PLUS 100 PAN CONTROL SYSTEM FOR DOUGH-RETARDES
REV. 01/04
READ AND KEEP
Use and maintenance manual
ELECTRICAL BOARDS FOR REFRIGERATING INSTALLATIONS
REV. 01-16
ENG
PLUS 100 PAN
REV. 01/04
PLUS 100 PAN
Pag. 3
USE AND MAINTENANCE MANUAL
Rev. 01-16
INTRODUCTION
Page 4 1.1 General
Page 4 1.2 Product ID codes
Page 5 1.3 Overall dimensions
Page 5 1.4 Identification data
INSTALLATION
Page 6 2.1 Important information for installer
Page 6 2.2 Standard assembly and use kit
FUNCTIONS
Page 7 3.1 Functions managed by the PLUS 100 PAN
TECHNICAL CHARACTERISTICS
Page 8 4.1 Technical characteristics
Page 9 4.2 Warranty terms
PARAMETER PROGRAMMING
Page 10 5.1 Control panel
Page 11 5.2 LCD display
Page 12 5.3 General features
Page 12 5.4 Key to symbols
Page 12 5.5 Setting and displaying the set-points
Page 13 5.6 Level 1 programming
Page 14 5.7 List of Level 1 variables
Page 15 5.8 Level 2 programming
Page 16 5.9 List of Level 2 variables
USING THE UNIT
Page 18 6.1 Cold/hot: maintaining room temperature
Page 18 6.2 Humidifying/dehumidifying: maintaining room humidity
Page 19 6.3 Ventilation
Page 19 6.4 Air changeover
Page 19 6.5 Clock / calendar
Page 20 6.6 Manual cycles
Page 21 6.7 Automatic cycles
Page 25 6.8 Supervision/monitoring system TeleNET
TROUBLESHOOTING
Page 26 7.1 Alarms: description and procedures
Page 27 7.2 Troubleshooting guide
APPENDICES
Page 29 A.1 EC declaration of conformity
Page 30 A.2 PLUS 100 PAN connections diagram
CONTENTS
CHAP. 1
CHAP. 2
CHAP. 3
CHAP. 4
CHAP. 5
CHAP. 6
CHAP. 7
PLUS 100 PAN
Pag. 4
USE AND MAINTENANCE MANUAL
Rev. 01-16
GENERAL
The PLUS 100 PAN system allows the user to control temperature and humidity. The
system consists of the 100 MASTER unit, on which all the electrical connections are
made, and the PLUS 100 PAN control panel, which features a large LCD display to
provide rapidly available, complete information on room status. The system allows the user
to cool, heat and ventilate the room, switch the room light on/off, humidify it, effect an air
changeover, dehumidify it, defrost it and control alarms.
PRODUCT ID CODES
PLUS100 PAN ……………………………. control of temperature and humidity for
pause-leavening applications.
CHAPTER 1: INTRODUCTION
CHAP. 1 - Introduction
PLUS 100 PAN
Pag. 5
USE AND MAINTENANCE MANUAL
Rev. 01-16
OVERALL DIMENSIONS
IDENTIFICATION DATA
The unit described in this manual has, on its side, an ID plate showing all the relevant
identification data:
• Name of Manufacturer
• Code and model of electrical board
• Serial number
• IP protection rating
• Power supply voltage
CHAP. 1 - Introduction
PLUS 100 PAN
Pag. 6
USE AND MAINTENANCE MANUAL
Rev. 01-16
IMPORTANT INFORMATION FOR THE INSTALLER
1. Install the device in places where the protection rating is observed and try not to
damage the box when drilling holes for wire/pipe seats.
2. Do not use multi-polar cables in which there are wires connected to inductive/power
loads or signalling wires (e.g. probes/sensors and digital inputs).
3. Do not fit power supply wiring and signal wiring (probes/sensors and digital inputs) in
the same raceways or ducts.
4. Minimise the length of connector wires so that wiring does not twist into a spiral shape
as this could have negative effects on the electronics.
5. Fit a general protection fuse upstream from the electronic controller.
6. All wiring must be of a cross-section suitable for relevant power levels.
7. When it is necessary to make a probe/sensor extension, the wires must be of the
correct cross-section, which in any case must be at least 1 mm2.
STANDARD ASSEMBLY AND USE KIT
The PLUS 100 PAN system is supplied with the following assembly and utilisation items:
n°2 temperature sensors
n°1 fixing bracket
n°1 telephone plug lead
n°1 user’s manual
CHAPTER 2: INSTALLATION
CHAP. 2 - Installation
PLUS 100 PAN
Pag. 7
USE AND MAINTENANCE MANUAL
Rev. 01-16
FUNCTIONS CONTROLLED BY THE PLUS 100 PAN
- Display and adjustment of temperature and humidity settings (neutral zone).
