON OFF OFF OFF OFF OFF

5ONOFF ON OFF OFF OFF OFF OFF

6 OFF ON ON OFF OFF OFF OFF OFF

7ONONONOFF OFF OFF OFF OFF

8 OFF OFF OFF ON OFF OFF OFF OFF

9ONOFF OFF ON OFF OFF OFF OFF

10 OFF ON OFF ON OFF OFF OFF OFF

11 ON ON OFF ON OFF OFF OFF OFF

12 OFF OFF ON ON OFF OFF OFF OFF

13 ON OFF ON ON OFF OFF OFF OFF

14 OFF ON ON ON OFF OFF OFF OFF

15 ON ON ON ON OFF OFF OFF OFF

16 OFF OFF OFF OFF ON OFF OFF OFF

17 ON OFF OFF OFF ON OFF OFF OFF

18 OFF ON OFF OFF ON OFF OFF OFF

19 ON ON OFF OFF ON OFF OFF OFF

20 OFF OFF ON OFF ON OFF OFF OFF

21 ON OFF ON OFF ON OFF OFF OFF

22 OFF ON ON OFF ON OFF OFF OFF

23 ON ON ON OFF ON OFF OFF OFF

24 OFF OFF OFF ON ON OFF OFF OFF

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

25 ON OFF OFF ON ON OFF OFF OFF

26 OFF ON OFF ON ON OFF OFF OFF

27 ON ON OFF ON ON OFF OFF OFF

28 OFF OFF ON ON ON OFF OFF OFF

29 ON OFF ON ON ON OFF OFF OFF

30 OFF ON ON ON ON OFF OFF OFF

31 ON ON ON ON ON OFF OFF OFF

32 OFF OFF OFF OFF OFF ON OFF OFF

33 ON OFF OFF OFF OFF ON OFF OFF

34 OFF ON OFF OFF OFF ON OFF OFF

35 ON ON OFF OFF OFF ON OFF OFF

36 OFF OFF ON OFF OFF ON OFF OFF

37 ON OFF ON OFF OFF ON OFF OFF

38 OFF ON ON OFF OFF ON OFF OFF

39 ON ON ON OFF OFF ON OFF OFF

40 OFF OFF OFF ON OFF ON OFF OFF

41 ON OFF OFF ON OFF ON OFF OFF

42 OFF ON OFF ON OFF ON OFF OFF

43 ON ON OFF ON OFF ON OFF OFF

44 OFF OFF ON ON OFF ON OFF OFF

45 ON OFF ON ON OFF ON OFF OFF

46 OFF ON ON ON OFF ON OFF OFF

47 ON ON ON ON OFF ON OFF OFF

48 OFF OFF OFF OFF ON ON OFF OFF

(Continued on next page)

Pelco Installation Manual C2429M (3/01) 11

Table E. Switch Settings for SW2 – D-Type Control (continued)

