PEGATRON WAP571 User Manual

Quick Start Guide

Cisco WAP571 Wireless-AC/N Premium Dual Radio Access Point with PoE

Welcome

Thank you for choosing the Cisco WAP571 Wireless-AC/N Premium Dual Radio Access Point with PoE. The Cisco WAP571 is an indoor dual radio

802.11ac + 802.11n access point.

This guide is designed to familiarize you with the general layout of the access point, describe how to deploy the device in your network, and describe how to configure the device. Your access point has more features and functionality than what is described in this guide. For additional information, see the Administration Guide. A link to the Administration Guide is found in Where to Go From Here, page 12.

Package Contents

• Wireless Access Point

• Mounting kit

• This Quick Start Guide

• Ethernet cable

• Pointer Card with China RoHS

• Technical Support Contacts

• EU Directives 1999/5/EC Compliance Information (for EU SKU only)

Before You Begin

Before you begin the installation, make sure that you have the following equipment and services:

• A computer with browser support for:

– Internet Explorer v7.0 or later

– Chrome v5.0 or later

– Firefox v3.0 or later

–Safari v3.0 or later

• Tools for installing the hardware

• One or more Ethernet network switches with PoE

1 Cisco WAP571 Wireless Access Point

Cisco WAP571 Wireless-AC/N Premium

Dual Radio Access Point with PoE Setup Features

Front Panel

The front panel of the device consists of a single system LED. For a full description of the colors of the light and its indications, see Verifying the

Hardware Installation, page 6.

A Kensington lock slot is found under the lights.

Back Panel

The back panel of the device has two RJ-45 Ethernet ports. Facing the back of the device, the right port (labeled “ETH0/PD”) is an 802.3at &

802.3af Power over Ethernet (PoE) port which is used to power your device. The left port (labeled “ETH1”) is a general Gigabit Ethernet LAN interface. Both are auto-sensing, Gigabit Ethernet (802.3) ports used to connect your WAP devices to network devices, such as computers, routers, or switches. We strongly recommend that you use a Category 5e or better cable for Gigabit connectivity.

The side panel of the device has a Reset button. See Rebooting the

Devices or Returning them to their Factory Default Settings, page 10

for information on the Reset button.

Default Setting

Parameter Default Value

Username cisco Password cisco LAN IP Address DHCP address assigned

by server Fallback LAN IP 192.168.1.245 Subnetwork Mask 255.255.255.0

If you are using a Cisco RV Series router, the default range for the DHCP assigned address is from 192.168.1.100 to 192.168.1.254. Any device connecting to the same LAN will be assigned an IP address in this range.

If your network does not have an existing DHCP server, the WAP571 will start a DHCP server for WLAN stations and stop the DHCP client when WAP571 is in factory default. The DHCP server will assign the IP address from 192.168.1.20 to 192.168.1.100.

Cisco WAP571 Wireless Access Point 2

Mounting the Cisco WAP571 Wireless-AC/

N Premium Dual Radio Access Point with PoE Setup

You can place your access point on a desktop, or mount it on a wall or ceiling.

Placement Tips

• Ambient Temperature—To prevent the access point from overheating,

do not operate it in an area that exceeds an ambient temperature of 104°F (40°C).

•Air Flow—Both side panels have vents that must be unobstructed to prevent overheating.

• Mechanical Loading—The device should be level, stable, and secure to prevent it from sliding or shifting out of position.

Wall and Ceiling Mounting

The Cisco WAP571 device can be wall or ceiling-mounted. A mounting kit is packaged with your device. The kit is designed to install your device to the wall or the ceiling.

The mounting bracket has some flexibility so that you can reuse existing holes drilled for a Cisco WAP551 or WAP561 device. The installer can remove the Cisco WAP551 or WAP561 and mount the Cisco WAP571.

The dimensions for the mount kit screws are as follows:

1 .31 to .33 in

(7.8 to 8.3 mm)

3 Cisco WAP571 Wireless Access Point

2 .86 to .88 in (21.8

to 22.3 mm)

3 .22 to .24 in

(5.5 to 6.0 mm)

4 .69 to .72 in

(17.5 to 18.2 mm)

WARNING Insecure mounting might damage the device or cause injury.

Cisco is not responsible for damages incurred by insecure wall or ceiling mounting.

To mount the Cisco WAP 571 device to a wall or ceiling:

STEP 1 Determine where you want to mount the device. Verify that the

surface is smooth, flat, dry, and sturdy.

STEP 2 Drill two pilot holes into the surface 2.75 inches (70 mm) apart for

your Cisco WAP device.

STEP 3 Insert a screw into each hole, leaving a gap between the surface

and the base of the screw head.

STEP 4 Place the upper slots of the bracket over the screws, adjust the

screws accordingly, and slide the bracket down until the screws fit snugly into the slots.