- Activation/deactivation of stand-by mode.
- Sensor alarm/warning signals.
- Adjustment of differential temperature and humidity parameters.
- Adjustment of air changeover control parameters.
- Adjustment of defrosting parameters.
- Adjustment of fan parameters.
- Display of output status.
- Simultaneous display of temperature and humidity values.
- Automatic program management with automatic variation of temperature and humidity
settings over time.
- Clock function
CHAP. 3 - Functions
CHAPTER 3: FUNCTIONS
PLUS 100 PAN
Pag. 8
USE AND MAINTENANCE MANUAL
Rev. 01-16
TECHNICAL CHARACTERISTICS
Power supply
Voltage
230 V~ 10% 50 Hz
MAX power absorption
~ 8 VA
Climatic conditions
Working temperature
-10 - 60°C
Storage temperature
-30 - 70°C
Relative humidity
below 90% RH
Input characteristics
Analogical inputs
NTC 10K 1% Temperature sensor
4…20 mA Humidity sensor
Read resolution
1°C Temperature
1 RH% Humidity
Sensor read precision
0.5 °C
see characteristics of humidity sensor
Read range
-45…+45 °C
0…99 RH%
Output characteristics
Outputs on relay
1 output on terminal N.A. 30A (AC1) 230 V AC
9 outputs on terminal N.A. 16A (AC1) 230 V AC
Dimensional characteristics
100 MASTER box dimensions (mm)
121,5 x 71 x 175 (HxDxL)
PLUS PAN keypad box (mm)
98 x 35 x 180 (HxDxL)
Insulation characteristics
Keypad protection rating
IP55
CHAP. 4 – Technical characteristics
CHAPTER 4: TECHNICAL CHARACTERISTICS
PLUS 100 PAN
Pag. 9
USE AND MAINTENANCE MANUAL
Rev. 01-16
WARRANTY CONDITIONS
PLUS 100 series electronic controllers are covered by a 24-month warranty against all
manufacturing defects as from the date indicated on the product ID code or from the date
of product registration card, if present.
In the event of a defect the product must be appropriately packaged and sent to our
factory or any authorized Service Center by authority RMA number received.
Customers are entitled to have defective products repaired, spare parts and labour
included. Transport expenses and risk shall be met entirely by the customer.
Repairs carried out under warranty do not prolong or renew the warranty expiration date.
The Warranty does not cover:
Damages resulting from tampering, impact or improper installation of humidifier and
its accessories.
Behaviour inconsistent with Manufacturer’s prescriptions and instructions.
Damages caused by repairs made by unauthorized persons.
Damages caused by natural phenomena as lightning, natural calamities, etc.
Warranty cover may be refused if the device is modified or changed.
Under no circumstances Pego S.r.l. will be responsible for possible loss of data and
information, costs of substitutive goods or services, damages to things, people or animals,
non-sale or non-gain, activity interruption, possible direct, indirect, accidental, property,
covering, punitive, special or consequential damages anyhow caused, whether they are
contractual, extra-contractual or due to negligence or other responsibility, derived from
product use or from its installation.
The wrong machine working caused by manumissions, shoves, inadequate installation
automatically forfeits the warranty right. It is compulsory to respect all information of this
user manual and device operating conditions.
PEGO S.r.l. declines any responsibility for possible errors or inaccuracies written in this
manual as a result of printing or transcription errors.
PEGO S.r.l. reserves the right to modify its products as it deems necessary without
altering its main characteristics.
Each new release of a PEGO user manual replaces all the previous ones.
However not expressly indicated, the warranty follows the laws in force and particularly the
section 1512 C.C. (Italian Civil Code)
For any controversy is elected by the parties and recognized the jurisdiction of the Court of
Rovigo.
CHAP. 4 – Technical characteristics
PLUS 100 PAN
Pag. 10
USE AND MAINTENANCE MANUAL
Rev. 01-16
6 7 8 1 2 3 4
5
CONTROL PANEL
1. LCD display.
2. Automatic cycle progress bar.
3. Cycle START/STOP (hold for a few seconds to start or stop an automatic cycle) /
Timer (press once to show day and time of end of cycle in progress).
4. UP (Automatic cycle programming).
5. Stand-by (system at standstill, does not interrupt cycle in progress).
6. SET temperature / SET humidity (press successively to alternate temperature and
humidity).
7. DOWN, forced defrosting, alarm mute.
8. Room light.
CHAP. 5 - Parameter programming
CHAPTER 5: PARAMETER PROGRAMMING
PLUS 100 PAN
Pag. 11
USE AND MAINTENANCE MANUAL
Rev. 01-16
LCD DISPLAY
1. Progress of PHASE 1 (cooling duration set by final user, physically occupies
sectors n° 1, 2, 3, 4, 5).