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

49 ON OFF OFF OFF ON ON OFF OFF

50 OFF ON OFF OFF ON ON OFF OFF

51 ON ON OFF OFF ON ON OFF OFF

52 OFF OFF ON OFF ON ON OFF OFF

53 ON OFF ON OFF ON ON OFF OFF

54 OFF ON ON OFF ON ON OFF OFF

55 ON ON ON OFF ON ON OFF OFF

56 OFF OFF OFF ON ON ON OFF OFF

57 ON OFF OFF ON ON ON OFF OFF

58 OFF ON OFF ON ON ON OFF OFF

59 ON ON OFF ON ON ON OFF OFF

60 OFF OFF ON ON ON ON OFF OFF

61 ON OFF ON ON ON ON OFF OFF

62 OFF ON ON ON ON ON OFF OFF

63 ON ON ON ON ON ON OFF OFF

64 OFF OFF OFF OFF OFF OFF ON OFF

65 ON OFF OFF OFF OFF OFF ON OFF

66 OFF ON OFF OFF OFF OFF ON OFF

67 ON ON OFF OFF OFF OFF ON OFF

68 OFF OFF ON OFF OFF OFF ON OFF

69 ON OFF ON OFF OFF OFF ON OFF

70 OFF ON ON OFF OFF OFF ON OFF

71 ON ON ON OFF OFF OFF ON OFF

72 OFF OFF OFF ON OFF OFF ON OFF

73 ON OFF OFF ON OFF OFF ON OFF

74 OFF ON OFF ON OFF OFF ON OFF

75 ON ON OFF ON OFF OFF ON OFF

76 OFF OFF ON ON OFF OFF ON OFF

77 ON OFF ON ON OFF OFF ON OFF

78 OFF ON ON ON OFF OFF ON OFF

79 ON ON ON ON OFF OFF ON OFF

80 OFF OFF OFF OFF ON OFF ON OFF

81 ON OFF OFF OFF ON OFF ON OFF

82 OFF ON OFF OFF ON OFF ON OFF

83 ON ON OFF OFF ON OFF ON OFF

84 OFF OFF ON OFF ON OFF ON OFF

85 ON OFF ON OFF ON OFF ON OFF

86 OFF ON ON OFF ON OFF ON OFF

87 ON ON ON OFF ON OFF ON OFF

88 OFF OFF OFF ON ON OFF ON OFF

89 ON OFF OFF ON ON OFF ON OFF

90 OFF ON OFF ON ON OFF ON OFF

91 ON ON OFF ON ON OFF ON OFF

92 OFF OFF ON ON ON OFF ON OFF

93 ON OFF ON ON ON OFF ON OFF

94 OFF ON ON ON ON OFF ON OFF

95 ON ON ON ON ON OFF ON OFF

96 OFF OFF OFF OFF OFF ON ON OFF

97 ON OFF OFF OFF OFF ON ON OFF

98 OFF ON OFF OFF OFF ON ON OFF

99 ON ON OFF OFF OFF ON ON OFF

100 OFF OFF ON OFF OFF ON ON OFF

101 ON OFF ON OFF OFF ON ON OFF

102 OFF ON ON OFF OFF ON ON OFF

103 ON ON ON OFF OFF ON ON OFF

104 OFF OFF OFF ON OFF ON ON OFF

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

105 ON OFF OFF ON OFF ON ON OFF

106 OFF ON OFF ON OFF ON ON OFF

107 ON ON OFF ON OFF ON ON OFF

108 OFF OFF ON ON OFF ON ON OFF

109 ON OFF ON ON OFF ON ON OFF

110 O FF O N ON ON OFF ON ON OFF

111 O N ON ON ON OFF ON ON OFF

112 O FF OFF OFF OFF ON ON ON OFF

113 ON OFF OFF OFF ON ON ON OFF

114 O FF O N OFF OFF ON ON ON OFF

115 ON ON OFF OFF ON ON ON OFF

116 O FF OFF ON OFF ON ON ON OFF

117 ON OFF ON OFF ON ON ON OFF

118 O FF O N ON OFF ON ON ON OFF

119 ON ON ON OFF ON ON ON OFF

120 OFF OFF OFF ON ON ON ON OFF

121 ON OFF OFF ON ON ON ON OFF

122 OFF ON OFF ON ON ON ON OFF

123 ON ON OFF ON ON ON ON OFF

124 OFF OFF ON ON ON ON ON OFF

125 ON OFF ON ON ON ON ON OFF

126 OFF ON ON ON ON ON ON OFF

127 ON ON ON ON ON ON ON OFF

128 OFF OFF OFF OFF OFF OFF OFF ON

129 ON OFF OFF OFF OFF OFF OFF ON

130 OFF ON OFF OFF OFF OFF OFF ON

131 ON ON OFF OFF OFF OFF OFF ON

132 OFF OFF ON OFF OFF OFF OFF ON

133 ON OFF ON OFF OFF OFF OFF ON

134 OFF ON ON OFF OFF OFF OFF ON

135 ON ON ON OFF OFF OFF OFF ON

136 OFF OFF OFF ON OFF OFF OFF ON

137 ON OFF OFF ON OFF OFF OFF ON

138 OFF ON OFF ON OFF OFF OFF ON

139 ON ON OFF ON OFF OFF OFF ON

140 OFF OFF ON ON OFF OFF OFF ON

141 ON OFF ON ON OFF OFF OFF ON

142 OFF ON ON ON OFF OFF OFF ON

143 ON ON ON ON OFF OFF OFF ON

144 OFF OFF OFF OFF ON OFF OFF ON

145 ON OFF OFF OFF ON OFF OFF ON

146 OFF ON OFF OFF ON OFF OFF ON

147 ON ON OFF OFF ON OFF OFF ON

148 OFF OFF ON OFF ON OFF OFF ON

149 ON OFF ON OFF ON OFF OFF ON

150 OFF ON ON OFF ON OFF OFF ON

151 ON ON ON OFF ON OFF OFF ON

152 OFF OFF OFF ON ON OFF OFF ON

153 ON OFF OFF ON ON OFF OFF ON

154 OFF ON OFF ON ON OFF OFF ON

155 ON ON OFF ON ON OFF OFF ON

156 OFF OFF ON ON ON OFF OFF ON

157 ON OFF ON ON ON OFF OFF ON

158 OFF ON ON ON ON OFF OFF ON

159 ON ON ON ON ON OFF OFF ON

160 OFF OFF OFF OFF OFF ON OFF ON

(Continued on next page)

