PEGATRON UPWL6580 User Manual

Manual

Unihan UPWL6580

 Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following

i. This device may not cause harmful interference, and

ii. This device must accept any interference received, including interference that may cause

undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

i. Reorient or relocate the receiving antenna.

ii. Increase the separation between the equipment and receiver.

iii. Connect the equipment into an outlet on a circui t different from that to which the receiver is

connected.

iv. Consult the dealer or an experienced radio/TV technician for help.

CAUTION! You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subj ect to the following two conditions: (1) this device may not cause interf erence, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

(

)

This radio transmitter (identify the device by certification number, or model number if Category II) has been approved by Industry Canada to operate with the antenna types listed bel ow wi th the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

No. Ant. Cat. Ant. Type Brand Part No. G

dBi

1 Integral PCB Wanshih UC3WFI0057 1.99 2 Integral PCB Wanshih UC3WFI0058 2.08 3 Integral PCB Wanshih UC3WFI0090 2.03 4 Integral PCB Airgain N5X20B (6.5cm) 1.70 5 Integral PCB Airgain N5X20B (10cm) 1.70 6 Integral PCB Airgain N5X20SC 1.90

 Safety statements

Regulatory Information/Disclaimers

Installation and use of this device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (includi ng the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution of the connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines.

CAUTION! To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance [20cm] between the radiator and your body. Use on the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations.

 Safety Information

In order to maintain compliance with the FCC RF exposure guidelines, this equipment should be installed and operated with minimum distance [20cm] between the radiator and your body. Use only with supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. CAUTION! Any changes or modifications not expressly approved in this manual could void your authorization to use this device. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

 MPE Statement

Your device contains a low power transmitter. When device is transmitted it send s out Radio Frequency (RF) signal.

 FCC Radio Frequency Exposure

This device has been evaluated under FCC Bulletin OET 65C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247(b)(4) addressing RF Exposure from radio frequency devices. The radiation output power of this device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation – as a mobile or portable device but use in a body-worn way is strictly prohibit. When using this device, a certain separation distance between antenna and nearby persons has to be kept to ensure RF exposure compliance. In order to comply with the RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than [20cm].

 RF Exposure

The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolle d environ ment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

The final end product must be labeled in a visible area with the following " Contains TX FCC ID: VUIUPWL6580".

This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains transmitter module IC: 7582A-UPWL6580”.