2. Progress of PHASE 2 (maintenance, so-called elastic phase, physically occupies
sectors n° 6, 7, 8, 9, 10).
3. Progress of PHASE 3 (leavening, duration set by final user, physically occupies
sectors n° 11, 12, 13, 14, 15, 16).
4. Progress of PHASE 4 (product ready settling, max. duration 4 hours, occupies the
last sectors n° 17, 18, 19, 20).
5. Relative ambient humidity / parameter values / error codes.
6. Ambient temperature / parameter values.
7. Programming (controller is in programming mode).
8. Cooling (flashes if called for dehumidification only).
9. Heating (flashes if called for dehumidification only).
CHAP. 5 - Parameter programming
7 1 2 3 4 5 6 8 9
10
11
12
13
14
15
16
17
PLUS 100 PAN
Pag. 12
USE AND MAINTENANCE MANUAL
Rev. 01-16
10. Humidification.
11. Dehumidification.
12. Defrosting.
13. Evaporator fans (both high and low speed).
14. Light.
15. Alarm.
16. Stand-by (light on continuously - controller ON, light flashing, controller in STANDBY).
17. Time / date / time parameter values.
GENERAL
To enhance safety and simplify the operator’s work, the PLUS 100 PAN system has two
programming levels; the first level (Level 1) is used to configure the frequently-modified
SET-POINT parameters. The second programming level (Level 2) is for general parameter
programming of the various controller work modes.
It is not possible to access Level 2 programming directly from Level 1: you must exit the
programming mode first.
KEY TO SYMBOLS
For purposes of practicality the following symbols are used:
• () the UP key is used to increase values and in programming the cycles;
• () the DOWN key is used to decrease values and mute the alarm.
SETTING AND DISPLAYING THE SET-POINTS
1. Press the SET key to display the current SET-POINT (temperature or humidity).
2. Hold down the SET key and press the () or () keys to modify the SET-POINT.
3. Release the SET key to return to room temperature display: the new setting will be
saved automatically.
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 13
USE AND MAINTENANCE MANUAL
Rev. 01-16
LEVEL 1 PROGRAMMING (User level)
To gain access to the Level 1 configuration menu proceed as follows:
1. Press the () and () keys simultaneously and keep them pressed for a few seconds
until the first programming variable appears on the display.
2. Release the () and () keys.
3. Select the variable to be modified using the () or () key.
4. When the variable has been selected it is possible:
• Display the setting in the respective sector of the display (5 or 17 page 11)
• To modify the setting by pressing the SET key and the () or () keys.
When configuration values have been set you can exit the menu by pressing the () and
() keys simultaneously for a few seconds until the room temperature reappears;
alternatively, do not press any key for a few seconds.
5. The new settings are saved automatically when you exit the configuration menu.
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 14
USE AND MAINTENANCE MANUAL
Rev. 01-16
LIST OF LEVEL 1 VARIABLES (User level)
LABEL
MEANING
RANGE
DEFAULT
d-t
Temperature difference compared to main
SET-POINT
1÷10 °C
2°C
d-U
Differential for Humidification compared to
main SET-POINT
1÷10 rH%
5 rH%
d-d
Differential for Dehumidification compared to
main SET-POINT
1÷10 rH%
5 rH%
d0
Air changeover interval (parameter only active
during the leavening phases)
00…24
hours
0:00
d1
Air changeover duration (parameter only
active during the leavening phases)
1….60 min
6 min
d4
Defrosting interval, interval between one
defrosting and the next
d4=0 no defrosting. (parameter only active
during cooling and maintenance stages
0..24 hours
8 hours
d5
Max defrost duration time
1..60 min
20 min
d6
End of defrosting temperature SET-POINT.
Defrosting is not executed if the temperature
read by the defrosting sensor is higher than the
end of defrosting setting.
(in the event of a faulty sensor defrosting is
timed)
-35 ÷ 45 °C
12°C
F5
Fan stop time (Expressed in minutes)
At the end of defrosting the fans can be kept at
standstill for a further set time. This time begins
at the end of defrosting (parameter active only
in the cooling and maintenance phases)
0 - 10 min’
2 min
F6
Fan shutdown temperature. (Expressed in °C.)
At the end of defrosting or at start-up the fans
can be kept at standstill until the evaporator
sensor temperature setting is reached.