12 Pelco Installation Manual C2429M (3/01)

Table E. Switch Settings for SW2 – D-Type Control (continued)

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

161 ON OFF OFF OFF OFF ON OFF ON

162 OFF ON OFF OFF OFF ON OFF ON

163 ON ON OFF OFF OFF ON OFF ON

164 OFF OFF ON OFF OFF ON OFF ON

165 ON OFF ON OFF OFF ON OFF ON

166 OFF ON ON OFF OFF ON OFF ON

167 ON ON ON OFF OFF ON OFF ON

168 OFF OFF OFF ON OFF ON OFF ON

169 ON OFF OFF ON OFF ON OFF ON

170 OFF ON OFF ON OFF ON OFF ON

171 ON ON OFF ON OFF ON OFF ON

172 OFF OFF ON ON OFF ON OFF ON

173 ON OFF ON ON OFF ON OFF ON

174 OFF ON ON ON OFF ON OFF ON

175 ON ON ON ON OFF ON OFF ON

176 OFF OFF OFF OFF ON ON OFF ON

177 ON OFF OFF OFF ON ON OFF ON

178 OFF ON OFF OFF ON ON OFF ON

179 ON ON OFF OFF ON ON OFF ON

180 OFF OFF ON OFF ON ON OFF ON

181 ON OFF ON OFF ON ON OFF ON

182 OFF ON ON OFF ON ON OFF ON

183 ON ON ON OFF ON ON OFF ON

184 OFF OFF OFF ON ON ON OFF ON

185 ON OFF OFF ON ON ON OFF ON

186 OFF ON OFF ON ON ON OFF ON

187 ON ON OFF ON ON ON OFF ON

188 OFF OFF ON ON ON ON OFF ON

189 ON OFF ON ON ON ON OFF ON

190 OFF ON ON ON ON ON OFF ON

191 ON ON ON ON ON ON OFF ON

192 OFF OFF OFF OFF OFF OFF ON ON

193 ON OFF OFF OFF OFF OFF ON ON

194 OFF ON OFF OFF OFF OFF ON ON

195 ON ON OFF OFF OFF OFF ON ON

196 OFF OFF ON OFF OFF OFF ON ON

197 ON OFF ON OFF OFF OFF ON ON

198 OFF ON ON OFF OFF OFF ON ON

199 ON ON ON OFF OFF OFF ON ON

200 OFF OFF OFF ON OFF OFF ON ON

201 ON OFF OFF ON OFF OFF ON ON

202 OFF ON OFF ON OFF OFF ON ON

203 ON ON OFF ON OFF OFF ON ON

204 OFF OFF ON ON OFF OFF ON ON

205 ON OFF ON ON OFF OFF ON ON

206 OFF ON ON ON OFF OFF ON ON

207 ON ON ON ON OFF OFF ON ON

208 OFF OFF OFF OFF ON OFF ON ON

Receiver Switch Setting

Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8

209 ON OFF OFF OFF ON OFF ON ON

210 OFF ON OFF OFF ON OFF ON ON

211 ON ON OFF OFF ON OFF ON ON

212 OFF OFF ON OFF ON OFF ON ON

213 ON OFF ON OFF ON OFF ON ON

214 OFF ON ON OFF ON OFF ON ON

215 ON ON ON OFF ON OFF ON ON

216 OFF OFF OFF ON ON OFF ON ON

217 ON OFF OFF ON ON OFF ON ON

218 OFF ON OFF ON ON OFF ON ON

219 ON ON OFF ON ON OFF ON ON

220 OFF OFF ON ON ON OFF ON ON

221 ON OFF ON ON ON OFF ON ON

222 OFF ON ON ON ON OFF ON ON

223 ON ON ON ON ON OFF ON ON

224 OFF OFF OFF OFF OFF ON ON ON

225 ON OFF OFF OFF OFF ON ON ON

226 OFF ON OFF OFF OFF ON ON ON

227 ON ON OFF OFF OFF ON ON ON

228 OFF OFF ON OFF OFF ON ON ON

229 ON OFF ON OFF OFF ON ON ON

230 OFF ON ON OFF OFF ON ON ON

231 ON ON ON OFF OFF ON ON ON

232 OFF OFF OFF ON OFF ON ON ON

233 ON OFF OFF ON OFF ON ON ON

234 OFF ON OFF ON OFF ON ON ON

235 ON ON OFF ON OFF ON ON ON

236 OFF OFF ON ON OFF ON ON ON

237 ON OFF ON ON OFF ON ON ON

238 OFF ON ON ON OFF ON ON ON

239 ON ON ON ON OFF ON ON ON

240 OFF OFF OFF OFF ON ON ON ON