STEP 5 Using the bracket as a template, drill two more holes for the lower

screws.

STEP 6 Insert a screw into each lower hole.

STEP 7 Slide the WAP device into the bracket, placing the cable through

the break-out tab found in the back of the bracket.

Connecting the Cisco WAP571 WirelessAC/N Premium Dual Radio Access Point with PoE Setup

The WiFi default SSID is “Cisco SB-Setup” with the passphrase “cisco123” in WPA2-PSK AES. This wireless default configuration will not allow traffic between WiFi and Ethernet; users will need to go through the setup wizard to resume the traffic between WiFi and Ethernet.

The user can also perform the initial configuration using a wired Ethernet connection.

To connect the device to the wired network:

STEP 1 Connect the Ethernet cable to the Ethernet port of a PoE switch.

STEP 2 Connect the other end of the network Ethernet cable to the

Ethernet port (PoE) of the wireless access point.

Cisco WAP571 Wireless Access Point 4

OTE WAP571 bundles the two Ethernet ports to be link

aggregation mode. If the two Ethernet ports have been connected at the same time, the link partner must also support link aggregation.

After installation, all lights should be active. Refer to Verifying the

Hardware Installation, page 6 for details about the different lights on each

switch.

5 Cisco WAP571 Wireless Access Point

Verifying the Hardware Installation

To verify the hardware installation, complete the following tasks:

• Check the cable connections.

• Check the state of the indicator lights.

Label Activity Description

Power

LAN

NOTE If you need help resolving a problem, visit the Cisco Support

Community at www.cisco.com/go/smallbizsupport.

Off The WAP571 is out of power. Solid (Green) The Cisco WAP571 is normal; no wireless

client connected.

Solid (Blue) The Cisco WAP571 is normal; at least one

wireless client connected. Flashing (Blue) The Cisco WAP571 is upgrading the firmware. Solid (Red) The Cisco WAP571 fails to boot with both

firmware images. Off No Ethernet link; FE Ethernet link is active or

10Mbps. Solid Green GE Ethernet link is active. Flashing Green The WAP 571 is transmitting or receiving data.

Cisco WAP571 Wireless Access Point 6

Getting Started with the Configuration

To configure the wireless access points, you can either use Ethernet or wireless. Please follow these steps to access the Wizard and then the web-based configuration utility from your computer by Ethernet:

STEP 1 Ethernet: Connect the wireless access point to the same network

(IP subnet) as your computer. The factory default IP address configuration of the access points is DHCP. Make sure your DHCP server is running and can be reached.

See Incorrect IP Address, page10 for troubleshooting information, or if you do not have a DHCP server.

Wireless: Search the wireless SSID "CiscoSB-Setup", and connect to this SSID with the passphrase "cisco123".

STEP 2 Locate the IP address of the wireless access point.

a. The wireless access points can be accessed and managed by

Cisco network tools and services including the Cisco FindIT Network Discovery Utility that enables you to automatically discover all supported Cisco devices in the same local network segment as your computer. You can get a snapshot view of each device or launch the product configuration utility to view and configure the settings. For more information, see

www.cisco.com/go/findit.

b. The wireless access points are Bonjour-enabled and

automatically broadcast their services and listen for services being advertised by other Bonjour-enabled devices. If you have a Bonjour-enabled browser, such as Microsoft Internet Explorer with a Bonjour plug-in, or the Apple Mac Safari browser, you can find the wireless access point on your local network without knowing its IP address.

You can download the complete Bonjour for Microsoft Internet Explorer browser from Apple’s website by visiting:

http://www.apple.com/bonjour/

c. Locate the IP address assigned by your DHCP server by

accessing your router or DHCP server. See your DHCP server instructions for more information.

STEP 3 Launch a web browser, such as Microsoft Internet Explorer or

Mozilla Firefox.

STEP 4 In the Address field, enter the default DHCP address and press the

Enter key.

7 Cisco WAP571 Wireless Access Point

TEP 5 Enter the default user name of cisco and password of cisco in the

User Name and Password fields.

STEP 6 Click Login. The Wireless Access Point Setup Wizard appears.

STEP 7 Follow the Setup Wizard instructions to finish the WAP device

installation. We strongly recommend that you use the Setup Wizard for the first installation.The Setup Wizard turns on the Wi-Fi radio, which allows you to connect wirelessly. For more advanced configurations, see the Administration Guide. A link to the Administration Guide is found in Release the Reset button when

the system light turns on., page 11.

Congratulations, you can now start using your wireless access point.

Suggested Next Steps

Smart PoE

Smart PoE is designed for detecting the power level from the PSE (Power Sourcing Equipment) side; it does not matter whether 802.3at or 802.3af mode, the WAP571 will operate at the appropriate mode automatically.