(parameter active only in the cooling and
maintenance phases)
-20 ÷ 30 °C
23 °C
tEu
Defrosting sensor temperature display
(evaporator)
--
Read only
DMy
Current date
dd:mm:yy
HMS
Current time
0:00 .. 23:59
hh:mm
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 15
USE AND MAINTENANCE MANUAL
Rev. 01-16
LEVEL 2 PROGRAMMING (Installer level)
To access the second programming level press the UP () and DOWN () keys and the
LIGHT key simultaneously for a few seconds.
When the first programming variable appears the system automatically goes to stand-by.
1. Select the variable to be modified by pressing the UP () and DOWN () keys.
When the parameter has been selected it is possible to:
2. View the setting in the respective sector of the display (5 or 17, page 11).
3. Modify the setting by holding the SET key down and pressing the () or () key.
4. When configuration settings have been completed you can exit the menu by pressing
the () and () keys simultaneously and keeping them pressed until the room
temperature value reappears.
Exit from Level 2 is not automatic, even if keys are left untouched for a long time.
5. Changes are saved automatically when you exit the configuration menu.
6. To enable the electronic controller press the STAND-BY key .
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 16
USE AND MAINTENANCE MANUAL
Rev. 01-16
LIST OF LEVEL 2 VARIABLES (Installer level)
LABEL
MEANING
RANGE
DEFAULT
AC
Door switch input status
0= NO
1= NC
0
C1
Minimum time between
compressor shutdown and
subsequent switching on
0...15 min
0 min
Ad
Network address for connection
to the TeleNET system
031
0
dEU
Dehumidification mode select.
Separate dehumidification calls
heat/cold by temperature only
0= cooling
1=heating
2= separated dehumid.
2
EnU
Humidification enable
1= enabled
0= disabled
Humidification control only
executed during leavening
and settling phases.
1
End
Dehumidification enable
1= enabled
0= disabled
Humidification control only
executed during leavening
and settling phases.
1
CAt
Ambient sensor value correction
-10…+10 °C
0 °C
CAU
Humidity sensor value
correction
-20…+20 rH%
0 rH%
St1
First leavening step temperature
set-point
0…+45 °C
5 °C
SU1
First leavening step humidity setpoint
50…99 rH%
(50%=humidity not
controlled)
85 rH%
t1
First leavening step duration
hh:mm
00:00…2:00 hh:mm
00:30
St2
Second leavening step
temperature set-point
0…+45 °C
10 °C
SU2
Second leavening step humidity
set-point
50…90 rH%
(50%= humidity not
controlled)
80 rH%
t2
Second leavening step duration
hh:mm
00:00…2:00 hh:mm
00:30
St3
Third leavening step temperature
set-point
0…+45 °C
16 °C
SU3
Third leavening step humidity setpoint
50…99 rH%
(50%= humidity not
controlled)
80 rH%
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 17
USE AND MAINTENANCE MANUAL
Rev. 01-16
t3
Third leavening step duration
hh:mm
00:00…2:00 hh:mm
00:30
St4
Fourth leavening step
temperature set-point
0…+45 °C
16 °C
SU4
Fourth leavening step humidity
set-point
50…99 rH%
(50%= humidity not
controlled)
80 rH%
t4
Fourth leavening step duration
hh:mm
00:00…2:00 hh:mm
00:00
St5
Fifth leavening step temperature
set-point
0…+45 °C
16 °C
SU5
Fifth leavening step humidity setpoint
50…90 rH%
(50%= humidity not
controlled)
80 rH%
t5
Fifth leavening step duration
hh:mm
00:00…2:00 hh:mm
00:00
Hr
Humidity control
Hr = 1 humidity control
enabled
Hr= 0 humidity control
disabled. Humidity sensor
can be disconnected
without error, the display
shows evaporator sensor
instead of humidity (if
dE=0)
1
dE
Evaporator sensor exclusion
0 = sensor present
1 = sensor absent
0
EnC
Enables cold (cooling) during
manual, automatic leavening and
settling.
0 = cold disabled
1 = cold enabled
1
Str
Settling phase temperature setpoint
0…+45 °C
12 °C
SUr
Settling phase humidity set-point
50…99 rH%
80 rH%
d9
Defrost enable during cooling
0 = defrosting disabled
1 = defrosting enabled
0
CHAP. 5 - Parameter programming
PLUS 100 PAN
Pag. 18
USE AND MAINTENANCE MANUAL
Rev. 01-16
COLD/HEAT: MAINTAINING AMBIENT TEMPERATURE
Heating/cooling is neutral-zone controlled on the basis of the temperature set-point (key 6
) and the temperature differential (parameter d-t).
Cooling is activated when the set + differential threshold is passed and stays on until the
set-point is reached.
Heating is activated when the setting – differential threshold is reached and stays on until
the set-point is reached.