241 ON OFF OFF OFF ON ON ON ON

242 OFF ON OFF OFF ON ON ON ON

243 ON ON OFF OFF ON ON ON ON

244 OFF OFF ON OFF ON ON ON ON

245 ON OFF ON OFF ON ON ON ON

246 OFF ON ON OFF ON ON ON ON

247 ON ON ON OFF ON ON ON ON

248 OFF OFF OFF ON ON ON ON ON

249 ON OFF OFF ON ON ON ON ON

250 OFF ON OFF ON ON ON ON ON

251 ON ON OFF ON ON ON ON ON

252 OFF OFF ON ON ON ON ON ON

253 ON OFF ON ON ON ON ON ON

254 OFF ON ON ON ON ON ON ON

Pelco Installation Manual C2429M (3/01) 13

SPECIFICATIONS

MECHANICAL

Construction

Back box: Aluminum
Dome drive: Aluminum, ABS plastic
Lower dome: Acrylic

Cable Entry

In-Ceiling: .75-inch (1.91 cm) conduit fitting
Pendant: Through 1.5-inch (3.81 cm) NPT pendant mount

Pan Movement: 360° continuous pan rotation

Ver tical Tilt: Unobstructed +2° to -92°

Manual Pan/Tilt Speeds*

Pan

Spectra II: 0.1-80°/sec manual operation, 150°/sec turbo
Spectra Lite: 0.5-80°/sec manual operation, 150°/sec turbo

Tilt

Spectra II: 0.1-40°/sec
Spectra Lite: 0.5-40°/sec

Preset Speeds

Pan: 250°/sec
Tilt: 200°/sec

* For variable-speed operation an appropriate controller is required. With fixed-speed controllers, Spectra II and Spectra Lite pan/tilt

speed is 24°/sec. The CM6700 controller with the KBD200 keyboard has programmable fixed speeds.

ELECTRICAL

Input Voltage: 18-30 VAC, 24 VAC nominal

Input Power

In-ceiling: 30 vA
Indoor pendant: 30 vA
Outdoor pendant: 75 vA

Fuse: 1.6 A

Relay Contacts

Type: Form C Open collector transistor output
Voltage: Low voltage (<40 V) 32 VDC maximum
Current: 2 A maximum 150 mA maximum

AUX 1 AUX 2 Output

14 Pelco Installation Manual C2429M (3/01)

GENERAL

Environment

In-Ceiling: Indoor only
Pendant: Indoor/outdoor

Operating Range

In-Ceiling: 32 to 140°F (0 to 60°C) intermittent operation; 32 to 122°F (0 to 50°C) continuous operation
Pendant

Without Heater: 32 to 140°F (0 to 60°C) absolute maximum operating temperature; 32 to 122°F (0 to 50°C) sustained

maximum operating temperature

With Heater: (Assumes no wind chill factor; for detailed test conditions, contact Pelco.)

Maximum operating temperature: 140°F (60°C) absolute maximum; 122°F (50°C) sustained maximum
Minimum operating temperature: -60°F (-51.11°C) absolute minimum; minimal icing at -50°F (-45.56°C)
sustained minimum; prevents icing at -40°F (-40°C) sustained minimum; de-ices .1 inch (2.5 mm) within
3 hours after power-up

Dimensions: See Figure 1

Ratings: NEMA Type 1–In-ceiling back boxes, all dome drives

NEMA Type 4X–Pendant back boxes
IP 66–Pendant back boxes

Weight

Unit

Back Box

In-ceiling: 2.17 lb (.98 kg)
Pendant Indoor: 4.45 lb (2.02 kg)

Outdoor Pendant: 4.75 lb (2.15 kg)
Dome Drive: 2.6 lb (1.18 kg)
Lower Dome

In-ceiling: 1.6 lb (.73 kg)

In-ceiling w/cage:

Pendant: 1.83 lb (.83 kg)

Pendant w/cage:

(Design and product specifications subject to change without notice.)

