Page 1
3"
(76 mm)
P246LF \ P246LF-M
P246LF-BN
P246LF-BN-M
1 17/32"
(39 mm)
2 15/32"
(62 mm)
4"
(102 mm)
1 7/8 "
(48 mm)
3 15/32"
(88 mm)
2 X 1/8"~1 1/2"
(29~38mm)
Hole Size
2 1/8"
(54 mm)
Dia.
1 5/8"
(42 mm)
to
2 3/8"
(61 mm)
11 7/8"
(302 mm)
1/2"-14 NPSM
4"
(102 mm)
Centers
6 1/2"
(165 mm)
3 5/16"
(84 mm)
2 1/8"
(54 mm)
Dia.
2 27/32"
(72 mm)
1"
(25 mm)
Max. Deck
Thickness
1 17/32"
(39 mm)
2 1/8"
(54 mm)
models P246LF & P246LF-BN with plastic pop-up
drain assembly, and models P246LF-M & P246LF-BN-M
with metal pop-up drain assembly.
;
STANDARD SPECIFICATIONS
• Maximum flow rate 1.5 gpm @ 60 PSI, 5.7 L/min @ 414 kPa.
WARRANTY
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes; or
for commercial users, for 5 years from the date
of purchase.
• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
to
from the date of purchase. No warranty is provided
on batteries.
5 13/32"
(137 mm)
PSP-L-P246LF Rev. B
1 3/8"
(35 mm)
Dia.
1 1/4"
(32 mm)
Dia.
4 9/16"
(116 mm)
1 3/8"
(35 mm)
Dia.
1 1/4"
(32 mm)
Dia.
IAPMO R&T
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC/ANSI A117.1
• EPA WaterSense®
• Verified compliant with 0.25% weighted
average Pb content regulations.