HUMIDIFICATION/DEHUMID.: MAINTAINING AMBIENT HUMIDITY
Humidity and dehumidification are neutral-zone controlled during the leavening,
maintenance and settling phases only, and only if the programmed set-point is greater
than the settable minimum *(50%) on the basis of the humidity set-point (key 6 ) and
the differential for Humidification (parameter d-U) and differential for Dehumidification
(parameter d-d).
Humidification is activated below the set – differential for Humidification (parameter d-
U) threshold and stays on until the set-point is reached.
Dehumidification is activated above the set + differential for Dehumidification
(parameter d-d) threshold and stays on until the set-point is reached.
Humidity control can be disabled via the Hr (relative humidity) parameter, or by setting the
set point to the minimum R.H.% 50 = humidity control disabled (display only).
Dehumidification alone be disabled via the End parameter.
Humidification alone can be disabled via the EnU parameter.
There are three dehumidification modes (dEU parameter):
1. Dehumidification with cooling (cold is called to dehumidify, heat is added only to
maintain ambient temperature).
2. Dehumidification with heating (heat is called to dehumidify, cold is added only to
maintain ambient temperature).
If the difference in temperature is, with respect to the setting, greater than 5°C
(during dehumidification with the compressor and elements) 5°C, the unit with the
CHAPTER 6: USING THE UNIT
CHAP. 6 - Using the unit
PLUS 100 PAN
Pag. 19
USE AND MAINTENANCE MANUAL
Rev. 01-16
greater value shuts down to prevent any overheating or over-cooling which could
damage the product.
3. Separated dehumidification (dehumidification output activated only but without
cold/heat call).
(*) if the humidity set point is set to the minimum (50%) neither dehumidification nor
humidification are controlled
VENTILATION
Fan speed is regulated by two digital outputs (high/low speed) and run at high speed with
the cold call during the cooling and maintenance phases and continuously at low speed
during the leavening and settling phases.
Fans are always off during defrosting.
Variants can be controlled via parameters F5 and F6.
AIR CHANGEOVER
Air changeover is controlled via parameters d0 and d1.
Use d0 to establish the interval between one air changeover and another: the counter
starts its count from zero at the start of every manual or automatic leavening cycle. If d0 =
00 no air changeover is carried out.
Use d1 to establish the duration of the air changeover.
Cooling, heating, humidification and dehumidification are not activated during air
changeover.
CLOCK / CALENDAR
Current time and date can be adjusted via the dMY and HMS parameters.
The current time is shown on the LCD display.
CHAP. 6 - Using the unit
PLUS 100 PAN
Pag. 20
USE AND MAINTENANCE MANUAL
Rev. 01-16
MANUAL CYCLES
The controller recognises the manual cycles (only hot or only cold) from the temperature
setting only when in stop mode, not in stand-by.
If the set-point is less than or equal to 10°C the controller recognises the manual cold
cycle. It will consequently run the fans simultaneously with the compressor call and
execute the programmed defrosts as per the parameter settings; humidity control will not
be executed.
If the set-point is higher than 10°C the controller recognises the manual hot cycle.
Consequently the fans are run continuously, humidity is controlled according to the RH%
setting and the defrost cycles are not executed.
PLUS 100 PAN
Pag. 21
USE AND MAINTENANCE MANUAL
Rev. 01-16
AUTOMATIC CYCLES
It is possible to set four automatic pause-leavening cycles each with fully independent
automatic programmed leavening, and a maintenance-only cycle (riC 0) with cooling start.
The four cycles have the following characteristics: cycle n°1 is carried out the same day
(12 hrs); cycle n°2 is for the next day (24 hrs); cycle 3 for the second successive day (48
hrs); and cycle 4 for the third successive day after the (72 hrs).
To enter the recipes programming mode press key 4 until the letters riC appear on
the temperature display and the numbers 01 … 04 on the RH% display. Use keys 4
and 7 to select the recipe to be programmed, press key 3 to enter
programming mode for the selected recipe. The 20 segments at the top of the unit should
all be off: only one of the first four will remain on to remind you of the recipe you are
programming. To program the data proceed as follows:
1. Use the () or () key to select the variable to be modified. After selecting the desired
variable it will be possible to:
2. View the value on the respective sector of the display (5 or 17 page 11).
3. Modify the setting by pressing or maintaining the SET key and pressing the ()
or () key.
Exit programming mode [from the product ready day window (LI6)] by keeping key 4
pressed for 2 seconds; in any case the unit will exit programming mode if no keys are
touched for 30 seconds.
CHAP. 6 - Using the unit
PLUS 100 PAN
Pag. 22
USE AND MAINTENANCE MANUAL
Rev. 01-16
CYCLE PROGRAMMING DATA:
DISPLAY
TEMP.