.060

.125

7.5

(19.05)

10.1

(25.65)

fl 6.13

(

fl 15.57)

NOTE: VALUES IN PARENTHESES ARE CENTIMETERS;

ALL OTHERS ARE INCHES

9.70

(24.64)

Figure 1. Dimension Drawing

Pelco Installation Manual C2429M (3/01) 15

PRODUCT WARRANTY AND RETURN INFORMATION

WARRANTY

Pelco will repair or replace, without charge, any merchandise proved defective in material or
workmanship for a period of one year after the date of shipment.

Exceptions to this warranty are as noted below:

• Five years on FT/FR8000 Series fiber optic products.

®

• Three years on Genex

• Three years on Camclosure® and fixed camera models, except the CC3701H-2,
CC3701H-2X, CC3751H-2, CC3651H-2X, MC3651H-2, and MC3651H-2X camera models,
which have a five-year warranty.

•Two years on standard motorized or fixed focal length lenses.

•Two years on Legacy
fixed dome products.

•Two years on Spectra
continuous motion applications.

•Two years on Esprit

• Eighteen months on DX Series digital video recorders, NVR300 Series network video
recorders, and Endura

• One year (except video heads) on video cassette recorders (VCRs). Video heads will be
covered for a period of six months.

• Six months on all pan and tilts, scanners or preset lenses used in continuous motion
applications (that is, preset scan, tour and auto scan modes).

Pelco will warrant all replacement parts and repairs for 90 days from the date of Pelco
shipment. All goods requiring warranty repair shall be sent freight prepaid to Pelco, Clovis,
California. Repairs made necessary by reason of misuse, alteration, normal wear, or accident
are not covered under this warranty.

Pelco assumes no risk and shall be subject to no liability for damages or loss resulting from
the specific use or application made of the Products. Pelco’s liability for any claim, whether
based on breach of contract, negligence, infringement of any rights of any party or product
liability, relating to the Products shall not exceed the price paid by the Dealer to Pelco for
such Products. In no event will Pelco be liable for any special, incidental or consequential
damages (including loss of use, loss of profit and claims of third parties) however caused,
whether by the negligence of Pelco or otherwise.

The above warranty provides the Dealer with specific legal rights. The Dealer may also have
additional rights, which are subject to variation from state to state.

Series products (multiplexers, server, and keyboard).

®

, CM6700/CM6800/CM9700 Series matrix, and DF5/DF8 Series

®

, Esprit®, ExSite™, and PS20 scanners, including when used in

®

and WW5700 Series window wiper (excluding wiper blades).

™

Series distributed network-based video products.

If a warranty repair is required, the Dealer must contact Pelco at [phone] or
[phone] to obtain a Repair Authorization number (RA), and provide the following
information:

1. Model and serial number

2. Date of shipment, P.O. number, Sales Order number, or Pelco invoice number

3. Details of the defect or problem

If there is a dispute regarding the warranty of a product which does not fall under the
warranty conditions stated above, please include a written explanation with the product
when returned.

Method of return shipment shall be the same or equal to the method by which the item was
received by Pelco.

RETURNS

In order to expedite parts returned to the factory for repair or credit, please call the factory at
[phone] or [phone] to obtain an authorization number (CA number if returned
for credit, and RA number if returned for repair).

All merchandise returned for credit may be subject to a 20% restocking and refurbishing
charge.

Goods returned for repair or credit should be clearly identified with the assigned CA or RA
number and freight should be prepaid. Ship to the appropriate address below.

If you are located within the continental U.S., Alaska, Hawaii or Puerto Rico, send goods to:

Service Department
Pelco
3500 Pelco Way
Clovis, CA 93612-5699

If you are located outside the continental U.S., Alaska, Hawaii or Puerto Rico and are
instructed to return goods to the USA, you may do one of the following:

If the goods are to be sent by a COURIER SERVICE, send the goods to:

Pelco
3500 Pelco Way
Clovis, CA 93612-5699 USA

If the goods are to be sent by a FREIGHT FORWARDER, send the goods to:

Pelco c/o Expeditors
473 Eccles Avenue
South San Francisco, CA 94080 USA
Phone: [phone]
Fax: [phone]

Pelco, the Pelco logo, Camclosure, Esprit, Genex, Legacy, and Spectra are registered trademarks of Pelco.

Endura and ExSite are trademarks of Pelco.

Loctite is a registered trademark of Loctite Corporation.

©Copyright 2000, Pelco. All rights reserved.

U.S. Patent No. 5,931,432.

REVISION HISTORY

Manual # Date Comments

C2429M 3/01 Original version.

16 Pelco Installation Manual C2429M (3/01)