Smart PoE ensures that the WAP571 remains functional once powered by

802.3af PSE, and intelligently to adjust operations below:

• Second Ethernet port disabled

• 2.4-GHz 802.11n radio in 2x2:2 spatial-stream mode

• 5-GHz 802.11ac radio operates without restrictions

In case of an error while installing, try the following troubleshooting procedures described in this section:

Troubleshooting

If you cannot display the configuration utility, you can test the ability of the computer to communicate with the device by using ping.

To u s e ping on a computer running Windows:

Cisco WAP571 Wireless Access Point 8

STEP 1 Verify that the Cisco WAP571 is powered on and the lights indicate

the appropriate links.

STEP 2 Locate the device’s IP address. While there are different ways to

locate your device’s IP address, this procedure uses Cisco FindIT.

a. If you have previously downloaded Cisco FindIT, open Internet

Explorer and launch Cisco FindIT. For more information on downloading Cisco FindIT, see www.cisco.com/go/findit.

b. In the Cisco FindIT display, place your mouse over the device’s

name. The device IP address is displayed along with other device information.

STEP 3 Open a command window by choosing Start > Run and enter

cmd.

STEP 4 At the command window prompt, enter ping and the device IP

address. In this example, we pinged 192.0.2.10.

If successful, you should get a reply similar to the following:

Pinging 192.0.2.10 with 32 bytes of data: Reply from 192.0.2.10: bytes=32 time<1ms TTL=128

If it fails, you should get a reply similar to the following:

Pinging 192.0.2.10 wit h 3 2 b y tes of data : Request timed out.

Possible Cause of Installation Failure

No Power

• Power up the switch and your computer if they are turned off.

• Make sure your PoE switch is powered on and the lights indicate that

you have a link. See Verifying the Hardware Installation, page 6.

• Verify that the devices on your network are not plugged into a switchable outlet.

Bad Ethernet Connection

• Check the state of the indicator lights. See Verif ying the Hardware

Installation, page 6.

• Check the Ethernet cable to ensure that it is firmly connected to your

devices. Devices connected by the Ethernet cable can include the WAP device, and routers, any switches, and your computer.

• Verify the connected switch has auto-negotiation enabled. The access point and the switch need the same negotiation parameters set.

9 Cisco WAP571 Wireless Access Point

Bad Image

After a new firmware installation, if the Power light is solid red, contact system support; see Release the Reset button when the system light

turns on., page 11.

Incorrect IP Address

The most likely cause of connectivity failure is an incorrect IP address. The Web browser may be pointing to the wrong IP address, or your computer may be configured with an IP address that is not in the same subnet as the device.

Because the factory default IP address configuration is DHCP, make sure that your DHCP server is running and can be reached. You may need to disconnect and reconnect the devices for them to discover their new IP addresses from the DHCP server. You can then query the DHCP server for the new IP address. See Step 2 of Getting Started with the

Configuration, page 7 for more information on how to find the DHCP

address.

If the wireless access points do not receive a DHCP response (there is no DHCP server on your network) after 60 seconds, the access points will fallback to the following default static IP address: 192.168.1.245 and a default mask of 255.255.255.0. To reach that IP address, be sure that your computer is on the 192.168.1.xxx network.

Rebooting the Devices or Returning them to their Factory Default Settings

To reboot your device:

• The Cisco WAP571 uses PoE power supply; unplug your Ethernet

connection and plug it back in.

• With the power on, press the Reset button with an opened paper clip for less than three seconds, or until the lights go off.

– When all the lights go off, release the Reset button.

– Release the Reset button as soon as the lights go off, or you will

restore the device to factory default settings and lose your configurations.

Cisco WAP571 Wireless Access Point 10

• Release the Reset button when the system light turns on.

11 Cisco WAP571 Wireless Access Point

Where to Go From Here

Support

Cisco Support Community

Cisco Support and Resources

Phone Support Contacts www.cisco.com/en/US/support/

Cisco Firmware Downloads

Cisco Open Source Requests

Cisco Partner Central (Partner Login Required)

Product Documentation

Cisco WAP571 Administration Guide

Cisco Power Adapters www.cisco.com/go/wap_accessories

www.cisco.com/go/smallbizsupport

www.cisco.com/go/smallbizhelp

tsd_cisco_small_business _support_center_contacts.html

www.cisco.com/go/smallbizfirmware

Select a link to download firmware for Cisco Products. No login is required.

www.cisco.com/go/ smallbiz_opensource_request

www.cisco.com/web/partners/sell/smb

www.cisco.com/go/300_wap_resources

Cisco WAP571 Wireless Access Point 12

To reset the device to factory default settings:

• With the power on, press and hold the Reset button with an opened

paper clip for more than 10 seconds. The system light will go off.