DISPLAY RH%
DISPLAY TIME
Default
recipe 1
Default
recipe 2
AC1
Cooling temperature
-20°C…..0°C.
Off
-7
-10
AC2
Off
Cooling time
00:00:00….29:59:00
04:00:00
05:00:00
Co1
Maintenance
temperature
-5°C…..15°C.
Off
-2
-4
Co2
Hr% Maintenance
50%….99.0%
Off
50
50
Li1
Final leavening
temp.
10°C…..+45°C.
Off
27
30
Li2
Off
Leavening duration
t1+t2+t3+t4+t5..09:59:00
04:00:00
05:00:00
Li3
Final leavening
RH% 50%….99.9%
Off
80
85
Li4
Off
Product ready time
00:00….23:59:00
02:00:00
02:30:00
Li5
End-of-cycle settling
1=Yes .… 0=No
Off 0 0
Li6
Off
Product ready day
01:01:04….31:12:99 (read
only)
/
/
N.B. the 00 cycle is dedicated to a cool-only cycle that consists of an initial cooling phase
followed by a switch to maintenance for an indefinite period; the programmable data items
for this recipe are therefore AC1; AC2; Co1; Co2.
Once programming has been completed you can start a cycle by pressing key 3
for a few seconds. The display asks which recipe is to be used (riC 00 … riC 04).
Select the desired recipe via the up/down keys: when key 3 is pressed again the
product ready (oven-ready) time and day are displayed for 5 seconds. If the shown data is
correct there is no need to carry out any further tasks and the controller makes subsequent
checks and then starts the cycle. If, however, the data is incorrect stop the cycle by
pressing key 3 , enter the recipe, modify the incorrect data and restart the cycle.
The controller makes a quick calculation to see if the cycle duration time is
compatible with the “product ready” time and day. If everything is compatible the cycle
begins and the first segment lights up. If, instead, there are incompatibilities the controller
goes to stand-by, the buzzer sounds and the EP message appears on the display to
CHAP. 6 - Using the unit
PLUS 100 PAN
Pag. 23
USE AND MAINTENANCE MANUAL
Rev. 01-16
indicate erroneous programming. To switch off the buzzer press key 7 . The
progress of the cycle is highlighted at the top of the unit as follows:
Phase 1: cooling n° 5 segments;
Phase 2 maintenance n° 5 segments;
Phase 3 leavening n° 6 segments;
Phase 4 settling (where enabled) n° 4 segments.
If a settling phase is enabled sector 19 will light up at the cycle START to remind the user
that, when the product ready time is reached, the cycle will be completed by a settling
phase. It goes off at the start of the settling phase (i.e. when segment n° 17 lights up).
While a complete cycle is being carried out the number of the recipe “riC 01” can
be viewed on the RH% display and the baking day/time displayed alternately on the clock
display (17) for a few seconds by pressing key 3 briefly. While a complete cycle is in
progress you can view and modify the recipe in use by pressing key 4 for 2
seconds: you can vary temperature and humidity but not the duration times of the
different stages.
At the end of the final leavening cycle (if settling is not enabled) the controller goes
to stand by. The buzzer sounds and the segment bar flashes to indicate that the cycle is
over. Buzzing/flashing stops automatically after 1 minute or when key 7 is pressed.
The user can vary temperature and humidity set-points alternately at any time
during the active cycle (manual heat/cool cycles included) via key 6 : note, however,
that during a complete cycle variation of the set-point is relative to the phase in progress.
The first phase is known as cooling (cold is produced and “accumulated”). If the recipe has
a cooling time of 0:00 the controller immediately goes to the maintenance phase at the
start if the cycle.
There then follow: maintenance, intermediate leavening, final leavening and (where
enabled) settling.
N.B. the end of the cycle (Li4 - product ready time) is defined by the end of the final
leavening phase, not the settling cycle.
PLUS 100 PAN
Pag. 24
USE AND MAINTENANCE MANUAL
Rev. 01-16
The cooling phase is characterised by:
Temperature set-point
Duration of the phase
The maintenance phase is characterised by:
Temperature set-point
Humidity set-point
The leavening phase is characterised by:
Temperature set-point
Humidity set-point
Duration of the intermediate leavening phases via 2nd level parameters and overall
leavening duration programmed by final user. N.B. overall leavening duration can
never be less than the sum of the 5 parameter-programmed steps.
The settling phase is characterised by:
Duration in hours (2nd level parameter)
Temperature set-point (2nd level parameter)
Humidity set-point (2nd level parameter)
If a phase has time 0, it is not executed and the controller goes to the next phase.
Phase times continue even in the event of an electrical power failure or controller stand-by.
