Page 1
Pressure (kPa)
Mounting without escutcheon plate:
7 1/16"
(180mm)
120° Swing Spout
P18550LF
P18550LF-SD
P18550LF-SD-W
8 1/16"
(205mm)
5 3/8"
(137mm)
7 1/16"
(180mm)
9 1/16"
(230mm)
1 1/2"
(38 mm)
Max. Deck
Thickness
Mounting with escutcheon plate:
7 1/16"
(180mm)
120° Swing Spout
1 13/16"
(46mm)
2 X1 5/16"~1 1/2"
(33~38mm)
Hole Size
1/2"-14 NPSM
3 1/8"
(79mm)
2 15/16"
(74mm)
8 1/16"
(205mm)
P18550LF
P18550LF-SD
P18550LF-SD-W
KITCHEN FAUCET
Single handle, lever, pull-out kitchen faucet,
2 function wand.
STANDARD SPECIFICATIONS
Single handle kitchen faucet for exposed mountings
on 1 and 3 hole sinks with 8" centers. (P18550LF only)
Single handle kitchen faucet for exposed mountings on 2 and
4 hole sinks with 8" centers. (P18550LF-SD & P18550LF-SD-W)
Standard 7 1/16" (180mm) long spout swings 120 .
Replaceable rotating ball valve with replacerble non-metallic seats.
1/2"- 14 NPSM threaded male inlet adapters.
5 15/16"
(150mm)
6 9/16"
(167mm)
8 9/16"
(217mm)
1/2"-14 NPSM
PSP-K-P18550LF Rev. C
1"
(25 mm)
Max. Deck
Thickness
4 X1 5/16"~1 1/2"
8"
(203mm)
10 1/4"
(260mm)
1 13/16"
(46mm)
(33~38mm)
Hole Size
8 9/16"
(218mm)
3 1/8"
(79mm)
2 15/16"
(74mm)
8 1/16"
(205mm)
WARRANTY
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and
for commercial users, for 5 years from the date
of purchase.
• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries.
0 69 138 207 276 345 414 483 552 621
6
5
4
3
2
1
0
Flow (U.S. Gallons Per Minute)
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
inishes; or,
22.7
Flow (Liters Per Minute)
18.9
15.1
11.4
7.6
3.8
0
