PEGATRON VJZ12AD11L, VJ8WRC1, VJ8WKB1 Users Manual

Start Guide

X-XXX-XXX-01 (1)

Personal Computer

VAIO® Z Canvas

VJZ12A

Printed in Japan

© 2015 VAIO Corporation

Parts and Controls

2

Parts and Controls on the Front

ȪȩȬȫ

Ȯ

ȭ

Ȳ

ȯ

Ȱ

ȱ

L button



Air exhaust vent



Built-in monaural microphone



R button



Built-in front camera indicator



! Notes

• Be aware that the exhaust vent may be heated while your VAIO computer is in operation.

• To keep the touch screen clean and protect it from scratches, attach the wireless keyboard to your VAIO computer before carrying

around the computer. For attaching the wireless keyboard, see Charging the Wireless Keyboard.

Built-in front camera



Touch screen



(Windows) Touch button



Charge port for Keyboard



Built-in stereo speaker



Parts and Controls on the Sides

3

Headset compatible headphone jack

 

ȩ

Ȫ

ȫ

Ȭ

ȭ

Ȯ

USB port



USB port



This port can be used for USB charging.

SD memory card slot



Mini DisplayPort output port



HDMI output port



LAN port

 





Charge indicator

DC IN port

ȯ

Ȱ
ȱ