When an automatic cycle is in progress it is possible to check the number of the cycle in
use and the in-oven day / time by briefly pressing key 3 (CYCLE START); sector 17
of the display (DATE TIME) shows first day and then time.
PLUS 100 PAN
Pag. 25
USE AND MAINTENANCE MANUAL
Rev. 01-16
Supervision/monitoring system TeleNET
The TeleNET supervision system allows the user to create a historical room temperature
and humidity database via Personal Computer.
To configure the instrument, refer to the TeleNET manual.
Assign the PLUS 100 PAN system address via the configuration sequence by selecting
the Ad label from the 2nd programming level (installer level) and following the normal
address attribution criteria used for TeleNET.
Temperature as detected by the controller can be displayed at the TeleNET address Ad+1
by setting the module as TWMT (temperature acquisition module).
In this way the TeleNET supervision program can simultaneously display temperature and
relative humidity as measured by the PLUS 100 PAN and build up a record of both
parameters.
Example: if parameter Ad is set to 3, relative humidity can be displayed on the TeleNET
by assigning the TWMUR module to address 3; temperature can be displayed by
assigning address 4 (obtained by summing one to the parameter Ad=3) as the TWMT
module.
N.B. The address Ad+1 can, in any case, be used by any device connectable to the
TeleNET (in place of PLUS 100 PAN temperature display) except for TWMT modules to
which a different address must be assigned so as to avoid any conflict.
PLUS 100 PAN
Pag. 26
USE AND MAINTENANCE MANUAL
Rev. 01-16
ALARMS: DESCRIPTION AND PROCEDURES
In the event of any anomalies the PLUS 100 PAN system warns the operator by displaying
alarm codes and sounding the warning buzzer inside the control panel. If an alarm is
tripped the display will show one of the following messages:
ALARM CODE
POSSIBLE CAUSE
PROCEDURE TO BE FOLLOWED
E0
Temperature sensor not working
properly (stops the system)
Check the temperature sensor
If the problem persists contact the technical
assistance service
E1
Humidity sensor not working
properly
(stops humidity control)
Check the humidity sensor
If the problem persists contact the technical
assistance service
E2
Evaporator sensor not working
properly (defrostings scheduled)
Check the evaporator sensor
If the problem persists contact the technical
assistance service
E3
EEPROM ALARM
EEPROM memory error detected.
(all outputs deactivated)
Switch off unit and switch back on
If the problem persists change the control
board
E4
Software compatibility error
Check for correct match between
MASTER board and control panel board
E6
Flat battery
Contact the technical assistance service
to have the battery replaced
EC
Compressor safeguard (e.g.
overheat or excess pressure).
(Compressor and dehumidification
output deactivated if parameter
dEU = 0 or 1)
Check compressor status
Check compressor absorption
If the problem persists contact the
technical assistance service
En
No connection between control
panel and control board
Check connections between the two units
Check for presence of ferrite on sensors
If the problem persists contact the technical
assistance service
EP
Erroneous recipe programming
(goes to stand-by)
Check recipe duration with product-ready
time and day at the moment of cycle START.
CHAPTER 7: TROUBLESHOOTING
CHAP. 7 – Troubleshooting
PLUS 100 PAN
Pag. 27
USE AND MAINTENANCE MANUAL
Rev. 01-16
EU
Humidifier alarm
(relevant output does not
deactivate)
Check specific alarm type on humidifier
control.
EF
Fan overheat safety device
(relevant output not deactivated)
Check fan absorption
If the problem persists contact the technical
assistance service
TROUBLESHOOTING GUIDE
PROBLEM
PROBABLE CAUSE
PROCEDURE TO BE
FOLLOWED
The Control Panel does
not respond and the
display is blank
Power supply fault (check connection
lead to control board).
Control board power supply not
connected.
Incorrect connection between Control
Panel and Control Board (Panel power
supply probably inverted with RS-485
signal)
Check that power
arrives at the Panel
and/or Control
Board terminals.
Check connections
between Control
Panel and Control
Board.
If the problem
persists contact the
technical assistance
service.
The Control Panel does
not respond and the
display reads En
Incorrect connection between Control
Panel and Control Board.
Connection between Control Panel and
Control Board interrupted
Invert RS-485 signal
lead connection.
Check connections
for continuity.
The PLUS 100 PAN
system generates false
alarms
Sensor(s) connected incorrectly or faulty
Check all
connections.
Check Control
Board connection
leads for continuity.
If the problem
persists contact the
technical assistance
service.
The humidity sensor
does not display the
correct humidity value
Sensor is not connected properly.
Correct type of humidity sensor not
selected.
Check that sensor is
working properly
and that connection
is correct.
The PLUS 100 PAN
system does not
respond to the
parameters set on the
configuration
Incorrect parameter settings
Check the system
configuration
settings.
CHAP. 7 - Troubleshooting
PLUS 100 PAN
Pag. 28
USE AND MAINTENANCE MANUAL
Rev. 01-16
The PLUS 100 PAN
system does not
dialogue with the
TeleNET
Connection of PLUS 100 PAN system to
the TeleNET module network has not
been made correctly
Check the
connection to the
TeleNET network.
Check attributed
address.
CHAP. 7 - Troubleshooting
PLUS 100 PAN
Pag. 29
USE AND MAINTENANCE MANUAL
Rev. 01-16
CE DECLARATION OF CONFORMITY
COSTRUTTORE / MANUFACTURER
PEGO S.r.l. Via Piacentina, 6/b 45030 Occhiobello (RO) – Italy –
Tel. (+39) 0425 762906 Fax. (+39) 0425 762905
DENOMINAZIONE DEL PRODOTTO / NAME OF THE PRODUCT
MOD.:
PLUS 100 PAN
IL PRODOTTO E’ CONFORME ALLE SEGUENTI DIRETTIVE CE:
THE PRODUCT IS IN CONFORMITY WITH THE REQUIREMENTS OF THE FOLLOWING EUROPEAN DIRECTIVES:
Direttiva Bassa Tensione (LVD): 2014/35/UE
Low voltage directive (LVD): 2014/35/EU
Direttiva EMC: 2014/30/CE
Electromagnetic compatibility (EMC): 2014/30/EU
LA CONFORMITA’ PRESCRITTA DALLA DIRETTIVA E’ GARANTITA DALL’ADEMPIMENTO A TUTTI GLI EFFETTI
DELLE SEGUENTI NORME (comprese tutte le modifiche):
THE CONFORMITY WITH THE REQUIREMENTS OF THIS DIRECTIVE IS TESTIFIED BY COMPLETE ADHERENCE
TO THE FOLLOWING STANDARDS (including all amendments):
Norme armonizzate: EN 60730-1:2011, EN 60730-2-9:2010, EN 61000-6–1:2007, EN 61000-6–3:2007
European standards: EN 60730-1:2011, EN 60730-2-9:2010, EN 61000-6–1:2007, EN 61000-6–3:2007
IL PRODOTTO E’ COSTITUITO PER ESSERE INCORPORATO IN UNA MACCHINA O PER ESSERE ASSEMBLATO
CON ALTRI MACCHINARI PER COSTITUIRE UNA MACCHINA CONSIDERATE DALLA DIRETTIVA: 2006/42/CE
“Direttiva Macchine”.
THE PRODUCT HAS BEEN MANUFACTURED TO BE INCLUDED IN A MACHINE OR TO BE ASSEMBLED
TOGHETER WITH OTHER MACHINERY TO COMPLETE A MACHINE ACCORDING TO DIRECTIVE: EC/2006/42
“Machinery Directive”.
Occhiobello (RO), 01/04/2016
CHAP. 6 - Diagnostica
Appendices
APPENDICES
PLUS 100 PAN
Pag. 30
USE AND MAINTENANCE MANUAL
Rev. 01-16
PLUS100 PAN CONNECTIONS DIAGRAM
Power section
Outputs section (free-voltage contacts)
1-2 Power supply 230VAC 50/60 Hz
21-22 Alarm
23-24 Defrost
Analogic inputs section
25-26 Dehumidification / air changeover
29-30 Evaporator sensor NTC
15-16 Stand-by
31-32 Humidity sensor 4-20 mA (0-
100Rh%) (32=V+ 31=Y)
13-14 Humidification
27-28 Ambient sensor NTC
11-12 Room light
9-10 Evaporator fans low speed (*)
Digital inputs section
7-8 Evaporator fans high speed (*)
44-50 Fan overheat safety device
5-6 Heat
43-50 Humidifier alarm
3-4 Cold
42-50 Switch door
41-50 Compressor safety device
TeleNET section:
39 A line on 2TWRS485
40 B line on 2TWRS485
(*)High speed: terminals 7-8 close, terminals 9-10 open
Low speed: terminals 7-8 open, terminals 9-10 close.
Appendices
PLUS 100 PAN
Pag. 31
USE AND MAINTENANCE MANUAL
Rev. 01-16
NOTES
PLUS 100 PAN
Pag. 32
USE AND MAINTENANCE MANUAL
Rev. 01-16
PEGO S.r.l.
Via Piacentina, 6/b
45030 OCCHIOBELLO –ROVIGOTel: 0425 762906
Fax: 0425 762905
www.pego.it
e-mail: info@pego.it
Dealer:
Loading...
